FAST TRACK
BOTTOM KEY
XGA LCD MULTIMEDIA PROJECTOR
ENGLISH
1. Place the projector on a stable, hard
SETTING UP
surface at the desired distance from
the projection screen.
2. Connect the computer source
equipment to the computer connector
port of the LCD projector.
3. Connect video sources if required,
using the supplied A/V cable. If
necessary use SCART adapter.
4. Connect one end of the mouse cable
marked ‘LCD’ into the mouse port on
the LCD projector and the other end
marked ‘MA’ (Mouse Adapter) into the
appropriate mouse adapter,
determined by which mouse type you
are using.
5. Ensure the ventilation grills on the
LCD projector are not obstructed.
Apply mains power to the projector.
Remember to switch on the unit at the
Power ON/OFF switch!
6. Apply mains power to the various
items of source equipment.
Improper use of this LCD projector
may cause a risk of damage or personal
injury due for example to electric shock or
the strong light source. Detailed safety
instructions are given in the user guide and
these must be followed at all times.
USING THE REMOTE CONTROL
RESET
CONTR BRIGHT VOLUME
COMPUTER
MASK SCALE PAN
TRACKERBALL
PLATE
LEFT KEY
The key functions explained:
KEY FUNCTION
RESET
ON/OFF
CONTR
BRIGHT
VOLUME
FREEZE
COMPUTER
VIDEO
S-VIDEO
MASK
SCALE
PAN
PROG
POINTER
LIGHT
MENU
TRACKBALL
LEFT KEY
RIGHT KEY
BOTTOM
KEY
Defaults to the standard
settings for active source
Turns the projected image
ON/OFF.
Alters the contrast of light
and dark colors.
Alters the brightness.
Volume up/down
Holds the image projected
on the screen
Computer source active.
Video source active.
S-video source active.
Applies mask to the image.
Direct 1:1 mapping/scaling.
Allows panning within
oversized images.
Programmed menu
selection
Applies a trackball-controlled
pointer to the screen.
Keys are illuminated.
Activates the menu system.
Simulates the actions of the
desktop mouse.
Emulates left mouse key.
Emulates right mouse key.
Click-and-hold function
(drag).
ON/OFF
MUTE
FREEZE
S-VIDEO
VIDEO
PROG
MENU
LIGHTPOINTER
RIGHT KEY
TRACKERBALL
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
TABLE OF CONTENTS
1 SYMBOL DESCRIPTIONS....................................................................5
2 SAFETY INSTRUCTIONS.....................................................................5
3 INTRODUCTION ...................................................................................9
3.1 YOUR LCD PROJECTOR.....................................................9
4 MAIN FEATURES ...............................................................................10
5 SUPPLIED MATERIAL........................................................................11
5.1 WHEN YOU OPEN THE LCD PROJECTOR PACKAGE......11
5.2 OPTIONAL MATERIAL.......................................................11
5.3 GLOSSARY........................................................................12
6 SETTING UP THE LCD PROJECTOR.................................................13
6.1 SAFETY PRECAUTIONS .................................................... 13
6.2 ARRANGEMENTS IN THE PROJECTION ROOM ............... 14
6.3 SELECTING ADDITIONAL ADAPTERS AND CABLES........15
6.3.1 FOR YOUR COMPUTER SOURCE....................15
6.3.2 FOR VIDEO SOURCES......................................15
6.3.3 FOR YOUR MOUSE ........................................... 16
6.4 MAKING THE CABLE CONNECTIONS...............................17
6.5 IMAGE ADJUSTMENTS......................................................18
7 USING THE LCD PROJECTOR ..........................................................21
7.1 TRACKBALL REMOTE CONTROL .....................................21
7.2 TOP PANEL KEYBOARD....................................................24
7.3 THE MENU SYSTEM..........................................................24
7.3.1 THE SET-UP MENU SELECTIONS ....................24
7.3.2 THE PICTURE SELECTIONS.............................25
7.3.3 THE SOUND SELECTIONS................................25
7.3.4 THE OPTIONS SELECTIONS ............................26
7.3.5 THE HELP SELECTIONS...................................26
8 SPECIAL FEATURES OF YOUR LCD PROJECTOR ........................... 27
8.1 COOLING SYSTEM ............................................................ 27
8.2 SET-UP MEMORY..............................................................27
8.3 OSD SYSTEM ....................................................................27
8.4 RESET ...............................................................................28
9 CEILING MOUNTING..........................................................................29
9.1 SELECTING A MOUNT.......................................................29
9.2 MOUNTING IN THE CEILING.............................................29
9.3 WIRING..............................................................................30
10 TROUBLE-SHOOTING .....................................................................31
11 MAINTENANCE ................................................................................33
11.1 GENERAL.........................................................................33
11.2 LAMP REPLACEMENT.....................................................33
11.3 LAMP REPLACEMENT MESSAGES.................................34
3
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
11.4 FUSE REPLACEMENT.....................................................36
11.5 CARE OF THE REMOTE CONTROL ................................37
12 TECHNICAL DATA ............................................................................ 38
12.1 GENERAL ENVIRONMENTAL LIMITS..............................38
12.2 LCD PROJECTOR UNIT...................................................39
12.3 POWER SUPPLY.............................................................39
12.4 REMOTE CONTROL ........................................................40
12.5 COMPATIBILITY...............................................................40
13 CONNECTORS.................................................................................41
13.1 COMPUTER .....................................................................41
13.2 MOUSE ............................................................................42
13.3 S-VIDEO...........................................................................42
13.4 VIDEO..............................................................................42
13.5 AUDIO..............................................................................42
14 ENVIRONMENTAL STATEMENT......................................................43
15 FCC STATEMENT.............................................................................44
This publication is printed on recycled paper
The information contained in this User Guide is preliminary, and the
products described herein are subjected to change without prior notice.
4
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
1 SYMBOL DESCRIPTIONS
DANGEROUS VOLTAGE
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltages” within the product
housing that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
WARNING
This symbol is used on the product to alert the user of
important operating and maintenance (servicing)
instructions, and also used in the product literature to
indicate important safety-related information.
HOT
This symbol is used on the product to make the user aware
of hot surfaces, i.e. fan ventilation grill.
NOTE
This symbol is used in this publication to highlight
information for the user.
2 SAFETY INSTRUCTIONS
Read instructions - All the safety and operating
instructions should be read before the projector is
operated.
Retain instructions - The safety and operating
instructions should be retained for future reference
Heed warnings - All warnings on the projector and in
the User Guide should be adhered to. If ignored, use
of this projector may cause death, injury or material
damage.
5
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
The normal operating life for the lamp is 750 hours.
High-pressure lamp may explode if improperly used.
Refer all servicing to authorized personnel only.
1. Water and Moisture - The projector is designed for indoor use only
and should not be used near water and moisture.
2. Carts and Stands - Place the projector on a stable, hard surface in a
manner that does not obstruct ventilation ports and openings in the
cabinet. Unstable carts, stands, tables, etc. may cause the projector to
fall, which may cause serious injury to people and/or the projector.
3. Ventilation - Slots and openings in the cabinet are provided for
ventilation. To ensure reliable operation of the projector and protection
from overheating, do not block or cover slots and openings in any way.
Do not place the projector on any soft surface or close to a heating
source, radiator, etc. Never install the projector in an enclosed unit.
4. Heat - The projector should be situated away from heat sources such
as direct sunlight, radiators, stoves or other strong heat sources.
5. Power Sources - The projector must only be connected to proper
electrical voltage as marked on the projector body. The projector
should be connected to electrical outlet using a power cord compatible
with the local electrical voltage. If you are not sure about the type of
electrical service at your location, consult your projector dealer or local
power company.
6. Power Cord Protection - Power cords should be routed so that they
are not likely to be walked on, pinched or unduly bent by items placed
upon or against them. Pay particular attention to cords and cables at
the point where they exit from the projector.
6
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
7. Cleaning - The projector should be cleaned only as recommended,
see the Maintenance section. Disconnect the power cord from the
power outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners.
8. Non-use Periods - The power cord of the projector should be
unplugged from the outlet when left unused for a long period of time.
9. Damage Requiring Service - The projector should be serviced only by
authorized service personnel when;
• the power supply cord or the plug has been damaged,
• objects have fallen, or liquid spilled, into the projector,
• the projector has been exposed to water or condense,
• the projector does not appear to operate normally (fan not
working, noise, smell, smoke, heat etc.)
• the projector has been dropped or damaged.
10. Object or Liquid Entry - Care should be taken so that objects do not
fall into the projector casing. Be careful not to spill liquids into the
inside of the projector. Do not insert metal or flammable objects into
the projector.
11. Servicing - The user should not attempt to perform unusual or
technical service to the projector. Do not open the unit. Refer all
servicing to authorized service personnel.
12. Grounding or Polarization - Precautions should be taken so that
grounding or polarization of a projector is maintained. Do not use a
three prong to a two prong adapter.
To prevent electric shock, do not use the polarized ac plug
with an extension cord, receptacle or other outlet unless
the blades can be fully inserted to prevent blade exposure.
14.Lamp Replacement - Do not attempt to replace lamp. Contact an
authorized service centre for lamp replacement.
15.Abnormality - If you detect an abnormal smell or smoke, immediately
turn off the power switch. Disconnect the power plug from the power
switch to prevent fire or electric shock.
7
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
16.Lifting/moving - When the projector is to be moved, let the unit cool
down completely, cover the lens, disconnect the power plug from the
power outlet and disconnect all external cords and cables to prevent
damage that may cause a fire, electric shock, etc. Be careful when
lifting and carrying the unit as it is heavy.
17.Lamp Beam - Do not look directly into the projector or lens when
operating the projector. The lamp emits rays which may cause eye
injury and/or sunburns.
18.Electrical Shock - To reduce risk of electrical shock do not open the
unit. Refer all servicing to authorized personnel only.
8
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
3 INTRODUCTION
The first time user will be introduced to the XGA LCD multimedia projector
and its capabilities through easy-to-read text and illustrations. Then a stepby-step illustrated connection procedure leads you through to problem-free
operation.
For the more experienced user, the later sections of this manual provide a
handy reference guide to help you get the most out of your LCD projector.
3.1 YOUR LCD PROJECTOR
Congratulations on purchasing this state-of-the-art, high resolution LCD
projector. This projector can be connected to most computer and video
sources, for the best projection results and maximum compatibility.
The XGA LCD multimedia projector displays bright vivid images in 16.7
million colors simultaneously, at XGA resolution, making it the ideal choice
for presenting computer generated text and graphics, as well as live video
with full sound capability.
Applications include multiple-menus and typical Windows and Workstation
environments, including Internet applications and CD-ROM based
multimedia presentations in any situations where a small or large audience
shares information.
Please spend some time reading this manual to get familiar with the
product, so that you can get the most out of your new LCD projector.
9
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
4 MAIN FEATURES
The unit employs the following important features that in total provide you
with a highly functional and powerful projector:
• High brightness 575 Watt illumination system
• True XGA 1024 x 768 resolution
• 640 x 480 to 1280 x 1024 image compatibility
• 16.7 million colors
• 2 x 5 W stereo High Fidelity sound system
• Trackball remote control
• On screen display (OSD) and menu system
• User’s source settings memorized
• Low noise cooling system
• False light blocking
• Prepared for ceiling mounting
10
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
5 SUPPLIED MATERIAL
5.1 WHEN YOU OPEN THE LCD PROJECTOR PACKAGE
A complete set includes the following components :
1. LCD Projector 7. Mouse Adapter PC (Y-Split)
2. A/V cable 8. Power Cord
3. SCART Adapter 9. Remote Control
4. VGA/XGA V-Split Cable 10. Batteries
5. BNC V-Split Cable 11. User Guide
6. Mouse Cable
5.2 OPTIONAL MATERIAL
Optional cables, adapters and accessories are available. Consult your
dealer for further information.
11
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
5.3 GLOSSARY
Take a closer look at the LCD projector itself. The following terms are used
throughout this user guide to identify the different parts of the LCD
projector, or to refer to certain ancillary items.
VENTILATION SLOTS
POWER STATUS INDICATOR
TOP PANEL KEYBOARD
PROJECTION LENS
HANDLE
LCD PROJECTOR UNIT
LENS CAP
FOCUSING RING
HEIGHT ADJUSTMENT RING
DESKTOP MOUSE
IR RECEIVER
MAINS POWER PORT
CONNECTOR PANEL
WITH CONNECTOR PORTS
REMOTE CONTROL
POWER ON/OFF SWITCH
FUSE HOLDER
12
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
6 SETTING UP THE LCD PROJECTOR
6.1 SAFETY PRECAUTIONS
Switch off all equipment before connecting together the
various items. Be aware of static electricity that may build
up, especially in the dry season and when operating on
synthetic carpets. Discharge any static electricity by
touching a metallic surface before you start.
Do not cover the ventilation grills in front and on top of the
projector housing, as this will prevent cooling. Also make
sure to place the projector on a flat, hard surface to avoid
blocking the air inlet at the bottom of the unit. A thermal
safety switch will cut off the illumination system if the
ventilation is reduced.
Do not connect any devices or cables other than those
supplied with the LCD projector into the connector ports on
the projector unit, even if the connector ports appear
identical, as this voids any warranty and may cause
permanent damage to the projector, and to the connected
source apparatus.
13
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
MINIMUM
MAXIMUM
DISTANCE
1.26m/ 49
”
2.00m/ 79
”
3.00m/ 118
”
3.90m/ 154
”
DIAGONAL
0.81m/ 32
”
1.36m/ 53
”
2.10m/ 83
”
2.73m/ 107
”
WIDTH
0.65m/ 25
”
1.09m/ 43
”
1.68m/ 66
”
2.18m/ 85
”
HEIGHT
0.49m/ 19
”
0.82m/ 32
”
1.25m/ 49
”
1.64m/ 64
”
6.2 ARRANGEMENTS IN THE PROJECTION ROOM
Place the LCD projector on a table, or other stable hard surface, at the
distance required to give the desired size of projected image on the wall.
The image should be projected onto a flat surface screen with high
reflectivity to get a bright and undistorted image.
The best viewing results are obtained in a dimmed room with no direct
sunlight shining in. Try to ensure also that the projected image is visible to
the whole audience by placing source equipment where it will not obscure
viewing. The LCD projector is provided with extra long cables for this
purpose.
(Actual projection distances and screen sizes may vary)
14
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
6.3 SELECTING ADDITIONAL ADAPTERS AND CABLES
The projector is compatible with a wide variety of computer and video
sources, utilizing many different connectors. To be able to connect to these
various sources, a set of cables and cable adapters are provided.
6.3.1 FOR YOUR COMPUTER SOURCE
The projector is supplied with one VGA type and one BNC type cable.
Optionally, adapter kits for Macintosh and 13W3 type computers are
available.
The VGA cable can be connected directly, or using a cable adapter,
depending on the type of connector used on your computer. See the table
below. One adapter is fitted at the computer end, the other adapter is fitted
at the monitor end.
The BNC cable may be used with computers with various connectors on
the computer side, but with a BNC type connector on the monitor. Use the
monitor cable, supplied with your computer, to connect to the BNC cable at
the computer end. The monitor branch connects directly to the BNC
connectors on the monitor.
COMPUTER ADAPTER
PC or compatible fitted with a
VGA, SVGA, XGA or SXGA
graphics adapter
Macintosh Set of two MAC adapters with VGA
Workstation with 13W3 type
connector on graphics adapter
Workstation with BNC
connectors (on monitor) and
various connector types on
graphics adapter
No adapter required. Connect
directly using VGA cable.
cable
Set of two 13W3 adapters with
VGA cable
No adapter required. Use original
monitor cable (supplied with your
computer) to connect to computer
end, then connect other branch to
monitor.
6.3.2 FOR VIDEO SOURCES
A combined composite video and stereo sound cable (the AV cable) is
supplied standard with your projector. This cable connects directly to
phono connectors on the video source. A SCART adapter is also supplied
that fits the AV cable.
15
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
S-video is connected using an optional cable. S-video can potentially
provide better video quality, as the color and luminance signals are
separate. Composite video, where the two signals are superimposed, yields
less resolution in image detail.
For RGB video, use the VGA or BNC cable. RGB should potentially yield
the best video signals, since the primary colors are completely separate.
6.3.3 FOR YOUR MOUSE
The mouse cable is connected through appropriate adapters according to
the table below.
MOUSE ADAPTER Y-SPLIT AVAILABILITY DRIVER
Microsoft
serial
mouse
compatible
Macintosh
ADB-bus
mouse
PS/2 PS/2 No Option
PC
Serial
MAC Yes Option
Yes Supplied
No Option
Microsoft
or 100%
compatible
driver.
Selfdetecting
Selfdetecting
16
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
6.4 MAKING THE CABLE CONNECTIONS
1. Place the projector on a stable, hard surface at the desired distance
from the projection screen.
2. Connect the computer source equipment to the computer connector
port of the LCD projector:
- PC: Insert the end of the VGA cable marked ‘LCD’ into the
COMPUTER connector port on the LCD projector. Connect the
connector marked ‘Monitor’ onto your monitor cable, and the
connector marked ‘VGA’, into the VGA port on the PC unit. If you
do not intend to use a monitor then just leave the short cable
section unconnected.
- MAC: Follow the above sequence, but insert applicable MAC cable
adapters as marked at the computer and monitor ends of the VGA
cable.
- WS: Follow the above procedure, but either use BNC type cable, attach
directly to monitor and through your original monitor cable to
computer, or alternatively use VGA cable and 13W3 adapters at
computer and monitor ends.
3. Connect video sources if required, using the supplied A/V cable. If
necessary use SCART adapter.
4. Connect one end of the mouse cable marked ‘LCD’ into the mouse port
on the LCD projector and the other end marked ‘MA’ (Mouse Adapter)
into the appropriate mouse adapter, determined by which mouse type
you are using.
5. Ensure the ventilation grills on the LCD projector are not obstructed.
Apply mains power to the projector. Remember to switch on the unit at
the Power ON/OFF switch!
6. Apply mains power to the various items of source equipment.
Your LCD projector is now fully connected up. Before use for your
presentation, refer to the next section on Image Adjustments to attain the
highest quality of projected image.
17
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
6.5 IMAGE ADJUSTMENTS
The infrared remote control is the main user interface by which the device
settings are adjusted. The remote control keys are used to adjust the
settings of the LCD projector correctly, either directly or through the menu
system, so as to achieve the best possible viewing conditions.
Set-up should be performed once with the source(s) you are using most
frequently. Allow some minutes for the unit to warm up before adjusting
the settings. Many settings will automatically be memorized individually for
each source for future use (see Using the LCD Projector).
OPERATION
LENS
• Use focusing ring on projection lens to sharpen the
image on the screen.
FREQ
• Select FREQUENCY in the MENU.
• With data from a source displayed on-screen, set the
background to a chequered pattern 50% grey (direct
mode 1:1 uncompressed).
• If the frequency is set wrongly, vertical unstable
bands will be visible in the image (see illustration).
• Adjust with the trackball to remove all the vertical
bands (see illustration).
18
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
OPERATION
TUNE
• Select TUNING in the MENU.
• Adjust the tuning using the trackball to stabilize the
image. Preferably all the “sideways swimming” lines
should be removed (see illustration).
SCALE
POSITION
CONTR
• If your computer source resolution is not exactly
1024x768, you can select SCALE. This will scale the
source resolution to fit the LCD screen resolution by
adjusting the number of vertical and horizontal pixel
lines at intervals throughout the image.
• Select POSITION in the MENU.
• Adjust using the trackball until the full image lies
within the viewing area (see illustration).
• If the positioning goes too fast, try to alter the
trackball sensitivity under options.
• Adjust using the contrast up/down keys for optimum
image quality
19
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
OPERATION
BRIGHT
The procedure for video sources is similar to that for the computer sources
as described above, except for TUNE which is not required. Follow the
same procedure using a video which is colorful, or at least bright, across
the width of the image instead of a 50% grey background as described
here for computer sources.
For video sources these additional settings may be required:
COLOR To enhance the color saturation of video images you
TINT To enhance the hue of NTSC video (only) images you
SHARPNESS
• Adjust using the brightness up/down keys for local
lighting conditions.
can:
• Select COLOR in the menu.
• The setting can be altered using the trackball.
can:
• Select TINT in the menu.
• The setting can be altered using the trackball.
To enhance the sharpness of the lines in a video image
you can:
• Select SHARPNESS in the menu.
The setting can be altered using the trackball.
Your LCD projector is now fully set up and ready for use. If you experience
any problems in carrying out this set up procedure you should refer to the
section called Trouble-shooting found later in this user guide.
20
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
7 USING THE LCD PROJECTOR
The LCD projector has a set of features and functions with which you need
to be familiar with in order to operate the unit efficiently and to allow you to
make a smooth, problem-free presentation.
7.1 TRACKBALL REMOTE CONTROL
The trackball remote control is the main user interface with the projector.
The remote control is used to set the LCD projector correctly so that the
best viewing conditions are achieved, and also to control your presentation.
The functions performed by the keys on the remote control are described
below.
TRACKERBALL
PLATE
LEFT KEY
RESET
CONTR BRIGHT VOLUME
COMPUTER
MASK SCALE PAN
VIDEO
LIGHTPOINTER
ON/OFF
MUTE
FREEZE
S-VIDEO
PROG
MENU
RIGHT KEY
TRACKERBALL
BOTTOM KEY
21
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
The MEM column indicates whether the function setting is memorized for
the source apparatus for future use.
KEY FUNCTION KEY TYPE MEM
RESET Defaults to the standard
settings for the active
single touch
activated
-
mode.
ON/OFF Turns off the light, and
toggle places the projector in
standby mode.
CONTR Contrast is the ratio
between light and dark
scale
(up/down arrows)
Yes
colors.
BRIGHT Brightness (whiteness) of
the image can be altered
scale
(up/down arrows)
Yes
to suit local lighting
conditions.
VOLUME Volume of the audio output
can be altered to suit local
scale
(up/down arrows)
Yes
conditions.
FREEZE Holds the image projected
on the screen. This feature
any key to
release
No
can be used to hide
actions on the computer
that the audience need not
see, such as changes
between software
packages, or for returning
the audience’s attention
back to the presenter!
COMPUTER Selects the computer as
the active source.
VIDEO Selects video as the active
source.
S-VIDEO Selects S-video as the
active source.
MASK Applies a mask to the
single touch
activated
single touch
activated
single touch
activated
toggle
image, which can be
moved using the trackball.
22
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
KEY FUNCTION KEY TYPE MEM
SCALE Selects direct 1:1 mapping
toggle No
or scaling of images.
Scaling not applicable in
1024 x 768 mode.
PAN Allows panning within
oversized images using
trackball
movements
-
the trackball. Use the
trackball to show different
areas of the image.
PROG This key may be
programmed to one of the
menu controls.
POINTER Applies a trackball
toggle No
controlled pointer to the
screen. The appearance of
the pointer can be
changed in the options
menu (cross/ball/arrow).
LIGHT Illuminates the keys for 4
toggle No
seconds.
MENU Activates the menu
toggle No
system.
TRACKBALL The trackball simulates the
actions of the desktop
trackball
movements
-
mouse to control the
computer cursor.
LEFT KEY Emulates the left mouse
key.
Once the menu is
accessed selection are
confirmed using LEFT.
RIGHT KEY Emulates the right mouse
key.
BOTTOM
KEY
This emulates the ‘clickand-hold’ (drag) function of
the desktop mouse.
Use BOTTOM key instead
of LEFT when connected
to a Macintosh computer.
23
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
7.2 TOP PANEL KEYBOARD
A reduced set of controls are available from the keyboard on the top of the
LCD projector. The controls are TUNE, BRIGHTNESS and RESET. See the
infrared remote control chapter for detailed descriptions of each control.
7.3 THE MENU SYSTEM
The menu system was developed to gain access to functions not often
used, as opposed to frequently used features that are directly available
through the remote control.
Press the MENU key on the remote control to invoke the menu system.
When the menu is active, the cursor keys are used to navigate between
options (and can therefore not be used for mouse control etc. at the same
time). The LEFT key is used to activate or deactivate an option.
The PROG key may be assigned to any of the relevant menu options.
Toggle functions (like OSD) are tagged when active and untagged when
not active.
Increase/decrease functions (like TUNE and FREQUENCY) are adjusted
using the trackball. OSD is used to indicate the actual setting.
The MENU key is toggling the menu on and off. The menu is also switched
off after one minute of no action. Most selections are memorized, unless
otherwise noted.
The main menu selections SETUP, PICTURE, SOUND, OPTIONS and
HELP are explained in detail below.
Features only available with some sources are shown in light italic
characters in the menu illustrations, while generally available functions are
shown in bold characters.
7.3.1 THE SET-UP MENU SELECTIONS
TUNE is used to stabilize the image. An untuned image can be seen as
sideways instability or “swimming”. The TUNE function has no effect in
VIDEO mode.
FREQUENCY is provided in order to adjust to special graphic cards that
are not in the compatibility list. Generally, an incorrect frequency setting
can be observed as an image too wide or too narrow, combined with
vertical, unstable bands.
24
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
POSITION. Due to minor variations in graphic cards, the horizontal and
vertical position may need adjustment. Select POSITION, then press LEFT
and use the trackball.
VGA text mode (720 x 400) is correctly displayed when the image is
positioned correctly.
REAR inverts the image for use in rear projection arrangements i.e.
projection from the back of a screen. This setting is not memorized. The
feature is switched on or off by selecting it from the menu.
CEILING switches between an upright and an upside-down projection by
flipping the image vertically.
FACTORY RESET. This function resumes factory settings of all
parameters.
7.3.2 THE PICTURE SELECTIONS
TINT controls the hue of an image, and is only active in NTSC-video.
SHARPNESS controls the sharpness of the lines in an image, and is only
active for video sources.
COLOR adjusts color saturation. Only applicable when video is connected.
GAMMA toggles the gamma correction on and off for video sources.
Gamma correction helps improve detail in low light situations, like indoors
scenes etc. Only active for video sources.
7.3.3 THE SOUND SELECTIONS
TREBLE controls the higher sound range.
BASS controls the lower sound range .
BALANCE controls the sound balance between the two stereo speakers.
MONO is selected if the audio source is not stereo, in order to get sound
in both speakers.
25
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
7.3.4 THE OPTIONS SELECTIONS
HIDE OSD switches the on screen echoing of controls on and off. This
setting only affects the direct control operations, not the menu system. This
setting is not memorized.
CHANNEL SEARCH is a toggle function that controls whether the projector
shall automatically switch to the next source when the current source is
switched off or removed. Manual source selection is maintained in both
modes as long as signals are present. Source priority is first COMPUTER,
then S-VIDEO and then VIDEO. If CHANNEL SEARCH is off (not tagged),
the manually selected source is maintained regardless of signal presence.
If CHANNEL SEARCH is tagged, the projector will switch to the next
prioritized active source, regardless of manual selection.
TRACKBALL SENSITIVITY controls the response of the trackball in the
menu system. (It does not affect the response of the computer mouse.
Please adjust computer mouse responsivity on the computer). FAST,
MEDIUM and SLOW options are available.
LANGUAGE. A selection of languages is available for the menu options,
including English, German, French, Italian, Spanish, Norwegian and
Japanese. Other languages may apply.
POINTER selects the pointer appearance. Options include ball, arrow and
cross. Other shapes may apply.
MASK selects whether the mask is applied downwards or upwards.
SERVICE. This function can only be accessed through a special service
code. This code is not available to the user.
7.3.5 THE HELP SELECTIONS
SOURCE INFO provides a status list of parameters relating to the source
selected.
ABOUT provides system information about the projector.
26
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
8 SPECIAL FEATURES OF YOUR LCD PROJECTOR
8.1 COOLING SYSTEM
The fan operates as long as the LCD projector is switched on. Provided
that the power cord is connected, the fan continues to run until the unit has
cooled down even after the unit has been switched off. This ensures a
continuous protection against high temperature inside the projector. The
cooling system is designed to minimize stray light and noise. If the air flow
is blocked, a temperature safety fuse will automatically shut off the
projector to protect it from overheating.
8.2 SET-UP MEMORY
The user controlled set-up, that usually is done when the projector is
connected to a new computer, is automatically memorized for future use.
The set-up information is stored in a non-volatile memory approximately 5
seconds after the last key is pressed.
The memory can store 40 different sources/modes. Some sources are
predefined, while the remaining are available for customer set-up. See the
Technical Data section for compatibility.
Custom sources are added to the memory only if their sync pattern differs
from any of the previous selections. The projector automatically selects a
new memory location.
Most settings are stored individually for each mode, including contrast,
brightness, tune etc. See the remote control function table in section Using
the LCD Projector.
8.3 OSD SYSTEM
The OSD (On Screen Display) system echoes on screen your keypad or
remote control actions. The OSD may be switched off and on in the menu
system.
27
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
8.4 RESET
This feature enables standard settings of most controls. RESET will only
reset the active mode.
A factory reset may be performed in the menu system. All
settings will return to factory defaults, so do not perform a
factory reset unless it is really required. This operation will also
erase all custom sources and modes that have been
memorized.
28
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
9 CEILING MOUNTING
The projector is prepared for ceiling mounting. As opposed to desktop use
(most tables are approximately 80 cm tall, are flat and have a hard surface
finish), ceilings vary in height and material. Also considerations must be
made with respect to signal and power wiring.
9.1 SELECTING A MOUNT
Various mounting systems are available from different sources. Contact
your dealer for further details or consult vendor catalogs. Be sure that the
vendor has tested the mount with this specific projector for operational
safety. Check that the ventilation slots are not blocked.
9.2 MOUNTING IN THE CEILING
An improperly mounted projector is a potential danger to people and
equipment. A projector and mount falling down may cause personal injury
and material damage. Such damage caused by bad workmanship in
mounting and operation may lead to legal action and should be avoided.
Avoid ceiling mounting of the projector in areas of frequent or
probable earth quakes.
When fixing the mount in the ceiling, be sure to check the ceiling material
and if it will hold the total weight of the mount and the projector. Look for
wood, steel beams or concrete that will secure a good and lasting fixture.
Avoid plaster or other fragile materials that do not have sufficient structural
properties. Follow the detailed instructions supplied with the ceiling mount
for proper mounting and operation.
After having mounted the projector in the ceiling, test if the holding force is
sufficient by adding a load to the mount double the weight of the combined
projector and mount. The mount should hold this extra weight with no sign
of fatigue and with no sign of mounting screws loosening. For positioning
see section 6.2.
29
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
9.3 WIRING
Ceiling mounted projectors require long signal and power wires.
The signals should be wired using high quality coaxial cable. The cables
usually need to be customized. Some vendors have specialized in this field.
Contact your dealer for further detail.
If the signal cables run over a longer distance from the source to the
projector, a line buffer (distribution amplifier) may be needed (available
from third party vendors).
As fire precaution, the power wiring should have a separate
switch so that the projector can be switched off completely
when not in use. The ON/OFF on the remote control only
suspends operation of the projector without switching off
completely.
30
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
10 TROUBLE-SHOOTING
This is a checklist to help you pinpoint any problem that may arise. Check
the symptoms carefully if you experience any problem. The cure may be at
your fingertips!
Always check that the OSD appears when the OSD key on
the remote control is pressed. This indicates that the LCD
projector is receiving signals from the remote control.
SYMPTOM SOLUTION
LCD projector
does not work
The projected
image is
completely
black
The projected
image is too
dark or too light.
Some colors are
unstable or
flickering
• Check if the mains cable is attached properly.
• Check that the Power switch at the mains inlet is
ON.
• Toggle the ON/OFF button on the remote control.
• Is the LCD projector fuse, located in the fuse
holder, blown? (See Maintenance for the
replacement procedure.)
• Check that the Power switch at the mains inlet is
ON.
• The unit may have overheated due to the
ventilation slots being covered while the projector
was in use. Also ensure that the ambient
temperature is within spec. Check the air inlet
filter, as it may need vacuuming (see
Maintenance). Wait until the unit has completely
cooled down before using again.
• Adjust the CONTRAST and BRIGHTNESS
settings.
• Press RESET, which will remove the predetermined settings for the current source, and
make the set-up adjustments again.
• Check first that there are no loose cable
connections.
• You can try to adjust the image quality with the
CONTRAST and BRIGHTNESS keys.
• Try to improve the tuning using the TUNE key.
31
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
SYMPTOM SOLUTION
The whole
image appears
to be unstable
or misplaced
• If the image is scaled, press SCALE to return to
the default mode.
• Adjust the frequency and tuning settings
(instability), or the image position settings
(misalignment).
• Check that you are using a source with
compatible resolution.
• The LCD projector may be connected to a source
with a non-standard computer (or video card).
Adjust the frequency and position of the image.
Cooling fan is
not working
• Check that the Power ON/OFF switch is ON.
• If the fan does not work the LCD projector must
not be used and should be returned to your
dealer for repair.
The remote
control is not
working
• Make sure you point the remote control at the
projection screen or directly at the IR receiver
• The maximum range of the IR transmitters is 15
m/ 49 feet - Are you standing close enough?
• If the effective range of the transmitters is
significantly reduced, the remote control needs
new batteries.
The desktop
mouse is not
working
• Remember that the mouse must be connected
before the computer source is switched on.
• Are the mouse cable and mouse adapter
connections secure?
• Check the mouse driver settings on the computer
source.
• You must boot the computer after the cable has
been connected for it to recognise the mouse. If
you are unsure whether this was the case, reboot
your computer.
32
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
11 MAINTENANCE
11.1 GENERAL
From time to time, the LCD projector unit and lens may be cleaned with a
damp, non-abrasive cloth to remove dust and dirt spots. The lens should
be cleaned with a mild dish-washing detergent solution, or with standard
lens cleaning solutions available from a photographic dealer.
Do not scratch the lens surface and use the lens cap for
added protection when the projector is not in use. Remember
to remove the lens-cap when the LCD projector is in use!
Vacuum the air inlet dust filter (located in the front, under the lens and in
the bottom) periodically, especially when build-up of dust is observed. This
will ensure cool operation of the projector.
11.2 LAMP REPLACEMENT
The projector is using a 575W metal halide lamp for illumination. This lamp
is HIGH PRESSURE when operating. The lamp may not be changed by
the user for safety reasons and under the terms of the warranty. Always
refer to authorized dealers if the LCD projector transmits a lamp
replacement message.
There are no user serviceable parts inside the projector.
Never touch any glass parts (lamp bulb or lenses), as the
fingerprints will burn and affect the optical quality of the
projected image. Also, fingerprints on the lamp bulb may
cause damage and possibly explosion of the lamp when in
operation. If any parts of the lamp or optics have been
touched, it must be cleaned using a cloth moistened with
alcohol (included with replacement bulb) and polished with a
dry cloth.
33
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
11.3 LAMP REPLACEMENT MESSAGES
When the time is due to replace the lamp, the projector will give you one of
the two following messages on the screen.
WARNING!
Lamp has less than 50 hours left of recommended burning time
Please change lamp!
Press any key to clear this message...
The lamp has only 50 hours burning time left, and should be changed.
Remember that you can check accumulated lamp usage each time the
projector is switched on. A message appears in the lower left hand corner
of the screen stating software revision and accumulated lamp hours used.
If you do not respond to the first message, a second message will appear
when the lamp has exceeded recommended burning time. Please read
Warnings and Notes in Lamp Replacement section carefully and refer lamp
change to qualified service personnel only.
WARNING!
Lamp has exceeded its lamp life of 750 hours
Continued use leads to a high risk of lamp explosion
PLEASE CHANGE LAMP IMMEDIATELY ! ! !
After the lamp has been replaced and the lamp timer has been reset, the
message below confirms that the operation has been successful.
INFO!
The lamp timer has been reset to 0
Press any key to clear this message...
34
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
If the lamp timer is accidentally reset before the lamp has reached
expected lifetime, or the lamp is changed before it is required and reset the
timer, the warning below appears. This leaves you with two alternatives
which are both described in the next paragraphs.
WARNING!
The lamp change indicator has been activated,
though the lamp has not reached expected lifetime.
Press RESET to confirm lamp change,
or press any other key to continue...
If the lamp has been changed on purpose before required, this message
appears when you confirm by pressing RESET.
INFO!
The lamp timer has been reset to 0
If the lamp timer was reset unintentionally, this message confirms that
mistake has been corrected by pressing any other key to continue.
INFO!
The lamp timer has not been changed
35
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
11.4 FUSE REPLACEMENT
The mains fuse are located at the mains input, as an integral part of the
connector and switch assembly.
Defective fuses may indicate a permanent electrical failure. If a
new fuse breaks immediately, please return the unit to you
dealer for control.
Release the fuse holder by using a flat screwdriver, and replace the broken
fuses with new ones. Make sure to use fuses of correct rating, see
Technical Data section.
36
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
11.5 CARE OF THE REMOTE CONTROL
The infrared remote control requires no maintenance, other than battery
replacement when required. To change the batteries, open the battery
holder on the rear of the handset. Remove the old batteries and dispose of
carefully. Insert four new batteries of the type described in the Technical
Data section, observing the polarity instructions inside the battery holder,
and close the clip-shut door. Test that the remote control functions
correctly by pressing OSD, which should bring up the OSD.
37
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
12 TECHNICAL DATA
The technical data given in this section was correct at the
time of going to print, but may change without prior notice in
order to improve product performance.
This LCD projector is designed for indoor use and should not be operated
or stored in conditions outside the general environmental limits given in
section below, as this may lead to permanent damage and will violate any
warranties.
12.1 GENERAL ENVIRONMENTAL LIMITS
Storage temperature
Storage humidity 10 - 90 % relative humidity, non-
Operating temperature
Operating humidity 20 - 80 % relative humidity
-20 - 60°C (-4 - 140 F)
condensing
15 - 30°C (59 - 86 F) ambient
Allow for slow acclimatization after storing at extreme
temperatures and humidities, to avoid condensation. Should
condensation appear, leave the projector unit in a controlled
environment within the operating limits until the condensation
has evaporated before using the LCD projector.
38
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
12.2 LCD PROJECTOR UNIT
PROJECTOR DIMENSIONS 322 x 245 x 638 mm
12.7 x 9.6 x 25.1 inch
PROJECTOR WEIGHT 12.5 kg, 27.5 lb.
PROJECTION LENS 303 - 335 mm VARIOFOCUS
ANTI-KEYSTONE CORRECTION 8 degrees
PROJECTION LAMP 575W Dual ended metal halide
(OSRAM 575W/GS or equivalent)
LIGHT OUTPUT 400 ANSI lumen
520 peak lumen
1125 peak lux
LCD CELL Active matrix TFT (thin film
transistor) stripe configuration
COLOR RESOLUTION 16.7 million
RESPONSE TIME 30 ms
CONTRAST RATIO 100:1
PIXEL RESOLUTION 1024 x 768 x 3 (RGB)
LCD SCREEN DIAGONAL 10 inches
DEFECTIVE PIXELS Maximum 25
(black, red, green or blue)
VIDEO FREQUENCY 14 - 140 MHz
HORIZONTAL SYNC 14 - 100 kHz
VERTICAL SYNC 50 - 100 Hz
NTSC SYSTEM M, 4.43 NTSC
PAL SYSTEM B, G, H, D, I
SECAM SYSTEM B, G, H, D, I, K1, L
COMPUTER INPUT 0 - 1 Vpp
VIDEO INPUT 0 - 1 Vpp
S-VIDEO INPUT 0 - 1 Vpp
AUDIO INPUT 1V RMS
SPEAKERS 2 x 5 W stereo
APPROVALS
• CE
• UL
• cUL
• FCC Class A, Subpart J, Part
15
12.3 POWER SUPPLY
DUAL VOLTAGE 100 - 120 VAC (9A), 60 Hz, fuse 10A
220 - 240 VAC (5A), 50 Hz, fuse 6.3A
39
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
12.4 REMOTE CONTROL
UNIT SIZE 190 x 49 x 21 mm / 7.5 x 1.9 x 0.8 inches
UNIT WEIGHT 154 g / 5.4 ounces (with batteries)
BATTERIES 4 pcs LR03/AM4 1.5V
FUNCTIONAL RANGE 15 m/45 ft
COMPATIBILITY Microsoft 2-key serial mouse; IBM PS/2; MAC
APPROVALS CE, FCC Class A
12.5 COMPATIBILITY
The LCD projector is compatible with the interfaces and resolutions shown
below, some of which are predefined. However since different varieties of
these exist, a frequency adjustment may be needed.
MODE RESOLUTION MAXIMUM VERTICAL
FREQUENCY (Hz)
Generic 640 x 350
640 x 400
640 x 480
720 x 480
800 x 600
1024 x 768
1280 x 1024 (compressed)
VGA 640 x 350
640 x 400
640 x 480
720 x 400
SVGA 800 x 600 100
XGA 1024 x 768 100
SXGA 1280 x 1024 (compressed) 80
MAC 640 x 480
832 x 624
1024 x 768
1152 x 870 (compressed)
85
85
85
85
100
100
80
85
85
85
85
85
100
100
90
40
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
1
234
5
ANALOG R IN
ANALOG G IN
ANALOG B IN
NOT USED
678
ANALOG R OUT
1
10199
182626 PIN HIGH DENSITY DSUB
FEMALE (FRONT VIEW)
9
10
11
12
1415ANALOG G OUT
ANALOG B OUT
ANALOG R GND IN
ANALOG G GND IN
ANALOG B GND IN
161718
19
202122
ANALOG R GND OUT
ANALOG G GND OUT
ANALOG B GND OUT
HSYNC IN
232425
26
C/VSYNC IN
DIGITAL GND
PCID0
PCID1
DIGITAL GND
HSYNC OUT
VSYNC OUT
13
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
13 CONNECTORS
The connector ports for the source equipment on the LCD projector are
located on the right hand-side (when facing) of the unit. The connector port
for the mains power cord is located next to the fuse cabinet. The pinouts of
all the connector ports is described in this section.
Do not connect any devices or cables other than those
supplied with the LCD projector into the connector ports on
the projector unit, even if the connector ports appear identical,
as this voids any warranty and may cause permanent damage
to the projector.
S-VIDEO VIDEOCOMPUTER S-VIDEO
AUDIO
LINE OUTVIDEO
COMPUTER MOUSE
13.1 COMPUTER
This connector relays all sync signals from the computer to the LCD
projector, and also to a local CRT monitor if required.
41
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
8 PIN MINIDIN
FEMALE
(FRONT VIEW)
12345
678
1
2
345
PS/2 CLOCK
RS232 TXD
RS232 RTS
RS232 RXD
RS232 CTS
6
78PS/2 DATA
MAC ADB
GND
4 PIN MINIDIN
FEMALE
(FRONT VIEW)
1
2
341
2
34GND
GND
LUMA
CHROMA
PHONO / RCA
FEMALE
(FRONT VIEW)
STEM
SHIELD
GND
COMPOSITE
3.5 mm
JACK
(FRONT VIEW)
TIP
STEM
COMMON
RIGHT
RING
LEFT
13.2 MOUSE
This port is used to exchange mouse messages between the projector and
the computer.
13.3 S-VIDEO
This connector is used as S-VHS video input.
13.4 VIDEO
This connector is used as composite video input.
13.5 AUDIO
Four similar connectors are used for stereo sound line input for
COMPUTER, S-VIDEO, VIDEO and LINE OUT channels respectively.
42
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
14 ENVIRONMENTAL STATEMENT
Care has been taken in the manufacture of this LCD projector that
environmental stress and pollution has been minimized. Where possible,
recyclable materials have been used to minimize the environmental impact.
There are no special requirements for handling the product. Should the
LCD module inside the projector become broken for any reason, resulting
in a spillage of liquid and glass fragments from inside the unit, the following
precautions should be taken:
• wear gloves,
• place the projector unit without opening it inside a heavy-duty
polythene bag to retain any further spillage,
• clean up the spillage, disposing of the waste wisely, and wash your
hands thoroughly.
The delivery packaging can be recycled without further ado. With respect
to the LCD projector unit itself, thought should be given to the eventual
disposal of the unit in the most environmentally friendly manner
considering the mechanical, electronic and chemical components inside.
43
USER GUIDE XGA LCD MULTIMEDIA PROJECTOR
15 FCC STATEMENT
This equipment has been certified to comply with the limits for a Class A
computing device, pursuant to Subpart J of Part 15 of FCC rules. Only
peripherals (computer input/output devices, terminals, printers, etc.)
certified to comply with the Class A limits may be attached to a computer
that complies with Class A limits. When connecting to a peripheral device,
a shielded input/output cable is required to ensure compliance with FCC
rules. The shielded cable that must be used is supplied with the equipment.
Operation with non-certified peripherals or non-shielded cables is likely to
result in interference to radio and TV reception.
This equipment generates and uses radio-frequency energy and, if not
installed and used in accordance with the instruction manual, may cause
interference to radio and television reception. It has been tested and found
to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of the FCC rules, which are
designed to provide reasonable protection against such interference when
operated in a commercial environment. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures :
• Reorient the receiving antenna.
• Relocate the projector with respect to the receiver.
• Plug the equipment to a different outlet so that equipment
and receiver are on different branch circuits.
• Fasten cables using mounting screws to ensure adequate EMI control.
You may require the following booklet from the Federal Communications
Commission (FCC) : "How to identify and resolve radio and TV interference
problems", available from the U.S. Government Printing Office,
Washington, DC 20402, Stock No. 004-000-00345-4.
44
Loading...
