USERS GUIDE

DIIA PROJECTOR

PRO AV SX1

For customer Use:

Enter the Serial No. which is located on the
side panel of the cabinet. Retain this infor
mation for future reference.

Model No.
Serial No.

PRO AV SX1

Thank you for purchasing this projector. Before using it, read and follow all instructions carefully to take full advantage of the projector's capabilities.

SAFETY PRECAUTIONS

IMPORTANT INFORMATION IMPORTANT SAFEGUARDS

WARNING :

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION :

To reduce the risk of electric shock, do not remove cover.
Refer servicing to qualified service personnel.

This projector is equipped with a 3-blade grounding-type
plug to satisfy FCC rule. If you are unable to insert the
plug into the outlet, contact your electrician.

FCC INFORMATION (U.S.A. only)

CAUTION: Changes or modification not approved by

PROXIMA could void the user's authority to operate
the equipment.

NOTE: This equipment has been tested and found to

comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own
expense.

About burning-in of the D-ILA device

Do not allow the same still picture to be projected for a long
time or an abnormally bright video picture to be projected.
Do not project video images with high-intensity or high­contrast on a screen. The video image could be burned in to
the D-ILA device.
Use special care when projecting video games or computer
program images. There is no problem with ordinary video
cassette playback images.

Electrical energy can perform many useful functions. This
unit has been engineered and manufactured to assure
your personal safety. But IMPROPER USE CAN RESULT

IN POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order not to defeat the safeguards

incorporated into this product, observe the following basic
rules for its installation, use and service. Please read these

“Important Safeguards” carefully before use.

- All the safety and operating instructions should be read

before the product is operated.

The safety and operating instructions should be retained
for future reference.

- All warnings on the product and in the operating

instructions should be adhered to.

All operating instructions should be followed.

Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

- Do not use attachments not recommended by the

product manufacturer as they may be hazardous.

- Do not use this product near water. Do not use
immediately after moving from a low temperature to high
temperature, as this causes condensation, which may
result in fire, electric shock, or other hazards.

- Do not place this product on an unstable cart, stand, or
table. The product may fall, causing serious injury to a
child or adult, and serious damage to the product. The
product should be mounted according to the
manufacturer’s instructions, and should use a mount
recommended by the manufacturer.

- When the product is used on a cart, care
should be taken to avoid quick stops,
excessive force, and uneven surfaces
which may cause the product and cart to
overturn, damaging equipment or causing
possible injury to the operator.

Slots and openings in the cabinet are provided for

ventilation. These ensure reliable operation of the
product and protect it from overheating. These openings
must not be blocked or covered. (The openings should
never be blocked by placing the product on bed, sofa,
rug, or similar surface. It should not be placed in a built­in installation such as a bookcase or rack unless proper
ventilation is provided and the manufacturer’s
instructions have been adhered to.)

For proper ventilation, separate the product from other
equipment, which may prevent ventilation and keep
distance more than 50 cm (19-3/4”).

SAFETY PRECAUTIONS (Cont.)

This product should be operated only with the type of
power source indicated on the label. If you are not sure
of the type of power supply to your home, consult your
product dealer or local power company.

This product is equipped with a three-wire plug. This
plug will fit only into a grounded power outlet. If you are
unable to insert the plug into the outlet, contact your
electrician to install the proper outlet. Do not defeat the
safety purpose of the grounded plug.

Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them. Pay particular attention to cords
at doors, plugs, receptacles, and the point where they
exit from the product.

For added protection of this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the cable system. This will prevent damage
to the product due to lightning and power line surges.

Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as this can
result in a risk of fire or electric shock.

Never push objects of any kind into this product through
openings as they may touch dangerous voltage points
or short out parts that could result in a fire or electric
shock. Never spill liquid of any kind on the product.

Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous

voltages and other hazards. Refer all service to qualified
service personnel.

Unplug this productfrom the wall outlet and refer service
to qualified service personnel under the following
conditions:

a) When the power supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen on

the product.

c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following

the operating instructions. Adjust only those controls
that are covered by the Operation Manual, as an
improper adjustment of controls may result in damage
and will often require extensive work by a qualified
technician to restore the product to normal operation.

e) If the product has been dropped or damaged in any

way.

f) When the product exhibits a distinct change in

performance - this indicates a need for service.

When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or with same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.

Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating
condition.

The product should be placed more than one foot away
from heat sources such as radiators, heat registers,
stoves, and other products (including amplifiers) that
produce heat.

When connecting other products such as VCR’s, and
personal computers, you should turn off the power of
this product for protection against electric shock.

Do not place combustibles behind the cooling fan. For
example, cloth, paper, matches, aerosol cans or gas
lighters that present special hazards when over heated.

Do not look into the projection lens while the illumination
lamp is turned on. Exposure of your eyes to the strong
light can result in impaired eyesight.

Do not look into the inside of this unit through vents
(ventilation holes), etc. Do not look at the illumination
lamp directly by opening the cabinet while the illumination
lamp is turned on. The illumination lamp also contains
ultraviolet rays and the light is so powerful that your
eyesight can be impaired.

Xenon gas is enclosed with high pressure inside the light­source lamp (lamp unit) of this projector. If you drop or

impart a shock to the lamp, or discard it as is, there is
the possibility of explosion, leading to personal injury.
Use special care when handling the lamp. For any
unclear points, consult your product dealer.

Use only the accessory cord designed for this product to
prevent shock.

The power supply voltage rating of this product is AC

120 V, the power cord attached conforms to the
following power supply voltage. Use only the power
cord designated by our dealer to ensure Safety and
EMC.

When it is used by other power supply voltage, power
cable must be changed.

Consult your product dealer.

Power cord

Power supply voltage: AC 120 V

^DO NOT allow any unqualified person to

install the unit.

Be sure to ask your dealer to install the unit
(e.g. attaching it to the ceilling) since special technical
knowledge and skills are required for installation.
If installation is performed by an unqualified person, it
may cause personal injury or electrical shock.

Contents

SAFETY PRECAUTIONS

............................................

2

Accessories.....................................................................5

Controls and Features................................................6

Front Side / Top Surface / Right Side

Left-hand side............................................................................................7

Bottom Surface.........................................................................................8

Control Panel.............................................................................................9

Connector Panel

Remote Control Unit..............................................................................13

Installing Batteries.................................................................................14

...................................................................................11

..................................................

Installing the Projector...............................................15

Precautions for installation
Projection Distance and Screen Size
Relationship between Projection Distances and

Projection Screen Sizes................................................................17

Effective Range and Distance of the Remote

Control unit.................................................................................... 18

Connecting to Various Devices

Signals that Can Be Input to the Projector

Connecting to Video Devices..............................................................20

Connecting to Hi-Vision Devices...................................................... 20

Connecting to Other Devices
Connecting to Devices which Control the

Projector.......................................................................................... 21

Connecting to Computer Devices
Connecting the Power Cord (Supplied)
When Turning On the Devices Connected to the

Projector...........................................................................................25

.................................................................

................................................

..............................

......................................

.............................................................

......................................................

............................................

19

Operating the Main Menu...........................................32

Configuration of the Main Menu..........................................................32

Operating the Main Menu (Basic Operation of the

Main Menu).......................................................................................34

6

15
16

Changing the Color System

Changing the Language Display....................................................... 36

Adjusting the Pixel Clock......................................................................37

Adjusting the Screen Position.............................................................38

Adjusting Picture Quality......................................................................39

Adjusting Sound Quality.......................................................................42

Setting and Adjusting Other Functions

(OPTIONS)

Changing (Setting) the Source

......................................................................................

...............................................................

............................................................

Replacing the Lamp.....................................................48

Resetting the Lamp Use Time..............................................................50

Cleaning and Replacing the Filter
Troubleshooting

...........................................................

..........................

Specifications................................................................54

19

21

22
24

35

..43

46

51

52

Basic Operations......................................................26

1. Turning on the power.......................................................................26

2. Select the video input to be projected

3. Adjust the screen size

4. Adjust focus..................................................................................... 28

5. Adjust sound volume.......................................................................28

• For Operating Other Functions

.....................................................................

Operating the Setting Menu

Making Basic Settings..........................................................................31

About this manual:

• This manual is divided into two language sections;
English and French.

• This manual mainly explains operations using the buttons on the remote control. You can also use the button on the
projector if they have the same or similar names, but in small letters.
In the following operational explanations, the buttons on the projector are expressed as, for example, the “video” button,
the “computer” button, while the buttons on the remote control are expressed as the VIDEO button, the COMPUTER

button.

........................................

.......................................................

....................................

27
27

29

31

Accessories

The following accessories are included with this projector. Check for them; if any item is missing, please contact your dealer.

Remote control unit

Personal computer connection cable

[approx. 2 m (6.56 ft)]

(D-sub, 3-row 15 pin)

AAA/R03-size dry cell battery (x2)

(for checking operation)

AV connection cable

[approx. 1.5 m (4.92 ft)]

Power code

[approx. 2.5 m (8.2 ft)]

Audio cable

[approx. 3 m (9.84 ft)]

(3.5 mm dia. stereo mini plug)

Conversion adapter for Mac

(for Macintosh)

BNC-RCA conversion plug

Controls and Features

Front Side / Top Surface / Right Side

m

[USE

[T] Control panel

For details, refer to “Control Panel” (page 9).

[2] Exhaust vents

Vents for cooling fans through which warm air comes out.

CAUTION

’ Do not block the exhaust vents, or heat builds up inside,

possibly causing a fire. Also, do not touch the vents, or this
could cause a low-temperature burn.

3] Carrying handle

Raise this handle when carrying the projector.

CAUTIONS

’ When carrying the projector, do not give a shock to it. Be

careful to keep its balance.

• Do not carry it while the light source lamp is on or the cooling

fan is operating. This could cause personal injury.

[4] Adjustable foot (for adjusting upper/lower angles)

It is adjusted to be level when shipped from the factory.
Turning to extend the foot allows adjustment up to + 7°.

Built-in speaker (ieft)

Built-in speaker (right)

¡T| Lens

Projection lens, which is an electrically driven, approx. 1.5
X zoom lens. Before projection, remove the lens cap.

[|] Lens cap

The cap has a string attached and the string is fixed to the
projector when shipped from the factory. It is recommended
that the cap be fitted on to prevent the lens becoming dirty
when the projector is not used.

Remote sensor

When operating with the remote control, aim it toward this
sensor. You can also operate the remote control by pointing
it to a screen and allowing the remote sensor to receive
the reflected light.

Controls and Features (cont.)

Left-hand side

[l^ AC IN (power input) terminal

This is the power input terminal where the supplied power
cord is connected. For details, refer to page 24.

[TT) MAIN POWER switch

This is the main power switch. When it is turned on, the

projector goes into stand-by state, and the “stand by”
indicator on the control panel comes on.
ON[l]: The main power turns on.

OFF [o]: The main power turns off.

¡1^ Connector panel

For details, refer to “Connector Panel” on page 11.

[l3j Adjustable foot (for horizontal angle adjustment)

It is set at the shortest position when shipped from the

factory. Turn the foot to make the projector level. Adjustment

can be made in the range of -i- 1.5° and - 1.5° from the
horizontal position.

Controls and Features (cont.)

Bottom Surface

Air intake area (fiiter)

Air is taken in through this area to cool the lamp. If this
area is blocked or if something that obstructs taking in or
exhausting air is placed around the projector, heat may
build up inside and could cause a fire. For details, refer to
“Precautions for Installation” on page 15.

CAUTIONS

' Be careful as paper, cloth or soft cushion could be drawn in

if placed nearby. Do not block the intake area, or heat may
build up and could cause a fire.

' Clean the filter periodically. For details, refer to “Cleaning and

Replacing the Filter” on page 51.
Deposition of dirt on the filter works to reduce the cooling
effect, causing heat to build up inside, which could cause a
fire or malfunction.

Opening for replacing the lamp

For replacing the lamp, refer to “Replacing the Lamp” on
page 48.

Fixing foot

Controls and Features (cont.)

Control Panel

m “stand by” Indicator

On : When in stand-by mode.
Blinking: When in cool-down mode.

IjJ “lamp replace” indicator

On : After the lamp has been used for more than

approx. 900 hours.

Blinking : Replace the lamp. Refer to “Replacing the

Lamp” on page 48.

jj] “temperature” indicator

On: The temperature inside the projector has risen

abnormally.

• While the “temperature” indicator is on (during abnormal
temperature), the power is automatically cut off, and an emergency
mode is shown (with the “emergency” indicator blinking).

“emergency” indicator
Blinking: Something abnormal has occurred with the

projector.

About the emergency mode:

The emergency mode is shown when the following anomalies have
occurred with the projector (the “emergency” indicator blinks). In the
emergency mode, projection is automatically interrupted and the
cooling fans operate for about 20 seconds,

• When the air filter is displaced.

• When the filter is clogged.

• When the light-source lamp has suddenly gone off.

• When the fans have stopped.

• When the temperature inside has risen abnormally high.

About the cool-down mode;

This projector has a function to cool down the heated lamp for a fixed
period of time after projection is finished. This feature is referred to as
the cool-down mode.

CAUTION

> The purpose of the cool-down mode is to prevent inner parts

from being deformed or broken by heat from the heated lamp

as well as to prolong the life of the lamp. Do not turn off the
main power switch while in the cool-down mode. Also, do not
place the projector on its side or stand it upright; this may
block the exhaust vents.

“operate” indicator
On: When the projector is in operation (projecting)

“operate” button

When the projector is in the stand-by mode, press this
button, and the main power switch is turned on, causing
the “operate” indicator to light. Press it again, and the
projector goes into the cool-down mode, then stand-by
mode.

While in the cool-down mode:

If you press the “operate” button, the projector is not tuned on.

CAUTION

• When an emergency mode is shown:

After the cooiing fans have stopped, turn off the main power
switch and unplug the power cord from the wall outlet.
Make sure the lamp-replacement cover and the air filter are
correctly installed. Then, plug in the power cord again and
operate the projector.
If it goes into an emergency mode again, after the cooling

fans have stopped, turn off the main power switch, unplug
the power cord, and call your dealer for repair.

Controls and Features (cont.)

Control Panel (Cont.)

“video” button

Use this button to select a device such as a VCR connected
to the AV IN terminal of the projector. Each time you press
the button, the device selected changes as follows:

Y/c

----------

VIDEO

................~i»»-Y,PB/B-Y,PR/R-Y

“quick align” button

While a menu screen is shown, use this button to adjust
the values for the item selected. When no menu is shown,

the quick alignment function works.

• When a menu is shown
+ button: The value for the selected item increases.

- button: The value for the selected item decreases.

• When no menu is shown
Press the + button and - button at the same time:

QUICK ALIGNMENT is displayed on the screen and the
quick alignment function works (TRACKING, PHASE, H.

POS. and V. POS. are automatically adjusted). When the

adjustment is finished, the display goes off automatically.

The quick alignment function :

• Works for computer input (PC IN-1 and PC lN-2 input terminals)
signals.

• Does not work for video input (AV IN input terminal) signals.

CAUTION

■Automatic adjustment with the quick alignment function
should be done on a bright still-picture screen. This function
may not work correctly on a dark screen or motion-picture
screen. If adjustment with this function is not satisfactory,
adjust TRACKING, PHASE, H. POS. and V. POS. manually

(see pages 31, 37 and 38).

[FI “computer” button

Use this button to select a device connected to the PC IN­1 or PC IN-2 terminals. Each time you press the button,

the selection changes as follows:

COMPUTER 1

“setting” button

Use this button to call up the setting menu. For details,
refer to “Making Basic Settings" on page 31.

.......

—^ COMPUTER 2

10

Controls and Features (cont.)

Connector Panel

m “S-video” input terminal (Mini DIN 4 pin)

Connect this terminal to the S video output terminal of a
video deck, etc.

|T1 “video” input terminal (BNC)

Connect this terminal to the composite video output terminal
of a VCR, etc. Use the BNC-RCA conversion plug to
connect the RCA cable.

[^1 Component signal input terminals (BNC)

These are input terminals for component -“y,cb,cr(Y,CB,CR)
or y,b-y,r-y(Y,B-Y,R-Y)”- signals and Hi-Vision base band

-“Y, Pb, Pr”- signals. Devices with component signal output
terminals for NTSC or HI- Vision can be connected.

in “audio L/R” input terminals (pin jacks)

Of devices connected to the video input terminals, such as
a VCR, etc., the audio output terminals of the device to be
projected is connected to these terminals. The input audio
signal is reproduced by the speakers of the projector. The
signal is also output from the “audio OUT” terminal of the
projector.
* When the input signal is stereo signal, connection should

be made to both L and R.

* Signals from a monaural device should be connected to only

L. That way, the projector’s speakers and the “audio OUT’

terminal produce the same sound from both L and R.

|5~| “audio OUT” terminal (stereo mini jack)

Of input signals inputted to the projector, the audio signal
of the device being projected is output. Volume should be
adjusted using the VOL. (-1-/-) buttons on the remote control
or VOLUME on the setting menu. When a cable is
connected to this jack, no audio sound is produced from
the projector’s speakers.

“remote” terminal (mini jack)

Connect an infrared remote control extension unit, etc. to
this jack.
* For details, consult your dealer.

\j] RS-232C terminal (D-sub 9 pin)

This is a RS-232C interface-specified terminal. This
projector can be controlled by a computer connected
externally.
* For details, consult your dealer.

“monitor” terminal (D-sub 3-row 15 pin)

The computer input signal projected on the screen is output.
A display unit can be used by connecting it to this terminal.

To select the proper audio input for video input:

The video input terminals (AV IN input terminals) can be switched
with the projector’s “video” button or remote control’s VIDEO button.

However, since this projector has only single audio input terminal,
reconnect audio input in accordance with the AV device to be used.

11

Controls and Features (cont.)

Connector Panel (Cont.)

PC IN-2 terminal (BNC)

These are input terminals for analog RGB signals, vertical
sync (V) signals, and horizontal sync (H) signals /composite
signals (Cs). Devices which have analog RGB signal output
terminals can be connected.
To input the composite sync signals (Cs) to this unit, use
the horizontal sync (H) terminal.

* Input of external sync signals is automaticaliy

detected.

Detection of H/D signals or Cs signals causes automatic
switch to external sync. The priority order is H/D > Cs.

CAUTION

' When computer signals are input, the uppermost edge of

the screen may appear bowing if the sync signal input is
composite sync (Cs) or G on sync signal. In that case, use
separate sync signals for vertical sync (V) and horizontal sync

(H).

1^ “audio” input terminal (stereo mini jack)

This is an audio input terminal for PC IN 2 terminal. Connect

the audio output signal of a device connected to PC lN-2
terminal.

* When input to COMPUTER 2 is selected, the audio signal

input is reproduced by the projector’s speakers. Also,
signals can be output from the “audio OUT” terminal.
(However, if a cabie is connected to “audio OUT” terminal,
audio sound does not come out from the projector’s
speakers.)

PC IN-1 terminal (D-sub 3- row 15 pin)

This is an input terminal (PC) dedicated for computer
signals (RGB video signals and sync signals).
Connect the display output terminal of the computer to this
terminal. When a Macintosh computer is to be connected,
use the Conversion adapter for Mac supplied.

CAUTION

' When computer signals are input, the uppermost edge of

the screen may appear bowing if the sync signal input is
composite sync (Cs) or G on sync signal. In that case, use
separate sync signals for vertical sync (V) and horizontal sync

(H).

12] “audio” input terminal (stereo mini jack)

This is an audio input terminal for PC IN-1 terminal. Connect
the audio output signal of a device connected to PC IN-1
terminal.

* When input to COMPUTER 1 is selected, the audio signal

input is reproduced by the projector’s speakers. Also,
signals can be output from the “audio OUT” terminal.
(However, if a cable is connected to “audio OUT” terminal,
audio sound does not come out from the projector’s
speakers.)

12

Controls and Features (Cont.)

Remote Control Unit

in Remote control’s signal transmitter

n COMPUTER button

Use this button to select the devices connected to the
projector’s PC IN-1 and PC IN-2 input terminals. Each time

you press the button, the selection changes as follows:

COMPUTER 1 COMPUTER 2

[3] VIDEO button

Use this button to select the devices such as a VCR
connected to the projector’s AV IN (AVinput) terminal. Each
time you press the button, the selection changes as follows:

Y/c VIDEO —

[4] ZOOM (T/W) button

Use these buttons to increase or decrease the screen size.

(The projector’s projection lens is an electrically driven

zoom lens of about 1.5 x.)

T : The screen size decreases.

W:The screen size increases.

FOCUS (+/-) button

Use these buttons to adjust the focus of the projected video.

-K The focus point becomes more distant.
The focus point becomes nearer.

H] MENU/ENTER button

Use this button to display the main menu. While the main
menu is displayed, pressing this button displays a details
setting (submenu) for items with details settings.

^ Cursor {¿lIwImI*-) button

While the main menu is displayed, use these buttons to
select an item to adjust or make adjustment.

[8] AV MUTING (On/Off) button

Use this button to turn off the video image and audio sound
temporarily. Pressing it again makes the video image and
audio sound to resume.

QUICK ALIGN. (Quick Alignment) button

Use this button to automatically adjust TRACKING, PHASE,
H. POS. and V. POS. of the projected video. During the
automatic adjustment, QUICK ALIGNMENT appears on
the screen, and disappears after it is finished.

Quick alignment function:

Does not work for video input (AV IN input terminal) signals.
Works only for computer-related (PC IN-1 and PC IN-2 input terminals)
signals.

CAUTION

• Automatic adjustment with the quick alignment function should be
done on a bright still-picture screen. This function may not work
correctly on a dark screen or motion-picture screen. If adjustment
with this function is not satisfactory, adjust TRACKING, PHASE, H.
POS. and V. POS. manually (see pages 31,37 and 38).

PRESET button

While making adjustment on the main or setting menu,
use this button to reset the setting of the selected item to
the factory-set value. This button works only for numerical
settings and does not work for switching ON to OFF.

[lT] PAGE BACK button

While a details setting is displayed, use this button to go
back to the previous page.

[1^ VOL. (Volume) (+!-) button

Use these buttons to adjust the sound volume:

-I-: Increase the volume level.

Decrease the volume level.

[13] OPERATE button

To turn on the power, press this button for one second or
more.
* About 30 seconds after the power has turned on, video

image will appear on the screen.

13

Controls and Features (cont.)

Installing Batteries

Install batteries in the remote control. If the remote control has started to work erratically, replace the batteries.

Open the back cover.

While pushing on the back cover, slide it in the direction
of the arrow.

Install the batteries.

Place the two batteries (AAA/R03-size) supplied in the
remote control as illustrated below.

Precautions for using batteries

If batteries are used incorrectly, they may crack or
leak liquid. This could cause a fire, burn, malfunction,
or staining or damaging the surrounding.

Beware of the following;

• Do not mix new and old batteries.

• Do not mix different types of batteries as they differ in

characteristics.

• Place batteries so they match the polarities indicated:

(+) to (+) and H to (-).

• Be sure to put the minus (-) end in first to avoid short-

circuiting.

• Use only designated batteries.

• Remove the batteries if not used for a prolonged period

of time.

•When the batteries are exhausted, replace them
immediately. Otherwise, liquid could leak, or malfunction
could occur due to leaked liquids. If the leaked liquid
contacts the skin, wipe it off with a cloth, otherwise the
skin could become rough.

• Do not put batteries into fire or try to recharge them.

• Batteries run for six months to one year in normai use.

But the batteries supplied are for confirming operation
and may not run that long. When the remote control starts
failing to work properly, replace the batteries with new
ones.

Close the back cover.

Slide the back cover in the direction of the arrow until a
click is heard.

14

Installing the Projector

Precautions for Installation

CAUTION

Do not install the projector in the following places :

•There is much water, humidity or dust.

• The projector may be subjected to oil smoke or cigarette smoke.

• On a soft surface such as a carpet or cushion.

•The projector may be subjected to direct sunlight.

•Temperature is high or humidity is low.
Allowable operation temperature range: + 5°C to + 35°C (41 °F to 95°F)
Allowable relative humidity range: 20% to 80% (no condensation)
Aliowable storage temperature range: -10°C to +60°C (14°F to 140°F)

When installing the projector, observe the following:

• Do not use the projector placed on its side.

Avoid using the projector placed on its side. This could cause a malfunction.

• Use the projector within the installed angle.

Avoid using the projector inclined ±30° or more right-to-left or left-to-right. This could cause color variation or reduce the
lamp life.

• Do not block the exhaust vents.

Do not use a cover which encloses the projector air-tight or blocks the exhaust vents. Allow sufficient space around the
projector. When the projector is enclosed in a space of the following dimensions, use an air conditioner so the temperature
inside becomes equal to the outside temperature.

Allowable minimum space required

20cm (7 - 7/8”)

50cm (19 - 3/4”)

20cm (7 - 7/8”)

20cm (7 - 7/8”)

15

Installing the Projector (Cont.)

Projection Distance and Screen Size

The projector’s projection lens is a zoom lens of about 1.5 x. The screen size at the maximum enlargement is 1.5

times that of the minimum size.
The projection distance that can be focused is 2.5 to 20 m. Install the projector within this range.

Projection

distance

Minimum projection screen Maximum projection screen

8.2 ft

(2.5 m)

16.4 ft
(5 m)

32.8 ft

(10 m)

65.6 ft

(20 m)

"Also, refer to the table of “Relationship Between Projection Distances and Projection Screen Sizes” on page 17 as a reference.

When screen aspect ratio is 4 : 3 When screen aspect ratio is 16 : 9

42”

(approx. 107 cm)

86”

(approx. 219 cm)

172”

(approx. 437 cm)

345”

(approx. 877 cm)

Projection screen size (diagonal length)

Minimum projection screen

63”

(approx. 160 cm)

128”

(approx. 325 cm)

259”

(approx. 657 cm)

521”

(approx. 1,323 cm)

39”

(approx. 100 cm)

79”

(approx. 201 cm)

158”

(approx. 402 cm)

317”

(approx. 806 cm)

Maximum projection screen

57”

(approx. 144 cm)

117”

(approx. 297 cm)

237”

(approx. 601 cm)

478”

(approx. 1,214 cm)

CAUTIONS and NOTES

' Install the screen so the lower edge of the projected picture aligns with the extended center line of the projector’s lens.

That way, the lower edge of the picture projected on a 4 : 3 aspect ratio screen aligns with the extended center line of the

lens. Also, the screen must be at right angles with the extended center line of the lens (so that projection occurs at right
angles with the screen).

' When installing the screen, use a 4 : 3 aspect ratio picture.

(A 16 : 9 aspect ratio picture is projected based on the width of the range in which a 4: 3 aspect ratio picture is projected.)

' The diagonal length of a 16 ; 9 aspect ratio picture is about 91.8% that of a 4; 3 aspect ratio picture. This value is a guide

and should be used as a reference.

■ When projecting at the maximum projection distance (20 m/65.6 ft), we recommend that the projector be used with the

zoom on the Tele (T).

’ If sunlight or lamp light strikes the projection screen directly, the picture becomes whitish and dim. Be sure to use a

curtain, etc. to shield the light.

> Trapezoidal distortion may not be corrected.

Adjust the projector within the range of angle adjustment (up/down adjustment angle: +7°; horizontal adjustment angle:
±1.5°) so that it is set up level.

•The numeric values listed in the table of Relationship between Projection Distances and Screen Sizes on page 17 are
provided only as a guide or reference. The projection sizes may vary within manufacturing tolerances of the projection

lens.

• When hanging the projector from the ceiling, use a dedicated hanging fixture.

16

Installing the Projector (Cont.)

Relationship between Projection Distances and Projection Screen Sizes

For 4 : 3 aspect ratio screens

Projection

distance

8.2 ft (2.5 m)

9.84 ft (3.0 m)

13.12ft (4.0 m)

16.4 ft (5.0 m)

19.68 ft (6.0 m)

22.96 ft (7.0 m)

26.24 ft (8.0 m)

29.52 ft (9.0 m)

32.8 ft (10.0 m)

36.08 ft (11.0 m)

39.36 ft (12.0 m)

42.64 ft (13.0 m)

45.92 ft (14.0 m)

49.2 ft (15.0 m)

52.48 ft (16.0 m)

55.76 ft (17.0 m)

59.04 ft (18.0 m)

62.32 ft (19.0 m)

65.6 ft (20.0 m)

Minimum projection screen size (Tele end)

42” (approx. 107 cm)
51”
68” (approx. 173 cm)

86” (approx. 219 cm)
103”
120”
138”
155” (approx. 394 cm)
172” (approx. 437 cm)
190” (approx. 483 cm)
207” (approx. 526 cm)
224”
242” (approx. 615 cm)
260” (approx. 661 cm)
276”
294” (approx. 747 cm) 443”
311"
328” (approx. 834 cm) 495”
345”

Projection screen size (diagonal length)

Maximum projection screen size (Wide end)

63”

(approx. 130 cm)

(approx. 262 cm)
(approx. 305 cm)
(approx. 351 cm)

(approx. 569 cm) 338”

(approx. 702 cm) 416”

(approx. 790 cm) 469”

(approx. 877 cm)

76” (approx. 193 cm)
102”
128”
154”
180”
207” (approx. 525 cm)
233” (approx. 591 cm)
259” (approx. 657 cm)
285”
310” (approx. 787 cm)

364”
390”

521” (approx. 1,323 cm)

(approx. 160 cm)

(approx. 259 cm)
(approx. 325 cm)
(approx. 391 cm)
(approx. 457 cm)

(approx. 723 cm)

(approx. 858 cm)
(approx. 924 cm)

(approx. 990 cm)
(approx. 1,056 cm)
(approx. 1,125 cm)
(approx. 1,191 cm)
(approx. 1,257 cm)

•16:9 aspect ratio screens

Projection

distance

8.2 ft (2.5 m)

9.84 ft (3.0 m)

13.12ft (4.0 m) 63”

16.4 ft (5.0 m)

19.68 ft (6.0 m)

22.96 ft (7.0 m)

26.24 ft (8.0 m)

29.52 ft (9.0 m)

32.8 ft (10.0 m) 158”

36.08 ft (11.0 m)

39.36 ft (12.0 m)

42.64 ft (13.0 m) 206”

45.92 ft (14.0 m)

49.2 ft (15.0 m)

52.48 ft (16.0 m) 254” (approx. 646 cm) 382”

55.76 ft (17.0 m)

59.04 ft (18.0 m) 285”

62.32 ft (19.0 m)

65.6 ft (20.0 m)

Minimum projection screen size (Tele end)

39” (approx. 100 cm)
47” (approx. 120 cm)

79” (approx. 201 cm) 117”

95” (approx. 242 cm) 140”
110” (approx. 280 cm) 165”
126” (approx. 321 cm)
142” (approx. 361 cm) 213”

174” (approx. 442 cm)
190” (approx. 483 cm) 286”

222” (approx. 564 cm) 334”
238” (approx. 605 cm) 358”

270” (approx. 686 cm) 406”

301”
317”

Projection screen size (diagonal length)

Maximum projection screen size (Wide end)

(approx. 161 cm)

(approx. 402 cm) 237”

(approx. 524 cm)

(approx. 724 cm) 430”
(approx. 765 cm) 454”

(approx. 806 cm) 478”

57” (approx. 144 cm)
69”
93”

189” (approx. 480 cm)

260”

310”

(approx. 175 cm)
(approx. 236 cm)
(approx. 297 cm)

(approx. 355 cm)

(approx. 419 cm)

(approx. 541 cm)

(approx. 601 cm)

(approx. 660 cm)
(approx. 726 cm)
(approx. 787 cm)

(approx. 848 cm)

(approx. 909 cm)

(approx. 970 cm)

(approx. 1,031 cm)
(approx. 1,092 cm)
(approx. 1,153 cm)
(approx. 1,214 cm)

17

Installing the Projector (Cont.)

Effective Range and Distance of the Remote Control Unit

The operable distance of the remote control unit is about 10 m (32.8 ft) for direct reception. The remote control can be used by
having it reflected on the screen, etc. When you use the remote control by reflecting it at the screen, the total distance of A + B
should be about 10 m (32.8 ft) or less. The operable angles of the remote control unit is 50° right to left, and 15° up and down.

The effective range and distance of the remote control unit

Use the projector with A+B about 10 m (32.8 ft) or less.

Depending on the type of the screen used, the effective distance of the remote control may be reduced.

18

Connecting to Various Devices

* Before connection, be sure to turn off the projector and connected devices.
* Read the manual which comes with each device thoroughly.

Signals that Can Be Input to the Projector

The following signals can be input to the projector:

■ Video signals

(1) Response to color systems

' -___Color system

Input terminal ~~

video

S-video о
video/y, c/cb(b-y), cr(r-y)
G, B, R, H,V

*1 ; Responds if “S-video” output is available.

*2: Signifies that component signals conform to the signal timing (synchronization and video period) of each color system. The

color systems are used for convenience only.

(2) Response to double density (*1), high-vision signals

Input terminal NTSC*2
video/y, c/cb(b-y), cr(r-y)
G, B, R, H, V

: Signals whose density of scanning lines/tield is twice as high.

;: Responds to signals whose horizontal scanning frequency is 31.5 kHz. NTSC can be made twice as dense by a line doubler

(separately available; recommended article). Also, possible to respond to fully-specified, decoded wide-clear-vision signals

and 525P progressive signals.

1: Responds to signals whose horizontal scanning frequency is 33.5 kHz. PAL can be made twice as dense by a line doubler

(separately available: recommended article).

NTSC NTSC4.43

О О

0*1

0*2

0*2

0 О

0 0

0*2

0*2 0*2

PAL*3

PAL

0

О

0*2

SECAM

О

0*2

0*2

High-vision signal

О

о

Computer signals

• Signals with the following resolutions can be input to the input terminal of PC IN-1 (analog RGB) or PC IN-2 (G, B, R, H, V).

(The following signals are preset.)

Screen resolution (standard name) Horizontal frequency Vertical frequency

640x400 (PC-9801)
640 X 350 (VGA1)
640 X 480 (VGA3)
640 X 480 (Macintosh 13”)
640 X 480 (VGA VESA)
800x600 (SVGA1)
800 X 600 (SVGA2)
832 X 624 (Macintosh16”)
1024x768 (XGA1)

1024x768 (XGA2)
1024 X 768 (Macintosh 19”)
1152 X 870 (Macintosh 21”)

1280x1024 (SXGA1)

1280x 1024 (SXGA2)
1360 X 1024 (SXGA3: Mac Board)

24.8kHz 56.4Hz

31.5kHz 70.1Hz

31.5kHz 59.9Hz

35.0kHz 66.7Hz

37.5kHz 75.0Hz

37.9kHz

48.1kHz

60.3Hz

72.2Hz Non-interlace

49.7kHz 74.6Hz

48.4kHz 60.0Hz

56.5kHz

70.1Hz Non-interlace

60.2kHz 74.9Hz

68.7kHz 75.0Hz

64.0kHz 60.0Hz Non-interlace5

70.8kHz 67.0Hz

80.0kHz 75.1Hz

• Interlace signals are not handled.

• Some signals other than listed above can be displayed. But they require adjustment. Even some of the signals listed above may require
adjustment depending on the video board used.

• When a signal other than listed above is input, the screen could be partially erased or an unneeded fold-over screen could appear.

• Even signals in the frequency range that can be input may not be displayed normally depending on the type of the signal.

• Composite sync.(Cs) and G on sync, signals cannot handled depending on the devices connected.

Scanning method

Non-interlace
Non-interlace
Non-interlace
Non-interlace
Non-interlace
Non-interlace

Non-interlace
Non-interlace

Non-interlace
Non-interlace

Non-interlace
Non-interlace

19

Connecting to Various Devices (Cont.)

Connecting to Video Devices

Before connection, be sure to turn off both the projector and video device.

• Read the manual which comes with each video device thoroughly.

• Use the supplied AV connection cable. An AV connection cable with an S video terminal is not supplied.

To “S-video” (separately available)

S video cable

Video devices

• VCR (Video Cassette recorder)

• Laser video disc player or DVD player

s

© o

' Camcorder

To select the proper audio input for video input

The video input terminal (AV IN input terminal) can

be switched with the VIDEO (or “video”) button.
However, since this projector has only a single audio
input terminal, reconnect audio input in accordance

with the AV device to be used.

' Use of an extension cable to connect a video device and the

projector could cause video degradation.

' When a signal with much jitter is reproduced on a VCR or special-

effect playback is performed, the upper part of the picture or the
picture itself may be erased or distorted.

Connecting to Hi-Vision Devices

Before connection, be sure to turn off both the projector and Hi-Vision devices.

• Read the manual which comes with each Hi-Vision device thoroughly.

• Use separately available BNC cables and audio cables to connect Hi-Vision devices.

□ 1—I

iS

=

To “audio R”

To “audio L”

Audio connection cable
(separately available)

ToAV IN

BNC cable (separately available)

To select the proper audio input for video input

The video input terminal (AV IN input terminal) can
be switched with the VIDEO (or “video”) button.
However, since this projector has only a single audio
input terminal, reconnect audio input in accordance

with the AV device to be used.

20

To'Video/y’

To ''c/cb(b-y)

^ To“cr(r-y)’

Hi-Vision devices

• W-VHS VCR or DVD player

• Text/video camera
1 /

1 i

..... 1 1

■
1 u

Hi-Vision video camera

Other devices with component signal output terminals (DVD player
(NTSC), etc.) can be connected.
*DVD: Digital Video Disc

1 ^

Connecting to Various Devices (Cont.)

Connecting to Other Devices

Before connection, be sure to turn off both the projector and other devices to be connected.

• Read the manual thoroughly which comes with the device to be connected.

• Speakers with a built-in amplifier and game devices can be connected. Use the AV connection cable and audio cable supplied,

or the cable supplied with a game device.

(or stereo mini-plug)

Connecting to Devices which Control the Projector

Before connection, be sure to turn off both the projector and devices to be connected.

• Read the manual thoroughly which comes with each device to be connected.

• By connecting a computer to the RS-232C terminal, you can control the projector. Also, you can make an infrared remote

sensor extension unit and connect it to the “remote” terminal of the projector.
* Obtain connection cables as required.
* For details, consult your authorized dealer or service center.

Connecting to Various Devices (Cont.)

Connecting to Computer Devices

Before connection, be sure to turn off both the projector and computer devices.

• Read the manual which comes with each device thoroughly.

M Connection to an IBM PC or IBM-compatible computer

• Use the supplied computer connection cable.

22

Connecting to Various Devices (Cont.)

Connecting to Computer Devices (Cont.)

Before connection, be sure to turn off both the projector and computer devices.

• Read the manual which comes with each device thoroughly.

■ Connection to Macintosh

• Use the supplied Personal computer connection cable and the supplied conversion adapter for Mac.

23

Connecting to Various Devices (Cont.)

Connecting the Power Cord (Supplied

After all devices have finished being connected, connect the projector’s power cord. At this time, do not turn on the MAIN
POWER switch yet.

[H Insert the supplied power cord

into the power input terminal (AC
IN ~) of the projector.

AC IN ~

Insert the plug of the supplied power cord into a wall outlet.

CAUTION

To prevent fire and electric shock, observe the following;

• When you do not use devices, pull out their power cords

from wall outlets.

• Do not connect the devices with power cords other than

supplied.

• Do not use voltage other than the power voltage indicated.

• Do not scar, damage, or work on the power cords. Also, do
not put a heavy object on, heat or pull the power cords,
otherwise they may be damaged.

• Do not insert or pull out the plugs with a wet hand.

CAUTION

' Since the power requirement of the projector is high, be sure

to insert the power plug directly into a wall outlet.

I To use the projector

• Remove the lens cap.

* The lens cap has a string attached and it is fixed to the

projector.

Be sure to fit lens cap when not in use.

24

Connecting to Various Devices (Cont.)

When Turning On the Devices Connected to the Projector

Turn on the switches of the projector and the devices connected in the following order. Skip over unconnected devices if there is any.

' When turning off the power switches, do so in the reverse order.

When the OPERATE (or “operate”) button is pressed but the power is not supplied:

If the filter or lamp replacement opening cover is displaced, the power is not supplied. Check them for correct installation.

CAUTIONS and NOTES

Do not turn off the MAIN POWER switch suddenly while the projector is being used or immediately after it has been

used. This could cause a malfunction.

•Since the projector uses a high-intensity lamp and is heated to high temperature, cooling fans are operating even during
projection. So, after use, the cooling fans continue to run from when the OPERATE (or “operate”) button is pressed until the
lamp is cooled down. During cooling, the “stand by” indicator blinks to alert the cooling fans are running. During this time, do
not turn off the main power switch. After the cooling of the lamp is finished (the fans stop) and the “stand by” indicator comes
on, then turn off the main power switch.

• If you press the OPERATE (or “operate”) button immediately after the lamp lights, it takes about 40 seconds for the lamp to go
off. To turn the lamp on again, wait 10 seconds or more before pressing the OPERATE (or “operate”) button.

When the “temperature” indicator lights, the power turns off automatically.

• While the lamp is on, if an abnormal temperature rise is detected, the “temperature” indicator comes on, the power is automatically
cut off, and the projector’s “emergency” indicator blinks (goes into an emergency mode).

When the “emergency” indicator blinks, turn off the main power switch after the fans have stopped running.

• If the following abnormality occur to the projector, it goes into an emergency mode (the “emergency” indicator blinks).
When the projector goes into an emergency mode, it stops projecting automatically and runs the fans for about 20 seconds.

- When the filter is dislodged.

- When the filter is clogged.

- When the lamp suddenly goes off.

- When the fans stop running.

- When the temperature inside rises abnormally high.

•When the projector goes into an emergency mode;
After the fans have stopped, turn off the MAIN POWER switch and pull out the power cord. After that, re-insert the power cord
and try to operate the projector. If it goes into emergency again, after the fans have stopped, turn off the main power switch,
pull out the power cord, and consult your authorized dealer or service center for repair.

25

Basic Operations

Projector’s buttons

stand by (!) O Z “stand by” indicator

“operate” indicator

- “operate” button

lamp replace ( )

temperature CD

a,®

The following describes the basic procedure for normal use of
the projector.

1. Turning on the power

m Turn on the MAIN POWER

switch.

ON [ I ]:The main power turns on and the “stand by”

indicator comes on.

Projector’s indicator

Press the “operate” button on
the projector.
(Or press the remote control’s
OPERATE button for one second
or more.)

• The “operate” indicator comes on.

•About 30 seconds after the MAIN POWER switch is

turned on, you can start projecting.

Projector

Remote control unit

Remote control unit

' After the power is turned on, the screen may be jumbled for a few

seconds, but this is not a malfunction.

Turning off the Power

® Press the “operate” button on

the projector.
(Or press the remote control’s
OPERATE button for one second
or more.)

• The “stand by” indicator changes to blinking, and the

projector goes into cool-down mode.

Example of the projector’s button Projector

(Blinking) 1

Stand by (I) •xjQ;" I

i

Turn off the MAIN POWER switch
after the “stand by” indicator
changes to steady on.

OFF [o]: The MAIN POWER switch turns off and the

“stand by” indicator goes off.

Projector

(Off)

stand by (!) O

26

Do not turn off the MAIN POWER switch during cool

down mode (the “stand by” indicator blinking). Turn it

off after the “stand by” indicator becomes on (stand-by
mode).

Basic Operations (Cont.)

Remote control unit

Projector’s buttons

m m m m m m m m

stand by t!) O ^

operate

lamp replace C D

temperature ( )

emergency

ie%

P

' COMPUTER button

'VIDEO button

• ZOOM (TAW) buttons

“video” button

“computer” button

2. Select the video input to be projected

■ Press the VIDEO (or “video”) button or the
COMPUTER (or “computer”) button to switch the
input.

• Each time you press either button, the selected input changes as

follows,

■ When you press VIDEO (or “video”):

Y/C ........

When you press COMPUTER (or “computer”):

COMPUTER 1

Remote control unit Projector

Screen display

When the input is switched, the line display (ex. VIDEO) and
the source display (ex. NTSC) are shown on the upper part of
the screen (they disappear in about five seconds). However,
they will not be shown if LINE DISPLAY in “Setting and Adjusting
Other Functions (OPTIONS)” on page 43 is set to OFF.
(For setting the source, see page 46.)

' To select the proper audio input for video input

The video input terminal (AV IN input terminal) can be switched with the
VIDEO (or “video") button. However, since this projector has only a single
audio input terminal, reconnect audio input in accordance with the AV device
to be used.

....

COMPUTER VIDEO

dJ CTD

.... VIDEO ----------

.......................

XPb/B-YPr/R-Y

► COMPUTER 2

ATTENTIONS

DO NOT give any shock to this projector while
operating it; otherwise, the lamp goes off (the

“emergency” indicator lights up).
if the shock turns off the lamp —

Turn off the power by pressing the MAIN POWER

switch, then turn it on again. Now you can operate

the projector as usual.

3. Adjust the screen size

Adjust the screen size with the remote control’s ZOOM
(T/W) buttons.

■ To enlarge the screen size:

Press the ZOOM (W) button.

■ To reduce the screen size:

Press the ZOOM (T) button.

Remote control unit

' The adjustment of the screen size (zoom adjustment) can also be made on

the setting menu.
For operating the setting menu, refer to “Making Basic Settings” on page 31.

27

Basic Operations (Cont.)

Remote control unit

- FOCUS (+/-) buttons

“VOL. (+/-) buttons

4. Adjust focus

Adjust focus with the remote control’s FOCUS (+/-)
buttons.

■ To focus on farther points;

Press the FOCUS (+) button.

■ To focus on nearer points:

Press the FOCUS (-) button.

Remote control unit

■ Focus adjustment can also be made on the setting menu. For operating the
setting menu, refer to “Making Basic Settings” on page 31.

5. Adjust sound volume

Adjust sound volume with the remote control’s VOL.
(+/-) buttons.

■ When you press the VOL. (+) button:

The sound volume becomes higher. (0 -)• 50)

■ When you press the VOL. (-) button:

The sound volume becomes lower. (50 ^ 0)

■ When you press either button, the corresponding AUDIO-VOL.
level is displayed on the screen (the display will disappear in about

five seconds).

Remote control unit

m

Screen display

• Sound volume can be adjusted on the setting menu. For operating the setting
menu, refer to “Making Basic Settings” on page 31.

28

Basic Operations (Cont.)

Remote control unit

QUICK ALIGN, button

AV MUTING button

For Operating Other Functions

To turn off video image and audio sound temporarily

Press the AV MUTING button.

■ Press once:

Video image and audio sound turn off.

■ Press again:

Video image and audio sound come out again.

Remote control unit

To use the quick alignment function

The quick alignment function is used to automatically adjust (set)
the screen settings of “TRACKING, PHASE, H. POS. and V. POS.”
of computer system input video.

• Use either the remote control or projector button.

■ When using the remote control unit:

Press the QUICK ALIGN, button.

■ When using the projector:

Clear the menu display, and press the projector’s “quick align

buttons at the same time.

Projector’s button

stand by (i) O ^

o

operate

lamp replace ( )

temperature CD

emergency CD

video ((

’ During the automatic adjustment, “QUICK ALIGNMENT” appears

on the screen and disappears automatically after the adjustment
is completed.

Remote control unit Projector

QUI
AUG

quick align

Screen display

• This function works only for computer system inputs.

It does not work for AV inputs.

CAUTION

•When performing automatic adjustment using the quick

alignment function:

Use a bright, still-picture screen. It may not function correctly on a
dark or motion-picture screen.
If the condition adjusted by using the quick alignment function is not
good, manually adjust TRACKING, PHASE, H. POS. and V. POS.
(see pages 31,37 and 38).

29

Basic Operations (Cont.)

Projector button

I To display the SETTING menu

The setting menu is used to make basic adjustments and settings
(TRACKING, PHASE, H. POS., V. POS. FOCUS, ZOOM and
AUDIO-VOL.) of the video picture being projected after installation
(connection) or after inputs are switched. For operating the setting
menu, refer to “Making Basic Settings” on page 31.

• Press the projector’s “setting” button.

The setting menu is displayed on the screen.

Projector

“setting” button

To display the MAIN menu

The main menu is used to adjust or set the projected video picture

and the projector’s condition, etc. (PIXEL CLOCK, POSITION,
PICTURE, SOUND, OPTIONS, SOURCE DECODER and
LANGUAGE). For operating the main menu, refer to pages 34 to

47.

' Press the remote control’s MENU/ENTER button.

The main menu appears on the screen.

Remote control unit

Remote control unit

"MENU/ENTER button

' To change the menu language displayed

English is set when the projector is shipped from the factory. The language
displayed can be selected from the following six languages:
(Japanese), ENGLISH, DEUTSCH (German), ESPAÑOL (Spanish),
ITALIANO (Italian), and FRANÇAIS (French). However, some words such
as “QUICK ALIGNMENT“ are displayed only in English. Pronouns such as
line display and source display are similarly treated.

■ To use the remote control’s PRESET button

The PRESET button Is used for adjustments made on the main

menu or setting menu.

• When resetting only the selected settings to the factory-set

values, press the remote control’s PRESET button.

Only the selected item’s setting is reset to the factory-set value.

Remote control unit

•

□

• This button works only for numeric values. It does not work for switching
between ON and OFF.

• For items such as PIXEL CLOCK (TRACKING and PHASE). POSITION (H.
POS. and V. POS.), SOUND (TREBLE and BASS), both settings are reset
at the same time.

30

Operating the Setting Menu

Making Basic Settings

Projector’s buttons

Ш emergency (— )

• This adjustment menu (setting menu) can be displayed with only the
projector’s button. After displaying the setting menu, you can select
or set (adjust) items with cursor buttons on the remote control unit,

• If settings and connections are changed, adjust and set those items
again.

• After this adjustment (setting menu), if video picture adjustment is
necessary by using the devices connected, perform the details setting
and adjustment on the main menu (pages 34 to 47).

• For computer-related inputs, use of the quick alignment function
allows automatic adjustment of TRACKING, PHASE, H. POS. and
y. POS. (See pages 31,37 and 38).

■j Press the “setting” button of the

2 Press the “setting” button to

projector.

• The setting menu is displayed on the screen.

select the desired item.

• The selected item is shown in magenta color. Each time
you press the button, the selected item changes as
follows:

TRACKING

PHASE

H. POS.

V. POS.

Description of adjustment and setting items

TRACKING ;

PHASE ; If characters on the screen flicker or become

H. POS. ; If the screen position is displaced to the right

V. POS. ; If the screen position is displaced upward or

FOCUS ; Adjust the focus of video picture.

ZOOM ; Adjust the screen size (angle of view).

AUDIO-VOL. ;

; If wide vertical stripes appear on the screen,

adjust the lateral video size and display area
so that they disappear. (-255 0 «-> -i-255)

dim, adjust so they become clear.
(-127 ^^0 e^-r127)

or left, adjust the horizontal position of the
screen. (-255 0 -t-255)

downward, adjust the vertical position of the
screen. (-120 0 ^ -i-120)

Focuses on near points.

+: Focuses on farther points.

T : Becomes smaller.
W: Becomes larger.

; Adjust the sound level.

(0 ^ 50)

Menu clearing

To select items using the remote control unit:

Items can be selected using the cursor buttons a (backward) or t
(fora/ard) on the remote control unit. In this case, menu clearing in the
above order is not available. The selection changes from AUDIO-VOL

to TRACKING directly.

AUDIO-VOL.

ZOOM

FOCUS

Q Adjust and set the selected item

using the “guick align +/-”

buttons.

• To adjust and set multiple items, repeat steps 2 and 3.

•To reset the adjustment value of the selected item
(TRACKING, PHASE, H. POS. or V. POS.) to the
factory-set value, press the remote control’s PRESET
button. This button does not work for focus, zoom or

sound volume.

To adjust and set items using the remote control unit;

Items can be adjusted and set using the cursor buttons or ► on the
remote control unit.

Clear the setting menu by
pressing the “setting” button

repeatedly.

To clear the setting menu using the remote control unit:

You can also clear the setting menu by pressing the PAGE BACK
button on the remote control unit.

Using the quick alignment function:

This function works only for computer-related signals inputted. Press
the remote control’s QUICK ALIGN, button, or after clearing the menu
displayed, press the projector’s “quick align +/-’’ at the same time.
TRACKING, PHASE, H. POS. and V. POS. are automatically adjusted.
During the adjustment, “QUICK ALIGNMENT” appears on the screen,
and disappears after the adjustment finishes.

31

Operating the Main Menu

Configuration the Main Menu (AV Input)

You can adjust video quality (PICTURE), audio quality (SOUND), etc. using the menus.

The menus are configured as follows;

Main menu (AV inputs : During AV IN input signal)

I PIXEL CLOCK I TRACKING

PHASE

POSITION

IpictureI

SOUND

OPTIONS

V. POS.
H. POS.

BRIGHTNESS
CONTRAST
SHARPNESS
COLOR
TINT
ALL RESET

TREBLE
BASS

MENU AUTO OFF
LINE DISPLAY

RIGHT LEFT REV.
TOP BOTTOM INV.
CLAMP

RESIZE
BACK COLOR

COLOR TEMP.

: Normally, no adjustment Is required. The lateral size and display area of video Image are adjusted.

: Normally, no adjustment is required. Flickering or dim video image is adjusted.

: The vertical position of the video image being projected is adjusted.
: The horizontal position of the video image being projected is adjusted.

: The brightness of the video image being projected is adjusted.
: The contrast of the video image being projected is adjusted.
: The sharpness of the video Image being projected is adjusted.
: The color density of the video image being projected is adjusted.
: The tint of the video image being projected is adjusted. (Displayed only for NTSC signal)
: All the items adjusted are reset.

: The treble of the audio sound being input is adjusted.

: The bass of the audio sound being input is adjusted.

: Sets whether to turn off menu display automatically (YES) or not (NO).
: Sets whether to make the line display effective (ON) or not (OFF) for about 5 seconds after input

switching.
: Video image is reversed right-to-left (for upside-down hanging (ceiling)).
: Video image is inverted top-to-bottom (for upside-down hanging (celling)).
: Sets the clamp pulse’s position at the back porch (BP) or on the sink tip (ST). Normally, the clamp

pulse is used at BP. if, with some PCs or workstations, the screen becomes unstable such as

being too dark or too bright, try to switch to ST.
: Does not work with AV (video) input. (RESIZE is shown in gray.)
: Specifies the background color when there is no video signal. Background color can be selected

from BLUE, CYAN, BLACK, GREEN, MAGENTA, RED, and YELLOW.

: Adjusts the color temperature of the image being projected. Make adjustment when the image

becomes reddish or bluish.

Color temperature can be set to LOW, MIDDLE, or HIGH.

32

SOURCE

DECODER I

LANGUAGE

ASPECT CHANGE ; Selects the vertical-to-horizontal ratio of the image projected. The factory-set ratio is 4 ; 3. When

projecting high-vision video image, a ratio of 16 : 9 can be selected.

SLEEP TIME

LAMP TIME : Indicates the accumulated used hours of the lamp.

; Normally set to AUTO. If the image is unstable, or does not display color, select the input source from the list.

Normally, set to AUTO. The color system of an input signal is automatically identified and shown in (
You can select from AUTO, NTSC, NTSC4.43, PAL, and SECAM.

Text on the screen can be changed to a language other than English. Languages that can be displayed are the

I

following six : BŸIp (Japanese), ENGLISH, DEUTSCH (German), ESPAÑOL (Spanish), ITALIANO (Italian), and
FRANÇAIS (French). However, some text such as “QUICK ALIGNMENT”, etc. are shown only in English.

; Sets the length of sleep time. A set sleep time after input signal is depleted, the projector goes into

a stand-by state. Sleep time can be selected from 10 minutes, 20 minutes, 30 minutes, and 60

minutes.

).

Operating the Main Menu (Cent.)

Configuration of the Main Menu (Computer input)

Main menu (Computer inputs : During PC IN-1 or PC IN-2 Input signal)

[ PIXEL CLOCigiRACKING

PHASE

[ POSITION I V. POS.

H. POS.

PICTURE BRIGHTNESS

CONTRAST
R-GAIN
G-GAIN
B-GAIN
TEXT MODE

ALL RESET

—jSOUNDl

OPTIONS I

TREBLE
BASS

MENU AUTO OFF
LINE DISPLAY

RIGHT LEFT REV.
TOP BOTTOM INV.
CLAMP

RESIZE

BACK COLOR

The lateral size and display area of video image are adjusted.

Flickering or dim video image is adjusted.

The vertical position of the video image being projected is adjusted.
The horizontal position of the video image being projected is adjusted.

The brightness of the video image being projected is adjusted.
The contrast of the video image being projected is adjusted.
The gain in red signal of the video image being projected is adjusted.
The gain in green signal of the video image being projected is adjusted.
The gain in blue signal of the video image being projected is adjusted.
Adjust easiness for reading text during RESIZE.
Normal : Normal

Text 1 : Display the outline of small letters already.
Text 2 : Makes the outline of iarge ietters sharp.

; All the items adjusted are reset.

: The treble of the audio sound being input is adjusted.
: The bass of the audio sound being input is adjusted.

Sets whether to turn off menu display automatically (YES) or not (NO).
Sets whether to make the line display effective (ON) or not (OFF) for about 5 seconds after input

switching.

Image is reversed right-to-left (for upside-down hanging (ceiling)).
Image is inverted top-to-bottom (for upside-down hanging (ceiling)).

Sets the clamp pulse’s position at the back porch (BP) or on the sink tip (ST). Normally, the clamp

pulse is used at BP. If, with some PCs or workstations, the screen becomes unstable such as
being too dark or too bright, try to switch to ST.

When the number of pixels (resolution) sought by the video image input is smaller than that

(resolution) of D-iLA device, the video image is then enlarged to a virtually full screen size of D-ILA

device and projected. (Resizing indication)

Specifies the background color when there is no image signal. Background color can be selected

from BLUE, CYAN, BLACK, GREEN, MAGENTA, RED. and YELLOW.

COLOR TEMP.

ASPECT CHANGE : Selects the vertical-to-horizontal ratio of the video image projected. The factory-set ratio is 4 : 3.

SLEEP TIME : Sets the length of sleep time. Aset sleep time after input signal is depleted, the projector goes into

LAMP TIME : Indicates accumulated used hours of the light-source lamp.

[ SOURCeI : Normally set to AUTO. If the image is unstable, or does not display color, select the input source from the list.

Adjusts the color temperature of the video image being projected. Make adjustment when the
video image becomes reddish or bluish.
Color temperature can be set to LOW, MIDDLE, or HIGH.

When projecting high-vision image, a ratio of 16 : 9 can be selected.

a stand-by state. Sleep time can be selected from 10 minutes, 20 minutes, 30 minutes, and 60

minutes.

I DECODE^ : Does not work with computer inputs. (The color system is indicated in gray.)

[ LANGUAG~E~| : Text on the screen can be changed to a language other than English. Languages that can be displayed are the

following six : 0:$;^ (Japanese), ENGLISH, DEUTSCH (German), ESPAÑOL (Spanish), ITALIANO (Italian), and
FRANÇAIS (French). However, some text such as “QUICK ALIGNMENT”, etc. are shown only in English.

33

Operating the Main Menu (Cent.)

Operating the Main Menu (Basic Operation of the Main Menu)

Remote control unit

PAGE BACK button

Main menu

(Example: During video signal input)

Color system (DECODER) Language

Submenu items

For projector’s menus, the setting menu and the main menu are
available.
For the setting menu, refer to “Making Basic Settings” on page 31.

-| Press the MENU/ENTER button.

• The main menu is displayed on the screen.

2 Select an item with the cursor button
^ A or

T.

• The selected item (displayed text) is shown in magenta color

on the screen.

0 Set (adjust) the item.

■ When you have selected DECODER or LANGUAGE,

• Set it with the cursor button ◄ or ►.
* To finish the main menu, press the PAGE BACK button.

■ When you have selected an item on the submenu,

• Press the MENU/ENTER button to display the submenu, then

set (adjust) the item with the cursor buttons ^ / ► or A / ▼.

* To return to the main menu, press PAGE BACK again. (To

finish the main menu from the submenu, press PAGE BACK
twice.)

About main menu display:

Input line: The selected input-mode designation is

displayed. For input-mode designation, “Y/
C”, “VIDEO”, “Y, Pb/B-Y, Pr/R-Y”,
“COMPUTER 1” and “COMPUTER 2” are
available.

Source: The type of signal being input is displayed.

With this projector, unique designations are
previously given to specific horizontal and
vertical frequencies. This allows the source
selected under SOURCE (submenu item) to
be indicated. The source setting can be
selected from AUTO mode and dedicated
(forced) modes. When AUTO is selected, the
horizontal and vertical frequencies of a
signal being input are detected and the
matched designation is displayed in ( ).
Display example: “AUTO (NTSC)”
Therefore, be careful as the source display
does not always correspond to the indication
or type of the input signal.
For the unique designations for the specific
horizontal and vertical frequencies, see
pages 19 and 46.

Submenu items:

PIXEL CLOCK: See page 37.
POSITION
SOUND
OPTIONS
SOURCE

Decoder (Color system)
Language

See page 38.
See pages 39-41.
See page 42.
See pages 43-45.
See pages 46 and 47.

: See page 35.
: See page 36.

34

Operating the Main Menu (Cent.)

Changing the Color System

Remote control unit

AUTO is set for the color system when the projector is shipped from
the factory. Normally, use it in AUTO. If operation in AUTO is unstable
such as with color not being shown, set to a dedicated color system
in accordance with the color system of the signal being input.

Press the MENU/ENTER button.

• The main menu is shown on the screen.

O Select “DECODER” with the cursor
^ button A or

• The selected item (displayed in text) is shown in magenta color

on the screen.

T.

Q Set the color system with the cursor

^ button ◄ or ►.

• Each time you press the cursor button ◄ or ►, the color system

changes as follows.
► : Forward / ◄ : Backward

AUTO

............................

NTSC

............................

Normally, set to AUTO. The color

system of a signal being input is
automatically identified.

Dedicated to NTSC.

Main menu

When computer signal is input, the display of the color system
is changed to gray color, making operation impossible. When
video signals from AV devices are input, the item for the
color system can be set.

NTSC4.43

....................

Dedicated to NTSC4.43.

I

PAL

SECAM.........................Dedicated to SECAM.

About automatic signal identification

• AUTO is selected when shipped from the factory. In AUTO, the color system
(DECODER) of the signal being input is automatically identified and indicated
in ( ). Refer to the main menu display.

• If operation in AUTO is unstable such as with color not being shown, set to a
dedicated color system in accordance with the color system of the signal
being input. When the dedicated color system is set, be careful as automatic
identification does not work.

• To finish the main menu, press the PAGE BACK

button.

Dedicated to PAL.

35

Operating the Main Menu (Cent.)

Changing the Language Display

Remote control unit

The language in the menu display is set to English when shipped
from the factory. When you want to change to another language, set
it as follows.

-| Press the MENU/ENTER button.

• The main menu is shown on the screen.

2 Select “LANGUAGE” with the cursor ^ button A or ▼.

• The selected item (displayed in text) is shown in magenta color

on the screen.

Q Set the desired language with the

^ cursor button ◄ or ►.

• Each time you press the cursor button -4 or ►, the selected

language changes as follows.

► : Forward / ◄ : Backward

.Japanese

ENGLISH

DEUTSCH

........................

.......................

English

German

Main menu

VIDEO NTSC

□ pixel clock
□ position
□ picture
□sound
□options
□source

decoder AUTO(NTSC)

LANGUAGE

Language

‘ The selected item is shown in magenta color. Items shown

in gray cannot be operated or set in the current mode.

ENGLISH

ESPAÑOL

......................

Spanish

I

ITALIANO

.......................

I

FRANÇAIS

About language display

English is selected when the projector is shipped from the factory. The

languages in the menu display are the following six : (Japanese),

ENGLISH, DEUTSCH (German), ESPAÑOL (Spanish), and FRANÇAIS
(French).
However, some text such as “QUICK ALIGNMENT" is displayed only in English.
Unique designations such as line display and source display are similarly

indicated.

• To finish the main menu, press the PAGE BACK

button.

.....................

French

36

Operating the Main Menu (Cent.)

Adjusting the Pixel Clock

Remote control unit

The pixel clock should be adjusted mainly for computer inputs.
(Normally, it does not need to be adjusted for video inputs.) If a wide
stripe appears on the screen, adjust the lateral size of video image
and the display area (tracking adjustment) so the stripe disappears.
Also, if text on the video screen appears flickering or dim, make
adjustment so it becomes clear (phase adjustment).

-| Press the MENU/ENTER button.

• The main menu appears on the screen.

2 Select “PIXEL CLOCK” with the cursor ^ button ▲ or ▼.

• The selected item (displayed in text) is shown in magenta color

on the screen.

0 Press the MENU/ENTER button.

• The submenu items of the PIXEL CLOCK menu appears on the

□ pixel clock

TRACKING PHASE
◄ ► 0

AT

0

Main menu

COMPUTERI

1 01 P'D'S'TTTO'N

Submenu item (PIXEL CLOCK)

■ The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.

' A dim screen could be caused by insufficient adjustment of

brightness and contrast. Before adjusting phase, make sure

that brightness and contrast are correctly adjusted.

j QjPIXEL CLOCK j

0PICTURE
0SOUND

□ options

0SOURCE

DECODER AUTO ( )
LANGUAGE ENGLISH

SXGA2

(PIXEL CLOCK menu)

Adjust “TRACKING” and “PHASE” with the cursor buttons.

•Adjust the tracking and phase of the video screen being
projected. To adjust the phase, first check for correct tracking
adjustment.

Adjustment item Button Adjustment content

The screen shrinks laterally (right-

TRACKING

PHASE

* To reset to the factory-set adjustment values, press the remote

control’s PRESET button.
Tracking and phase are reset to the factory-set adjustment values.

To return to the main menu, press the PAGE
BACK button. To finish the main menu, press
PAGE BACK again.

• To finish the menu display from the submenu display (PIXEL

CLOCK menu), press PAGE BACK twice.

to-left). (-255 ^ 0 ^ -H255)
The screen extends laterally

►

(right-to-left). (-255 0 ^ +255)
Set to a position where text

appears clear.
(-127-^0^-Hi 27)

▲
▼ (-127^0h--h127)

37

Operating the Main Menu (Cent.)

Adjusting the Screen Position

Remote control unit

PAGE BACK button

IMain menu

MENU/ENTER
button

Cursor buttons

Adjust the position of the screen if it is displaced.

■| Press the MENU/ENTER button.

•The main menu appears on the screen.

2 Select “POSITION” with the cursor

button A or

• The selected item (displayed in text) is shown in magenta color

on the screen.

T.

2 Press the MENU/ENTER button.

•The submenu items of the POSITION menu appear on the

screen.

□ POSITION

H.POS. H.POS.

◄ ► 0

AT

(POSITION menu)

Adjust “H. POS.” and “V. POS.” with the
cursor buttons.

• Adjust the horizontal and vertical positions of the video picture

screen being projected.

Adjustment item

H. POS.

V. POS.

' To reset to the factory-set adjustment values, press the remote

control’s PRESET button. H. POS. and V. POS. are reset to the
factory-set adjustment values.

Button Adjustment content

The screen moves to the left.

◄

(-255 ^ 0 ^ +255)
The screen moves to the right.

►

(-255 ^ 0 ^ +255)
The screen moves upwards.

A

(-120^0^+120)
The screen moves downwards.

▼

(-120 ^ 0 ^+120)

' The selected item is shown in magenta color. Items shown
In gray color cannot be operated or set in the current mode.

38

To return to the main menu, press the PAGE
BACK button. To finish the main menu, press
PAGE BACK again.

• To finish the menu display from the submenu display (POSITION

menu), press PAGE BACK twice.

Operating the Main Menu (Cent.)

Adjusting Picture Quality

Remote control unit

Adjust brightness, contrast, etc. so you have the desired screen.
Adjustment items (on the PICTURE menu) are different when AV
signals are input and when computer signals are input.

-| Press the MENU/ENTER button.

• The main menu appears on the screen.

O Select “PICTURE” with the cursor ^ button ▲ or ▼.

• The selected item (displayed in text) is shown in magenta color

on the screen.

2 Press the MENU/ENTER button.

•The submenu items of the PICTURE menu appear on the

screen.

■ When AV signals are input

□picture

(NTSC)

BRIGHTNESS 0
CONTRAST
SHARPNESS
COLOR

TINT
0ALL RESET

0
3
3
1

Main menu

Qpixel clock

0PICTURE

0OPTIONS
□SOURCE

DECODER
LANGUAGE

Submenu item (PICTURE)

' The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.

' Adjustment items (on the PICTURE menu) are different when

AV signals are input and when computer signals are input.

AUTO(NTSC)

ENGLISH

(PICTURE menu)

When computer signals are input

□picture

(SXGA2)

BRIGHTNESS

contrast

R-GAIN

g-gain 0

B-GAIN 0

text mode

□ all reset

0
0
0

NORMAL

(PICTURE menu)

A Select the item to adjust with the cursor

^ button ▲ or

• The items to adjust (shown in text) is displayed In magenta color.

T.

39

Operating the Main Menu (Cent.)

Adjusting Picture Quality (Cont.)

IRemote control unit

OPERATE COMPUTER VIDEO

□ CD CZZ)

1 -r 1

1 -1

1 w 1

PAGE BACK button

■Submenu items

[PICTURE menu]

□picture

(NTSC)

BRIGHTNESS
CONTRAST

SHARPNESS

COLOR
TINT
y ALL RESET

MENU/ENTER
button

Cursor buttons

0
0
3

- 3
1

C Make adjustment with the cursor

^ button ◄ or ►.

■ For video system input

• To adjust multiple items, repeat steps 4 and 5.

• To reset all items (to factory-set adjustment values “0”), select
ALL RESET with the cursor buttons and press the MENU/

ENTER button.

• To reset only the selected items (ALL RESET excluded) to
the factory-set adjustment value, press the remote control’s

PRESET button. The selected item is reset to the factory-set

adjustment value.

Adjustment item

BRIGHTNESS

CONTRAST

SHARPNESS

COLOR

TINT

ALL RESET

Button

◄

►

◄

►

◄

►

◄

►

Adjustment content

Gets darker.
(-30 ^ 0 ^ +30)

Gets brighter.
(-30 ^ 0 ^ +30)

Gets lower.
(-30 ^ 0 ^ +30)

Gets higher.
(-30 ^ 0 ^ +30)

Gets softer.
(0^7)

Gets sharper.
(0^7)

Gets softer.
(-30 ^ 0 ^ +30)

Gets deeper.
(-30 ^ 0 ^ +30)

Gets reddish.
(-30 ^ 0 ^ +30)

Gets greenish.

►

(-30 ^ 0 ^ +30)
Resets all adjustment values of

MENU/

items on the PICTURE menu to

ENTER

the factory-set values (0).

• The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.

• Adjustment items (on the PICTURE menu) are different when
AV signals are input and when computer signals are input.

40

■ The adjustment item, TINT, is displayed only for NTSC system. It is not
displayed (cannot be adjusted) when PAL or SECAM system signals are
input.

■ When video signals are input to the PC IN-2 terminal, adjustment items
“COLOR” and “TINT” are indicated but cannot be adjusted.

For computer system input

• To adjust multiple items, repeat steps 4 and 5.

• To reset all items (to factory-set adjustment values “0”), select
ALL RESET with the cursor buttons and press the MENU/ENTER

button.

• To reset only the selected items (ALL RESET excluded) to the
factory-set adjustment value, press the remote control’s PRESET

button. The selected item is reset to the factory-set adjustment

value.

Operating the Main Menu (Cent.)

Adjusting Picture Quality (Cent.)

I Remote control unit

■Submenu items

[PICTURE menu]

□picture

(SXGA2)

BRIGHTNESS 0
CONTRAST
R-GAlN 0
G-GAIN
B-GAIN

TEXT MODE

□ all reset

• The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.

• Adjustment items (on the PICTURE menu) are different when
AV signals are input and when computer signals are input.

0
0

0

NORMAL

Adjustment item Button

BRIGHTNESS

CONTRAST

R-GAIN

G-GAIN

B-GAIN

TEXT MODE Sets a mode which allows easy

ALL RESET

• There is a relationship between the adjustment of items R-GAIN, G-GAIN,
and B-GAIN and that of item CONTRAST. For example, when adjustment
values are : R-GAIN: 0, G-GAIN: 5, B-GAIN: 0, and CONTRAST: 0, changing
CONTRAST to 1 changes the adjustment values as follows: R-GAIN: 1, G­GAIN: 6, and B-GAIN: 1.
Also, when the adjustment value of any of R-GAIN, G-GAIN, and B-GAIN
has reached -30 (minimum) or +30 (maximum), CONTRAST cannot be
adjusted to any higher value. For example, when R-GAIN is 0, G-GAIN is 5,
B-GAlN is 0, and CONTRAST is 0, increasing CONTRAST allows the other
adjustment values to increase until R-GAIN: 25, G-GAIN: 30, and B-GAIN:
25, then CONTRAST becomes 25 and cannot be adjusted to any higher
value.

►

►

►

►

◄

►

◄

►

MENU/

ENTER

Adjustment content

Gets darker.

(-30 ^ 0 -p30)

Gets brighter.

(-30 ^ 0 ^ -p30)
Gets lower.

(-30 ^ 0 ^ -p30)

Gets higher.
(-30 -+0^ +30)

Gets less reddish.
(-30 ^ 0 +- +30)

Gets more reddish.
(-30 -+ 0 ^ +30)

Gets less greenish.
(-30 ^ 0 +- +30)

Gets more greenish.
(-30 ^ 0 ^ +30)

Gets less bluish.
(-30 <- 0 ^ +30)

Gets more bluish.
(-30 ^ 0 -+ +30)

text reading.
1" NORMAL+i— TEXT1 >#~|

TEXT2

r®-NORMALTEXT1 —;

Resets all adjustment values of
items on the PICTURE quality
menu to the factory-set status
(adjustment values: 0, text
mode: NORMAL).

• To return to the main menu, press the PAGE

BACK button. To finish the main menu, press
PAGE BACK again.

' To finish the menu display from the submenu display (PICTURE

menu), press PAGE BACK twice.

41

Operating the Main Menu (Cent.)

Adjusting Sound Quality

Remote control unit

PAGE BACK button

Main menu

Adjust the quality (treble/bass) of sound.

-| Press the MENU/ENTER button.

•The main menu appears on the screen.

2 Select the “SOUND” with the cursor ^ button A or ▼.

• The selected item (displayed in text) is shown in magenta color

on the screen.

3 Press the MENU/ENTER button.

•The submenu items of the SOUND menu appear on the screen.

4 Adjust “TREBLE” and “BASS” with the ^ cursor buttons.

• Adjust the quality (TREBLE and BASS) of sound.

Adjustment item Button Adjustment content

Gets weaker.

◄

►

▲

▼

(-5^0^ +5)
Gets stronger.

(-5-^0^ +5)
Gets stronger.

(-5^0^ +5)
Gets weaker.

(-5^0^ +5)

TREBLE

BASS

* To reset to the factory-set adjustment values, press the remote

control’s PRESET button. The treble and bass are reset to the
factory-set adjustment values.

' The selected item is shown in magenta color, items shown

in gray coior cannot be operated or set in the current mode.

42

• To return to the main menu, press the PAGE
BACK button. To finish the main menu, press
PAGE BACK again.

•To finish the menu display from the submenu display (SOUND

menu), press PAGE BACK twice.

Operating the Main Menu (Cent.)

Setting and Adjusting Other Functions (OPTIONS)

Remote control unit

OPERATE

CZ)

1 +1

VOL.

m

PAGE BACK button

COMPUTER VIDEO

CD CZD

m

FOCUS

ZOOM

1 W 1

CZ]

ENTER li

1 1 '’I. .

Main menu

□ pixel clock
□ position
□ picture

„-O&aujm™——-

□ OPTIONS

■™—p-STTiTiTC^“—

DECODER AUTO(NTSC)
LANGUAGE ENGLISH

MENU/ENTER
button

Cursor buttons

The following optional functions can be set (adjusted).

• MENU AUTO OFF • LINE DISPLAY • RIGHT LEFT REV.

• TOP BOTTOM INV. • CLAMP • RESIZE

•BACK COLOR ‘COLOR TEMPERATURE

•ASPECT CHANGE ‘SLEEP TIME ‘LAMP TIME

About the lamp use time

The lamp use time indicates the accumulated used hours of the lamp and
cannot be set or adjusted. When you have replaced with a new lamp, reset the
lamp use time (see page 50).

• The RESIZE function works for only computer system input. It does network
for video system input.

-| Press the MENU/ENTER button.

• The main menu appears on the screen.

2 Select the “OPTIONS” with the cursor
^ button A or

• The selected item (displayed in text) Is shown in magenta color

on the screen.

T.

0 Press the MENU/ENTER button.

• The submenu items of the OPTIONS menu are displayed.

□ OPTIONS

MENU AUTO OFF
LINE DISPLAY ON
RIGHT LEFT REV.
TOP BOTTOM INV.
CLAMP BP
RESIZE ON
BACK COLOR
COLOR TEMP.
ASPECT CHANGE 4:3
SLEEP TIME
LAMP TIME 10 H.

(OPTIONS menu)

NO

OFF
OFF

BLUE
MIDDLE

30 Min.

Submenu item (OPTIONS)

' The selected item is shown in magenta color. Items shown

in gray color cannot be operated or set in the current mode.

' Items to be set (adjusted) are different when AV signals are

input and when computer signals are input.

^ Select the item to set (adjust) with the
^ cursor button A or

• The item to set (adjust) is shown in magenta color.

T.

43

Operating the Main Menu (Cent.)

Setting and Adjusting Other Functions (OPTIONS) (Cent.)

■Remote control unit

MENU/ENTER

button

OPERATE COMPUTER VIDEO

CZZ)

Cursor buttons

PAGE BACK button

■Submenu items

[OPTIONS menu]

y OPTIONS

MENU AUTO OFF NO
LINE DISPLAY
RIGHT LEFT REV. OFF
TOP BOTTOM INV,
CLAMP BP
RESIZE ON
BACK COLOR BLUE
COLOR TEMP.
ASPECT CHANGE
SLEEP TIME
LAMP TIME

• The selected item is shown in magenta coior. items shown
in gray coior cannot be operated or set in the current mode.

• items to be set (adjusted) are different when AV signais are
input and when computer signais are input.

• When you turn the RESiZE function ON, aiiowing the screen
to be eniarged virtualiy to its fuli size for projection (resizing
dispiay), the video image (resolution) becomes coarse.

ON
OFF

MIDDLE
4:3
30 Min.

10 H.

^ Set (adjust) the desired item with the ^ cursor button ◄ or ►.

• To adjust multiple items, repeat steps 4 and 5.

Adjustment item

MENU AUTO
OFF

LINE DISPLAY

RIGHT LEFT
REV.

TOP BOTTOM
INV.

CLAMP

RESIZE

Button

Sets whether to clear the menu display
automatically a fixed time later or not.
(Factory setting : NO)

YES: Clears the display automatically in

*/►

NO : Does not clear the display

Sets whether to show the line display (Y/C,
VIDEO, etc.) at the top of the projected
screen or not. (Factory setting : ON)

OFF; Does not show the line display.
ON : Shows the line display.

OFF ON

Reverses video image right-to-left.
(Factory setting : OFF)

OFF: For the front method
ON : For upside hanging from the ceiling

OFF ON

Inverses video image upside-down.
(Factory setting : OFF)

OFF: For normal set-up
ON : For upside hanging from the ceiling

OFF .#»»»»»#. ON

Sets the clamp pulse’s position at the back
porch (BP) or on the sink tip (ST).
Normally, the clamp is used at BP. If, with
some PCs or workstations, the screen
becomes unstable such as being too dark
or too bright, try to switch to ST.
(factory setting: BP)

BP : The clamp pulse is positioned at the

ST : The clamp pulse is positioned on the

When the number of pixels (resolution)
sought by the input video is smaller than
that (resolution) of D-ILA device, the video
image is then enlarged to virtually full
screen size of D-ILA device and projected
(resizing display). (Factory setting : ON)
Cannot be set for AV input.

OFF : Does not enlarge the video image for

ON : Enlarges virtually to the full screen

OFF «#—«► ON

Adjustment content

about 25 seconds.

automatically.

YES

(The line display disappears about 5
seconds after it is shown.)

back porch.

sink tip.

ST

projection. When the number of
pixels sought by video image is
smaller than that of D-ILA device,
projection takes place on a small
screen size with a black area around
the screen.

size of D-ILA device for projection
(resizing display).

44

Operating the Main Menu (Cent.)

Setting and Adjusting Other Functions (OPTIONS) (Cont.)

IRemote control unit

ISubmenu items

[OPTIONS menu]

Adjustment item Button

BACK COLOR

COLOR
TEMP.

ASPECT
CHANGE

SLEEP TIME

Adjustment content

Sets background color when there is no input

signal. (Factory setting ; BLUE)

BLUE CYAN o«™™* BLACK GREEN

I ^
1 4

YELLOW RED MAGENTA

Sets the color temperature of the video image
being projected. Make adjustment when the
image becomes reddish or bluish. (Factory
setting : MIDDLE)

LOW : Color temperature decreases

(video image becoming reddish).

MIDDLE: Results in middle color

temperature.

HIGH : Color temperature increases

(video image becoming bluish).

LOW MIDDLE HIGH

Sets the vertioal-to-horizontal ratio (4 : 3 or 16
: 9) of the video image projected. (Factory
setting : 4 : 3)

4:3: The aspect ratio of the screen

becomes 4 : 3. Set it to 4 : 3 for video
of NTSC, NTSC4.43, PAL, SECAM.

16:9: The aspect ratio of the screen

becomes 16:9. Set it to 16 : 9 for Hi­Vision devices (W-VHS VCR, etc.)

4 ; 3 16 : 9

Sets the length of sleep time which
automatically brings the projector into stand
by state. You can select one of the following
sleep times : 10 minutes, 20 minute, 30
minutes, and 60 minutes. (Factory setting :
30 minutes)
10 20 30 *—*• 60

□ OPTIONS

MENU AUTO OFF
LINE DISPLAY ON
RIGHT LEFT REV. OFF
TOP BOTTOM INV. OFF
CLAMP BP
RESIZE ON
BACK COLOR BLUE
COLOR TEMP.
ASPECT CHANGE 4:3
SLEEP TIME 30 Min.
LAMP TIME 10 H.

' The selected item is shown in magenta color, items shown

in gray color cannot be operated or set in the current mode.

' Items to be set (adjusted) are different when AV signals are

input and when computer signals are input.

NO

MIDDLE

To return to the main menu, press the PAGE

BACK button. To finish the main menu, press
PAGE BACK again.

• To finish the menu display from the submenu display (OPTIONS

menu), press PAGE BACK twice.

• When you view a conventional (normal) 4 :3 video picture, which is not wide
video picture, on the projector’s screen the aspect change function, the upper
and lower parts of the video picture become partially invisible.

45

Operating the Main Menu (Cent.)

Changing (Setting) the Source

Remote control unit

MENU/ENTER

button

Cursor buttons

Normally set to AUTO. If the image is unstable, or does not display
color, select the input souce from the list.

' When shipped from the factory, the source settings are as follows:

Input mode Factory setting Input mode

VIDEO NTSC COMPUTER 1

Y/C

NTSC COMPUTER 2

Y, Pb/B-Y, Pr/R-Y AUTO

—

Factory setting

AUTO
AUTO

—

■ Depending on the signal from a device connected, adjustment may be needed
after a dedicated source is set. If that is the case, adjust the appropriate
items.

' When the input mode (SOURCE) is VIDEO or Y/C, and if AUTO is set, the

automatic detecting function may work, possibly causing the screen to be
intermitted or disturbed, in that case, set to a dedicated source (forced mode).

' When special effect playback (fast-forward/ twice-speed/triple-speed) is

performed on a video deck, etc, the picture may be disturbed or intermitted,

depending on the device.

Press the MENU/ENTER button.

• The main menu appears on the screen.

PAGE BACK button

IMain menu

AUTO (NTSC)

□ pixel clock
□ position
□ picture
□sound

...Qaaiiims

DECODER AUTO(NTSC)
LANGUAGE ENGLISH

Submenu item [SOURCE]

' The selected item is shown in magenta color. Items shown

in gray color cannot be operated or set in the current mode.

' Items that can be set are different when AV signals are input

and when computer signals are input.

' For dedicated source signals (corresponding frequency, etc.)

for computer signals, see page 19.

□SOURCE

----------

2 Select a submenu item “SOURCE”
^ using the cursor button a or

• The SOURCE item (shown in text) is indicated in magenta color.

t.

2 Press the MENU/ENTER button.

•The submenu items, SOURCE menu, appears on the screen.

j (AUTO) ]-------------------------------------------------------

□auto

□ ntsc

□ PAL/SECAM
QEDTV II

Qhdtv

OPC-98
□ VGAI
OVGA3

□ MAC13

□ VGA VESA

□ SVGAI
□ SVGA2
□ MAC16
gXGAI
□ XGA2
QMAC19
□ MAC21
QSXGA1
gSXGA2
QSXGA3

--------

-The display in ( ) shows
the currently set status.

(SOURCE menu)

Select the item to set using the cursor
buttons

• The item to set is shown in magenta color.

A/T

or ◄/►.

□source

□auto
□ ntsc

□ PAL/SECAM
□ EDTV II
□ HDTV
□ PC-98
QVGAI
□ VGA3
□ MACI 3
□ VGA VESA

(AUTO)

□ SVGAI
□ SVGA2
Q) M AC 1 6
□ XGA1
□ XGA2
QMACI 9
□ MAC21
□ SXGA1
□ SXGA2
ySXGA3

46

Operating the Main Menu (Cent.)

Changing (Setting) the Source (Cont.)

Remote control unit

Submenu item

(SOURCE menu)

□source

(AUTO)

□ auto
□ ntsc
□ pal/secam
Qedtv II

□ HDTV
OPC-98
□ VGA1
OVGA3

□ MAC1 3

QVGA VESA

□ SVGA1
□SVGA2
□ MAC1 6
QXGA1
□ XGA2
yMAC19
□ MAC21
ySXGAI
ySXGA2
ySXGAS

C Press the MENU/ENTER button to set

^it.

M When AUTO is selected:

The main menu is automaticaily cleared, completing the
setting procedure, and the source display inputted appears.

• Both line display and source display appear on the screen
and disappear in five seconds. However, they do not appear
if the line display is set to OFF.

□source

(AUTO)

□auto
□ ntsc
□ pal/secam

□ EDTV II
□ HDTV
□ PC-98
□ VGA!
□ VGA3
□ MAC13
□ VGA VESA

□ SVGAI
□ SVGA2
□ MAC16
□ XGA1
□ XGA2
g|MACl9
□ MAC21
QSXGA1
gSXGA2
QSXGA3

I When other than AUTO is selected:

The selected item is shown in ( ) beneath the Indicated
text “SOURCE” at the top of the screen, completing the
setting procedure.

•To finish the menu display, press the PAGE BACK button
twice (the first press returns you to the main menu and the
second press clears it).

□source

(NTSC)

Oauto
□ ntsc

□ PAL/SECAM
□ EDTV II
□ HDTV
□ PC-98

Qvgai

□ VGA3
OMAC13
UVGA VESA

□ SVGAI
OSVGA2
QjMACi 6
□ XGA1
□ XGA2
QMAC1 9
QMAC21
QSXGA1
□SXGA2
QSXGA3

Press the PAGE BACK

button.

' The selected item is shown in magenta color. Items shown

in gray color cannot be operated or set in the current mode.

' Items that can be set are different when AV signals are input

and when computer signals are input.

■ For dedicated source signals (corresponding frequency, etc.)
for computer signals, see page 19.

47

Replacing the Lamp

The lamp service life is 1000 hours.

When the lamp approaches the end of its service life, its degradation progresses rapidly. When the lamp’s used hours exceeds
900 hours, the projector’s “lamp replace’’ indicator comes on. Also, at the start of projection (lamp energized), the message
“REPL.-LAMP” appears on the projection screen for about two minutes. Then, replace with a new lamp, or arrange for a

replacement lamp. When lamp’s service has reached 1000 hours, the projector’s “lamp replace” indicator starts blinking, and if
you press the “operate” button or press the remote control’s OPERATE button for more than one second, the lamp does not turn
on. The specified lamp replacement period is 1000 hours, but depending on use conditions, the replacement period may vary.

If video image is dark and its color tint is extraordinary even after you have adjusted color tint and brightness, replace the lamp
a little earlier.

Purchase new lamps from the dealer where you have purchased the projector, or consult the nearest service center.

CAUTIONS and NOTES

’ If the projector is set up in a tight place which is unsuitable for work, and if you perform replacement work there, this could hurt

you. Move the projector to a place wide enough for work, and then replace the lamp.

’ Use a genuine product for the lamp. If you use other than a genuine product, this could cause a malfunction. Also, never use

an old lamp. An old lamp could cause marked degradation in performance or explode, possibly causing the projector to
malfunction. Also, its broken pieces could come out of the projector and harm you when replacing the lamp.

' Do not replace the lamp immediately after the projector has been used. The temperature of the lamp is still high and could

cause a burn. Be sure to allow a cooling period of one hour or more before performing replacement work.

' Before starting lamp replacement work, turn off the MAIN POWER switch (see page 26), and disconnect the power cord from

the wall outlet. If you perform the replacement work with the power cord left connected, this could cause harm or electric
shock.

’ Never discard an old lamp (used lamp), as is. Otherwise, this could involve a great danger. The lamp contains an xenon gas

inside, which is applying a high pressure. If the gas is not removed, it could cause the lamp to explode.
For handling used lamps, refer to the manual supplied with the new replacement lamp you have purchased. If you have any
questions, consult an authorized dealer where you have bought the replacement lamp or nearest service center.

-| Remove the lamp-replacement
’ opening cover by loosening

screws.

Loosen the two screws with a flat-end screwdriver.

' The screws are fitted so that they do not come off the lamp-

replacement opening cover.

48

Replacing the Lamp (Cent.)

2 Loosen the lamp-unit screws, raise
^ the handle, and pull out the lamp

unit.

Loosen the two screws with a flat-end screwdriver.

' The screws are fitted so that they do not come off the lamp-

unit.

Q Insert the new lamp unit fully

^ Inside and fasten the screws.

Fasten the two screws with a flat-end screwdriver.

CAUTION

> Do not touch the glass surface of the lamp directly with

your hand as well as staining it. If you touch with a bare
hand, stains on your hand may adhere to the lamp,

possibly preventing the lamp from performing as
specified due to a shortened lamp life, a darkened screen,
etc. To handle a new lamp, hold its plastic part. Never
touch the metal part or the front glass surface.

Replace the lamp-replacement

opening cover and fasten the screws.

Fasten the two screws with a flat-end screwdriver.

Lamp-replacement

CAUTIONS

' Install the lamp unit and close the lamp-replacement opening cover correctly; otherwise, a safety switch is activated

to prevent the projector from operating.

' If the claw on the lamp-replacement opening cover is damaged, the projector may not operate. Then, replace with a

new lamp-replacement opening cover.

' After replacing the lamp, be sure to reset the lamp use time (see page 50).

49

Replacing the Lamp (Cont.)

Resetting the Lamp Use Time

After replacing with a new lamp, reset the counter inside the projector. This works to reset the life calculation of the lamp,
allowing the used time of the new lamp to be accumulated.

IProjector’s button

[MAIN POWER switch]

[Control panel]

operate

lamp replace ( )

temperature ( )

emergency (—)

1

“stand by” indicator

“operate” indicator

■j Turn on the MAIN POWER switch

" to go into stand-by mode.

• ON [ I ];The main power turns ON and the “stand by”

indicator lights.

2 Press and hold down the “video,”

“setting” and “quick align +” at the

same time for six seconds or more.

• The “stand by” and “operate” indicators come on at the

same time.

Q While the “stand by” and “operate”
'^indicators are on, press the

“video,” “setting” and “computer”
buttons at the same time.

• The “stand by” and “operate” indicators blink two seconds
alternately, and after blinking, the projector returns to
stand-by state (the “stand by” indicator lights).

• This completes the resetting of the lamp use time.

To check the lamp use time has been reset:

You can check it by LAMP TIME on the OPTIONS menu.

CAUTIONS

• After replacing with a new lamp, be sure to reset the
lamp use time. When the lamp use time indicates 1000
hours, and if it is not reset, the projector does not

operate. (The lamp does not turn on.)

• Reset the lamp use time only when you have replaced
with a new lamp. Never reset it at a halfway time.

Otherwise, the replacement time may become unclear,
degrade performance markedly, or cause lamp

explosion.

50

Cleaning and Replacing the Filter

Clean the filter periodically. If the filter is heavily stained and does not get clean, or if it is damaged, replace the filter

with a new filter. Otherwise, dirt may get inside and appear on the screen. If dirt gets inside or if you need information
about the filter, consult an authorized dealer where you have purchased the projector.

Turn off the MAIN POWER switch.

1

After the projector goes into stand-by state with the “stand by” indicator on, turn off the main power switch and pull out the
power cord from the projector and the wall outlet.

_____________

Remove the filter.

Loosen the screw with a flat-end screwdriver.

• The screws are fitted so that they do not come off the filter.

• If the filter is clogged with dirt, etc., the projector goes into an
emergency mode (the “emergency” indicator blinks).
So, clean the filter periodically. For the emergency mode, refer to
pages 9 and 25.

2 Clean the filter.

Clean the filter with a neutral detergent, wash it in water, and then dry it in the shade.

^ Reinstall the filter.

Fasten the screw with a flat-end screwdriver.

' Install the filter correctly. Othenwlse, the projector does not operate.

(Goes Into an emergency mode.)

• If the filter’s claws are damaged, the projector may not operate. Then,
replace with a new filter.

CAUTIONS

Put on rubber gloves when using neutral detergent.

After you have washed the filter in water, make sure the filter is
completely dry before reinstalling it. Otherwise, electric shock
or malfunction could occur.

Do not clean the filter using a vacuum cleaner. Since the filter
is soft, it may be sucked into the vacuum cleaner or damaged.

51

Troubleshooting

Solutions to common problems related to your projector are described here. If none of the solutions presented here solves the
problem, unplug the projector and consult an authorized dealer.

Symptom

Projector will not turn
on.

Light is not emitted,
or light level is low.

With power on,
operation starts but
stops in a few minutes.

Video image does not
appear, or audio
sound does not occur.

Probable cause

• Is the power cord disconnected?

• Is the main power switch turned on?

• Is the lamp-replacement opening cover

closed correctly?

• Is the air filter closed correctly?

• Has the lamp life expired? (Has the

lamp use time reached 1000 hours?)

• Is the lens cap removed?

• Is the lamp life near its end?

• Is the air intake or exhaust area

blocked?

• Is the correct input selected? • Select the correct inputs with the

• Are the devices connected correctly? • Connect the devices correctly.

• Insert the power cord (plug) firmly. 24

• Turn on the MAIN POWER switch.

• Turn off the MAIN POWER switch,
close the lamp-replacement opening
cover, and turn on the main power
switch again.

• Turn off the MAIN POWER switch, fit
the air filter correctly, and turn on the
main power switch again.

• Turn off the MAIN POWER switch,
replace with a new lamp, and turn on
the MAIN POWER switch. Reset the
lamp use time after replacing with a
new lamp.

• Remove the lens cap. 24

• Check the lamp use time on the menu,
and if the lamp life is near its end,
arrange for a replacement lamp, or
replace a little earlier.

• Turn off the MAIN POWER switch,
remove any blocking objects, and turn
on the MAIN POWER switch again.

VIDEO (or “video”) and COMPUTER
(or “computer”) buttons.

Corrective action Page

26

26, 48

26, 51

26, 48, 50

43

6, 8, 15, 26

27

19

Video image is not
clear.

Color is poor or

unstable.

• Are signals being supplied from the

connected devices?

• Are input signals (scanning frequency,

etc.) appropriate?

• Is the source setting correctly selected? • Set the source setting to AUTO or to

• Is brightness adjusted correctly?

• Is volume set at minimum? • Adjust volume with the remote control’s

• Aren’t video and audio turned off by
pressing the remote control’s AV
MUTING button?

• Is focus adjusted correctly? • Adjust focus with the remote control’s

• Is distance too short or too long? • Set the projector at the correct

• Are TRACKING and PHASE adjusted
correctly?

• Is picture quality (color density, etc.)
adjusted correctly?

• Is the correct broadcast system (color
system) selected?

• Are signals (scanning frequency, etc.) to
connected devices appropriate?

• Is the source setting correctly selected?
Isn’t a wrong source (forced mode)
selected?

• Set the devices correctly.

• Check if the signal is correct as input

(scanning frequency, etc.).
Input the appropriate signal.

the correct dedicated source (forced

mode).

• Adjust brightness on the menu.

VOL. (-I-/-) buttons.

• Press the remote control’s AV MUTING

button to turn video and audio on.

FOCUS (+/-) buttons.

distance.

• Adjust TRACKING and PHASE on the

menu.

• Adjust picture quality on the menu.

• Set the broadcast system (color

system) to AUTO.

• Check if the signal is appropriate
(scanning frequency, etc.), and input

the appropriate signal.

• Set the source setting to AUTO. If the
problem still persists, set it to the

correct dedicated source (forced mode).

—

19

46, 47

39

28

29

28, 31

16, 17

31,37

39

35

19

46

52

Symptom

The upper part of the
video image bows or
distorts.

Video image and
audio sound suddenly
go out.

Remote control unit

• While computer system signal is input,
using a sync signal for composite sync
(Cs) or G on sync being input?

• Isn’t signal with much jitter or skew
distortion being input from a VCR?

• Is the source setting correctly selected?
Isn’t a wrong source (forced mode)

selected?

• Are video picture and audio turned off

by pressing the AV MUTING button on
the remote control unit?

• Are batteries installed correctly? • Match the polarities of batteries

does not work.

• Are batteries exhausted? • Replace with new batteries. 14

• Is there a shielding object between the
remote control unit and the remote

sensor?

• Is the distance too long?

' This projector is equipped with a microcomputer that may operate abnormally due to interference from external components.

If this happens, turn off the main power and disconnect the power cord from the wall AC outlet. Then reconnect the power cord

to AC outlet and turn on the main power again.

(For the turning on and off the power, see pages 25 to 26.)

Probable cause

Corrective action

• Input separate sync signals for vertical
sync (V) and horizontal sync (H)
signals.

• Input signals with little jitter or distor
tion.

• Set the source setting to AUTO. If the
problem still persists, set it to the
correct dedicated source (forced
mode).

• Turn on video picture and audio by
pressing the remote control’s AV
MUTING.

correctly (-1- to + and - to -).

• Remove any shielding objects.

• Use the remote control unit at a nearer
point.

Page

12

—

46

29

14

18

18

Maintenance

• Stains on the cabinet

Should be wiped off with a soft cloth. If the cabinet is heavily stained, wipe it with a damp cloth with water-diluted neutral
detergent, then wipe clean with a dry cloth.

• Since the cabinet may deteriorate in quaiity, become damaged or get its paint peeled off, be careful about the following;

- Do not wipe it with a hard cloth.

- Do not wipe it strong.

- Do not wipe it with thinner or benzene.

- Do not apply any volatile substance such as insecticides to it.

- Do not allow any rubber or vinyl article to remain in contact with it for a long time.

• Stains on the lens

Should be cleaned off with commercially available blowers or lens cleaning paper (for cleaning glasses and cameras).
Do not use liquid cleaning agents. This could cause the surface coating to be removed.
Do not rub or hit the lens as its surface is prone to damage.

53

Specifications

Optical mechanism system

' Projection method 3D-ILA device, 1 lens, 3 primary color optical shutter method
> D-ILA device 0.9'' measured diagonally (1365 x1024 pixels) x 3 (Total number of pixels : 4,193,280)

• Projecting lens Electric-driven zoom of 1.5 x

• Screen size 42" to 300" [recommended] to 521" [maximum] measured diagonally (*with aspect ratio : 4: 3)

• Light-source lamp 400 W xenon lamp

Electrical system

• Color system

• Resolution

• Scanning frequency

Input / output

[AV IN input]

• “S-video”

“video” 1-line, BNC X 1

NTSC, NTSC4.43, PAL, SECAM (* Automatic switching / manual switching)
1365 x 1024 dots (*S-XGA full resolution, during RGB input)
1000TV lines (‘Horizontal resolution, aspect ratio 4 : 3, during video input)
Horizontal frequency : 15 kHz ~ 82 kHz

Vertical frequency : 50 Hz ~ 78 Hz

1-line, mini-DIN 4 pin x 1

Y (luminance signal)
C (chroma signal)

Composite video signal 1 Vp-p, 75Q (negative sync)

1 Vp-p, 75Q (negative sync)

0.286Vp-p (burst signal), 75Q [NTSC]

0.3Vp-p (burst signal), 75Q [PAL]

' “video/y, c/cb(b-y), cr(r-y)” 1-line, BNC x 3

Component -“Y,Cb,Cr or Y,B-Y,R-Y”- signals

“video/y” [Y]
“c/cb(b-y)” [Cb/B-Y]
“cr(r-y)” [Cr/Y-R]
High-vision base band -“Y,Pb,Pr”- signals
“video/y” [Y]
“c/cb(b-y)” [Pb]
“cr(r-y)” [Pr]

• “audio L/R” (for AV IN)

1-line, RCAx 2

Audio signal: 0.5Vrms, high impedance

[Computer input]

• PC IN-1 (analog RBG)

' “audio” for PC IN-1

1-line, D-sub 3-row 15 pin x 1

Analog RGB signal

R
B

G

G on Sync

Sync signal

Some connected devices may not correspond to composite sync (Cs) or G on sync signal.

1-line, stereo mini-jack x 1

0.5Vrms, high impedance

1 Vp-p, 75Q (negative sync)

0.7Vp-p, 75Q

0,7Vp-p, 75Q

1 Vp-p, 75Q (3-value sync)
± 0.35Vp-p, 75Q
± 0.35Vp-p, 75Q

0.7Vp-p, 75Q

0.7Vp-p, 75Q

0.7Vp-p, 75Q
IVp-p, 75i2 (negative sync)
1 to 5Vp-p, high impedance (positive/negative polarity)

54

- PC IN-2

1-line, BNC x 5

Analog RGB signal

R
B
G
G on sync

0.7Vp-p, 75Q

0.7Vp-p, 75Q

0.7Vp-p, 75Q
IVp-p, 75Q (negative sync)

Specifications (Cont.)

Horizontal sync/composite sync signal (H/Cs)
H ; 1 to 5Vp-p, high impedance (positive/negative polarity)
Cs : 1 to 5Vp-p, high impedance (positive/negative polarity)

Vertical sync signal (V)
V : 1 to 5Vp-p, high impedance (positive/negative polarity)
* Some connected devices may not correspond to composite sync (Cs) or G on sync signal.

' “audio” for PC IN-2

[Computer output]

• “monitor”

’ “audio OUT”

[Control]

• RS-232C

• “remote”

1-line, stereo mini-jack x 1

O.SVrms, high impedance

1-line, D-sub 3-row 15-pin x 1

Analog RGB signal
R ; 0.7Vp-p, 75Q
B : 0.7VP-P, 75Q
G : 0.7Vp-p, 75Ì2
G on sync : 1 Vp-p, 75Q (negative sync)

Horizontal sync/composite sync signal (H/Cs)
H ; TTL level (Polarity : Same for input)
Cs
Vertical sync signal (V)
V : TTL level (Polarity : Same for input)

1-line, stereo mini-jack x 1
0 to O.SVrms (variable output)

: 1-line, D-sub 9-pin x 1

* RS-232C-interface specified control terminal for controlling this projector with a personal

computer.

: 1-line, mini-jack X 1

* Remote terminal for connecting an infrared remote sensor extension unit, etc.

: TTL level (Polarity : Same for input)

[Other]

• Audio power output

(effective)

• Built-in speaker

1 W-t-1 W

6 X 3 cm (2-Va'' x l-Ve") oval type x 2, impedance 8Q

General

• Power requirements
' Power consumption
> Allowable operation temperature

- Allowable relative humidity

• Allowable storage temperature

• Maximum outside dimensions

• Weight
' Accessories

* Design and specifications are subject to change without notice.

*D-iLA devices are manufactured with a very high-precision technology, allowing 99.99% of the pixels to be effective. Only

0.01% or less of the pixels are missing or always on.

* For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed, and may be more

or less different from actual products.

*TRADEMARKS

IBM, IBM PC, and VGA are registered trademarks of International Business Machines Corporation. Macintosh is registered
trademarks of Apple Computer, Inc.

VESA is a trademark of the non-profit organization Video Electronics Standard Association.
All other product names mentioned herein are used for identification purposes only, and may be the trademarks or registered
trademarks of their respective companies.

AC 120 V, 60 Hz
8 A (7 W during stand-by)

-r 5°C to -t- 35°C (41 °F to 95°F)
20% to 80% (no condensation)

- 10°C to-r 60°C (14“Fto 140°F)
Approx. (W)425 X (H)246 x (D)375 mm (16-W x 9-%" x 14-78”)

(excluding protruding parts)
Approx. 32.56 lbs.(14.8kg)
(Refer to page 5.)

*

55

Specifications (Cont.)

Outside dimensions

■ Top

16-% (425)*’

Unit; inch (mm)

*1: Protrusion excluded

I Side

14-% (375)

2-'U (55.5)

56

Specifications (Cont.)

Pin assignment (Specifications for terminals)

iS-video terminai

Pin number

4, ,3

RS-232C terminal

Pin number

I

PC IN-1 (analog RGB) / “monitor” Terminal

Pin number Signal name

Signal name

1
2
3
4

1
2
3
4
5

1
2
3
4
5
6
7
8

GND (Y)
GND (C)

Y
C

Signal name

N/C

RD
TD

N/C

GND

Red

Green

Blue

N/C
N/C

GND (Red)

GND (Green)

GND (Blue)

Pin number

6
7
8
9

........

....■■...............

Pin number

9
10
11
12
13

14

15

Signal name

N/C
N/C
N/C
N/C

..........

Signal name

N/C

GND (SYNC)

GND

N/C
H.SYNC
V.SYNC

N/C

.......................

57
