New Hallingford
4 Door 3 Drawer Wardrobe
DR899243
Assembly Instructions - Please keep for future reference
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
2478441
2497714
2574242
2377700
2588771
Dimensions
Width - 197,9cm
Depth - 60,3cm
Height -205,7cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
03456 400 800
Issue 1 - 12-06-2014
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• From time to time check that
there are no loose screws on
this unit.
•To reduce the
likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Dispose of all packaging
carefully and responsibly.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
2
Components - Panels
If you have damaged or missing parts, call the
Customer Helpline:
Please check you have all the panels listed below
03456 400 800
Left side
1
(205.6 x 58cm)
P2349b
Top/Bottom x 2
6
(194.9 x 57.7cm)
P1349
Drawer base x 3
9
(94.5 x 34.9cm)
BO33956
Right side
2
(205.6 x 58cm)
P2349b
Upright x2
3
(196.9 x 57.6cm)
P2354b
Large horizontal
7
(96.7 x 57.6cm)
P1342
Drawer wrap x 3
10
(35 x 95.8 x 10cm)
LA1868
Left mirror door
4
(151.2 x 48.8cm)
PS3323
Right mirror door
5
(151.2 x 48.8cm)
PS3324
Small horizontal x2
8
(47.6 x 57.6cm)
P1343
Drawer front x 3
11
(97.9 x 15.7cm)
P4309
Back x2
13
(199.3 x 48.8cm)
BO33902
Foldy back
14
(152.3 x 98cm)
BO33934
Door x 2
15
(199.2 x 48.8cm)
P3304
Plinth front
16
(194.8 x 14cm)
P7338C
Plinth back
17
(194.8 x 5.4cm)
P7339C
Pelmet
18
(198.1 x 4.5cm)
FA249
3
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
40mm Screw x 11
D
15mm Screw x 45
G
L-Bracket x 1
J
Small locking
nut x 6
M
Hanger rail support x 6
P
FK1324
FK1400
FK1235
FK1010
FK1217
FK1980
B
20mm Screw x 20
FK1301
E
10mm Fixing screw drawer x 12
FK1011
H
24mm locking screw x 40
FA1515 FK1419
K
Nail x 60
FK1250
N
Drawerbase Support x 6
FK1268FK1269
Q
C
9mm Srew x 6
F
12.5 mm Screw x 6
I
Large locking
nut x 34
L
Nail holder x 1
O
15mm Screw x 12
R
FK1981
FK1309
FK1012
FK1311
PM16951
S
V
Hanger rail large x 1
Tools required
Hinge back x 12
FK1234
Peg x 2
PM1884
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Piercer
(small)
5mm Suitable drill bit
5mm Suitable drill bit
Hinge door x 12
T
Door/Drawer handle x 10
W
Wall plug and parkerscrew x 1
Drill
spirit level
Setsquare
Runner x 6
GR1975 PM1873
U
Hanger rail small x 2
ZF99936
Small
Stairs
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
hammer
Ruler/tape
measure
Scissors
Eye protection
(when using a
hammer or drill)
Ruler - Use this ruler to help correctly identify the screws
4
Assembly Instructions
Step 1
Drawer assembly x 3
a: Insert two small locking
nuts J into drawer wrap
0.
Make sure the ‘arrow’ on
J is pointing towards the
hole in the edge of 0.
J
a:
10
J
H
H
11
b: Screw 24mm locking
screws H into holes
shown on back of drawer
front !.
Make sure 24mm locking
screws H are tightened
right up against drawer
front !.
c: Slide drawer base 0
into grooves shown on
drawer wrap 0.
b
H
H
11
c:
9
10
5
Assembly Instructions
Step 1 - continued
d: Turn the drawer wrap
assembly over and push
onto drawer front !. Use
a philips or flatblade
screwdriver, that is a good
fit, to turn small locking nut
J as far as it will go - more
than 1/2 turn.
J
H
e: Fix drawer handle T
onto drawer front ! using
30mm screw B
Turn over drawer and
slide Drawerbase supports
N in corner as shown and
fix them, using the
attached screws .
e:
B
d
J
11
J
N
N
B
B
B
11
T
Step 2
Attaching runners
a: Slide top of runners R
foreward and fix on upright
3 as shown using 10mm
fixing screw drawer E.
Attention!
There are two uprights
3 one is the right side
3R
, the other is the
left side , either of
them can be used as
3L
or !
3L
3R
a:
Finished
front edge
3R
3L
T
E
R
E
R
E
E
R
R
R
E
3L
E
E
E
R
R
3R
R
Finished
front edge
6
Assembly Instructions
Step 2 - continuedStep 2 - continued
b: Slide top of runners R
back.
Fix through 3rd hole of
runner R and pre-drilled
holes of upright 3 using
10mm fixing screw drawer
E.
Fix through 1st and 9th
hole of runners R using
15mm screw O.
Note: there are no predrilled holes for 15mm
screw O.
Step 3
b
Finished
front edge
3L
3R
R
E
O
O
E
O
E
O
O
R
R
O
O
E
O
3L
R
R
R
O
R
O
E
R
O
E
O
O
3R
O
E
O
E
O
Finished
front edge
Insert fittings
a: Screw 24mm locking
screw H into 1 upright 3,
this will be the right upright.
Note: Insert 24mm locking
screw H as far as shown.
Do not over tighten.
Attach hinge back P onto
upright 3.
Attach hanger rail
support M using 12.5mm
screw F onto upright 3.
Flip panel
b: Screw 24mm locking
screw 3 into upright N,
this will be the right upright.
Attach hanger rail support
M using 12.5mm screw F
onto upright 3.
P
b
a:
3R
3R
3
P
F
M
P
H
H
F
M
P
H
3
H
3
F
M
P
3L
P
Finished
front edge
H
H
H
F
M
3L
H
H
M
H
Finished
front edge
F
H
H
H
P
Finished
front edge
Finished
front edge
b
Attention!
There are two uprights
3 one is the right side
3R
, the other is the
left side , either of
3L
them can be used as
3L
or !
3R
7
Assembly Instructions
Step 4
Attaching panels
Position large horizontal
7 onto upright .
Insert two large locking
nuts I into large
horizontal 7 as shown.
Use a screwdriver to turn
locking nuts I clockwise
to lock.
3R
Step 5
Attaching panels
Position large horizontal 7
onto upright .
Insert two large locking
nuts I into large
horizontal 7�as shown.
Use a screwdriver to turn
locking nuts I clockwise
to lock.
Note: Internal Uprights
are identical. Large holes
for locking nuts should not
face each other”.
3L
I
I
Unfinished
back edge
I
I
7
3R
7
I
I
I
I
3L
Step 6
Insert fittings
Screw 24mm locking screw
H into top/bottom 6,
this will be the top.
Note: Insert 24mm locking
screw H as far as shown.
Do not over tighten.
8
H
H
H
6
H
H
3
Assembly Instructions
I
I
I
I
I
Step 7
Attaching plinths
Align the sides of plinth
front ^ with bottom 6 as
shown and attach using
40mm screw A.
Note: there are no
predrilled holes for
40mm screw A.
Note: top and bottom
panels 6 are identical.
Only prepare one of the
panels at this stage. This
will be the bottom panel
Repeat with plinth back
&.
Step 8
Insert locking screws
A
A
A
17
A
Finished
front edge
H
6
A
A
A
16
H
6
A
H
Screw 24mm locking
screw H into bottom 6.
Step 9
Attaching panels
Position bottom 6 and top
6 onto uprights 3.
Insert four Large locking
nuts I into uprights 3 as
shown.
Use a screwdriver to turn
locking nuts I clockwise to
lock.
Finished
front edge
I
I
H
I
I
I
I
I
I
9
Assembly Instructions
III
I
I
IIIII
I
Step 10
Attaching panels
Position small horizontals
8 onto uprights 3.
Insert three large locking
nuts I into small
horizontals 8 as shown.
Use a screwdriver to turn
locking nuts I clockwise
to lock.
Step 11
Insert fittings
a: Screw 24mm locking
screw H into left side 1
and right side 2.
8
I
3
3
1
P
H
1
2
2
P
I
I
I
H
F
M
8
H
H
H
H
P
Note: Insert 24mm locking
screw H as far as shown.
Do not over tighten.
Attach hinge back P onto
left side 1 and right side
2.
Attach hanger rail support
M using 12.5mm screw
F�onto left side 1 and
right side 2.
Step 12
Attaching panels
Position left side 1 and
right side 2 onto the unit.
Insert large locking nuts
I�into top/bottoms 6
and small horizontals 8
as shown.
H
P
H
P
H
H
I
2
I
Finished
front edge
P
1
I
I
I
H
M
H
P
F
H
H
1
M
I
H
F
Use a screwdriver to turn
locking nuts I clockwise
to lock.
10
1
Assembly Instructions
Step 13
Fitting back panels
Attach back # and foldy
back $ to back of wardrobe
with the coloured surface
facing the inside of the unit
using nails K and 15mm
screws D.
Use nail holder L to hold
the nails K vertical and at
correct distance as you
secure the back # and
foldy back $. Nails K
should be spaced about
150mm apart.
Important:
Cabinet MUST
be ‘square’
when back is
attached.
Stand up the unit!
2 people required.
13
14
K
D
J
13
13
14
3
A
Step 14
Attaching pelment &
hanger rails
Position pelent * onto top
6 as shown, fix by using
three 40mm screws A.
Place hanger rails U and
V onto hanger rail support
M.
A
6
A
U
V
S
M
U
18
U
V
11
Assembly Instructions
Step 15
Inserting drawers
a: Pull runners out. Slide
drawers onto runners
so they butt up against
back of drawer front.
b: Fix through drawer
sides into runners using
9mm screws C.
a:
C
C
b:
1st small
threaded hole
C
Step 16
Fitting hinges & door
handles to doors
Fix three hinge doors Q
to each door 35%
using 15mm screws D.
Attach door handles T
using 30mm screws B.
D
D
D
D
Q
D
15
54
B
B
T
4
5
15
D
Q
Q
D
D
Q
Q
12
Assembly Instructions
Step 17
Hanging doors &
attaching L-bracket
a: With help, slot hinge
door Q onto hinge back
P.
b: Tighten screw shown
to lock hinges in position.
Repeat a and b for other
doors.
See ‘Hinge adjustment’in
step 18 if the doors need
adjusting.
a:
W
b:
P
Q
P
P
P
c:
Q
W
D
G
Q
Q
c: Position L-Bracket G
onto top 6 as shown, fix by
using 15mm screw D.
Note: there are no pre-drilled
holes for 15mm screw D.
Use W to fix on the wall,
please see last page for
more information.
d: Before adjusting the
doors, use a spirit level to
check if the base of this
unit is level front-to-back
and side-to-side in the
three positions shown.
Q
P
Q
d:
Use pegs S to square
your unit. Knock peg S in,
as far as you require,
under the ends of the unit
and then snap off flush
with the panel.
SNAP!
S
13
Assembly Instructions
Step 18
Hinge adjustment
a: To move doors up
or down: loosen screws
shown and move doors
to suit.
Once doors are aligned,
re-tighten.
b: To move doors in
or out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
a:
b:
c: To move doors left
or right: loosen screw
shown and move doors
to suit.
Re-tighten screws.
14
c:
A Guide to - Wall Mounting & Fixings
Important note:
If plastic wall plugs
are supplied with your
product:
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect fixings is the
responsibility of the installer.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Types of walls
No.1 “General Purpose” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can
be used.
No.2 “Plasterboard” wall plug
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
No.3 “Cavity Fixing” wall plug
For use with plasterboard partitions or
hollow wooden doors.
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
For use with walls stuck with
plasterboard. The hamemr fixing allows
it to be fixed to the wall rather than the
plasterboard. Always check the fixing
is secure to the retaining wall.
No.6 “Shield Anchor” wall plug
Heavy loads
For use when attaching light loads on
to plasterboard partitions.
Care &
Maintenance
For use when fitting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
15
Loading...
