Argos Mix and Match - Chests ASSEMBLY INSTRUCTIONS

MADE IN
BRITAIN
Mix and Match - Chests
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 11/12/12
Important - Please read these instructions fully before starting assembly
Chest
Dimensions
Width - 75cm
Depth - 36cm
Height - 57.5cm
Bedside
Dimensions
Width - 38.5cm
Depth - 36cm
Height - 41.5cm
709/2482
709/0219
709/2475
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warning: These units weigh approximately 21kgs. Please lift with care.
• Check you have all the components and tools listed on pages 1, 2 and 3.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Parts of the assembly will be easier with 2 people.
• Make sure you have enough space to layout the parts before starting.
• Do not stand or put weight on the products, this could cause damage.
• Assemble the items as close to their final position (in the same room) as possible.
• Assemble on a soft level surface to avoid damaging the units or your floor (use opened out unit carton).
• We do not recommend the use of power drill/drivers for
inserting screws, as this could damage the units. Only use hand screwdrivers.
Safety note: If there is any chance of these units being pulled over by children etc. it is recommended that the units are secured to a wall using suitable fixings (not supplied).
• Dispose of all packaging carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
• From time to time check that there are no loose screws on this unit.
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
Note: If required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
Tools required
Rule Scissors Hammer
Eye protection (when using a hammer or drill)
Cross-head screwdriver
Electric drill (do not use for fitting screws)
Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
1 2 3
1 Door Bedside (follow steps 1 to 14)
3 Drawer Chest (follow steps 15 to 25)
Left Side (D0013A)
(560 x 353mm)
8
Plinth (D0017A)
(714 x 80mm) x 2
11
Large Drawer Wrap (W162)
(1308 x 95mm) x 3
12
Right Side (D0014A)
(560 x 353mm)
9
Top (D0015A)
(747 x 356mm)
10
13
Large Drawer Base (T162)
(695 x 299mm) x 3
14 15
Left Side (D0888A)
(399 x 353mm)
Right Side (D0889A)
(399 x 353mm)
Base (D0625A)
(349 x 351mm)
Top (D0020A)
(382 x 356mm)
Door (D0890A)
(299 x 345mm)
4
Plinth (D0022A)
(349 x 80mm)
5
6
7
Drawer Front (D0887A)
(710 x 157mm) x 3
Back (X810)
(738 x 359mm)
Back (X811)
(331 x 373mm)
Please check you have all the fittings listed below
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A
Wooden dowel (F22) x 12
C
D
G
40mm Screw (F910) x 10
H
25mm Screw (F50) x 14
Nail (F51) x 25
I
F
Large locking
nut (F900) x 4
Small locking nut (F3) x 6
E
B
Metal dowel (F901) x 10
J
R (F601)
L (F600)
F599
F599
Drawer stops (F599) x 6 Runners (F600) x 3 and (F601) x 3
Door stop (F110) x 1
13mm Screw (F63) x 4
L M
Hinge (F522) x 2
Hinge plate (F523) x 2
Silver Handle (F1091) x 7
K
Blue/Pink Handle (F215) x 7
Beech units are supplied with Silver Handles
White units are supplied with either Blue or Pink Handles
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
Step 3
F
F
A
10mm
A
Finished
front edge
L
L
1
L
2
L
Prepare the right side
Refer to step 1 and, if required, fit 2 hinge
plates onto the right side , making sure that they face the same way as the diagram.
Insert a large locking nut into the right side .
Tap a wooden dowel into the right side .
Step 2
Prepare the left side
Refer to step 1 and, if required, fit 2 hinge
plates onto the left side , making sure that they face the same way as the diagram.
Insert a large locking nut into the left side .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Tap a wooden dowel into the left side .
Note: Wooden dowels must not stick out from the edge
by more than 10mm or they may damage other panels.
1
L
F
1
A
1
Choose which way you would like the door to open
You can fit the door to the left side or right side.
If you would
like your door
to open this
way, fit the
hinge plates
to the left side
If you would
like your door
to open this
way, fit the
hinge plates to
the right side
F
A
L
L
Finished
front edge
2
L
F
2
A
2
2
1
