Argos Malibu - Double Cupboard MK2 ASSEMBLY INSTRUCTIONS
MADE IN
BRITAIN
Dimensions
Width - 73.5cm
Depth - 49cm
Height - 72cm
Malibu - Double Cupboard MK2
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 18/03/13
Important - Please read these instructions fully before starting assembly
621/3372
621/3389
621/3883
Dimensions
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 23kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Plinth (D0879A)
(698 x 80mm)
1 2 3
4
5
6
7
8
Left Side (D1161A)
(706 x 442mm)
Top (D1170A)
(733 x 490mm)
Base (D1168A)
(698 x 426mm)
Shelf (D1169A)
(698 x 421mm)
Back (X848)
(718 x 622mm)
Door (D1172A)
(623 x 345mm) x 2
Right Side (D1387A)
(706 x 442mm)
Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A
Wooden dowel (F22) x 2
B
Metal dowel (F901) x 4
C
D
Large locking
nut (F900) x 4
E
I
Nail (F51) x 16
J
G
40mm Screw (F910) x 6
13mm Screw (F63) x 8
H
K
25mm Screw (F50) x 2
Handle (F631) x 2
Hinge plate (F523) x 4 Hinge (F522) x 4
Shelf stud (F110) x 4
F
Electric drill
(do not use for
fitting screws)
Finished
front edge
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
Step 2
2
J
Prepare the right side
Fit 2 hinge plates onto
the right side , making
sure that the slot is
facing towards the
finished front edge.
Insert 2 large locking
nuts into the right
side as shown.
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
J
2
E
2
1
J
Prepare the left side
Fit 2 hinge plates onto
the left side , making
sure that the slot is
facing towards the
finished front edge.
Insert 2 large locking
nuts into the left side
. as shown.
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
J
1
E
1
E
E
E
J
J
1
E
E
J
J
Finished
front edge
2
G
G
G
Finished
front edge
Finished
front edge
Assembly Instructions
5
Step 3
Step 4
Join the right side and
base
Position the base
against the right side
as shown and secure
with 2 screws .
4
2
G
Prepare the plinth
Tap 2 wooden dowels
into the plinth .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
Step 5
A
A
6
A
6
Fit the plinth
Push the plinth onto
the right side as
shown and secure with
screw .
6
2
G
plain chipboard surface
plain
chipboard
surface
4
2
6
plain chipboard surface
2
Assembly Instructions
6
Step 6
Fit the left side
Push the left side
onto the assembly as
shown and secure with 3
screws .
1
G
Prepare the top
Screw 4 metal dowels
into the top .
Note: Tighten metal
dowels up fully against
the panels.
3
B
Step 7
6
4
Finished
front edge
G
G
G
1
3
plain
chipboard
surface
B
B
B
B
B
Finished
front edge
Assembly Instructions
7
Step 9
E
B
Fit the top
Push the top onto
the assembly.
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the inside of the side
panels and .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
3
E
1 2
E
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the sides
and bottom edges of the
back .
Note: Nails should
be spaced about 150mm
apart.
Stand the unit up for
the next step.
8
D
8
Step 8
1
3
2
Finished
front edge
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
y
x
x
y
b:
D
8
