Assembly Instructions - Please keep for future reference
CR
CR
CR
548/5840
542/6122
555/0847
539/6489
541/0688
381/0840
368/3871
381/2752
380/5903
381/6521
More help is available throughout this booklet by scanning
in the QR codes or typing in the links
Dimensions
Width - 38.3cm
Depth - 39.6cm
Height - 60.6cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
MADE IN
BRITAIN
Issue 2 - 24/05/16
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 15kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
Care and maintenance
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: To prevent
possible overbalancing this unit
must be secured to a wall
using the overbalance protector
kit supplied or, an alternative
fixing method of your choice.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Components - Panels
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Please check you have all the panels listed below
Left Side
12
(59.1 x 39.4cm)
(DF6018)
Right Side (DF6019)
(59.1 x 39.4cm)
When applicable, remove any
protective film before use
Top (DF6020)
3
(38.3 x 39.6cm)
456
Plinth (DF6021)
(34.9 x 9.2cm)
Drawer Front (DF6025)
789
(34.3 x 15.7cm)
10
Drawer Back
(30 x 13cm)
x 3
(W300-130)
x 3
Back Rail
(34.9 x 6cm)
Left Drawer Side (W350-130LH)
(35 x 13cm)
11
Drawer Base
(31.1 x 34.7cm)
(DF6022)
x 3
(T311-347)
x 3
Cross Rail (DF6023)
(34.9 x 6cm)
Right Drawer Side
(35 x 13cm)
12
Back (X509-375)
(50.9 x 37.5cm)
(W350-130RH)
x 3
2
Components - Fittings
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Drawer Fittings Bag marked ‘drw kit’
A
Quickfit dowel
(F545) x 6
DE
19mm
Screw (F461) x 3
Main Fittings Bag
A
Quickfit dowel
G
Wooden dowel (F22) x 12
(F545) x 8
H
9mm Screw (F73) x 18
B
Large locking cam nut
Wedgefix
(F639) x 6
B
Locking nut (F607) x 8
I
Plastic Nail
(F607) x 6
(F91) x 4
C
Knock-in Peg
(F171GY) x 12
F
13mm Screw (F63) x 12
F
13mm Screw
(F63) x 6
J
Nail (F51) x 12
Individual Fittings Bags
K
Handle
a
M
b
M
(F418) x 3
350mm long
CL
CL Runner
(F422) x 3
CR Runner (F424) x 3
L
Overbalance protector
F474) x 1
kit (
M
c
DL
DL Runner (F425) x 3
CR
M
d
DR Runner
(F426) x 3
DR
Ruler - Use this ruler to help correctly identify the screws
Use the Drawer Fittings Bag marked ‘drw kit’ for Steps 1 - 7
Prepare the drawer
sides
a: Insert a large locking
cam nut into the left
drawer sides and the
right drawer sides .
Note: The arrow on the
locking cam nut must
point towards the
hole in the end of the
panel.
B
8
9
b: Push 1 of the quickfit
dowels as far as it will
go into the left drawer
side and the right
drawer side .
Note: Only the plastic
thread of the quickfit
dowel sticks out from the
panel.
A
8
9
a:
B
b:
B
B
8
9
x 3x 3
8
A
9
x 3x 3
B
A
Step 2
Fit the drawer sides
to the drawer front
Push the left drawer side
. and right drawer side
8
. down onto the back
9
of the drawer front .
Turn the large locking
cam nuts clockwise
as far as they will go to
secure the panels.
Important: Make sure
there is no gap between
the fitted panels.
B
7
B
9
x 3
8
7
4
Assembly Instructions
Step 3
Fit the drawer bases
Slide a drawer base
down the grooves in the
drawer sides and
and down into the
groove in the drawer
front .
7
11
98
Step 4
Fit the drawer backs
Fit a drawer back
between the drawer
sides and .
89
10
8
11
7
x 3
9
9
10
x 3
C
C
Make sure that the
drawer base fits into
the groove in the drawer
10
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
11
10
C
89
Step 5
Fit the handles
C
11
C
8
D
99
Attach a handle to
each drawer front
using screws .
5
K
D
x 3
7
7
K
Assembly Instructions
Step 6
Fit the wedgefixes
Turn the drawer
assemblies over and
slide 2 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
E
x 3
E
E
E
Important: Make sure
that the drawer assembly
is square before fitting
the wedgefixes.
Step 7
Fit runners to the
drawers
Fit the DL runner to
the bottom edge of the
left drawer side , as
shown, making sure that
it is pushed up against
the back of the drawer
front . Use a bradawl
to mark the fixing
positions, then secure
with 2 screws .
Fit the DR runner to
the bottom edge of the
right drawer side
using the same method.
7
M c
8
F
M d
9
Fixing Bottom Mounter Runners
hps://www.youtube.com/watch?v=Z6lGMy19h7Q
Runners must be
pushed up against
the drawer front
F
F
x 3
M d
DL
F
7
F
9
DL
8
DR
M c
6
Assembly Instructions
Step 8
Prepare the left side
a: Fit 3 CL runners
to the left side .
The 1st screw uses
the 1st hole in from the
front of the runner.
The 2nd and 3rd screws
H
. use the holes that line
up with the other panel
holes.
b: Fit a screw into
the hole at the top of the
runner .
M a
c: Insert 2 large locking
cam nuts into the left
side .
Push 2 of the quickfit
dowels as far as they
will go into the left side
1
. .
B
1
A
M a
1
H
F
Use the Main Fittings Bag for Steps 8 - end
Fixing Bottom Mounter Runners
hps://www.youtube.com/watch?v=Z6lGMy19h7Q
1st
front edge
Finished
Finished
front edge
a:
front edge
Finished
H
screw
M a
CL
H
H
CL
H
M a
H
H
M a
M a
1
H
H
H
CL
H
CL
F
Tap 2 wooden dowels
into the left side .
1
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
G
Finished
F
front edge
b:
CL
Finished
front edge
c:
CL
F
F
CL
CL
1
A
B
A
G
B
CL
CL
G
B
A
10mm
1
G
7
Assembly Instructions
Step 9
Prepare the right side
a: Fit 3 CR runners
to the right side .
The 1st screw uses
M b
2
H
the 1st hole in from the
front of the runner.
The 2nd and 3rd screws
H
. use the holes that line
up with the other panel
holes.
b: Fit a screw into
F
the hole at the top of the
runner .
M b
c: Insert 2 large locking
cam nuts into the
right side .
B
2
CR
a:
M b
1st
screw
H
2
H
H
H
H
CR
H
H
CR
M b
front edge
Finished
H
H
H
CR
M b
M b
Finished
front edge
F
front edge
Finished
Push 2 of the quickfit
dowels as far as they
A
will go into the right side
. .
2
Tap 2 wooden dowels
into the right side .
G
2
b:
c:
F
F
F
CR
2
CR
CR
Finished
front edge
A
B
A
G
B
CR
CR
CR
2
G
A
B
Finished
front edge
8
Assembly Instructions
Step 10
Prepare the cross rail
Tap 4 wooden dowels
into the cross rail .
G
6
Step 11
Fit the cross rail onto
the left side
Push the cross rail
down onto the left side
. .
1
6
G
G
Finished
front edge
Finished
front edge
Finished
front edge
Note: The cross rail has no
holes drilled on either surface
6
G
G
6
CL
CL
1
CL
Step 12
Prepare the plinth
Insert 2 large locking
cam nuts into the
plinth .
B
4
Push 2 of the quickfit
dowels as far as they
will go into the plinth .
Tap 2 wooden dowels
into the plinth .
A
4
G
4
Step 13
Fit the plinth
Push the plinth down
onto the left side .
Turn the large locking
cam nut clockwise as
B
far as it will go to secure
the panels.
4
1
A
B
A
G
B
B
4
Carcase Assembly
hps://www.youtube.com/watch?v=9C7tgv5xnbE
4
CL
CL
CL
1
A
G
Important: Make sure
there is no gap between
the fitted panels.
9
Assembly Instructions
Step 14
Prepare the back rail
Insert 2 large locking
cam nuts into the
back rail .
B
5
Push 2 of the quickfit
dowels as far as they
A
will go into the back rail
. .
5
Tap 2 wooden dowels
into the back rail .
G
5
Step 15
Fit the back rail
A
B
B
A
G
5
B
A
G
Push the back rail
5
down onto the left side
1
. .
Turn the large locking
cam nut clockwise as
B
far as it will go to secure
the panels.
Important: Make sure
there is no gap between
the fitted panels.
Step 16
Fit the right side
Push the right side
down onto the assembly.
2
Finished
front edge
CL
CL
CL
5
1
2
Turn the 2 large locking
cam nuts clockwise
B
as far as it will go to
secure the panels.
Important: Make sure
there is no gap between
the fitted panels.
CL
CL
CL
10
Assembly Instructions
Step 17
Fit the top
Push the top down
onto the assembly.
Turn the 4 large locking
cam nuts clockwise
as far as they will go to
secure the panels.
Important: Make sure
there is no gap between
the fitted panels.
3
B
Step 18
Fit the back
3
CR
CR
CR
Finished
front edge
Squaring up a Chest and tting the Back Panel
www.youtube.com/watch?v=FeaI6541z7o
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
J
outside edges of the
12
back .
Note: Nails should be
spaced out evenly.
12
The measurement from top corner X to bottom corner X must be
a:
equal to the measurement from top corner Y to bottom corner Y
b:
J
x
x
y
12
12
y
y
CR
CR
xx
9
Assembly Instructions
Step 19
Fit the 4 plastic nails
Tap 2 plastic nails
I
into the bottom edge of
each of the sides and
. .
2
1
Carefully stand the
unit up for the next
step.
Step 20
Fit the overbalance
protector kit
a: Before fitting the
overbalance protector
kit, use a spirit level to
check the top of the unit
is level, front-to-back
and side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level.
I
I
2
CR
CR
I
1
I
a:
To prevent possible
overbalancing this unit
must be secured to a
suitable wall by fitting of
the overbalance
protector kit to the
L
unit, or an alternative
fixing method of your
choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
Take care when
Note:
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
CR
CR
b:
CR
Top
L
Back
Cut-out
in back panel
12
Assembly Instructions
Step 21
Fit the drawers
Slide the wheels of the
runners fitted to the
drawers, over the wheels
of the runners fitted to
the side panels and push
the drawers into position.
Assembly is complete
Fixing Bottom Mounter Runners
hps://www.youtube.com/watch?v=Z6lGMy19h7Q
CR
CR
CR
Side
panel
Drawer
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
13
ALR3317
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
