Arc ICC6GE2 Operating Instructions
600mm
Ceramic
PRODUCT SERVICE NUMBER
1800 805 300
Cooktop
MODEL: ICC6GE2
RSDMC1208
InstallatIon and opEratIon Manual
Dear Customer,
Congratulations on your purchase this new touch control cook top. We wish
you many years of satisfaction and use of this appliance.
Please read this manual thoroughly to familiarise yourself with the installation,
operation and care of the cook top. Ensure you keep this manual for future
reference.
Safety
Safety instructions
Please comply with these instructions. If you do not, any damage or fault will
not be covered under the warranty.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been instructed or under supervision concerning
use of this appliance by a person responsible for their safety.
Do not leave the appliance unattended during operation.
This appliance should only be used for cooking and frying of food in a
domestic situation.
This appliance is to be installed indoors only.
This appliance must not be used as a work surface or as a storage surface.
It is not permitted to make additions or modifications in any way to this
appliance.
Do not place or store flammable liquids, materials or fusible objects, such
as plastic film, on, near or under this appliance.
Children’s safety
ALWAYS keep small children away from the appliance. The cook top
surface will become hot during cooking.
The appliance is not intended for use by young children or infirm persons
without supervision.
Children should be supervised to ensure they do not play with this
appliance.
Activating the Childproof lock is recommended to avoid small children
and pets from unintentionally switching the appliance on.
General safety
The appliance must only be installed and connected by a trained and
registered electrician.
2
Safety
This appliance can only be operated when installed into suitable built-in units
and work surfaces meeting local standards.
Should there be damage to the ceramic glass surface, such as cracks, or any
faults to the appliance it must be switched off and disconnected from the
electrical supply to prevent the possibility of electrical shock. An authorised
service agent should be contacted immediately.
Any repairs are to be only carried out by trained and registered service
technicians.
Cables from electrical appliances should not touch the hot surface of the
appliance.
If the appliance is used carelessly, there is a risk of burns. Do not place any
metal objects on the cooking surface.
Ensure all cooking zones are switched off after use. Activation of
Childproof lock is recommended.
Ensure proper cookware is used on the ceramic glass surface. Use of
aluminum or copper based cookware can cause pitting of the ceramic glass
surface. Ensure all cookware have flat bases, uneven or damaged based
cookware can cause damage to the surface and not work efficiently.
Ensure objects are placed carefully on the cooktop surface. Do not drop or
scrape cookware or objects across the ceramic glass surface as damage or
breakage could occur. The edge of the ceramic glass can be damaged should
care not be taken.
Do not use the cooking zones with empty cookware or absence of cookware.
Do not allow saucepans or frying pans to boil dry. Damage to both the
cookware and ceramic glass surface could occur.
Clean spills as soon as possible after the appliance is switched off and
cooled. Food spills with high sugar content in particular should be removed
as soon as possible the ceramic glass surface.
A scraper, suitable for ceramic glass will remove stubborn spills and use of
a silicon based cleaner / protector, such as Hillmark’s CERAPOL, is
recommended for removal of residuals.
Safety Features
High temperature protection
The temperature sensor mounted on the radiant electric element monitors
the temperature inside the cook top from time to time. When an excessive
temperature is detected, the element will be directly disconnected and stop
power output. As a result this may seem as though the element is not
working all the time. The element cycles on and off due to the heat retained
in the ceramic glass surface and maintains a constant temperature based
on the selected settings chosen . This ensures that there is reduced risk
of food burning or damage occurring to the cook top.
3
Safety Features
2
Residual heat indicators
After using the cook top, residual heat remains in the cooking zone.
The digital display shows the code “H”, warning to stay away from the
cooking zone .
Auto shut off protection
3
During use, the cook top will shut off automatically a cooking zone when
the default working time is reached, for that selected power level. The
time is based on no adjustment being made to either power or timer
setting for the cooking zone. If several cooking zones are working
simultaneously, the cook top will automatically shut off any zone that
reaches it’s default time. The default working time for various power levels
are shown in the table below.
Power level 1 2 3 4 5 6 7 8 9
Default working
time(hour)
8 8 8 4 4 4 2 2 2
Installation
Preparation of bench top
1
Cut hole
For the purpose of installation and use, a minimum of 50 mm space is
required from rear wall and 75mm to any side vertical surface from the
cutout hole. Bench top should be at least 30mm in thickness
into bench top according to the sizes shown in the figure 1.
.
5
2
0
m
m
0
9
5
m
0
7
5
30 mm
5
0
m
m
m
i
n
min
m
m
5
7
m
m
5
0
0
m
m
m
n
i
m
m
m
5
7
n
i
m
4
