Arc AP6C1 User Manual
60cm & 90cm Ceramic Cooktop
Model ICC6GE3 (60cm) & CC96GB (90cm)
INSTRUCTION /
INSTALLATION MANUAL
PLEASE READ THE USER MANUAL CAREFULLY BEFORE USE
www.glendimplex.com.au
Product / Installer details
For future reference we suggest that you staple a copy of your purchase receipt here and complete the below so the
information is always at hand.
Product Details
Model number: ________________________________________________________________________________________
Description: ___________________________________________________________________________________________
Serial number: _________________________________________________________________________________________
(Located on the product rating label)
Purchase Details
Date of purchase: ______________________________________________________________________________________
Place of purchase: _____________________________________________________________________________________
Store name: ___________________________________________________________________________________________
Address: ______________________________________________________________________________________________
Telephone: ____________________________________________________________________________________________
Invoice / receipt number: ________________________________________________________________________________
Installation Details
Electrical date of installation: ___________________________________________________________________________
Electrician Installers Details: Company / Installers Name: _____________________________________________
Licence Number: ______________________________________________________
Telephone Number: ____________________________________________________
Gas date of installation: _________________________________________________________________________________
Gas installers details: Company / Installers Name: _____________________________________________
Licence Number: ______________________________________________________
Telephone Number: ____________________________________________________
Plumbing date of installation: ___________________________________________________________________________
Plumbers installers details: Company / Installers Name: _____________________________________________
Licence Number: ______________________________________________________
Telephone Number: ____________________________________________________
Page ii 60cm - ICC6GE3 & 90cm - CC96GB Ceramic Cooktops
Dear Customer,
Congratulations on the purchase of your new product from
Glen Dimplex Australia Pty Ltd.
We recommend you please take some time to read the instruction manual
thoroughly to familiarise yourself with the functionality and operations to ensure
optimum performance of your new appliance.
After reading the manual, please store it in a safe and accessible location for
future reference.
Installation
The installation of your new appliance must be carried out by a qualied
installer / technician in accordance to local regulations.
The packaging of your appliance has been selected from environmentally
friendly materials and can usually be recycled. Please ensure these are disposed
of correctly.
Customer Care
Our Customer Care centre is available should you wish to learn more about your
appliance in relation to how to use it to its best potential, or tips on cleaning as
well as available accessories.
For further details please contact our Customer Care team on
1800 444 357 or email: customercare@hapl.com.au
Thank you
Regards,
Glen Dimplex Australia
60cm - ICC6GE3 & 90 cm - CC96GB Ceramic Cook tops Page iii
CONTENTS
Contents ______________________________________________________ 1
Safety Warnings - Installation __________________________________ 2-3
Safety Warnings - Operation and Maintenance ___________________ 3-6
Product Overview _____________________________________________ 7-8
Before using your new cooktop ___________________________________ 8
Using the Touch Controls ________________________________________ 8
Choosing the right cookware _____________________________________ 9
Using your Cooktop ____________________________________________ 10
Dual Zone Function (for model CC96GB) __________________________ 11
Locking the controls ___________________________________________ 12
Residual Heat Indicators ________________________________________ 12
Auto Shutdown ________________________________________________ 12
Using the Timer ____________________________________________ 13-15
Cooking Guidelines _________________________________________ 16-17
Heat Settings _________________________________________________ 17
Care and Cleaning _____________________________________________ 18
Troubleshooting Guide - hints and tips ___________________________ 19
Technical Specication _________________________________________ 20
Installation - material and dimensions ____________________________ 21
Installation - ventilation and clearances ___________________________ 22
Installation - xing cooktops to work surface ______________________ 23
Installation - electrcial connection ________________________________ 24
Page 1 60cm - ICC6GE3 & 90cm - CC96GB Ceramic Cooktops
SAFETY WARNINGS
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
BEFORE USING THE APPLIANCE.
Installation
Electrical Shock Hazard
• Disconnect the appliance from the mains electricity supply before carrying out
any work or maintenance on it.
• Connection to a good earth wiring system is essential and mandatory.
• Means for disconnection must be incorporated in the xed wiring in
accordance with the wiring rules.
• Alterations to the domestic wiring system must only be made by a qualied
electrician.
• Failure to follow this advice may result in electrical shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Read these instructions carefully before installing or using this appliance.
• No combustible material or products should be placed on this appliance at any
time.
• Please make this information available to the person responsible for installing
the appliance as it could reduce your installation costs.
• In order to avoid a hazard, this appliance must be installed according to these
instructions for installation.
• This appliance is to be properly installed and earthed only by a suitably
qualied person.
60cm - ICC6GE3 & 90 cm - CC96GB Ceramic Cook tops Page 2
SAFETY WARNINGS
• This appliance should be connected to a circuit which incorporates an isolating
switch providing full disconnection from the power supply.
• WARNING: Use only cooktop guards designed by the manufacturer of the
cooking appliance or indicated by the manufacturer of the appliance in the
instructions for use as suitable or cooktop guards incorporated in the appliance.
The use of inappropriate guards can cause accidents.
• Failure to install the appliance correctly could invalidate any warranty or liability
claims.
• Regarding the details of installation, thanks to refer to the section ‘Installation’.
Operation and Maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked cooktop. If the cooktop surface is broken
or cracked, switch the appliance off immediately at the mains power supply (wall
switch) and contact a qualied technician.
• Switch the cooktop off at the wall before cleaning or maintenance.
• Failure to follow this advice may result in electrical shock or death.
Health Hazard
• This appliance complies with electromagnetic safety standards.
Hot Surface Hazard
• During use, accessible parts of this appliance will become hot enough to cause
burns.
• Do not let your body, clothing or any item other than suitable cookware contact
the ceramic glass until the surface is cool.
• Metallic objects such as knives, forks, spoons and lids should not be placed on
the hob surface since they can get hot.
Page 3 60cm - ICC6GE3 & 90cm - CC96GB Ceramic Cooktops
SAFETY WARNINGS
• Children less than 8 years of age shall be kept away unless continuously
supervised.
• Handles of saucepans may be hot to touch. Check saucepan handles do not
overhang other cooking zones that are on. Keep handles out of reach of children.
• Failure to follow this advice could result in burns and scalds.
Cut Hazard
• The razor-sharp blade of a cooktop scraper is exposed when the safety cover
is retracted. Use with extreme care and always store safely and out of reach of
children.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Never leave the appliance unattended when in use. Boil over causes smoking
and greasy spillovers that may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as described in
this manual (i.e. by using the touch controls).
• Do not allow children to play with the appliance or sit, stand, or climb on it.
• Do not store items of interest to children in cabinets above the appliance.
Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the appliance is in
use.
60cm - ICC6GE3 & 90 cm - CC96GB Ceramic Cook tops Page 4
SAFETY WARNINGS
•
Children or persons with a disability which limits their ability to use the
appliance should have a responsible and competent person to instruct them in
its use. The instructor should be satised that they can use the appliance without
danger to themselves or their surroundings.
•
Do not leave children alone or unattended in the area where the appliance is in
use.
• Children or persons with a disability which limits their ability to use the
appliance should have a responsible and competent person to instruct them in
its use. The instructor should be satised that they can use the appliance without
danger to themselves or their surroundings.
• Do not repair or replace any part of the appliance unless specically
recommended in the manual. All other servicing should be done by a qualied
technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans across the glass surface as
this can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to clean your
cooktop, as these can scratch the ceramic glass.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
• This appliance is intended to be used in a domestic household environment
only! Commercial use of any kind is not covered under the manufacturer’s
warranty!
• WARNING: The appliance and its accessible parts become hot during use.
• Care should be taken to avoid touching heating elements.
Page 5 60cm - ICC6GE3 & 90cm - CC96GB Ceramic Cooktops
SAFETY WARNINGS
• Children less than 8 years of age shall be kept away unless continuously
supervised.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• WARNING: Unattended cooking on a cooktop with fat or oil can be dangerous
and may result in re. NEVER try to extinguish a re with water, but switch off the
appliance and then cover ame e.g. with a lid or a re blanket.
• WARNING: Danger of re: do not store items on the cooking surfaces.
• WARNING: If the surface is cracked, switch off the appliance to avoid the
possibility of electric shock, for hob surfaces of glass-ceramic or similar material
which protect live parts.
• The appliance is not intended to be operated by means of an external timer or
separate remote-control system.
• CAUTION: The cooking process has to be supervised. A short term cooking
process has to be supervised continuously.
• Power cord can’t be accessible after installation.
60cm - ICC6GE3 & 90 cm - CC96GB Ceramic Cook tops Page 6
Loading...
