Apex Digital MD 100 User Manual
1
APEX DIGITALMD - 100
Congratulations on purchasing this high-quality Car Audio DVD player.
The development work invested in the new DVD player offers you
complete multimedia enjoyment in your v ehicle. Apex Digital D VD Pla y ers
are one of the first mobile DVD Players to feature MP3 capabilities, and
also contain a number of technical highlights as well, such as:
• DVD/VCD/CD/CD-R playback
• Full function remote
• AC/DC adapter
• Dolby/dts Digital Out
• A/V pass through for video game systems
• Extended remote sensor
• Cigarette lighter adapter
To achieve the best possible audio and video quality from your new DVD
player, we recommend that it is installed by an authorized dealer, and that
the proper voltage is used. This way you could obtain the full enjoyment
of the performance of your DVD Player.
Let us finally mention the aspect of your safety of others while operating
a motor vehicle with a video source. Please remember when operating a
motor vehicle with a video source, that the video source cannot be in view
of the driver. Ser ious injury or death may occur if the video source is in
view of the driver. Remember to follow all state and local laws while
driving. This product is designed for rear seat entertainment only.
Introduction
2
APEX DIGITAL
3
APEX DIGITALMD - 100 MD - 100
Safety Precautions
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rule. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Any modifications of the units on factory settings
besides setup menu are the responsibility of the user.
FCC NOTICE:
WARNING:
In the space provided below, record the Model and Serial No.located
on the rear panel of your DVD video player.
Model No.__________________ Serial No. __________________
Retain this information for future reference.
The lightning flash with a arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
WARNING:TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PART INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
!
Safety Precautions
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
This digital video disc player emplo ys a Laser System. To
ensure proper use of this product, please read this
owner’s manual carefully and retain for future reference.
Should the unit require maintenance, contact an
authorized service location - see warranty.
Use of control adjustment or the performance of
procedures other than those specified may result in
hazardous radiation exposure.
To prev ent direct exposure to the laser beam, do no try to
open the enclosure.
Visible laser radiation when open and interlocks
defeated.
DO NOT STARE INTO THE BEAM.
CAUTIO
CAUTION:
4
APEX DIGITAL
5
APEX DIGITALMD - 100 MD - 100
4. Heat
The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers)
that produce heat.
5. Water and Moisture
Do not use this product near water - for example, near a bath tub,
in a wet basement, or near a swimming pool.
6. Cleaning
Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
7. Power-cord Protection
Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them, paying
particular attention to cords at plugs, conveniences receptacles, and the
point where they exit from the product.
8. Overloading
Do not overload wall outlets as this can result in a risk of fire or
electric shock.
9. Lightning
Unplug it from the wall outlet. This will prevent damage to the
product due to lightning and power-line surges.
10. Object and Liquid Entry
Never push objects of any kind into this product through openings
as they may touch dangerous voltage points or short-out parts that
could result in a fire or electric shock. Never spill liquid of any kind on
the product.
11. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
12. Disc Tra y
Keep your fingers well clear of the disc tray as it is closing. It may
cause serious personal injury, or do damage to the machine.
Impor tant Safety InstructionsImpor tant Safety Instructions
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS
AND INSTRUCTIONS GIVEN IN THIS OWNER’S
MANUAL AND THOSE MARKED ON THE UNIT.
RETAIN THIS BOOKLET FOR FUTURE
REFERENCE.
This set has been designed and manufactured to assure personal
safety. Improper use can result in electric shock or fire hazard. The
safeguards incorporated in this unit will protect you if you observe the
following procedures for installation, use and servicing. This unit is
fully transistorized and does not contain any parts that can be
repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE
EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL ONLY.
1. Read The Owner’s Manual After Unpacking This Product.
Read the owner’s manual carefully, and follow all the operating and
other instructions.
2. Power Source
This product should be operated only from the type or power source
indicated on the marketing label. If y ou are not sure of the type of pow er
supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power , or other
sources, refer to the operating instructions.
3. Ventilation
Slots and openings in the cabinet are provided for v entilation and to
ensure reliable operation of the product and to protect it from overheating. There openings must not be blocked or cov ered. The openings
should never be blocked by placing the product on a bed, sofa, rug or
the similar surface.
6
APEX DIGITAL
7
APEX DIGITALMD - 100 MD - 100
18. Replacement Parts
When replacements parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or
the same substitutions may results in fire, electric shock, or other
hazards.
19. Grounding or Polarization
This product may be equipped with a polarized alternating current
line plug (a plug having one blade wider than the other). This plug will
fit into the power outlet only one wa y. This is a saf ety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug.
20. Temperature
If your car was parked in direct sunlight resulting in a considerate
rise in temperature inside the car, allow the unit to cool off before
operating it.
Impor tant Safety Instructions
13. Burden
Do not place a heavy object on or step on the product. The object
may fall, causing serious personal injury and serious damage to the
product.
14. Safety Check
Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the
product is in the proper operating condition.
15. Disc
Do not use a cracked, deformed, or repaired disc. These discs are
easily broken and may cause serious personal injury and product
malfunction.
16. Damage Requiring Service
Unplug this product from the power port and refer servicing to
qualified service personnel under the following conditions.
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the
product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions because improper
adjustments of other controls may result in damage and will
then require extensive work b y a qualified technician to restore
the product to its normal operation
f) When the product exhibits a distinct change in performance
- this indicates a need for service.
17. Servicing
Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified ser vice personnel.
Impor tant Safety Instructions
Continued
8
APEX DIGITAL
9
APEX DIGITALMD - 100 MD - 100
The DVD video player is a high technology, precision
device. If the optical pick-up lens and disc drive parts are
dirty or worn down, the picture quality becomes poor. To
maintain a clear picture, we recommend regular inspection
and maintenance (cleaning or parts replacement) every
1,000 hours of use depending on the operating
environment. For details, contact your nearest dealer.
Beware of Moisture Condensation
Moisture condensation damages the DVD video player.
Please read the following carefully.
Moisture may condense on the optical pick-up lens inside
this unit, one of the most crucial internal par ts of the DVD
video player.
Moisture condensation occurs during the following cases:
• When you bring the DVD video player directly from a cold place
to a warm place.
• In summer, when you use the DVD video player in a hot and
humid place just after you move the unit from an air conditioned
room.
• When you use the DVD video player in a humid place.
Do not use the DVD video player when moisture
condensation may occur.
■
PrecautionsPrecautions
Handling Y our DVD
When Shipping the DVD video player, the original shipping
carton and packing materials comes in handy. For
maximum protection, repack the unit as it was originally
packed at the factory.
Do not use volatile liquids, such as insect spray, near the
DVD video player. Do not leave rubber or plastic products
in contact with the DVD video player for a long time. They
will leave marks on the finish.
The top and rear panels of the DVD video player may
become warm after a period of use. This is not a
malfunction.
When the D VD video pla yer is not in use , be sure to remov e
the disc and turn off the power.
If you do not use the DVD video player for a long period of
time, the unit may not function properly in the future. Turn
on and use the DVD video player occasionally.
Where to Locate Your DVD
When you place this DVD video player near a TV, radio or
video cassette recorder (VCR), the playback picture may
become poor and the sound may be distorted. In this case,
place the D VD video pla yer a wa y from the TV, radio or VCR.
Cleaning Y our DVD
Use a soft, dry cloth for cleaning.
• For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe it dry.
Do not use any type of solvent, such as thinner and
benzine, as they ma y damage the surf ace of the DVD video
player.
• If you use a chemical saturated cloth to clean the unit,
follow that product’s instructions.
To Obtain a Clear Picture
■
■
■
■
■
10
APEX DIGITAL
11
APEX DIGITALMD - 100 MD - 100
Identification of Control
FRONT PANEL
BACK PANEL
INSTALLATION
MOUNTING
When choosing a mounting location, the DVD unit should be stable and
in a position where sufficient cooling is available . Before mounting, attach
the supplied brackets and hardware for top or bottom mount.
Plug the supplied CLA power cord into the back of the DVD unit and r un
the wire to a power point. (Some vehicles do not have accessory power
outlets. In this case, the cigarette lighter must be used.) Plug the
supplied yellow video cable into the video output of the DVD unit and plug
the other end into the video input of the monitor (not supplied). Repeat
this process with the red and white audio cords.
Introduction ...................... 1
Safety Precautions .............. 2 - 3
Important Safety Instructions
.......................................... 4 - 7
Precautions ........................ 8 - 9
Identification of Control ...... 11
Remote Control ................. 12 - 13
Connecting to a TV using a RF
Modulator..............................14-15
What is MP3 and VCD ?..... 16 - 17
Playing Back a Disc .......... 18 - 19
Locating a Specific Title, Chapter
or Track .............................. 20 - 27
Zooming a Picture .............. 28
Selecting the Camera Angle/
Selecting a Language ........ 29 - 30
Selecting Subtitles ............. 31
Using the On-Screen
Display .............................. 32
Setting the Parental Lock... 33 - 34
Customizing the Function
Settings ............................. 35
Notes on Discs ................... 36 - 38
Troubleshooting Guide ....... 39 - 40
Specifications ..................... 41
Memo ................................. 42 - 43
Warranty .......................... 44 - 45
Table of Content
12
APEX DIGITAL
13
APEX DIGITALMD - 100 MD - 100
Remote Control
1
2
Open the cover.
Insert batteries (AA size).
Make sure to match the + and - on
the batteries to the marks inside the
battery compar tment.
PREPARING THE REMOTE CONTROL
Insert the batteries into the remote control so you can use it to operate
the DVD video player.
NOTICE
Follow instructions below because incorrect use of batteries might cause
them to leak or corrode.
• Do not place the batteries in the wrong direction.
• It is dangerous to charge/heat/open or short-circuit the batteries.
• Do not leave dead batteries or mix old/new batteries in the remote control.
• When not using the remote control for a long duration of time, remove the
batteries.
• When difficulties occur, with the remote control, or if the operating range
becomes reduced, then replace the batteries.
• If leakage from the battery occurs, wipe the battery liquid from the batter y
compartment, then replace the batteries.
3
Close the cover.
OPERA TING WITH THE REMOTE CONTROL
Operating DVD video player with the remote control.
OPERA TING DVD VIDEO PLAYER WITH THE EXTENDED
REMOTE SENSOR
ON
OFF
L-AUDIO IN-R VIDEO IN
MD-100
O/C
STOP
SKIP
PLAY
MENU
SKIP
DVD/VIDEO CD/ CD PLAYER
30
30
O/C MUTE DISPLAY SWITCH
AUDIO SUB-T ANGLE TITLE
1234
5678
9010+GOTO
STOP STEP/PAUSE
PREV PLAY/ENTER NEXT
MENU VOL SLOW
SETUP ZOOM REPEAT
A-B REP
1
The remote control must be pointed at the
remote sensor, in order for the DVD player to
function correctly.
Distance: Maximum of 7 m from the front of the
remote sensor.
Angle: Approximately 30˚ from each direction.
*Please do not place the remote sensor towards
any strong light source such as direct sunlight or
illumination.
Plug the jack (male) of the extended remote sensor into the jack
(female) of the real panel of the DVD video player. The extended
remote sensor should be placed on dash board or central console.
Remote Control
NOTICE
• The remote control should be aimed directly towards the remote sensor of
the DVD video player.
• Avoid dropping the remote control.
• The extended remote sensor is usually used in the car.
O/C MUTE DISPLAY SWITCH
AUDIO SUB-T ANGLE TITLE
1234
5678
9010+GOTO
STOP STEP/PAUSE
PREV PLAY/ENTER NEXT
MENU VOL SLOW
SETUP ZOOM REPEAT
A-B REP
15
APEX DIGITALMD - 100
14
APEX DIGITAL MD - 100
Connecting to a TV using a RF
Modulator
Note: Not all RF Modulators are compatible
with APEX Digital players. Please see our
website for recommendations.
Many older televisions do not have the newer component-video,
composite-video, or s-video connections that optimize DVD
technology.While it would be advised to purchase a newer
television in order to take full advantage of the digital quality of
DVD’s, it is possible to connect an older television to a DVD
player.This connection requires a device called an RF modulator.
First, it is necessary to ascer tain whether or not your TV needs a
RF modulator.Look at the back of your TV. If you see three input
connectors lined up in a row, in the colors of yellow, red, and
white, then you will not need an RF modulator. If you see a
connector labeled "s-video", then you will not need an RF
modulator.If you do not have either of these connectors, then you
will need to purchase an RF modulator from the store where you
purchased your Apex Digital DVD player or other home
electronics retailers.
Older televisions use a coaxial connection, which combines all of
the video signal from an exterior source into a single line.This
line is then translated by your TV into the picture you see.The RF
modulator combines the output signals from the DVD player, or
any other device, into the coaxial connection for use by your
television.
Below are written and pictoral instructions on the proper way to
connect an RF modulator to your Apex DVD player and your TV.
Connecting the
TV to the DVD
through the VCR
Note: Many VCRs
will distort the
picture of a DVD
player.This is NOT
a malfunction of the
DVD player or VCR.
All DVD
manufacturers are
required to install
macrovision copyright ciruritry to
prevent copying via VCR.This is
what causes the distortion.
1) Connect the three-terminal
composite video cable to the back
of your Apex DVD player.This
cable has three prongs, one each
in yellow, red, and white.The
yellow prong will go into the jack
labeled "Video Out"; the white
prong will go into the jack labeled
"Front-L";the
red prong will go into the jack
labeled
"Front-R".
2) Connect the opposite end of the
composite-video cable into the
back of the RF modulator. Make
sure to match up the colors
correctly.
3) Connect a coaxial cable from
the "Antenna Out" jack on the back
of your VCR to the "Antenna" jack
on the RF modulator.The coaxial
cable is the one-wire, metal-ended
type that you screw onto the VCR.
4) Connect a coaxial cable from
the "To TV" jack on the RF
modulator to the jack on the back
of your TV.
5) Make sure your TV is set to the
appropriate channel before using
your DVD player. In most cases,
this is channel 3 or 4.
Connecting to a TV using a RF
Modulator Continued
DVD (Back)
TV / Video Input
Conntection
COAXIAL
VIDEO OUT
AUDIO OUT
L
1
(L)
(R)
R2
TV /Audio Input
Conntection
(V)
(L)
Your V CR (Back)
(R)
UHF/Antenna OUT
Coaxial
RF-Modulator
VTo TVAntennaRL
(V)
Your TV (Back)
UHF/Antenna IN
Coaxial
Loading...
