Apex Digital HT-175 User Manual
1
SAFETY INFORMATION
TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
: To reduce the
risk of fire and electric shock, do
not remove the cover (or back) of
the unit. Refer servicing only to qualified service personnel.
CAUTION
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operation and servicing instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
In addition to the careful attention devoted to quality standards
in the manufacture of your video product, safety is a major factor
in the design of every instrument. However, safety is your
responsibility, too. This sheet lists important information that will
help to assure your enjoyment and proper use of the video
product and accessory equipment. Please read them carefully
before operation and using your video product.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not bolck any ventilation openings. Install in accordance with
the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers,stoves, or other apparatus(including amplifiers) that produce
heat.
Do not defect the safety purpose of the polarized plug. A polarized plug has two blades with one wider than the other . The wide
blade is provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they
exit from the apparatus.
Only use attachments/ accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/ apparatus combination
To avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long period
of time.
Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as when the power-supply
cord or plug is damaged, liquid has been spilled, objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, or when the
unit does not operate normally , or has been dropped.
The apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.
Power cord protection- To avoid any malfunctions of the unit and to protect
against electric shock, fire or personal injury, please observe the following:
a) Hold the plug firmly when connecting or disconnecting the AC power
cord to this unit.
b) Do not connect or disconnect the AC power cord with wet hands.
c) Keep the AC power cord away from heating appliances.
d) Never put any heavy object on the AC power cord.
e) Do not attempt to repair or reconstruct the AC power cord in any way.
Remote dust, dirt, etc. on the plug at regular intervals.
If the unit has been dropped or otherwise damaged, turn off the power and
disconnect the AC power cord.
If smoke, odors or noises are emitted from the unit, turn off the power and disconnect the AC power cord.
Placement: Avoid placing the unit in areas of direct sunlight, heating radiators,
closed automobiles, high temperature (over 35C(95F), high humidity (over
90%), excessive dust, vibration, impact or where the surface is titled, as the
internal parts may be seriously damaged.
Non-use periods- When the unit is not used, turn the power off.
When the unit is unused for a long period of time, the unit should be
unplugged from the household AC outlet.
No fingers or other objects inside-Touching internal parts of this unit is dangerous and may cause serious damage to the unit. Do not attempt to disassemble the unit.
Do not put any foreign objecton the disc tray.
Keep away from water and magnets.
Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled
into the unit, serious damage could occur.
Keep magnetic objects, such as speakers, distant from the player.
Stacking: Place the unit in a horizontal position and do not place anything
heavy on it.
Do not place the unit on amplifiers or other equipment which may become hot.
Condesation/Moisture may form on the lens in the following cases:a) immediately after a heater has been turned on b) in a steamy or very humid room
c)the unit is moved from a cold environment to a warm one.
If moisture forms inside this unit, it may not operate properly. In this case , turn
off the power and wait about one hour for the moisture to evaporate.
Noise interference while a broadcast is being received. Depending on the
reception condition of TV, interference may appear on the TV screen while you
are watching a TV broadcast, if the units is switched on . This is not a malfunction of the unit or the TV. To watch a TV broadcast , turn off this unit.
Use of controls or adjustment or performance of procedures other than those
specified here in may result in hazardous radiation exposure.
Polarization- This video product is equipped with a polarized alternating -current line plug. This plug will fit into the power outlet, try reversing the plug. If
the plug still fails to fit, contact your electrician to replace your obsolete outlet.
To prevent electric shock, do not use this polarized plug with an extension
cord, receptacle, or other outlet unless the blades can be fully inserted without
blade exposure. If you need an extension cord, use a polarized cord.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
SAFETY INFORMATION -CONTINUED
UNPACKING
First check and identify the contents of your HT-175 package, as listed below:
- DVD Home Theater unit
- Remote control (1)
- Size AAA batteries (2)
- Audio cable (1 pair)
- Video cable (1)
- Owner’s manual (1)
- AM loop antenna (1)
- All in one control cable (1)
- FM wire antenna (1)
- Speakers (5), Powered Subwoofer (1)
- Speaker cables (5 pair)
If any item should be damaged or missing, please inform your dealer without delay.
Keep the packaging materials, you may need them to transport your player in the future.
WHERE TO PLACE YOUR UNIT
A. Place the unit on a firm, flat surface.
B. When you place the unit near other electronics, the playback picture may become poor and/or distorted. In this situa-
tion, move the unit further away from them.
C. Keep away from direct sunlight & domestic heating equipment.
D. If placed in a cabinet, please allow at least 2.5 cm (1 inch) of free space all around the player for proper ventilation.
TO OBTAIN A CLEAR PICTURE
This unit is a precision device. If the optical pick-up lens and disc drive parts become dirty or worn down, the picture quality may become poor. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts
replacement) every 1,000 hours of use depending on the operating environment. For details, contact your nearest dealer.
NOTICE:
The OSD and the illustration in this manual may be somewhat different from the unit.
Please take the unit as the standard.
Notes on handling
• When shipping the player, the original shipping carton and packing materials may come in handy. For maximum protection, repack the unit as it was originally packed by the factory.
• Do not use volatile liquids, such as insect spray, near the player. Do not leave rubber or plastic products in contact with
the unit for a long time. They will leave marks on the finish.
• The top and rear panels of the unit/ powered subwoofer may become warm after a long period of use. This is not a malfunction.
• When the unit is not in use, be sure to remove the disc and turn off the power.
Notes on location
• Place the player on a level surface. Do not use on a shaky or unstable surface such as a wobbling table or inclined stand.
If this occurs, the loaded disc may come off its spindle and cause damage to the player.
• When you place this player near a TV or radio, the playback picture may become poor and the sound may be distorted.
In this case, place the player away from the TV or radio.
Notes on cleaning
Use a soft, dry cloth for cleaning.
• For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not
use any type of solvent, such as thinner and gasoline, as they may damage the surface of the player.
• If you use a cloth saturated with a cleaning agent, follow that product's instructions and test a small, unobtrusive place on
the player before cleaning further to ensure no harm will come to the unit’s finish.
To obtain a clear picture
The player is a precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality
becomes poor. To maintain a clear picture, we recommend regular inspection and maintenance (cleaning or parts replacement) every 1,000 hours of use depending on the operating environment. For details, contact your nearest dealer.
Notes on moisture condensation
Moisture condensation damages the player. Please read the following carefully.
Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on
the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the
most crucial internal parts of the player.
Moisture condensation occurs during the following cases.
• When you bring the player directly from a cold place to a warm place.
• When you use the player in a room where you just turned on the heater, or a place where the cold wind from the air conditioner directly hits the unit.
• In summer, when you use the player in a hot and humid place just after you move the unit from an air-conditioned room.
• When you use the player in a humid place.
Do not use the player when moisture condensation may occur.
If you use the player in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord
of the player to the wall outlet, turn on the player, and leave it for two or three hours, the player will have warmed up and
evaporated any moisture. Keep the player connected to the wall outlet and moisture condensation will seldom occur.
2
FCC INFORMATION / DISCLAIMERS
3
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
The user is cautioned that changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
NOTE: In order for an installation of the product to maintain compliance with the limits for a Class B device, shielded cables
must be used.
The HT-175 supports “clear” or “unprotected” WMA content only. It does not support secure music downloads from services
that require Digital Rights Management (DRM) capabilities.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
There may be circumstances where a multimedia file that is played back on your unit may not work properly. THIS IS NOT A
MALFUNCTION OF THE HT-175 this is a common occurence with media files due to the differences in how the original file
was encoded.
Note: Apex Digital inc, shall not be responsible for damage that may occur to a disc from being operated in the player.
Due to unforeseen software compatibility issues, certain forms of disc media may not playback properly. This includes compressed media formats, i.e. MP3,JPEG files.
CAUTION:
VISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. DO NOT STARE INTO BEAM.
CAUTION: THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT.” So, to use this model
properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the
unit. To prevent being exposed to the laser beam, do not try to open the enclosure
.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works. © 1992-1997 Dolby Laboratories.
All rights reserved.
TABLE OF CONTENTS
4
Safety Information...................................................
FCC Information / Disclaimers................................
Table of Contents....................................................
Introduction..............................................................
What’s in the box?...................................................
Remote Control Battery Installation........................
Front Panel Overview..............................................
Visual Function Display (VFD)................................
Top Panel Overview (Controls)...............................
Rear Panel Overview..............................................
Powered Subwoofer Overview................................
Remote Control Overview.......................................
Subwoofer/Speaker Setup.......................................
Subwoofer/Satellite Speaker Wiring Diagram.........
Placement of HT-175 Speakers in your room.........
Connecting to your TV.............................................
AM/FM Antenna Connections.................................
Getting S
tarted.......................................................
How to play a disc...................................................
Listening to AM/FM Radio.......................................
Adjusting Level, Volume, Bass/Treble.....................
Setting the System Clock.......................................
Function Buttons
Skip Forward/Backward..........................................
search Forward/Backward.......................................
Slow.........................................................................
Dimmer....................................................................
GoTo a desired selection.........................................
Numeric Key Pad/Direct Program Access..............
Multi-Angle..............................................................
Progressive Scan....................................................
Zoom.......................................................................
Display.....................................................................
Mute........................................................................
Subtitle....................................................................
Audio.......................................................................
Sleep Timer.............................................................
AFF (Active Full Screen Function)..........................
MP3/WMA
Playback...............................................
KODAK/JPEG Photo Playback.............................
Setup Menu Options
.............................................
Language Setup Page:
-OSD Menu............................................................
-Subtitle Menu........................................................
-Audio Menu...........................................................
-DVD Menu............................................................
Setup Menu Options
Video Setup Page:
-TV Shape.............................................................
-Video Output.........................................................
Audio Setup Page:
-Digital Out.............................................................
-Test Tone.............................................................
-DRC (Dynamic Range Compression)..................
-Center Delay........................................................
-Rear Delay...........................................................
Rating
Password/Rating/Load Factory..............................
T
roubleshooting
....................................................
S
pecifications........................................................
W
arranty.................................................................
27
28
28
28
29
29
29
30
31
32
33
1
3
4
5
5
6
7
7
7
8
8
9
10
11
12
13
14
15
15
16
17
17
18
18
18
18
19
20
20
20
21
21
21
22
22
22
23
24
25
26
26
26
27
27
INTRODUCTION
5
DVD features symbols:
Each DVD disc contains various features depending on production of the
disc. Below are some of the symbols representing the features:
Regional Code / Video output system
Dolby Digital Surround
DTS Digital Surround
Number of Audio Tracks
Number of Subtitles
Screen Format
Child Lock
Angle Indicator
Thank you for purchasing your new Apex Digital HT-175 Mini Home Theater
System. Your system is designed for you to enjoy most forms of disc media (DVD,
CD, MP3 and WMA) and while playing DVDs, you’ll enjoy "at -the-movies" picture
and cinema quality sound in 5.1 digital surround. AM/FM stereo playback is available in 2.1 channel mode (2 front speakers and 1 subwoofer).
It has several enchanced features, including Component and S-Video outputs,
Parental Control, and Kodak Picture CD compatibility to view your digital photo
files in a slide show presentation.
The Progressive Scan feature will provide a "film like" quality when connected
between the component (Y,Pb,Pr) connectors and your ED/HDTV set.
Disc Types DVD CD
Capacity
Single-layer / Single side
4.7GB = 2 hr
Single-layer / Double sided
8.5GB = 4 hr
Dual-layer / Single side
9.4GB = 4.5 hr
Dual-Layer / Double sided
17GB = 8 hr
650MB = 74min
Disc Size 12 cm/8 cm 12 cm/8 cm
Subtitles 32
Soundtracks 8
Format Logo
Note: Apex Digital inc, shall not be responsible for damage that
may occur to a disc from being operated in the player.
Due to unforeseen software compatibility issues, certain forms of
disc media may not playback properly. This includes compressed
media formats, i.e. MP3,JPEG files.
What’s in the Box?
- DVD Home Theater unit
- Remote control (1)
- Size AAA batteries (2)
- All in One Control Cable (1)
- Audio cable (1 pair)
- Video cable (1)
- Owner’s manual (1)
- AM loop antenna (1)
- FM wire antenna (1)
- Speakers (5), Powered Subwoofer (1)
- Speaker cables (5 pair)
If any item should be damaged or missing, please
inform your dealer without delay. Keep the packaging
materials, you may need them to transport your player
in the future.
DVD Discs are manufactured under a worldwide
agreed upon "DVD Regional Code System". This
player is designed for playback of Region 1 discs
only, for use in Canada and USA.
Hold the disc's outer edge and/or the center spindle
hole.
Do not touch the disc surface if at all possible.
Do not bend or press on the disc. Do NOT expose the
disc to direct sunlight or heating sources.
A video disc contains high density compressed data that
requires proper Handling.
Store discs in a cabinet vertically, in a dry location.
Prevent exposure to:
- Direct sunlight
- Heat or exhaust from a heating device.
- Extreme humidity.
Clean the disc surface with a soft, dry cleaning cloth.
Wipe the disc surface gently, from center toward
the outer edge.
Do not apply thinner, alcohol chemical solvent, or sprays
when cleaning. Such cleaning fluids will permanently
damage the disc surface.
Do not attach paper or tape to the disc.
A video disc contains high density compressed data that
requires proper Handling.
Care of the Disc
REMOTE CONTROL BATTERY INSTALLATION
6
Remove the battery compartment cover.
Load two AAA batteries into the battery
compartment.
Make sure that the batteries have been inserted
properly, matching to the symbols
+, - marked in the battery compartment. Close
the battery compartment cover.
When replacing batteries, replace both batteries.
Do not mix new and used batteries
together, otherwise, battery life will
be much shorter than normal.
Remove the batteries if the unit will not be used
for a prolonged period of time.
The remote control transmits a directional
infrared beam. Be sure to aim the remote
control directly at the infrared sensor of the
unit during operation.
If the sensor has been covered or there is a
large object between the remote control and
the sensor, the sensor will not respond.
The sensor may not able to receive the
remote signal when it is exposed to direct
sunlight or a strong artificial light (fluorescent
or strobe light). In this case, change the
direction of the light or reposition the unit to
avoid direct lighting.
Within approximately
6 meter (20 feet)
FRONT PANEL OVERVIEW (DISPLAY)
VISUAL FUNCTION DISPLAY (VFD)
TOP PANEL OVERVIEW (CONTROLS)
7
Disc Drawer IR/Remote
Sensor
Previous
Track
Next
Track
Stop Play/
Pause
Open/
Close
Function
Control
Visual
Function
Display
(VFD)
Visual
Function
Display
(VFD)
Headphone
Connector
Volume
Control
FL FR
SL SW C SR
TREBLE BASS DOLBY ST
FM AM KHz MHz
AUX TU
8 8 8 8 8
FL FR
SL SW C SR
TREBLE BASS DOLBY ST
FM AM KHz MHz
AUX TU
8 8 8 8 8
REAR PANEL OVERVIEW
POWERED SUBWOOFER OVERVIEW
8
All In One
Link
to/from
Subwoofer
All In One
Link
to/from
Subwoofer
Speaker
Connectors
Power
On/Off
Switch
Aux Input Progressive/
Component
Outputs
Composite Video & Analog
2 channel output
Digital
Coaxial
Output
AM Antenna
Input
FM Antenna
Input
S-Video
Output
9
REMOTE CONTROL OVERVIEW
Notes:
The remote control transmits a directional infrared beam. Be sure to aim
the remote control directly at the infrared sensor during operation. When
the sensor is covered or there is a large object between the remote control and the sensor will not receive a signal. The sensor may not be
able to receive signals properly when it is exposed to direct sunlight or
strong artificial light (such as a fluorescent or strobe light). In this case,
change the direction of the light or reposition the unit to avoid direct
lighting.
Open/Close
Function
Angle
Audio
Numeric Keys
Clear
Goto
AFF
Cursor Keys: Up / Down / Left / Right
Enter
Timer
Setup
Stop
Pause/Step
Volume Control +/-
Mode
Stereo/Mono
Slow
Dimmer
Repeat
A-B Repeat
I/P
Sleep
Power On/Off
Subtitle
Return
Zoom
Title
Menu
Play
Skip (Next Track/Previous Track)
Search (Fast Forward/Reverse)
Band
Store
Display
Mute
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Important:
Certain features may not operate if the disc does not
support the feature or requires a special setting.
Check the feature content printed on the
disc’s packaging.
1
24
25
26
27
28
29
30
31
32
33
34
35
36
2
3
5
6
7
8
9
10
11
12
13
14
15
16
18
20
21
22
23
19
17
4
10
SUBWOOFER/SPEAKER SETUP
NOTE: Before making or changing any rear panel connections, make sure that all the compo-
nents are switched off and unplugged from the power supply.
First Connect (see diagram below) the supplied “All in One Link” Cable to the HT-175 main unit
and the Subwoofer, this cable transfers the pre-amp signals for all channels from the main unit
to the powered subwoofer.
IMPORTANT: Do not connect any of the supplied speakers to any other amplifier. This may result in
malfunction or fire. This system has been designed for best performance when connected to the
supplied speakers. We do not, therefore, recommend that you connect and use other speakers with
this system, doing so will void your warranty. The front and center speakers supplied with this system are magnetically shielded. However, placing them extremely close to a television may result in
color distortion on the screen. If this happens, move the speakers a little further away and switch off
the television for a couple of minutes. The rear speakers and subwoofer are not magnetically shielded, so they should not be placed near a TV or monitor.
Loading...
