APEX Digital,Inc.
2919 E. Philadelphia Avenue
Ontario, California 91761
FOR SERVICE CALL: 800-4-APEX-INC
Please read this manual carefully before operation.
H
IGH DEFINITION P
ROJECTION TELEVISIONS
INSTRUCTION MANUAL
Rear Projection - GB43HD09, GBHD5109
HDTV MMonitor
M
O
C
.
C
N
I
L
A
T
I
G
I
D
X
E
P
A
1
Projection - GB4308, GB5108
Dear Customer:
Congratulations! You have purchased one of the
finest CoIor TVs on the market!
This manuaI wiIl help you use the many exciting
and usefuI features to make your TV viewing more
enjoyabIe than ever before.
Before operating your TV set, pIease read alI these
safety and operating instructions completely and
then retain for future reference.
Customer's Record
You wiIl find the model number and chassis number on the back of your TV set.
Record these numbers in the spaces provided
beIow.
Refer to them whenever you caII upon your Apex
deaIer regarding this product.
Model Number: GB4308, GB5108
Chassis Number:
Avoid dispIaying stationary images on your TV
screen for extended periods of time. Stationary
patterns generated by computer dispIays, video
games, stock market reports, etc. can become
permanentIy engrained on the picture tube. This
damage is not protected by your warranty as it is
the result of misuse. ShouId you wish to use your
Apex TeIevision to dispIay stiIl images, it is aIways
advisabIe to reduce brightness and contrast settings. Never Ieave a video game or computer display unattended.
NOTE TO CABLE INSTALLER lN THE USA:
This reminder is provided to caIl your attention to
ArticIe 820 - 40 of the NEC that provides guideIines for proper grounding and, in particular,
specifies that the cable ground shaII be connected to the grounding system of the building, as
cIose to the point of cable entry as practicaI.
BEFORE OPERATION
Safety Precautions
WARNING:
TO REDUCE THE RISK OF FlRE OR ELECTRlC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAlN OR MOISTURE.
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR
BACK). NO USER SERVICEABLE PARTS lNSlDE. REFER SERVlClNG TO QUALlFIED
SERVlCE PERSONNEL.
The symboI is intended to alert the user
to the presence of "dangerous voltage"
within the product's enclosure that may
be strong enough to cause an electric
shock.
DO NOT TRY TO SERVlCE THlS
PRODUCT YOURSELF.
This symbol is intended to alert the user
to the presence of important operating
and maintenance instructions in the
manual.
CAUTIONS:
TO PREVENT ELECTRIC SHOCK, DO NOT USE
THlS POLARlZED PLUG WlTH AN EXTENSION
CORD RECEPTACLE OR OTHER OUTLET UNLESS THE PRONGS CAN BE FULLY INSERTED
INTO THE OUTLET TO PREVENTANY EXPOSURE
OF THE PRONGS ON THE POLARIZED PLUG.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
2
Instruction Manual
BEFORE OPERATiON (continued)
CAUTION
PLEASE READ THESE INSTRUCTIONS, KEEP THESE INSTRUCTIONS AND HEED ALLWARNINGS. FOLLOW ALL INSTRUCTIONS.
Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. However
improper use can result in potential electrical shock or fire hazards. In order not to defeat the safe guards incorporated in this TV set, observe the following basic rules for antenna/ TV installation, use and servicing. All operating and use instructions should be followed.
Do not remove the cabinet cover. This may expose you to dangerous voltages. Refer all servicing to qualified service personnel.
Important Safety Instructions
Power Sources - The TV set should be operated only from the type of power source indicated on the TV set or as indicated in the Operation Manual.
If you are not sure of the type of power supply in your home, consult your local power company. For TV sets designed to operate from battery power, or
other sources, refer to the operating instructions.
Alternate Warnings - This plug will only fit into a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact your electrician to have a suitable outlet installed. Do not defeat the safety purpose of the grounding plug.
Water and Moisture Warnings - Do not use the TV set near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like. The TV set should not be exposed to dripping or splashing and no objects filled with liquids, such as vases,
should be placed on the TV set.
Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV set and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV set on a bed, sofa, rug,or other similar surface. This TV set should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
Grounding or Polarization - Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
3
Projection - GB4308, GB5108
Damage Requiring Service - Unplug the TV set from the wall outlet and refer servicing to qualified se rvice p ersonne l
under the following conditions:
a. lf the power cord or plug is damaged or frayed.
b. lf liquid has been spilled or objects have fallen into the TV set.
c. lf the TV set has been exposed to rain or water.
d. If the TV set has been subject to excessive shock by being dropped, or the cabinet has been damaged.
e. If the TV set does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV set to its normal operation.
f. When the TV set exhibits a distinct change in performance-this indicates a need for service.
Servicing - Do not attempt to service the TV set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
BEFORE OPERATiON (continued)
Precautions (continued)
ANTENNA
Outdoor Antenna Grounding- If an outdoor antenna is
installed, follow the precautions below.
An outdoor antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can come in contact with such
power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL
Be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static
charges. Section 810 of the National Electrical Code in
USA and Section 54 of the Canadian Electrical
Code(ANSl/NFPA 70) in Canada provides information with
respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original parts. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
Safety Check - Upon completion of any service or repairs to the TV set, ask the service technician to perform routine safety
checks to determine that the TV set is in proper operating condition.
Disposal - When the TV set reaches the end of its useful life, improper disposal could result in a picture tube implosion.
Ask a qualified service technician to dispose of the TV set.
Example of antenna grounding according
to National Electrical Code (NEC )
4
Instruction Manual
BEFORE OPERATlON (continued)
FCC Warning
Class B Computing Device
Information to User
This equipment has been tested and found to compIy with the Iimits for a class B digitaI device pursuant to
part 15 of FCC Rules. These limits are designed to provide reasonabIe protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not instalIed and used in accordance with the instructions, may cause harmfuI interference to radio
communications. However, there is no guarantee that interference wiIl not occur in a particuIar instaIlation.
lf this equipment does cause harmful interference to radio or TV reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
1) Reorient or reIocate the receiving antenna.
2) lncrease the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) ConsuIt the deaIer or an experienced radio/TV technician for help and for additionaI suggestions.
The user may find the foIlowing booklet prepared by the FederaI Communications Commission helpfuI:"How
to ldentify and ResoIve Radio -TV Interference Problems". This bookIet is available from the US Government
Printing Office. Washington, D. C 20402, Stock No. 004-000-00345-4.
FCC Warning
The user is cautioned that changes or modifications not expressly approved by the manufacturer could void
the user's authority to operate the equipment.
NOTE: ln order for an installation of the product to maintain compIiance with the Iimits for a CIass B device,
shielded cables must be used.
5
Projection - GB4308, GB5108
Introducing the APEX Projection TV
Presenting the APEX Projection TV......................................................................................................9
Using this Manual ................................................................................................................................10
Installing and Connecting the Projection TV
Inserting Batteries into the Remote Control.........................................................................................11
Carrying the Projection TV...................................................................................................................11
Installing the Projection TV..................................................................................................................12
Connector Types...................................................................................................................................13
Projection TV Front panel.................................................................................................................... 14
Projection TV Rear panel ....................................................................................................................14
Connecting the Antenna....................................................................................................................... 15
Connecting an AV receiver...................................................................................................................16
Connecting a VCD , VCR or camcorder.............................................................................................. 17
Connecting a DVD Player with Component Video Connectors.......................................................... 18
Connecting a DVD Player with A/V Connectors................................................................................. 18
Connecting a Digital TV Receiver....................................................................................................... 19
Using the Features
Using the Remote Control....................................................................................................................20
Powering on/off.................................................................................................................................... 21
Watching the TV....................................................................................................................................22
Watching the Digital TV........................................................................................................................25
Using Browsing Channel Function.......................................................................................................25
Watching PIP.........................................................................................................................................26
Using the Menus
Overview...............................................................................................................................................27
Using the Video Menu..........................................................................................................................28
Using the Audio Menu..........................................................................................................................29
Using the System Menu........................................................................................................................30
Using the Tune Menu........................................................................................................................... 34
Other Information
Programming the Remote Control........................................................................................................36
Operating Other Components with Your Projection TV Remote Control............................................40
Troubleshooting.................................................................................................................................... 41
Specifications and Accessories.............................................................................................................42
Limited United States Warranty............................................................................................................43
*
The OSD and figures shown in this manual may be somewhat different from the actual situation.
Contents
6
Instruction Manual
This manual is for models GB43HD09 and GB51HD09.
Model GB51HD09 is used for illustration purposes.
Features
HDTV Monitor: Enables you to receive the 1080i, 720p, 480p, and 480i
digital TV formats. By using the YP
BPR
1/YPBPR2 IN jacks, you can connect
a DTV (digital television) receiver to view DTV programs.
3D Y/C Comb Filter
Film mode: Using the 3:2 Pulldown technology, the Film Mode feature
allows you to obtain a smooth picture movement when playing back movie
or other video sources on film.
Browsing Channel : Allows you to view and choose channels from all
receivable channels scrolling on the screen without leaving the current
channel.
Dual Tuner PIP: Allows you to watch two moving programs
at the same time.
Auto Volume Control (AVC) : Equalizes volume levels so there is con-
sistent output between programs and commercials.
BTSC Sound System: Enjoy stereo, bilingual and mono programs.
BBE Sound Enhancement : This function can characterize the sound,
generate the playback sound almost like natural sound.
DBE Sound Enhancement : You can make bass richer by boosting low
frequency.
Component Video Inputs : Offers the best video quality for DVD (480p,
480i ) and digital set-top box (1080i, 720p, 480p, 480i) connections.
S-VIDEO Inputs: Provides a high - quality image for connected equipment.
Some of features that you will enjoy with your new projection TV include:
INTRODUCTION
7
Projection - GB4308, GB5108
Using this manual
On/off Timer: Turn on/off your projection TV or turn on a certain
channel number at the specified time.
HELP Function
Graphic OSD
Protective Shield
1st Surface Mirror
English/France/Spanish Menu
User Convergence Adjustment:Allows you to adjust convergence.
V-Chip Function: V- Chip technology allows parents to block
unsuitable programming for younger viewers.
CCD function:Allows you to select from three closed caption modes
(for programs that are broadcast with closed captioning).
We recommend that you carefully review the contents of the
following three section in the order shown to ensure that you
fully understand the operation of your new projection TV.
1 Installing and Connecting the Projection TV
This section guides you through your initial setup. It shows
you how to install your projection TV, to connect your new
components and to connect the antenna and cable.
2 Using the Feature
This section shows you how to begin using your new projec-
tion TV. It also shows you how to use your remote control.
3 Using the menus
This section teaches you how to access on-screen menus and
adjust your projection TV settings.
INTRODUCTION (continued)
8
Instruction Manual
Inserting Batteries into the Remote Control
Carrying the Projection TV
Insert two LR03WCH batteries by matching the and on the
batteries to the diagram inside the battery compartment.
Remove the batteries to avoid damage from possible battery
leakage whenever you anticipate that the remote control will
not be used for an extended period.
Handle the remote control with care. Avoid dropping it, getting
it wet, or placing it in direct sunlight, near a heater, or where the
humidity is high.
Your remote control can be programmed to operate most video
equipment (See “Programming the Remote Control”on page 36).
Carrying the projection TV requires two or more people.
The projection TV has been equipped with casters for easy
movement on a hard surface.
Please move your projection TV using the casters.
+-
*
*
*
INTRODUCTION (continued)
9
Projection - GB4308, GB5108
Installing the Projection TV
Please read the “Safe Precautions”and “Specifications and Accessories” completely before installa-
tion.
It is recommended to watch projection TV in soft and indirect light and face center of the screen
for optimum watching effect.
Allow enough space (at least 10cm)between the projection TV and the wall for proper ventilation.
Avoid excessively warm or wet locations to prevent possible damage to the cabinet or components.
To prevent the projection TV from toppling, there is supports under front panel and real panel of
the projection TV. Please contact with your dealer if there is no such supports when you first open
the packing carton.
Front
Panel
Rear
Panel
Support
Support
Keep proper watching distance
After installation,plug the projection TV in the
supply socket.
INSTALLATION (continued)
10
Instruction Manual
Connector Types
Your may find it necessary to use some of the following connector
types during set up.
Coaxial cable
Standard TV cable and antenna cable
Plug Type
Push into connection.
Screw into connection.
Align guides and push
Into connection.
Push into connection.
Screw-on Type
S Video cable
High quality video cable for enhanced picture quality
Video-Yellow
Audio(Left)-White
Audio(Right)-Red
Some DVD Players are equipped with the following three
video connectors:
Y- Green
P
B(CB
,Cbor B-Y)-Blue
P
R(CR
,Cror R-Y)-Red
Audio/Video cable
INSTALLATION (continued)
11
Projection - GB4308, GB5108
Projection TV Front panel
Projection TV Rear panel
The front panel allows you to do the basic operations without using the remote control. Similar
functions on the front panel please refer to the use of the remote control.
*
AIR
CABLE
MAIN POWER
SWITCH
POWER indicator (Green)
STANDBY indicator (Red)
REMOTE indicator (flicker)
INSTALLATION (continued)
12
Instruction Manual
Connecting the Antenna
An outdoor antenna or CATV is recommended for the best reception. The antenna type and its location differ
dependent on local conditions.
It is recommended that a 75Ω coaxial cable be used in order to eliminate possible interference and
noise which may occur due to nearby radio transmissions.
When using a 300Ω twin - lead feeder, connect it to a 300Ω / 75Ω converter and insert the convert-
er into the projection TV’s CABLE IN terminal.
Connect an outdoor antenna referring to the above figure. Set up a lightning arrester and check it
regularly when an outdoor antenna is used.
The antenna cable should not be tied together with other wiring.
The two RF jack allow you to switch signal between Cable and Air input.
75-ohm coaxial cable
300-ohm twin-lead cable
Antenna adapter
(not supplied)
Outdoor antenna
OR
*
*
*
*
*
INSTALLATION (continued)
13
Projection - GB4308, GB5108
Connecting an AV Receiver
Please turn off the power supply of the projection TV and external equipment before connection. Read the oper-
ation manuals of the external audio/video equipment that will be connected to the projection TV completely.
You can connect a stereo system to the MONITOR OUT terminals on the projection TV to enjoy a high quality
sound, or connect a VCR to the projection TV to record programs. The MONITOR OUT terminals output the
audio and video signals being monitored on the projection TV(main picture.)
No output is available at MONITOR OUT when the signal is from YP
BPR
1 or YPBPR2 of the main picture.
*
INSTALLATION (continued)
14
Instruction Manual
Connecting a VCD, VCR or Camcorder
Disconnect all power before making any connections.
You can connect video equipment such as VCD, VCR or camcorder to the projection TV and enjoy the high-
quality picture.
If your video equipment has an S-VIDEO OUT terminal, connect it to the SVHS IN terminal of the projection
TV. If not, connect it to the VIDEO IN terminal.
If you have a mono camcorder, connect
its left audio output to the projection
TV’s AUDIO L (INPUT) jack of AV1,
AV2 or FAV.
:Signal direction
:Yellow terminal (Video)
:White terminal (Audio L)
:Red terminal (Audio R)
Y
W
R
*
Front panel
INSTALLATION (continued)
15
Projection - GB4308, GB5108
Connecting a VCD Player with Component Video Connectors
Connecting a VCD Player with A/V Connectors
Your DVD player has component (Y,B-Y, and R-Y)jacks.
Disconnect all power before making any connections.
1 Using three separate component video cables, connect the DVD player’s Y, B-Y and R-Y jacks to
the YP
BPR
1 or YPBPR2 jacks on the projection TV.
2 Using an audio cable, connect the DVD player’s Audio OUT jacks to the projection TV’s
YP
BPR
1 or YPBPR2 AUDIO IN jacks.
3 Switch to YPbPr1 or YPbPr2 mode, press the VIDEO button.
You DVD player does not have component (Y,PB,and PR) jacks.
Disconnect all power before making any connections.
If you video equipment has an S-VIDEO OUT terminal, connect it to the SVHS IN terminal of the
projection TV. If not, connect it to the VIDEO IN terminal.
INSTALLATION (continued)
16
Instruction Manual
Connecting a Digital TV Receiver
Disconnect all power before making any connections.
1 Using three separate component video cables, connect the digital TV set-top box’s Y, P
B
and P
R
jacks to the YPBPR1 or YPBPR2 jacks on the projection TV.
2 Using an audio cable,connect the Digital TV Set-top box’s Audio OUT jacks to the projection TV’s
YP
BPR
1 or YPBPR2 AUDIO IN jacks.
3 Press VIDEO to switch to YPbPr1 or YPbPr2 mode.
This projection TV is not compatible with digital TV receivers configured with RGB or VGA
output connectors.
If you digital TV set-top box has both VIDEO OUT and S-VIDEO terminals, you can also
connect them to the corresponding IN terminal of the projection TV.
*
*
INSTALLATION (continued)
17
Projection - GB4308, GB5108
Using the Features
Using the Remot control
Remote Control
Instructions in this manual are written for the remote control.Similar controls are also found on
the projection TV console.
The button design and specifications of the remote control are subject to change without notice.
Many TV features can be accessed directly through the remote control.Press “TV”(function but-
ton )on the remote control first to enter TV mode before operating the remote control.
*
*
*
18
Instruction Manual
Power On / Off
Plug in the supply socket and press on the projection TV to turn on the projection TV,
and the indicator becomes green.
Press on the remote control, the projection TV is turned off and enters STANDBY
mode .The indicator becomes red.
In the STANDBY mode, press or CH+/- on the remote control or P+/- on the front
panel to turn on the projection TV. The indicator becomes green.
To turn off the projection TV completely, press .
Main power switch button
Power switch button on remote control
Power switch button on remote control
Main power switch button
The indicator flickers when receiving the signal emitted by the remote control (It does’t flicker in
user convergence adjustment mode).
Auto off without signal reception
When a channel has no signal (e.g. the TV station fails to send signals ) and blue background
appears, the projection TV will automatically enter the STANDBY mode if no button is pressed
within 15 min. If Off Time is preset and the time left is less than 15 min., the projection TV will
carry out first the Off Time .
The function of auto -off without signal doesn' t work in the AV mode.
*
*
FEATURES (continued)
19
Projection - GB4308, GB5108
Watching the TV
1 TV (FUNCTION)
Activates the remote control for use with the projection TV.
2 ANT (Antenna)
Press ANT first to display the current antenna mode. Press repeatedly
to change between the Cable and Air input.
3 POWER
Turns on or off the projection TV.
5 CH+/-
Press to scan through the channels (+ up or -down).
6 VOL+/ -
Press to adjust the volume (+ up or - down).
7 RECALL
Press to alternate or jump back and forth between two channels or
sources. The projection TV will jump between the current channel and
the last channel selected.
8 MUTE
During watching projection TV program, press MUTE to eliminate sound.
Press it again to resume sound.
Pressing VOL + can also cancel the MUTE function.
Pressing VOL - can decrease the volume in the MUTE mode ,but not
cancel the MUTE mode.
4 100+ and 0~9
Use for direct channel selection.
To enter a three - digit channel number when “Anetnna” is set to “Cable”,
press 100+ to call up “1--”, then press 0~9 to enter the last two numbers.
It is invalid if you enter channel number more than 69 (or less than 2)
in the Air mode or more than 125 (or less than 1) in the Cable mode.
The channel number is red when entering by direct channel selection
buttons and the channel is set to “Skip ON”.
The projection TV will return to the TV mode if you press Channel
Number in the AV mode.
*
*
*
*
*
FEATURES (continued)
20
Instruction Manual
9 STILL
Press STILL repeatedly and the picture switches between the still and moving
modes.
STILL is not available in YPbPr1 or YPbPr2.
*
10 DISPLAY
Press to display the current program status, such as the channel number, sound
sysstem, antenna system and current time (if set ). To turn the display off, press
it again.
11 P-MODE
Press repeatedly to scroll through the following available video inputs:
Movie Normal Vivid Personal
Movie: Select to display a finely detailed picture for low light environment
Normal: Select to display a standard picture for normal viewing environment
Vivid: Select for enhanced picture contrast and sharpness.
Personal:User-set picture mode.
Press repeatedly to directly choose one of four different sound modes
that best suits the program you are watching.
News Hall Music Personal
Press to turn on or off the BBE effect mode.
News: News /dialogue
Hall: Hall audio effect
Music: Concert hall audio effect
Personal: User-set sound mode
12 S-MODE
13 BBE
Press repeatedly to select projection TV signal sources shown as the
follows:
14 VIDEO
CHANNEL NO. (AV1) SVHS1 (AV2)
YPbPr2 YPbPr1 F SVHS (F AV) SVHS2
FEATURES (continued)
21
Projection - GB4308, GB5108
You may use this function to watch the
desired program at the preset time and
turn on/off your projection TV at the
preset time.
Call up the item to be adjusted by pressing
CH+/- and adjust it by VOL+/-.
* The other items in TIMER SET menu
can only available after you finish Clock setting.
* “On Set”, “Order Set” and “Off Set” can set to OFF/ONCE/
ALWAYS respectively. Your setting is one-time after your projection
TV is set to ONCE, and last forever after set to ALWAYS unless you
turn off the main power supply.
* “On Timer” and “On Channel” are not available when “On Set” is
set to OFF.
“Order Timer” and “Order Channel” are not available when “Order
Set” is set to OFF.
“Off Timer” is not available when “Off Set” is set to OFF.
* The timer setting will be cancelled automatically after turning off
the main power supply of the projection TV.
CHANNEL NO. Radio Signal
AV 1AV1 Signal
AV 2AV2 Signal
F AV Front AV
SVHS1 S-VIDEO Signal IN 1
SVHS2 S-VIDEO Signal IN 2
F SVHS Front S-VIDEO Signal IN
YPbPr1 DVD Component Signal and DTV Signal IN 1
YPbPr2 DVD Component Signal and DTV Signal IN 2
* SVHS prevails when inserting AV-Video and SVHS simultaneously
(For detail, see page 31).
* If inserting SVHS and turning “S Ident” to ON, the corresponding
AV1, AV2 or F AV will not be displayed (For detail, see page 30).
* To watch component signal and DTV signal, switch to YPbPr1 or
YPbPr2 channel.
Press HELP to display the remote control profile. Press it again to exit.
Press CH+/- to highlight a button, and its function is displayed.
15 TIMER
16 HELP
TIMER SET
CLOCK
On Set
Order Timer
Order Channel
Off Set
Off Time
ALWAYS
ALWAYS
ALWAYS
On Timer
On Channel
Under set
123
123
FEATURES (continued)
22
Instruction Manual
Allows you to display multiple channels and select one directly.
1 Press on the remote control to browse channel and press it again to
exit.
The first nine receivable channels will appear one after another.
2 When the channel becomes moving picture and channel number is yellow,
press VOL+/-, the selected channel will enlarge for normal viewing.
3 At the receiving interval of the first nine channel and second nine channel,
press CH+/- to select the channel that you wish to wiew. The selected channel
becomes moving picture and channel number is yellow, press VOL+/-, the
selected channel will enlarge for normal viewing.
* Browsing Channel will not function when “ Parental Lock” is set ot ON or in
AV mode.
Using Browsing Channel Function
Watching the Digital TV
When you have connected the DTV receiver, you can enjoy digital TV
programs. This projection TV is capable of receiving the 1080i,720p,480p
and 480i digital TV formats.
* This projection TV is not capable of display a native 720p format signal.
When a 720p format signal is received, it make down-conversion.
To view a digital TV program
1 Connect the DTV receiver to YP
BPR
1 or YP
B
23
Projection - GB4308, GB5108
Watching PIP
Press to turn on or off PIP function.
2 LOCATION
Press to change the position of the sub-picture. The position of the sub-pic-
ture will change in the order of lower right, lower left, upper left and upper
right corner of the screen.
3 SIZE
Press to adjust the size of the sub-picture. The sub-picture will change
between SMALL SIZE and BIG SIZE cyclically by pressing it repeatedly.
4 SWAP
Press to switch between the main and sub-picture.
5 PIP VIDEO
Press to realize switching between AV and TV.
* YPbPr1 and YPbPr2 are not available in PIP.
6 PIP CH+
Press to select a upper channel number for PIP.
* You can only select the programs that are auto-searched and stored by
pressing PIP CH+.
7 PIP CH-
Press to select a lower channel number for PIP.
* You can only select the programs that are auto-searched and stored by
pressing PIP CH-.
8 PIP STILL
Press to make PIP picture still, and presss it again to make the picture mov-
able.
9 PIP Quality Adjustment Menu
When PIP is set to ON, press MENU to display the following menu:
Press CH+/- to highlight the desired item and press VOL+/- to adjust.
1 PIP ON/OFF
Contrast 60
60
Color
PIP
FEATURES (continued)
24
Instruction Manual
Many functions are realized through menu operation. Press repeatedly and displays the following menus:
After selecting a menu, press CH+/- to highlight the desired item and press VOL+/- to adjust.
* Items with the mark of “ ” indicate that there is a sub-menu (except Auto Search).
* PIP menu will not appear by pressing if PIP doesn’t turn on.
* Only Video menu and Audio menu appear when switching AV to YPbPr1 or YPbPr2.
Using the Menus
Overview
MENU
DISPLAY
MENU
DISPLAY
Brightness
Treble 60
60
ON
ON
ON
Stereo
+15
Bass
Balance
Surround
DBE
AVC
Audio Out
MTS
60
60
60
Contrast
Color
Source F SVHS
ON3D Comb
60
ON
ON
Air
3D Comb
Channel
Brightness
Treble Language English
ON
ON
T4
Blue Back
S Ident
CCD
Convergence
VCHIP
Bass
Balance
Surround
DBE
AVC
Audio Out
MTS
Contrast
Color
Sharpness
Tint
Advance
Skip
Antema
Auto Search
Contrast 60
60
60
60
ON
ON
ON
Stereo
+15
60
60
60
+15
60
Color
PIP
25
Projection - GB4308, GB5108
Using the Video Menu
Press MENU to enter Video menu.
Press CH+/- to highlight the item to be adjusted.
Press VOL+/- to adjust parameters.
LT1: Luminance Transience Improvement ON/OFF
* “Sharpness” doesn’t work when LTI is OFF.
CTI: Chrominance Transience Improvement ON/OFF
TFNR: Temporal Frame-filtering Noise Reduction Low/Middle/High/OFF
VSM: Velocity Scan Modulation Low/Middle/High/OFF
Sharpens picture definition to give a sharp and clear edge.
BLX: Black Level eXtender ON/OFF
SCC: Skin Color Correct ON/OFF
ETI: Enhance Tube Image ON/OFF
PM: Picture Motion ON/OFF
When it is set to ON, the picture will move slightly left or right automatically about every 20min, which
can reduce the risk of image retention on your projection TV.
Advance sub-menu:
Item
Adjustment Effect
- +
Brightness
Color
Contrast
Sharpness
Tint
Advance
Darker
Lighter
Lower
Lower
More Purple
Brighter
Deeper
Higher
Higher
More Green
Press VOL+/- to turn on the next menu.
Press CH+/- to select an adjustment, and press VOL+/- to adjust
parameters.
Brightness 60
60
60
60
+15
Contrast
Color
Sharpness
Tint
Advance
LT1 ON
ON
High
High
ON
ON
ON
ON
Cold
ON
CT1
TFMR
USM
BLX
SCC
ET1
PM
CTA
PILM
MENUS (continued)
26
Instruction Manual
CTA: Color Temperature Adjust Normal/Cold/Warm
You can select Cold, Normal or Warm that best suits the program you are watching.
Cold: Select to give the white colors a blue tint.
Normal:Select to give the white colors a neutral tint.
Warm: Select to give the white colors a red tint (NTSC-Standard).
FILM:Film mode ON/OFF
Recommended for 24 frame-per-second films.
Press MENU to enter Audio menu.
Press CH+/- to highlight the item to be adjusted.
Press VOL+/- to adjust parameters.
Item
Adjustment Effect
ON/OFF
ON/OFF
Auto volume control ON/OFF
Press VOL+/- to turn on the next menu.
Press CH+/- to call up the item to be adjusted, and press VOL+/- to adjust.
* You can not select Audio Out when in YPbPr1 or YPbPr2.
Stereo:Select for stereo reception when viewing a program broadcast in stereo.
SAP: select to automatically switch the projection TV to second audio programs
when a signal is received.
(If no SAP signal is present, the projection TV remains in Stereo mode.)
Mono:Select mono reception
* You can not make selection when receiving Mono signal.
* MTS can not be selected in AV mode and has only Stereo mode.
VOL-
Decrease
Decrease
Increase left speaker
VOL+
Increase
Increase
Increase right speaker
Treble
Bass
Balance
Surround
DBE
AV C
Audio Out
MTS
Using the Audio Menu
Treble 60
60
+15
ON
ON
ON
Stereo
Bass
Balance
Surround
DBE
AVC
Audio Out
MTS
MENUS (continued)
27
Projection - GB4308, GB5108
Audio Out sub-menu:
Using the System Menu
When Fixed is set to OFF, the volume output from your audio system can still be controlled by the projec-
tion TV’s remote control. When Fixed is set to ON, the volume output of the projection TV is fixed. Use
your audio receiver’s volume control to adjust the volume through your audio system.
Press MENU to enter System menu.
Press CH+/- to highlight the item to be adjusted.
Press VOL+/- to adjust parameters.
Language:You can switch the languages for the On-Screen-Display to English, French to Spanish.
Blue Back: Blue back ON/OFF
If “ Blue Back” is set to ON, the projection TV will display a soft blue backbround when no
signal received.
If “ Blue Back” is set to OFF, and even nosie dot will be displayed on the screen when no sig-
nal is in the TV mode, and the screen becomes dark when no signal is in the AV mode.
* “Blue Back” isn’t available for YPbrPr1 and YPbPr2. The screen background becomes black
without signal reception in YPbPr1 and YPbPr2.
S Ident: S-Video indentfication ON/OFF.
When it is set to ON, press VIDEO to skip the related AV (AV1,Av2 and FAV) if inserting the relat-
ed SVHS.
When it is set to OFF, pressing VIDEO cannot skip the related AV if inserting the related SVHS.
For example, when SVHS1 is inserted and “ S Ident” is set to ON, the projection signal source will
change in the following order by pressing VIDEO (AV1 is skipped)
CHANNEL NO. SVHS1 AV2 SVHS2 F AV
YPbPr2 YPbPr1 F SVHS
Fixed ON
AV Level 60
Language English
ON
ON
T4
Blue Back
S Ident
CCD
Convergence
Vcmo
MENUS (continued)
28
Instruction Manual
* When both AV-Video and SVHS are inserted , and “ S Ident ” is OFF, SVHS will prevail, and the
related AV-Video will display SVHS signal in monochrome. To watch AV-Video, unplug SVHS.
“OFF” Turns off Caption Vision.
“CC1,CC2,CC3,CC4” Displays a printed version fo the dialog or sound effects of a program.
(Should be set to CC1 for most programs).
“T1 ,T2 ,T3 ,T4” Display network/station information presented using either half of the
whole screen (if available). For closed captioning ,set to CC1.
“XDS” Display a network name, program name, program length, and time of
(eXtended Data Service) the show if the broadcast offers this cervice.
* If OSD appears on the screen, there is no CCD display.
* CCD function is not available in PIP, sub-picture in Double View, YPbPr1 and YPbPr2.
Convergence Adjustent
The projection tube image appears on the screen in three colore (red,
green and blue ).If they do not converge, the color is poor and the picture
blurs. Before you use your projectio TV, be sure to adjust the convergen-
ce. The convergences of the projection TVs have been adjusted before
they go out of factory. If you are not satisfactory, adjust the convergence
according to the following procedures.
* Unshielded speakers or other metallic objects can cause picture distor-
tion if placed close to the projection TV.
Press CH+/ - to highlight the item of Convergence in System Menu, and
press VOL+/ - to enter convergence adjustment mode.
1 Press “5” first to select the center point on the screen to be adjusted
shown as the following figure.
2 Press MENU to select red or blue convergence adjustment.
When four arrows on the lower left corner become red, it indicates red
convergence is ready for adjustment, and when they become blue, it indi-
cates blue convergence is ready for adjustment.
CCD:
MENUS (continued)
29
Projection - GB4308, GB5108
Press CH+/ - to adjust cross cursor vertically, and VOL+/ - to adjust horizontally
so that the red and blue cross cursor is lined with the green one , and the cross
cursor is lined with the green one , and the cross cursor becomes white.
* When “MAX” is displayed on the screen, it indicates that the adjustment
is maximum.
After completion of above adjsutment, press “1”, “2”, “3”, “4”, “6”, “7”,
“8” , or “9” to adjust the other points on the screen.
Repeat Step 2 and 3 to align the red or blue cross cursor with the green one.
To save the adjusted data, press POWER.
If you are not satisfactory with the adjustment result, do not press
POWER to save the data. Press “0” to load the factory- set data in order
to resume the previous status.
Press PIP STILL to exit convergence adjustment mode.
V CHIPsub-menu :
You may prevent children from watching programs not suitable for them, such as sexual or violence
program.
Press VOL+/ - to enter V Chip sub-menu. Four-digit password is required. The original password is
“6688”
3
4
5
6
Poor convergence line
Green reference line
Before adjustment After adjustment
Convergence line is aligned with
green reference line basically
Enter The Password
Press 0-9
X X X X
MENUS (continued)
30
Instruction Manual
The old password is invalid after change.
If you forget your password, see “Lost password” on page 41.
The next menu will turn on after you enter correct password.
Parent Lock : ON/OFF
Parent lock is OFF , No programs are blocked from viewing.
No Rating : Block/Unblock
No Rating is block. Blocks all programs and movies that are broadcast without a rating.
No Rating is unblock. Allows programs and movies that are broadcast without a rating.
Ext Source : Block/Unblock
Rating options sub-menu
Press CH+/- to highlight one of the items, and press VOL+/ - to dispay U or B on the screen. A“U”
indicates a rating which is unblocked and a “B” indicates a rating which is blocked.
TV Guoidelines : Press VOL+/ - to enter TV Guidelines sub-menu.
TV-Y : All children FV : Fantasy Violence
TV-Y7: Directed to older children D : Suggestive Dialogue
TV-G : General Audience L : Strong Language
TV-PG : Parental Guidance suggested S : Sexual situations
TV-14 : Parents Strongly Cautioned V : Violence
TV-MA : Mature Audience only
Rating All FU D L S V
TV-MA
TV-14
TV-PG
TV-G
TV-Y7
TV-Y
U U U U
U U U U U
U U U U U
U
U U
U
Parent Control
Parent Lock ON
Block
Block
No Rating
EXT Source
TV Guidelines
Movie Ratings
Change Password
MENUS (continued)
31
Projection - GB4308, GB5108
Movie Ratings : Press VOL+/- to enter Movie Ratings sub- menu.
G: All children and General Audience
PG: Parental Guidance suggested
PG-13: Parental Guidance for children under 13
R: Restricted viewing , Parental guidance is suggested for children under 17
NC-17 : No one 17 and under allowed
and X
Change the Password sub-menu :
Press VOL+/ - to enter Change the Password sub-menu.
* The settings of V Chip for main picture work for PIP and sub-picture.
Channel : Press VOL+/ - to select the channel you want to adjust.
3D Comb: 3D YC comb filter ON/OFF
*3D Comb is invalid when receiving monochromatic signal.
Using Tune Menu
Movie Ratings
Change The Password
Enter New Password X X X X
Repeat New Password X X X X
Press 0-9
X B
B
B
B
B
B
MC-17
R
PG-13
PG
Channel
60
ON
ON
Air
3D Comb
Skip
Aotenna
Audo Search
G
MENUS (continued)
32
Instruction Manual
Skip: ON/OFF
Skip ON Enable you to skip undesirable program by pressing CH+/-.
Skip OFF Enable you add or resume the skipped channel.
* The channel number is red when “Skip” is ON, and green when “Skip” is OFF.
Antenna : Air/Cable Allows you to select antenna input mode.
Auto Search : The projection TV will auto-search and save channels automatically by pressing
VOL+/-. The channel without program will be skipped . The skipped channel won’t be
displayed even if pressig CH+/- or using Browsing Channel function.
Pressing VOL+/- or MENU stops auto - searching.
* When “Antenna” is set to the “Air” mode, the projection TV will auto search from channel number
2 to 69, and when set to the “Cable” mode, it will search from 1 to 125.
33
Projection - GB4308, GB5108
Programming the Remote Control
Remote-control switchover
Press VCR/DVD, SAT/CABLE or AUX to select the device you want to control.
To program the remote control
Press and hold VCR.DVD, SAT/CABLE or AUX for over 2 seconds until the LED on the remote control turns
off. Release the button the LED will light again (the remote control enters the PROGRAMMING mode).
Enter three-digit code number for your equipment. If the correct code number is entered, the LED blinks
three times. If you enter a code not listed below, or you press any other buttons than SEARCH and 100+,
the LED turns off.
To search codes
Press ad hold VCR/DVD,SAT/CABLE or AUX for over 2 seconds unil the LED turns off. Release the button
(the LED wil light again) and the remote control enters the PROGRAMMING mode.
Press SEARCH.
Press CH+/- to search codes downwards or upwards. Each time you press CH+/-, the code number decreas-
es or increases by 1 while the remote control sends the code number for POWER button on your device.
If the desired code number is found,press 100+ to program the code for your device until the LED blinks
three times.Then the remote control exits from the PROGRAMMING mode and returns to norml operation.
Or press any other button to exit from the PROGRAMMING mode after the LED blinks rapidly eight times,
and the operation is not active.
To check the current code number
Press and hold VCR/DVD, SAT/CABLE or AUX for over 2 seconds until the LED turns off. Release the but-
ton (the LED will light again) and the remote control enters the PROGRAMMING mode.
Press 100+ .
You may read the code numder according to the LED display status as follows.
* If there is no operation within 20 seconds during the steps mentioned above, the remote control will
automatically exit from the appropriate operation.
Code Number
First - digit
0
1
0
1
Second - digit
0
0
4
5
Third - digit
0
6
3
0
First - digit
Blinks rapidly once
Blinks once
Blinks rapidly once
Bliks once
Secod - digit
Blinks rapidly once
Blinks rapidly once
Blinks four times
Bliks five times
Third - digit
Blinks rapidly once
Blinks six times
Blinks three times
Bliks rapidly once
LED Display Status
(2 sec. time interval between every two digits.)
Other Information
34
Instruction Manual
DVD CODES
Brand
APEX
ChangHong
Aiwa
Hitachi
JVC
Magnavox
Mitsubishi
Panasonic
Philips
Pioneer
Proscan
RCA
Sanyo
Sony
Toshiba
Code Number
300,395
300,301,302,303
312
313
309,314
308
307
315,386
308,316,317,318
306,311
310
310
319
305,320,321
304
VCR CODES
Brand
Admiral
Aiwa
Akai
Amstrad
ASA
Audio Dynamics
Audiovox
Broksonic
Bush
Calix
Candle
Canon
Capeheart
Carver
CCE
Citizen
Code Number
373
340,387,388
350,379
340
357
334,374
376
375,377
339
376
336,376
361,362
349
343
379
336,337,376,379
Brand
Craig
Curtis Mathes
Daewoo
Daytron
DBX
Dimensia
Dynatech
Electrohome
Electrophonic
Emerson
Fisher
Funai
GE
Go Video
Goldstar
Goodmans
Code Number
331,337,376
332,336,361,372
349,363,377,379,380
349
334,374
384
340
330,376,381
376
330,338,340,345,375,376,377,381
329,331,340,341,351
377
32,337,361,372
359,360,389
336,376,379
339
LD CODES
Brand
Magnavox
Panasonic
Pioneer
Sony
Code Number
322
326,327
328
323,324,325
INFORMATION (continued)
35
Projection - GB4308, GB5108
Brand
Gradiente
Grundig
Harley Davidson
Harman Kardon
Hinari
Hitachi
Instant Replay
JC Penney
Jensen
JVC
Kenwood
Kodak
Lloyk
Logik
LXI
Magnavox
Marantz
Marta
MEI
Memorex
MGA
Minolta
Mitsubishi
Motorola
MTC
Mutitech
NEC
Nikko
Olympus
Optimus
Optonica
Panasonic
Pentax
Perdio
Philco
Philips
Pilot
Pioneer
Portland
Code Number
378
357
378
364
339
340,342,347,350
385
333,334,337,347,350,361,364,374,376
342,350
333,334,336,350,352,358,374
333,334,336,350,352,358,374
376
340,378
339
376,390,391,392,393,394
343,344,357,361
333,334,336,343,357,361,374
376
361
331,340,361,373,376,378
330,345,356,381
342,347
330,342,345,352,356,358,381
373
340,378
337,339,340,378
333,334,336,350,352,358,364,374
376
383
373,376
346
335,348,361,365,366
336,342,347
340
343,344,361
343,346,357,631
376
334,342,352,358,374
349
Brand
Proscan
Quasar
Radio Shack
Radix
Randex
RCA
Realistic
Ricoh
Salora
Samsung
Sanky
Sansui
Sanyo
SBR
Schneider
Scott
Sears
Sharp
Shintom
Sony
STS
Sylvania
Symphonic
Tandy
Tashiko
Tatung
Teac
Techoics
Teknika
Toshiba
Totevision
Ve ctor Tesearch
Victor
Videosonic
Video Concepts
Wards
XR-1000
Yamaha
Zenith
Code Number
332,372
354,355,361
329,330,331,341,346,373,376,378,381
376
376
332,337,342,347,365,372
340,341,346,361,373,376,378,381
369
356
337,363
373
334,350,352,353
331
357
339
338,345,375,377
329,331,341,342,347,351,376
330,346,381
339
367,368,369,370,371
347
340,343,344,345,356,361,378
340,378
340
340,376
333,350,353
333,340,350,378
348,361
340,361,376,378
338,341,342,345,356,363
337,376
334,364
334,358
337
334
330,331,337,338,339,340,342,346,347,361,373,376,378,381
378
333,334,336,350,364
370,371
INFORMATION (continued)
36
Instruction Manual
CABLE CODES
CABLE CODES
Brand
ChangHong
ABC
General Instrument
Hamiln
Hytex
Jerrold
Movie Time
NSC
Oak
Panasonic
Philips
Pioneer
RCA
Scientific Atlantic
StarCom
Tocom
TV86
United Artists
Viewstar
Zenith
Brand
GE
Genernal Electric
Hitachi
Hughes
JVC
Magnavox
Panasonic
Philips
Proscan
RCA
Sony
Toshiba
Code Number
528,531,532
526
534,535
537,538
533
536
543
536
528,531,532
528,531,532,540
529,539
527,530
CABLE CODES
Brand
ChangHong
Aiwa
Carver
Fisher
JVC
Magnavox
Memorex
Panasonic
Pioneer
Proton
Quasar
RCA
Sony
Techniques
Toshiba
Victor
Code Number
700,701
702
709
709
706,712
708
704
710
703,704
708
710
707,713
702,705
710
711
706
Code Number
500
508,509,510,511
525
541,542,545,546,547
508
506,510,511,512,513,520,525,548,549,550
515
515
501,508,516
502,507,544
514
503,504,517
524
504,505,518,519
511
509,512
515
508
514,515
504,521,522,523
INFORMATION (continued)
37
Projection - GB4308, GB5108
Operating Other Components with Your Projeciton TV Remote Control
Operating a VCR Operating a DVD player
Operating a laser disc player
at the same time
* When operating your non - TV AV equipment with the
remote control, refer to operation instructions of your
original remote.
Power on the laser disc player
Search chapters forward or backwad
Play disc
Stop
Pause
Power on the VCR
Select channels directly
Change channels
Play video tape
Stop
Search forward or backward
Pause
Record
To
Press
Power on the DVD player
Select chapters directly
Search chapters forward or backward
Play DVD
Stop
Pause
Move the cursor in the menu
Display the DVD menu
Press To Press To
INFORMATION (continued)
38
Instruction Manual
Troubleshooting
Symptom Check these things
No power supply
Poor color/hue
Spots appear on the screen.
Stripes appear on the screen.
Double or triple images
Snowy picture
Abnormal color or no picture
The remote control
does not work.
Lost password
Cannot receive
Digital channels
Some channels missing with
Browsing Channel Function
Make sure the power cord is plugged in and turn on the main power
switch.
May be the misadjustment for contrast, color and hue.
May be jamming from cars, motorcycles, electric trains, high tension
lines,neon signs, hair dryers, etc.
May be jamming from other TV receivers, personal computers, and TV
games as well as interference from radio station.
May be jamming by reflection from nearby mountains or buildings.
Check if the direction of the antenna has changed because of strong wind,
etc.
Check the antenna/cable connections.
Check if the direction of the antenna has changed.
May be due to improper fast power-on. Power off the projection TV, then
power it on again.
The batteries in the remote control may be exhausted.
Check the orientation of the batteries.
Press TV on the remote control.
“6688” is super password, and allows you will enter “Parent Control”,and
therefore change password.
Check the connections between the DTV receiver and the projecton TV
(see page 19).
Check your local listing to find out if you can receive digital broadcasts in
your area.
Use Auto Search in the Tune Menu to add receivable TV channels that are
not presently in TV memory(see page 35).
Before calling service personnel, please check the following chart for a possible cause to the trouble
you are experiencing.
INFORMATION (continued)
39
Projection - GB4308, GB5108
Specifcations and Accessories
Projecton system
Picture tube
Rated voltage
Rated power consumption
3 picture tubes, 3 leses, horizontal in-line system
7-inch high-brightness monochrome tubes, with optical
AC: 120V, 60Hz
~280W
Designs and specifications are subject to change without notice.
Dimensions
Weight
Projection screen
(Effective screen sjze)
Channel coverage
Channel preset
Television system
181
NTSC,American TV Standard
Video(IN): 3 1Vp-p,75 ohms unbalanced,sync negative
S Video(IN): 3 Y:1Vp-p,75 ohms unbalanced,sync negative
C:0.286Vp-p (Burst signal),75 ohms
Audio(IN): 5 500mVrms(100% modulation)
Impecance:47 kiloohms
MONITOR OUT: 1 Video:1Vp-p 75 ohms unbalanced,sync negative
Audio:500 mVrms at the maximum volume setting
(Variable)
500mVrms (Fixed)
Impedance:1 kiloohm
Component Video IN: 2 (Y,P
B,PR
) Y: 1Vp-p,75 ohms unbalanced,sync negative
P
B
: 0.7Vp-p,75 ohms
P
R
: 0.7Vp-p,75 ohns
Number of inputs/outputs
Antenna input
Audio output
75Ω(unbalanced)
≥15W+15W(THD=7%)
Operation manual
Universal remote control
LR03WCH alkaline batteries(2)
Accessories supplied
GB43HD09:~940mm(w) x 1190mm(h) x 560mm(d)
GB51HD09:~1092mm(w) x 1420mm(h) x 560mm(d)
GB43HD09:~876mm(w) x 656mm(h)
GB51HD09:~1035mm(w) x 778mm(h)
VHF 2~13
UHF 14~69
CABLE TV : MID BAND(A-8~A-1,A~1)
SUPER BAN43D (J~W)
HYPER BAND (AA~22,AAA,BBB)
ULTRA BAND (65~94,100~125)
GB43HD09:~61kg
GB51HD09:~70.5kg
INFORMATION (continued)
40
Instruction Manual
LIMITED UNITED STATES WARRANTY
Apex DigitaI, Inc makes the foIlowing Iimited warranties. These Iimited warranties extend to the originaI consumer purchaser or any person receiving this product as a gift from the originaI consumer purchaser and to no other purchaser or transferee.
Limited One - Year Warranty
Apex Digital, Inc warrants this product and its parts against defects in materiaI or workmanship for a period of one (1) year after the
date of original retaiI purchase. During this period Apex DigitaI, Inc wilI repair or repIace a defective part or product at their option, with
a new or refurbished part or product, without charge to you. " Authorized " Apex DigitaI, lnc Service Center personneI wiII come to your
home when warranty service is required. Depending on the type of repair required, the service wiIl either be performed in your home or
the set wiII be taken to the Authorized Apex DigitaI, lnc Service Center's repair facility for repair and then returned to your home at no
cost to you.
Limited Two Year Warranty
Apex Digital, lnc further warrants the picture tube in this product against defects in materiaIs or workmanship for a period of two (2)
years after the date of original retail purchase. During this period Apex Digital, Inc wiII replace the defective picture tube or product at
their option with a new or rebuilt picture tube or at their option replace the entire product with a new or refurbished product at no
charge to you; if however the defective picture tube or product is replaced after one (1 ) year from the date of the original retaiI purchase, you pay all labor, packing, transportation and insurance charges involved in the repIacement.
RentaI Product
The warranty for a rental product begins with the original date of receipt by the rentaI firm.
Your ResponsibiIity
The above warranties are subject to the foIIowing conditions:
You must retain your bilI of saIe to provide proof of purchase
AII warranty service of this product must be made by an Authorized Apex DigitaI, Inc Service Center
These warranties are effective onIy if the product is purchased and operated in the U S. A.
Labor service charges for set instaIlation, setup, adjustment of customer controIs and installation or repair of any type of
antenna or cabIe systems are not covered by this warranty. Reception probIems caused by inadequate antenna or cable
system are your responsibility.
Warranties extend onIy to defects in materials or workmanship as limited above and do not extend to any product or
parts which have been Iost or discarded by you or damage to product or parts caused by misuse, accident, damage
caused by Acts of God, such as Iightning or fluctuations in eIectricaI power, improper instaIlation, improper maintenance
or use in vioIation of instructions furnished by us, or to product which has been modified or had the seriaI number
removed, aItered, defaced or rendered iIlegibIe.
How to Obtain Warranty Service
lf after foIlowing aII the operating instructions in this manuaI and reading the section TroubIeshooting you find that service is necessary:
1. Contact our Customer Service Center directly caIl 866 4 APEXlNC (866 427 --3946 ), Mon -- Fri 8am --5pm (Pacific Time)
2. After obtaining the requested information. You must present your biIl of saIe to the Authorized Service Center to obtain warranty service.
3. Authorized Apex DigitaI, Inc Service personneI wiIl come to your home when warranty service is required. Depending on the type of
repair required, the service wilI either be performed in your home or the set wiII be taken to the Authorized Service Center's faciIity for
repair and then returned to your' home.
Limitations
AlI warranties implied by state law, including the impIied warranties of merchantability and fitness for a particutar purpose , are expressly
limited to the duration of the Iimited warranties as set forth above. With the exception of any warranties impIied by state law as hereby
limited, the foregoing warranty is excIusive and in Iieu of alI other warranties, guarantees. agreements and similar obligations of manufacturers or seIIer with respect to the repair or repIacement of any parts. ln no event shall Apex Digital, Inc be IiabIe for consequentiaI or incidentaI damages.
No person, agent, distributor, deaIer or company is authorized to change, modify or extend the terms of these warranties in any manner
whatsoever. The time within which action must be commenced to enforce any obligation of Apex Digital, lnc arising under this warranty or
under any stature, or Iaw of the United States or any state thereof, is hereby Iimited to ninety (90 ) days from the date you discover or shouId
have discovered the defect. This Iimitation does not appIy to impIied warranties arising under state Iaw.
This warranty gives you specific rights and you may aIso have these rights which may vary from state to state. Some states do not aIlow
Iimitation on how long an implied warranty lasts, when an action may be brought, or the excIusion or Iimitation of incidental or consequentiaI
damages, so the above provisions may not appIy to you.
41
Projection - GB4308, GB5108
Packing List
Parts
Projection TV Receiver
Universal Remote Control
Operation Manual
LR03WCH Alkaline Batteries
NO. Quantities Remarks
1
2
3
4
1
1
1
2
Loading...
