APC SILCON 990-4053 User Manual

APC Silcon

480kW 400V UPS

Installation Guide

Copyright 2000 APC Denmark ApS

This manual is subject to change without

notice and does not represent a commitment

on the part of the vendor

Thank You!

Thank you for chosing the APC Silcon Series UPS. Please read this Installation Guide
thoroughly prior to installing the system. It provides important information on safe and
efficient installation.

The installation and use of this product must comply with national, federal, state, municipal
and local codes.

Safety Symbols used in this manual

WARNING! Indicates a hazard which, if not avoided, could result in injury or death.

CAUTION!

NOTICE!

WARNING!

This UPS unit contains hazardous AC and DC voltages. Only qualified electricians should install
the UPS, AC line and external batteries, and must be familiar with batteries and battery
installation.
Before installing, maintaining or servicing the UPS, shut off the UPS and disconnect all sources
of AC and DC power.
As the UPS has no built-in disconnection devices to switch off external AC and DC input power,
ensure that disconnection devices are provided as separate parts in connection with the
installation!
The installer must provide each external disconnecting device for this UPS system with labels
with the following text:
“Isolate the Uninterruptible Power Supply (UPS) as instructed in this guide before working on
circuit”

AC and/or DC voltage will always involve a potential risk of AC voltage at UPS output generated
from either batteries or mains. To avoid equipment damage or personal injury, always assume
that there may be voltage at UPS output.
This system is equipped with an auto-start function. If activated, the system may start without
warning. Refer to the “Programming” section of this guide for information on de-activation.

Indicates a hazard which, if not avoided, could result in damage to the
product or other property.

Read and pay attention to this important information.

TEST BEFORE YOU TOUCH!

To reduce the risk of fire or electric shocks, install the UPS and external batteries in a
temperature and humidity controlled indoor area, free of conductive contaminants.
UPS batteries are high-current sources. Shorting battery terminals or DC terminals, DC busbars
can cause severe arcing, equipment damage and injury. A short circuit can cause a battery to
explode. Always wear protective clothing and eye protection and use insulated tools when
working on batteries.

CAUTION!

This unit contains components sensitive to electrostatic discharge (ESD). If you do not follow the
ESD procedures, you may cause severe damage to electronic components.

990-4053

2 Installation Guide APC Silcon 480kW 400V UPS

Contents

1.0 Introduction 5

1.1 Tools and Equipment 5

2.0 Unpacking 6

3.0 Installation 7

3.1 Requirements on Site 7

3.1.1

3.2 Footprint 8

3.2.1 1900mm Cabinet for 480kW UPS 8

3.2.2 1600mm Cabinet for 480kW Isolation Transformer 8

4.0 External Connection 9

4.1 Connecting the UPS 9

4.2 System Integration Interface 11

4.2.1 Connections 12

4.3 Parallel Board 13

4.4 Relay Board 16

4.4.1 Relay Board/Relay Functions 17

4.5 Communication Interface Board 19

4.5.1 Connections 19

4.6 Connecting of APC Silcon Tripel Chassis 20

4.7 APC Silcon Triple Chassis 21

4.7.1 Safety Warnings 21

4.7.2 Product Description 21

4.7.3 Installing Management Peripherals 22

4.7.4 Powering the APC Silcon Triple Chassis 24

4.7.5 Troubleshooting 25

4.7.6 Product Specifications 26

4.8 APC Silcon Battery Cabinets 29

4.9 Battery Breaker Box/Fuse-box 31

4.9.1 Battery Breaker Box 32

4.9.2 APC Battery Breaker Box Connection Diagram 33

4.9.3 UPS with External Battery in Battery Breaker Box/Fuse-box Configuration 34

5.0 Programming Parameters 35

5.1 Parameters 35

5.1.1 Programming Keys 36

5.1.2 Programming Example - Switch to Bypass Operation 37

5.2 System Configuration 37

5.2.1 Programming Example - Change Charge Voltage to 446 39

5.2.2 Programming Example - Change to Output Isolation Transformer available 40

5.3 Programming Parameters for Advanced Parallel Operation 41

5.3.1 Description of Settings 41

5.3.2 Programming example 42

5.4 Battery Monitor 42

5.4.1 Installation of new batteries 42

6.0 Options/Accessories 43

6.1 Service Bypass Panel for Single Operation 43

6.1.1 Wiring up UPS with SBP in TN-C-S Network 44

6.1.2 Wiring up UPS with SBP in TN-S Network 44

6.1.3 Operating The External Service Bypass Switch 45

6.2 Service Bypass Panel for Parallel Redundant Operation 47

6.2.1 Two Parallel Systems with Service Bypass Panel 48

6.2.2 Parallel/Redundant Operation with Service Bypass Panel and External Battery

6.2.3 Operating External Service Bypass Switch for Parallel Systems 50

6.2.4 Isolating One UPS for Service/Maintenance 54

6.2.5 Switching Back to Normal Parallel/Redundant Operation 55

6.3 Intersystem Synchronization Unit 56

6.4 Remote Display 57

Cabinet Dimensions 7

via MCCB 49

990-4053

Installation Guide APC Silcon 480kW 400V UPS 3

6.4.1 Extension of Remote Display Communication Distance 57

6.4.2 Remote Display Installation 59

6.4.3 Remote Display Use 60

6.5 Isolation Transformer 61

6.5.1 Connecting Isolation Transformer 62

6.5.2 Wiring up UPS with External Yyn0 Isolation Transformer at Output 64

6.5.3 Wiring up UPS with External Yyn0 Isolation Transformer at Input 65

6.5.4 Wiring up UPS with External Optional Dzn0 Isolation Transformer at Input 66

6.5.5 Wiring up UPS with External Optional Dzn0 Isolation Transformer at Output 67

6.5.6 Wiring up UPS with External Optional Dyn11 Isolation Transformer at Input 68

7.0 System Specifications 69

7.1 Technical Data 69

7.2 Dimensions / Weight 69

8.0 Warranty 70

8.1 APC Silcon Series Limited Factory Warranty 70

9.0 Appendix 71

9.1 Table 1. Installation Planning Data 71

10.0 How to Contact APC 73

990-4053

4 Installation Guide APC Silcon 480kW 400V UPS

Introduction

1.0 Introduction

Power regulation varies from country to country, and information given in this installation
guide can therefore only be of a general nature. Electricians should therefore always refer to
national and local electrical codes prior to installing the UPS system.

1.1 Tools and Equipment

CAUTION!

Heavy equipment. To prevent personal injury or equipment damage, take extreme care when
handling and transporting UPS cabinet and equipment.

CAUTION!

Ensure that front doors are in place and that internal front cover is fastened by screws before
attempting to lift or transport the system.

This section lists all tools and equipment required to install all UPS configurations. See also
section 4.0 of this guide for further details on connection.

Tools:

• 10mm socket

• 13mm socket-deep

• 17mm socket

• 19mm socket-deep

• 19mm combo wrench

• Small flat head/regular screwdriver

• #3 philips screwdriver

• Compression lug crimping tool

• Knock-out set (for glands)

Equipment:

• Compression lugs for cable terminations

• Cable to Service Bypass Panel from system feeder

• Cable to UPS input from Service Bypass Panel

• Cable to Service Bypass Panel from UPS output

• Cable from Service Bypass Panel to customer distribution

• Cable to UPS input from external batteries/external Battery Breaker Box
(systems with external battery)

• Solid core, control cable to UPS from Service Bypass Panel

• Solid core, control cable to UPS from external batteries/external Battery
Breaker Box

990-4053

Installation Guide APC Silcon 480kW 400V UPS 5

Unpacking

2.0 Unpacking

NOTICE!

Unless otherwise specified by the shipping company use a fork lift to unload equipment from
pallet

1. To unpack UPS unit, remove top and bottom screws from side plates of packaging and lift up side plates

2. Verify compliance between type label on reverse side of front door and system ordered. Check input and
output voltage

3. Copy type label data to label copy below for easy identification of system

4. Use fork lift to transport system to installation site

Copy of type label

PLEASE RECYCLE

The shipping materials for the APC Silcon UPS are recyclable. Please save them for later use or
dispose of them appropriately.

990-4053

6 Installation Guide APC Silcon 480kW 400V UPS

Installation

3.0 Installation

3.1 Requirements on Site

All system parts are accessible from front or top of UPS. Cable entries are accessible from
bottom. A 1m free space on all sides should be allowed during installation. Once the system is
installed it may be placed close to walls as long as free space is allowed for system doors to open.
(Per applicable national and/or local codes.)

For ventilation and service purposes allow for free space of minimum 1m above the unit or per
national and/or local codes and in front of UPS. Never install systems in direct sunlight.

NOTICE!

For reliability reasons do not stand on the UPS. keep the UPS cabinet surface free of any objects.

3.1.1 Cabinet Dimensions

UPS Height [mm] Width [mm] Depth [mm]

320kW 1800 1600 800

480 1800 1900 800

Cabinet

1900 mm wide

1600 mm wide

1800 mm

480kW

1800 mm

APC Isolation

Transformer Module

320-480kW

990-4053

Installation Guide APC Silcon 480kW 400V UPS 7

Installation

3.2 Footprint

3.2.1 1900mm Cabinet for 480kW UPS

Rear

Com. cable entry

Front

3.2.2 1600mm Cabinet for 480kW Isolation Transformer

Rear

Power cable entry

Power cable entry

Front

990-4053

8 Installation Guide APC Silcon 480kW 400V UPS

4.0 External Connection

4.1 Connecting the UPS

Right side view

Relay board
Please refer

to “Relay Board” section

External Connection

Battery

Front view

System Integration
Interface

Communication
Interface

Parallel Controller

NOTICE!

Check correct phase rotation of mains input voltage!!
Max. input/output cables: 3//300 mm
If there is no neutral input Dzn0 or Dyn11 input isolation transformer is required.

2

.

CAUTION!

This UPS unit is an EN 50091-2 product and may cause radio interference in a domestic
environment. Take preventive measures in necessary.

990-4053

Installation Guide APC Silcon 480kW 400V UPS 9

External Connection

CAUTION!

At a switch mode load of 100% the neutral must be rated for 200% output phase current.

UPS External

Input

Fuses* FM

[A]

380-415V

480kW 1000 3//185 185 800 3//150

* DIN gL types

NOTICE!

All cable dimensions are recommended sizes only.
Refer to local legal regulations.

UPS External Alarm

Cable max.

[mm2]

480kW 2 25 800 3//150

PVC cables insulated to withstand ambient temperature of max. 30oC
** Must be rated as external PE cable if mains system is not supplying PE

External

Input Cable

[mm2]

380-415V

External System

Earth Cable

External PE

Cable

[mm2]

[mm2]**

Maximum

External

Output
Fuses*

[A]

External Battery

Breaker

[A]

Output Cable

External Battery

Cable [mm2]

External

[mm2]

NOTICE!

Install gland plate in bottom of unit.

990-4053

10 Installation Guide APC Silcon 480kW 400V UPS

4.2 System Integration Interface

External Connection

NOTICE!

Consistent use of designations (Q001, Q002, Q003, H002, H003) in diagrams simplifies
information exchange.

System Integration Interface (SII) is the control link between UPS and system main switches
as shown in above diagram. The purpose of the SII is to ensure correct operation of switches
without losing system output power.

Auxiliary contacts on the main switches transmit the SII board inputs. Lamps on Service
Bypass Panel and Battery Breaker Box/Battery Cabinet indicate “green light” for operation of
output switches.

SII board also integrates input facilities for emergency shut-down and temperature
compensation of charge voltage for external battery (use with battery monitor). “Battery
operation” and “Common fault” are two main SII board status relay signals.

990-4053

Installation Guide APC Silcon 480kW 400V UPS 11

External Connection

4.2.1 Connections

Blue
Brown

990-4053

12 Installation Guide APC Silcon 480kW 400V UPS

External Connection

Terminal Blocks: X003/X004 (Anxiliary Contacts)

When switching Q001, Q002, Q010, Battery Breaker 1 or Battery Breaker 2 from “ON or 1” to
“OFF or 0”, the anxiliary contact has to be open BEFORE the corresponding main contacts are
opened. When switching Q001, Q002, Q010, Battery Breaker 1 or Battery Breaker 2 the
opposite way from “OFF or 0” to “ON or 1”, the anxiliary contact has to close with a maximum
delay of 0.5 seconds from the time the corresponding main contacts are closed.

• This type of auxillary contact is called a “late make” contact. (This also means that it will

“break early” when activated in opposite direction.)

• This auxillary contact is also called “NORMALLY OPEN” (NO), because the auxillary

contact will be open when the main contacts are open.

• Please note that the above term “NORMALLY” has nothing to do with NORMAL UPS

OPERATION MODE.

When switching Q003 from “OFF or 0” to “ON or 1”, the anxiliary contact has to open BEFORE
the corresponding main contacts are closed. When switching Q003 the opposite way from “ON
or 1” to “OFF or 0”, the auxillary contact has to close with a maximum delay of 0.5 seconds from
the time when the corresponding main contacts are opened.

• This type of anxiliary contact is called an “early break” contact. (This also means that it will

“make late” when activated in the opposite direction.)

• The auxiliary contact is also called “NORMALLY CLOSED” (NC), because the auxiliary

contact will be closed when the main contacts are open.

• Please note that the above term “NORMALLY” has nothing to do with NORMAL UPS

OPERATION.

X005 (Output Relays)

Battery operation signals are received with a 30-second delay. This function is inactive during
battery test. Common fault relay facility is programmable (standard factory setting: 10 sec.)
See APC Silcon User Guide for details.
Maximum nominal voltage on contact circuits is 277VAC. If two different phases are involved,
maximum phase to neutral voltage should be below 160VAC. Please note that phase L1 is
already present on the System Integration Interface board, supplied from the Service Bypass
Panel. Therefore, if a phase is needed for alarm or signal purposes, Phase L1 should be used.

4.3 Parallel Board

CAUTION!

Control cables must be separated from AC and DC power cables.

Parallel Board

990-4053

Installation Guide APC Silcon 480kW 400V UPS 13

External Connection

The built-in parallel board connects two or more UPS systems in parallel, either to obtain
increased system reliability or to obtain higher output power. The parallel board also ensures
correct load-sharing between paralled systems.

NOTICE!

For reliability reasons, APC recommends separate battery packs in redundant/parallel
conigurations.

To prepare the UPS for parallel/redundant mode, disconnect all sources of AC and DC power
supply to the UPS and connect the ribbon cable from the parallel board to the main controller
board (the ribbon cable is delivered with the UPS).

CAUTION!

DO NOT connect ribbon cable between controller and parallel card in single configurations.
Ribbon cable is for parallel operation only.

Complete the parallel system set-up by connecting the external control cables (see below).
Follow the instructions in the “Programming Parameters for Advanced Parallel” section of this
guide to execute necessary re-programming.

990-4053

14 Installation Guide APC Silcon 480kW 400V UPS

External Connection

Parallel Board

X021:15-pin SUB-D female

X020:15-pin SUB-D female

External multicore cable with 14 wires + shield

to other parallel units

UPS 1

External Control Cables

External multicore cable is equipped with 15-pin SUB-D plug at either end. Connect pin 1 to
pin 1, and pin 2 to pin 2 etc. up to pin 15 - with the exception of pin 8, which is not to be
connected.
Shield is connected to plug cover at both ends.
Terminals X020 and X021 for control cables located on parallel board. Connect X020 in UPS1
to X021 in UPS2, and connect X020 in UPS2 to X021 in UPS3 etc. Connect X020 in last UPS
to X021 in UPS1.

Cable is delivered with the UPS.

Power Cables

To optimize load-sharing in parallel operation, external power circuits must be “symmetrical”:
Power input and output cables to have same length and identical cross-sections.

UPS 2

UPS 3

990-4053

Installation Guide APC Silcon 480kW 400V UPS 15

External Connection

4.4 Relay Board

990-4053

1

2

3

Relays

All relays are “fail safe”: In alarm modes, relay coil will be de-energized.

Maximum load: 8.0A – 250VAC

0.3A – 60VDC

Minimum load: 0.05A – 6VAC

0.05A – 6VDC

16 Installation Guide APC Silcon 480kW 400V UPS

External Connection

4.4.1 Relay Board/Relay Functions

NOTICE

If alarm mode “Communication to controller lost” is active, ALL relays will indicate failure

Relay

Number

1 ## (X002) Mains outside limits Mains voltage RMS outside limits

2 ## (X003) Bypass outside limits Bypass voltage RMS outside limits

3 ## (X004) Output outside limits Output voltage RMS value outside limits

4 (X005) System overload Output load exceeding 100%

5 (X006) Fan fault Blocked or faulty fan

6 (X007) High Equipment

7 (X008) MCCB battery off Battery MCCB/Fuse not closed or released

8 (X009) Normal operation UPS running in normal operation mode(status)

9 ## (X010) Battery operation UPS running in battery operation mode(status)

10 ## (X011) Bypass operation UPS running in bypass operation mode(status)

11 ## (X012) Stand-by operation UPS in stand-by mode

12 (X013) Service bypass

13 ## (X014) Boost charge

14 (X015) Battery voltage

15 (X016) Battery condition

16 ## (X017) Common fault All alarms as mentioned above

Message Alarm-trigging Events

Mains wave form (fast detector) outside limits

Mains frequency outside limits

Bypass wave form (fast detector) outside limits

Bypass frequency outside limits

Output wave form (fast detector) outside limits

Output frequency outside limits

Delta inverter current limiter active

Main inverter current limiter active

Static switch temperature too high

Temperature or

Inverter Fuse Blown

operation

operation

outside limits

fault

Main inverter failure (temperature too high or fuse blown)

Delta inverter temperature too high

Magnetic temperature too high

Isolation transformer (option) temperature too high

Battery temperature too high

(Hot stand-by - parallel systems only)

Service bypass switch active

UPS boost-charging on battery

DC voltage too high (shut down)

DC voltage below warning level
DC voltage too low (shut down)

ABM has detected weak battery condition

ABM has detected defect battery

(ABM = Advanced Battery Monitor)

(except relays 8+9+10+11)
Internal power supply fault

System locked in operation mode

Internal memory fault

Internal communication fault

990-4053

Installation Guide APC Silcon 480kW 400V UPS 17

External Connection

## Delay programmable in configuration stack : “Common fault delay”. Settings 0,10,20,30
seconds.

See section 5.2: System configuration

NOTICE!

Alarm Trigging Events 1-2-3-9-10-11-13 activates the corresponding alarm relay after the delay.

Alarm Trigging Events 4-5-6-7-8-12-14-15 activates the corresponding alarm relay momentarily.

Common fault relay 16 is activated at the same time as relay 1-2-3-4-5-6-7-12-13-14-15, or in
any of the below situations.:

• Internal power supply fault

• System locked in operation mode

• Internal memory fault

• Internal communication fault

990-4053

18 Installation Guide APC Silcon 480kW 400V UPS

External Connection

4.5 Communication Interface Board

The 3-port ComInterface is used to establish an interaction between UPS and e.g. a computer
system. Main purpose: To ensure a controlled computer shut-down in case of a mains supply
failure.

4.5.1 Connections

.

.

990-4053

Installation Guide APC Silcon 480kW 400V UPS 19

External Connection

4.6 Connecting of APC Silcon Tripel Chassis

The enclosed Triple Chassis must be connected to the serial port on the Communication
Interface Board, and to the 24V supply (cables included). Terminal locations shown below.

480

Front view of UPS Cabinet (doors open)

APC Silcon Triple Chassis

Serial ports

X50

X50 is a 24V supply for Triple Chassis.

Only to be used for this purpose.

Not suitable for telephone equipment.

Triple Chassis must be connected to both

X50 and a serial port.

For more information please refer to the following section.

990-4053

20 Installation Guide APC Silcon 480kW 400V UPS

External Connection

4.7 APC Silcon Triple Chassis

The APC Silcon Triple Chassis (AP9604S) is an American Power Conversion (APC) external
management peripheral that allows you to use monitoring and control management
peripherals with your APC Silcon series UPS. The retrofit model (AP9604SR) is for use with
Silcon series UPSs that are not equipped with a 24 VDC power port.

4.7.1 Safety Warnings

Use the APC Silcon Triple Chassis only in conjunction with an APC Silcon UPS.

Do not connect a computer to any APC Silcon Triple Chassis port using a straight-through
extension cable. Use the communications cable provided with the APC Silcon Triple Chassis.

Connections using a cable made by any other manufacturer may cause damage or improper
operation of the APC Silcon Triple Chassis, the UPS, or the computer.

4.7.2 Product Description

➊

➍

➋

➌

Monitoring port

1

To UPS port

2

4.7.2.1 Monitoring Port

Status LED

3

Optional Power port

4

The Monitoring port has two functions:

• Connecting to a terminal for configuration of the chassis. For direct connection to the
Monitoring port, you must use the Monitoring cable supplied with the chassis (APC
P/N 940-0024C).

• Connecting to other APC external management peripherals in a daisy chain.

4.7.2.2 To UPS Port

The “To UPS” port connects the chassis to the UPS, using the Silcon UPS cable (APC P/N 940-

0071). The cable connector plugs into a communications port on an APC Silcon UPS.

990-4053

Installation Guide APC Silcon 480kW 400V UPS 21

External Connection

4.7.2.3 LEDs

The APC Silcon Triple Chassis status LED provides important information concerning
operation of the chassis. Refer to the table below for a description of the conditions indicated
by the LED.

IF the LED is… THEN the Silcon Triple Chassis…

off is not receiving power.

flashing quickly
(5 times per second)

has not been configured. See the APC Silcon Management Quick
Start Guide provided with your chassis or the Web/SNMP
Management Card Installation Guide on the CD for more
information.

flashing slowly
(1 time per second)

on is operating normally.

4.7.2.4 Optional Power Input

With the Optional Power input, you can power the APC Silcon Triple Chassis from an external
source, using a 24 VDC power adapter. A universal adapter (AP9505i) or a standard adapter
(AP9505) can be purchased separately from APC.

4.7.3 Installing Management Peripherals

There are two basic types of APC management peripherals that work with the APC Silcon
Triple Chassis:

• Management peripheral cards, which fit into external management peripherals that
are equipped with a card slot.

• External management peripherals, which connect to the Monitoring (or Advanced)
port of other external management peripherals.

NOTICE!

The name “Monitoring” port varies from product to product, but its purpose is the same – to
replicate the UPS communications port.

is powered on but is not communicating with the UPS.

990-4053

22 Installation Guide APC Silcon 480kW 400V UPS

External Connection

4.7.3.1 Order of Management Peripheral Cards

Because UPS signals are passed between management peripherals, you must install
management peripheral cards in the correct order for them to work together properly. The card
slots are numbered 1 to 3, from left to right, as viewed from the rear of the chassis. The
following table lists the management peripheral cards, their priority, and proper position.

Management
Peripheral Card

Web/

SNMP Management

Card

Out-of-Band
Management Card
(Call-

UPS®II)

Interface Expander AP9607 Second lowest

Environmental
Monitoring Card
(Measure-

4.7.3.2 Installing Management Peripheral Cards

To install management peripherals, perform the following steps.

1) Make sure that the chassis is powered off.

2) Install management peripheral cards into the housings on the rear of the chassis. See the
instructions supplied with the cards and the table above.

3) If you are daisy-chaining other APC external management peripherals to the APC Silcon
Triple Chassis: Connect the UPS cable (supplied with the management peripheral) to the
Monitoring port of the chassis and to the “To UPS” port of the other management peripheral
(Share-UPS, MasterSwitch, etc.). See “Daisy-chaining the APC Silcon Triple Chassis”.

4) Power the APC Silcon Triple Chassis and all external management peripherals.

UPS

®

II)

P/N Priority Position

AP9606 Highest

AP9608 Second-highest

AP9612T
AP9612TH

Lowest

High-numbered slot

Low-numbered slot

NOTICE!

If your configuration requires additional power, connect a 24V AC/DC power adapter available
from APC (part number AP9505 or AP9505i) for all models of Triple Chassis.

4.7.3.3 Daisy-chaining the APC Silcon Triple Chassis

If you need more than the three card slots available with the APC Silcon Triple Chassis, or if
you want to use other external management peripherals, you can daisy-chain external
management peripherals together, provided that the total amperage of all installed
management peripherals — cards and external — does not exceed the supplied amperage. (See
“Determining Power Requirements:”).

NOTICE!

When daisy-chaining Triple Chassis units, you may need to use a power adapter.

990-4053

Installation Guide APC Silcon 480kW 400V UPS 23
