BroadBand

PowerShield®

User Manual

990-0375G 12/2006

Chapter 1 General Information

The PowerShield® provides a power source for broadband telephony and other DC applications.

Safety

This Safety Guide contains important instructions that should be followed during installation and maintenance of the APC equipment and batteries. It is intended for APC customers who setup, install, relocate, or maintain APC equipment.

Changes and modifications to this unit not expressly approved by APC could void the warranty.

Failure to observe these warnings may result in serious injury, death or damage to the equipment.

Electrical Warnings

Do not work alone under hazardous conditions. Servicing this equipment may require working with protective covers removed

and utility power connected. Use extreme caution during these procedures. Check that the power cord(s), plug(s), and sockets are in good condition. Replacement of fuses or other parts must be with identical types and ratings.

Substitution of nonidentical parts may cause safety and fire hazards.

Battery Warnings

Danger of explosion if battery is incorrectly connected or replaced. Use only APC replacement batteries.

Specifications

Model Number

CP15U48

CP24U12

CP40U48

Input Output Max

Signal Voltage

100-240V 50-60Hz 1.0A

100-240V 50-60Hz 1.5A

48V 15W

12V 24W

48V 40W

30V 5mA

Max Signal Current

Battery type Same for All Models

12V 7.2AHr Spill-Proof,

Maintenance-Free, Sealed Lead Acid

Environmental Specifications

Operating Temperature Operating Humidity Max Operating Elevation Max Storage Elevation Storage Temperature

32º F to 113º F (0º C to 45º C) 0 to 95% noncondensing within enclosure 10,000 ft (3,000 m) 50,000 ft (15,000 m)

-5º F to 113º F (-15º C to 45º C)

Physical Specifications

Characteristic Specification Height x Width x Depth UPS

UPS carton Weight UPS

UPS with package materials

7.5 x 9.5 x 3 in (19 x 24 x 7.6 cm)

13.5 x 13.5 x 4.5 in (34 x 34 x 11 cm)

7.5 lbs (3 kg) 9 lbs (4 kg)

Unpacking

Inspect the unit upon receipt. Notify the shipping carrier or product supplier if there is damage. The packaging is recyclable; save it for reuse or dispose of it properly. Check the package contents. The package contains the enclosure, the battery (to be installed), one

power cord, one seven-pin output connector, and product documentation.
