Chapter 3
Award BIOS
This chapter tellshowtoconfigurethe system parameters. You may update your
BIOS via AWARD Flash Utility.
Important: Because the BIOS code is the most
often changed part of the mainboard design, the
BIOS information contained in this chapter
(especiallythe Chipset Setup parameters) may be a
little different compared to the actual BIOS that
came with your mainboard.
3.1 Entering the Award BIOS Setup Menu
The BIOS setup utility is a segment of codes/routines residing in the BIOS Flash
ROM. This routine allows you to configure the system parameters and save the
configuration into the 128 byte CMOS area, (normally in the RTC chip or directly
in the main chipset). To enter the BIOS Setup, press during POST
(Power-On Self Test). The BIOS Setup Main Menu appears as follows.
3-1
AWARD BIOS
ROM PCI/ISA BIOS (XXXXXXXX)
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
STANDARD CMOS SETUP
BIOS FEATURES SETUP
CHIPSET FEATURES SETUP
POWER MANAGEMENT SETUP
PNP/PCI CONFIGURATION SETUP
LOAD SETUP DEFAULTS
LOAD TURBO DEFAULTS
ESC : Quit á â à ß : Select Item
F10 : Save & Exit Setup (Shift) F2 : Change Color
Description of each function
INTEGRATED PERIPHRALS
PASSWORD SETTING
IDE HDD AUTO DETECTION
SAVE & EXIT SETUP
EXIT WITHOUT SAVING
Tip: Choose "Load Setup Defaults" for
recommended optimal performance. Choose
"Load Turbo Defaults" for best performance
with light system loading. Refer to section 3.7.
The section at the bottom of the screen tells how to control the screen. Use the
arrowkeys to move between items, to color scheme of the display,
to exit, and to save the changes before exit. Another section at the bottom of
the screen displays a brief description of the highlighted item.
After selecting an item, press to select or enter a submenu.
3.2 Standard CMOS Setup
The "Standard CMOS Setup" sets the basic system parameters such as the
date, time, and the hard disk type. Use the arrow keys to highlight an item and
or to select the value for each item.
3-2
AWARD BIOS
ROM PCI/ISA BIOS (XXXXXXXX)
STANDARD CMOS SETUP
AWARD SOFTWARE, INC.
Date (mm:dd:yy) : Wed. Mar 6 1996
Time (hh:mm:ss) : 00:00:00
HARD DISK TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTORS MODE
Primary Master : Auto 0 0 0 0 0 0 AUTO
Primary Slave : Auto 0 0 0 0 0 0 AUTO
Secondary Master: Auto 0 0 0 0 0 0 AUTO
Secondary Slave : Auto 0 0 0 0 0 0 AUTO
Drive A : 1.44M, 3.5 in
Drive B : None
Video : EGA/VGA
Halt On : All Errors
ESC : Quit á â à ß : Select Item
F10 : Save & Exit Setup (Shift) F2 : Change Color
Standard CMOS à Date
To set the date, highlight the Date parameter. Press or to set the
current date. The date format is month, date, and year.
Base Memory : 640 K
Extended Memory: 15360 K
Other Memory : 384 K
Total Memory : 16384 K
Standard CMOS à Time
To set the time, highlight the Time parameter. Press or to set the
current time in hour, minute, and second format. The time is based on the 24
hour military clock.
3-3
AWARD BIOS
Standard CMOS à Primary Master à Type
Standard CMOS à Primary Slave à Type
Standard CMOS à Secondary Master à Type
Standard CMOS à Secondary Slave à Type
Type
Auto
User
None
1
2
...
45
This item lets you select the IDE hard disk parameters that
your system supports. These parameters are Size,
Number of Cylinder, Number of Head, Start Cylinder for
Pre-compensation, Cylinder number of Head Landing
Zone and Number of Sector per Track. The default setting
is Auto, which enables BIOS to automatically detect the
parameters of installed HDD at POST (Power-On Self
Test). If you prefer to enter HDD parameters manually,
select User. Select None if no HDD is connected to the
system.
The IDE CDROM is always automatically detected.
Tip: For an IDE hard disk, we recommend that
you use the "IDE HDD Auto Detection" to enter
the drive specifications automatically. See the
section "IDE HDD Auto Detection".
Standard CMOS à Primary Master à Mode
Standard CMOS à Primary Slave à Mode
Standard CMOS à Secondary Master à Mode
Standard CMOS à Secondary Slave à Mode
Mode
Auto
Normal
LBA
Large
The enhanced IDE feature allows the system to use a
hard disk with a capacity of more than 528MB. This is
made possible through the Logical Block Address (LBA)
mode translation. The LBA is now considered as a
standard feature of current IDE hard disk on the market
because of its capability to support capacity larger than
528MB. Note that if HDD is formatted with LBA On, it will
not be able to boot with LBA Off.
3-4
Standard CMOS à Drive A
Standard CMOS à Drive B
AWARD BIOS
Drive A
None
360KB 5.25"
1.2MB 5.25"
720KB 3.5"
1.44MB 3.5"
2.88MB 3.5"
These items select floppy drive type. The available settings
and types supported by the mainboard are listed on the left.
Standard CMOS à Video
Video
EGA/VGA
CGA40
CGA80
Mono
This item specifies the type of video card in use. The
default setting is VGA/EGA. Since current PCs use VGA
only, this function is almost useless and may be
disregarded in the future.
Standard CMOS à Halt On
Halt On
No Errors
All Errors
All, But Keyboard
All, But Diskette
All, But Disk/Key
This parameter enables you to control the system stops in
case of Power-On Self Test (POST) error.
3-5
AWARD BIOS
3.3 BIOS Features Setup
This screen appears when you select the option "BIOS Features Setup" from the
main menu.
ROM PCI/ISA BIOS (XXXXXXXX)
BIOS FEATURES SETUP
AWARD SOFTWARE, INC.
Virus Warning : Disabled
External Cache : Enabled
Quick Power On Self Test : Enabled
Boot Sequence : A,C,SCSI
Swap Floppy Drive : Disabled
Boot Up Floppy Seek : Disabled
Boot Up NumLock Status : ON
Boot Up System Speed : High
Typematic Rate Setting : Disabled
Typematic Rate (Chars/Sec) : 6
Typematic Delay (Msec) : 250
Security Option : Setup
PCI/VGA Palette Snoop : Disabled
OS Select for DRAM > 64MB : Non-OS/2
BIOS Features à Virus Warning
Virus Warning
Enabled
Disabled
Type "Y" to accept write, or "N" to abort write
Set this parameter to Enabled to activate the warning message.
This feature protects the boot sector and partition table of your
hard disk from virus intrusion.
Any attempt during boot up to write to the boot sector of the hard
disk drive stops the system and the following warning message
appears on the screen. Run an anti-virus program to locate the
problem.
! WARNING !
Disk Boot Sector is to be modified
Award Software, Inc.
Video BIOS Shadow : Enabled
C8000-CBFFF Shadow : Disabled
CC000-CFFFF Shadow : Disabled
D0000-D3FFF Shadow : Disabled
D4000-D7FFF Shadow : Disabled
D8000-DBFFF Shadow : Disabled
DC000-DFFFF Shadow : Disabled
ESC: Quit áâàß : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2 : Color
F6 : Load Setup Defaults
F7 : Load Turbo Defaults
3-6
BIOS Features à External Cache
AWARD BIOS
External Cache
Enabled
Disabled
Enabling this parameter activates the secondary cache
(currently, PBSRAM cache). Disabling the parameter slows
down the system. Therefore, we recommend that you leave
it enabled unless you are troubleshooting a problem.
BIOS Features à Power-On Self-Test
Quick Power-on
Self-test
Enable
Disabled
This parameter speeds up POST by skipping some items
that are normally checked.
BIOS Features à Boot Sequence
Boot Sequence
A,C,SCSI
C,A,SCSI
C,CDROM,A
CDROM,C,A
D,A,SCSI
E,A,SCSI
F,A,SCSI
SCSI,A,C
SCSI,C,A
C only
This parameter allows you to specify the system boot up
search sequence. The hard disk ID are listed below:
C: Primary master
D: Primary slave
E: Secondary master
F: Secondary slave
BIOS Features à Swap Floppy Drive
Swap Floppy Drive
Enabled
Disabled
This item allows you to swap floppy drives. For example, if
you have two floppy drives (A and B), you can assign the first
drive as drive B and the second drive as drive A or viceversa.
BIOS Features à Boot-up Floppy Seek
3-7
AWARD BIOS
Boot-up Floppy
Seek
Enabled
Disabled
When enabled, the BIOS issues the seek command to the
floppy drive during POST to move floppy drive head
forward and backward.
BIOS Features à Boot-up NumLock Status
Boot-up NumLock
Status
On
Off
Setting this parameter to On enables the numeric function of
the numeric keypad. Set this parameter to Off to disregard
the function. Disabling the numeric function allows you to
use the numeric keypad for cursor control.
BIOS Features à Boot-up System Speed
Boot-up System
Speed
High
Low
Select High or Low system speed after boot.
BIOS Features à Typematic Rate Setting
Typematic Rate
Setting
Enabled
Disabled
Set this parameter to Enable/Disable the keyboard repeat
function. When enabled, continuallyholding down a key on
the keyboard will generate repeatedly keystrokes.
BIOS Features à Typematic Rate
Typematic Rate
6
8
10
12
15
20
24
30
3-8
This item allows you to control the speed of repeated
keystrokes. The default is 30 characters/sec.
BIOS Features à Typematic Delay
AWARD BIOS
Typematic Delay
250
500
750
1000
This parameter allows you to control the delay time
between the first and the second keystroke (where the
repeated keystrokes begin). The typematic delay settings
are 250, 500, 750, and 1000 msec.
BIOS Features à Security Option
Security Option
Setup
System
The System option limits access to both the System boot
and BIOS setup. A prompt asking you to enter your
password appears on the screen every time you boot the
system.
The Setup option limits access only to BIOS setup.
To disable the security option, select Password Setting from
the main menu, don't type anything and just press <Enter>.
BIOS Features à PCI/VGA Palette Snoop
PCI/VGA Palette
Snoop
Enabled
Disabled
Enabling this iteminforms the PCI VGA cardto keep silent
(and to prevent conflict) when palette register is updated
(i.e., accepts data without responding any communication
signals). This is useful only when two display cards use
the same palette address and plugged in the PCI bus at
the same time (such as MPEQ or Video capture). In such
case, PCI VGA is silent while MPEQ/Video capture is set
to function normally.
BIOS Features à OS Select for DRAM > 64MB
OS Select for
DRAM > 64MB
OS/2
Non-OS/2
Set to OS/2 if your system is utilizing an OS/2 operating
system and has a memory size of more than 64 MB.
3-9
AWARD BIOS
BIOS Features à Video BIOS Shadow
Video BIOS Shadow
Enabled
Disabled
VGA BIOS Shadowing means to copy video display card
BIOS into the DRAM area. This enhances system
performance because DRAM access time is faster than
ROM.
BIOS Features à C800-CBFF Shadow
BIOS Features à CC00-CFFF Shadow
BIOS Features à D000-D3FF Shadow
BIOS Features à D400-D7FF Shadow
BIOS Features à D800-DBFF Shadow
BIOS Features à DC00-DFFF Shadow
C8000-CBFFF
Shadow
Enabled
Disabled
These six items are for shadowing ROM code on other
expansion cards. Before you set these parameters, you
need to know the specific addresses of that ROM code. If
you do not know this information, enable all the ROM
shadow settings.
Note: The F000 and E000 segments are always
shadowed because BIOS code occupies these
areas.
3-10
AWARD BIOS
3.4 Chipset Features Setup
The "Chipset Features Setup" includes settings for the chipset dependent
features. These features are related to system performance.
ROM PCI/ISA BIOS (XXXXXXXX)
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
Auto Configuration : Enabled
DRAM Timing : 60 ns
DRAM Leadoff Timing : 10/6/3/3
DRAM Read Burst (EDO/FP) : x222/x333
DRAM Write Burst Timing : x222
Fast EDO Lead Off : Disabled
Refresh RAS# Assertion : 5 Clks
DRAM Page Idle Timer : 2 Clks
DRAM Enhanced Paging : Enabled
Fast MA to RAS# Delay : 2 Clks
SDRAM(CAS Lat/RAS-to-CAS) : 3/3
SDRAM Speculative Read : Disabled
System BIOS Cacheable : Enabled
Video BIOS Cacheable : Enabled
8 Bit I/O Recovery Time : 4
16 Bit I/O Recovery Time : 1
Memory Hole At 15M-16M : Disabled
PCI Passive Release : Disabled
PCI Delayed Transaction : Disabled
Mem. Drive Str.(MA/RAS) : 16mA/16mA
ESC: Quit áâàß : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2 : Color
F6 : Load Setup Defaults
F7 : Load Turbo Defaults
Caution: Make sure you fully understand the
items contained in this menu before you try to
change anything. You may change the
parameter settings to improve system
performance . However, it may cause system
unstable if the setting are not correct for your
system configuration.
3-11
AWARD BIOS
3-12
Chipset Features à Auto Configuration
AWARD BIOS
Auto Configuration
Enabled
Disabled
When Enabled, the DRAM and cache related timing
are set to pre-defined value according to CPU type and
clock. Select Disable if you want to specify your own
DRAM timing.
Chipset Features à DRAM Timing
DRAM Timing
60 ns
70 ns
There to sets of DRAM timing parameters can be
automatically set by BIOS, 60ns and 70ns.
Warning: The default memory timing setting is
60ns to get the optimal performance. Because
the specification limitation of INTEL TX chipset ,
70ns SIMM can only be used with CPU external
clock 60MHz. To use 70ns SIMM with 66MHz
CPU external clock may result in unstable
system behavior.
Chipset Features à DRAM Leadoff Timing
DRAM Leadoff
Timing
11/7/3/4
10/6/3/3
11/7/4/4
10/6/4/3
The Leadoff means the timing of first memory cycle in
the burst read or write. Actually, this item controls only
page miss read/write leadoff timing and the clocks of
RAS precharge and RAS to CAS delay. The four digital
represent Read Leadoff/ Write Leadoff/ RAS
Precharge/ RAS to CAS delay. For example, default is
10/6/3/3, which means you have 10-x-x-x DRAM page
miss read and 6-x-x-x DRAM write, with 3 clocks RAS
precharge and 3 clocks RAS to CAS delay.
Chipset Features à DRAM Read Burst (EDO/FP)
3-13
AWARD BIOS
DRAM Read Burst
(EDO/FP)
x444/x444
x333/x444
x222/x333
Read Burst means to read four continuous memory
cycles on four predefined addresses from the DRAM.
The default value is x222/x333 for 60ns EDO or FPM
(Fast Page Mode) DRAM. Which means the 2nd,3rd
and 4th memory cycles are 2 CPU clocks for EDO and 3
clocks for FPM. The value of x is the timing of first
memory cycle and depends on the "DRAM Leadoff
Timing" setting.
Chipset Features à DRAM Write Burst Timing
DRAM Write Burst
Timing
x444
x333
x222
Write Burst means to write four continuous memory
cycles on four predefined addresses to the DRAM. This
item sets the DRAM write timing of the 2nd,3rd and 4th
memory cycles. There is no difference of EDO and
FPM DRAM on the write burst timing. The value of x
depends on the "DRAM Leadoff Timing" setting.
Chipset Features à Fast EDO Lead Off
Fast EDO Lead Off
Enabled
Disabled
This item enables fast EDO read timing, results 1 clock
pull-in for read leadoff latency of EDO read cycles. It
must be Disabled, if any FPM DRAM is installed.
Chipset Features à Refresh RAS# Assertion
Refresh RAS#
Assertion
5 Clks
4 Clks
This item controls the number of clocks RAS is asserted
for refresh cycle.
Chipset Features à DRAM Page Idle Timer
3-14
AWARD BIOS
DRAM Page Idle
Timer
2 Clks
4 Clks
6 Clks
8 Clks
This item determines the amount of time in CPU clocks
that DRAM page will be close after CPU becomes idle.
Chipset Features à DRAM Enhance Paging
DRAM Enhance
Paging
Enabled
Disabled
When Enabled, TX chipset will keep DRAM page open
as long as possible according to enhanced method.
Chipset Features à SDRAM(CAS Lat/RAS-to-CAS)
SDRAM(CAS
Lat/RAS-to-CAS)
2/2
3/3
These are timing of SDRAM CAS Latency and RAS to
CAS Delay, calculated by clocks. They are important
parameters affects SDRAM performance, default is 2
clocks. If your SDRAM has unstable problem, change
2/2 to 3/3.
Chipset Features à SDRAM Speculative Read
SDRAM Speculative
Read
Enabled
Disabled
Enable this item reduce one clock of SDRAM read
leadoff timing by presenting the SDRAM read request
before the controller chip decodes the final memory
target. This Item must be Disabled if more than one
DIMM is installed in the system.
Chipset Features à System BIOS Cacheable
System BIOS
Cacheable
Enabled
Disabled
Enabling this item allows you to cache the system BIOS
to further enhance system performance.
3-15
AWARD BIOS
Chipset Features à Video BIOS Cacheable
Video BIOS
Cacheable
Allows the video BIOS to be cached to allow faster
video performance.
Enabled
Disabled
Chipset Features à 8 Bit I/O Recovery Time
8 Bit I/O Recovery
Time
1
2
3
4
5
6
7
8
NA
For some old I/O chips, after the execution of an I/O
command, the device requires a certain amount of time
(recovery time) before the execution of the next I/O
command. Because of new generation CPU and
mainboard chipset, the assertion of I/O command is
faster, and sometimes shorter than specified I/O
recovery time of old I/O devices. This item lets you
specify the delay of 8-bit I/O command by count of ISA
bus clock. If you find any unstable 8-bit I/O card, you
may try to extend the I/O recovery time via this item.
The BIOS default value is 4 ISA clock. If set to NA, the
chipset will insert 3.5 system clocks.
Chipset Features à 16 Bit I/O Recovery Time
16 Bit I/O Recovery
Time
1
2
3
4
NA
The same as 16-bit I/O recovery time. This item lets
you specify the recovery time for the execution of 16-bit
I/O commands by count of ISA bus clock. If you find any
of the installed 16-bit I/O cards unstable, try extending
the I/O recovery time via this item. The BIOS default
value is 1 ISA clocks. If set to NA, the chipset will
automatically insert 3.5 system clocks.
Chipset Features à Memory Hole At 15M-16M
Memory Hole At
15M-16M
Enabled
Disabled
3-16
This option lets you reserve system memory area for
special ISA cards. The chipset accesses code/data of
these areas from the ISA bus directly. Normally, these
areas are reserved for memory mapped I/O card.
Chipset Features à PCI Passive Release
AWARD BIOS
PCI Passive Release
Enabled
Disabled
This item lets you control the Passive Release function
of the PIIX4 chipset (Intel PCI to ISA bridge). This
function is used to meet latency of ISA bus master. Try
to enable or disable it, if you have ISA card compatibility
problem.
Chipset Features à PCI Delayed Transaction
PCI Delayed
Transaction
Enabled
Disabled
This item lets you control the Delayed Transaction
function of the PIIX4 chipset (Intel PCI to ISA bridge).
This function is used to meet latency of PCI cycles to or
from ISA bus. Try to enable or disable it, if you have ISA
card compatibility problem.
Chipset Features à Mem. Drive Str. (MA/RAS)
Mem. Drive Str.
(MA/RAS)
10mA/10mA
10mA/16mA
16mA/10mA
16mA/16mA
This option controls the driving strength of memory
address and control signals. It is recommended to use
less driving current for light memory loading, to prevent
undershoot or overshoot.
3-17
AWARD BIOS
3.5 Power Management Setup
The Power Management Setup screen enables you to control the mainboard’s
green features. See the following screen.
ROM PCI/ISA BIOS (XXXXXXXX)
POWER MANAGEMENT SETUP
AWARD SOFTWARE, INC.
Power Management : Disabled
PM Control by APM : Yes
Video Off Method : V/H SYNC + Blank
Video Off After : Suspend
Doze Mode : Disabled
Standby Mode : Disabled
Suspend Mode : Disabled
HDD Power Down : Disabled
Modem WakeUp : Disabled
Suspend Mode Option : Power On Suspend
Throttle Duty Cycle : 62.5%
VGA Active Monitor : Disabled
Power Bottom Override : Disabled
RTC WakeUp timer : Disabled
WakeUp Date (of Month): 0
WakeUp Time (hh:mm:ss): 07:00:00
** Break event From Suspend **
IRQ 8 Clock Event : Disabled
** Reload Global Timer Events **
IRQ [3-7,9-15],NMI : Enabled
Primary IDE 0 : Disabled
Primary IDE 1 : Disabled
Secondary IDE 0 : Disabled
Secondary IDE 1 : Disabled
Floppy Disk : Disabled
Serial Port : Disabled
Parallel Port : Disabled
ESC: Quit áâàß : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2 : Color
F6 : Load Setup Defaults
F7 : Load Turbo Defaults
Power Management à Power Management
Power Management
Max Saving
Mix Saving
User Defined
Disabled
This function allows you to set the default parameters of
power-saving modes. Set to Disable to turn off power
management function. Set to User Defined to choose
your own parameters.
Mode Doze Standby Suspend HDD Power Down
Min Saving 1 hour 1 hour 1 hour 15 min
Max Saving 1 min 1 min 1 min 1 min
3-18
Power Management à PM Controlled by APM
AWARD BIOS
PM Controlled by
APM
Yes
No
If "Max Saving" is selected, you can turn on this item,
transfer power management control to APM (Advanced
Power Management) and enhance power saving
function. For example, stop CPU internal clock.
Power Management à Video Off Method
Video Off Method
Blank Screen
V/H SYNC+Blank
DPMS
This determines the way that monitor is off. Blank
Screen writes blanks to video buffer. V/H SYNC+Blank
allows BIOS to control VSYNC and HSYNC signals.
This function applies only for DPMS (Display Power
Management Standard) monitor. The DPMS mode
uses DPMS function provided by VGA card.
Power Management à Video Off After
Video Off After
N/A
Doze
Standby
Suspend
To turn off video monitor at which power down mode.
Power Management à Doze Mode
Doze Mode
Disabled
1 Min
2 Min
4 Min
8 Min
12 Min
20 Min
30 Min
40 Min
1 Hour
This item lets you set the period of time after which the
system enters into Doze mode. In this mode, the CPU
clock slows down. The ratio is specified in the "Throttle
Duty Cycle". Any activity detected returns the system to
full power. The system activity (or event) is detected by
monitoring the IRQ signals.
3-19
AWARD BIOS
Power Management à Standby Mode
Standby Mode
Disabled
1 Min
2 Min
4 Min
8 Min
12 Min
20 Min
30 Min
40 Min
1 Hour
This item lets you set the period of time after which the
system enters into Standby mode. In this mode, CPU
clock slows down, hard disk will be shut off and the
monitor power-saving feature activates. Any activity
detected returns the system to full power. The system
activity (or event) is detected by monitoring the IRQ
signals.
Power Management à Suspend Mode
Suspend Mode
Disabled
1 Min
2 Min
4 Min
8 Min
12 Min
20 Min
30 Min
40 Min
1 Hour
This item lets you set the period of time after which the
system enters into Suspend mode. The Suspend mode
can be Power On Suspend or Suspend to Hard Drive,
selected by "Suspend Mode Option".
Power Management à HDD Power Down
HDD Power Down
Disabled
1 Min
.....
15 Min
This option lets you specify the IDE HDD idle time
before the device enters the power down state. This
item is independent from the power states previously
described in this section (Standby and Suspend).
Power Management à Modem WakeUp
3-20
AWARD BIOS
Modem WakeUp
Disabled
Enabled
This mainboard implements AOpen special circuit
(patent applied) to detect modem ring signal and
wakeup from soft power off. The most possible
applications are automatic answering machine and fax
send/receive. It does not like traditional green PC
suspend mode, the system can be true power off,
(identified by the fan of your power supply is off). You
can use external box modem or AOpen MP32/F34I
internal modem card for modem ring-on, but MP32/F34I
is recommended, since MP32/F34I has special circuit to
cooperate with this mainboard and the modem power
and system power can be off together. For detail of how
to use modem ring-on, refer to section 3-17 "Modem
Wake Up".
Power Management à Suspend Mode Option
Suspend Mode Option
Power On Suspend
Suspennd to Hard Drive
You can select suspend mode by this item. Power On
Suspend is the traditional Green PC suspend mode,
the CPU clock is stop, all other devices are shut off. But
power must be kept On to detect activities from
modem, keyboard/mouse and returns the system to full
power. The system activities is detected by monitoring
the IRQ signals. Suspend to Hard Drive saves system
status, memory and screen image into hard disk, then
the power can be totally Off. Next time, when power is
turned On, the system goes back to your original work
within just few seconds. You need utility ZVHDD to
reserve disk space. Refer to section 3.16 "Suspend to
Hard Drive" for more information".
Power Management à Throttle Duty Cycle
3-21
AWARD BIOS
Throttle Duty Cycle
12.5 %
25.0 %
37.5 %
50.0 %
62.5 %
75.0 %
87.5 %
Clock Throttling means at the Doze/Standby state, the
CPU clock count in a given time (not the frequency) is
reduced to the ratio specified in this parameter.
Actually, the period per CPU clock is not changed. For
example, a 66MHz CPU clock remains the same 30ns
clock period when system goes into Doze/Suspend.
The chipset generates the STPCLK (stop clock) signal
periodically to prevent CPU for accepting clock from
clock generator. For full power on, the CPU can receive
66M count in one second. If the Slow Clock Ratio is set
to 50%, the CPU will only receive 33M clock count in
one second. This will effectively reduce CPU speed as
well as CPU power.
Power Management à VGA Active Monitor
VGA Activity Monitor
Enabled
Disabled
To enable or disable the detection of VGA activity for
power down state transition.
Power Management à Power Bottom Override
Power Bottom
Override
Disabled
Enabled
This is a specification of ACPI and supported by
hardware. When Enabled, the soft power switch on the
front panel can be used to control power On, Suspend
and Off. If the switch is pressed less than 4 sec during
power On, the system will go into Suspend mode. If the
switch is pressed longer than 4 sec, the system will be
turned Off. The default setting is Disabled, soft power
switch is only used to control On and Off, there is no
need to press 4 sec, and there is no Suspend.
Power Management à RTC WakeUp Timer
3-22
AWARD BIOS
RTC WakeUp Timer
Disabled
Wake Up
Power Off
The RTC WakeUp Timer can be programmed at a
specified date/time to wakeup the system. The
Date/Time is set by " WakeUp Date (of Month)" and
"WakeUp Time (hh:mm:ss)". For automatic power off,
you can select the idle timer in "Doze Mode" + "Standby
Mode" + "Suspend Mode" to power off after system is
detected without any activities.
Power Management à WakeUp Date (of Month)
Date (of Month)
Alarm
0
1
2
......
30
31
This item selects the date of month to on which to wake
up or power off the system. Set to 0 means everyday.
Power Management à Wake Up Time (hh:mm:ss)
Time (hh:mm:ss)
Alarm
07:00:00
.. : .. : ..
This item selects the time at which to wake up or power
off the system. The format is hour:minute:second, note
that hour is in 24 hours form.
Power Management à IRQ 8 Clock Event
IRQ 8 Clock Event
Enabled
Disabled
To enable or disable the detection of IRQ8 (RTC) event
for power down state transition. OS2 has periodically
IRQ8 (RTC) interruptions, If IRQ8 is not set to
Disabled, OS/2 may fail to go into
Doze/Standby/Suspend mode.
3-23
AWARD BIOS
Power Management à IRQ [3-7,9-15],NMI
IRQ [3-7,9-15],NMI
Enabled
Disabled
To enable or disable the detection of IRQ3-7, IRQ9-15
or NMI interrupt events for power down state transition.
Power Management à Primary IDE 0
Power Management à Primary IDE 1
Power Management à Secondary IDE 0
Power Management à Secondary IDE 1
Power Management à Floppy Disk
Power Management à Serial Port
Power Management à Parallel Port
Primary IDE 0
Enabled
Disabled
These items enable or disable the detection of IDE,
floppy, serial and parallel port activities for power down
state transition. Actually it detects the read/writeto/from
I/O or address port.
3-24
AWARD BIOS
3.6 PNP/PCI Configuration Setup
The PNP/PCI Configuration Setup allows you to configure the ISA and PCI
devices installed in your system. The following screen appears if you select the
option "PNP/PCI Configuration Setup" from the main menu.
ROM PCI/ISA BIOS (XXXXXXXX)
PNP/PCI CONFIGURATION SETUP
AWARD SOFTWARE, INC.
PnP OS Installed : No
Resources Controlled By : Manual
Reset Configuration Data : Disabled
IRQ 3 assigned to : PCI/ISA PnP
IRQ 4 assigned to : PCI/ISA PnP
IRQ 5 assigned to : PCI/ISA PnP
IRQ 7 assigned to : PCI/ISA PnP
IRQ 9 assigned to : PCI/ISA PnP
IRQ 10 assigned to : PCI/ISA PnP
IRQ 11 assigned to : PCI/ISA PnP
IRQ 12 assigned to : PCI/ISA PnP
IRQ 14 assigned to : PCI/ISA PnP
IRQ 15 assigned to : PCI/ISA PnP
DMA 0 assigned to : PCI/ISA PnP
DMA 1 assigned to : PCI/ISA PnP
DMA 3 assigned to : PCI/ISA PnP
DMA 5 assigned to : PCI/ISA PnP
DMA 6 assigned to : PCI/ISA PnP
DMA 7 assigned to : PCI/ISA PnP
PCI IDE IRQ Map To : PCI-Auto
Primary IDE INT# : A
Secondary IDE INT# : B
Used MEM base addr : N/A
Used MEM Length : 8K
ESC: Quit áâàß : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2 : Color
F6 : Load Setup Defaults
F7 : Load Turbo Defaults
PNP/PCI Configuration à PnP OS Installed
PnP OS Installed
Yes
No
Normally, the PnP resources are allocated by BIOS
during POST (Power-On Self Test). If you are using a
PnP operating system (such as Windows 95), set this
item to Yes to inform BIOS to configure only the
resources needed for booting (VGA/IDE or SCSI). The
rest of system resources will be allocated by PnP
operating system.
3-25
AWARD BIOS
PNP/PCI Configuration à Resources Controlled By
Resources Controlled
by
Auto
Manual
Setting this option to Manual allows you to individually
assign the IRQs and DMAs to the ISA and PCI devices.
Set this to Auto to enable the auto-configuration
function.
PNP/PCI Configuration à Reset Configuration Data
Reset Configuration
Data
Enabled
Disabled
In case conflict occurs after you assign the IRQs or after
you configure your system, you can enable this
function, allow your system to automatically reset your
configuration and reassign the IRQs.
PNP/PCI Configuration à IRQ3 (COM2)
PNP/PCI Configuration à IRQ4 (COM1)
PNP/PCI Configuration à IRQ5 (Network/Sound or Others)
PNP/PCI Configuration à IRQ7 (Printer or Others)
PNP/PCI Configuration à IRQ9 (Video or Others)
PNP/PCI Configuration à IRQ10 (SCSI or Others)
PNP/PCI Configuration à IRQ11 (SCSI or Others)
PNP/PCI Configuration à IRQ12 (PS/2 Mouse)
PNP/PCI Configuration à IRQ14 (IDE1)
PNP/PCI Configuration à IRQ15 (IDE2)
IRQ 3
Legacy ISA
PCI/ISA PnP
If your ISA card is not PnP compatible and requires a
special IRQ to support its function, set the selected IRQ
to Legacy ISA. This setting informs the PnP BIOS to
reserve the selected IRQ for the installed legacy ISA
card. The default is PCI/ISA PnP. Take note that PCI
cards are always PnP compatible (except old PCI IDE
card).
3-26
PNP/PCI Configuration à DMA 0
PNP/PCI Configuration à DMA 1
PNP/PCI Configuration à DMA 3
PNP/PCI Configuration à DMA 5
PNP/PCI Configuration à DMA 6
PNP/PCI Configuration à DMA 7
AWARD BIOS
DMA 0
Legacy ISA
PCI/ISA PnP
If your ISA card is not PnP compatible and requires a special
DMA channel to support its function, set the selected DMA
channel to Legacy ISA. This setting informs the PnP BIOS to
reserve the selected DMA channel for the installed legacyISA
card. The default is PCI/ISA PnP. Take note that PCI card
does not require DMA channel.
PNP/PCI Configuration à PCI IDE IRQ Map To
PCI IDE IRQ Map To
ISA
PCI-Slot1
PCI-Slot2
PCI-Slot3
PCI-Slot4
PCI-Auto
Some old PCI IDE add-on cards are not fully PnP
compatible. These cards require you to specify the slot
in use to enable BIOS to properly configure the PnP
resources. This function allows you to select the PCI
slot for any PCI IDE add-on card present in your
system. Set this item to Auto to allow BIOS to
automatically configure the installed PCI IDE card(s).
PNP/PCI Configuration à Primary IDE INT#
PNP/PCI Configuration à Secondary IDE INT#
Primary IDE INT#
A
B
C
D
These two items, in conjunction with item "PCI IDE IRQ
Map To", specify the IRQ routing of the primary or
secondary channel of the PCI IDE add-on card (not the
onboard IDE). Each PCI slot has four PCI interrupts
aligned as listed in the table below. You must specify
the slot in the "PCI IDE IRQ Map To", and set the PCI
interrupt (INTx) here according to the interrupt
connection on the card.
PCI Slot Location 1 Location 2 Location 3 Location 4
3-27
AWARD BIOS
(pin A6) (pin B7) (pin A7) (pin B8)
Slot 1 INTA INTB INTC INTD
Slot 2 INTB INTC INTD INTA
Slot 3 INTC INTD INTA INTB
Slot 4 INTD INTA INTB INTC
Slot 5 (if any) INTD INTA INTB INTC
PNP/PCI Configuration à Used MEM Base Addr
Used MEM base addr
N/A
C800
CC00
D000
D400
D800
DC00
This item, in conjunction with the "Used MEM Length",
lets you set a memory space for non-PnP compatible
ISA card. This item specifies the memory base (start
address) of the reserved memory space. The memory
size is specified in the "Used MEM Length".
PNP/PCI Configuration à Used MEM Length
Used MEM Length
8K
16K
32K
64K
If your ISA card is not PnP compatible and requires
special memory space to support its function, specify
the memory size in this parameter to inform the PnP
BIOS to reserve the specified memory space for
installed legacy ISA card.
3.7 Load Setup Defaults
The "Load Setup Defaults" option loads optimized settings for optimum system
performance. Optimal settings are relatively safer than the Turbo settings. We
recommend you to use the Optimal settings if your system has large memory
size and fully loaded with add-on card (for example, a file server using doublesided 8MB SIMM x4 and SCSI plus Network card occupying the PCI and ISA
slots).
3-28
AWARD BIOS
Optimal is not the slowest setting for this mainboard. If you need to verify a
unstable problem, you may manually set the parameter in the "BIOS Features
Setup" and "Chipset Features Setup" to get slowest and safer setting.
3.8 Load Turbo Defaults
The "Load Turbo Defaults" option gives better performance than Optimal values.
However, Turbo values may not be the best setting of this mainboard but these
values are qualified by the AOpen RD and QA department as the reliable settings
especially if you have limited loading of add-on card and memory size (for
example, a system that contains only a VGA/Sound card and two SIMMs).
To attain the best system performance, you may manually set the parameters in
the "Chipset Features Setup" to get proprietary setting. Make sure that you know
and understand the functions of every item in Chipset Setup menu. The
performance difference of Turbo from Optimal is normally around 3% to 10%,
depending on the chipset and the application.
3-29
AWARD BIOS
3.9 Integrated Peripherals
The following screen appears if you select the option "Integrated Peripherals"
from the main menu. This option allows you to configure the I/O features.
ROM PCI/ISA BIOS (XXXXXXXX)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
IDE HDD Block Mode: : Enabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO : Auto
IDE Secondary Slave PIO : Auto
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA : Auto
On-Chip Primary PCI-IDE : Enabled
On-Chip Secondary PCI-IDE : Enabled
USB Legacy Support : Disabled
USB IRQ Released : No
Onboard FDC Controller : Enabled
Onboard UART 1 : AUTO
Onboard UART 2 : AUTO
Onboard UART 2 Mode : Standard
IR Duplex Mode : Half
Onboard Parallel Port : 378/IRQ7
Parallel Port Mode : Normal
ECP Mode Use DMA : 3
****** Hardware Monitor ******
System Voltage +12V : Ignore
System Voltage +5V : Ignore
VIO Voltage +3.3V : Ignore
CPU Core Voltage +2.8V : Ignore
CPU Thermal (Temp.) : Monitor
CPU FAN : Ignore
ESC: Quit áâàß : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2 : Color
F6 : Load Setup Defaults
F7 : Load Turbo Defaults
Integrated Peripherals à IDE HDD Block Mode
IDE HDD Block Mode
Enabled
Disabled
This feature enhances disk performance by allowing
multisector data transfers and eliminates the interrupt
handling time for each sector. Most IDE drives, except
with old designs, can support this feature.
Integrated Peripherals à IDE Primary Master PIO
Integrated Peripherals à IDE Primary Slave PIO
Integrated Peripherals à IDE Secondary Master PIO
Integrated Peripherals à IDE Secondary Slave PIO
3-30
AWARD BIOS
IDE Primary Master
PIO
Auto
Mode 1
Mode 2
Mode 3
Mode 4
Setting this item to Auto activates the HDD speed
auto-detect function. The PIO mode specifies the data
transfer rate of HDD. For example: mode 0 data
transfer rate is 3.3MB/s, mode 1 is 5.2MB/s, mode 2 is
8.3MB/s, mode 3 is 11.1MB/s and mode 4 is 16.6MB/s.
If your hard disk performance becomes unstable, you
may manually try the slower mode.
Caution: It is recommended that you
connect the first IDE device of each channel
to the endmost connector of the IDE cable.
Refer to section 2.3 "Connectors" for details
on how to connect IDE device(s).
Integrated Peripherals à IDE Primary Master UDMA
Integrated Peripherals à IDE Primary Slave UDMA
Integrated Peripherals à IDE Secondary Master UDMA
Integrated Peripherals à IDE Secondary Slave UDMA
IDE Primary Master
UDMA
Auto
Disabled
This item allows you to set the Ultra DMA/33 mode
supported by the hard disk drive connected to your
primary IDE connector.
Integrated Peripherals à On-Chip Primary PCI IDE
Integrated Peripherals à On-Chip Secondary PCI IDE
On-Chip Primary PCI
IDE
Enabled
Disabled
This parameter lets you enable or disable the IDE
device connected to the primary IDE connector.
3-31
AWARD BIOS
Integrated Peripherals à USB Legacy Support
USB Legacy Support
Enabled
Disabled
USB IRQ Released
Yes
No
This item lets you enable or disable the USB keyboard
driver within the onboard BIOS. The keyboard driver
simulates legacy keyboard command and let you use
USB keyboard during POST or after boot if you don't
have USB driver in the operating system.
Caution: You can not use both USB driver and
USB legacy keyboard at the same time. Disable
"USB Legacy Support" if you have USB driver in
the operating system.
USB device is default to use PCI INTD#, the same as
PCI slot4. If you installed PCI card on slot4 and require
to use INTD#, set this item to Yes. The USB device will
then be disabled.
Note: Normally, PCI VGA does not need PCI
interrupt, you may put PCI VGA on slot4.
Integrated Peripherals à Onboard FDC Controller
Onboard FDC
Controller
Enabled
Disabled
Setting this parameter to Enabled allows you to connect
your floppy disk drives to the onboard floppy disk
connector instead of a separate controllercard. Change
the setting to Disabled if you want to use a separate
controller card.
3-32
Integrated Peripherals à Onboard UART 1
Integrated Peripherals à Onboard UART 2
AWARD BIOS
Onboard UART 1
Auto
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
This item allow you to assign address and interrupt for
the board serial port. Default is Auto.
Note: If you are using an network card, make
sure that the interrupt does not conflict.
Integrated Peripherals à Onboard UART 2 Mode
Onboard UART 2
Mode
Standard
HPSIR
ASKIR
This item is configurable only if the "Onboard
UART 2" is enabled. This allows you to specify the
mode of serial port2. The available mode selections
are:
• Standard - Sets serial port 2 to operate in normal mode. This is the
default setting.
• HPSIR - Select this setting if you installed an Infrared module in your
system via IrDA connector (refer to section 2.3 "Connectors"). This setting
allows infrared serial communication at a maximum baud rate of 115K
baud.
• ASKIR - Select this setting if you installed an Infrared module via IrDA
connector (refer to section 2.32.3 "Connectors"). This setting allows
infrared serial communication at a maximum baud rate of 19.2K baud.
•
3-33
AWARD BIOS
Integrated Peripherals à IR Duplex Mode
IR Duplex Mode
Full
Half
This item lets you set the duplex mode for the IR
communication. Full - Allows IR communication in bidirectional mode. Half - Allows IR communication in
single direction only.
Note: This option appears only if the IR function
is activated and the Onboard UART 2 Mode
parameter is NOT set to Standard.
Integrated Peripherals à Onboard Parallel Port
Onboard Parallel Port
3BC/IRQ7
378/IRQ7
278/IRQ7
Disabled
This item controls the onboard parallel port address and
interrupt.
Note: If you are using an I/O card with a parallel
port, make sure that the addresses and IRQ do
not conflict.
Integrated Peripherals à Parallel Port Mode
Parallel Port Mode
Normal
SPP
EPP 1.7 + SPP
EPP 1.9 + SPP
ECP
EPP 1.7 + ECP
EPP 1.9 + ECP
3-34
This item lets you set the parallel port mode. The mode
options are Normal (Standard and Bidirection Parallel
Port), EPP (Enhanced Parallel Port) and ECP
(Extended Parallel Port). Normal is the IBM AT and
PS/2 compatible mode. EPP enhances the parallel port
throughput by directly writing/reading data to/from
parallel port withoutlatch. ECP supports DMA and RLE
(Run Length Encoded) compression and
decompression. EPP1.7 and EPP1.9 are protocol
difference.
Integrated Peripherals à ECP Mode Use DMA
AWARD BIOS
ECP Mode Use DMA
3
1
This item lets you set the DMA channel of ECP mode.
Integrated Peripherals à System Voltage +12V
Integrated Peripherals à System Voltage +5V
Integrated Peripherals à VIO Voltage +3.3V
Integrated Peripherals à CPU Core Voltage +2.8V
Integrated Peripherals à CPU Thermal (Temp.)
Integrated Peripherals à CPU FAN
System Voltage +12V
Ignore
Monitor
This item lets you enable or disable the hardware
monitoring function.
Note: Because of hardware limitation, the CPU
core voltage other than 2.8V will not be
monitored.
Note: Because of hardware limitation, CPU fan
monitoring can only be supported from AX5T-
3.1 and later. AX5T-3 does not support CPU fan
monitoring.
3-35
AWARD BIOS
3.10 Password Setting
Password prevents unauthorized use of your computer. If you set a password,
the system prompts for the correct password before boot or access to Setup.
To set a password:
1. At the prompt, type your password. Your password can be up to 8
alphanumeric characters. When you type the characters, they appear as
asterisks on the password screen box.
2. After typing the password, press.
3. At the next prompt, re-type your password and press again to confirm the
new password. After the password entry, the screen automatically reverts
to the main screen.
To disable the password, press when prompted to enter the password. The
screen displays a message confirming that the password has been disabled.
3.11 IDE HDD Auto Detection
If your system has an IDE hard drive, you can use this function to detect its
parameters and enter them into the "Standard CMOS Setup" automatically.
This routine only detects one set of parameters for your IDE hard drive. Some
IDE drives can use more than one set of parameters. If your hard disk is
formatted using different parameters than those detected, you have to enter the
parameters manually. If the parameters listed do not match the ones used to
format the disk, the information on that disk will not be accessible. If the autodetected parameters displayed do not match those that used for your drive,
ignore them. Type N to reject the values and enter the correct ones manually
from the Standard CMOS Setup screen.
3.12 Save & Exit Setup
This function automatically saves all CMOS values before leaving Setup.
3-36
AWARD BIOS
3.13 Exit without Saving
Use this function to exit Setup without saving the CMOS value changes. Do not
use this option if you want to save the new configuration.
3.14 NCR SCSI BIOS and Drivers
The NCR 53C810 SCSI BIOS resides in the same flash memory chip as the
system BIOS. The onboard NCR SCSI BIOS is used to support NCR 53C810
SCSI control card without BIOS code.
The NCR SCSI BIOS directly supports DOS, Windows 3.1 and OS/2. For better
system performance, you may use the drivers that come with the NCR SCSI card
or with your operating system. For details, refer to the installation manual of your
NCR 53C810 SCSI card.
3-37
AWARD BIOS
3.15 BIOS Flash Utility
The BIOS Flash utility allows you to upgrade the system BIOS. To get the
AOpen Flash utility and the upgrade BIOS file, contact your local distributor or
visit our homepage at http://www.aopen.com.tw. Please make sure that you
have the correct BIOS ready, the BIOS filename is normally like AP5TR110.BIN,
which means model AP5T BIOS revision 1.10.
There are two useful programs, Checksum utility CHECKSUM.EXE and AOpen
Flash utility AOFLASH.EXE. Follow the procedures below to upgrade your
BIOS.
[CHECKSUM.EXE]
This utility will help you to determine if the BIOS has been downloaded correctly
or not.
1. Execute
C:> CHECKSUM Biosfile.bin
Biosfile.bin is the filename of the BIOS code.
2. The utility will show "Checksum is ssss".
3. Compare the "ssss" with original checksum posted on Web or BBS. If they
are different, please do not proceed any further and try to download the BIOS
again.
[AOFLASH.EXE]
This utility will try to check the mainboard model, BIOS version and Super/Ultra
IO chip model. To ensure the correct BIOS file for the correct mainboard and IO
chip. This utility will permanently replace your original BIOS content after
flashing.
1. Bootup the system from DOS prompt without loading any memory manager
(HIMEM, EMM386, QEMM386, ...).
2. Execute
C:> AOFLASH Biosfile.bin
Biosfile.bin is the filename of the BIOS code.
3. After loading the new BIOS code, the utility will prompt you to save original
BIOS code into your HDD or floppy. Please press "Y" to store it as
"BIOS.OLD".
3-38
AWARD BIOS
4. After the old BIOS has been successfully saved, press "Y" to replace BIOS.
5. DO NOT turn off the power during "FLASHING".
6. Reboot the system by turn off the power after "FLASHING".
7. Press "DEL" key to enter BIOS setup during POST.
8. Reload the "BIOS SETUP DEFAULT" and reconfigure other items as
previous set.
9. Save & Exit. Done!
Warning: DO NOT turn off the power during
"FLASHING". If the BIOS programming is not
successfully finished, the system will not be boot
again, and you may need to physically replace the
BIOS chip.
Tip: You may load back original BIOS "BIOS.OLD" by
the same procedure.
3-39
Loading...
