SERVICE MANUAL
维 修 手 册
客户/品牌 机种名
AOC 936Swb+
1
变更说明
版本 发布日期 变更说明 对外机种名 对内机种名
A00 Jan.-19-2010 Initial Release 936Swb+ T894M5ND6WA4QNE
2
目录
1. 技术规格-------------------------------------------------------------------------------------------------------------- 4
1.1 一般规格 --------------------------------------------------------------------------------------------------------- 4
1.2 工厂预设模式 --------------------------------------------------------------------------------------------------- 5
2. 操作说明-------------------------------------------------------------------------------------------------------------- 6
2.1控制面板--------------------------------------------------------------------------------------------------------- 6
2.2接口说明--------------------------------------------------------------------------------------------------------- 7
2.3 OSD 菜单调整 -------------------------------------------------------------------------------------------------8
3. 工厂模式调整-------------------------------------------------------------------------------------------------------- -9
4. 故障处理流程-------------------------------------------------------------------------------------------------------- 10
4.1 主板--------------------------------------------------------------------------------------------------------------- 10
4.2 电源板------------------------------------------------------------------------------------------------------------ 13
4.3 按键板------------------------------------------------------------------------------------------------------------ 15
5. 电气方框图----------------------------------------------------------------------------------------------------------- 16
5.1主板--------------------------------------------------------------------------------------------------------------- 16
5.2电源板------------------------------------------------------------------------------------------------------------ 17
6. 线路图----------------------------------------------------------------------------------------------------------------- 18
6.1主板--------------------------------------------------------------------------------------------------------------- 18
6.2电源板------------------------------------------------------------------------------------------------------------ 23
7. 料件清单-------------------------------------------------------------------------------------------------------------- 25
3
1.技术规格
1.1 一般规格
LCD 面板
分辨率
产品代码
驱动系统 TFT 彩色 LCD
可视尺寸 470mm 对角
像素间距
视频 R, G, B 模拟接口
独立同步 行 /场 TTL
显示颜色 16.7M 色彩
点时钟
水平扫描范围
水平扫描尺寸（最大）
垂直扫描范围
垂直扫描尺寸（最大）
预设的最佳分辨率
预设的最高分辨率
即插即用
输入连接器 D-Sub 15 针
936Swb+
0.3mm(H) x 0.3mm(V)
85.5MHz
30 kHz - 80 kHz
409.8mm
55 Hz - 75 Hz
230.4mm
1366x768 (60 Hz)
1366x768 (60 Hz) )
VESA DDC2B/CI
物理 特性
输入视频信号 模拟： 0.7Vp-p（标准），75 OHM
电源
功率消耗
USB 外接端口 支持 USB 移动设备，负载<100 毫安
定时关机 0~24 小时 设定显示器关机时间
连接器类型 15- 针 Mini D-Sub
信号电缆类型 可分离
高度 (含底座)
宽度
尺寸和重量
温度
湿度
深度
重量（仅显示器）
重量（含包装）
工作时
非工作时
工作时 10% - 85%（非凝露）
非工作时 5% - 80%（非凝露）
100-240VAC, 50/60Hz
正常工作< 25W
离机 < 1 W
358.66mm
463.14mm
186mm
3.63 kg
5.02kg
0°- +40°
-20°- +60°
海拔高度
工作时
非工作时
0~3000m (0~10000 ft)
0~5000m (0~15000 ft)
4
1.2 工厂预设模式
标准 解析度 水平频率（KHz） 垂直频率（Hz）
VGA 640×480 @60Hz DMT 31.469 59.94
VGA 640×480 @67Hz MAC 35 66.667
VGA 640×480 @72Hz DMT 37.861 72.809
VGA 640×480 @75Hz DMT 37.5 75
Dos-mode 720×400 @70Hz DOS 31.469 70.087
SVGA 800×600 @56Hz DMT 35.156 56.25
SVGA 800×600 @60Hz DMT 37.879 60.317
SVGA 800×600 @72Hz DMT 48.077 72.188
SVGA 800×600 @75Hz DMT 46.875 75
SVGA 832×624 @75Hz 49.725 74.55
XGA 1024×768 @60Hz DMT 48.363 60.004
XGA 1024×768 @70Hz DMT 56.476 70.069
XGA 1024×768 @75Hz DMT 60.023 75.029
WXGA 1366×768 @60Hz DMT 47.765 59.85
5
2.操作说明
2.1 控制面板
外部控制
按电源开关即可开关显示器。其它功能按键位于前面板右下方。通过调节这些功能键可得到您需要的画面。
* 接好电源线。
* 将信号线接到 PC 机显卡 。
* 打开显示器把开关打到开机位置，电源指示灯亮。
电源：按电源键打开或关闭显示器.
4:3 或宽屏/向上：
按此键切换 4：3 或宽屏模式，当输入信号的分辨率是宽屏时，此键没有作用，当主菜单或子菜单被激活时，在
OSD 菜单中此按键是向上功能键或者是增加数值。
自动调整 /向下：当没有 OSD 菜单时，按自动调整快捷键启动自动调整功能。
6
2.2 接口说明
管脚号 信号电缆的 15 针一端 管脚号 信号电缆的 15 针一端
1
2
3
4 N.C. 12
5
6 GND-R 14
7 GND-G 15
8 GND-B
视频 - 红色
视频 - 绿色
视频 - 蓝色
检测电缆
9 +5V
10
11 N.C.
13
接地
DDC- 串行数据
H- 同步
V- 同步
DDC- 串行时钟
7
2.3 OSD 菜单调整
亮度情景模式 ---动态对比度,标准，文本，网络，游戏，电影，运动
备注：当情景模式不是在标准模式时，对比度和亮度不能被调节，当 DCR 打开时，对比度、亮度、情景模式和伽玛都
不能调节。
LED 指示灯
8
3.工厂模式调整
进入工厂模式方法：
先按“电源”键关机，然后在按^(上)和ˇ(下)键的同时,按“电源”键开机，最后按“菜单”键，这时工厂模式菜单
将出现在屏幕的
左上方。
a.基本调整:
设置对比度 为 50。
设置亮度
为 90。
b.增益调整:
调整9300K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择9300K进行R G B增益调整
x = 283±30, y = 297 ±30, Y =170 cd/m
调整7300K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2
2、按“MENU”选择7300K进行R G B增益调整
x = 302 ±30, y = 318 ±30, Y = 180 cd/m
2
调整6500K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择 6500K 进行 R G B 增益调整
x = 313±30, y = 329 ±30, Y =200 cd/m
2
调整sRGB色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择 sRGB 进行 R G B 增益调整
x = 313±30, y = 329 ±30, Y =180 cd/m
2
c.调整完毕直接关闭电源。
9
4.故障处理流程
4.1 主板
无供电
无供电
按下电源键看画面是否正常
NG
重新插插头然后检查 AC:100-240V 是否正常?
NG
OK
检查 U404 Vout=3.3V,C423(+)=1.8V
NG
OK
检查 X401 晶振是否正常
NG
OK
检查适配器及升压板部分和交流电源输入
检查或更换 CN404,U404,C423
更换 X401
更换 U401
10
无画 (LED 橙色)
G
无画
检查信号线
OK
检查 U404 Vout=3.3V,C423(+)=1.8V
OK
N
检查 X401 震荡波是否正常
OK
检查 CN101 的 HS/VS 是否正常
NG
OK
更换信号线
更换 CN404,U404,C423
更换 X401
检查相关回路
更换 U401
11
白屏
白屏
检查 Q302 的基极是否
为低电平
OK
检查 FB402,Q405 是否
损坏或 CN405 虚焊
NG
OK
更换 PA NEL
检查相关元件
NG
检查 X401 的晶振是否
正常
NG
OK
检查 U401 复位电路是
否正常
NG
OK
更换 U401
更换 X401
检查相关元件
12
4.2 电源板
死机
检测交流电 100V or 240V 是否正常？
OK
NG
检测 C907 (+)的电压大小
NG
OK
检测 IC901 第 8 脚电压是否正常？
NG
OK
检测二次启动电压是否正常？
NG
OK
检测 AC 输入
检测全桥整流回路和 F901 回路
检测 R908 或更换 IC901
1) 检测 U901
2) 检测 D904/D907 回路
检测 IC901 第 5,6 脚的 PWM 波形
NG
OK
检测 D901,D902,D906,Q901,U902,U903,ZD901
检测 U901
13
无背光
检测 C811(+)电压是否为 14.5V
NG
OK
检测 ON/OFF 信号
NG
OK
检测 IC801 第 9 脚是否为 16V
NG
OK
检测 IC801 第 11/1 4 脚的 PWM 波形
检测 Adapter 回路
检测主板
更换 IC801
NG
OK
检测 T801 的输出
NG
OK
检查接口或灯管,反馈和保护回路
检测 Q803
更换 T801
14
4.3 按键板
OSD 画面不稳定及不可调整
OSD 画面不稳定及不可调整
OK
按键板是否连接正常
OK
按键开关是否正常
OK
NG
连接好按键板
NG
替换按键开关
按键板是否正常
OK
检查主板
NG
替换按键板
15
5.电气方框图
5.1 主板
FLASH ROM
EN25F20-100GCP
(U402)
Crystal 14.31818MHz
(X401)
Scalar IC TSUM1PFR-LF
(Include ADC, OSD, MCU)
D-Sub Connector
(CN101)
(U401)
Panel Interface
(CN405)
Key Control Interface
(CN409)
16
5.2 电源板
(
A
C input
EMI filter
Bridge
Rectifier,Filter
Transformer
(T901)
Rectifier diodes
14.5V
5V
Start Circuit
(R908)
PWM Control IC
LD7576
Power Switch
(Q901)
Photocoupler
(U902)
Regulator
(U903)
Lamp
Output
Circuit
Transformer
(T801)
MOSFET
(Q803)
16V
Feedback
Circuit
PWM Control IC
MPS10091
U801)
DIM
ON/OFF
17
6.线路图
6.1 主板
TSUM1PFR SCHEMATIC
CMVCC1
CMVCC1
VCC3.3
CMVCC
DSUB_5V
DSUB_5V
VCC3.3
XGA/SXGA
DSUB_5V
VCC3.3
CMVCC1
02.Input
VCC1.8
VCC1.8
on_BACKLI GHT
VCC3.3
Adj_BACKLIGH T
CMVCC
CMVCC1
DSUB_R+
DSUB_R-
DSUB_G+
DSUB_G-
DSUB_SOG
DSUB_B+
DSUB_B-
DSUB_H
DSUB_V
DDC1_SDA
DDC1_SCL
DET_CABLE
EDI D_CTRL
Mut e
Volume#
PANEL_ID #DSUB_5V
VCTRL
DSUB_R+
DSUB_RDSUB_G+
DSUB_GDSUB_SOG
DSUB_B+
DSUB_BDSUB_H
DSUB_V
DDC1_SDA
DDC1_SCL
DET_CABLE
EDID_CTRL
on_BACKLIGH T
Mut e
Volume#
PANEL_ID #
Adj_BACKLIGH T
VCTRL
LVDS OUTPUT
VCC1.8
VCC1.8
VCC3.3
CMVCC
CMVCC1
PA[0..1]
PA[4..9]
PB[0..9]
PPWR_ON#
VCC 3.3
PA[0..1]
PA[4..9]
PB[0..9]
CMVCC
CMVCC1
PA[0..1]
PA[4..9]
PB[0..9]
PPWR_ON#
CMVCC
CMVCC
05.Power
03.Scalar
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
G3324-I-X-X-6-090105
01.Top
18
04.Output
<
A
F
称爹
>
OEM MO DEL
TPV MODEL
PCB NAME
Sheet
OTS R-series
715G3244-I
of
37Tuesday , January 06, 2009
Size
Rev
称爹
DDC1_SCL5
DDC1_SDA5
R120
R121
R110
R113
D403
U405
Q407
R472
R473
R474
R475
R476
C434
VCC3. 3
VCC3. 3 7
R120
R121
NC/ 10K 1/16W 5%
DDC1_SCL
DDC1_SDA DSUB_SDA
GND POWER
NC/ 10K 1/16W 5%
R110
NC/ 100R 1/16W 5%
R113
NC/ 100R 1/16W 5%
DGND
EDID externalEDID internal
10K 1/16W 5%
10K 1/16W 5%
100R 1/16W 5%
100R 1/16W 5%
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
BAV70
M24C02-WMN6TP
2N3904S-RTK/PS
4K7 1/16W 5%
4K7 1/16W 5%
4K7 1/16W 5%
47R 1/16W 5%
47R 1/16W 5%
0.22uF
H_Sync
R101 0R05 1/10W 5% R 102 100R 1/16W 5%
V_Sy nc
ZD103
RLZ5.6B
H_Sync
V_Sy nc
C102
22pF
DSUB_5V
I/O1
I/O4
GND
VDD
I/O23I/O3
I/O1
I/O4
GND
VDD
I/O23I/O3
DSUB_SCL
DSUB_SDA
R106
2K2 1/16W 5%
VGA_BVGA_B+
VGA_GVGA_G+
VGA_RVGA_R+
6
5
4
6
5
4
R475 47R 1/ 16W 5%
R476 47R 1/ 16W 5%
DDC 1_SDA
DDC 1_SCL
R105
2K2 1/16W 5%
CN101
DB15
DSUB_SCL VGA_PLUG
15
14
13
12
11
10
5
9
4
8
3
7
2
6
1
17 16
U103
DSUB_SDA
DSUB_SCL
VGA_G+
VGA_R+ VGA_B+
AZC199- 04S
1
2
U102
AZC199- 04S
1
2
R103 100R 1/ 16W 5%
C103
22pF
DSUB_5V
ZD104
RLZ5.6B
R472
4K7 1/16W 5%
DSUB_5V 5
CMVCC1
2
R474
R473
4K7 1/16W 5%
DSUB_H 5
DSUB_V 5
VGA_B+
VGA_B-
VGA_G+
VGA_G-
VGA_R+
VGA_R-
DSUB_5V
1
3
8
4K7 1/16W 5%
7
6
5
M24C 02- WMN 6TP
FB102
1 2
BEAD
R107
75R 1/16 W 5%
FB103
1 2
BEAD
R112
75R 1/16 W 5%
FB101
1 2
BEAD
R116
75R 1/16 W 5%
D403
BAV70
C434
1
2
3
4
0.22uF16 V
Q407
LMBT3904LT1G
G3244-G-X-X-6-090105
02.Inpu t
U405
A0
VCC
A1
WP
A2
SCL
VSS
SDA
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
VGA_PLUG
CMVCC1
C104
5pF/50V
C108
5pF/50V
C111
5pF/50V
100R 1/ 16W 5%
R118
10K 1/16W 5%
R122
R104
100R 1/ 16W 5%
R108
100R 1/ 16W 5%
R109
390 OHM 1/16W
R111
100R 1/ 16W 5%
R114
100R 1/ 16W 5%
R115
100R 1/ 16W 5%
R117
CMVCC1 5
NC
R123 4K7 1/16W 5%
OEM MO DEL
TPV MODEL
PCB NAME
Sheet
AOC 836S
715G3244-I
47Tuesday , January 06, 2009
C101
0.047uF
C105
0.047uF
C106
0.047uF
C107
0.047uF
C109
0.047uF
C110
0.047uF
C113
0.047uF
DET_CABLE 5
EDID _CTRL
of
DSUB_B+ 5
DSUB_B- 5
DSUB_SOG 5
DSUB_G+ 5
DSUB_G- 5
DSUB_R+ 5
DSUB_R- 5
Size
Rev
称爹
B
F
称爹
>
<
19
For user data, WB, EDID,
SST
HDCP are saved in
Eon
Flash.
SST
010A
Befor AOC ID2007 OSD
For ID2008 ID2009
020A
Eon
For All model020
VCC3.3
C408
0.22uF16V
R408
10K 1/16W 5%
CMVCC1
CMVCC17
CMVCC7
According to MST's
request, reserve another
RST circuit.
CN408
6
5
4
3
2
1
NC/CONN
CN409
7
6
5
4
3
2
TOUCH POWER
1
CONN
10uF/50V
CMVCC
C430
NC/10uF/ 50V
NC/10K 1/16W 5%
ZD404
NC/UDZSNP5.6B
C410
+
U402
U402
U402
+
R421
1 2
U402
1
CS#
2
DO
WP
3
WP#
VSS4DI
EN25F20-100GCP
R417
10K 1/16W 5%
R460
NC
R483
0R05 1/16W
R427
3.9K OHM 1/16W
C413
NC/0. 1uF/16V
ZD402
NC/UD ZSNP5.6B
8
VCC
7
HOLD#
6
CLK
5
C411 47pF
C412 47pF
VCC3.3
C414
NC/0.1uF /16V
NC/U DZSN P5.6B
1 2
Near to Connect
DSUB_R+3
DSUB_R-3
DSUB_G+3
DSUB_G-3
DSUB_SOG3
DSUB_B+3
DSUB_B-3
DSUB_H3
DSUB_V3
DDC1_SDA3
DDC1_SCL3
AVDD
R456 0R05 1/16W
R457 0R05 1/16W
R405 100R 1/16W 5%
X401
14.31818MHz
1 2
LED_ORANGE/TOUCH VCC
R484
NC
R428
3.9K OHM 1/16W
C415
NC/0.1uF /16V
ZD403
1 2
R403 390 OHM 1/16W
C401
0.1uF/16V
R401
0R05 1/16W
0R05 1/16W
R402
KEY1
KEY2
POWER_KEY#
LED_GRN/BLUE
LED_ORANGE/TOUCH VCC
R404
C416
NC/10K 1/16W 5%
0.1uF/16V
LED_ORANGE/TOUCH VCC
U401
13
RIN0P
12
RIN0M
10
GIN0P
9
GIN0M
11
SOGIN0
8
BIN0P
7
BIN0M
16
HSYNC0
17
VSYNC0
18
DDCA_SDA/ RS232_TX
19
DDCA_SCL/ rs232_RX
4
REXT
15
REFP
14
REFM
21
SDO
22
SCZ
23
SCK
24
SDI
28
GPIO_P27/PWM1
54
RST
1
XIN
2
XOU T
31
MODE [0 ]
32
MODE [1 ]
R461 NC/0R 05 1/16W
R462 NC/0R 05 1/16W
VCC3. 3
R478 NC
C417
NC/0.1uF /16V
FB404
NC/150 OHM
FB405
150 OHM
ZD401
NC/R LZ5.6B
VCC3.3 VCC 1.8
AVDD
6
AVDD_ADC
LVDS
GND
GND
5
3
29
R463 NC
R464 NC
R407
10K 1/16W 5%
TOUCH POWER
51
30
53
VDDP
VDDC
GPIO_P10/I2C_MCL
GPIO_P11/I2C_MDA
GND
TSUM1PFR-LF
C433
1uF 10V
VCTRL
VDDC
LVA3P
LVA3M
LVA2P
LVA2M
LVA1P
LVA1M
LVA0P
LVA0M
LVB3P
LVB3M
LVBCKP
LVBCKM
LVB2P
LVB2M
LVB1P
LVB1M
LVB0P
LVB0M
GPIO_P15/PWM0
PWM2/GPIO_P24
GPIO_P12
PWM1/GPIO_P25
RSTN
GPIO_P00/SAR1
GPIO_P01/SAR2
GPIO_P06
GPIO_P07
PWM0/GPIO_P26
GPIO_P13
GPIO_P14
CN406
1
2
3
4
5
6
7
8
NC/CONN
CN402
1
2
3
4
5
6
NC/CONN
CN407
1
2
3
4
5
6
7
NC/CONN
52
PA0
33
PA1
34
PA4
35
PA5
36
PA6
37
PA7
38
PA8
39
PA9
40
PB0
41
PB1
42
PB2
43
PB3
44
PB4
45
PB5
46
PB6
47
PB7
48
PB8
49
PB9
50
R424 NC
20
27
55
56
57
58
R411 100R 1/16W 5%
R412 100R 1/16W 5%
59
60
R414 10K 1/16W 5%
R410 1K 1/16W 5%
61
62
R418 NC/100R 1/16W 5%
63
64
R419 NC/100R 1/16W 5%
Max condition for LED:
1. Vcc = 3.3 V
2. Current = 12 mA
FW need to be modified.
26
25
R413 100R 1/16W 5%
R466
2K2 1/16W 5%
LED_G/B
1
R469
1K 1/16W 5%
LED_O
When use touch
Key,GPIO_P07 as
to control touch
key VCC
PA[0..1]
PA[4..9]
PB[0..9]
KEY2
KEY1
CMVCC1
23
R467
0R05 1/10W 5%
Q403
LMBT3906LT1G
R470
0R05 1/10W 5%
Q402
LMBT3906LT1G
VCTRL 7
PA[0..1] 5
PA[4..9] 5
PB[0..9] 5
R425
NC
on_BACKLIGHT 7
adj_BACKLI GHT 7
LED_G/B
LED_O
Volume# 7
Mute 7
PPWR_ON # 6
DET_CABLE 4
LED_GRN/BLUE
R468 200 OHM 1/16W
CMVCC1
R481
NC/0R05 1/16W
VCC3. 3
R482 0R05 1/16W
R471 0R 1/16W 5%
EE_WP
C418
NC
LED_ORANGE/TOUCH VCC
VCC3. 37
VCC1. 87
R485 0R05 1/16W
R426 NC/100R 1/16W 5%
R452 NC
R420 NC/100R 1/16W 5%
R451 NC
MSCL
MSDA
For NVRAM
U403
M24C04-WMN6TP
0.22uF16V
C419
100R 1/16W 5%
R424
R451
100R 1/16W 5%
100R 1/16W 5%
R452
10K 1/16W 5%
R453
R454
10K 1/16W 5%
10K 1/16W 5%
R455
R420 NC
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
MSDA
POWER_KEY#
MSCL
NC
VCC3.3
VCC1.8
EDID_CTRL
PANEL_ID# 7
R453
R454
NC
NC
NC or 100R 1/16W 5%R426
NC or 100R 1/16W 5%
G3244-G-X-X-6-090105
03.Scalar
FB401
300OHM
C403
0.1uF/16V
C407
C406
0.1uF/16V
0.1uF/16V
For RSTN detect
function
CMVCC7
NC/AO3401
C409
NC/0.1uF /16V
R455
NC
EE_WP
Without NVRAM
NC
NC
NC
NC
NC
NC
NC
NC
AVDD
C404
0.1uF/16V
CMVCC
Q401
R406
NC/6K8 1/16W 5%
U403
8
NC
VCC
7
E1
WC
6
E2
SCL
5
VSS4SDA
NC/M24C 04-WMN6TP
OEM MODEL
TPV MOD EL
PCB NAME
Sheet
CMVCC1
R458
NC/10K 1/16W 5%
R459
NC/47K 1/16W 5%
R409
NC/ 10K 1/16W 5%
VCC3.3
C429
NC
1
2
3
When NVRAM is used,
POWER_KEY# and PANEL_ID#
will not be used at same
time.
R425, C418 depend on
case.
PANEL_ID# and POWER_KEY#
could be optional.
AOC 836S
715G3244-I
57Sunday, May 31, 2009
of
C
Size
Rev
F
<
称爹
>
称爹
20
PA[0.. 1]5
PA[4.. 9]5
PB[0..9]5
PA[0.. 1]
PA[4.. 9]
PB[0..9]
PA0
PA1
PA4
PA5
PA6
PA7
PA8
PA9
PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PB8
PB9
R477
NC/ 150R 1/4W 5%
PANEL_VCC
R434
330 OHM 1/4W
3
D
1
G
AO3401L
CN403
1
2
C420
0.1uF/ 16V
PA0
PA1
PB2
PB3
PA4
PA5
PA6
PA7
PA8
PA9
PB0
PB1
PB2
2
S
PB3
PB4
PB5
PB6
PB7
PB8
PB9
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
PA1
PB3
PA5
PA7
PA9 PA8
PB1
PB3
PB7
PB9
PANEL_VCC
CN405
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
CONN
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
PA0
PB2
PA4
PA6
PB0
PB2
PB4PB5
PB6
PB8
2006-11-7 Add pull up 4K7 to MVCC
R435
4K7 1/16W 5%
PPWR _ON#5
PPWR _ON#
R433
10K 1/16W 5%
R436
100K 1/16W 5%
Q404
PMBS3906
絬 隔 瓜 絪 腹
Key Component
CMVCC
C419
0.1uF/ 16V
4
3
Q411
S1S2S
5
21
G
NC/AO4411
D8D7D6D
FB402
120OHM
Q405
AO3401
T P V ( Top Victory Electronics Co . , Ltd. )
G3244-G-X-X-6-090105
04.Output
Date
CMVCC 7
PANEL_VCC
OE M MODE L
TPV MO DEL
PCB N AME
Sheet
NC/CONN
C421
+
100uF/25V
AOC 836S
715G3244-I
67Sunday , May 31, 2009
of
Size
Rev
称爹
<
A
F
称爹
>
2008/01/14
BAT99 : If 0.05A,VF=1.0V
BAV70 : If 0.05A,VF=1.0V
It's need to use Low Dropout Regulator.
DSUB_5V
CN404
CONN
9
8
7
6
5
4
3
2
1
CMVCC5, 6
CMVCC
CMVCC
BKLT-VBRI
BKLT-EN
C_PANEL_I NDEX
Volume
Mut e
CMVCC
NC/0 OHM 1/3W
D402
R450 NC
NC(R0402)
PANEL_ID # 5
1
2
3
CMVCC1
D401
NC/ BAV99
R449
NC
DSUB_5V 2
CMVCC1 5
Mut e 5
BKLT-EN
C425
NC
CMVCC1
R465
NC
R437
10K 1/16W 5%
Q406
LMBT3904LT1G
4K7 1/16W 5%
R440
VCC3. 3VCC3. 3
R439
10K 1/16W 5%
on_BACKLIGH T 5
VCC3. 3
R480
2.2 OHM 2W
R479
NC/0R05 1/4W 5%
VCTRL5
Q410
KN2907AS
Q409
KN2907AS
C432
0.1uF /16V
VCC1. 8
+
C423
100uF/ 25V
VCC1. 8 5
BKLT-VBRI
R441
1K 1/16W 5%
100R 1/16W 5%
R442
adj_BACKLIGH T 5
Volume
VCC3. 3 VCC3.3VCC3. 3
R446
NC
Q408
NC/LMBT3904LT1G
R447
NC/ 10K 1/16W 5%
R448
NC/ 4K7 1/16W 5%
Volume# 5
+
C426
100uF/ 25V
MVC C
C428
0.1uF /16V
FB403 NC
VIN
VOUT
ADJ(GN D)
U404
AP1117D33L-13
VCC3. 3
3
2
1
+
C422
0.1uF /16V
C427
100uF/ 25V
VCC3. 3 4, 5
CMVCC1
U404 can use package 223 or 252.
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
G3244-G-X-X-6-090105
05.Power
Date
OEM MODEL
TPV MODEL
PCB NAME
Sheet
AOC 836S
715G3244-I
77Sunday, May 31, 2009
of
Size
Rev
称爹
B
F
<
称爹
>
22
6.2 电源板
BD901
KBP208G
2
R900
620K OHM 1/4W
C902
1000pF
!
!
1
+
-
4
!
C909
NC/0. 22uF/275V
L901
3
142
30mH
R901
620K OHM 1/4W
!
C908
0.22UF
3
CN901
SOCKET
3
!
R902
620K OHM 1/4W
NR901
NTCR
!
F902
FUSE
C903
1000pF
12
R931
R929 100 O HM 1/4W
R930 100 O HM 1/4W
R903 100 O HM 1/4W
C937
0.01uF/2KV
NC
R932
NC
!
R933
NC
D908
NC/I N4148
C927
0.047uF
R934
NC
C915
C907
+
!
100UF450V
C938
NC
R921
NC/100K 1/ 10W 1%
1
2
1
2
1
2
3
HS1
HEAT SINK(Q901)
HS3
HEAT SINK(D906_5V/ 2.5A)
U901
CT
COMP
CS
VCC
GND4OUT
LD7576
HV
NC
C914
470pF
!
R908
10K OHM 1/4W +-5%
8
7
6
5
C912
0.1uF/25V
C911
1500PF2KV
D904
FR103
+
C913
22uF/50V
D907
IN4148
R917
10R 1/4W 5%
R918
10K 1/10W 1%
R923
220 OHM 1/4W
HS2
NC/ HEAT SINK(D906_5V/4A)
1
2
GND1
GND
1
2
R906
100KOHM + -5% 2WS
!
D903
FR107
R913
1.5 OHM 1/4W + -5%
!
Q901
FMA07N65GX
12
FB901
BEAD
R924
0.39 OHM 2W + -5%
!
U902
PC123X2YFZOF
C900
0.0022UF
+5V
!
T901
POWER X'FMR
6
5
4
2
1
43
C926
0.1uF/ 16V
12
11
7
8
10
9
12
U903
KIA431A-AT/P
VOL
ON/OFF
DIM
R920
1K 1/10W 1%
C924
0.1uF/16V
R928
1K 1/10W 1%
MUTE
R909 100 O HM 1/4W
R910 100 O HM 1/4W
R912 100 O HM 1/4W
D905 NC /31DQ06FC3
R919
150R 1/8W 5%
2008-12-01
CN902
9
8
7
6
5
4
3
2
1
Wire Harness
D901
NC/SR5150
1 2
D902
SB5150
1 2
1
C916
0.001uF
2008-11-22
C917
0.001uF
D906
2
3
FMW-2156
2008-12-01
T P V ( Top Victory Electronics Co . , Ltd. )
Date
G2892-1-3-X-2-090317
01.POWER
絬 隔 瓜 絪 腹
Key Component
+
+
1000uF M 16V
C925
2008-12-01
C921
1000uF 25V
+
+
C918
1000uF 25V
L906
C920
1000uF 25V
L907
Q904
KTD1028
OEM MODEL
TPV MODEL
PCB NAME
Sheet
R904
220 OHM 2W
C922
+
470uF 16V
R935
NC
C931
+
470uF 16V
PWPC9A21SHD 1
715G2892-1-3
24Tuesday, March 17, 2009
C923
0.001uF
of
ZD901
MTZJ T-72 16B
1 2
R905
470R 1/10W 5%
R907
1K 1/10W 1%
R916
3.65K OHM 1% 1/10W
F903
FUSE
2008-12-01
R914
43.2K OHM 1% 1/4W
R925
2.43K OHM 1% 1/10W
2008-12-01
+5V1
F801
0R05 1/4W 5%
F901
FUSE
Custom
Size
Rev
ODM MO DEL
称爹
+14.5V
+5V
1
23
+14.5V
DIM
ON/OFF
10K 1/10W 5%
R817
10K 1/10W 5%
R811
C809
0.001uF
20K 1/10W 1%
RJ805
0R05 1/4W 5%
0.01uF
C810
R810
R809
100K 1/10W 5%
C808
C807
1uF 16V
0.0039uF/16V
LI2
7
6
5
4
3
2
1
OV2
LI1
+
C811
470uF 25V
0.1uF50V
MPS10091
DBRT8VIN
EN
FSET
FT
COMP
LI2
LI1
OV2
U801
REF
R805
R807
R808
REF
10K 1/10W 5%
C801
10pF3KV
R806
10K 1/10W 5%
C803
10pF3KV
LI1
C802
0.0039uF/16V
LI2
C804
0.0039uF/16V
RJ804
0R05 1/4W 5%
BAW56
D803
2
1
0R05 1/4W 5%
RJ806
0R05 1/4W 5%
2K 1/10W 5%
3
RJ801
2K 1/10W 5%
R803
R804
R801
430 OHM 1/10W
0R05 1/4W 5%
R802
430OHM 1/10W
C814
R816
10 OHM +-5% 1/ 10W
C815
C806
9
0.047uF
10
BT
11
TG
12
SW
13
VCC
14
BG
15
GND
16
OV1
OV1
R813
3.3 OHM +-5% 1/10W
C805
REF
1uF 16V
R812
3.3 OHM +-5% 1/10W
0R05 1/4W 5%
RJ807
RJ803
0R05 1/4W 5%
1uF 25V
R815
10 OHM +-5% 1/ 10W
4
G2
3
S2
2
G1
1
S1
P8008HV
R814
10 OHM +-5% 1/ 10W
Q803
T801
POWER X'FMR
6
C813
2N2 50V
5
D2
6
D2
7
D1
8
D1
C812
2N2 50V
3
4
1 8
OV2
7
OV1
10K 1/10W 5%
10K 1/10W 5%
RJ802
CN801
1
2
CONN
CN802
1
CONN
2
24
T P V ( Top Victory Electronics Co . , Ltd. )
G2892-1-3-X-2090317
絬 隔 瓜 絪 腹
Key Component
02.INVER TER
Date
OEM MODEL
TPV MODEL
PCB NAME
Sheet
715G2892-1-3
34Tuesday, March 17, 2009
of
PWPC9A21SHD1
Custom
Size
1
Rev
ODM MODEL
称爹
7.料件清单
注意：以下料件信息仅供参考，如有变更，恕不另行通知，请到 http://cs.tpv.com.cn 获取最新信息。
T894M5ND6WA4QNE
点位 组件 对象描述 备注
026G 800504 H BARCODE
040G 58162435A P/N LABEL FOR MANUAL PE BAG
052G 1186 SMALL TAPE
052G 1208 A ALUMINIUM TAPE
052G 1211 B
052G 1211550 ALUMINUM FOIL TAPE
052G 2191 A PAPER TAPE
E08902 089G 715HAAE01 SIGNAL CABLE
E08901 089G414A15N IS POWER CORD
E09508 095G8014 5XH09 HARNESS 5P(PLUG)-5P(2501) 200MM
E09503 095G8014 7T588 HARNESS 7P(PLUG)-6P(C2003) 260MM
E09501 095G8018 3TH55 HARNESS 30P-30P 140MM
0D1G1730 8120 SCREW
0M1G 130 5120 SCREW
705GH934100 18.5" STAND_BASE ASS'Y
E750 750GLV185W1411N000 PANEL TPM185B1-XW01 V4A FQ TPV
H40G 18N615 1B ID LABEL
H40G 58161569A USB LABEL
H40G 58161596B BASIC GOLD EPA LABEL
H40G 58169017A CEL-1 LABEL
Conductive Tape 85mm *40mm *0.09mm (单导)
H40G 58261561A CARTON LABEL
H41G7800615 7F WARRANTY BOOKLIST
H41G780061580A QSG
H44G8018101 EPS 936S
H44G8018201 EPS 936S
H44G8018615 6A 936Swb+ CARTON
H45G 77 6 PE PACKING
H45G 87 18 23 PE BAG FOR MONITOR
H70G200961541A CD MANUAL
KEPC9HAB KEY BOARD
PWPC9921MHD2 POWER BOARD
Q15G0413202 MAIN FRAME
Q34G0558AEDB1B0100 bezel L185WA-936
Q34G0559AEDA5B0100 rearcover L185WA-936
Q45G 76 28 H A PE BAG FOR MANUAL
25
Q45G 76 28V13 A PE BAG
Q50G 4 10 TIE (Y1900221)
Q52G 1185 99 big carton tape for aoc
Q85G0118101 AOC 936S AC SHIELD
USB9HA1 USB BOARD
USB9HA2 USB BOARD
0Q1G1040 8120 SCREW
Q01G6064 1 screw
Q34G0560AED 1B0100 AOC-936 stand_front
Q34G0561AED 1B0100 AOC-936 stand_rear
Q34G0562AED 1B0130 AOC-936 base
Q37G0133011 AOC 936S HINGE
756GH9CB A4037 MAIN BOARD-CBPC9M5A1H1
U402 056G1133129 IC EN25F20-100GCP 2Mb SOP-8
SMTCR-U402 100GAMA8010W11 MCU ASS'Y-056G1133129
CN409 033G3802 7B Y W WAFER
CN404 033G3802 9B Y W WAFER
CN405 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE
040G 45762412B CBPC LABEL
R480 061G152M22964L RST MOFR 2.2ohm +-5% 2WS
CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW
X401 093G 22 53 YC Crystal 14.31818MHz/32PF 49U/S YC
E09513 095G8022 6X504 HARNESS 6P-6P 200MM
A33G0564 2 1L0100 Key-Guide
Q52G 3 75 3M DOUBLE FACE TAPE
GND1 009G6005 1 GROUND TERMINAL
CN802 033G8021 2E U INVERT CONNECTOR
CN801 033G8021 2E U INVERT CONNECTOR
040G 45762412B CBPC LABEL
U902 056G 139 7 1 IC EL817MA M-TYPE
NR901 061G 5810T RST NTCR 8 OHM +-20% 4A 13mm THINKING
C908 063G107K2246S1 X2 CAP 0.22UF K 275VAC
C937 065G 2M103 3B 0.01uF 2KV 20% Z5U
C801 065G 3J1006ET 10PF,J,3KV,SL
C803 065G 3J1006ET 10PF,J,3KV,SL
C902 065G305M1022BP Y2 1000PF M 250VAC Y5P
C903 065G305M1022BP Y2 1000PF M 250VAC Y5P
C900 065G306M2222BP 2200PF +-20% 250VAC
C925 067G215P1023AV
C918 067G215P1024AV
CAP 105℃ 1000UF M 16V
CAP 105℃ 1000UF M 25V
26
C920 067G215P1024AV
CAP 105℃ 1000UF M 25V
C811 067G215P4714AV
C922 067G215S4713KV
C907 067G215Z10115A
CAP 105℃ 470UF M 25V
EC 105℃ CAP 470UF M 16V
CAP 105℃ 100UF M 450V
L901 073G 174 65 H2 LINE FILTER 30mH MIN
L906 073G 253191 H IND CHOKE 1.1uH DADON
T901 080GL17T 47 N X'FMR 600uH YUVA-1080
T801 080GL22T 1 H1 X'FMR INVERTER 72uH
CN901 087G 501 32 DL AC SOCKET DIP 3PIN+2PIN GROUND
D902 093G 60325 DIODE SB5150 5A/150V DO-201AD
CN902 095G 825 9T518 HARNESS 9P-9P 120MM
705GQ857021 Q901 ASS'Y
705GQ893027 D906 ASS'Y
PW9921MHD2SMT POWER BOARD FOR SMT
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON
CN511 033G3802 5 BH L CONNECTOR 5PIN
CN512 088G 352 2 XH USB CONN
715G2663 2 USB BOARD PCB
CN501 033G3802 5B Y L CONN 2.0 5P
CN502 088G 351 2B XH USB CONN
C410 067G 2151007RT LOW E.S.R 10UF +/-20% 50V
C423 067G 305101 4T 100UF +-20% 25V
C421 067G 305101 4T 100UF +-20% 25V
C427 067G 305101 4T 100UF +-20% 25V
C426 067G 305101 4T 100UF +-20% 25V
U401 056G 562557 IC TSUM1PFR-LF
U404 056G 563 52 IC AP1117D33G-13 TO252-3L DIODES
U102 056G 662502 IC ESD AZC199-04S SOT23-6L
U103 056G 662502 IC ESD AZC199-04S SOT23-6L
U405 056G1133 34 M24C02-WMN6TP
U402 056G1133129 IC EN25F20-100GCP 2Mb SOP-8
Q404 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q409 057G 417 22 T TRA KN2907AS -60V/-0.6A SOT-23
Q410 057G 417 22 T TRA KN2907AS -60V/-0.6A SOT-23
Q402 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q403 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q406 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q407 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q405 057G 763 1 A03401 SOT23 BY AOS(A1)
R471 061G0402000 RST CHIP MAX 0R05 1/16W
27
R485 061G0402000 RST CHIP MAX 0R05 1/16W
R483 061G0402000 RST CHIP MAX 0R05 1/16W
R482 061G0402000 RST CHIP MAX 0R05 1/16W
R457 061G0402000 RST CHIP MAX 0R05 1/16W
R456 061G0402000 RST CHIP MAX 0R05 1/16W
R402 061G0402000 RST CHIP MAX 0R05 1/16W
R401 061G0402000 RST CHIP MAX 0R05 1/16W
R442 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R413 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R412 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R411 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R405 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R117 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R115 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R114 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R111 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R108 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R104 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R103 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R102 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R469 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R441 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R410 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R439 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R437 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R433 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R417 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R414 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R408 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R407 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R118 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R436 061G0402104 RST CHIPR 100 KOHM +-5% 1/16W
R468 061G0402201 RST CHIP 200R 1/16W 5%
R105 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R106 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R466 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R109 061G0402390 0F RST CHIP 390R 1/16W 1%
R403 061G0402390 0F RST CHIP 390R 1/16W 1%
R428 061G0402392 RST CHIP 3.9K 1/16W 5%
R427 061G0402392 RST CHIP 3.9K 1/16W 5%
28
R475 061G0402470 RST CHIPR 47 OHM +-5% 1/16W
R476 061G0402470 RST CHIPR 47 OHM +-5% 1/16W
R123 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R435 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R440 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R472 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R473 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R474 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R116 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R112 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R107 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R101 061G0603000 RST CHIP MAX 0R05 1/10W
R467 061G0603000 RST CHIP MAX 0R05 1/10W
R470 061G0603000 RST CHIP MAX 0R05 1/10W
R434 061G1206331 RST CHIPR 330 OHM +-5% 1/4W
D402 061G2010000 RST CHIP MAX 0 OHM 3/4W
C416 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C432 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C428 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C422 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C420 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C419 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C407 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C404 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C403 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C401 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C433 065G0402105 A5 CAP 0402 1UF K 10V X5R
C103 065G0402220 31 CHIP 22PF 50V NPO
C102 065G0402220 31 CHIP 22PF 50V NPO
C408 065G0402224 17 CAP CER 0.22UF -20%-80%
C434 065G0402224 17 CAP CER 0.22UF -20%-80%
C411 065G0402470 31 MLCC 0402 CAP 47PF J 50V NPO
C412 065G0402470 31 MLCC 0402 CAP 47PF J 50V NPO
C113 065G0402473 12 CHIP 0.047uF 16V X7R
C110 065G0402473 12 CHIP 0.047uF 16V X7R
C109 065G0402473 12 CHIP 0.047uF 16V X7R
C107 065G0402473 12 CHIP 0.047uF 16V X7R
C106 065G0402473 12 CHIP 0.047uF 16V X7R
C105 065G0402473 12 CHIP 0.047uF 16V X7R
29
C101 065G0402473 12 CHIP 0.047uF 16V X7R
C104 065G0402509 31 CHIP 5pF 50V NPO
C108 065G0402509 31 CHIP 5pF 50V NPO
C111 065G0402509 31 CHIP 5pF 50V NPO
FB405 071G 56G151 A TB160808G151
FB402 071G 56K121 M CHIP BEAD
FB401 071G 56V301 B CHIP BEAD FCM2012VF-301T07 bullwill
FB101 071G 59K190 B 19 OHM BEAD
FB102 071G 59K190 B 19 OHM BEAD
FB103 071G 59K190 B 19 OHM BEAD
D403 093G 64 42 L DIODE LBAV70LT1G SOT-23 LRC
ZD103 093G 39GA01 T RLZ5.6B
ZD104 093G 39GA01 T RLZ5.6B
715G3244 1 MAIN BOARD PCB
CN001 033G8034 6H H X WAFER 1.0mm SMT 6P
U001 056G 665 43 IC CY8C20180-LDX2I QFN-16(COL)
R012 061G0603000 RST CHIP MAX 0R05 1/10W
R009 061G0603000 RST CHIP MAX 0R05 1/10W
R008 061G0603000 RST CHIP MAX 0R05 1/10W
R001 061G0603000 RST CHIP MAX 0R05 1/10W
R002 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R005 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R006 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R007 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R004 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
C001 065G0603102 31 CHIP 1000PF 50V NPO
C002 065G0603225 A5 CHIP 2.2uF 10V X5R
LED001 081G15BY 2 GP LED GPTD1204BOC1-A GP
ZD004 093G 39S 34 T UDZSNP5.6B ROHM
ZD005 093G 39S 34 T UDZSNP5.6B ROHM
715G3371 2 KEY BOARD PCB
Q901 057G 667 56 MOSFET 7A/650V FMA07N65GX TO-220F
HS1 090G6064 1 HEAT SINK
0M1G 930 8120 SCREW
HS3 090G6084 1 GP HEAT SINK
D906 093G1506 2 FMW-2156
0M1G 930 8120 SCREW
U901 056G 379128 IC LD7576 GS SOP-8
U801 056G 379154 IC AM9000ES SOIC-16
Q803 057G 763 92 FET P8008HV 4A/80V SOP-8
30
R816 061G0603100 RST CHIPR 10 OHM +-5% 1/10W
R815 061G0603100 RST CHIPR 10 OHM +-5% 1/10W
R814 061G0603100 RST CHIPR 10 OHM +-5% 1/10W
R928 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R920 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R907 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R918 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R809 061G0603100 3F RST CHIPR 100 KOHM +-1% 1/10W
R806 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R805 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R807 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R808 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R811 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R817 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R803 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
R804 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
R810 061G0603203 RST CHIPR 20 KOHM +-5% 1/10W
R925 061G0603243 1F RST CHIPR 2.43K OHM +-1% 1/10W
R812 061G0603339 RST CHIPR 3.3 OHM +-5% 1/10W
R813 061G0603339 RST CHIPR 3.3 OHM +-5% 1/10W
R916 061G0603365 1F RST CHIPR 3.65 KOHM +-1% 1/10W
R801 061G0603430 0F RST CHIPR 430 OHM +-1% 1/10W
R802 061G0603430 0F RST CHIPR 430 OHM +-1% 1/10W
R905 061G0603471 RST CHIPR 470 OHM +-5% 1/10W
R919 061G0805151 RST CHIPR 150 OHM +-5% 1/8W
RJ801 061G1206000 RST CHIP MAX 0R05 1/4W
F801 061G1206000 RST CHIP MAX 0R05 1/4W
RJ807 061G1206000 RST CHIP MAX 0R05 1/4W
RJ806 061G1206000 RST CHIP MAX 0R05 1/4W
RJ805 061G1206000 RST CHIP MAX 0R05 1/4W
RJ804 061G1206000 RST CHIP MAX 0R05 1/4W
RJ803 061G1206000 RST CHIP MAX 0R05 1/4W
RJ802 061G1206000 RST CHIP MAX 0R05 1/4W
R917 061G1206100 RST CHIPR 10 OHM +-5% 1/4W
R903 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R909 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R910 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R912 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R929 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R930 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
31
R908 061G1206103 RST CHIPR 10K OHM +-5% 1/4W
R913 061G1206159 RST CHIPR 1.5 OHM +-5% 1/4W
R923 061G1206221 RST CHIPR 220 OHM +-5% 1/4W
R914 061G1206432 2F RST CHIPR 43.2 KOHM +-1% 1/4W
R900 061G1206624 RST CHIPR 620 KOHM +-5% 1/4W
R901 061G1206624 RST CHIPR 620 KOHM +-5% 1/4W
R902 061G1206624 RST CHIPR 620 KOHM +-5% 1/4W
C923 065G0603102 32 1000PF +-10% 50V X7R
C915 065G0603103 32 CAP CHIP 0603 0.01UF K 50V X7R
C810 065G0603103 32 CAP CHIP 0603 0.01UF K 50V X7R
C926 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R
C924 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R
C912 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R
C805 065G0603105 17 1UF 16V Y5V
C808 065G0603105 17 1UF 16V Y5V
C914 065G0603471 32 CHIP 470PF 50V X7R
C809 065G0805102 32 CHIP 1000P 50VX7R 0805
C815 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R
C814 065G080510522K 3 CAP CHIP 0805 1U 25V X7R +/-10%
C813 065G0805222 32 CHIP 2200PF 50V X7R 0805
C812 065G0805222 32 CHIP 2200PF 50V X7R 0805
C807 065G0805392 31 CHIP 3900PF 50V X7R 0805
C802 065G0805392 31 CHIP 3900PF 50V X7R 0805
C804 065G0805392 31 CHIP 3900PF 50V X7R 0805
C806 065G0805473 32 CHIP 0.047UF 50V X7R
C927 065G0805473 32 CHIP 0.047UF 50V X7R
C916 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R
C917 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R
D803 093G 64 38 P BAW56
PW9921MHD1AI POWER BOARD FOR AI
C503 065G0603104 12 CER2 0603 X7R 16V 100N P
C501 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
C502 065G0603509 31 CHIP 5PF +-0.5PF 50V NPO
FB501 071G 56K121 M CHIP BEAD
715G3501 2 USB BOARD PCB
CN901 006G 31500 EYELET
U903 056G 158 10 T IC AS431AZTR-E1 TO-92
Q904 057G 530503 T 2SD1207T
R906 061G152M10452T SY RST MOFR 100KOHM +-5% 2WS FUTABA
R904 061G152M22152T RST MOF 220OHM 5% 2W
32
R924 061G152M39852T RST MOFR 0.39 OHM +-5% 2WS
C911 065G 2K152 2T6921 CAP CER 1500pF K 2KV Y5P
C913 067G215Y2207KT
FB901 071G 55 29 FERRITE BEAD
F901 084G 56 4 B FUSE 4A 250V
F902 084G 56 4 B FUSE 4A 250V
ZD901 093G 3916752T MTZJ T-72 16B
D903 093G 6026T52T RECTIFIER DIODE FR107
D904 093G 6038T52T FR103
D907 093G 64 1152T 1N4148
J804 095G 90 23 JUMPER WIRE
J805 095G 90 23 JUMPER WIRE
J806 095G 90 23 JUMPER WIRE
J807 095G 90 23 JUMPER WIRE
J808 095G 90 23 JUMPER WIRE
J822 095G 90 23 JUMPER WIRE
J901 095G 90 23 JUMPER WIRE
J902 095G 90 23 JUMPER WIRE
CAP 105℃ 22UF M 50V KINGNICHI
J903 095G 90 23 JUMPER WIRE
J905 095G 90 23 JUMPER WIRE
J906 095G 90 23 JUMPER WIRE
J907 095G 90 23 JUMPER WIRE
J908 095G 90 23 JUMPER WIRE
J909 095G 90 23 JUMPER WIRE
J921 095G 90 23 JUMPER WIRE
J608 095G 90 23 JUMPER WIRE
J911 095G 90 23 JUMPER WIRE
J803 095G 90 23 JUMPER WIRE
J802 095G 90 23 JUMPER WIRE
J801 095G 90 23 JUMPER WIRE
715G2892 2 3 POWER BOARD PCB
33
Loading...
