SERVICE MANUAL
维 修 手 册
客户/品牌 机种名
AOC 931Swl
1
变更说明
版本 发布日期 变更说明 对外机种名 对内机种名
A00 Jan.-28-2010 Initial Release 931Swl T89AHENDW5A4NNE
2
目录
1. 技术规格-------------------------------------------------------------------------------------------------------------- 4
1.1 一般规格 --------------------------------------------------------------------------------------------------------- 4
1.2 工厂预设模式 --------------------------------------------------------------------------------------------------- 5
2. 操作说明-------------------------------------------------------------------------------------------------------------- 6
2.1控制面板--------------------------------------------------------------------------------------------------------- 6
2.2接口说明--------------------------------------------------------------------------------------------------------- 7
2.3 OSD 菜单调整 -------------------------------------------------------------------------------------------------8
3. 工厂模式调整-------------------------------------------------------------------------------------------------------- -9
4. 故障处理流程-------------------------------------------------------------------------------------------------------- 10
4.1 主板--------------------------------------------------------------------------------------------------------------- 10
4.2 电源板------------------------------------------------------------------------------------------------------------ 13
4.3 按键板------------------------------------------------------------------------------------------------------------ 15
5. 电气方框图----------------------------------------------------------------------------------------------------------- 16
5.1主板--------------------------------------------------------------------------------------------------------------- 16
5.2电源板------------------------------------------------------------------------------------------------------------ 17
6. 线路图----------------------------------------------------------------------------------------------------------------- 18
6.1主板--------------------------------------------------------------------------------------------------------------- 18
6.2电源板------------------------------------------------------------------------------------------------------------ 22
7. 料件清单-------------------------------------------------------------------------------------------------------------- 24
3
1.技术规格
1.1 一般规格
产品代码 931Swl
驱动系统 TFT 彩色 LCD
可视尺寸 470mm 对角
LCD 面板
分辨率
像素间距 0.3mm(H) x 0.3mm(V)
视频 R, G, B 模拟接口
独立同步 行 /场 TTL
显示颜色 16.7M 色彩
点时钟 85.5 MHz
水平扫描范围 30 kHz - 81 kHz
水平扫描尺寸（最大） 409.8mm
垂直扫描范围 55 Hz - 75 Hz
垂直扫描尺寸（最大） 230.4mm
预设的最佳分辨率 1366 x 768 (60 Hz)
预设的最高分辨率 1366 x 768 (60 Hz)
即插即用 VESA DDC2B/CI
输入连接器 D-Sub 15 针
输入视频信号 模拟： 0.7Vp-p（标准），75 OHM
电源 100-240VAC, 50/60Hz
开机 < 25 W
功率消耗
离机 < 1 W
物理 特性
环境
连接器类型 15- 针 Mini D-Sub
信号电缆类型 可分离
尺寸和重量：
高度 (含底座) 357.9 mm
宽度 455.2mm
深度 219.7mm
重量（仅监视器） 3.53kg
重量（含包装） 4.86 kg
温度
工作时 0°- +40°
非工作时 -20°- +60°
湿度：
工作时 10% - 85%（非凝露）
非工作时 5% - 80%（非凝露）
海拔高度
工作时 0~3000m (0~10000 ft)
非工作时 0~5000m (0~15000 ft)
4
1.2 工厂预设模式
标准 分辨率 水平频率(kHZ) 垂直频率(Hz)
VGA 640 x 480 @60Hz 31.469 59.94
VGA 640 x 480 @67Hz 35 66.667
VGA 640 x 480 @72Hz 37.861 72.809
VGA 640 x 480 @75Hz 37.5 75
Dos-mode 640 x 400 @70Hz 31.469 70.087
Dos-mode 720 x 400 @70Hz 31.469 70.087
SVGA 800 x 600 @56Hz 35.156 56.25
SVGA 800 x 600 @60Hz 37.879 60.317
SVGA 800 x 600 @72Hz 48.077 72.188
SVGA 800 x 600 @75Hz 46.875 75
Mac-mode 832 x 624 @75Hz 49.725 74.5
XGA 1360 x 768 @60Hz 47.712 60.015
XGA 1024 x 768 @60Hz 48.363 60.004
XGA 1024 x 768 @70Hz 56.476 70.069
XGA 1024 x 768 @72Hz 57.5 72.074
XGA 1024 x 768 @75Hz 60.023 75.029
XGA 1024 x 768 @75Hz 60.241 74.927
WSXGA 1366 x 768 @60Hz 47.765 59.85
5
2.操作说明
2.1 控制面板
外部控制
按电源开关即可开关显示器。其它功能按键位于前面板下方 。通过调节这些功能键可得到您需要的画面。
* 接好电源线。
* 将信号线接到 PC 机显卡。
* 打开显示器把开关打到开机位置，电源指示灯亮。
1 亮度情景模式(动态对比度) / -
2 4:3/宽屏切换 /+
3 电源开关
4 自动调整 / 退出
5 菜单键/选择
6
2.2 接口说明
管脚号 信号电缆的 15 针一端 管脚号 信号电缆的 15 针一端
1 视频 - 红色 9 +5V
2 视频 - 绿色 10 接地
3 视频 - 蓝色 11 接地
4 接地 12 DDC- 串行数据
5 检测电缆 13 H- 同步
6 GND-R 14 V- 同步
7 GND-G 15 DDC- 串行时钟
8 GND-B
7
2.3 OSD 菜单调整
• 按 MENU 按钮激活 OSD 窗口。
• 按 + 或 - 浏览这些功能。 如果想要调整的功能突出显示，按 MENU 按钮激活它。如果所选的功能包含有子菜单，再
按一下 + 或 - 可以浏览到子菜单功能。如果想要调整的功能突出显示，按 MENU 按钮激活它。
• 按 + 或 - 更改所选功能的设置。要退出和保存，请选择退出功能。
• 如果您想调整其它任何功能，请重复步骤 2-3 。
• OSD 锁定功能： 要锁定 OSD ，请在显示器关闭时按住 MENU 按钮，然后按电源按钮打开显示器。 要解锁 OSD ，
请在显示器关闭时按住 MENU 按钮，然后按电源按钮打开显示器 。
• 亮度情景模式及动态对比度热键： 在画面没有 OSD 时，连续按此热键可选择不同的亮度情景应用模式及打开动态对比度
功能。
• 4:3 及宽屏画面切换热键 : 在画面没有 OSD 时, 连续按此键可进行 4:3 或宽屏显示模式切换(如果产品屏幕尺寸是 4:3 或
者输入信号的分辨率是宽屏模式时, 此键无作用)。
• 自动调整快捷键: 当没有 OSD 菜单时, 按自动调整快捷键可启动自动调整功能。
LED 指示灯
状态 LED 颜色
开机模式 绿色或蓝色
离机模式 橙色或红色
8
3.工厂模式调整
进入工厂模式方法：
机器应处于开机状态，先按住Menu键，再关断输入的电源，然后接通电源，工厂模式菜单将位于屏的左上角。
a.基本调整:
设置对比度 为 50。
设置亮度
为 90。
b.增益调整:
调整9300K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择9300K进行R G B增益调整
x = 283±30, y = 297 ±30, Y =180 ±30 cd/m
调整7300K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择7300K进行R G B增益调整
x = 302 ±30, y = 318 ±30, Y = 180 ±30 cd/m
调整6500K色温
2
2
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择 6500K 进行 R G B 增益调整
x = 313±30, y = 329 ±30, Y =180 ±30 cd/m
调整sRGB色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择 sRGB 进行 R G B 增益调整
x = 313±30, y = 329 ±30, Y =180 ±30 cd/m
2
c.调整完毕直接关闭电源。
2
9
4.故障处理流程
4.1 主板
无供电
无供电
按下电源键看画面是否正常
重新插插头然后检查 AC:100-240V 是否正常?
OK
检查 U404 Vout=3.3V,U405 Vout=1.8V
OK
检查 X401 晶振是否正常
OK
NG
NG
NG
NG
检查适配器及升压板部分和交流电源输入
检查或更换 CN404,U404,U405
更换 X401
更换 U401
10
无画 (LED 橙色)
G
无画
检查信号线
OK
检查 U404 Vout=3.3V,U405 Vout=1.8V
OK
N
检查 X401 震荡波是否正常
OK
检查 CN101 的 HS/VS 是否正常
NG
OK
更换信号线
更换 CN404,U404,U405
更换 X401
检查相关回路
更换 U401
11
白屏
白屏
检查 Q404 的基极是否
为低电平
OK
检查 FB402,Q404 是否
损坏或 CN405 虚焊
NG
OK
更换 PA NEL
检查相关元件
NG
检查 X401 的晶振是否
正常
NG
OK
检查 U401 复位电路是
否正常
NG
OK
更换 U401
更换 X401
检查相关元件
12
4.2 电源板
死机
检测交流电 100V or 240V 是否正常？
OK
NG
检测 C907 (+)的电压大小
NG
OK
检测 IC901 第 8 脚电压是否正常？
NG
OK
检测二次启动电压是否正常？
NG
OK
检测 AC 输入
检测全桥整流回路和 F901 回路
检测 R904,R932 或更换 IC901
1) 检测 IC901
2) 检测 D901/D903 回路
检测 IC901 第 5,6 脚的 PWM 波形
NG
OK
检测 D905,D906,D906,Q901,IC902,IC903,ZD902
检测 IC901
13
无背光
检测 C802(+)电压是否为 12V
NG
OK
检测 ON/OFF 信号
NG
OK
检测 IC801 第 8/11 脚是否为 12V
NG
OK
检测 IC801 第 9/10 脚的 PWM 波形
检测 Adapter 回路
检测主板
更换 IC801
NG
OK
检测 T801 的输出
NG
OK
检查接口或灯管,反馈和保护回路
检测 Q802
更换 T801
14
4.3 按键板
OSD 画面不稳定及不可调整
OSD 画面不稳定及不可调整
OK
按键板是否连接正常
OK
按键开关是否正常
OK
NG
连接好按键板
NG
替换按键开关
按键板是否正常
OK
检查主板
NG
替换按键板
15
5.电气方框图
5.1 主板
FLASH ROM
MX25L2026MI
(U402)
Crystal 24.576MHz
(X401)
Scalar IC HX6810
(Include ADC, OSD, MCU)
D-Sub Connector
(CN101)
(U401)
Panel Interface
(CN405)
Key Control Interface
(CN408)
16
5.2 电源板
AC input
EMI filter
Bridge
Rectifier
and Filter
Start Circuit:R904,R932
Transformer
(T901)
Rectifier
diodes
CN902
12V
PWM Control IC
LD7575A PS
(IC901)
Over
Voltage
Protect
Feedback
Circuit
5V
ON/OFF
Lamp
LC
Resonance
Transforme
MOSFET
(T801)
Feedback
Circuit
Over
Voltage
PWM
Control IC
ON/OFF
Control
DIM
17
6.线路图
6.1 主板
DB15
15
VGA_VS
14
VGA_HS
13
12
11
RXD3
R111
0R05 1/16W
SDA_VGA
SCL_VGA
U103
SDA_VGA
SCL_VGA
VGA_G
VGA_R VGA_B
AZC199-0 4S
1
I/O1
2
GND
I/O23I/O3
U102
AZC199-0 4S
1
I/O1
2
GND
I/O23I/O3
I/O4
VDD
I/O4
VDD
6
5
4
VGA_PLUG
6
5
4
VGA_HS
VGA_VS
10
5
9
4
8
3
7
2
6
1
17 16
CN101
R105 0R 05 1/10W 5%
R107
2K2 1/16W 5%
VGA_5V_S
C115
候綼
U103
VGA_5V_S
C114
候綼
U101
VGA INTERFACE
VGA PIN DEFIINITION
1 R_OUT 6 R_GND
2 G_OUT
3 B_OUT
4 TXD
5
VGA_PLUG
VGA_PLUG
VGA_5V
B_GND
VGA_B
G_GND
VGA_G
R_GND
VGA_R
R109 0R05 1/16W
R110 100R 1/16W 5%
R113 100R 1/16W 5%
C102
R108
22pF
2K2 1/16W 5%
NC
NC
7 G_GND
8 B_GND
9 +5V(DDC)
10 GND
R106 1K 1/16W 5%
R104 1K 1/16W 5%
C103
22pF
11 RXD
12 DDC SDA
13 TTL H-S
14 TTL V-S
15 DDC SCL
VGA_5V
TXD 3
ZD104
RLZ5.6B
VGA_SDA
VGA_SCL
VGA_H
VGA_V
S_5V
VGA_5V
VGA_5V
DET_CABLE_N3
VGA_DDCA_SDA 3
VGA_DDCA_SCL 3
HSYNC 3
VSYN C 3
D101
1
3
2
BAV70
U101
1
A0
2
A1
3
A2
VSS4SDA
M24C02-WMN6TP
VGA_PLUG
C116
VCC
WP
SCL
VCC3D3
VGA_5V_S
0.22uF
8
EDID_W P
7
VGA_SCL
6
VGA_SDA
5
FOR VGA DDC
R127
1K 1/16W 5%
R126
4K7 1/16W 5%
R123
R124
4K7 1/16W 5%
EDID _WP
Q101
LMBT3904LT1G
R125
4K7 1/16W 5%
VGA_R
R_GND
VGA_B
B_GND
VGA_G
G_GND
4K7 1/16W 5%
FB101
1 2
BEAD
FB102
1 2
BEAD
FB103
1 2
BEAD
R122
R112
R116
R114 10 0R 1/16W 5%
C111
NC
R115 10 0R 1/16W 5%
75R 1/16W 5%
75R 1/16W 5%
75R 1/16W 5%
R117 10 0R 1/16W 5%
C108
NC
R118 10 0R 1/16W 5%
R119 10 0R 1/16W 5%
C104
R121 39 0 OHM 1/16W
NC
R120 10 0R 1/16W 5%
C101 0.047uF
C105 0.047uF
C107 0.047uF
C109 0.047uF
C110 0.047uF
C106 1 000pF
C113 0.047uF
R3
GND_R 3
B3
GND_B 3
G3
SOG 3
GND_G 3
18
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
G3635-M0B-000-0040-1-090612
02.Input
Date
OEM MODEL
TBD
TPV MODEL
AOC 919Wx+ B
PCB NAME
G3635-M0B-000-004S
Sheet
of
26Tuesday , September 22, 200 9
Size
Rev
称爹
B
称爹
>
<
VCC3D3
ADC POWER 3.3V
VCC3D3
ADC PLL 3.3V
FB405
300 OHM
FB406
300 OHM
VCCK 1.8V
VCC1D8
FB407
300OHM
C441
10uF 10V
VCC3D3
FB408
300 OHM
C426
10uF 10V
3.3V -> 1.8V
FB409
NC
Q415
KN2907AS_NC
Q416
KN2907AS_NC
Q417
KN2907AS_NC
VCTRL
C449
0.1uF/16V_NC
VCC3IO
C425
0.1uF/16V
綼
GNDIO
VDDP_AD
C442
0.1uF/16V
VSSP_AD
VDDDP_AD
C443
0.1uF/16V
綼
IC PIN
VCCK
C444
0.1uF/16V
CLOSE IC PIN
VCC1D8
C448
IC PIN
VCCK
C453
0.1uF/16V
0.1uF/16V_NC
S_5V
R465
10K1/16W
AC_DET
POWER_KEY#
RESET X'TAL
S_5V
C456
1uF/16V
RST_N
R482
10K 1/16W 5%
R429
0R05 1/16W
C452
33pF
VCC3IO
XTAL_OUT
X401
GND
VCCK
1M 1/16W 5%
24.576MHz
R467 20K 1/16W
C450
0.1uF/16V
KEY1
KEY2
DET_CABLE_N2
VOL_PWM4
R484
X1 GROUND
SHIELDING
LVA1N5
LVA0P5
LVA0N5
MUTE4
VCTRL
XTAL_OUT
XTAL_IN
R413
NC
KEY1
R495100OHM1/16W
KEY2
R496100OHM1/16W
AC_DET
R489 100R 1/16W 5%
C451
33pF
XTAL_OUT
XTAL_IN
R497 0R05
RST_N
GNDIO
VCC3D3
CN408
CONN
CN409
NC/CONN
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
LVA3P5
LVA3N5
LVACKP5
LVACKN5
LVA2P5
LVA2N5
LVA1P5
U401
FRSB1N/LVA1N/ER 6
FRSB2P/LVA0P/ER 5
FRSB2N/LVA0N/ER 4
VCC3IO (3.3V)
GNDIO (0V)/GNDK (0V)
VCCK (1.8V)/VCCP (1.8V)
XTAL_OUT
XTAL_IN
GPIO06
VCTRL_1.8
SAR0
SAR1
SAR3
PWMC/GPI O11
PWMD/GPI O12
RST_N
GND_B2
B2
GND_G2
G2
SOG2
GND_R2
R2
FB404
NC
ZD401
NC/UDZSNP5.6B
1 2
6
5
4
3
2
1
7
6
5
4
3
2
TOUCH_POWER
1
40
42
46
48
45
41
43
44
47
FRSB0P/ LVA2P/EG1
FRSB1P/ LVA1P/ER7
FRSB0N/LV A2N/EG0
FRSG2N /LVACKN/ EG2
FRSG0P/LVB0P/EG7
FRSG1P/LVA3P/EG5
FRSG0N/LVB0N/EG6
FRSG1N/LVA3N/EG4
FRSG2P/LVACKP/EG3
HX6810_A00
GIN_N
BIN_P
BIN_N
3
2
1
TOUCH_POWER
C445
NC
ZD404
NC/UDZSNP5.6B
GIN_P4SOGIN
R421
NC
1 2
5
3.9K OHM 1/16W
NC/UDZSNP5.6B
VRP
RIN_N6RIN_P7HVSS_AD(0V)8VRN9PVDDD_AD/HVDD_AD(3.3V)11HSYNC
10
VRP
VRN
C457
C479
100N 16V
VCC3D3
R427
C413
C414
0.1uF/16V
0.1uF/16V
ZD402
NC/UDZSNP5.6B
1 2
Near to Connect
LVB0N 5
LVB0P 5
LVB1N 5
LVB1P 5
LVB2N 5
LVB2P 5
LVB3N 5
LVB3P 5
39
FRSCLKN/LVB1N/ EB0
0.1uF/16V
34
36
38
35
37
FRSR2P/LVB2P
FRSR0N/LVB3N
FRSR2N/LVB2N
FRSCLKP/ LVB1P
VSYNC
PVSSD_AD(0V)14FILT15PVDDA_AD(3.3V)
13
12
16
VSYNC 2
HSYNC 2
VDDDP_AD
R401 4K7 1/16W 5%
33
TSTMD
PWMB/GPIO10
FRSR0P/LVB3P
GPIO04/PWMC
GPIO03/PWMB
GPIO02/RS232_RX/GPIO30
GPIO01/RS232_TX/GPIO31
USRD_MSCL/GPIO16
USRD_MSDA/GPIO15
GPIO00/PWMD
DDCA_SCL/RS232_RX/GPIO30
DDCA_SDA/ RS232_TX/GPIO31
VDDP_AD
C455 0.01uF/25V
VDDP_AD
IC PIN
C454
綼
KEYPAD
R428
3.9K OHM 1/16W
KEY1
KEY2
POWER_KEY #
LED_GRN/BLUE
LED_ORANGE/TOUCH VCC
R487
C416
C415
ZD403
0.1uF/16V
1 2
10K 1/16W 5%
0.1uF/16V
LED_ORANGE/TOUCH VCC
GND
32
31
GPIO05
30
29
28
VCCK (1.8V)
0.1uF/16V
RS_RXD
27
RS_TXD
26
25
SDI
24
SCK
23
CSN
22
SDO
21
R459 NC
20
R490 NC
19
18
17
R402
1K6 OHM 1/16W 5%
R463 NC
R464 NC
R485 NC/ 1K
R486 NC/ 1K 1/16W 5%
C417
0.1uF/16V
FB410
NC
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
BL_ADJ 4
SPI_WP#
SPI_WP#
PANEL_ON/ OFF 5
BL_PW 4
VCCK
R403 NC
R404 NC
R491 0R05 1/16W
R476 0R05 1/16W
R441 0R05 1/16W
R446 0R05 1/16W
USRD_MSCL
USRD_MSDA
PANEL_ID # 4
POWER_KEY #
UDA_WP
UDA_WP
VGA_DDCA_SCL 2
KEY1
R493 NC
R494 NC
R488
10K 1/16W 5%
KEY2
VGA_DDCA_SDA 2
TOUCH_POWER
G3635-M0B-000-0040-1-090612
02.Input
LED_G
LED_O
RXD 2
TXD 2
SDI
SCK
CSN
SDO
CN406
1
2
3
4
5
6
7
8
NC/CONN
CN402
1
2
3
4
5
6
NC/CONN
CN407
1
2
3
4
5
6
7
NC/CONN
SPI FLASH
VCC3D3
R409
NC
C458
0.22uF16V
U402
1
8
CS#
VCC
2
7
DO
HOLD#
SPI_WP# SCK
3
6
WP#
CLK
5
VSS4DI
R410
MX25L2026MI-12G
10K 1/16W 5%
R471
SDO
10K1/16W
R474
NC
R472
CSN SCK
10K1/16W
R480NCR481
VCC3D3VCC3D3 VCC3D3
10K1/16W
NC
R473
Pull low to Pull high for Himax IC request
USER DATA
VCC3D3
C459
1
NC
0.22uF16V
2
E1
3
E2
VSS4SDA
M24C04-WMN6TP
R405
R448 10K 1/ 16W 5%
R408 NC
R406
2.2K1/16W
R492
R498
NC
36Tuesday, Sept ember 22, 2009
of
2.2K1/16W
Q402
LED_G
LED_O
10K 1/16W 5%
OEM MOD EL
TBD
TPV MOD EL
AOC 919Wx+ B
G3635-M0B-000-004S
PCB NAME
Sheet
U406
8
VCC
7
WC
6
SCL
5
S_5V
Q422
LMBT3906LT1G
R462 300R 1/10W 5%
R433 NC
R436 0R
LMBT3906LT1G
R499 330R 1/10W 5%
R4114K7 1/16W 5%
R4154K7 1/16W 5%
R4164K7 1/16W 5%
UDA_WP
USRD_MSCL
USRD_MSDA
LED_GRN/BLUE
VCC3D3
S_5V
LED_ORANGE/TOUCH VCC
Size
Rev
称爹
SDI
CSN
SDO
C
<
称爹
>
19
S_5V
CN404
9
8
7
6
5
4
3
2
1
CONN
S_5V S_5V
BKLT_EN
C427
NC
5V_SYS
5V_SYS
BKLT_VBRI
BKLT_EN
Volume
Mut e
R437
10K 1/16W 5%
Q406
2N3904S-R TK/PS
R440
4K7 1/16W 5%
5V_SYS
VOL_PWM 3
Mut e 3
R439
10K 1/16W 5 %
BL_PW 3
S_5V
NC
R400
PANEL_ID # 3
S_5V 2, 3,5
BKLT_VBRI
S_5V
R475
10K 1/16W 5%
R477
100R 1/1 6W 5%
BL_ADJ 3
C428
+
100uF M 16V
S_5V
3
C431
0.1uF/ 16V
R438
3.3 OHM 2W
C435
0.1uF/ 16V
U404
VIN
AP1117E33LA
1
U403
1
ADJ(GND)
2
VOUT
3
VIN
NC
VI3VO
U407
1
ADJ(GN D)
2
VOUT
3
VIN
NC
VSS
VOUT
4
U405
1
VCC3D3
2
4
VO
GND
C430
0.1uF/16V
2
4
C432
0.1uF/ 16V
C429
+
100uF M 16V
VCC1D8
+
VCC3D3 2,3
C434
100uF M 16V
20
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
G3635-M0B-000-0040-1-090612
02.Input
Date
OEM MODEL
TPV MODEL
PCB NAME
Sheet
TBD
AOC 919Wx + B
G3635-M0B-000-004S
of
46Tuesday , September 22, 20 09
Size
Rev
称爹
B
<
称爹
>
2006-11-7 Add pull up 4K7 to MVCC
4K7 1/16W 5%
PANEL_ON/ OFF3
R304
1K1/16W
22K to 1K,Q404 Base
drive current is not
enough
R308
C478
NC
R305
10K 1/16W 5%
R306 56K 1/16W
Q404
LMBT3906LT1G
C302
0.22uF16V
R307
NC
5V_SYS
Q405
AO3401
4
3
G
5
120OHM
S1S2S
D8D7D6D
FB402
Q401
NC/ AO4411
PANEL_VCC
C305
+
100UF25V
PANEL_VCC
R435
330 OHM 1/ 4W
PANEL_VC C
CN405
1
3
PA1
PB3
PA5
PA7
PB1
PB3
PB5 PB4
PB7
PB9
5
7
9
11
13
15
17
19
21
23
25
27
29
NC
LVDS OUTPUT
C436
0.1uF/ 16V
LVB3P3
LVB3N3
LVACKP3
LVACKN3
LVB2P3
LVB2N3
LVB1P3
LVB1N3
LVB0P3
LVB0N3
LVA3P3
LVA3N3
LVACKP3
LVACKN3
LVA2P3
LVA2N3
LVA1P3
LVA1N3
LVA0P3
LVA0N3
PA0
PA1
PB2
PB3
PA4
PA5
PA6
PA7
PA8
PA9
PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PB8
PB9
2
4
6
PA0
8
PB2
10
PA4
12
PA6
14
PA8PA9
16
PB0
18
PB2
20
22
PB6
24
PB8
26
28
30
CN403
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
G3635-M0B-000-0040-1-090612
02.Input
21
OEM MO DE L
TPV MODEL
PCB NAME
Sheet
CONN
TBD
AOC 919Wx + B
G3635-M0B-000-004S
56Tuesday , September 22, 2009
of
Size
Rev
称爹
<
A4
称爹
>
6.2 电源板
!
2
BD901
KBP208G
0.22UF
!
C902
1000pF
!
0.22UF
!
680K OHM 1/4W
R900
680K OHM 1/4W
NR901
NTCR
!
t
CN901
SOCKET
87G 501 32 S
1
+
-
4
C904
2
1
C908
R902
!
VAR901
Varistor
N.C
3
C901
1000pF
3
L901
30mH
4
12
3
!
!
!
!
R901
680K OHM 1/4W
!
!
!
+
R915
100K OHM 1% 1/8W
0.01uF
!
F901
FUSE
C907
82uF 450V
NC
C911
0.1uF
C928
HEAT SINK(D906_Q90G6263-6)
HEAT SINK(Q901_Q90G6263-6)
1
2
HS3
C938
1
2
3
1
2
1
2
RT
COMP
CS
GND4OUT
GND1
GND
HS2
R904
10K OHM 1/4W
R932
10K OHM 1/4W
IC901
HV
NC
VCC
LD7575A PS
R918
100 OHM 1/4W
R919
100 OHM 1/4W
R920
100 OHM 1/4W
!
T901
POWER X'FMR
43
!
9
10
7
8
11
12
12
IC902
PC123X2YFZOF
IC903
AZ431AZ-AE1
R921
R922
R923NC
R961 100 OH M 1/4W
R962 100 OH M 1/4W
R935 100 OH M 1/4W
C924
0.1uF
4
5
6
2
1
C900
3300pF 250V
R905
NC
R906
NC
D901
FR103
C903
+
22uF/50V
R907
NC
D903
LL4148
8
7
6
5
R910
10R 1/4W
ZD905
RLZ18B
R912
220 OHM 1/4W
C909
470pF/25V
HS5
SHIELD(H 85G0002-1)
1
2
1 2
C906
1500pF2KV
R938
10K 1/8W
R908
100KOHM + -5% 2WS
D900
FR107
R909
5.1 OHM 1/4W
!
Q901
2SK2645-54MR
R914
0.47 OHM +- 5% 2WS
C912
0.001uF
2
1
3
D906
FCH 10U10
D907 NC
NC
NC
D905 31DQ06FC3
C929
0.001uF
R925
1K 1/8W
R926
1K 1/10W 1%
C925
NC
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
C917
680uF/25V
C910
NC
+
+
2.POWER
L904
1.0uH
+
C918
680uF/25V
L905
NC
C921
NC
C939
+
NC
C940
1000uF16V
R924
150R 1/8W
2.43K OHM 1% 1 /10W
G2852-3-4-X-6-090818
+
NC
L903
1.0uH
RLZ5.1B
LL4148
1K 1/10W 1%
+
R948
NC
Q904
ZD922
D916
C922
470PF50V
R942
R930
ZD923
NC
1 2
OEM MODEL
TPV MODEL
PCB NAME
Sheet
R946
150 OHM 2W
Q903
PMBS3904
1 2
R947
NC
R952
NC
MUTE
VOL
+5V
DIM
R940
33K 1/10W
470uF/16V
0.1uF
ZD921
RLZ13B
1 2
R927
3.6K OHM 1% 1/ 10W
D915
LL4148
ON/OF F
F19S
PWPC9821GHD 1 A
715G2852-3-4
24Tuesday, August 18, 2009
of
C931
C932
C915
0.001uF
+
1 2
R943
470R 1/8W
R939
1K 1/8W
NC
Size
Rev
称爹
ZD902
RLZ13B
F902
NC
F904
F903
NC
F905
0 OHM 1/4W
C930
0.1uF
CN902
1
2
3
4
5
6
7
8
9
10
CONN
Custom
ODM MODEL
+12V
+5V1
+5V
22
ON/OFF
1
2
D801
BAV99
D802
BAV99
CONN
CN801
2
1
1
2
CONN
CN802
2
1
C839
1500PF/50V
R855
+12V
DIM
F801
0 OHM 1/4W
Q805
PDTC144WK
C807
0.1uF/25V
R804
100R 1/8W
Q808
PDTA144WK
C825
0.1uF/25V
PMBS3904
Q804
PMBS3906
Q801
23
1
Q811
PMBS3904
D810
NC
R839
22R 1/8W
D811
NC
C802
470PF50V
C824
+
0.1uF
Q802
AM9945N-T1-PF
1
S
2
G
3
S
4
G
15R 1/4W
R856
15R 1/4W
8
D
C838
7
D
1500PF/50V
6
D
5
D
POWER X'FMR
6
3
4
T801
7
C801
30pF/3KV
81
C803
30pF/3KV
D807
LL4148
D805
LL4148
C819
0.0022uF
C823
0.0022uF
R817
10K 1/10W 1%
R828
10K 1/10W 1%
R821
1K 1/8W
3
R801
1K5 1/10W 1%
R822
1K 1/8W
3
R814
1K5 1/10W 1%
D817
LL4148
6K8 1/10W
10K 1/10W 1%
R827
1K 1/10W 1%
R851
R830
NC
R820
R802
8.2K 1/10W 1%
C822
1uF/25V
D812
LL4148
10K 1/10W 1%
Q806
PMBS3904
C842
0.01uF
R863
C835
NC
R832
10K 1/10W 1%
R831
1K 1/8W
R823
0R05 1/10W 5%
C821
0.1uF/25V
51K OHM 1% 1/8W
R810
C820
220pF50V
PMBS3906
R865
NC
新增
Q812
1
R861
NC
Q807
N.C
23
R853
68K 1/10W
R850
22R 1/8W
R841
68K OHM 1% 1/10W
R829
22R 1/8W
R825
22R 1/8W
R837
47K 1/8W
R824
1K 1/10W 1%
R807
10K 1/10W 1%
R808
10K 1/10W 1%
C845
2.2uF/16V
R862
1M 1/10W 5%
R803
680K 1/10W
D814
LL4148
C834
0.1uF/25V
G2852-3-4-X-6-090818
3.INVERTER
D806
LL4148
R835
1M 1/10W 5%
F19S
OEM MODEL
TPV MOD EL
PWPC9821GHD1 A
PCB NAME
715G2852-3-4
34Tuesday, Augus t 18, 2009
Sheet
of
Custom
Size
Rev
ODM MO DEL
称爹
R818
1K 1/10W 1%
Q809
RK7002
C846
NC
T P V ( Top Victory Electronics Co . , Ltd. )
絬 隔 瓜 絪 腹
Key Component
Date
TL494IDR
IC801
1
1IN+
2
1IN-
3
FEEDBACK
4
DTC
5
CT
6
RT
7
GND
8
C1
R864
NC
穝糤
C817
NC
OUTPUT CTRL
R854
NC
16
2IN+
15
2IN-
14
REF
13
12
VCC
11
C2
10
E2
9
E1
R826
1K 1/8W
23
7.料件清单
注意：以下料件信息仅供参考，如有变更，恕不另行通知，请到 http://cs.tpv.com.cn 获取最新信息。
T89AHENDW5A4NNE
点位 组件 对象描述 备注
026G 800504 H BARCODE
040G 58162435A P/N LABEL FOR MANUAL PE BAG
052G 1150 C INSULATING TAPE
052G 1186 SMALL TAPE
052G 1207 A
052G 1211 B
052G6019 1 INSULATING TAPE
E08902 089G 715HAAE01 SIGNAL CABLE
E08901 089G414A15N HL POWER CORD 1.5M
E09502 095G8014 6TE01 HARNESS 6P-6P 160MM
E09503 095G8018 3TH55 HARNESS 30P-30P 140MM
0D1G1730 8120 SCREW
0M1G1740 12120 SCREW 42-D021241
705GH934056 18.5 STAND ASS'Y
E750 750GLU185X1854N000 PANEL M185XW01 V80D SH AUO
E750 750GLU185X1864N000 PANEL M185XW01 V80E SH AUO 2nd source
H15G0023701 MAIN FRAME
H40G 18N615 8C ID LABEL
H40G 58169018A CEL-2 LABEL
H40G 582615 1B CARTON LABEL
Conductive Tape 45mm *25mm *0.08mm (单导）
Conductive Tape 85mm *40mm *0.09mm (单导)
H40G 58261546A BASIC SILVE LABEL
H41G7800615 7F WARRANTY BOOKLIST
H41G780061592A 931SwI QSG BLACK
H44G9903615 1C 931SWl CARTON
H45G 77 6 PE PACKING
H45G 87 1 4H A EPE COVER
H70G200961517C 931Swl CD MANUAL
J44G9903101 EPS CUSHION
J44G9903201 EPS CUSHION
KEPC9HAC KEY BAORD
PWPC9821GHD1 POWER BAORD
Q33G0188AED 1L0100 key pad
Q33G0189 1 1C0100 LENS
Q34G0358BBM 1B0100 LOGO LOOP
Q34G0452AEDB2B0130 BEZEL18.5"
24
Q34G0453ABJA6B0100 REAR COVER18.5"
Q34G0455AED 1B0100 STAND COVER
Q45G 76 28 H A PE BAG FOR MANUAL
Q50G 4 10 TIE (Y1900221)
Q52G 1185 99 big carton tape for aoc
0Q1G1030 8120 SCREW
Q01G6022 2 SCREW
Q34G0360AED 1B0130 BASE
Q34G0454AED 1B0100 STAND
Q37G0101011 HINGE(AOC 831Sw)
756GH9CB A1095 MAIN BOARD-CBPC9HEE1H1
SMTCR-U402 100GAHA8005W11 MCU ASS'Y-056G1133137
CN408 033G3802 6B Y L WAFER
CN404 033G3802 9B Y L CONN 2.0 9P
CN405 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE
040G 45762412B CBPC LABEL
R438 061G152M33964L SY RST MOFR 3.3 OHM +-5% 2WS SHANG YU
CN101 088G 35315F HD D-SUB CONN F ATTACHED SCREW
X401 093G 2270B H XAT024576FK1H-3OHX AT-49 24.576MHZ
CN001 033G3802 6H L CONNECTOR 6PIN
SW005 077G 602 1A CJ TACT SWITCH
SW004 077G 602 1A CJ TACT SWITCH
SW003 077G 602 1A CJ TACT SWITCH
SW002 077G 602 1A CJ TACT SWITCH
SW001 077G 602 1A CJ TACT SWITCH
LED001 081G 122CT GH
Φ3 黄蓝双色弯脚型 LED
CN802 033G8021 2E F WAFER
CN801 033G8021 2E F WAFER
040G 45762412B CBPC LABEL
IC902 056G 139 3A IC PC123Y22FZ0F
NR901 061G 58080 WT 8 OHM NCT
C908 063G107K224 UM X2 CAP 0.22uF K 275VAC
C904 063G107K224 UM X2 CAP 0.22uF K 275VAC
C801 065G 3J3006ET 30PF 5% SL 3KV TDK
C803 065G 3J3006ET 30PF 5% SL 3KV TDK
C901 065G305M1022BP Y2 1000PF M 250VAC Y5P
C902 065G305M1022BP Y2 1000PF M 250VAC Y5P
C900 065G306M3322BP 3300PF 20%
C907 067G 40Z82015K EC 82uF M 450V 18*35mm
C802 067G215D4714KV
E.C 105℃ CAP 470UF M 25V ED SERIES
25
C940 067G215P1023XV
CAP 105℃ 1000UF M 16V
C922 067G215P4714AV
CAP 105℃ 470UF M 25V
C918 067G215P6814XV CAP 105C 680UF M 25V
C917 067G215P6814XV CAP 105C 680UF M 25V
C915 067G215S4713KV
EC 105℃ CAP 470UF M 16V
L904 073G 253 91 V1 CHOKE COIL 1.1uH
L903 073G 253 91 V1 CHOKE COIL 1.1uH
L901 073L 174 40 HG GBQM4.778.391
CN901 087G 501 32 S AC SOCKET
D905 093G 60519 DIODE SR560 5A/60V DO-27 SECOS
CN902 095G 82510TE12 HARNESS 10P-9P 120MM
705GQ857020 Q901 ASS'Y
705GQ893028 D906 ASS'Y
PW9821MHD3SMT POWER BOARD FOR SMT
T801 S80GL17T40V Transformer
T901 S80GL19T26V Transformer ASS'Y
R908 061G152M10452T RST MOFR 100KOHM +-5% 2WS
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON
C428 067G 3051013PB
C429 067G 3051013PB
C434 067G 3051013PB
EC 105℃ 100uF M 16V 5*11mm
EC 105℃ 100uF M 16V 5*11mm
EC 105℃ 100uF M 16V 5*11mm
C305 067G 3151014KB EC 100uF M 25V 6.3*11
U401 056G 562596 IC HX6810-A05MLAG 1680*1050 LQFP-64
U405 056G 56327A IC AP1117E18LA SOT223-3L ANACHIP
U404 056G 585 4A IC AP1117E33L-13
U102 056G 662502 IC ESD AZC199-04S SOT23-6L
U103 056G 662502 IC ESD AZC199-04S SOT23-6L
U406 056G1133 32 IC M24C04-WMN6TP SO8
U101 056G1133 34 M24C02-WMN6TP
U402 056G1133137 IC MX25L2026MI-12G SOP-8
Q406 057G 417 12 T KEC 2N3904S-RTK/PS
Q402 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q404 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q422 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q101 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q405 057G 763 1 A03401 SOT23 BY AOS(A1)
R497 061G0402000 RST CHIP MAX 0R05 1/16W
R491 061G0402000 RST CHIP MAX 0R05 1/16W
R476 061G0402000 RST CHIP MAX 0R05 1/16W
R446 061G0402000 RST CHIP MAX 0R05 1/16W
26
R441 061G0402000 RST CHIP MAX 0R05 1/16W
R436 061G0402000 RST CHIP MAX 0R05 1/16W
R429 061G0402000 RST CHIP MAX 0R05 1/16W
R111 061G0402000 RST CHIP MAX 0R05 1/16W
R109 061G0402000 RST CHIP MAX 0R05 1/16W
R489 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R477 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R120 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R119 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R118 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R117 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R115 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R114 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R113 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R110 061G0402101 RST CHIPR 100 OHM +-5% 1/16W
R496 061G0402101 JY RST CHIPR 100 OHM +-5% 1/16W YAGEO
R495 061G0402101 JY RST CHIPR 100 OHM +-5% 1/16W YAGEO
R127 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R104 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R106 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W
R304 061G0402102 JY RST CHIPR 1KOHM +-5% 1/16W YAGEO
R492 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R488 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R487 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R482 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R475 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R448 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R439 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R437 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R410 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R305 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W
R465 061G0402103 JY RST CHIPR 10KOHM +-5% 1/16W YAGEO
R473 061G0402103 JY RST CHIPR 10KOHM +-5% 1/16W YAGEO
R472 061G0402103 JY RST CHIPR 10KOHM +-5% 1/16W YAGEO
R471 061G0402103 JY RST CHIPR 10KOHM +-5% 1/16W YAGEO
R484 061G0402105 RST CHIPR 1MOHM +-5% 1/16W
R402 061G0402162 RST CHIP 1K6 1/16W 5%
R467 061G0402203 JY RST CHIPR 20KOHM +-5% 1/16W YAGEO
R107 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
R108 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W
27
R406 061G0402222 JY RST CHIPR 2.2KOHM +-5% 1/16W YAGEO
R405 061G0402222 JY RST CHIPR 2.2KOHM +-5% 1/16W YAGEO
R121 061G0402390 0F RST CHIP 390R 1/16W 1%
R427 061G0402392 RST CHIP 3.9K 1/16W 5%
R428 061G0402392 RST CHIP 3.9K 1/16W 5%
R440 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R416 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R415 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R411 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R401 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R308 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R126 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R125 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R124 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R123 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W
R306 061G0402563 JY RST CHIPR 56KOHM 1/16W YAGEO
R112 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R116 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R122 061G0402750 RST CHIPR 75 OHM +-5% 1/16W
R105 061G0603000 RST CHIP MAX 0R05 1/10W
R462 061G0603301 RST CHIPR 300 OHM +-5% 1/10W
R499 061G0603331 RST CHIP 330R 1/10W 5%
R435 061G1206331 RST CHIPR 330 OHM +-5% 1/4W
C106 065G0402102 32 1000PF +-10% 50V X7R
C457 065G040210232K A CAP 0402 1NF K 50V X7R
C455 065G0402103 32 0.01uF +-10% 16V X7R
C435 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C436 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C442 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C443 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C444 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C450 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C453 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C454 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C432 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C431 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C430 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C425 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C417 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C416 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
28
C415 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C414 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C413 065G040210412K A CAP CHIP 0402 100nF K 16V X7R
C103 065G0402220 31 CHIP 22PF 50V NPO
C102 065G0402220 31 CHIP 22PF 50V NPO
C302 065G0402224 17 CAP CER 0.22UF -20%-80%
C458 065G0402224 17 CAP CER 0.22UF -20%-80%
C459 065G0402224 17 CAP CER 0.22UF -20%-80%
C451 065G0402330 31 CHIP CAP 0402 33pF J 50V NPO
C452 065G0402330 31 CHIP CAP 0402 33pF J 50V NPO
C113 065G0402473 12 CHIP 0.047uF 16V X7R
C110 065G0402473 12 CHIP 0.047uF 16V X7R
C109 065G0402473 12 CHIP 0.047uF 16V X7R
C107 065G0402473 12 CHIP 0.047uF 16V X7R
C105 065G0402473 12 CHIP 0.047uF 16V X7R
C101 065G0402473 12 CHIP 0.047uF 16V X7R
C456 065G0805105 22 CAP CHIP 0805 1uF K 25V X7R
C426 065G0805106A5K T CHIP 10uF 10V X5R 0805
C441 065G0805106A5K T CHIP 10uF 10V X5R 0805
FB402 071G 56K121 M CHIP BEAD
FB407 071G 56V301 B CHIP BEAD FCM2012VF-301T07 bullwill
FB406 071G 59G301 CHIP BEAD 300OHM
FB408 071G 59G301 CHIP BEAD 300OHM
FB405 071G 59G301 CHIP BEAD 300OHM
FB101 071G 59K190 B 19 OHM BEAD
FB102 071G 59K190 B 19 OHM BEAD
FB103 071G 59K190 B 19 OHM BEAD
D101 093G 64 42 PP BAV70 SOT-23
ZD104 093G 39GA01 T RLZ5.6B
715G3635M01000004F MAIN BOARD PCB
R003 061G0603000 RST CHIP MAX 0R05 1/10W
R005 061G0603102 RST CHIPR 1K OHM +-5% 1/10W
R002 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
R004 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
J001 061G1206000 RST CHIP MAX 0R05 1/4W
J002 061G1206000 RST CHIP MAX 0R05 1/4W
715G2991 2 KEY BOARD PCB
Q901 057G 667 51 FET 2SK4101LS 7A/650V TO-220FI(LS)
0M1G 930 8120 SCREW
HS3 Q90G6263 6 HEAT SINK
29
D906 093G 60267 SP10100
0M1G 930 8120 SCREW
HS2 Q90G6263 6 HEAT SINK
IC801 056G 379 22 IC TL494IDR SOIC-16
IC901 056G 379107 IC LD7575A PS SOP-8
Q804 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q812 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC
Q801 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q806 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q807 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q811 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q903 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC
Q809 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM
Q808 057G 760 4A DTA144WN3/S SOT-23
Q805 057G 760 5A DTC 144WN3/S SOT-23
Q802 057G 763 6 AO4828 SOIC-8 BY AOS
R823 061G0603000 RST CHIP MAX 0R05 1/10W
R942 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R926 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R827 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R824 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R818 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R863 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R832 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R828 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R820 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R817 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R808 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R807 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W
R862 061G0603105 RST CHIPR 1M OHM +-5% 1/10W
R801 061G0603150 1F RST CHIPR 1.5 KOHM +-1% 1/10W
R814 061G0603150 1F RST CHIPR 1.5 KOHM +-1% 1/10W
R930 061G0603243 1F RST CHIPR 2.43K OHM +-1% 1/10W
R940 061G0603330 2F RST CHIPR 33K OHM +-1% 1/10W
R927 061G0603360 1F RST CHIPR 3.6K OHM +-1% 1/10W
R861 061G06034753FF RST CHIPR 475KOHM +-1% 1/10W FENGHUA
R851 061G0603680 1F RST CHIPR 6.8 KOHM +-1% 1/10W
R841 061G0603680 2F RST CHIPR 68K OHM +-1% 1/10W
R853 061G0603683 RST CHIPR 68K OHM +-5% 1/10W
R854 061G0603683 RST CHIPR 68K OHM +-5% 1/10W
30
R803 061G0603684 RST CHIPR 680 KOHM +-5% 1/10W
R802 061G0603820 1F RST CHIPR 8.2 KOHM +-1% 1/10W
JR902 061G0805000 RST CHIP MAX 0R05 1/8W
R822 061G0805100 1F RST CHIPR 1K OHM +-1% 1/8W
R821 061G0805100 1F RST CHIPR 1K OHM +-1% 1/8W
R831 061G0805100 1F RST CHIPR 1K OHM +-1% 1/8W
R915 061G0805100 3F RST CHIPR 100KOHM +-1% 1/8W
R804 061G0805101 1ST CHIPR 100 OHM +-5% 1/8W
R939 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R826 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R925 061G0805102 RST CHIPR 1K OHM +-5% 1/8W
R938 061G0805103 RST CHIPR 10K OHM +-5% 1/8W
R924 061G0805151 RST CHIPR 150 OHM +-5% 1/8W
R850 061G0805220 RST CHIPR 22 OHM +-5% 1/8W
R839 061G0805220 RST CHIPR 22 OHM +-5% 1/8W
R829 061G0805220 RST CHIPR 22 OHM +-5% 1/8W
R825 061G0805220 RST CHIPR 22 OHM +-5% 1/8W
R943 061G0805471 RST CHIPR 470 OHM +-5% 1/8W
R837 061G0805473 RST CHIPR 47K OHM +-5% 1/8W
R810 061G0805510 2F RST CHIPR 51K OHM +-1% 1/8W
JR801 061G1206000 RST CHIP MAX 0R05 1/4W
F801 061G1206000 4 RST CHIP MAX 0R05 1/4W
F905 061G1206000 4 RST CHIP MAX 0R05 1/4W
R910 061G1206100 RST CHIPR 10 OHM +-5% 1/4W
R918 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R919 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R920 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R935 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R961 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R962 061G1206101 RST CHIPR 100 OHM +-5% 1/4W
R904 061G1206103 RST CHIPR 10K OHM +-5% 1/4W
R932 061G1206103 RST CHIPR 10K OHM +-5% 1/4W
R856 061G1206150 RST CHIPR 15 OHM +-5% 1/4W
R855 061G1206150 RST CHIPR 15 OHM +-5% 1/4W
R912 061G1206221 RST CHIPR 220 OHM +-5% 1/4W
R909 061G1206519 RST CHIPR 5.1 OHM +-5% 1/4W
R900 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R901 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
R902 061G1206684 RST CHIPR 680K OHM +-5% 1/4W
C932 065G0603102 32 1000PF +-10% 50V X7R
31
C842 065G0603103 32 CAP CHIP 0603 0.01UF K 50V X7R
C834 065G0603103 32 CAP CHIP 0603 0.01UF K 50V X7R
C825 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R
C821 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R
C807 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R
C823 065G0603222 32 CHIP 2200PF 50V X7R
C819 065G0603222 32 CHIP 2200PF 50V X7R
C928 065G0805103 32 CAP CHIP 0805 10NF K 50V X7R
C824 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R
C911 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R
C924 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R
C930 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R
C931 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R
C822 065G080510522K 3 CAP CHIP 0805 1U 25V X7R +/-10%
C838 065G0805152 31 1.5nF/50V
C839 065G0805152 31 1.5nF/50V
C820 065G080522131G CAP CHIP 0805 220PF G 50V NPO
C845 065G080522512K 3 CAP CHIP 0805 2U2 16V X7R +/-10%
C909 065G0805471 31 CHIP 470PF 50V NPO
C929 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R
C912 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R
D802 093G 6433L DIODE LBAV99LT1G SOT-23 LRC
D801 093G 6433L DIODE LBAV99LT1G SOT-23 LRC
ZD922 093G 39GA26 T ZENER DIODE RLZ5.1B SEMTECH
ZD921 093G 39GA28 T ZENER DIODE RLZ13B SEMTECH
ZD902 093G 39GA28 T ZENER DIODE RLZ13B SEMTECH
ZD905 093G 39GA31 T ZENER DIODE RLZ18B SEMTECH
D812 093G 64S522SEM LL4148
D805 093G 64S522SEM LL4148
D806 093G 64S522SEM LL4148
D807 093G 64S522SEM LL4148
D916 093G 64S522SEM LL4148
D814 093G 64S522SEM LL4148
D817 093G 64S522SEM LL4148
D903 093G 64S522SEM LL4148
D915 093G 64S522SEM LL4148
709G2852 HS001 CONSUMPTIVE ASS'Y
PW8521VYD2AI POWER BOARD FOR AI
052G 2191 A PAPER TAPE
CN901 006G 31500 EYELET
32
IC903 056G 158 10 T IC AS431AZTR-E1 TO-92
R946 061G152M15152T RST MOFR 150 OHM +-5% 2WS
R914 061G152M47852T RST MOFR 0.47 OHM +-5% 2WS
C906 065G 2K152 2T6921 CAP CER 1500pF K 2KV Y5P
C903 067G 2152207NT KY50VB22M-TP5 5*11
F901 084G 56 3 B FUSE 3.15A 250V
D900 093G 6026T52T RECTIFIER DIODE FR107
D901 093G 6038T52T FR103
J903 095G 90 23 C JUMP WIRE
J901 095G 90 23 C JUMP WIRE
J813 095G 90 23 C JUMP WIRE
J812 095G 90 23 C JUMP WIRE
J811 095G 90 23 C JUMP WIRE
J809 095G 90 23 C JUMP WIRE
J807 095G 90 23 C JUMP WIRE
J806 095G 90 23 C JUMP WIRE
J805 095G 90 23 C JUMP WIRE
J904 095G 90 23 C JUMP WIRE
J906 095G 90 23 C JUMP WIRE
J907 095G 90 23 C JUMP WIRE
J908 095G 90 23 C JUMP WIRE
J909 095G 90 23 C JUMP WIRE
J910 095G 90 23 C JUMP WIRE
J911 095G 90 23 C JUMP WIRE
J912 095G 90 23 C JUMP WIRE
J914 095G 90 23 C JUMP WIRE
J804 095G 90 23 C JUMP WIRE
J803 095G 90 23 C JUMP WIRE
J802 095G 90 23 C JUMP WIRE
J801 095G 90 23 C JUMP WIRE
709G2852 HA001 CONSUMPTIVE ASS'Y
715G2852 3 4 POWER BOARD PCB
095G 90 23 JUMPER WIRE
33
Loading...
