AOC 27B2H User Manual

27B2H

27 inch (60.4 cm) LCD MONITOR

Sleek and super-thin design, flexible inputs, large 27"
IPS panel with popping colours and eye-saving
features

IPS Panel

No matter if you are viewing photos, videos, a magazine layout in InDesign or playing your favourite game – we want
your content to look excellent from whatever angle you are seeing it. That is why this display comes with an
advanced IPS panel, which produces brilliant colours and offers wide viewing angles. This way, images always look
excellent and accurate, regardless from which angle you – or your friends and co-workers sitting or standing next to
you – are looking at the screen.

HDMI

HDMI (High-Definition Multimedia Interface) is supported by the current gaming consoles, current GPUs, set-top
boxes, supporting the HDCP digital content protection system. HDMI 1.3-1.4b versions support up to 144 Hz refresh
rate@1080p and 75 Hz@1440p, while HDMI 2.0-2.0b versions support 240Hz@1080p, 144Hz@1440p and 60
Hz@2160p (4K).

Lowblue Light

AOC Lowblue Light protects you from harmful blue light which, during long sessions, has been shown to cause eye
strain, headaches, and sleeping disorders. Our Lowbue Light feature reduces the harmful wavelengths emitted
without sacrificing color composition, setting the experience free from the worry of eye damage.

Frameless

Besides looking modern and attractive, frameless designs enable seamless multi-monitor setups. Your
cursor/windows will not be lost anymore in the dark abyss of bezels, when many displays are placed side by side.

27B2H Lifestyle

General

CartonDimensions 492x614x131 mm

Screen Details

Color Black

Resolution 1920x1080

Refresh rate 75Hz

Response time 7 ms

Panel IPS

Backlight WLED

sRGB Coverage (%) 0

flickerfree ✔

Aspect ratio 16:9

Brightness (typical) 250 cd/m²

Contrast (dynamic) 20M:1

Contrast (static) 1000:1

Pixel Pitch (H) (V) 0.3114

Diagonal (inch) 27 inch

Active Screen Area (HxW) 527,04x296,46 mm mm

Viewing angle (CR10) 178/178 º

Display Colours 16.7 Million

Weight without stand 2.18 kg

Scanning Frequency 30 -83kHz (H) / 50 -76 Hz (V)

Adobe RGB Coverage (%) 0

OSD languages EN, FR , ES, PT, DE, IT, NL, SE, FI,

PL ,CZ, RU, KR, CN (T), CN (S), JP

Connections

Signal Input HDMI 1.4 x 1, VGA

USB input 0

Audio output Headphone out (3.5mm)

What's in the box

HDMI cable (1.5 m), Power Cable C13 (1.5m m),

Sustainability

• Environmental and energy: RoHS, Lead-free, Mercury Free

• Recyclable packaging material: 100 %

Ergonomics

Tilt -3.5/21.5 °

Power details

Powersupply Internal

Powersource 100 - 240V 50/60Hz

Power Consumption On 22 watt, Off 0.5 watt

Standby 0.5 watt,

Dimensions

Product Dimensions (incl base) 419.8x540.1x186.8 mm

CartonDimensions 492x614x131 mm

Net Weight (excl package) 2.7 Kg

Gross Weight (incl package) 4.5 Kg

Warranty

Warranty Period 3 Years

EAN 4038986187183

MTBF 50.000 hours

Regulations

TUV-GS 1, FCC 1, EAC 1, Reach compliant 1,
