Anton-Bauer INTERACTIVE 2000 2400, INTERACTIVE 2000 2700 User Manual

®

PowerCharger

DUAL and QUAD

2400 and 2700 series

OWNER’S MANUAL

TABLE OF CONTENTS

INTRODUCTION.............................................................................................1

STANDARD FEATURES.................................................................................1

EXPANSION OPTIONS ..................................................................................2

SAFEGUARDS................................................................................................3

GROUNDING/EARTHING...............................................................................3

FUSE TYPE/REPLACEMENT.........................................................................3

OPERATION....................................................................................................3

Self-Test.......................................................................................................3

Charging.......................................................................................................4

Applications..................................................................................................4

Three Stage Charging Methodology............................................................5

LCD Indications............................................................................................6

LED Indications............................................................................................7

Priority Battery Function...............................................................................8

DDM (DIAGNOSTIC/DISCHARGE MODULE)................................................8

To Operate The PowerCharger with DDM...................................................9

“AUTOCAL” Feature ..................................................................................10

XM CHARGE EXPANSION MODULE ..........................................................11

OPERATION AS DC CAMERA SUPPLY FROM MAINS .............................11

POWER LOSS MEMORY MODE .................................................................12

FCC NOTICE.................................................................................................12

WARRANTY..................................................................................................13

INTRODUCTION

This Anton/Bauer InterActive 2000 PowerCharger represents over 25 years of Anton/Bauer
technology and experience in a totally new portable power system. The technology
advancements of this new combination, charger/camera power supply, delivers the features
and performance of several essential power products in one economical package.

Fully compatible with all current and future Anton/Bauer Logic Series Gold Mount
batteries, the InterActive 2000 system is a totally new modular platform. PowerChargers
deliver all the advancements and proven reliability of InterActive charging , plus the ability
to power a camera from AC mains. Its unique m odular design allows econom ical expansion
to meet future operational needs and technological development s.

Because the PowerCharger is completely software controlled, as new technology batteries
are introduced, the PowerCharger will merely require a new programming chip to charge the
new batteries along side your existing ones.

The unprecedented value and unique features of the InterActive 2000
PowerCharger system has redefined the standard of power for all video operations

- from individual videographers to the largest broadcast operation.

STANDARD FEATURES

• Two and Four Position models each with the full complement of InterActive

technologies including: six simultaneous charge termination systems, SSP (Selective
Sequence Programming), balance and rejuvenation mode, Lifesaver Maintenance
mode, Power Loss Memory mode.

• Multifunction LCD displays critical battery and charger data automatically.

• Regulated DC power supply output for camera operation from AC mains,

eliminating the need for a separate bulky power supply.

• Wide range mains input compatibility (90-250 VAC 50-60 Hz) automatically adapts

to any mains source worldwide.

• Modular design allows addition of expansion options.

• Expanded InterActive communications with DIGITAL batteries, anticipating new

cell technologies.

• Serial output port for printer and PC interface.

• Slim, ultra-lightweight design for easy portability. A four position PowerCharger fits

easily in a notebook computer carry case.

• Charge position expansion port for charging up to four additional batteries.

• Two power module choices for optimized performance and economy. Model series

2400 features a 40 watt power supply and Models 2700 feature a 70 watt power
supply. Model and rating can be confirmed in the Signature Display .

1

EXPANSION OPTIONS

The exclusive modular design of the new Anton/Bauer InterActive 2000 PowerCharger
provides ultimate flexibility for all video operations. Starting with any base model, a
wide range of expansion modules and upgrades can be added: diagnostic/discharge
functions, charge position expansion, and power supply modules. All this is as easy as
installing a memory or peripheral addition to a computer.

• Diagnostic/discharge module (DDM) featuring automatic calibration of DIGITAL

batteries. This also allows periodic diagnostic testing of any Logic Series battery. This
optional module is a standard feature of the QUAD 2702.

• Four position expansion module (XM 2004) allows charging of up to eight (8) Logic

Series Gold Mount batteries.

• Power Supply upgrade allows 40 watt models (2400 series) to be upgraded to 70

watt (2700 series) capability.

1 2

3 4

MAX. OUTPUT

70 WATTS

IMPORTANT: READ ALL INSTRUCTIONS, NOTES AND OPERATING

SPECIFICATIONS FULLY BEFORE OPERATING THIS
EQUIPMENT.

This unit was packaged at the factory to arrive intact at its destination. If there
is any damage to the packaging or the unit when received, please notify the
carrier immediately.

1 - - - - - - - 2 - - - - - - ­3 - - - - - - - 4 - - - - - - -

1 2

3 4

FRONT

ANTON/BAUER

SHELTON, CT USA

[phone]

BACK

DISPLAY

1 2

3 4

TEST

1 2

3 4

2

SAFEGUARDS

Power Sources: This unit was designed to operate at mains voltages from

90 to 250 Volts AC, 50-60 Hz.

Risk of Electrical Shock: Refer servicing to qualified service personnel.

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.

GROUNDING/EARTHING

IMPORTANT WARNING: THIS APPARATUS MUST BE EARTHED.

To ensure safe operation, the three pin plug supplied must be inserted only into a
standard three-pin power point which is effectively grounded through the normal
household wiring. Extension cords used with the equipment must be three-conductor
and be correctly wired to provide connection to earth ground. Improperly wired
extension cords are a dangerous electrical hazard.

The fact that the equipment operates satisfactorily does not imply that the power point is
properly grounded and that the installation is completely safe. If any doubt exists about
the correct grounding of the power point, consult a qualified electrician.

IMPORTANT: The wires in this main lead are colored in accordance with the

following code:

Green and yellow Earth
Blue Neutral
Brown Live

FUSE TYPE/REPLACEMENT

The mains input of the PowerCharger is fused using a printed circuit board
mounted device which should be replaced ONLY by a qualified service technician.

OPERATION

Self-Test

Upon applying mains power, each PowerCharger will initiate a self-test mode. This mode is
indicated in the LCD, by an audible alert and the lighting of each LED on the PowerCharger
(and any charge module attached) in sequence. Upon completion of the self-test, the green
status light will light steadily, indicating that the unit is ready for operation.

NOTE: Mount batteries to the charger or any charge expansion module attached only

when the PowerCharger has completed its self-test mode. Disconnect the
camera cable from the 4 Pin XLR Connector located on the back of the
PowerCharger.
