QRC-LG
®
Gold Mount
Installation Instructions
The QRC-LG Gold Mount® is designed to allow mounting to various lighting stands in order to utilize an
nton/Bauer battery for a mobile lighting solution. The QRC-LG provides three PowerTap® outputs to
support field lighting kits with multiple lights.
Step 1: Attach the QRC-LG
Gold Mount
stand using the integrated
Manfrotto™ Mini Clamp.
Tighten fully.
®
to the lighting
Note: Maximum total output from the Anton/Bauer Powertap receptacles is 10 amps (10 am internal fuse).
Europe, B.V. Eurode Business Center, Eurode-Park 1-2, 6461 KB Kerkrade, The Netherlands • (+31) 45 5639220 • Fax (+31) 45 5639222 • [email protected]
Anton/Bauer Inc., 14 Progress Drive, Shelton, Connecticut 06484 USA • (203) 929-1100 • Fax (203) 925-4988 • [email protected]
Singapore Office - Anton/Bauer, 6 New Industrial Road, # 02-02 Hoe Huat Ind. Bld., Singapore 536199 • (+65) 62975784 • Fax (+65) 62825235
Step 2: Plug the lights PowerTap
connectors into the QRC-LG
PowerTap receptacles.
Step 3: Snap-On the Logic Series® battery.
www.antonbauer.com 7595-0428 Rev A
