Evaluation Board User Guide
UG-105
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluation Board for the ADF4360-8 Integrated PLL and VCO Frequency Synthesizer
FEATURES
Self-contained board for generating RF frequencies
Flexibility for reference input, PFD frequency, and loop
bandwidth
Accompanying software allows complete control of
synthesizer functions from a PC
Flexibility for changing external inductor to allow different
VCO output frequency ranges
USB-/battery-operated 9 V supplies
EVALUATION BOARD PHOTOGRAPH
GENERAL DESCRIPTION
The EV-ADF4360-8EB1Z board is designed to allow the user to
evaluate the performance of the ADF4360-8 frequency
synthesizer consisting of an integrated PLL and VCO (see Figure 1).
It contains the ADF4360-8BCPZ, a USB connector, and SMA
connectors for the RF outputs. Unpopulated SMA footprints are
available for the power supplies, the chip enable (CE), and the
external reference input. The evaluation board also contains the
loop filter to complete the PLL. It can be modified as necessary for
the user’s PLL requirements. A USB cable is included with the
board to allow software programmability.
The package also contains a CD with Windows® software to allow
quick, user-friendly programming of the synthesizer. The CD
contains numerous other PLL data sheets, technical notes, articles,
and ADIsimPLL™ V3.4, Analog Devices, Inc., PLL simulation
software. More information is available at www.analog.com/pll.
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Figure 1.
Rev. B | Page 1 of 16
UG-105 Evaluation Board User Guide
TABLE OF CONTENTS
Features .............................................................................................. 1
General Description ......................................................................... 1
Evaluation Board Photograph ......................................................... 1
Revision History ............................................................................... 2
Evaluation Board Hardware ............................................................ 3
RF Output Stage ............................................................................ 3
External Inductor Options .......................................................... 3
Evaluation Board Software Quick Start Procedures .................... 5
REVISION HISTORY
2/12—Rev. A to Rev. B
Changed EVAL-ADF4360-8EBZ1 to EV-ADF4360-8EB1Z
Throughout ....................................................................................... 1
11/11—Rev. 0 to Rev. A
Changes to Features Section, General Description Section, and
Figure 1 .............................................................................................. 1
Changes to Evaluation Board Hardware Section and Figure 2 .. 3
Deleted Figure 3; Renumbered Sequentially ................................. 3
Changes to External Inductor Options Section and Figure 3 ..... 3
Replaced Evaluation Board Software Section with Evaluation
Board Software Quick Start Procedures Section .......................... 5
Windows XP OS ............................................................................5
Windows Vista OS and Windows 7 (32-Bit) OS ...........................5
Windows 7 (64-Bit) OS ................................................................6
Using the Evaluation Board Software .............................................7
Evaluation Board Schematics...........................................................9
Ordering Information .................................................................... 12
Bill of Materials ........................................................................... 12
Related Links ................................................................................... 13
Added Figure 5, Figure 6, and Figure 7; Renumbered
Sequentially ........................................................................................ 5
Added Figure 8 and Figure 9 ............................................................ 6
Replaced Programmable Software Settings Section with Using
the Evaluation Board Software Section .......................................... 7
Changes to Figure 10 ......................................................................... 8
Changes to Figure 11 ......................................................................... 9
Changes to Figure 12 ...................................................................... 10
Changes to Figure 13 ...................................................................... 11
Changes to Table 1 .......................................................................... 12
8/10—Revision 0: Initial Version
Rev. B | Page 2 of 16
Evaluation Board User Guide UG-105
08892-002
08892-003
EVALUATION BOARD HARDWARE
The evaluation board comes with a cable to connect to the USB
port of a PC. The silkscreen for the evaluation board is shown
in Figure 2. The board schematics are shown in Figure 11,
Figure 12, and Figure 13.
RF OUTPUT STAGE
The RF output stage of the board allows the user to insert a
tuned load for a particular frequency. The particular network
inserted in the board is optimized for 120 MHz operation. For
different frequencies, the output stage needs different component
values. Consult the ADF4360-8 data sheet for further information.
If in doubt, use a 50 Ω resistor instead of the shunt inductor and
a 100 pF bypass capacitor and a 0 Ω resistor instead of the series
in du ctor.
It is important that the same components be placed on the RF
and RF
B lines. In addition, it is essential that both outputs be
OUT
OUT
A
terminated with 50 Ω loads. Otherwise, the output power is not
optimal, and, in some cases, the part may malfunction.
In applications that only use the divider, both RF outputs are
best terminated with a shunt 50 Ω resistor to AV
, a series
DD
100 pF dc bypass capacitor, and a 50 Ω load to GND.
EXTERNAL INDUCTOR OPTIONS
The ADF4360-8 uses external inductors (L1 and L2) to set up the
LC tank circuit of the VCO. The evaluation board has a footprint
for the placement of these. A value of 220 nH is inserted on the
board giving a VCO center frequency of 120 MHz. Insert two
470 Ω resistors (R25 and R26) parallel to ground for both L1 and L2
(see Figure 3).
Figure 2. Evaluation Board Silkscreen—Top View
The board is powered from a single 9 V battery or from the USB
supply by changing the position of Switch SW1. All components
necessary for LO generation are catered for on board. A 10 MHz
TCXO from Fox Electronics provides the necessary reference
input. Otherwise, an external reference signal can be connected
via J3. The PLL comprises the ADF4360-8BCPZ and a passive
loop filter. The VCO output from RF
the standard SMA connector, J1, and the complementary RF
A is available through
OUT
OUT
B
VCO output is available from J2.
Users can provide their own power supplies using the J4 and J5
connectors, as shown in Figure 2. Hardware power-down using
the CE pin can be controlled by inserting an SMA connector
into J6 and removing R12.
The on-board filter is a third-order, passive, low-pass filter. The
filter contains three capacitors (C13, C14, and C15) plus two
resistors (R10 and R11). The footprint for R10 is located on the
underside of the board. The design parameters for the loop
filter are for a center frequency of 120 MHz, a PFD frequency of
1 MHz, and a low-pass filter bandwidth of 40 kHz. To design a
filter for different frequency setups, use the ADIsimPLL simulation
software.
Rev. B | Page 3 of 16
Figure 3. External Inductors and Resistors for the ADF4360-8 Tank Circuit
UG-105 Evaluation Board User Guide
0
150
50
100
350
250
300
200
450
400
0 100 200 300 400 600500
INDUCTANCE (n H)
FREQUENCY (MHz)
08892-004
To find the optimum frequency range for a given inductor, see
Figure 4. Ensure that the desired frequency is between the two
lines and determine the appropriate inductance needed.
Figure 4. Output Center Frequency vs. External Inductor Value
Rev. B | Page 4 of 16
Evaluation Board User Guide UG-105
08892-005
08892-006
08892-007
EVALUATION BOARD SOFTWARE QUICK START PROCEDURES
The control software and USB drivers for EV-ADF4360-8EB1Z
accompany the EV-ADF4360-8EB1Z on a CD.
To install the software, use the following steps:
1. Open ADF4360_setup.msi.
2. The install wizard guides you through the installation
process. The software is installed in a default directory called
C:/Program Files/Analog Devices/ADF4360.
The software requires Microsoft’s .NET Framework Version 3.5
or later to be installed on your machine. The installer automatically downloads the framework from the Microsoft website if you
do not have this installed. If you do not have an Internet connection or have a slow connection on the PC, you can install the
.NET framework directly from the CD. Do this by double-clicking
dotnetfx.exe. Once installed, run ADF4360_Setup.msi again.
WINDOWS XP OS
After you have installed the software, install the USB drivers.
To do so, use the following steps:
1. Plug a USB cable into the USB connector on the evaluation
board. The Found New Hardware box opens. See Figure 5.
2. Choose Install from a list or specified location
(Advanced).
If the installation is successful, the message in Figure 6 appears.
Figure 6. Successful Installation
WINDOWS VISTA OS AND WINDOWS 7 (32-BIT) OS
For Windows Vista or Windows 7 (32-bit), you must manually
install the drivers. To do so, use the following steps:
1. Find the new unknown device (the evaluation board)
in Device Manager and double-click it to open the
properties. The device should be Unknown device,
under Other devices (see Figure 7).
Figure 5. New Hardware Wizard
3. Click Continue Anyway when asked about Windows Logo
testing.
Rev. B | Page 5 of 16
Figure 7. Device Manager
UG-105 Evaluation Board User Guide
08892-008
08892-009
2. Click Update Driver in the properties window (see
Figure 8).
Figure 8. Unknown Device Properties
3. On the Update Driver Software dialog box, choose
Browse my computer for driver software.
4. Browse to C:\Program Files\Analog Devices\ADF4360.
5. Click OK or Next.
6. If prompted by Windows security, choose Install this
driver software anyway.
7. If the installation is successful, the message in Figure 9
appears.
Figure 9. Successful Installation
WINDOWS 7 (64-BIT) OS
Windows 7 64-bit uses a different driver than 32-bit systems. To
install this driver:
1. Disconnect the USB evaluation board.
2. Open ADF4360_setup.msi.
3. The install wizard guides you through the installation
process. The software is installed in a default directory called
C:/Program Files/Analog Devices/ADF4360.
4. Connect your USB evaluation board. The driver should be
found automatically.
Note that installing this driver package disables older versions
of Analog Devices PLL software; therefore, only install if needed.
Rev. B | Page 6 of 16
Evaluation Board User Guide UG-105
USING THE EVALUATION BOARD SOFTWARE
The control software for the EV-ADF4360-8EB1Z accompanies
the EV-ADF4360-8EB1Z on a CD. To install the software, see
the Evaluation Board Software Quick Start Procedures section.
To run the software, double-click the ADF4360.exe file on the
desktop or from the Start menu.
The main interface window opens (see Figure 10). Confirm that
Analog Devices RFG.L Eval Board connected is displayed at
the top of the window. Otherwise, the software has no connection
to the evaluation board.
The evaluation board can be connected and disconnected while
the software is running. Note that, when connecting the board,
it takes about 5 seconds for the status label to change.
Under the File menu, the current settings can be saved to, and
loaded from, a text file.
Use the REF IN Frequency text box to set the correct reference
frequency and the reference frequency divider. The reference
TCXO on the evaluation board runs at 10 MHz.
The Settings section controls the charge pump current setting,
the output power setting, and the multiplexer output setting.
Use the Frequency Settings section to control the output
frequency. You can input the desired output frequency
in the RF Output Frequency text box (in megahertz).
In the Registers tab, you can manually input the desired value
to be written to the registers.
In the Sweep and hop tab, you can make the device sweep a
range of frequencies or hop between two set frequencies.
In the Latches to write section at the bottom of the window,
the values to be written to each register are displayed. If the
background on the text box is green, the value displayed is
different from the value actually on the device. Click Wr it e N
counter Latch or Write R counter Latch to write that value to
the device.
Press the F2, F3, and F4 keys to switch between the three tabs.
F12 increases the output frequency by one channel spacing and
writes it to the device. F11 decreases the output frequency by
one channel spacing.
Rev. B | Page 7 of 16
UG-105 Evaluation Board User Guide
08892-010
Figure 10. Software Front Panel Display
Rev. B | Page 8 of 16
Evaluation Board User Guide UG-105
08892-011
EVALUATION BOARD SCHEMATICS
Figure 11. EV-ADF4360-8EB1Z Schematic
Rev. B | Page 9 of 16
UG-105 Evaluation Board User Guide
08892-012
Figure 12. EV-ADF4360-8EB1Z Schematic (Continued)
Rev. B | Page 10 of 16
Evaluation Board User Guide UG-105
08892-013
Figure 13. EV-ADF4360-8EB1Z Schematic (Continued)
Rev. B | Page 11 of 16
UG-105 Evaluation Board User Guide
J1, J2
Jack SMA end launch tab
Johnson Components 142-0701-851
L3, L4
Resistor, 0603, 0 Ω
Multicomp MC 0.063W 0603 0R
ORDERING INFORMATION
BILL OF MATERIALS
Table 1.
Reference Designator Part Description Manufacturer/Part No.
C1, C3, C5, C29, C30, C32, C37,
C38, C39, C40, C41, C42, C43
C2, C4, C6, C8 Capacitor, 0402, 10 pF, 50 V Kemet C0402C100J5GACTU
C7 Capacitor, Case A, 22 µF, 6.3 V AVX TAJA226K006R
C9, C10, C27 Capacitor, 0603, 1 nF, 50 V AVX 06035A102JAT2A
C11, C12, C21, C24 Capacitor, 0402, 10 nF, 16 V Yageo (Phycomp) CC0402ZRY5V7BB103
C13 2-pin capacitor, 120 pF, 0603, 50 V Yageo CC0603KRX7R9BB121
C14 2-pin capacitor, 1.5 nF, 0603, 50 V Yageo CC0603KRX7R9BB152
C15 2-pin capacitor, 47 pF, 0603, 50 V Yageo CC0603JRNP09BN470
C16 Multilayer ceramic capacitor, 50 V, X7R, 1 nF, ±10%, 0402 Murata GRM155R71H102KA01D
C17, C19 Capacitor, 0603, 100 pF, 50 V Phycomp 2238 867 15101
C18, C28 Capacitor 0603, 1 µF, 25 V Taiyo Yuden TMK107BJ105KA-T
C20, C23 Capacitor, Case A, 1 µF, 16 V AVX TAJA105K016R
C22, C25 Capacitor, Case A, 4.7 µF, 10 V AVX TPSA475K010R1400
C26 Capacitor, Case A, 10 µF, 6.3 V Kemet T491A106M016AT
C31, C33 Capacitor, 0805, 10 µF, 6.3 V Murata GRM21BR71A106KE51L
C34 Capacitor, 0402, 22 pF, 50 V NPO Kemet C0402C220J5GACTU
C35, C36 Capacitor 0402, 12 pF, 50V Kemet C0402C120J5GACTU
D1 LED, SMD red Avago HSMS-C170
D2 Diode, 1 A, 50 V Multicomp 1N4001
D3 Schottky diode, 20 V Micro Commercial Components, Inc.,
D4 LED, SMD red Avago HSMS-C170
Capacitor, 0402, 0.1 µF, 16 V Kemet C0402C104K4RAC
SD103C-TP
J3 to J6 Jack SMA end launch tab (not inserted)
J7 USB mini-B Molex 56579-0576
L1, L2 Ceramic chip inductor, 220 nH, 5%, 0603 for ADF4360-8 Coilcraft 0603CS-R22X_L
L5, L6 Ceramic chip inductor, 240 nH, 5%, 0603 Coilcraft 0603LS-36NX_LU
LK1, LK2 Header, 1-row, 2-way and jumper socket black Harwin Plc M20-9990245 and
Harwin Plc M7567-05
P1 Battery clip, PCB mounting Keystone Electronics Corp. 593+594
R1 to R4, R9, R13, R22 to R24 Resistor, 0603, 0 Ω Multicomp MC 0.063W 0603 0R
R27, R36, R37, R40, R41,R38, R5 Resistor, 0603, 51 Ω Multicomp MC 0.063W 0603 1% 51R
R6, R15 Resistor, 0603, 4.7 kΩ Multicomp MC 0.063W 0603 1% 4K7
R7, R8, R12, R28, R29, R30 Resistor, 0603, 10 kΩ Multicomp MC 0.063W 0603 1% 10K
R10 2-pin resistor, 12 kΩ, 0603, 1% Multicomp MC 0.063W 0603 1% 12K
R11 2-pin resistor, 5.1 kΩ, 0603, 1% Multicomp MC 0.063W 0603 1% 5K1
R14, R16 Resistor, 0603, 330 kΩ Multicomp MC 0.063W 0603 1% 330K
R17 to R19 Resistor, 0603, 330 Ω Multicomp MC 0.063W 0603 1% 330R
R20, R21 Resistor, 0603, 2.2 kΩ Multicomp MC 0.063W 0603 1% 2K2
R25, R26 Resistor, 0402, 470 Ω Multicomp MC 0.063W 0402 1% 470R
R31, R32 Resistor, 0603, 100 kΩ Multicomp MC 0.063W 0603 1% 100K
R34 Resistor, 0603, 140 kΩ Multicomp MC 0.063W 0603 1% 140K
R35 Resistor, 0603, 78.7 kΩ Multicomp MC 0.063W 0603 1% 78K7
SW1 Switch, PCB SPDT APEM TL36P0050
T1 to T8, T13 to T16 Terminal, PCB, red, PK100 Vero Technologies, Ltd. 20-313137
T9 to T12 Test point (not inserted)
Rev. B | Page 12 of 16
Evaluation Board User Guide UG-105
Reference Designator Part Description Manufacturer/Part No.
U1 Integrated integer-N synthesizer Analog Devices ADF4360-8BCPZ
U2, U3 High accuracy low dropout linear 3 V regulator Analog Devices ADP3300ARTZ-3
U4 ADP3334 adjustable LDO regulator Analog Devices ADP3334ARMZ
U5 IC serial EEPROM 8-SOIC Microchip 24LC64-ISN
U6 USB microcontroller Cypress CY7C68013A-56LFXC
U7 ADCMP602 comparator Not inserted
Y1 10 MHz TCXO (FOX801) Fox Electronics FOX801-BELF
RELATED LINKS
Resource Description
ADF4360-8 Product Page, Integrated Integer-N Synthesizer and VCO—Output Frequency 65 MHz to 400 MHz
ADP3300 Product Page, High Accuracy anyCAP® 50 mA Low Dropout Linear Regulator
ADP3334 Product Page, High Accuracy Low IQ, 500 mA anyCAP® Adjustable Low Dropout Regulator
ADCMP602 Product Page, Rail-to-Rail, Very Fast, 2.5 V to 5.5 V, Single-Supply TTL/CMOS Comparator in 8-Lead MSOP and LSCFP
Packages
Rev. B | Page 13 of 16
UG-105 Evaluation Board User Guide
NOTES
Rev. B | Page 14 of 16
Evaluation Board User Guide UG-105
NOTES
Rev. B | Page 15 of 16
UG-105 Evaluation Board User Guide
neer chips on the Evaluation Board. Customer shall inform ADI of any
rued in accordance with the substantive laws of the Commonwealth of
NOTES
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high e nergy ESD. Therefore, proper ESD precaution s should be taken to avoid per forma nce degra dation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms a nd conditions
set forth below ( “Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you
have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”) and Analog Devices, Inc.
(“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. S ubject to the terms and conditions of the Agreement, ADI hereby grants to Customer a free, limited, personal,
temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and agrees that the Evaluation Board is provided
for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Further more, the license granted is expressly made subject to the following additional
limitations: Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board; and (ii) permit any Third Party to access the Evaluation Board. As used herein, the term
“Third Party ” includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is NOT sold to Customer; all rights not expressly granted herein, including
ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all be considered the confidential and proprietary information of A DI. Customer may
not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of use of the Evaluation Board or termination of this Agreement, Customer agrees to
promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile or reverse engi
occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited to soldering or any other activity that affects the material content of the Evaluation Board.
Modifications to the Evaluation Board must comply with applicable law, inclu ding but not limited to the RoHS Directive. TERMINATION . ADI may t erminate this Agreement at any time upon giving written notice
to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS” AND ADI MAKES NO
WARRANTIES OR REPRES ENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICAL LY DISC LAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUA RANTEES, OR WARRANT IES, EXPRESS OR IMPLIED, RELATED
TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL
PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF
THE EVALUAT ION BOARD, INCLUDING BUT NOT LIMI TED TO LOST PROFITS, DE LAY COSTS, LABOR COSTS OR LOSS OF GOODWI LL. ADI’S TOTAL LIA BILITY FROM AN Y AND ALL CAUSES SHALL BE LIMITE D TO THE
AMOUNT OF ONE HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable
United States federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and const
Massachusetts (excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the stat e or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby
submits to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the Intern ational Sale of Goo ds shall not ap ply to this Agreement and is expressly disclaimed.
©2010–2012 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
UG08892-0-2/12(B)
Rev. B | Page 16 of 16
Loading...
