Interfacing Two AD73311 Codecs to the ADSP-218x

Talkthrough Program for 2 cascaded 73311:
European DSP Apps, E. A.
Tested on SK 2185-Board, 03/98

Hardware Information:

- CODECS are attached to DSP’s SPORT 0

- Cascade circuitry: see AD73311 Data Sheet and below

- DSP's internally generated SCLK1 feeds Master Codec's MCLK

- Codecs' reset and SE lines are controlled per Flip-Flop via fl0 and fl1 respectively

- The 2 D-Flip-Flops synchronise Codecs' SE and reset to MCLK

- Programmable flag PF2 (not on the diagram) of the ADSP-218x is used to clear the 2 Flip-Flop sections
(corresponding to Codec reset and SE)

ADSP-218x connected
to 2 AD73311 Codecs
in cascade

a

{*******************************************************************}

.module/RAM/ABS=0 talkthru;
.const SPORT1_Autobuf= 0x3fef;
.const SPORT1_RFSDIV= 0x3ff0;
.const SPORT1_SCLKDIV= 0x3ff1;
.const SPORT1_Control_Reg= 0x3ff2;
.const SPORT0_Autobuf= 0x3ff3;
.const SPORT0_RFSDIV= 0x3ff4;
.const SPORT0_SCLKDIV= 0x3ff5;
.const SPORT0_Control_Reg= 0x3ff6;
.const SPORT0_TX_Channels0= 0x3ff7;
.const SPORT0_TX_Channels1= 0x3ff8;
.const SPORT0_RX_Channels0= 0x3ff9;
.const SPORT0_RX_Channels1= 0x3ffa;
.const TSCALE= 0x3ffb;
.const TCOUNT= 0x3ffc;
.const TPERIOD= 0x3ffd;
.const DM_Wait_Reg= 0x3ffe;
.const System_Control_Reg= 0x3fff;

.var/dm/ram/circ data[2];

{^data -> codec2;
^data+1 -> codec1}

.var/dm/ram/circ init_cmds[10];
.var/dm stat_flag;

.init init_cmds:

{ CR DEV REG REG }
{ DW ADD ADD DATA }
{ |+ --- *** ======== }
{ |+ --- *** ======== }
b#1000100100000011, {reg B,2 b#10 001 001 00000011 }
b#1000000100000011, {reg B,1 b#10 000 001 00000011 }

{ CRB4:6 DMCLK=MCLK; }
{ CRB2:3 00 -> SCLK = DMCLK/8}

b#1000101011111001, {reg C,2 b#10 001 010 11111001 5VEN }
b#1000001011111001, {reg C,1 b#10 000 010 11111001 }

0x8b40, {reg D,2 b#10 001 011 01000000}
{-6dB output gain & 0dB input gain}
