EPROM Booting In Host Mode
With 100 Pin 218x Processors

Written By: Greg F.
Last Modified: 9/23/98

This EE Note will explain how to boot an Analog
Device’s adsp218x DSP processor (2184/85/86/87/89) via
the Byte Memory interface (BDMA) while it is
configured for host memory mode. Host memory mode
allows a host processor to boot or access the DSP’s
internal memory via the Internal Direct Memory
Addressing port (IDMA). Normally, these processors can
be configured to boot in only one of two methods; from
an eprom (full memory mode), or from a host processor
via the IDMA port (host memory mode).

Overview

Full Memory Mode

Full Memory Mode gives complete use of the external
address and data busses as found in the ADSP-2181. In
Full Memory Mode, the ADSP-2185/2186 behaves like
an ADSP-2181 with the IDMA port removed. There is a
24 bit external data bus, a 14 bit address bus and 5
memory select signals. Byte memory is accessed using
the middle eight bits of the data bus for data. The upper
eight bits of the data bus together with the 14 address pins
provide a 22 bit address for byte memory space. All of
these features behave exactly the same as on the ADSP-

2181. Hold Off cases (autobuffer cycle stealing, external
memory accesses with wait states, etc.) are simplified
because an IDMA transfer will never occur. In this mode
the IDMA port is disabled as if /IS was deselected or
pulled high on the ADSP-2181.

All of the previously mentioned processors feature a 100­pin package which uses a multiplexed external bus that
has the following functionality:

• Full Memory Mode : Provides complete use of the

external address and data busses as found in the
ADSP-2181. Allows BDMA operation with full
external overlay memory and I/O capability. IDMA
functionality is disabled

• Host Mode: Allows complete IDMA port operation

with limited external addressing capabilities.

The functionality of the external bus is dependent upon
the setting of the external mode C pin of the processor.
The logic state of this pin is acknowledged by the
processor during reset; mode C = 0 configures the DSP in
full memory mode, mode C = 1 configures the processor
in host memory mode.

Note: the state of the mode C pin must not be changed
once the DSP begins execution. For more information on

the operation and configurations of the Mode C pin,
please refer to the appropriate ADSP-2185/6/7L data

Host Mode

Host Mode gives full use of the IDMA port as found on
the ADSP-2181, but there are limitations on the use of the
external memory bus. In Host Mode the lower eight bits
of the data bus, D[7:0] become IDMA control pins and
IAD bus pins. The upper 13 bits of the address bus
A[13:1] become the lower 13 bits of the IDMA
address/data bus, IAD[12:0]. The Pinout Diagram and
tables for the Memory Interface Pins in the ADSP­2185/6/7L Data Sheets show the alternate functions for
each pin in either major I/O mode. IDMA transfers occur
exactly as on the ADSP-2181.

Accessing Peripherals

The external bus in Host Mode still remains available in a
limited form. The DSP’s address pins A[13:1] are
changed to IAD[12:0] when the Mode C pin is high. As
a result, the chip cannot drive an address externally.
However, internally the chip will behave as if external
accesses are occurring.

a

The external bus will behave as an ADSP-2181 system
where address bits A[13:1] and data bits D[7:0] are
ignored. The upper 16 bits of the data bus can still be
used for external data transfers, but only one address bit is
available, A0. Writes to Data Memory or I/O Space will
activate the appropriate memory select(s), /RD or /WR,
place data on D[23:8], and drive a single address bit on
A0.

Program memory reads and writes behave similarly but
have the added consideration of the PX register. For
program memory reads and writes only the upper 16 bits
will be available externally. When 24 bit data is written
to external program memory the upper 16 bits will be
driven out on data bus pins [23:16]. The PX register will
still latch the lower eight bits of the program memory
word, but they will not be driven externally. If a 24 bit
read of external memory occurs, no external pins will
control the value of the PX register, and the PX register
will be written with all ones. The missing address bits
restrict using the external bus with a conventional
memory device which has separated address and data
buses. These external transfers might be usable with
shared address/data memory chips or can be used for
communication with an ASIC. The memory selects will
still be active, so each memory space is effectively
collapsed into two external addresses, address 0 and 1.

So What Does This All Mean?

Since the DSP is configured in host mode, the external
address bus is limited to one pin, A0. What this means to
us is that we now need to use address generators to drive
the external address pins of the EPROM to facilitate
booting of the DSP. (Please refer to the included data
sheet for more information on the operation of the address
generators, Philips part number 74HC4040.)

The one caveat of building this hardware configuration is
that the address generators output sequential address
values, while the prom splitter for the 218x family does
not. So the executable file must be massaged to allow the
prom splitter to output sequential data for the eprom.
Normally, the prom splitter (when used in conjunction
with the -2181 and -loader switches), prepends a boot
loader kernel to the beginning of the eprom file. This is
done because the development tools for the 218x family
use a different boot paging scheme than the rest of the
21xx family DSP processors to initialize program
memory segments, program data segments, and data
memory segments.

The Real Solution

Byte Memory Accesses

BDMA accesses are still allowed in Host Mode.
However, because address pins A[13:1], now operate as
the IAD bus, construction of a complete byte address is
impossible, without external circuitry.

Byte memory addresses on the ADSP-2181 were 22-bit
addresses formed from external data pins D[23:16] and
address pins A[13:0]. In Host Mode D[23:16] and A0 are
the only address bits available externally. The values of
the external data pins D[23:16], will be the values
contained in the BMPAGE field of the BDMA Control
Register, located at internal DM address 0x3fe3 of the
processor. A0 will be 1 for odd byte addresses and 0 for
even byte addresses.

BDMA and IDMA timing and cycle stealing are the same
as on the ADSP-2181. BDMA with limited address bits
available still provides a flexible interface to the DSP.
Without full address bits addressing memory will be more
difficult but host or microcontroller communication is
possible because the order of the byte sequence is known.
For information on byte sequencing, refer to Byte Memory
Word Formats in Ch. 11 of the ADSP-2100 Family
User’s Manual.

Here are the following steps that are needed to complete
our design:

1. Create a system file (*.sys) for a 2101 processor that

declares on chip memory space for a 218x system,
but also includes boot page segments.

2. Declare a boot page segment in your source code’s

.module directive.

3. Replace the @BO symbol in your *.exe file with an

@PA symbol. (The @BO symbol is located on the
second line of the *.exe file; you can edit this file
with any text editor, since the file is written in an
ASCII file format.)

EN-79 Page 2

Technical Notes on using Analog Devices’ DSP components and development tools

Phone: (800) ANALOG-D, FAX: [phone], FTP: ftp.analog.com, EMAIL: [e-mail]

The following example is the system file (Boothost.sys)
used to build this project:

.system BootHost;
.adsp2101;
.mmap0;
.seg/pm/ram/code/data/abs=0 int_pm[0x4000];
.seg/dm/ram/data/abs=0 int_dm[0x3c00];
.seg/rom/boot=0 boot0[2048];
.endsys;

From this example system file, you’ll notice that we’ve
declared an adsp2101 system with roughly 16k words of
PM and DM respectively!! This step is required to “trick”
the tools into using boot segments, (“.seg/rom/boot=0
boot0[2048];”), with a 2181 memory model.

Now here is our code example. Here you’ll notice again
that a boot segment is used in this source file (located at
line 1), which is normally illegal for a 218x system. But,
since we’ve tricked the tools into using our modified 2101
system file, everything will work accordingly.

/* Filename : Boothost.DSP */
.module/ram/boot=0 booty;
#include "vectab.h"
#define IRQ2ON

IRQ2INT:
toggle fl0;
none = pass sr0;
if eq call resetpf; {reset PF data}
ar = sr0 OR 0x80;
dm(0x3fde) = ar; {set data for BDMA wr}
ax0 = 0x7fdf;
dm(0x3fe0) = ax0; {set IDMAA to PF DATA reg}
ay0 = 0x0;
dm(0x3fe2) = ay0; {set BEAD}
ay0 = 0x3fde;
dm(0x3fe1) = ay0; {set BIAD}
ay0 = 0x7;

dm(0x3fe3) = ay0; {set BDMA Control}
ay0 = 0x1;
dm(0x3fe4) = ay0; {set BWCOUNT, start BDMA}
nop; nop; nop; nop;
sr = lshift sr0 by -1 (LO); {shift reg holding PF data}
ay1 = dm(0x3fdf);
dm(0x3fe5) = ay1;
rti;

RESETPF:
sr0 = 0x40;
rts;

START:
ax0 = 0x0400;
dm(0x3fff) = ax0;
ax0 = 0x0000; {set IOWAIT to 0}
dm(0x3ffe) = ax0;
imask = 0x200; {enable IRQ2}
ax0 = 0x1f7f;
dm(0x3fe6) = ax0; {make PFs output exc PF7}
ax0 = 0x80;
dm(0x3fe5) = ax0; {make all PFs exc PF7 lo}
sr0 = 0x40; {set data for first PF}
reset fl0;
cntr = 0x6;
do FLASHER until ce;
cntr = 0x1000;
do FLASHER1 until ce;
cntr = 0x2000;
do FLASHER2 until ce;
FLASHER2: nop; {wait for IRQ2}
FLASHER1: nop;
FLASHER:
toggle fl0;
NOWHERE: idle;
jump NOWHERE;

#include "trailer.h"

EN-79 Page 3

Technical Notes on using Analog Devices’ DSP components and development tools

Phone: (800) ANALOG-D, FAX: [phone], FTP: ftp.analog.com, EMAIL: [e-mail]

.endmod; /* end of boothost.dsp program */

From this point, we’re able to build our executable file.
We’ll use the following command line(s) at the DOS
prompt:

bld21 boothost
asm21 boothost.dsp -o boothost
ld21 boothost -a boothost.ach -e boothost -x -g

The first line creates our architecture file from the file
boothost.sys. The second line assembles the file
boothost.dsp and creates an object file boothost.obj. The
third line creates our executable file boothost.exe using
the boothost.obj and boothost.ach files.

At this step in the build we need to perform one more
task; we need to manually edit the executable file to
generate a program memory executable file, not a ROM
executable file. This can be done by performing the
following steps;

References And Appendices

Please refer to chapters two and five of the 2100 Family
Assembler Tools and Simulator Manual, (System Builder
and PROM Splitter, respectively), as well as the latest
version of the development tools release notes for more
information on the usage and functionality of these tools.
(All of these documents can be downloaded from our
website at the following URL;
http://www.analog.com/support/product_documentation/d
sp_prdoc.html.) Also included at the end of this
application note is a schematic that shows the interface
used for this design. For more information please contact
Analog Devices at 1-800-ANALOGD, or
http://www.analog.com/dsp.

1. Edit the file boothost.exe.

2. Change the first line in the file from @BO to @PA.

(This changes the file from a ROM bootable file to a
program memory executable file.)

3. Save the file as boothost.exe.

At this point, we are able to perform the final step in our
build, by typing the following command line at the DOS
prompt; spl21 boothost boothost -loader -2181. This will
create the file boothost.bnm, that we can use to burn into
the EPROM for our system.

EN-79 Page 4

Technical Notes on using Analog Devices’ DSP components and development tools

Phone: (800) ANALOG-D, FAX: [phone], FTP: ftp.analog.com, EMAIL: [e-mail]

D7D6D5D4D3D2D1

D1575D1474D1373D12

D8
D9
D10
D11

D12
D13
D14
D15

D0
D1
D2
D3
D4
D5
D6
D7

D8
D9
D10
D11
D12
D13
D14
D15

76

D16

77

D17

78

D18

79

D19

80

GND

81

D20

82

D21

83

D22

84

D23

85

U9

1

NC

7

GND

OSCILLATOR

100

86
87
88
89
90
91
92
93
94
95
96
97
98
99

FL2
FL1
FL0
PF3
PF2/MODEC
VDD
PWD
GND
PF1/MODEB
PF0/MODEA
BGH
PWDACK
A0
A1/IAD0
A2/IAD1
A3/IAD2

VDD

OUT

3

2
4
6

8
11
13
15
17

1
19

2

4

6

8
11
13
15
17

1
19

U6A

74HC32

U7

1A1
1A2
1A3
1A4
2A1
2A2
2A3
2A4

1G
2G

74HC244

U8

1A1
1A2
1A3
1A4
2A1
2A2
2A3
2A4

1G
2G

74HC244

14

A4/IAD31A5/IAD42GND3A6/IAD54A7/IAD65A8/IAD76A9/IAD8

8

1Y1
1Y2
1Y3
1Y4
2Y1
2Y2
2Y3
2Y4

1Y1
1Y2
1Y3
1Y4
2Y1
2Y2
2Y3
2Y4

VDD

IAD0
IAD1
IAD2

D0

VDD

IAD15

IAD14

IAD13

72

71

69D968

67

66D865

64

63

62

61

60

59

58

55BG54

53BR52

51

D1170D10

VDD

VDD

EBG

GND

GND

GND

D4/IS

D5/IAL

D6/IRD

D7/IWR

U4

218X_100L

A10/IAD9

CLKIN

VDD

A11/IAD109A12/IAD1110A13/IAD1211GND

XTAL

IAD8

IAD0
IAD1
IAD2
IAD3
IAD4
IAD5
IAD6
IAD7

IAD8
IAD9
IAD10
IAD11
IAD12
IAD13
IAD14
IAD15

CLKOUT16GND

12

13

14

15

17

IAD12

IAD11

IAD10

IAD9

7

8

IAD7

IAD6

IAD5

IAD4

IAD3

2

1

18
16
14
12

9
7
5
3

18
16
14
12

9
7
5
3

D3/IACK

D2/IAD1557D1/IAD1456D0/IAD13

VDD18WR19RD

20

EBR

50

EINT

49

ELIN

48

ELOUT

47

ECLK

46

EE

45

EMS

44

RESET

43

ERESET

42

SCLK1

41

GND

40

DR1

39

RFS1

38

TFS1

37

DT1

36

VDD

35

SCLK0

34

DR0

33

RFS0

32

TFS0

31

DT0

30

IRQ2/PF7

29

IRQL1/PF6

28

GND

27

IRQL0/PF5

26

IRQE/PF4

DMS

CMS

BMS

PMS23IOMS

21

22

24

25

IRQ2

RESET

U5A

1 2

74HC04

U2

11

RESET

10

CLOCK

74HC4040

U3

11

RESET

10

CLOCK

74HC4040

A1

9

Q1

A2

7

Q2

A3

6

Q3

A4

5

Q4

A5

3

Q5

A6

2

Q6

A7

4

Q7

A8

13

Q8

A9

12

Q9

A10

14

Q10

A11

15

Q11

A12

1

Q12

A13

9

Q1

A14

7

Q2

A15

6

Q3

A16

5

Q4

A17

3

Q5

A18

2

Q6

A19

4

Q7

A20

13

Q8

A21

12

Q9

A22

14

Q10

A23

15

Q11

A24

1

Q12

A0

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19

ANALOG DEVICES INC
3 TECHNOLOGY WAY
NORWOOD, MA 02062

Title

218X 100L BDMA BOOT ONLY CIRCUIT

Document Number

Size

A

Date: Sheet of

U1

12

A0

11
10

27
26
23
25

28
29

30
31

22
24

O0

A1

O1

A2

O2

9

A3

O3

8

A4

O4

7

A5

O5

6

A6

O6

5

A7

O7
A8
A9
A10
A11

4

A12
A13
A14

3

A15

2

A16
A17
A18

1

A19

CE
OE/VPP

27C080

D0

13

D1

14

D2

15

D3

17

D4

18

D5

19

D6

20

D7

21

Rev

1 1Monday, September 14, 1998

F

Figure 1: Example schematic for Host Mode EPROM booting system

Technical Notes on using Analog Devices’ DSP components and development tools

Phone: (800) ANALOG-D, FAX: [phone], FTP: ftp.analog.com, EMAIL: [e-mail]

Page 5
