Amplicomms M6900 Operation Manual
PowerTel
M6900
mobile phone
Operating
Instructions
M6900
Hearing aid compatibility
This telephone is equipped with T Coil coupler making it com-
patible with most popular hearing aids. Due to the wide range
of hearing aids available there is no guarantee that the tele-
phone will function with all hearing aid models. Please check
your hearing aid immunity rating is higher than M2. This rat-
ing can be provided by the manufacturer of your hearing aid.
Instruments with rating lower than M2 may not be compatible
with this telephone. When using this telephone press the ‘T’
button on your hearing aid to switch it to Telecoil mode, this
will link your hearing aid to the phone and will enable clearer
sound without background noises. Please check if your hear-
ing aid is equipped with ‘T’ facility and if it is automatic or
manual. Hearing aids with high immunity rating equipped
with automatic T mode should be able to detect your phone
automatically and switch over to T position. Hearing aids with
Manual T function would need manual activation of this func-
tion on your hearing aids.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
CONTENTS
Quick Start Guide.............................................................6
Quick Glance ...............................................................................6
What is in the box .....................................................................8
Installing the SIM card and battery ........................................8
Charging the battery ...............................................................10
Charging via the mini USB charging socket .......................10
Charging via the desktop charging unit ...............................10
Battery status ...........................................................................11
Switching the mobile phone on and off ...............................11
Make sure you are in range of your Network .....................12
Setting the display language .................................................12
Setting the time and date ......................................................13
Taking a call .............................................................................13
Rejecting a call .........................................................................13
Ending a call ............................................................................13
Making a call ............................................................................13
Advanced Settings and Functions ........................................14
Questions and Answers .........................................................14
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
1
CONTENTS
The phone in details ......................................................18
Keys and Parts ..........................................................................18
Special key functions ...............................................................18
Icons in the display ..................................................................22
Using the phone .............................................................24
General ......................................................................................24
Switching the mobile phone on and off ...............................25
Using the Torch ........................................................................26
Dialling a phone number / Calling .........................................26
Dialling with the speed dialling keys.....................................27
Dialling with the one−touch dialling keys.............................27
Using redial / using the Calls list............................................28
Taking a call...............................................................................28
Setting the volume...................................................................28
Hands-free .................................................................................29
Muting the microphone...........................................................29
3-party conference ...................................................................29
“Phonebook“ menu .......................................................30
Opening the phonebook .........................................................30
2
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
CONTENTS
Checking the memory status..................................................30
Creating a new phonebook entry...........................................31
Calling from the phonebook...................................................32
Editing a phonebook entry......................................................32
Deleting a phonebook entry ...................................................33
Deleting all phonebook entries ..............................................33
Copying all phonebook entries ..............................................34
Storing a phonebook entry to a speed dialling key.............34
Storing a phonebook entry to an one−touch ......................35
dialling key ................................................................................35
“Messages“ menu..........................................................38
Messages menu .......................................................................38
Writing and sending a SMS....................................................40
Reading/deleting SMS and further options ..........................41
“Call center“ menu ........................................................43
Reading the calls list ................................................................43
Deleting the calls list................................................................44
Call settings...............................................................................45
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
3
CONTENTS
“SOS“ menu ...................................................................49
Selecting an emergency call destination ..............................49
Entering emergency call numbers.........................................49
Select an outgoing emergency voice message ...................50
Recording a personal emergency voice message...............51
Emergency call procedure ......................................................51
Cancel the emergency call function.......................................53
“Settings“ menu ............................................................54
User profiles..............................................................................54
Direct number...........................................................................56
Tone control ..............................................................................56
Phone settings ..........................................................................57
Network settings ......................................................................58
Security settings.......................................................................59
Restore factory settings...........................................................60
“Organizer“ menu..........................................................61
Calender ....................................................................................61
Calculator ..................................................................................61
Alarm .........................................................................................62
4
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
CONTENTS
Tasks...........................................................................................63
Stopwatch .................................................................................63
“Services“ menu ............................................................65
Appendix .........................................................................66
Technical data ...........................................................................66
Service hotline ..........................................................................67
Problems and solutions...........................................................67
Tips on the battery ...................................................................70
Intended use ............................................................................70
Areas of use .............................................................................71
Safety Information ..................................................................71
Power adapter plug..................................................................74
Disposal .....................................................................................74
Declaration of Conformity ......................................................76
Maintenance ............................................................................76
Guarantee .................................................................................77
Index ................................................................................79
Menu tree........................................................................82
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
5
QUICK START GUIDE
Quick Start Guide
Important: Before you start, please read the safety information on page 71.
Quick Glance
1 Display
2 Direct call keys
M1, M2, M3
3 Left soft key
4 Call key
5 Keypad
6 Star key
7 Earpiece
8 Right soft key
9 End call key /
On/Off key
10 Microphone
11 Hash key
12 Mini-USB charging socket
13 Volume up/Down
14 Charge contact plate
15 Torch
16 LED Charging/Low battery
17 Headset socket (Headset not
supplied)
18 Emergency call switch
19 Battery cover
20 Loudspeaker
21 Navigation key
6
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
QUICK START GUIDE
7
1
2
3
4
5
6
21
8
9
10
11
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
12
13
14
17
15
16
18
19
20
7
QUICK START GUIDE
What is in the box
1 mobile phone 1 power adapter plug
1 li−ion battery 1 operating manual
1 desktop charging unit
Installing the SIM card and battery
Risk of swallowing small objects!
The SIM card can be removed.
Small children can swallow them.
Pay attention that the SIM card is not bent or
scratched. Prevent any contact with water, dirt or
electrical charges.
Your telephone number is carried by the SIM card, not
the phone. Therefore if you use a SIM card you had in a
previous phone, you will keep the same phone number.
• Switch the phone off.
• Remove the battery cover by pressing on it in the area
beneath the SOS key, slide it down and take it off.
• If there is already a battery inside, remove it.
8
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
QUICK START GUIDE
• Slide the SIM card with the
golden contacts facing down in
the moulded SIM card holder.
The SIM card must be located
under the metal retaining bar
to be in the correct position.
• Insert the battery. The golden
contacts on the battery must
face towards the bottom right.
Press lightly on the top end of the battery until it snaps
into place.
• Replace the battery cover on the back of the phone and
shift it upwards until it clicks into place.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
9
QUICK START GUIDE
Charging the battery
• Before starting to charge the battery, check that it has been
installed properly. Do not remove the battery while it is
being charged. This could damage the phone.
• When charging the battery for the first time, it should be
charged for at least 4 hours. Some batteries only reach their
full capacity after several complete charge/discharge cycles.
Charging via the mini USB charging socket
• Plug the power adapter in the mini USB charging socket.
• Connect the power adapter plug. For safety reasons, only
use the power adapter plug supplied.
Charging via the desktop charging unit
• Plug the power adapter plug in the mini USB charging
socket on the charging unit. Insert the phone in the charg-
ing unit to charge it.
• It may take a few seconds before the phone indicates the
charging process.
10
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
QUICK START GUIDE
Battery status
The current battery charge status is indicated in the display as
follows:
Empty - - > - - > - - > - - > - - > - - > - - > - - Full
When the battery charge is low, a corresponding warning
message appears in the display. Charge the battery.
When the battery charge drops below the minimum status,
the phone switches off automatically.
Switching the mobile phone on and off
3 sec. Switch the mobile phone on. To stop the melody
press the End call key.
3 sec. Switch the mobile phone off. To stop the melody
press the End call key.
Note
: The Power on/off melodies can be silenced, see page 55.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
11
QUICK START GUIDE
Some SIM cards will require you to enter a PIN code. Follow
the prompts on the screen.
The SIM code (PIN of the SIM card) that you received with
your SIM card, protects the SIM card against unauthorised
use. The PIN2 code supplied with some SIM cards, you need
to access certain services. If you enter the PIN or PIN2 code
incorrectly three times in a row, you will be prompted to enter
the PUK or PUK2 code. Check with your provider if you do not
know these codes.
Make sure you are in range of your Network
Some networks offer better coverage than others in different
areas. The icon indicates you have a signal and are con-
nected to the network. The network name will also ap pear in
the display.
Setting the display language
If you want to select a different language please refer
to page 58. There are different languages available.
12
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
QUICK START GUIDE
Setting the time and date
Refer to page 57.
Taking a call
Take the call
Rejecting a call
Reject the call
Ending a call
End the call
Making a call
Enter the phone number
Clear
Delete the last digit if incorrect
Dial the phone number
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
13
QUICK START GUIDE
Advanced Settings and Functions
For more details about setting up your Amplicomms M6900
and other functions follow the descriptions in this user guide.
Examples:
• Set your one−touch dialling keys -> page 35.
• Store numbers in the phone book -> page 31.
Questions and Answers
In the majority of cases your M6900 phone is supplied with out
a SIM card. You may find the following “Questions and
Answers“ (Q & A) helpful.
Why hasn’t the mobile phone been supplied with a SIM
card?
Many people already have a mobile phone and wish to trans-
fer their existing SIM card over to the new phone. This has the
advantage of keeping the same telephone number and if the
card is subscribed to a Pay−as−you−go service then you also
14
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
QUICK START GUIDE
benefit from being able to carry over any credit that has been
paid on the card.
Where can I get a SIM card from?
Any high street mobile phone shop will be able to provide you
with a SIM card. Some of the major supermarket chains also
provide mobile phone services and can supply a SIM card. A
useful tip when choosing a SIM card / service provider howev-
er is to make sure that you have adequate signal coverage at
home; this is particularly important if you live in a very rural
area.
Why doesn’t the mobile phone have a telephone number?
The telephone number is supplied by the service provider and
will be registered onto the SIM card.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
15
QUICK START GUIDE
Can I use the SIM card from my old mobile phone?
Yes as long as the SIM card is less than three years old you
can transfer the card over. Some old SIM cards however are
not compatible with the Amplicomms mobile phone as they
are from an earlier generation of SIM card design.
Can I use a SIM card from any mobile phone company?
Yes. The Amplicomms mobile phone is what is termed as an
open SIM card phone and so it is not restricted to any particu-
lar service provider or mobile phone company.
How do I pay for my calls?
There are two main types of registration with a service
provider or mobile phone company. One is a contract − this is
where you sign up for an agreed contract over several months
/ year and pay an agreed monthly fee. This is more suited to
people who are using their mobile phone as part of their job
for example. The other is Pay−as−you−go, sometimes abbrevi-
16
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
QUICK START GUIDE
ated to PAYG. With this type of service you add credit to the
card and top up as and when required. Topping up the card is
easy, you can do this over the phone, on−line, at many shops
and even some cash points allow you to do this. PAYG is
more suited to less frequent users.
How do I find out my credit balance?
The service provider of the SIM card should have provided an
information pack with the card. This will give details of a short
number to dial in order to check your balance. These access
codes differ between mobile phone companies so please
check the details specific to your service provider. Key in your
number, press the talk button and the credit balance will be
announced to you.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
17
THE PHONE IN DETAILS
The phone in details
Keys and Parts
For the explanation of keys and parts please refer to page 6.
Special key functions
Left softkey
Right softkey
Direct call keys M1, M2, M3
In standby -> open the main menu
In menus the function changes due to
the term in the display above the soft-
key (e. g.
In standby -> open the phonebook
In menus the function changes due to
the term in the display above the soft-
key (e. g.
keys dials the assigned phone number.
A phonebook entry can be assigned to
each one−touch dialling key (refer to
“Storing a phonebook entry to a one-
OK
).
Back
).
- pressing one of these
18
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
THE PHONE IN DETAILS
touch dialling key“ page 35).
Since this operation only requires a
short press of a button, it could lead to
unintentional dialling.
Call key
- Open the call list and the redial list
End call key
- Cancel the current process and return
- Switch the mobile phone on and off
Navigation key
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
- Take a call or dial a number.
- End or reject a call
to standby (in menus)
Navigate through the menu.
In standby the up/down key offers a
quick access to specific menu items.
◄ - Calculator: quick access to the
calculator.
► - Alarm settings: quick access to
the setting of alarm times.
Note
:
19
THE PHONE IN DETAILS
▲ - User profiles: Activation /
▼ - Calendar: View the calendar and
◉ - red button in the centre of the
Digit key 0
Digit key 1
In idle mode, long press (approx 3 s)
to toggle the tone control setting
between “Low frequency“, “High fre-
quency“ and “Normal frequency“.
(See page 56 for explanation of tone
control).
Long press (approx. 3 s) dials the
number to access your voice mail
messages (to change the number,
please refer to page 40).
Note
customisation of a user profile.
add / delete events.
navigation key
In menus: function “OK“.
: If prompted, it may be neces-
20
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
THE PHONE IN DETAILS
sary to enter your network's voice mail
number first. Refer to the documenta-
tion supplied with your SIM card for
this number.
Star key
- when entering text: open the special
Hash key
Short press: - to enter the international
prefix “+“ in pre-dialling (press 2
times) or to enter P (pause)/ W (wait)
(may be necessary for call-through
numbers or remote accessing an
answering machine).
character table.
- In standby: long press (3 seconds): to
switch between ringer off (Silent mode)
and ringer on (General activated).
- when entering text: toggles between
case and numbers.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
21
THE PHONE IN DETAILS
Volume control +/- keys:
ume level of the key tone
- Whilst on a call -> adjusts the ear-
piece or Hands-free volume.
+-key
-
switches the torch on/off (will automat-
ically switch off after 30 seconds).
SOS switch
Start the SOS sequence. For details
please refer to page 51.
- In standby: adjusts the vol-
when the phone is closed:
Icons in the display
Signal strength of the phone’s connection
Battery capacity (refer to page 11)
New SMS
New call
Call forwarding active
Alarm is activated
22
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
THE PHONE IN DETAILS
Boost is activated
Ring only
Ring and vibrate
Vibrate then ring
Vibrate only
A headset is connected
Silent mode is activated
USB is connected
A stopwatch is running in the background
The “Roaming” symbol will appear if the phone switches
to an alternate network provider. This may occur for
example when entering another country. The Roaming
facility depends on your network provider. Call your network provider if you have any queries regarding this
service.
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
23
USING THE PHONE
Using the phone
General
All the functions can be accessed via the various menus.
• Use the up/down key ▲ /▼ to scroll though the menus and
the lists (e. g. phonebook).
• Press
• Press
• When entering text (e. g. phonebook or SMS) use the
Back
, to return to the last step.
OK
or
Select
to get to the next step.
#
key
to toggle between uppercase letters (ABC), lowercase let-
ters (abc), words beginning in size (Abc) or numbers (123).
Use the star key to open the special character table.
- In order to enter text in
labelled with the corresponding letter/character. If the
first character of the group is required, press the key
once. If the second character is required, press it twice,
and so on. To enter two characters assigned to the same
key, press the key the respective number of times to
Multitap
mode, press the key
24
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
USING THE PHONE
enter the first character. Then wait for approx. 2 sec. and
enter the second letter.
• Use the up/down key ▲ /▼ or ◄ or ► to place the cursor
and press
Important Note: If the display light turns off, any keystroke activates only the light again. You must press the desired button a second time to perform the function.
Switching the mobile phone on and off
Switch off
seconds the telephone will be switched off.
Switch on
play light will be switched on. Enter the PIN code for your SIM
card and press
this feature is switched off for your SIM card (refer to page 59
“SIM security“ / not available for every provider).
Delete
: Press and hold the red end call key. After a few
: Press and hold the red end call key until the dis-
for deleting characters.
OK
. Entering the PIN code is not required if
Helpline 0844 800 6503
(See page 67 for costs and hours of operation)
25
Loading...
