SVT 210AV
Speaker Cabinet
Owner’s Manual
SVT 210AV Speaker Cabinet
Important Safety Instructions
1. Read, follow, and keep these instructions. Heed all warnings.
2. This speaker is capable of producing high sound pressure levels that may cause permanent
hearing damage. User caution is advised and ear protection is recommended during use.
3. This speaker is designed for use on a sturdy, level surface. Whenever stacking speaker cabinets, do not stack more than two high.
4. Speaker cables are a tripping hazard and must be routed out of traffic areas and away from any
possible accidental contact.
5. Do not expose this speaker to rain or moisture. Do not place liquid filled containers on this
speaker. Clean only with a dry cloth.
6. Repair or service of this speaker should be performed only by qualified personnel.
Introduction
Congratulations!
You are now the proud owner of an Ampeg SVT 210AV speaker cabinet. This
cabinet has been designed to follow the classical good looks and features of our renowned
SVT-Series cabinets.
The SVT 210AV speaker cabinet is designed as an ideal companion to the Micro-VR amplifier
head, available separately.
Like all Ampeg products, your SVT 210AV cabinet is designed by musicians and built using
only the best of components. Each cabinet is tested to confirm that it meets our specifications, and we believe that this cabinet is the absolute best that it can be.
In order to get the most out of your new cabinet, please read this manual before you begin
playing.
And thank you for choosing Ampeg.
Here are some of the features packed into your new Ampeg SVT 210AV speaker cabinet:
• Detailed 1970s-era SVT series appearance
• Designed as a stack with the Micro-VR amplifier (available separately)
• Foot cups on the top panel allow secure stacking of a Micro-VR amplifier
or up to four empty shot glasses.
• Two ten-inch Eminence speakers
• Two 1/4” TS parallel input and output jacks
• Nominal impedance 8 ohms
• Power handling 200 W RMS
• Stylish top handle.
Micro-VR and
SVT 210AV
Stack
2
System Block Diagram
1
From Power Amplier
+
–
10" EMINENCE
4 OHM SPEAKERS
TWO
PARALLEL
JACKS
+
–
Rear Panel Connector Plate
SVT 210AV Speaker Cabinet
1. 1/4" TS Input and Output Jacks: Connect the speaker-level output of your amplifier
(rated up to 200W into 8 ohms) to the input jack using good quality (non-shielded) speaker cable. Never use (shielded) instrument cable to connect speakers to an amplifier.
You can use the output jack to connect a second speaker cabinet in parallel. This will
present a total load of 4 ohms to the amplifier (maximum power input = 400 watts rms
into 4 ohms).
3
SVT 210AV Speaker Cabinet
SVT 210AV TECHNICAL SPECIFICATIONS
Impedance 8 ohms
Power Rating 200 W RMS
Cabinet Construction Birch plywood
Speaker Specs Eminence Speakers
2 x 10"
Inputs 2 x 1/4" parallel jacks
Size (H x W x D) 25.2 in/640 mm (including feet and handle) x
13.0 in/330 mm x 11.0 in/280 mm
Weight 26.3 lb/11.9 kg
The SVT 210AV cabinet is covered with a durable fabric-backed vinyl material. Clean with a dry lintfree cloth. Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Ampeg continually develops new products, and improves upon existing ones. For this reason, the specifications
and information in this manual are subject to change without notice.
“Ampeg” is a registered trademark of LOUD Technologies Inc. All other brand names mentioned are trademarks
or registered trademarks of their respective holders and are hereby acknowledged.
Service Information
I
f you are having a problem with your SVT 210AV cabinet, you can go to our website
(www.ampeg.com)
ing business hours (7
your local distributor for technical support and service.
4
and click on Support for service information, or call 1-800-898-3211 dur-
am to 5 pm PST, Monday-Friday). If you are outside of the U.S., contact
Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household waste,
according to the WEEE directive (2002/96/EC) and your national law. This product should be handed over to an authorized
collection site for recycling waste electrical and electronic equipment (EEE). Improper handling of this type of waste could have
a possible negative impact on the environment and human health due to potentially hazardous substances that are generally
associated with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the effective
usage of natural resources. For more information about where you can drop off your waste equipment for recycling, please contact
your local city office, waste authority, or your household waste disposal service.
www.ampeg.com
16220 Wood-Red Road NE • Woodinville, WA 98072
@2008 LOUD Technologies Inc.
Part No. 0031573 Rev. A 08/08
