American Dynamics IPS02D2OSWTT User Manual

Configuration & User Guide

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome

Series

8200-1135-01 D0

Notice

The information in this manual was current when published. The manufacturer reserves the right to revise and improve its

products. All specifications are therefore subject to change without notice.

Copyright

Under copyright laws, the contents of this manual may not be copied, photocopied, repr oduced, translated or reduced to any

electronic medium or machine-readable form, in whole or in part, without prior written consent of Tyco Security Products. ©

2017 Tyco Security Products. All Rights Reserved.

Tyco Security Products

6600 Congress Avenue

Boca Raton, FL 33487 U.S.A.

Customer Service

Thank you for using Illustra products. We support our products thr ough an extensive worldwide network of dealers. The

dealer through whom you originally purchased this product is your point of contact if you need service or support. Our dealers

are empowered to pr ovide the very best in customer serviceand support. Dealers should contact Tyco Security Product s at

[phone] or [phone] or on the Web at www.illustracameras.com.

Trademarks

Windows®is a registered trademark of Microsoft Corporation. PS/2® is a registered trademark of International Business

Machines Corporation.

The trademar ks, logos, and service marks displayed on this document are registered in the United States [or other countries].

Any misuse of the trademar ks is strictlyprohibited and T yco Security Products. will aggr essively enforce its intellectual

property rightsto the fullest extent of the law, including pursuit of criminal prosecution wherever necessary. All trademarks not

owned by Tyco Security Products are the property of their respective owners, and ar e used with per mission or allowed under

applicable laws.

Product offerings and specifications are subject to change without notice. Actualproducts may vary from photos. Not all

products include all features. Availabilityvaries by region; contact your salesrepresentative.

License Information

Your use of this product is governed by certain terms and conditions. Please see the detailed license information at the end of

this manual.

Introduction

The Illustra Pro Series Mini Dome (hereafter referred to as the camera) is a high definition IP camera, available in
5 megapixel, 3 megapixel and 2 megapixel models. ONVIF-compatibility allows interoperability with other ONVIF­compliant third party NVRs. A built-in web server allows you to configure the camera and stream video using
Internet Explorer version 10 and higher.

The camera can operate as a standalone camera on a network however it is intended to be integrated into
sophisticated security solutions.

Please refer to the Illustra Cameras website (www.illustracameras.com) to ensure that you have the most current
version of this Configuration and User Guide. Release Notes are also available on the website for each software
release which will document any known limitations not covered in this user guide.

The following provides a list of the camera models available in the series.

Illustra Pro 2MPModels

IPS02D2ICWTT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, clear, white, TDN, TWDR

IPS02D2ICWIT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, clear, white, TDN w/IR, TWDR

IPS02D2OCWTT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, clear, white, TDN, TWDR

IPS02D2OCWIT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, clear, white, TDN w/IR, TWDR

IPS02D2ISWTT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, smoked, white, TDN, TWDR

IPS02D2ISWIT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, smoked, white, TDN w/IR, TWDR

IPS02D2OSWTT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, smoked, white, TDN, TWDR

IPS02D2OSWIT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, smoked, white, TDN w/IR, TWDR

IPS02D2ICBTT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, clear, black, TDN, TWDR

IPS02D2ICBIT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, clear, black, TDN w/IR, TWDR

IPS02D2OCBTT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, clear, black, TDN, TWDR

IPS02D2OCBIT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, clear, black, TDN w/IR, TWDR

IPS02D2ISBTT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, smoked, black, TDN, TWDR

IPS02D2ISBIT Illustra Pro 2MP Mini-dome, 3-9mm, indoor, vandal, smoked, black, TDN w/IR, TWDR

IPS02D2OSBTT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, smoked, black, TDN, TWDR

IPS02D2OSBIT Illustra Pro 2MP Mini-dome, 3-9mm, outdoor, vandal, smoked, black, TDN w/IR, TWDR

IPS02D3ICWTT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, clear, white, TDN, TWDR

IPS02D3ICWIT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, clear, white, TDN w/IR, TWDR

IPS02D3ISWTT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, smoked, white, TDN, TWDR

IPS02D3ISWIT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, smoked, white, TDN w/IR, TWDR

IPS02D3ICBTT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, clear, black, TDN, TWDR

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Configuration & User Guide 3

IPS02D3ICBIT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, clear, black, TDN w/IR, TWDR

IPS02D3ISBTT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, smoked, black, TDN, TWDR

IPS02D3ISBIT Illustra Pro 2MP Mini-dome, 9-22mm, indoor, vandal, smoked, black, TDN w/IR, TWDR

Illustra Pro 3MPModels

IPS03D2ICWTT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, clear, white, TDN, TWDR

IPS03D2ICWIT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, clear, white, TDN w/IR, TWDR

IPS03D2OCWTT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, clear, white, TDN, TWDR

IPS03D2OCWIT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, clear, white, TDN w/IR, TWDR

IPS03D2ISWTT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, smoked, white, TDN, TWDR

IPS03D2ISWIT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, smoked, white, TDN w/IR, TWDR

IPS03D2OSWTT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, smoked, white, TDN, TWDR

IPS03D2OSWIT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, smoked, white, TDN w/IR, TWDR

IPS03D2ICBTT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, clear, black, TDN, TWDR

IPS03D2ICBIT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, clear, black, TDN w/IR, TWDR

IPS03D2OCBTT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, clear, black, TDN, TWDR

IPS03D2OCBIT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, clear, black, TDN w/IR, TWDR

IPS03D2ISBTT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, smoked, black, TDN, TWDR

IPS03D2ISBIT Illustra Pro 3MP Minidome, 3-9mm, indoor, vandal, smoked, black, TDN w/IR, TWDR

IPS03D2OSBTT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, smoked, black, TDN, TWDR

IPS03D2OSBIT Illustra Pro 3MP Minidome, 3-9mm, outdoor, vandal, smoked, black, TDN w/IR, TWDR

IPS03D3ICWTT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, clear, white, TDN, TWDR

IPS03D3ICWIT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, clear, white, TDN w/IR, TWDR

IPS03D3ISWTT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, smoked, white, TDN, TWDR

IPS03D3ISWIT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, smoked, white, TDN w/IR, TWDR

IPS03D3ICBTT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, clear, black, TDN, TWDR

IPS03D3ICBIT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, clear, black, TDN w/IR, TWDR

IPS03D3ISBTT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, smoked, black, TDN, TWDR

IPS03D3ISBIT Illustra Pro 3MP Minidome, 9-22mm, indoor, vandal, smoked, black, TDN w/IR, TWDR

Illustra Pro 5MPModels

IPS05D2ICWTY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, clear, white, TDN, WDR

IPS05D2ICWIY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, clear, white, TDN w/IR, WDR

4

IPS05D2OCWTY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, clear, white, TDN, WDR

IPS05D2OCWIY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, clear, white, TDN w/IR, WDR

IPS05D2ISWTY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, smoked, white, TDN, WDR

IPS05D2ISWIY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, smoked, white, TDN w/IR, WDR

IPS05D2OSWTY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, smoked, white, TDN, WDR

IPS05D2OSWIY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, smoked, white, TDN w/IR, WDR

IPS05D2ICBTY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, clear, black, TDN, WDR

IPS05D2ICBIY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, clear, black, TDN w/IR, WDR

IPS05D2OCBTY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, clear, black, TDN, WDR

IPS05D2OCBIY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, clear, black, TDN w/IR, WDR

IPS05D2ISBTY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, black, smoked, TDN, WDR

IPS05D2ISBIY Illustra Pro 5MP Minidome, 3-9mm, indoor, vandal, black, smoked, TDN w/IR, WDR

IPS05D2OSBTY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, black, smoked, TDN, WDR

IPS05D2OSBIY Illustra Pro 5MP Minidome, 3-9mm, outdoor, vandal, smoked, black, TDN w/IR, WDR

IPS05D3ICWTY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, clear, white, TDN, WDR

IPS05D3ICWIY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, clear, white, TDN w/IR, WDR

IPS05D3ISWTY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, smoked, white, TDN, WDR

IPS05D3ISWIY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, smoked, white, TDN w/IR, WDR

IPS05D3ICBTY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, clear, black, TDN, WDR

IPS05D3ICBIY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, clear, black, TDN w/IR, WDR

IPS05D3ISBTY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, smoked, black, TDN, WDR

IPS05D3ISBIY Illustra Pro 5MP Minidome, 9-22mm, indoor, vandal, smoked, black, TDN w/IR, WDR

IPL05D2ICWCY Illustra Pro LT 5MP Minidome, 3-9mm, indoor, vandal, clear, white, color only, WDR

IPL05D2ISWCY Illustra Pro LT 5MP Minidome, 3-9mm, indoor, vandal, smoked, white, color only, WDR

IPL05D3ICWCY Illustra Pro LT 5MP Minidome, 9-22mm, indoor, vandal, clear, white, color only, WDR

IPL05D3ISWCY Illustra Pro LT 5MP Minidome, 9-22mm, indoor, vandal, smoked, white, color only, WDR

5

Web Configuration

This section details how to configure the camera using the built-in Web Configuration feature.

Note:

1 Adobe Reader must be installed to view the online help.

2 To view the video pane at the cameras best quality the latest version of QuickTime must be installed and

enabled on the computer running the browser session, this will allow for a supported stream on the
camera to be viewed on the Web User Interface. Otherwise the camera will use a lower bandwidth
stream to display live video on the Web User Interface.

3 Web Configuration sessions timeout after a period of inactivity.

4 Only users with administrative rights can access all the areas of the Web Configuration pages.

Security Mode Profiles for First Time Connection

The Illustra Pro Series Mini Dome camera now has Enhanced Security features that allow for operation in a Stand
ard Security mode or in an Enhanced Security mode.

The Enhanced Security mode of operation is used to control changes to the camera communication protocols
HTTP, HTTPS, FTP, and SMTP. When the camera is in Enhanced Security mode, a complex seven character
Administrator password is required to make changes to these protocols.

Accessing the Illustra Pro Series Camera Web User Interface

Logging in to the Camera

Use the following procedure to access the camera Web User Interface.

Procedure 2-1 Log in to the Camera

Step Action

1 Refer to the Installation chapter for details on how to connect the camera to your network or computer.

2 When the camera is selected the sign in page will be displayed.

3 Select your preferred language from the drop-down menu.

The default language is ‘English’.

4 Enter the default ID and password when prompted - ID: admin, Password: admin.

Note:

Security Profile:

The first time you access the camera, you are prompted to use either the Standard Security or Enhanced
Security. If you are keeping Standard Security, best practice is to use the Change Password check box
to immediately change the default password to one unique to your surveillance system.

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Configuration & User Guide 6

Changing the Camera Web User Interface Language

5 If you select the Enhanced Security option, you will be required and instructed to create a complex

password.

Note:

The password must meet the following requirements:

• Be a minimum of seven characters long.

• Have at least one character from at least three of the following character groups:

• Upper-case letters

• Lower-case letters

• Numeric characters

• Special characters

6 Click Log in.

The camera Web User Interface displays.

- End -

Logging out of the Camera

Use the following procedure to log off the camera Web User Interface.

Procedure 2-2 Log off the Camera

Step Action

1 Select Log Off in the upper right hand corner of the Web User Interface.

You will be logged off the camera and sign in page will be displayed.

- End -

Changing the Camera Web User Interface Language

Use the following procedure to change the language used in the camera Web User Interface.

Procedure 2-3 Change the Camera Web User Interface Language

Step Action

1 Open the camera sign in page. If you are already logged in to the Web User Interface, select Log Off to

display the sign in page.

2 Select your preferred language from the drop-down menu:

• English

• Arabic

• Czech

7

Accessing the Setup Menus from Live View

• Danish

• German

• Spanish

• French

• Hungarian

• Italian

• Japanese

• Korean

• Dutch

• Polish

• Portuguese

• Swedish

• Turkish

• Chinese Simplified

• Chinese Traditional

The default language is ‘English’.

3 Enter the Username.

4 Enter the Password.

5 Select Log in.

The camera web User Interface will be displayed in the selected language.

- End -

Accessing the Setup Menus from Live View

Setup menus within the web User Interface are restricted by user account access levels.

Refer to Appendix A: User Account Access for details on the features which are available to each role.

Procedure 2-4 Access Setup Menus from Live View

Step Action

1 When displaying full screen live video select Setup on the Web User Interface banner to access the

setup menus.

The Model page will be displayed.

Note:

When an admin user logs in for the first time the QuickStart page will be displayed. After this, on each
login the Stream page will be displayed.

8

Displaying the Live View Page

Displaying the Live View Page

Display the live camera view page.

Procedure 2-5 Display Live View Page

Step Action

1 Select Live in the Web User Interface banner.

The live view page will be displayed.

2 Select a video stream from Stream to view.

3 Select a percentage from Scale to change the display size of the video pane:

• 25%

• 50%

• 75%

• 100%

The default setting is ‘50%’

- End -

Web User Interface Icons

The following provides information on the icons used throughout the camera interface. These icons will be
referenced throughout this manual:

Select to start streaming video to the video pane.

Check box, deselected.

Delete the corresponding function.

View or activate the corresponding function.

Hide the active tab details.

Select to stop
streaming
video to the
video pane.

Check box,
selected.

Refresh the
current tab.

Edit the
corresponding
function.

Unhide the
active tab
details

Slider bar - The slider bar can be
moved left or right using the
mouse. For fine adjustments,
select the slider bar with the
mouse and use the left and right
arrow keys on the PC keyboard to
adjust the slider.

9

Video Pane

Video Pane

The video pane provides a simple way to view the live video stream from the camera when using the web User
Interface. The live viewing page however is not intended to be the primary way of viewing the video on the
camera; this should be performed using the Network Video Recording device.

Viewing Live Streams via the Video Pane

The video pane is accessible to any authorized user and is displayed when accessing the Web User Interface
menus.

Procedure 2-6 Viewing Live Video via the Video Pane

Step Action

Select the page number or arrows
to navigate through the
corresponding pages.

1 The video stream will start automatically when a page is opened.

2 Select to stop the video stream.

3 If the video has been stopped, select to start the video stream.

- End -

Maximize the Video Pane on an Active Tab

The maximize and minimize icon allows you to switch between a normal active tab layout and one where the
video pane has been maximized.

Procedure 2-7 Maximize/Minimize the Video Pane

Step Action

1 Select a tab to display from the menu.

The selected tab will be displayed.

2 Select to maximize the video pane.

10

3 Select to minimize the video pane and return to a normal active tab layout.

- End -

Quick Start Menu

When the Quick Start menu is selected Figure 3-1 Basic Configuration Page will be displayed.

Note:

When an admin user logs in for the first time the Basic Configuration page will be displayed. After this, on each
login the Video > Streams page will be displayed.

Figure 3-1 Basic Configuration Menu

The Basic Configuration menu provides access to the most common features required when setting up a camera
for the first time and is only available to an ‘admin’ user. The following tabs are displayed:

• TCP/IP

• Video Stream Settings

• Picture Basic

• Picture Additional

• Date/Time/OSD

TCP/IP

Configure the IPv4 and IPv6 network settings on the camera.

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Configuration & User Guide 11

TCP/IP

IPv4

Configure the IPv4 network settings for the camera.

Procedure 3-1 Configure the IPv4 Settings

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the TCP/IP tab in the Basic Configuration menu.

3 Select the Enable DHCP check box to enable DHCP and disable manual settings.

OR

Deselect Enable DHCP to disable DHCP and allow manual settings to be entered.

The default setting is ‘Enabled’.

4 If Enable DHCP has been disabled:

a Enter the IPv4 Address in the IPv4 Address text box in the form xxx.xxx.xxx.xxx.

The default setting is ‘192.168.1.168’

b Enter the Network Mask in the Network Mask text box xxx.xxx.xxx.xxx.

The default setting is ‘255.255.255.0’

c Enter the Gateway IP address in Gateway text box xxx.xxx.xxx.xxx.

d Enter the Primary DNS Server in the Primary DNS Server text box xxx.xxx.xxx.xxx.

5 Select Apply to save the settings.

- End -

IPv6

Enable or disable IPv6 on the camera.

Procedure 3-2 Enable/Disable IPv6

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the TCP/IP tab in the Basic Configuration menu.

3 Select the IPv6 Enable check box to enable IPv6 on the camera.

OR

Deselect the IPv6 Enable check box to disable IPv6 on the camera.

The default setting is ‘Enabled’.

If IPv6 is enabled the Link Local and DHCP address will be displayed beside ‘Current IPv6 Addresses’ if
available.

12

- End -

Video Stream Settings

Video Stream Settings

The camera allows the configuration of three video streams; Stream 1, Stream 2 and Stream 3. These streams
can be configured via the Web User Interface, as detailed here or via the Illustra API or Network Video Recorder.

Configuring the Web Video Stream

Adjust the settings for each video stream.

Procedure 3-3 Configure the Video Stream settings

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Streams tab in the Basic Configuration menu.

3 Select either Stream 1, 2 or 3 from the Stream Number drop-down menu.

4 Select the required Codec by selecting the radio buttons:

• H264

• MJPEG

The default setting is ‘H264’.

5 Select the required Resolution from the drop-down menu.

The resolutions available will depend on the Image Source selected:

2MP

Stream 1 Stream 2 Stream 3

(1920x1080) 1080p 16:9 (1280x720) 720p 16:9 (1024x576) PAL+ 16:9

(1664x936) 16:9 (1024x576) PAL+ 16:9 (640x360) nHD 16:9

(1280x720) 720p 16:9 (640x360) nHD 16:9 (384x216) 16:9

(1024x576) PAL+ 16:9 (384x216) 16:9

(640x360) nHD 16:9

(384x216) 16:9

3MP

Stream 1 Stream 2 Stream 3

13

(2048x1536) QXGA 4:3 (1280x720) 720p 16:9 (1024x576) PAL+ 16:9

(1920x1440) 4:3 (1024x768) 1024 XGA 4:3 (960x720) 4:3

(1920x1080) 1080p 16:9 (1024x576) PAL+ 16:9 (768x576) 4:3

(1600x1200) UXGA 4:3 (768x576) 4:3 (640x480) 640 VGA 4:3

Video Stream Settings

3MP

Stream 1 Stream 2 Stream 3

(1280x960) SXGA 4:3 (640x480) 640 VGA 4:3 (640x360) nHD 16:9

(1280x720) 720p 16:9 (640x360) nHD 16:9 (480x360) 480 4:3

(1024x768) 1024 XGA 4:3 (480x360) 480 4:3 (384x288) 4:3

(1024x576) PAL+ 16:9 (384x288) 4:3 (384x216) 16:9

(768x576) 4:3 (384x216) 16:9

(640x480) 640 VGA 4:3

(640x360) nHD 16:9

(480x360) 480 4:3

(384x288) 4:3

(384x216) 16:9

5MP

Stream 1 Stream 2 Stream 3

(2592x1944) 4:3 (H264 Only) (1920x1080) 1080p 16:9 (1024x576) PAL+ 16:9

(1920x1440) 4:3 (1600x1200) UXGA 4:3 (920x720) 4:3

(1920x1080) 1080p 16:9 (1280x960) SXGA 4:3 (768x576) 4:3

(1600x1200) UXGA 4:3 (1280x720) 720p 16:9 (640x480) 640 VGA 4:3

(1280x960) SXGA 4:3 (1024x768) 1024 XGA 4:3 (640x360) nHD 16:9

(1280x720) 720p 16:9 (1024x576) PAL+ 16:9 (480x360) 480 4:3

(1024x768) 1024 XGA 4:3 (768x576) 4:3 (384x288) 4:3

(1024x576) PAL+ 16:9 (640x480) 640 VGA 4:3 (384x216) 16:9

(768x576) 4:3 (640x360) nHD 16:9

(640x480) 640 VGA 4:3 (480x360) 480 4:3

(640x360) nHD 16:9 (384x288) 4:3

(480x360) 480 4:3 (384x216) 16:9

(384x288) 4:3

(384x216) 16:9

14

6 Use the slider bar to select the Frame Rate (ips).

The settings are:

2MP

Video Stream Settings

• Stream 1 - 1 - 30 ips, default 30.

• Stream 2 - 1 - 15 ips, default 15.

• Stream 3 - 7ips fixed.

3MP

• Stream 1 - 1 - 30 ips, default 30.

• Stream 2 - 1 - 15 ips, default 15.

• Stream 3 - 7ips fixed.

5MP

• Stream 1 - 1 - 15 ips, default 15.

• Stream 2 - 1 - 15 ips, default 15.

• Stream 3 - 7ips fixed.

7 If MJPEG has been selected, MJPEG Quality will be enabled. Use the slider bar to select the MJPEG

Quality.

The default setting is 50.

OR

8 If H264 has been selected in step 4, Rate Control will be enabled. Select the required Rate Control by

selecting the radio buttons:

• VBR (Variable Bit Rate)

• CBR (Constant Bit Rate)

The default setting is ‘VBR’.

a If VBR has been selected, VBR Quality will be enabled. Select the required VBR Quality from the

drop-down menu.

• Highest

• High

• Medium

• Low

• Lowest

The default setting is ‘High’.

OR

b If CBR has been selected, CBR Bit Rate will be enabled. Use the slider bar to select the CBR Bit

Rate.

The default setting is 1000.

15

9 Select the Enable Gaming Mode checkbox to enable gaming mode

OR

De-select the Enable Gaming Mode checkbox to disable gaming mode.

The default setting is 'Disabled'. Refer to Quick Start Menu

Gaming Mode

Gaming Mode

Specifically designed for multiple gaming industries, e.g., casino, Gaming Mode maintains Frame Rate as a
priority to meet the demanding requirements of gaming environments. The default setting is OFF.

Note:

Gaming mode can be enabled or disabled for the primary stream (Stream 1).

Note:

If the camera requires FPS adjustment during Gaming mode, this can be applied via the recorder (using the Illustra
API (IAPI). The camera will continue to provide frame rate a priority at the new set FPS value.

Frame Rate Fixed to 30 FPS / 3MP, 15 FPS / 5MP,30 FPS / 2MP.

GOP Fixed to 30 / 3MP, 15 / 5MP, 30/2MP.

Max Exposure Fixed to 1/30 for 3MP, 1/15 for 5MP, 1/30 for 2MP.

Fixed Item Fixed Value

Picture Basic

Adjust Picture Rotation, Focus / Zoom and Exposure displayed in the video pane.

Picture Rotation

Configure the orientation and corridor mode settings. Both settings are optional.

Procedure 3-4 Configure Orientation Settings

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select the required Orientation setting:

• Mirror

• Flip

The video pane will update to display the new settings.

Note:

When wall mounting the camera you should select Flip and Mirror to correct the lens orientation.

16

- End -

Picture Basic

Corridor Mode

Provides a better perspective when viewing a long corridor.

Note:

This feature is only available on the 2MPcamera models.

Procedure 3-5 Configure Corridor Mode Settings

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

4 Select the required Corridor Mode setting:

• None

• -90°

• +90°

The video pane will update to display the new settings.

- End -

Focus / Zoom

The Focus is manually configured on initial setup. The One Touch button can be used to automatically focus the
area of view highlighted in the yellow outlined box displayed on the video pane. This box can be moved and
resized as required and subsequent manual adjustments can be applied if required using the plus and minus
values. The plus and minus arrows are used to manually fine tune the image.

The Zoom slider bar is used to manually zoom in and out to manually configure to picture.

When IR Compensate is enabled, the camera refocuses within 30 seconds of the mode transisition between day
to night mode and night to day mode.

Procedure 3-6 Adjust Camera Focus / Zoom

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

4 Use the plus and minus arrows to manually configure the focus and the slider bar to adjust zoom settings

until the image is clear.

17

The video pane will update to display the new settings.

- End -

Picture Basic

Procedure 3-7 Adjust Camera Focus using OneTouch Autofocus

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

4 Draw a region around the area to be focused on within the image.

5 Select the One Touch button.

Procedure 3-8 Enable/Disable IR Compensate

1 Select Setup on the Web User Interface banner to display the setup menus.

The camera refocuses to the optimal zoom level for the image.

The video pane will update to display the new settings.

- End -

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select the IR compensate check box to enable IR compensation

OR

Clear the IR compensate check box to disable IR compensation.

- End -

Exposure

Configure the exposure settings for the camera.

Procedure 3-9 Configure Exposure Settings

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Settings tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

4 Select the Exposure Method from the drop-down menu:

• Full Picture Weighted - exposure calculations are based on the entire image.

• Center Weighted - exposure calculations are based on a region around the center of the
image.

18

• Spot - exposure calculations are based on the very center of the image.

• ROI Weighted - exposure calculations are based on a region of interest selected.

The default setting is Center Weighted.

5 Select the Exposure Offset (F-Stops) from the drop-down menu.

Picture Additional

6 Select the Max Exposure from the drop-down menu.

7 Select the Max Gain from the drop-down menu.

8 Select the Bright objects from the drop-down menu.

9 Select the Flicker control from the drop-down menu.

Procedure 3-10 Restore Exposure Defaults

Step Action

The default setting is 0.0.

The default setting is 1/4 for 5MP, 1/8 for 3MP and 1/8 for 2MP.

The default setting is30db for 5MP, 42db for 3MP and 42db for 2MP.
The video pane will update to display the new settings.

The default setting isauto.

50 Hz= max 25 fps

60Hz = max 30 fps

The default setting is60HZ.

- End -

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Settings tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

4 Select Exposure Defaults to restore the default settings.

The default values are:

• Exposure Method: Center Weighted

• Exposure Offset (F-Stops): 0

• Max Exposure (sec): 1/30 for 5MP, 1/8 for 3MP and 1/8 for 2MP

• Max Gain (dB): 30db for 5MP, 42db for 3MP and 42db for 2MP

• Bright objects: auto

• Flicker control (Hertz): 60HZ

Picture Additional

Configure Wide Dynamic Range, Day Night Mode, Flicker Control and Picture Adjustments including Brightness,
Contrast, White Balance, Saturation and Sharpness displayed in the video pane.

- End -

Wide Dynamic Range

Wide Dynamic Range (WDR) is a feature that allows viewing of high contrast scenes that include both bright and
low light areas in the same field of view (FOV).

19

Picture Additional

WDR Level allows you to adjust the WDR level to favour a underexposed or overexposed image. By selecting the
lower end of the control the image is underexposed which provides more detail in areas of bright but less details in
areas of darkness. Selecting the higher end of the control the image is overexposed which provides more detail in
the dark areas but less details in the bright areas.

A typical use for this feature would be viewing a scene with both indoor and outdoor lighting conditions
simultaneously, for example, in a warehouse area with an open bay door.

Procedure 3-11 Disable/Enable Wide Dynamic Range (WDR)

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Additional tab from the Basic Configuration menu.

3 Select the required WDR from the drop down list:

4 Use the slider bar to adjust the WDR Level.

• WDR

• True WDR

The video pane will update to display the new settings.

The values range from 1-10.

The default value is 5.

- End -

Day Night Mode

IR/DayNight Mode utilizes a series of specific camera functions to dramatically enhance low light performance.

When needed one of these functions, the True TDN mechanism, removes an IR Cut Filter (IRCF) from in front of
the imager allowing the camera to see in black and white (BW) and utilize additional near-infrared energy found in
many lighting sources like halogen, moonlight, etc.

This, along with slowing down another function, the shutter speed, significantly improves low light performance
rendering clear images where none could be viewed previously.

IR Illuminator

When the camera is in B/W mode it can utilize or “see” near-IR illumination; something the human eye cannot do.
This can be extremely powerful when the dome is paired with 850~950nm IR illuminators. With this combination a
scene can be well lit with IR light that the dome can see but people cannot. This is great for areas where externally
lighting is not allowed or there is a need for covert security.

Imager Resolution 5 Megapixel 5 Megapixel 3 Megapixel 3 Megapixel 2 Megapixel 2 Megapixel

Lens

3 to 9 mm

Lens

9 to 22 mm

Lens

3 to 9 mm

Lens

9 to 22 mm

Lens

3 to 9 mm

Lens

9 to 22 mm

Lens

Min. illumination color

Min. illumination b/w

20

(Lux):

(Lux):

0.3 0.4 0.05 0.06 0.03 0.04

0.02 0.03 0.003 0.004 0.001 0.002

Picture Additional

Dynamic range (db) 90 90 96 96 96 96

Procedure 3-12 Enable / Disable IR Illuminator

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Additional from the Basic Configuration menu.

3 Select the Enable IR Illuminator check box to enable IR Illuminator.

OR

Deselect the Enable IR Illuminator check box to disable IR Illuminator.

The default setting is ‘Enabled’.

- End -

Day Night Mode

The dome provides a black-and-white (B/W) mode to improve camera performance when the light level falls below
certain thresholds. This allows clear images to be obtained under low-light conditions. There are three Day/Night
settings:Forced Color, Forced B/W and Auto.

Procedure 3-13 Configure Day Night Mode

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Additional from the Basic Configuration menu.

3 Select a Day Night Mode setting from the drop-down menu:

• Forced Color - enable full-time color mode.

• Forced B/W - enable full-time black and white mode.

• Auto Low- camera will adjust between BW and Color depending on light levels.

• Auto Mid - camera will give a good balance of Color and BW depending on the scene.

• Auto High - increases the chance of switching to BWmode as light levels drop.

• Manual - a slider bar will display, the user can adjust the setting to suit the environment.

The default setting is 'Auto Low'.

- End -

Picture Adjustment

Adjust brightness, contrast and saturation of the image displayed on the video pane.

21

Procedure 3-14 Adjust the Brightness, Contrast and Saturation

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Additional tab from the Basic Configuration menu.

Picture Additional

3 Select to start the video stream if it is not already active.

4 Use the slider bars to adjust:

Procedure 3-15 Restore Picture Balance Defaults

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Picture Settings tab from the Basic Configuration menu.

The video pane will display the current camera view.

• Brightness

• Contrast

• Saturation

• Sharpness

The video pane will update to display the new settings.

The values range from 0% to 100%.

- End -

3 Select Defaults to restore the default settings.

The default values are:

• Brightness: 50%

• Contrast: 50%

• Saturation: 50%

• Sharpness: 50%

- End -

White Balance

White balance (the ability to keep whites looking white) is normally compensated for automatically via the default
Auto White Balance setting.

Manual White Balance is available when specific color temperature settings want to be set and preserved. This
can be done using the red and blue slider adjustments set for optimal viewing.

Procedure 3-16 Configure Auto White Balance

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

22

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

The video pane will display the current camera view.

4 Select the required White Balance from the drop-down menu:

Lens Calibration

Procedure 3-17 Manually Select White Balance

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

• Auto Wide: Suitable for a wider than normal range of lighting conditions

• Auto Normal: Suitable for a normal range of lighting conditions

• Sunny: Suitable for sunny conditions

• Shadow: Suitable for shady conditions

• Indoor: Suitable for indoor conditions

• Lamp: Suitable for artificial light conditions

• Manual: Adjustable red and blue balance

• ROI Manual

• ROI Auto

The default setting is ‘Auto Normal’.

- End -

2 Select the Picture Basic tab from the Basic Configuration menu.

3 Select to start the video stream if it is not already active.

The video pane will display the current camera view.

4 Select Manual from the White Balance drop-down menu.

The Red and Blue slider bars will be displayed.

5 Use the slider bars to adjust the Red and Blue balance.

The live video pane will update to display the new settings.

The red and blue values range from 1% to 100%.

The default settings are Red 18% and Blue 18%.

Lens Calibration

Use the lens calibration process to recover focus and zoom after motor stalling has occurred. Motor step stalling
is rare but it can occur during shipping or through mishandling of the camera. If the One Touch focus at Wide or
Tele is not working through the zoom range, the camera requires lens calibration. The lens calibration tool uses
infinity focus curves to align the camera lens and correct problems focusing at Wide or Tele.

- End -

23

You can run a lens calibration from the Lens Calibration tab.

Note:

Objects at least 30 feet (9.144m) away from the camera sholud be in the Field Of Vision

Date / Time / OSD

Procedure 3-18 Run a Lens Calibration

Step Action

1 Select Setup on the Web Interface Banner to display the setup menus.

2 Select Picture Settings from the Video menu.

3 Select the Lens Calibration tab.

4 Select Start Calibration and wait for the camera lens initialization to complete.

5 Drag the Step 1: Focus at WIDE slider bar up and down until you are satisfied with the picture focus,

6 Drag the Step 2: Focus at TELE slider bar up and down until you are satisfied with the picture focus,

7 Drag the Step 3: Re Focus at TELE slider bar up and down until you are satisfied with the picture focus,

8 To confirm the success of the lens calibration, selec the Picture Basic tab from the Picture Settings

and select Apply to apply your changes.

and select Apply to apply your changes.

and select Apply to apply your changes.

menu and verify that the image is in focus through the zoom range.

Use the OneTouch button to automatically focus the area of view highlighted in the yellow box displayed
in the video pane.

Date / Time / OSD

Change the camera name, date and time and enable OSD.

Camera Name

The camera name will be displayed on the Web User Interface banner and the on-screen display for the camera.
This name will also be displayed when using Illustra Connect or ONVIF.

Procedure 3-19 Change the Camera Name

Step Action

1 Select Setup on the Web User Interface banner.

2 Select the Date/Time/OSD tab in the Basic Configuration menu.

3 Enter the name of the camera in the Camera Friendly Name text box.

- End -

- End -

24

Date / Time / OSD

Date / Time

Set the date and time on the camera.

Procedure 3-20 Configuring the Date and Time

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Date/Time/OSD from the Basic Configuration menu.

3 Select the Time 24-hour check box to enable the 24-hour clock.

4 Select the Date Display Format from the drop-down menu:

Or

Deselect the Time 24-hour check box to enable the 12-hour clock.

The default setting is ‘24-hour’.

• DD/MM/YYYY

• MM/DD/YYYY

• YYYY/MM/DD

The default setting is ‘YYYY/MM/DD’.

5 Select the Time Zone from the drop-down menu.

The default setting is ‘(GMT-05:00) Eastern Time (US & Canada)

6 Select the Set Time setting by selecting the radio buttons:

• Manually

• via NTP

The default setting is ‘Manually’.

7 If you select Manually in step 5:

c Select the Date (DD/MM/YYYY) using the drop-down menus.

d Select the Time (HH:MM:SS) using the drop-down menus.

8 If you select via NTP in step 5:

a Enter the NTP Server Name in the text box.

- End -

On-Screen Display (OSD)

25

Within OSD you can set enable or disable camera name and time display.

Date / Time / OSD

Procedure 3-21 Display or Hide the Camera Name OSD

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Date/Time/OSD tab in the Basic Configuration menu.

3 Select the Camera Name check box to display the camera name in the OSD.

Procedure 3-22 Display or Hide the Camera Time OSD

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Date/Time/OSD tab in the Basic Configuration menu.

OR

Deselect the Camera Name check box to hide the camera name in the OSD.

The default setting is ‘Disabled’.

- End -

3 Select the Time check box to display the camera name in the OSD.

OR

Deselect the Time check box to hide the camera name in the OSD.

The default setting is ‘Disabled’.

- End -

26

When the video menu is selected Figure 4-1 Video Menu will be displayed.

Video Menu

The Video Menu provides access to the following camera settings and functions:

• Streams

• Picture Settings

• Date / Time / OSD

• Privacy Zones

Streams

The camera allows the configuration of up to three independent video streams: Stream 1, Stream 2 and Stream 3.
These streams can be configured via the Web User Interface, as detailed here or via the Illustra API.

Video displayed on the video pane will reflect the settings configured in the stream selected from the drop-down
menu, either Stream 1 or Stream 2 or Stream 3.

Figure 4-1 Video Menu

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Configuration & User Guide 27

Configuring the Video Stream

Caution

Note:

Stream 3 will be used by the Web User Interface when no Quicktime application is present on the PC. To obtain
the cameras highest resolution video on the Web User Interface, Quicktime should be downloaded and installed.

Alarm Video

Edge Recording

Camera can directly record specific events (MD, DIO and Face detection) directly to SD card. User can chose
either Stream 1, 2 or 3 to be recorded. When setting up motion detection on the camera, both streams can be
used. Alarm Video is configured in the Edge Recording > Record Settings menu.

Integration with other Illustra API Clients

The 3 video streams can be configured via the Web User Interface, as detailed here, or via the Illustra API
interface. Changes made to the streams via either method will be applied and the video will be displayed
according to the configuration.

Opening the Web User Interface live video will allow the stream to be shared with the Illustra API and will
minimize the impact on camera resources.

Configuring the Video Stream

Adjust the settings for each video stream.

Procedure 4-1 Configure the Video Stream settings

Step Action

1 Select Setup on the Web User Interface banner to display the setup menus.

2 Select the Streams tab in the Video menu.

3 Select Stream1 , 2or 3,from the Stream Number drop-down menu.

4 Select the required Codec by selecting the radio buttons:

• H264

• MJPEG

28

The default setting is ‘H264’.

5 Select the required Resolution from the drop-down menu.

The resolutions available will depend on the model selected:

Configuring the Video Stream

(1920x1080) 1080p 16:9 (1280x720) 720p 16:9 (1024x576) PAL+ 16:9

(1280x720) 720p 16:9 (640x360) nHD 16:9 (384x216) 16:9

(1024x576) PAL+ 16:9 (384x216) 16:9

(2048x1536) QXGA 4:3 (1280 x720) 720p 16:9 (1024x576) PAL+ 16:9

2MP

Stream 1 Stream 2 Stream 3

(1664x936) 16:9 (1024x576) PAL+ 16:9 (640x360) nHD 16:9

(640x360) nHD 16:9

(384x216) 16:9

3MP

Stream 1 Stream 2 Stream 3

(1920x1440) 4:3 (1024x768) 1024 XGA 4:3 (960x720) 4:3

(1920x1080) 1080p 16:9 (1024x576) PAL+ 16:9 (768x576) 4:3

(1600x1200) UXGA 4:3 (768x576) 4:3 (640x480) 640 VGA 4:3

(1280x960) SXGA 4:3 (640x480) 640 VGA 4:3 (640x360) nHD 16:9

(1280x720) 720p 16:9 (640x360) nHD 16:9 (480x360) 480 4:3

(1024x768) 1024 XGA 4:3 (480x360) 480 4:3 (384x288) 4:3

(1024x576) PAL+ 16:9 (384x288) 4:3 (384x216) 16:9

(768x576) 4:3 (384x216) 16:9

(640x480) 640 VGA 4:3

(640x360) nHD 16:9

(480x360) 480 4:3

(384x288) 4:3

(384x216) 16:9

5MP

29

Stream 1 Stream 2 Stream 3

(2592x1944) 4:3 (H264 Only) (1920x1080) 1080p 16:9 (1024x576) PAL+ 16:9

(1920x1440) 4:3 (1600x1200) UXGA 4:3 (920x720) 4:3

(1920x1080) 1080p 16:9 (1280x960) SXGA 4:3 (768x576) 4:3

Configuring the Video Stream

(1600x1200) UXGA 4:3 (1280x720) 720p 16:9 (640x480) 640 VGA 4:3

(1280x960) SXGA 4:3 (1024x768) 1024 XGA 4:3 (640x360) nHD 16:9

(1280x720) 720p 16:9 (1024x576) PAL+ 16:9 (480x360) 480 4:3

(1024x768) 1024 XGA 4:3 (768x576) 4:3 (384x288) 4:3

(1024x576) PAL+ 16:9 (640x480) 640 VGA 4:3 (384x216) 16:9

(640x480) 640 VGA 4:3 (480x360) 480 4:3

(640x360) nHD 16:9 (384x288) 4:3

(480x360) 480 4:3 (384x216) 16:9

5MP

Stream 1 Stream 2 Stream 3

(768x576) 4:3 (640x360) nHD 16:9

(384x288) 4:3

(384x216) 16:9

6 Use the slider bar to select the Frame Rate (ips).

The settings are:

2MP

• Stream 1 - 1 - 30 ips, default 30.

• Stream 2 - 1 - 15 ips, default 15.

• Stream 3 - 7ips fixed.

3MP

• Stream 1 - 1 - 30 ips, default 30.

• Stream 2 - 1 - 15 ips, default 15.

• Stream 3 - 7ips fixed.

5MP

• Stream 1 - 1 - 15 ips, default 15.

• Stream 2 - 1 - 15 ips, default 15.

• Stream 3 - 7ips fixed.

7 If MJPEG has been selected, MJPEG Quality will be enabled. Use the slider bar to select the MJPEG

Quality.

30

The default setting is 50.

OR

8 If H264 has been selected in step 4, Rate Control will be enabled. Select the required Rate Control by

selecting the radio buttons:
