Amana NFW7300WW User Manual
FRONT-LOADING
AUTOMATIC WASHER
Use & Care Guide
For questions about features, operation/performance, parts,
accessories, or service, call: 1-800-843-0304
or visit our website at...
www.amana.com
In Canada, call: 1-800-807-6777
or visit our website at...
www.amanacanada.ca
LAVEUSE AUTOMATIQUE
À CHARGEMENT
FRONTAL
Guide d'utilisation et d'entretien
Pour assistance, installation, ou service, composez le : 1-800-807-6777
ou visitez notre site internet à..
www.amana.ca
TABLE OF CONTENTS
Page
WASHER SAFETY .......................................................................................2
INSTALLATION REQUIREMENTS .............................................................3
Tools and Parts.........................................................................................3
Options...................................................................................................... 3
Location Requirements.............................................................................3
Drain System.............................................................................................5
Electrical Requirements............................................................................ 6
INSTALLATION INSTRUCTIONS ...............................................................7
Remove Transport System.......................................................................7
Connect the Inlet Hoses ...........................................................................7
Connect the Drain Hose ...........................................................................8
Secure the Drain Hose..............................................................................9
Level the Washer ......................................................................................9
Complete Installation ................................................................................9
FEATURES AND BENEFITS .....................................................................10
WASHER USE ............................................................................................11
Starting Your Washer..............................................................................11
Using the Proper Detergent....................................................................11
Using the Dispenser................................................................................12
Pausing or Restarting .............................................................................13
Changing Cycles and Options................................................................13
Status Lights ...........................................................................................13
Cycles .....................................................................................................13
Normal Sounds.......................................................................................14
Options....................................................................................................14
LAUNDRY TIPS..........................................................................................15
WASHER CARE .........................................................................................17
TROUBLESHOOTING ...............................................................................19
WARRANTY ...............................................................................................23
ASSISTANCE OR SERVICE..................................................BACK COVER
TABLE DES MATIÈRES
Page
SÉCURITÉ DE LA LAVEUSE ....................................................................24
EXIGENCES D'INSTALLATION................................................................25
Outillage et pièces .................................................................................. 25
Options ................................................................................................... 25
Exigences d'emplacement ..................................................................... 25
Système de vidange...............................................................................27
Spécifications électriques...................
INSTRUCTIONS D'INSTALLATION ......................................................... 29
Élimination des accessoires de transport .............................................. 29
Raccordement des tuyaux d'alimentation
Raccordement du tuyau de vidange..
Immobilisation du tuyau de vidange ......................................................31
Réglage de l'aplomb de la laveuse ........................................................ 31
Achever l'installation............................................................................... 31
CARACTÉRISTIQUES ET AVANTAGES.................................................. 32
UTILISATION DE LA LAVEUSE................................................................33
Mise en marche de la laveuse.........
Utilisation du détergent approprié..........................................................33
Utilisation du distributeur........................................................................ 34
Pause ou remise en marche...................................................................35
Modification des programmes et options.............................................. 35
Témoins lumineux................................................................................... 35
Programmes ...........................................................................................36
Sons normaux.........................................................................................37
Options ................................................................................................... 37
CONSEILS DE LESSIVAGE ...................................................................... 38
ENTRETIEN DE LA LAVEUSE.................................................................. 40
DÉPANNAGE .............................................................................................42
GARANTIE..................................................................................................47
ASSISTANCE OU SERVICE............................... COUVERTURE ARRIÈRE
.................................................... 28
............................................. 29
.................................................... 30
....................................................... 33
W10252719A
WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
You can be killed or seriously injured if you don't immediately
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
follow instructions.
can be killed or seriously injured if you don't
You
instructions.
follow
2
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
The parts supplied are in the washer drum.
Tools needed for connecting the water inlet hoses
■ Pliers (that open to 1
■ Flashlight (optional)
Tools needed for connecting the drain hose
■ Locking pliers (that open to 1
Tools needed for installation
■ Open end wrenches 14 mm and 13 mm
■ Level
■ Wood block
■ Ruler or measuring tape
Parts supplied
A B
EF
A. Drain hose form
B. Inlet hose (2)
C. Inlet hose washer (4)
D. Drain hose
Alternate Parts
Your installation may require additional parts. If you are interested
in purchasing one of the items listed here, call the toll-free number
on the cover or in the “Assistance or Service” section.
If You Have You Will Need to Buy
Laundry tub or
standpipe taller
an 96" (2.4 m)
th
Overhead sewer Standard 20 gal. (76 L), 30" (762 mm) tall
Floor drain Siphon break, Part Number 285320;
Drain hose too
short
Water faucets
beyond reach of fill
hoses
9
/16" [39.5 mm])
9
/16" [39.5 mm])
C
D
G
E.Transport bolt hole plug (4)
F. B e a d e d s t ra p
G. Hose clamp
Sump pump system (if not already
available)
tub or utility sink and sump pump
drain
(available from local plumbing suppliers)
add
itional drain hose
Part Number 8318155; and connector
t Number 2858835
kit, Par
4 ft. (1.2 m) drain hose extension kit,
Part Number 2858863
Longer water fill hose:
10 ft. (3.0 m) Part Number 8212656RP
Options
Pedestal
You have the option of purchasing pedestal separately for this
washer. You may select a 10" (254 mm) or a 15.5" (394 mm)
pedestal. The pedestal will add to the total height of the washer.
Optional pedestal
Pedestal
Height
Approximate
Height with
Color Model
Number
Washer
10" (254 mm) 46" (1168 mm) White MHP1000SQ
15.5" (394 mm) 51.5" (1308 mm) White XHP1550VW
Stack Kit
Are you planning to stack your washer and dryer? To do so you
will need to purchase a Stack Kit.
To order, call the dealer from who
m you purchased your washer or
refer to the “Assistance or Service” section. Ask for Part Number
8572546.
Location Requirements
Selecting the proper location for your washer improves
performance and minimizes noise and possible washer “walk.”
Your washer can be installed under a custom counter, or in a
basement, laundr
System.”
Companion appliance location req
considered. Proper installation is your responsibility.
You will need
■ A water heater set to deliver 120°F (49°C) water to the washer.
■ A grounded electrical outlet located within 6 ft. (1.8 m) of
where the power cord is attached to the back of the washer.
See “Electrical Requirements.”
■ Hot and cold water faucets located within 4 ft. (1.2 m) of the
hot and cold water fill valves, and water pressure of
20-100 psi (137.9-689.6 kPa).
■ A level floor with a maximum slope of 1" (25 mm) under entire
washer. Installing the washer on soft floor surfaces, such as
carpets or surfaces with foam backing, is not recommended.
■ A sturdy and solid floor to support the washer with a total
weight (water and load) of 400 lbs. (180 kg).
Do not operate your washer in t
Some water can remain in the washer and can cause damage in
low temperatures.
y room, closet, or recessed area. See “Drain
uirements should also be
emperatures below 32°F (0°C).
3
Installation clearances
■ The location must be large enough to allow the washer door
to be fully opened.
■ Additional spacing should be considered for ease of
installation and servicing. The door opens more than 90°,
and it is not reversible.
■ Additional clearances might be required for wall, door, and
floor moldings.
■ Additional spacing of 1" (25 mm) on all sides of the washer
is recommended to reduce noise transfer.
■ Companion appliance spacing should also be considered.
Washer Dimensions
27
"
5
01/4"
(1276 mm)
(686 mm)
36
"
(914 mm)
Recommended spacing for recessed or closet installation,
with or without a pedestal
The dimensions shown are for the recommended spacing.
Recessed area or closet installation
48
"
1
"
(25 mm)
(1220 mm)
301/2"
(775 mm)
4
"
(102 mm)
(310 cm2)
(155 cm2)
A
A. Side view - closet or confined area
B. Closet door with vents
48 in.
24 in.
(76 mm)
2
2
(76 mm)
B
3
"
3
"
301/2"
(775 mm)
Recommended spacing for custom undercounter installation
The dimensions shown are for the recommended spacing.
Custom undercounter installation - Washer only
2
" (50 mm)
36
" min.
(914 mm)
27
1
"
(25 mm)
"
(686 mm)
1
"
(25 mm)
Recessed or closet installation - W
1
1
"
(25 mm)
27
"
(686 mm)
"
(25 mm)
(25 mm)
A B
A. Recessed area
B. Side view - closet or confined area
asher on pedestal
38
" min.
(965 mm)
1
"
301/2"
(775 mm)
4
(102 mm)
"
4
Recommended spacing for recessed or closet installation,
with stacked washer and dryer
The dimensions shown are for the recommended spacing.
2
*
48 in.
2
(310 cm
)
2
*
24 in.
2
(155 cm
)
3"
(76 mm)
3"
(76 mm)
12
" (305 mm)
1
" (25 mm)
Drain System
The washer can be installed using the standpipe drain system
(floor or wall), the laundry tub drain system, or the floor drain
system. Select the drain hose installation method you need.
See “Tools and Parts.”
Standpipe drain system - wall or floor (views A & B)
The standpipe drain requires a minimum diameter standpipe of
2" (50 mm). The minimum carry-away capac
than 17 gal. (64 L) per minute.
The top of the standpipe
must be at least 30" (762 mm) high
and no higher than 96" (2.4 m) from the bottom of the washer.
30
" min.
(762 mm)
ity can be no less
72
"
(1829 mm)
1
51/4"**
(133 mm)
1
"***
(25 mm)
27
"
(686 mm)
"***
(25 mm)
*Min. top and bottom air openings for closet door.
**External exhaust elbow requires additional space.
***Wall, door, and floor molding may r
equire additional spacing.
Recommended spacing for cabinet installation
The dimensions shown are for the recommended spacing.
For cabinet installation, with a door, the minimum ventilation
openings in the top are required.
7
"
(178 mm)
7
"
(178 mm)
9
"
(229 mm)
A B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L) capacity. The top
of the laundry tub must be at least 30" (762 mm) above the floor.
Floor drain system (view D)
The floor drain system requires a siphon break that may be
purchased separately. See “Tools and Parts.”
The siphon break must be a minimum
bottom of the washer. Additional hoses might be needed.
30
" min.
(762 mm)
C D
of 28" (710 mm) from the
28
" min.
(710 mm)
4
"
(102 mm)
1
31
"
/2
(800 mm)
1
"
(25 mm)
27
"
(686 mm)
1
"
(25 mm)
5
Electrical Requirements
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
■ A 120 volt, 60 Hz., AC only, 15- or 20-amp, fused electrical
supply is required. A time-delay fuse or circuit breaker is
recommended. It is recommended that a separate circuit
serving only this appliance be provided.
■ This washer is equipped with a power supply cord having a
3 prong grounding plug.
■ To minimize possible shock hazard, the cord must be plugged
into a mating, 3 prong, grounding-type outlet, grounded in
ccordance with local codes and ordinances. If a mating
a
outlet is not available, it is the personal responsibility and
obligation of the customer to have the properly grounded
outlet installed by a qualified electrician.
■ If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
■ Do not ground to a gas pipe.
■ Check with a qualified electrician if you are not sure the
washer is properly grounded.
■ Do not have a fuse in the neutral or ground circuit.
6
INSTALLATION INSTRUCTIONS
Remove Transport System
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
IMPORTANT: Position the washer so that the rear of the washer is
within approximately 3 ft. (900 mm) of its final location.
There are 4 transport bolts in the rear panel of the washer that
port the suspension system during transportation. These bolts
sup
also retain the power cord inside the washer until the bolts are
removed.
Connect the Inlet Hoses
Insert new flat washers (supplied) into each end of the inlet hoses.
Firmly seat the washers in the couplings.
A B
A. Coupling
B. Washer
Connect the inlet hoses to the water faucets
Make sure washer drum is empty and flat washers have been
placed into hose couplings. Both hoses must be used for the
washer to work properly.
1. Attach
2. Attach
3. Us
a hose to the hot water faucet. Screw on coupling by
hand until it is seated on the washer.
a hose to the cold water faucet. Screw on coupling by
hand until it is seated on the washer.
ing pliers, tighten the couplings with an additional
two-thirds turn.
1. On the back of the washer, loosen the 4 transport bolts using
a 13 mm wrench.
2. Once th
completely pull out the bolt, including the plastic spacer
covering the bolt.
3. Once all 4 bolts are removed, discard the bolts and spacers.
Then pull the power cord through the opening of the rear
panel and close the hole with the attached cap.
4. C
NOTE: If the washer is to be transported at a later date, call your
local service center. To avoid suspension and structural damage,
your machine must be properly set up for relocation by a certified
technician.
e bolt is loose, move it to the center of the hole and
over the bolt holes with the 4 transport bolt hole plugs.
NOTE: Do not overtighten. Damage to the coupling or water
faucet can result. Both faucets must be turned on for the washer
to work properly.
Clear the water lines
■ Run water through both faucets and inlet hoses, into a laundry
tub, drainpipe or bucket, to get rid of particles in the water
lines that might clog the inlet valve screens.
■ Check the temperature of the water to make sure that the hot
water hose is connected to the hot water faucet and that the
cold water hose is connected to the cold water faucet.
7
Connect the inlet hoses to the washer
IMPORTANT: Make sure that the flat washers have been placed
into the hose couplings.
C H
H. Hot water inlet
C. Cold water inlet
1. Attach the hot water hose to the washer’s hot (H) water inlet
valve. Screw on coupling by hand until it is seated on the
washer.
tach the cold water hose to the washer’s cold (C) water
2. At
faucet. Screw on coupling by hand until it is seated on the
washer.
sing pliers, tighten the couplings with an additional
3. U
two-thirds turn.
NOTE: Do
valve. Damage to the valves can result.
urn on the water faucets completely and check for leaks.
4. T
NOTE: Replace inlet hoses after 5 years of use to reduce the
risk of hose failure. Record hose installation or replacement
dates on the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.
not overtighten or use tape or sealants on the
2. Slide drain hose onto washer connection.
3. Once drain hose is in place, release pliers.
4. Washer drain system can be installed using a floor drain, wall
standpipe, floor standpipe, or laundry tub.
Laundry tub drain or standpi
Connect the drain hose form to the
pe drain
corrugated drain hose.
Connect the Drain Hose
Remove drain hose from washer drum
1. Use locking pliers, squeeze hose clamp tabs together and insert
over the end of drain hose.
A B
A. Snap either end of the drain hose form to the drain hose at the point
where the corrugation begins.
B. Bend drain hose over drain hose form and snap into place.
To keep drain water from going back into the washer
■ Use the drain hose form, and do not force excess drain hose
into standpipe. Hose should be secure, but loose enough to
provide a gap for air.
■ Do not lay excess hose on the bottom of the laundry tub.
Floor drain
You may need additional parts. See Floor drain under “Tools and
Parts.”
8
Secure the Drain Hose
Drain hose must be secured to stop the hose from moving when
water is pumped out. If the drain hose moves, water may end up
on the floor.
rape the power cord over the washer top.
1. D
2. Move the washer to its final location.
3. Place the drain hose in the laundry tub or standpipe as shown.
See illustrations A and B.
A B C
NOTES:
■ Do not force excess drain hose back into the rear of the
washer.
■ To avoid siphoning, do not seal or put more than
4½"(114 mm) of the drain hose into dr
4. If the washer faucets and the drain standpipe are recessed, put the hooked end of the drain hose in the standpipe as shown. See illustration C.
ainpipe or standpipe.
Level the Washer
Proper foot to floor contact and leveling your washer avoids
excessive noise and vibration.
NOTE:
Installing washer on soft floor surfaces, such as carpets or
surfaces with foam backing, is not recommended.
ide the washer to its final location.
1. Sl
2. Check that all four feet are in firm contact with the floor.
3. Check the levelness of the washer by placing a level on the
top edge of the washer, first side to side then front to back.
6. The washer should not mo
diagonally when pushed on its top edges.
nfirm the levelness of the washer.
7. Co
ve front to back, side to side, or
Complete Installation
1. Check the electrical requirements. Be sure that you have the
correct electrical supply and the recommended grounding
method. See “Electrical Requirements.”
2. Chec
3. Chec
4. Dispose of/recycle all packaging materials.
5. Check that both water faucets are on.
6. Check for leaks around faucets and inlet hoses.
k that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
k that you have all of your tools.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
7. Plug into a grounded 3 prong outlet.
ead “Washer Use.”
8. R
9. To test and to clean your washer, measure 1/2 the detergent
manufacturer’s recommended amount of High Efficiency (HE)
detergent for a medium-size load. Pour the detergent into the
detergent dispenser. Select Clean Washer with AFFRESH™
cycle, then press START/PAUSE button for 3 seconds to start
washer. Allow washer to complete one cycle.
If the washer is against a wall, move the washer out slightly
before tipping back. If the washer is not level, first prop the
front with a wooden block and adjust the front feet height
moving the hexagonal plastic part as necessary. Repeat to
adjust back feet.
ake sure all four feet are in firm contact with the floor. Then
4. M
check that the washer is perfectly level (use a level). Repeat
steps 1-3 until washer is level.
5. After the washer is level, and all four feet are in firm contact
with the floor, use a 9/16" (14 mm) open-end wrench to turn
the locknuts on the feet, tightly against the washer cabinet.
IMPORTANT: Al
the locknuts are not tight against the washer cabinet, the washer
may vibrate.
l four locknuts on the feet must be tightened. If
Use only HE High Efficiency detergent.
9
FEATURES AND BENEFITS
Your new front-loading high efficiency washer, was designed to
conserve resources and lower your water and energy bills. The
washer is designed to determine and then provide the amount of
water needed for the best performance. The time of operation
may be greater for this new system than for a conventional
washer.
Electronic Controls
Flexible electronic controls are easy to use whether you are a
beginner or an expert.
Auto Water Level
Adjusting to the size of the load, this feature allows the washer to
use the minimal amount of water needed to clean and rinse the
clothes. With a low water level, you can obtain the same results.
Because only the required amount of water is used, the washer
saves energy, too. You can obtain the same washing results for
small and large load sizes.
Larger Load Size
Since there is no agitator, you can wash larger, bulkier items such
as an average size sleeping bag. You are also able to wash more
clothes at one time, which means fewer loads. You can wash a
pillow or a large stuffed teddy bear.
Suspension System
To reduce washer “walk” and “off-balance” conditions, your new
washer combines:
■ 2 Springs to isolate vibration
■ 3 Shock absorbers at the washer base to minimize movement
Stainless Steel Drum
The stainless steel drum eliminates corrosion and enables higher
spin speeds for more water extraction, reducing drying time.
Add Garment
This option is available in all wash cycles except Rinse & Spin,
Drain & Spin, and Clean Washer with AFFRESH™ cycle. When
this option is available at the beginning of the cycle, the Add
Garment status light will illuminate for approximately the first
7 minutes. This washer allows a 7-minute period in whic
garments may be added to a load.
h other
Dynamic Balance
A precision balancing system allows the washer to reach highspeed spins. The washer spins faster so that clothes coming out
of the washer will have less moisture than with traditional top load
machines. In addition, if the Dynamic Balance system detects offbalance loads during spinning, it redistributes the clothes so that
they are evenly balanced.
Smart Dispensers
The three compartments in the dispenser allow loading of all
laundry products before the washer is started. The products
will be dispensed into the wash at th
performance cleaning. The bleach release system is included in
the detergent advantage system. The detergent is added at the
beginning of the cycle, and the bleach is added after the enzymes
have had a chance to do their cleaning. The fabric softener is
dispensed in the rinse cycle. The Detergent Advantage System
Dispenser tray is easily removed for cleaning.
Use only HE High Efficiency detergent.
e optimal time for high-
Adaptive Variable Speed Motor
The motor adapts to the load size and to the cycle selected to
give the optimum cleaning, rinsing, and spinning conditions. The
motor can handle slow speeds needed for delicate items and is
powerful enough to drive an average clothes load up to highspeed spin.
10
WASHER USE
Starting Your Washer
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
The following is a guide to using your washer. Please refer to
ific sections of this manual for more detailed information.
spec
Do not store laundry products on the top surface of this washer.
V
ibration is normal during operation.
Using the Proper Detergent
Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE” or “High Efficiency.” This wash
system, along with less water, will create too much sudsing with a
regular non-HE detergent. Using regular detergent will likely result in
washer errors, longer cycle times, and reduced rinsing performance.
It may also result in component failures and noticeable mold or
mildew. HE detergents are made to produce the right amount of
suds for the best performance. Follow the manufacturer’s
instructions to determine the amount of detergent to use.
Use only HE High Efficiency detergent.
First Wash Cycle Without Laundry
Before washing clothes for the first time, if not completed during
the complete installation step, choose the Normal cycle and run it
without clothes. Use only HE High Efficiency detergent. Use 1/2
the manufacturer’s recommended amount for a medium-size
load. This initial cycle serves to ensure the interior is clean before
washing clothes.
For All Wash Cycles
1. To load washer
Open the washer door by pulling on the
according to color and type of fabric. Place a load of sorted
clothes in the washer. Do not overload washer. Overloading
can cause poor cleaning.
■ Always empty pockets. Small items can be caught within
the washer resulting in noise or plugging the pump.
■ The washer can be fully loaded, but not tightly packed.
Washer door should close easily.
■ Mix large and small items. Avoid washing a single item.
Load evenly.
■ Wash small items such as infant socks in mesh garment
bags. It is recommended that more than one garment bag
be used and that each garment bag be filled with equal
amounts of material.
■ When unloading garments, occasionally check under the
rubber rim at the front of the tub for small items.
2. Close the wa
After a lock check at the beginning of the cycle, the washer
door will remain locked during the wash cycle.
NOTE: After an
opened and then closed before a new cycle can begin. The
door can be opened only if START/PAUSE is selected while
the Add Garment light is illuminated or if the cycle has been
canceled. See “To cancel a cycle” in the “Changing Cycles
and Options” section.
3. Open the dis
detergent, bleach, or fabric softener compartments. Close
drawer slowly to avoid spills. See “Using the Dispenser.”
urn on the washer by pressing POWER or Select Cycle
4. T
button. Select one of the cycles by pushing the cycle selector.
The indicator light for the selected cycle will illuminate. When
selecting a Wash Cycle, the TEMP indicator light for the preset
temperature will illuminate. This setting provide the
recommended fabric care for the selected cycle. See
“Cycles.”
5. Select the desir
all cycles. See “Options.”
6. If de
sired, select the Cycle Signal. The signal is helpful when
you are washing items that should be removed from the
washer as soon as it stops. Press and hold CYCLE SIGNAL to
select signal on or signal off.
sher door by pushing it firmly until the lock clicks.
y wash cycle is completed, the door must be
penser drawer and add laundry products to the
ed Options. Not all Options are available with
handle. Sort laundry
11
7. To begin the wash cycle immediately
A
Press and hold START/PAUSE (for approximately 3 seconds).
■ You will hear the door locking, unlocking, and locking
again. This is normal.
■ The washer will automatically shut off if you do not press
START/PAUSE within 5 minutes of selecting a cycle.
■ When the wash cycle is done, the COMPLETE status light
illuminates, the door unlocks, and the wash load can be
removed from the washer. To power down the washer
after the wash cycle is done and the COMPLETE status
light goes off, open the door or press POWER.
Using the Dispenser
Your new washer has a dispenser drawer with three separate
compartments for your laundry products—one is for detergent,
one is for liquid chlorine bleach, and one is for liquid fabric
softener. Laundry products are diluted and dispensed
automatically at the proper time during the wash cycle, making it
unnecessary for you to return to the washer during the cycle to
add them.
It is normal for small amounts of water to r
when the wash cycle is complete.
Do not put laundry products directly into the
use the proper dispensers when adding laundry products.
Choosing the Right Detergent
Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE” or “High Efficiency.”
system, along with less water, will create too much sudsing with a
regular non-HE detergent. Using regular detergent will likely result in
washer errors, longer cycle times, and reduced rinsing performance.
It may also result in component failures and noticeable mold or
HE detergents are made to produce the right amount of
mildew.
suds for the best performance. Follow the manufacturer's
instructions to determine the amount of detergent to use.
emain in the dispensers
wash tub. Always
This wash
3. Push
in the dispenser drawer slowly and completely (to avoid
a spill).
C
B
D
Dispenser
A. Dispenser release lever
B. Main Wash detergent compartment
C. Liquid chlorine bleach compartment
D. Fabric softener compartment
Main Wash detergent compartment
(Letter B in Dispenser Illustration)
Add liquid or powdered HE detergent to this compartment for
your main wash cycle.
■ Liquid color-safe bleach or oxi products may be added to the
Main Wash compartment along with liquid detergent.
■ Powdered color-safe bleach or oxi products may be added to
the Main Wash compartment along with the powdered
detergent.
■ Do not mix powdered and liquid products in the Main Wash
compartment.
■ Use the measurement device which comes with the detergent.
Add no more than the manufacturer's recommended amount.
NOTE: Overfillin
g could cause an oversudsing condition.
Use only HE High Efficiency detergent.
Chlorine bleach compartment
(Letter C in Dispenser Illustration)
To fill dispenser compartments
1. Pull out the dispenser drawer.
2. Add the desired laundry products to the proper compartment.
Add NO MORE THAN 2/3 cup (160 mL) liquid chlorine bleach to
this compartment. The bleach will be automatically diluted and
dispensed at the best time during the first rinse after the wash
cycle. This compartment cannot dilute powdered bleach.
■ Use only liquid chlorine bleach in this dispenser. Do not use
this dispenser to add powdered chlorine or any form of colorsafe bleach or oxi products to your load.
■ Always measure liquid chlorine bleach. Use a measuring cup
with a pour spout; do not guess. Follow the manufacturer’s
directions for proper use.
■ Do not fill beyond the “MAX” level.
NOTE: Overfilling could cause garment damage.
Fabric softener compartment
(Letter D in Dispenser Illustration)
Follow the manufacturer's instructions to determine the amount of
fabric softener to use. Fabric softener will be automatically
dispensed in the final rinse.
■ Do not fill beyond the “MAX” level.
12
Pausing or Restarting
1. To pause the washer at any time, press START/PAUSE.
2. To continue the cycle, press and hold START/PAUSE (for
approximately 3 seconds).
Changing Cycles and Options
Not all Options are available with all Cycles.
Cycles and Options can be changed anytime before START/
PAU SE is pressed.
To cancel a cycle
1. Press POWER.
2. The washer powers down, the door unlocks, and clothes can
be removed.
NOTE: If
will drain automatically before the door unlocks.
1. Press START/PAUSE once.
2. Pr
3. Pr
1. Press START/PAUSE.
2. Select DRAIN & SPIN
3. Press and hold START/PAUSE (for approximately 3 seconds)
4. Wh
the water level or the temperature is too high, the washer
To change an Option after the cycle has started
ess the desired OPTION. If the option is not available, the
machine will beep.
ess and hold START/PAUSE (for approximately 3 seconds)
to continue the cycle.
To drain the washer manually
.
to begin the drain.
en the spin is complete, the door unlocks. Items can be
removed from the washer.
Status Lights
These lights show which portion of the cycle the washer is
operating. They also indicate when you can add an additional item
to the wash cycle.
Complete
The Complete light comes on after the cycle is done. The light will
stay on until door is opened or Power button pressed.
Cycles
Wash Cycles
Choose Wash Cycles by pushing the Cycle selector button to the
desired cycle. Each cycle is designed for different types of fabric
and soil levels.
■ Each cycle has a preset cycle time, temperature, spin speed,
and may have preset Options. The preset settings provide the
recommended fabric care for the selected cycle.
■ The preset settings can be changed anytime before START/
PAUSE is pressed. Not all Options (TEMP) are available with
all Cycles. To change settings after the cycle has started,
press START/PAUSE, then select the desired settings. Press
and hold START/PAUSE (for approximately 3 seconds) to
tinue the cycle.
con
Preset Cycle Settings
Each cycle has a preset cycle time, temperature, and spin speed.
These settings provide the recommended fabric care for the
selected cycle. See chart.
Cycle Estimated
Time*
(hr:min)
Te m p Spin
Speed
Adding items
You can add items to the washer after the wash cycle has started,
if the Add Garment status light is illuminated. All cycles have this
feature except Rinse & Spin, Drain & Spin, and Clean Washer with
AFFRESH™ cycle.
To add items
ess START/PAUSE. The washer door unlocks, and items
1. Pr
can be added.
o continue the cycle, close the door and press and hold
2. T
START/PAUSE (for approximately 3 seconds).
To add garments after the Add Garment period is over, the
NOTE:
wash cycle needs to be canceled, the items added, and a new
wash cycle started.
Heavy Duty 1:22 Hot High
Normal 1:12 Warm High
Delicate 0:37 Cold Low
Rinse & Spin 0:26 Cold High
Drain & Spin 0:14 N/A High
Clean Washer with
AFFRESH™
*The cycle times vary automatically
water temperature, detergent, and clothes load. The cycle time
will be extended if oversudsing occurs or the load is unbalanced.
Heavy Duty
Use this cycle to wash loads of sturdy, colorfast fabrics and
heavily soiled garments. This cycle combines fast-speed
tumbling, longer wash time, and high-speed spin to shorten
drying times.
0:54 N/A High
based on your water pressure,
13
Normal
Use this cycle to wash loads of no-iron fabrics such as sport
shirts, blouses, casual business clothes, permanent press blends,
cottons and linens, and synthetic fabrics. This cycle combines
medium-speed tumbling, high-speed spin, and a load cooling
process to reduce wrinkling.
Delicate
Use this cycle to wash sheer fabrics and lingerie. This cycle
combines low-speed tumbling and low-speed spin for gentle
fabric care.
■ Use mesh garment bags to wash undergarments such as
underwire bras, items with strings, and small items such as
socks.
Options
You can customize your wash by adding options to your cycle
selections. You can add or change an option after starting a cycle
anytime before the selected option begins. Not all Options are
available with all cycles.
Rinse & Spin
Use this cycle to get a rinse and spin only. This cycle combines
fast-speed tumbling and high-speed spin.
Rinse & Spin is useful for:
■ Loads that need rinsing only.
■ Adding fabric softener to a load using the fabric softener
dispenser.
Drain & Spin
Use this cycle to drain your washer or to drain and spin your wash
load. The spin speed is present to high.
Using Drain & Spin:
1. Select Drain
Clean Washer with AFFRESH™ cycle
Use the Clean Washer with AFFRESH™ cycle once a month to
keep the inside of your washer fresh and clean. This cycle uses a
higher water level in combination with AFFRESH® washer cleaner
tablet or chlorine bleach to thoroughly clean the inside of your
washing machine. See “Cleaning Your Washer.”
IMPORTANT: Do no
during the Clean Washer with AFFRESH™ cycle. Use this cycle
with an empty wash drum.
& Spin cycle.
t place garments or other items in the washer
Normal Sounds
As with any new product, you will hear sounds that you are not
accustomed to. You may hear various sounds when the door is
locked or unlocked, and during the washing, rinsing, or spinning
process. Between changes in wash actions, there will be
momentary pauses. You will hear water spraying and splashing
during the wash and rinse cycles. These new sounds and pauses
are part of normal washer operation. See “Troubleshooting.”
■ If an option is available with a selected cycle, the light for that
option will illuminate when selected.
■ If an option is unavailable with a selected cycle, there will be a
short tone and the light for that option will not illuminate when
selected.
Te m p
Each cycle has a preset water temperature setting. To change the
water temperature, press the TEMP button until the desired
setting is illuminated.
Select a water temperatur
washing. Use the warmest wash water safe for fabrics. Follow
garment label instructions.
The water temperature for all rinses are cold. Cold rinses save
energy.
e based on the type of load you are
Temperature Guide
Te mp Suggested Fabrics
HOT Whites and pastels
Heavy soils
WARM Bright colors
Moderate to light soils
COLD Colors that bleed or fade
Light soils
In wash water temperatures colder t
do not dissolve well. Soils may be difficult to remove.
han 60°F (15.6°C), detergents
Controlled Temperature
Warm and cold wash temperatures are sensed and maintained by
regulating the amount of hot and cold water from your faucet. This
provided excellent cleaning while saving energy.
ATC (Auto Temp Control) electronically sen
uniform water temperature, by regulating incoming hot and cold
water.
■ Cold rinse is not controlled by the ATC and will be the same
temperature as the water coming from your cold water faucet.
ses and maintains a
14
Cycle Signal
This signal is helpful when you are removing items from the
washer as soon as it stops. Press and hold CYCLE SIGNAL to
select signal on or off.
LAUNDRY TIPS
Preparing clothes for washing
Follow these recommendations to help you prolong the life of your
garments.
■ Use only High Efficiency detergents. The package for this type
of detergent will be marked “HE” or “High Efficiency.” This
wash system, along with less water, will create too much
sudsing with a regular non-HE detergent. Using regular
detergent will likely result in washer errors, longer cycle times
and reduced rinsing performance. It may also result in
component failures and noticeable mold or mildew. HE
detergents are made to produce the right amount of suds for
the best performance. Follow the manufacturer's instructions
to determine the amount of detergent to use.
Use only HE High Efficiency detergent.
■ Close zippers, snaps, and hooks to avoid snagging other
items. Remove pins, buckles, and other hard objects to avoid
scratching the washer interior. Remove non-washable trim
and ornaments.
■ Empty pockets. Small items can be caught with the washer
resulting in noise or plugging the pump.
■ Turn down cuffs; brush away lint and dirt.
■ Turn wool and synthetic knits inside out to avoid pilling.
■ Tie strings and sashes so they will not tangle.
■ Mend tears, loose hems, and seams.
■ Treat spots and stains.
■ Stained or wet garments should be washed promptly for best
results.
■ Mix large and small items, avoid washing single items, and
load evenly.
■ Wash small items, such as infant socks, in a mesh garment
bag. To create a balanced load it is recommended that more
than one garment bag be used, and that each garment bag be
filled with equal amounts of material.
NOTE: If
you are washing only small items, it is recommended
that more than one mesh garment bag be used, and that each
garment bag be filled with equal amounts of material.
Unloading
■ Remove clothes from washer after the cycle is completed.
Metal objects such as zippers, snaps, and buckles may rust if
left in the washer basket for a long time.
■ When unloading garments, occasionally check under the
colored seal at the front of the tub for small items.
Loading
Loading suggestions
Heavy Work Clothes
2 pair pants
3shirts
Mixed Load
2double sheets or
1 king size sheet(s)
4 pillowcases
6T-shirts
Towels
8bath towels
8hand towels
Delicates
3 camisoles
4slips
4panties
Small Load cycle
(2-3 garments)
3 pair jeans
1 coverall
6pair shorts
2shirts
2blouses
6 handkerchiefs
10 washcloths
1bath mat
2bras
2 nighties
2 dress shirts
1 pair dress pants
Sorting
■ Separate heavily soiled items from lightly soiled ones, even if
they would normally be washed together. Separate lint-givers
(towels, chenille) from lint-takers (corduroy, synthetics,
permanent press). When possible, turn lint-givers inside out.
■ Separate dark colors from light colors, colorfast items from
noncolorfast items.
■ Sort by fabric and construction (sturdy cottons, knits, delicate
items).
15
