100G Development Kit, Stratix V GX Edition User Guide
100G Development Kit, Stratix V GX Edition
User Guide
101 Innovation Drive
San Jose, CA 95134
www.altera.com
UG-01111-1.1
Feedback Subscribe
© 2012 Altera Corporation. All rights reserved. ALTERA, ARRIA, CYCLONE, HARDCOPY, MAX, MEGACORE, NIOS, QUARTUS and STRATIX words and logos
are trademarks of Altera Corporation and registered in the U.S. Patent and Trademark Office and in other countries. All other words and logos identified as
trademarks or service marks are the property of their respective holders as described at www.altera.com/common/legal.html. Altera warrants performance of its
semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any products and
services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information, product, or service
described herein except as expressly agreed to in writing by Altera. Altera customers are advised to obtain the latest version of device specifications before relying
on any published information and before placing orders for products or services.
ISO
9001:2008
Registered
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
Contents
Chapter 1. About This Kit
Kit Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Quartus II Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Stratix V GX 100G Development Kit Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
Chapter 2. Getting Started
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Inspect the Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Chapter 3. Software Installation
Installing the Quartus II Subscription Edition Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
Licensing Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
Installing the Development Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–3
Installing the USB-Blaster II Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–4
Chapter 4. Development Board Setup
Setting Up the Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
Factory Default Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2
Chapter 5. Board Update Portal
Connecting to the Board Update Portal Web Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
Using the Board Update Portal to Update User Designs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
Chapter 6. Board Test System
Preparing the Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1
Running the Board Test System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1
Using the Board Test System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–2
The Configure Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–2
The System Info Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3
Power Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3
Board Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3
MAX II Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–4
JTAG Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–5
The GPIO Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–6
Character LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–6
User DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–6
User LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–7
Push Button Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–7
The Flash Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–7
Start address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–7
Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Write . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Random Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
CFI Query . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
iv Contents
Increment Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Data Display/Entry Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
Flash Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8
The XCVR1 Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–9
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–9
Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–10
PMA Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–10
Data Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–10
Error Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–11
Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–11
Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–11
Performance Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–11
The XCVR2 Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–12
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–12
Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–12
PMA Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
Data Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
Error Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
Performance Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
The Power Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–14
Temperature Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–15
Power Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–15
Power Graph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–15
Graph Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–15
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–15
The Clock Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–15
Clock Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–16
Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–16
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–16
Disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–16
Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–17
Set New Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–17
Configuring the FPGA Using the Quartus II Programmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–17
Appendix A. Programming the Flash Memory Device
CFI Flash Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–1
Preparing Design Files for Flash Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–2
Creating Flash Files Using the Nios II EDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–2
Programming Flash Memory Using the Board Update Portal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–2
Programming Flash Memory Using the Nios II EDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3
Restoring the Flash Device to the Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–4
Restoring the MAX II CPLD to the Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–5
Additional Information
Document Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–1
How to Contact Altera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–1
Typographic Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–1
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Kit Features
f For a complete list of this kit’s contents and capabilities, refer to the 100G
Hardware
1. About This Kit
The Altera® Stratix®V GX 100G Development Kit is a complete design environment
that includes both the hardware and software you need to develop Stratix V GX
FPGA designs.
This section briefly describes the Stratix V GX 100G Development Kit contents.
Development Kit, Stratix V GX page.
The Stratix V GX 100G Development Kit includes the following hardware:
■ Stratix V GX 100G development board—A development platform that allows you
to develop and prototype hardware designs running on the Stratix V GX FPGA.
Software
f For detailed information about the board components and interfaces, refer
to the 100G Development Kit, Stratix V GX Edition Reference Manual.
■ CFP loopback board
■ SFP loopback module
■ QSFP loopback module
■ Two Interlaken loopback boards
■ Heatsink and fan
■ Power supply and cables—The kit includes the following items:
■ Power supply and AC adapters for North America/Japan, Europe, and the
United Kingdom
■ Ethernet and USB cables
The software for this kit, described in the following sections, is available on the Altera
website for immediate downloading. You can also request to have Altera mail the
software to you on DVDs.
Quartus II Software
Your kit includes a license for the Development Kit Edition (DKE) of the Quartus II
software (Windows platform only). For one year, this license entitles you to most of
the features of the Subscription Edition (excluding the IP Base Suite).
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
1–2 Chapter 1: About This Kit
Kit Features
1 After the year, your DKE license will no longer be valid and you will not be permitted
to use this version of the Quartus II software. To continue using the Quartus II
software, you should download the free Quartus II Web Edition or purchase a
subscription to Quartus II software. For more information, refer to the Design
Software page of the Altera website.
The Quartus II Development Kit Edition (DKE) software includes the following items:
■ Quartus II Software—The Quartus II software, including the Qsys system
integration tool, provides a comprehensive environment for network on a chip
(NoC) design. The Quartus II software integrates into nearly any design
environment and provides interfaces to industry-standard EDA tools.
■ MegaCore
®
IP Library—A library that contains Altera IP MegaCore functions. You
can evaluate MegaCore functions by using the OpenCore Plus feature to do the
following:
■ Simulate behavior of a MegaCore function within your system.
■ Verify functionality of your design, and quickly and easily evaluate its size and
speed.
■ Generate time-limited device programming files for designs that include
MegaCore functions.
■ Program a device and verify your design in hardware.
1 The OpenCore Plus hardware evaluation feature is an evaluation tool for
prototyping only. You must purchase a license to use a MegaCore function
in production.
f For more information about OpenCore Plus, refer to AN 320: OpenCore Plus
Evaluation of Megafunctions.
■ Nios
®
II Embedded Design Suite (EDS)—A full-featured set of tools that allows
you to develop embedded software for the Nios II processor, which you can
include in your Altera FPGA designs.
Stratix V GX 100G Development Kit Installer
The license-free Stratix V GX 100G Development Kit installer includes all the
documentation and design examples for the kit.
For information on installing the Development Kit Installer, refer to “Software
Installation” on page 3–1.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
The remaining chapters in this user guide lead you through the following
Stratix V GX 100G development board setup steps:
■ Inspecting the contents of the kit
■ Installing the design and kit software
■ Setting up, powering up, and verifying correct operation of the 100G development
■ Configuring the Stratix V GX FPGA
■ Running the Board Test System designs
f For complete information about the 100G development board, refer to the 100G
Development Kit, Stratix V GX Edition Reference Manual.
Before You Begin
2. Getting Started
board
Inspect the Boards
References
Before using the kit or installing the software, check the kit contents and inspect the
boards to verify that you received all of the items listed in “Kit Features” on page 1–1.
If any of the items are missing, contact Altera before you proceed.
To inspect each board, perform the following steps:
1. Place the board on an anti-static surface and inspect it to ensure that it has not been
damaged during shipment.
c Without proper anti-static handling, you can damage the board.
2. Verify that all components are on the board and appear intact.
Use the following links to check the Altera website for other related information:
■ For the latest board design files and reference designs, refer to the 100G
Development Kit, Stratix V GX page.
■ For additional daughter cards available for purchase, refer to the Development
Board Daughtercards page.
■ For the Stratix V GX device documentation, refer to the Literature: Stratix V
Devices page.
■ To purchase devices from the eStore, refer to the Devices page.
■ For Stratix V GX OrCAD symbols, refer to the Capture CIS Symbols page.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
2–2 Chapter 2: Getting Started
■ For Nios II 32-bit embedded processor solutions, refer to the Embedded
References
Processing page.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
3. Software Installation
This chapter explains how to install the following software:
■ Quartus II Subscription Edition Software
■ Stratix V GX 100G Development Kit
■ USB-Blaster™ II driver
Installing the Quartus II Subscription Edition Software
The Quartus II Subscription Edition Software provides the necessary tools for
developing hardware and software for Altera devices. Included in the Quartus II
Subscription Edition Software are the Quartus II software, the Nios II EDS, and the
MegaCore IP Library. The Quartus II software (including Qsys) and the Nios II EDS
are the primary FPGA development tools used to create the reference designs in this
kit. To install the Altera development tools, perform the following steps:
1. Download the Quartus II Subscription Edition Software from the Quartus II
Subscription Edition Software page of the Altera website. Alternatively, you can
request a DVD from the Altera IP and Software DVD Request Form page of the
Altera website.
2. Follow the on-screen instructions to complete the installation process.
f If you have difficulty installing the Quartus II software, refer to Altera Software
Installation and Licensing Manual.
Licensing Considerations
Purchasing this kit entitles you to a one-year license for the Development Kit Edition
(DKE) of the Quartus II software.
After the year, your DKE license will no longer be valid and you will not be permitted
to use this version of the Quartus II software. To continue using the Quartus II
software, you should download the free Quartus II Web Edition or purchase a
subscription to Quartus II software.
Before using the Quartus II software, you must activate your license, identify specific
users and computers, and obtain and install a license file.
If you already have a licensed version of the subscription edition, you can use that
license file with this kit. If not, you need to obtain and install a license file. To begin,
go to the Self Service Licensing Center page of the Altera website, log into or create
your myAltera account, and take the following actions:
1. On the Activate Products page, enter the serial number provided with your
development kit in the License Activation Code box.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
3–2 Chapter 3: Software Installation
Installing the Quartus II Subscription Edition Software
1 Your serial number is printed on the development kit box below the bottom
bar code. The number is 10 or 11 alphanumeric characters and does not
contain hyphens. Figure 3–1 shows 3S150SPXXXX as an example serial
number.
Figure 3–1. Locating Your Serial Number
2. Consult the Activate Products table, to determine how to proceed.
a. If the administrator listed for your product is someone other than you, skip the
remaining steps and contact your administrator to become a licensed user.
b. If the administrator listed for your product is you, proceed to step 3.
c. If the administrator listed for your product is Stocking, activate the product,
making you the administrator, and proceed to step 3.
3. Use the Create New License page to license your product for a specific user (you)
on specific computers. The Manage Computers and Manage Users pages allow
you to add users and computers not already present in the licensing system.
1 To license the Quartus II software, you need your computer’s network
interface card (NIC) ID, a number that uniquely identifies your computer.
On the computer you use to run the Quartus II software, type
/all
at a command prompt to determine the NIC ID. Your NIC ID is the
ipconfig
12-digit hexadecimal number on the Physical Address line.
4. When licensing is complete, Altera emails a license.dat file to you. Store the file on
your computer and use the License Setup page of the Options dialog box in the
Quartus_II software to enable the software.
f For complete licensing details, refer to Altera Software Installation and Licensing Manual.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 3: Software Installation 3–3
<install dir>
documents
board_design_files
The default Windows installation directory is C:\altera\
<version>
\.
examples
factory_recovery
demos
kits
stratixVGX_5sgxea7nf45_100g
Installing the Development Kit
Installing the Development Kit
To install the Stratix V GX 100G Development Kit, perform the following steps:
1. Download the Stratix V GX 100G Development Kit installer from the 100G
Development Kit, Stratix V GX page of the Altera website. Alternatively, you can
request a development kit DVD from the Altera Kit Installations DVD Request
Form page of the Altera website.
2. Follow the on-screen instructions to complete the installation process. Be sure that
the installation directory you choose is in the same relative location to the
Quartus II software installation.
The installation program creates the Stratix V GX 100G Development Kit directory
structure shown in Figure 3–2.
Figure 3–2. Stratix V GX 100G Development Kit Installed Directory Structure
Note to Figure 3–2:
(1) Early-release versions might have slightly different directory names.
Tab le 3 –1 lists the file directory names and a description of their contents.
Table 3–1. Installed Directory Contents
Directory Name Description of Contents
board_design_files
Contains schematic, layout, assembly, and bill of material board design files. Use these files as a
starting point for a new prototype board design.
demos Contains demonstration applications.
documents Contains the kit documentation.
examples Contains the sample design files for the Stratix V GX 100G Development Kit.
factory_recovery
Contains the original data programmed onto the board before shipment. Use this data to restore
the board with its original factory contents.
(1)
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
3–4 Chapter 3: Software Installation
Installing the USB-Blaster II Driver
Installing the USB-Blaster II Driver
The Stratix V GX 100G development board includes integrated USB-Blaster II
circuitry for FPGA programming. However, for the host computer and board to
communicate, you must install the USB-Blaster driver II on the host computer.
f Installation instructions for the USB-Blaster II driver for your operating system are
available on the Altera website. On the Altera Programming Cable Driver Information
page of the Altera website, locate the table entry for your configuration and click the
link to access the instructions.
f For USB-Blaster II configuration details, refer to the On-Board USB-Blaster II page.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
This chapter explains how to set up the Stratix V GX 100G development board.
Setting Up the Board
To prepare and apply power to the board, perform the following steps:
1. The Stratix V GX 100G development board ships with its board switches
preconfigured to support the design examples in the kit. If you suspect your board
might not be currently configured with the default settings, follow the instructions
in “Factory Default Switch Settings” on page 4–2 to return the board to its factory
settings before proceeding.
2. Connect the +19 V, 120 W to the DC Power Jack (J1) on the FPGA board and plug
the cord into a power outlet.
c Use only the supplied power supply. Power regulation circuitry on the
4. Development Board Setup
board can be damaged by power supplies with greater voltage.
3. Set the POWER switch (SW1) to the on position. When power is supplied to the
board, blue LED (D1) illuminates indicating that the board has power.
The MAX II device on the board contains (among other things) a parallel flash loader
(PFL) megafunction. When the board powers up, the PFL reads a design from flash
memory and configures the FPGA. Pressing the PGM_SEL (S8) push-button loads the
design into the FPGA from flash using the PFL in the MAX II device.
When configuration is complete, the MAX_CONF_DN LED (D25) illuminates,
signaling that the Stratix V GX device configured successfully.
1 The kit includes a MAX II design which contains the MAX II PFL megafunction. The
design resides in the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\examples\max2 directory.
f For more information about the PFL megafunction, refer to AN 386: Parallel Flash
Loader Megafunction User Guide.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
4–2 Chapter 4: Development Board Setup
J9
(not installed)
FAN BYPASS
J62
(not installed)
MAX_JTAG_EN
FPGA USER
SW4
7
0
1
6543210
MAX USER
LCD Display
SW5
76543210
SW3
1
1
23
45678
0
SW2
0
1
MSEL 0
MSEL 1
MSEL 2
MSEL 3
MSEL 4
SECURITY
CLK644_EN
REFCLKB_SEL
REFCLKA_SEL
DIFFCLKA_SEL
USB DISABLEN
123456
Factory Default Switch Settings
Factory Default Switch Settings
This section shows the factory switch settings for the Stratix V GX 100G development
board. Figure 4–1 shows the switch locations and the default position of each switch.
Figure 4–1. Switch Locations and Default Settings
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 4: Development Board Setup 4–3
Factory Default Switch Settings
To restore the switches to their factory default settings, perform the following steps:
1. Set DIP switch bank (SW2) to match Tab le 4 –1 and Figure 4–1.
Table 4–1. SW2 Dip Switch Settings
Switch
Board
Label
0 MSEL 0
1 MSEL 1
2 MSEL 2
3 MSEL 3
4 MSEL 4
5—
Switch 0 has the following options:
■ Open = Logic 1
■ Closed = Logic 0
Switch 1 has the following options:
■ Open = Logic 1
■ Closed = Logic 0
Switch 2 has the following options:
■ Open = Logic 1
■ Closed = Logic 0
Switch 4 has the following options:
■ Open = Logic 1
■ Closed = Logic 0
Switch 4 has the following options:
■ Open = Logic 1
■ Closed = Logic 0
Switch 4 has the following options:
■ Open = Logic 1
■ Closed = Logic 0
Function
Default
Position
Closed
Closed
Open
Closed
Open
Closed
2. Set DIP switch bank (SW3) to match Tab le 4 –2 and Figure 4–1.
Table 4–2. SW3 DIP Switch Settings (Part 1 of 2)
Switch
Board
Label
Switch 4 has the following options:
1 USB_DISABLEN
■ When off (1), USB is enabled.
■ When on (0), USB is disabled.
Switch 4 has the following options:
2 DIFFCLKA_SEL
■ When off (1), SMA is selected.
■ When on (0), PLL is selected.
Switch 3 has the following options:
3 REFCLKA_SEL
■ When off (1), SMA is selected.
■ When on (0), PLL is selected.
Switch 4 has the following options:
4 DIFFCLKB_SEL
■ When off (1), SMA is selected.
■ When on (0), PLL is selected.
Function
Default
Position
1
1
1
1
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
4–4 Chapter 4: Development Board Setup
Factory Default Switch Settings
Table 4–2. SW3 DIP Switch Settings (Part 2 of 2)
Switch
Board
Label
5 REFCLKB_SEL
6 CLK_644_EN
7 SECURITY
8—
Function
Default
Position
Switch 5 has the following options:
■ When on (1), the SMA is selected.
■ When off (0), the PLL is selected.
Switch 6 has the following options:
■ When on (1), 644-MHz clock is enabled.
■ When off (10, 644-MHz clock is disabled.
Switch 7 has the following options:
■ When on (1), configuration security is enabled.
■ When off (0), configuration security is disabled.
When enabled, the FPGA cannot be accessed via JTAG if the device has
already been programmed by the PFL.
—
3. Set jumper blocks (J9, J62) to match Tab le 4 –3 and Figure 4–1.
Table 4–3. Jumper Settings
Board Reference Description Shunt Position
J9
J62
Fan Bypass — Shut installed forces the fan to ON and at
full speed.
MAX_JTAG_EN (logic 1) — Shunt installed removes
MAX II from JTAG chain.
Not Installed
Not Installed
0
1
1
—
f For more information about the FPGA board settings, refer to the 100G Development
Kit, Stratix V GX Edition Reference Manual.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
5. Board Update Portal
The Stratix V GX 100G Development Kit ships with the Board Update Portal design
example stored in the factory portion of the flash memory on the board. The design
consists of a Nios II embedded processor, an Ethernet MAC, and an HTML web
server.
When you power up the board, the FPGA configures with the with the Board Update
Portal design example from flash memory. The design can obtain an IP address from
any DHCP server and serve a web page from the flash on your board to any host
computer on the same network. The web page allows you to upload new FPGA
designs to the user hardware 1 portion of flash memory and provides kit-specific links
and design resources.
The source code for the Board Update Portal design resides in the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\examples directory. If the Board Update
Portal is corrupted or deleted from the flash memory, refer to “Restoring the Flash
Device to the Factory Settings” on page A–4 to restore the board with its original
factory contents.
Connecting to the Board Update Portal Web Page
This section provides instructions to connect to the Board Update Portal web page.
1 Before you proceed, ensure that you have the following:
■ A PC with a connection to a working Ethernet port on a DHCP enabled network.
■ A separate working Ethernet port connected to the same network for the board.
■ The Ethernet and power cables that are included in the kit.
To connect to the Board Update Portal web page, perform these steps:
1. Attach the Ethernet cable from the board to your LAN.
2. Power up the board. The board connects to the LAN’s gateway router, and then
obtains an IP address. The LCD on the board displays the IP address.
3. Launch a web browser on a PC that is connected to the same network, and enter
the IP address from the LCD into the browser address bar. The Board Update
Portal web page appears in the browser.
1 You can click Stratix V GX 100G Development Kit on the Board Update Portal
web page to access the kit’s home page for documentation updates and
additional new designs.
Using the Board Update Portal to Update User Designs
The Board Update Portal allows you to write new designs to the user hardware 1
portion of flash memory. Designs must be in the Nios II Flash Programmer File
(.flash) format.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
5–2 Chapter 5: Board Update Portal
Using the Board Update Portal to Update User Designs
1 Design files available from the 100G Development Kit, Stratix V GX page include
.flash files. You can also create .flash files from your own custom design. Refer to
“Preparing Design Files for Flash Programming” on page A–2 for information about
preparing your own design for upload.
To upload a design over the network into the user portion of flash memory on your
board, perform the following steps:
1. Perform the steps in “Connecting to the Board Update Portal Web Page” to access
the Board Update Portal web page.
2. In the Hardware File Name field specify the .flash file that you either downloaded
from the Altera website or created on your own. If there is a software component
to the design, specify it in the same manner using the Software File Name field;
otherwise, leave the Software File Name field blank.
3. Click Upload.
4. To configure the FPGA with the new user design after the flash memory upload
process is complete, press PGM_SEL (S8) until POF 1 LED (D34) illuminates, and
then press LOAD (S5) to configure the user hardware portion of flash memory.
1 As long as you don’t overwrite the factory image in the flash memory device, you can
continue to use the Board Update Portal to write new designs to the user hardware 1
portion of flash memory. If you do overwrite the factory image, you can restore it by
following the instructions in “Restoring the Flash Device to the Factory Settings” on
page A–4.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
6. Board Test System
The kit includes a design example and an application called the Board Test System to
test the functionality of the Stratix V GX 100G development board. The application
provides an easy-to-use interface to alter functional settings and observe the results.
You can use the application to test board components, modify functional parameters,
observe performance, and measure power usage. (While using the application, you
reconfigure the FPGA several times with test designs specific to the functionality you
are testing.) The application is also useful as a reference for designing systems. To
install the application, follow the steps in “Installing the Development Kit” on
page 3–3.
The Board Test System GUI communicates over the JTAG bus to a test design running
in the Stratix V GX device.
Several designs are provided to test the major board features. Each design provides
data for one or more tabs in the application. The Configure menu identifies the
appropriate design to download to the FPGA for each tab.
After successful FPGA configuration, the appropriate tab appears and allows you to
exercise the related board features. Highlights appear in the board picture around the
corresponding components.
Preparing the Board
With the power to the board off, following these steps:
1. Connect the USB cable to the board.
2. Ensure that the development board switches and jumpers are set to the default
positions as shown in the “Factory Default Switch Settings” section starting on
page 4–2.
f For more information about the board’s DIP switch and jumper settings,
3. Turn on the power to the board. The board loads the design stored in the user
hardware 1 portion of flash memory into the FPGA. If your board is still in the
factory configuration, or if you have downloaded a newer version of the Board
Test System to flash memory through the Board Update Portal, the design loads
the GPIO and flash memory tests.
c To ensure operating stability, keep the USB cable connected and the board
refer to the 100G Development Kit, Stratix V GX Edition Reference Manual.
powered on when running the demonstration application. The application
cannot run correctly unless the USB cable is attached and the board is on.
Running the Board Test System
To run the application, navigate to the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\examples\board_test_system directory
and run the BoardTestSystem.exe application.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–2 Chapter 6: Board Test System
Using the Board Test System
1 On Windows, click Start > All Programs > Altera > Stratix V GX 100G Development
Kit <version> > Board Test System to run the application.
A GUI appears, displaying the application tab that corresponds to the design running
in the FPGA.
c If using the optic modules (CFP, SFP, QSFP) you must set the user switch SW4.7 to
enabled (1) to turn on the laser. When done using the optics, set SW4.7 to disabled (0).
Using the Board Test System
This section describes each control in the Board Test System application.
1 The Board Test System and Power Monitor share the JTAG bus with other
applications like the Nios II debugger and the SignalTap
®
II Embedded Logic
Analyzer. Because the Quartus II programmer uses most of the bandwidth of the
JTAG bus, other applications using the JTAG bus might time out. Be sure to close the
other applications before attempting to reconfigure the FPGA using the Quartus II
Programmer.
The Configure Menu
Use the Configure menu (Figure 6–1) to select the design you want to use. Each design
example tests different functions that corresponds to one or more application tabs.
Figure 6–1. The Configure Menu
To configure the FPGA with a test system design, perform the following steps:
1. On the Configure menu, click the configure command that corresponds to the
functionality you wish to test.
2. In the dialog box that appears, click Configure or Download Start to download
the corresponding design’s Raw-Binary Format (.rbf) configuration file to the
FPGA. The download process usually takes about a minute.
3. When configuration finishes, close the Quartus II Programmer if open. The design
begins running in the FPGA. The corresponding GUI application tabs that
interface with the design are now enabled.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–3
Using the Board Test System
The System Info Tab
The System Info tab shows board’s current configuration. This tab displays the
contents of the MAX II registers, the JTAG chain, the board’s MAC address, the flash
memory map, and other details stored on the board.
Figure 6–2 shows the initial GUI for a board that is in the factory configuration.
Figure 6–2. Board Test System Graphical User Interface
The following sections describe the controls on the System Info tab.
Power Monitor
This button starts the Power Monitor application that measures and reports current
power and temperature information for the board. Because the application
communicates over the JTAG bus to the MAX II device, you can measure the power of
any design in the FPGA, including your own designs. For details, refer to “The Power
Monitor” on page 6–13.
Board Information
The Board information controls display static information about your board.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–4 Chapter 6: Board Test System
■ Name—Indicates the official name of the board, given by the Board Test System.
■ Part number—Indicates the part number of the board.
■ Serial number—Indicates the serial number of the board.
■ Factory test version—Indicates the version of the Board Test System currently
Using the Board Test System
running on the board.
■ Factory test date—Indicates the release date of the Board Test System currently
running on the board.
■ MAX II ver—Indicates the version of MAX II code currently running on the board,
which resides in the <install dir>\kits\stratixVGX_5sgxea7nf45_100g\examples
directory. Newer revisions of this code might be available on the 100G
Development Kit, Stratix V GX page of the Altera website.
■ MAC address—Indicates the MAC address of the board.
MAX II Registers
The MAX II registers control allow you to view and change the current MAX II
register values as described in Table 6–1. Changes to the register values with the GUI
take effect immediately. For example, writing a 0 to SRST resets the board.
Table 6–1. MAX II Registers
Register Name
System Reset
(SRST)
Page Select Register
(PSR)
Page Select Override
(PSO)
Page Select Switch
(PSS)
Read/Write
Capability
Write only Set to 0 to initiate an FPGA reconfiguration.
Read / Write
Read / Write
Read only
Description
Determines which of the flash memory to use for FPGA
reconfiguration. The flash memory ships with pages 0 and 1
preconfigured.
When set to 0, the value in PSR determines the page of
flash memory to use for FPGA reconfiguration. When set to
1, the value in PSS determines the page of flash memory to
use for FPGA reconfiguration.
Holds the current value of the illuminated USER_POF LEDs
(D32, D33, D34).
■ 0 = USER_POF1 LED (D34)
■ 1 = USER_POF2 LED (D33)
■ 2 = USER_POF3 LED (D32)
cThis state selects a page not supported by the default
memory map. Use of this extra page may require the
flash to be re-imaged if you want to return to the
factory state.
■ SRST—Resets the system and reloads the FPGA with a design from flash memory
based on the other MAX II register values.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–5
Using the Board Test System
■ PSO—Sets the MAX II PSO register. The following options are available:
■ Use PSR—Allows the PSR to determine the page of flash memory to use for
FPGA reconfiguration.
■ Use PSS—Allows the PSS to determine the page of flash memory to use for
FPGA reconfiguration.
■ PSS—Displays the MAX II PSS register value.
■ PSR—Sets the MAX II PSR register. The numerical values in the list corresponds to
the page of flash memory to load during FPGA reconfiguration. Refer to Tabl e 6– 1
for more information.
1 Because the System Info tab requires that a specific design is running in the FPGA at
a specific clock speed, writing a 0 to SRST; or changing the PSO value can cause the
Board Test System to stop running.
JTAG Chain
The JTAG chain control shows all the devices currently in the JTAG chain. The
Stratix V GX device is always the first device in the chain.
1 MAX_JTAG_EN (J62) includes the MAX II device in the JTAG chain when a jumper is
not installed. To remove the MAX II device from the chain, install a jumper to J62.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–6 Chapter 6: Board Test System
Using the Board Test System
The GPIO Tab
The GPIO tab allows you to interact with all the general purpose user I/O
components on your board. Figure 6–3 shows the GPIO tab.
Figure 6–3. The GPIO Tab
The following sections describe the controls on the GPIO tab.
Character LCD
This controls allows you to display text strings on the character LCD on your board.
Type text in the text boxes and then click Display.
1 If you exceed the 16 character display limit on either line, a warning message appears.
User DIP Switch
The read-only User DIP switch control displays the current positions of the switches
in the user DIP switch bank (SW4). Change the switches on the board to see the
graphical display change accordingly.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–7
Using the Board Test System
User LEDs
This control displays the current state of the user LEDs.
Push Button Switches
This read-only control displays the current state of the board user push buttons. Press
a push button on the board to see the graphical display change accordingly.
The Flash Tab
The Flash tab allows you to read and write flash memory on your board. Figure 6–4
shows the Flash tab.
Figure 6–4. The Flash Tab
The following sections describe the controls on the Flash tab.
Start address
This control allows you to enter an 8-hex digit (preceding with the 0x hex identifier).
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–8 Chapter 6: Board Test System
Using the Board Test System
Range
Static display that shows the flash address range.
Read
The Read control reads the flash memory on your board. To see the flash memory
contents, type a starting address in the text box and click Read. Values starting at the
specified address appear in the table.
1 If you enter an address outside of the flash memory address space, a warning
message identifies the valid flash memory address range.
Write
The Wri te control writes the flash memory on your board. To update the flash
memory contents, change values in the table and click Wr ite. The application writes
the new values to flash memory and then reads the values back to guarantee that the
graphical display accurately reflects the memory contents.
Random Test
Starts a random data pattern test to flash memory, which is limited to a scratch page in
the upper 128K block.
CFI Query
The CFI Query control updates the memory table, displaying the CFI ROM table
contents from the flash device.
Increment Test
Starts an incrementing data pattern test to flash memory, which is limited to a scratch
page in the upper 128K block.
Reset
The Reset control executes the flash device’s reset command and updates the memory
table displayed on the Flash tab.
Erase
Erases flash memory, which is limited to a scratch page in the upper 128K block.
Data Display/Entry Boxes
This control, consisting of a table with an Address column and four 32-bit data
columns, allows you to view and enter SRAM data.
Flash Memory Map
Displays the flash memory map for the 100G Development Kit, Stratix V GX Edition.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–9
Using the Board Test System
The XCVR1 Tab
The XCVR1 tab allows you to perform loopback tests on the CFP, QSFP, and
Interlaken ports. Figure 6–5 shows the XCVR1 tab.
Figure 6–5. The XCVR1 Tab
The following sections describe the controls on the XCVR1 tab.
Status
The Status control displays the following status information during the loopback test:
■ PLL lock—Shows the PLL locked or unlocked state.
■ Channel lock—Shows the channel locked or unlocked state. When locked, all
lanes are word aligned and channel bonded, and all TX and RX PLL lanes are
phase locked to data; RX lanes are word aligned and deskewed.
■ Pattern sync—Shows the pattern synced or not synced state. The pattern is
considered synced when the start of the data sequence is detected after channel
lock is acquired.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–10 Chapter 6: Board Test System
Using the Board Test System
Port
The Port control allows you to specify which interface to test. The following port tests
are available:
■ CFP x10
■ QSFP0, QSFP1
■ Interlaken[5..0], [11..6], [17..12], [23..18]
PMA Setting
The PMA Setting button allows you to make changes to the PMA parameters that
affect the active transceiver interface. The following settings are available for analysis:
■ Serial Loopback—Routes signals between transmitter and the receiver. Enter the
following values to enable the serial loopbacks:
0
= High speed serial transceiver signals to loopback on the board
1
= Serial loopback (internal loopback)
2
= Reverse serial loopback pre-CDR
4
= Reverse serial loopback post-CDR
■ VOD—Specifies the voltage output differential of the transmitter buffer.
■ Pre-emphasis tap
■ Pre—Specifies the amount of pre-emphasis on the pre-tap of the transmitter
buffer.
■ First post—Specifies the amount of pre-emphasis on the first post tap of the
transmitter buffer.
■ Second post—Specifies the amount of pre-emphasis on the second post tap of
the transmitter buffer.
■ Equalizer—Specifies the setting for the receiver equalizer.
■ DC gain—Specifies the DC portion of the receiver equalizer.
Data Type
The Data type control specifies the type of data contained in the transactions. The
following data types are available for analysis:
■ PRBS 7—Selects pseudo-random 7-bit sequences
■ PRBS 15—Selects pseudo-random 15-bit sequences
■ PRBS 23—Selects pseudo-random 23-bit sequences
■ PRBS 31—Selects pseudo-random 31-bit sequences
■ HF—Selects highest frequency divide-by-2 data pattern "10101010"
■ HF1—Selects next highest frequency divide-by-6 data pattern "111000111000"
■ HF2—Selects second lowest frequency divide-by-22 data pattern
■ LF—Selects lowest frequency divide by 33 data pattern
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–11
Using the Board Test System
Error Control
The Error control controls display data errors detected during analysis and allow you
to insert errors:
■ Detected errors—Displays the number of data errors detected in the hardware.
■ Inserted errors—Displays the number of errors inserted into the transmit data
stream.
■ Insert Error—Inserts a one-word error into the transmit data stream each time you
click the button. Insert Error is only enabled during transaction performance
analysis.
■ Clear—Resets the Detected errors and Inserted errors counters to zeros.
Start
The Start control initiates the active port transaction performance analysis.
Stop
The Stop control terminates transaction performance analysis.
1 Always click Clear before Start.
Performance Indicators
These controls display current transaction performance analysis information collected
since you last clicked Start:
■ TX and RX performance bars—Show the percentage of maximum theoretical data
rate that the requested transactions are able to achieve.
■ Tx (MBps) and Rx (MBps)—Show the number of bytes of data analyzed per
second.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–12 Chapter 6: Board Test System
Using the Board Test System
The XCVR2 Tab
The XCVR2 tab allows you to perform loopback tests on the SFP and SMA ports.
Figure 6–6 shows the XCVR2 tab.
Figure 6–6. The XCVR2 Tab
The following sections describe the controls on the XCVR2 tab.
Status
The Status control displays status information during the loopback test. For details on
this control, refer to “Status” on page 6–9.
Port
The Port control allows you to specify which interface to test. The following port tests
are available:
■ SFP0, SFP1, SFP2, SFP3
■ SMA x2
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–13
The Power Monitor
PMA Setting
The PMA Setting button allows you to make changes to the PMA parameters that
affect the active transceiver interface. For details, refer to “PMA Setting” on
page 6–10.
Data Type
The Data type control specifies the type of data contained in the transactions. For
details, refer to “Data Type” on page 6–10.
Error Control
This control displays data errors detected during analysis and allows you to insert
errors. For details, refer to “Error Control” on page 6–11.
Start
The Start control initiates the active port transaction performance analysis.
Stop
The Stop control terminates transaction performance analysis.
1 Always click Clear before Start.
Performance Indicators
These controls display current transaction performance analysis information collected
since you last clicked Start:
■ Tx and Rx performance bars—Show the percentage of maximum theoretical data
rate that the requested transactions are able to achieve.
■ Tx (MBps) and Rx (MBps)—Show the number of bytes of data analyzed per
second.
The Power Monitor
The Power Monitor measures and reports current power and temperature
information for the board. To start the application, click Power Monitor in the Board
Test System application.
1 You can also run the Power Monitor as a stand-alone application. PowerMonitor.exe
resides in the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\examples\board_test_system directory.
On Windows, click Start > All Programs > Altera > Stratix V GX 100G Development
Kit <version> > Power Monitor to start the application.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–14 Chapter 6: Board Test System
The Power Monitor
The Power Monitor communicates with the MAX II device on the board through the
JTAG bus. A power monitor circuit attached to the MAX II device allows you to
measure the power that the Stratix V GX FPGA device is consuming. Figure 6–7
shows the Power Monitor.
Figure 6–7. The Power Monitor
The following sections describe the Power Monitor controls.
General Information
The General information controls display the following information about the
MAX II device:
■ MAX II version—Indicates the version of MAX II code currently running on the
board. The MAX V code resides in the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery and <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\examples\max2 directories. Newer
revisions of this code might be available on the 100G Development Kit,
Stratix V GX page of the Altera website.
■ Power Rail—Indicates the currently-selected power rail.
f For more information on the power rails, refer to the 100G Development Kit,
Stratix V GX Edition Reference Manual.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–15
The Clock Control
Temperature Information
The Temperature information control displays the temperature readings for the
FPGA and the board.
Power Information
The Power information control displays current, maximum, and minimum power
readings for the following unit:
■ mAmp
Power Graph
The power graph displays the mA power consumption of your board over time. The
green line indicates the current value. The red line indicates the maximum value read
since the last reset. The yellow line indicates the minimum value read since the last
reset.
Graph Settings
The following Graph settings controls allow you to define the look and feel of the
power graph:
■ Scale select—Specifies the amount to scale the power graph. Select a smaller
number to zoom in to see finer detail. Select a larger number to zoom out to see the
entire range of recorded values.
■ Update speed—Specifies how often to refresh the graph.
Reset
This Reset control clears the graph, resets the minimum and maximum values, and
restarts the Power Monitor.
The Clock Control
The Clock Control application sets the Si5338 programmable oscillator to any
frequency between 10 MHz and 810 MHz with eight digits of precision to the right of
the decimal point. The oscillator drives a 2-to-4 buffer that drives a copy of the clock
to all four edges of the FPGA.
The Clock Control application runs as a stand-alone application. ClockControl.exe
resides in the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\examples\board_test_system directory.
On Windows, click Start > All Programs > Altera > Stratix V GX 100G Development
Kit <version> > Clock Control to start the application.
f For more information about the Si5338 and the Stratix V GX 100G development
board’s clocking circuitry and clock input pins, refer to the 100G Development Kit,
Stratix V GX Edition Reference Manual.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–16 Chapter 6: Board Test System
The Clock Control
The Clock Control communicates with the MAX II device on the board through the
JTAG bus. Figure 6–8 shows the Clock Control.
Figure 6–8. The Clock Control
The following sections describe the Clock Control controls.
Clock Tabs
There are three tabs to control each clock generator device. The U53 Si5338 tab
controls the clocks to the Stratix V fabric clock input and the reference clocks for all
the optical interfaces. The default is 100 MHz for the fabric and 644.53125 MHz for the
reference clocks for the transceivers. The U44 Si5338 tab controls the clocks for the
DDR3 and the Interlaken interface; its default is 100MHz for the DDR3 interface and
625MHz for the Interlaken interface. The U22 Si5338 tab controls the clocks for the
QDR II interface and the transceivers for the optical interfaces. The default
frequencies for these interfaces are 100MHz for the QDR II interface and
644.53125 MHz for the transceivers.
Registers
The Registers control shows the current values from the clock driver.
Frequency
Enter the desired frequencies for each CLK. The range of this GUI is from 5 MHz to
710 MHz. There are some limitations for what frequency combinations are allowed.
Disable
The Disable controls enables and disables all or selected outputs of the clock
generators.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Chapter 6: Board Test System 6–17
Configuring the FPGA Using the Quartus II Programmer
Read
Reads the register values and calculates the frequency based on these values.
Default
This control sets the frequency for the oscillator associated with the active tab back to
its default value. This can also be accomplished by power cycling the board.
Set New Frequency
The Set New Frequency control sets the Si5338 programmable oscillator frequency to
the value in the Target frequency control. Frequency changes might take several
milliseconds to take effect. You might see glitches on the clock during this time. Altera
recommends resetting the FPGA logic after changing frequencies.
Configuring the FPGA Using the Quartus II Programmer
You can use the Quartus II Programmer to configure the FPGA with a specific .sof.
Before configuring the FPGA, ensure that the Quartus II Programmer and the
USB-Blaster driver are installed on the host computer, the USB cable is connected to
the 100G development board, power to the board is on, and no other applications that
use the JTAG chain are running.
To configure the Stratix V GX FPGA, perform the following steps:
1. Start the Quartus II Programmer.
2. Click Auto Detect to display the devices in the JTAG chain.
3. Click Add File and select the path to the desired .sof.
4. Turn on the Program/Configure option for the added file.
5. Click Start to download the selected file to the FPGA. Configuration is complete
when the progress bar reaches 100%.
1 Using the Quartus II programmer to configure a device on the board causes other
JTAG-based applications such as the Board Test System and the Power Monitor to lose
their connection to the board. Restart those applications after configuration is
complete.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
6–18 Chapter 6: Board Test System
Configuring the FPGA Using the Quartus II Programmer
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
A. Programming the Flash Memory
Device
As you develop your own project using the Altera tools, you can program the flash
memory device so that your own design loads from flash memory into the FPGA on
power up. This appendix describes the preprogrammed contents of the common flash
interface (CFI) flash memory device on the Stratix V GX 100G development board and
the Nios II EDS tools involved with reprogramming the user portions of the flash
memory device.
The Stratix V GX 100G development board ships with the CFI flash device
preprogrammed with a default factory FPGA configuration for running the Board
Update Portal design example and a default user configuration for running the Board
Test System demonstration. There are several other factory software files written to
the CFI flash device to support the Board Update Portal. These software files were
created using the Nios II EDS, just as the hardware design was created using the
Quartus II software.
f For more information about Altera development tools, refer to the Design Software
page of the Altera website.
CFI Flash Memory Map
Tab le A –1 shows the default memory contents of the 1-Gb CFI flash device. For the
Board Update Portal to run correctly and update designs in the user memory, this
memory map must not be altered.
Table A–1. Byte Address Flash Memory Map
Block Description Size Address Range
Unused 128 0x07FE.0000 - 0x07FF.FFFF
User software 24,320 0x0716.0000 - 0x07F7.FFFF
Factory software 8,192 0x0696.0000 - 0x0715.FFFF
zipfs (html, web content) 8,192 0x0616.0000 - 0x0695.FFFF
User hardware 2 33,152 0x0410.0000 - 0x0615.FFFF
User hardware 1 33,152 0x020A.0000 - 0x040F.FFFF
Factory hardware 33,152 0x0002.0000 - 0x0209.FFFF
PFL option bits 32 0x0001.8000 - 0x0001.FFFF
Board information 32 0x0001.0000 - 0x0001.7FFF
Ethernet option bits 32 0x0000.8000 - 0x0000.FFFF
User design reset vector 32 0x0000.0000 - 0x0000.7FFF
c Altera recommends that you do not overwrite the factory hardware and factory
software images unless you are an expert with the Altera tools. If you unintentionally
overwrite the factory hardware or factory software image, refer to “Restoring the
Flash Device to the Factory Settings” on page A–4.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
A–2 Appendix A: Programming the Flash Memory Device
Preparing Design Files for Flash Programming
Preparing Design Files for Flash Programming
You can obtain designs containing prepared .flash files from the 100G Development
Kit, Stratix V GX page of the Altera website or create .flash files from your own
custom design.
The Nios II EDS sof2flash command line utility converts your Quartus II-compiled
.sof into the .flash format necessary for the flash device. Similarly, the Nios II EDS
elf2flash command line utility converts your compiled and linked Executable and
Linking Format File (.elf) software design to .flash. After your design files are in the
.flash format, use the Board Update Portal or the Nios II EDS
nios2-flash-programmer utility to write the .flash files to the user hardware 1 and
user software locations of the flash memory.
f For more information about Nios II EDS software tools and practices, refer to the
Embedded Software Development page of the Altera website.
Creating Flash Files Using the Nios II EDS
If you have an FPGA design developed using the Quartus II software, and software
developed using the Nios II EDS, follow these instructions:
1. On the Windows Start menu, click All Programs > Altera > Nios II EDS > Nios II
Command Shell.
2. In the Nios II command shell, navigate to the directory where your design files
reside and type the following Nios II EDS commands:
■ For Quartus II .sof files:
sof2flash --input=<yourfile>_hw.sof --output=<yourfile>_hw.flash --offset=0x020A0000
--pfl --optionbit=0x00081000 --programmingmode=PSr
■ For Nios II .elf files:
elf2flash --base=0x0 --end=0x07FFFFFF --reset=0x07160000 --input=<yourfile>_sw.elf
--output=<yourfile>_sw.flash
--boot=$SOPC_KIT_NIOS2/components/altera_nios2/boot_loader_cfi.srecr
The resulting .flash files are ready for flash device programming. If your design uses
additional files such as image data or files used by the runtime program, you must
first convert the files to .flash format and concatenate them into one .flash file before
using the Board Update Portal to upload them.
1 The Board Update Portal standard .flash format conventionally uses either
<filename>_hw.flash for hardware design files or <filename>_sw.flash for software
design files.
Programming Flash Memory Using the Board Update Portal
Once you have the necessary .flash files, you can use the Board Update Portal to
reprogram the flash memory. Refer to “Using the Board Update Portal to Update User
Designs” on page 5–1 for more information.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Appendix A: Programming the Flash Memory Device A–3
Programming Flash Memory Using the Nios II EDS
1 If you have generated a .sof that operates without a software design file, you can still
use the Board Update Portal to upload your design. In this case, leave the Software
File Name field blank.
Programming Flash Memory Using the Nios II EDS
The Nios II EDS offers a nios2-flash-programmer utility to program the flash memory
directly. To program the .flash files or any compatible S-Record File (.srec) to the
board using nios2-flash-programmer, perform the following steps:
1. Attach the USB-Blaster cable and power up the board.
2. If the board has powered up and the LCD displays either Connecting... or a valid IP
address (such as 152.198.231.75), proceed to step 7. If no output appears on the
LCD or if the MAX_CONF_DN LED (D25) does not illuminate, continue to step 3
to load the FPGA with a flash-writing design.
3. Launch the Quartus II Programmer to configure the FPGA with a .sof capable of
flash programming. Refer to “Configuring the FPGA Using the Quartus II
Programmer” on page 6–17 for more information.
4. Click Add File and select <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery\s5gx100g_fpga_bup
.sof.
5. Turn on the Program/Configure option for the added file.
6. Click Start to download the selected configuration file to the FPGA. Configuration
is complete when the progress bar reaches 100%. The MAX_CONF_DN LED (D25)
illuminates indicating that the flash device is ready for programming.
7. On the Windows Start menu, click All Programs > Altera > Nios II EDS > Nios II
Command Shell.
8. In the Nios II command shell, navigate to the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery directory (or to the
directory of the .flash files you created in “Creating Flash Files Using the Nios II
EDS” on page A–2) and type the following Nios II EDS command:
nios2-flash-programmer --base=0x0 <yourfile>_hw.flash r
9. After programming completes, if you have a software file to program, type the
following Nios II EDS command:
nios2-flash-programmer --base=0x0 <yourfile>_sw.flash r
10. Press the PGM_SEL button (S8) until the POF 1 LED (D34) illuminates, and then
press the LOAD (S5) to load and run the user hardware design.
Programming the board is now complete.
f For more information about the nios2-flash-programmer utility, refer to the Nios II
Flash Programmer User Guide.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
A–4 Appendix A: Programming the Flash Memory Device
Restoring the Flash Device to the Factory Settings
Restoring the Flash Device to the Factory Settings
This section describes how to restore the original factory contents to the flash memory
device on the 100G development board. Make sure you have the Nios II EDS installed,
and perform the following instructions:
1. Set the board switches to the factory default settings described in “Factory Default
Switch Settings” on page 4–2.
2. Launch the Quartus II Programmer to configure the FPGA with a .sof capable of
flash programming. Refer to “Configuring the FPGA Using the Quartus II
Programmer” on page 6–17 for more information.
3. Click Add File and select <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery\s5gx100g_fpga_bup
.sof.
4. Turn on the Program/Configure option for the added file.
5. Click Start to download the selected configuration file to the FPGA. Configuration
is complete when the progress bar reaches 100%. The MAX_CONF_DN LED (D25)
illuminates indicating that the flash device is ready for programming.
6. On the Windows Start menu, click All Programs > Altera > Nios II EDS > Nios II
Command Shell.
7. In the Nios II command shell, navigate to the <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery directory and type
the following command to run the restore script:
./restore.sh r
Restoring the flash memory might take several minutes. Follow any instructions
that appear in the Nios II command shell.
8. After all flash programming completes, cycle the POWER switch (SW1) off then
on.
9. Using the Quartus II Programmer, click Add File and select <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery\s5gx100g_fpga_bup
.sof.
10. Turn on the Program/Configure option for the added file.
11. Click Start to download the selected configuration file to the FPGA. Configuration
is complete when the progress bar reaches 100%. The MAX_CONF_DN LED (D25)
illuminates indicating the flash memory device is now restored with the factory
contents. The flash device is ready for programming.
12. Cycle the POWER switch (SW1) off then on to load and run the restored factory
design.
13. The restore script cannot restore the board’s MAC address automatically. In the
Nios II command shell, type the following Nios II EDS command:
nios2-terminal r
and follow the instructions in the terminal window to generate a unique MAC
address.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Appendix A: Programming the Flash Memory Device A–5
Restoring the MAX II CPLD to the Factory Settings
f To ensure that you have the most up-to-date factory restore files and information
about this product, refer to the 100G Development Kit, Stratix V GX page of the Altera
website.
Restoring the MAX II CPLD to the Factory Settings
This section describes how to restore the original factory contents to the MAX II CPLD
on the 100G development board. Make sure you have the Nios II EDS installed, and
perform the following instructions:
1. Set the board switches to the factory default settings described in “Factory Default
Switch Settings” on page 4–2.
1 Installing a shunt to MAX_JTAG_EN (J62) removes the MAX II device in
the JTAG chain.
2. Launch the Quartus II Programmer.
3. Click Auto Detect.
4. Click Add File and select <install
dir>\kits\stratixVGX_5sgxea7nf45_100g\factory_recovery\max2.pof.
5. Turn on the Program/Configure option for the added file.
6. Click Start to download the selected configuration file to the MAX II CPLD.
Configuration is complete when the progress bar reaches 100%.
f To ensure that you have the most up-to-date factory restore files and information
about this product, refer to the 100G Development Kit, Stratix V GX page of the Altera
website.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
A–6 Appendix A: Programming the Flash Memory Device
Restoring the MAX II CPLD to the Factory Settings
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
This chapter provides additional information about the document and Altera.
Document Revision History
The following table shows the revision history for this document.
Date Version Changes
August 2012 1.1 Release update for production silicon version.
February 2012 1.0 Initial release.
How to Contact Altera
To locate the most up-to-date information about Altera products, refer to the
following table.
Additional Information
Contact
Technical support Website www.altera.com/support
Technical training
Product literature Website www.altera.com/literature
Nontechnical support (general) Email nacomp@altera.com
Note to Table:
(1) You can also contact your local Altera sales office or sales representative.
(1)
(software licensing) Email authorization@altera.com
Contact Method Address
Website www.altera.com/training
Email custrain@altera.com
Typographic Conventions
The following table shows the typographic conventions this document uses.
Visual Cue Meaning
Bold Type with Initial Capital
Letters
bold type
Italic Type with Initial Capital Letters Indicate document titles. For example, Stratix IV Design Guidelines.
italic type
Indicate command names, dialog box titles, dialog box options, and other GUI
labels. For example, Save As dialog box. For GUI elements, capitalization matches
the GUI.
Indicates directory names, project names, disk drive names, file names, file name
extensions, software utility names, and GUI labels. For example, \qdesigns
directory, D: drive, and chiptrip.gdf file.
Indicates variables. For example, n + 1.
Variable names are enclosed in angle brackets (< >). For example, <file name> and
<project name>.pof file.
August 2012 Altera Corporation 100G Development Kit, Stratix V GX Edition
User Guide
Info–2 Additional Information
Typographic Conventions
Visual Cue Meaning
Initial Capital Letters
“Subheading Title”
Indicate keyboard keys and menu names. For example, the Delete key and the
Options menu.
Quotation marks indicate references to sections in a document and titles of
Quartus II Help topics. For example, “Typographic Conventions.”
Indicates signal, port, register, bit, block, and primitive names. For example,
tdi
, and
input
. The suffix n denotes an active-low signal. For example,
resetn
data1
.
,
Indicates command line commands and anything that must be typed exactly as it
Courier type
appears. For example,
c:\qdesigns\tutorial\chiptrip.gdf
.
Also indicates sections of an actual file, such as a Report File, references to parts of
files (for example, the AHDL keyword
TRI
example,
).
SUBDESIGN
), and logic function names (for
r An angled arrow instructs you to press the Enter key.
1., 2., 3., and
a., b., c., and so on
■ ■ ■ Bullets indicate a list of items when the sequence of the items is not important.
Numbered steps indicate a list of items when the sequence of the items is important,
such as the steps listed in a procedure.
1 The hand points to information that requires special attention.
h The question mark directs you to a software help system with related information.
f The feet direct you to another document or website with related information.
m The multimedia icon directs you to a related multimedia presentation.
c
w
A caution calls attention to a condition or possible situation that can damage or
destroy the product or your work.
A warning calls attention to a condition or possible situation that can cause you
injury.
The envelope links to the Email Subscription Management Center page of the Altera
website, where you can sign up to receive update notifications for Altera documents.
The feedback icon allows you to submit feedback to Altera about the document.
Methods for collecting feedback vary as appropriate for each document.
100G Development Kit, Stratix V GX Edition August 2012 Altera Corporation
User Guide
Loading...
