Alpha SF154A2 Specsheet

Product Specification Sheet APS734 - Rev. 07/2013

SF154A2 Emergency Push Call Station - 2 CircuitsSF154A2 Emergency Push Call Station - 2 Circuits

387 CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone] CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone]

Web: www.canalalarm.comWeb: www.canalalarm.com

Copyright © 1998-2 017 Alpha Communication s® - All Righ ts Reserved.

Due to c ontinuo us product i mprovement, all col ors, sizes, materials, finishes and sp ecifications are subject to change witho ut not ice.

Architects' And Engineers'Architects' And Engineers'

SpecificationsSpecifications

Emergency Push St ation(s) shall be Alpha
Communications® SF154A2 or approved
equal.

Operation of all syst em emergency signals
shall be acc omplished by depressing the
push button switc h. When ac t ivated, the
switc h shall turn from Black to Red,
indicating that a c all has been plac ed.
Canceling the call shall be possible only at
the point of origin. The switch shall be
mounted on a white plastic faceplate,
marked 'EMERGENCY' in black lettering.
Fac eplate shall be made of flame
retardant White ABS plastic. Standard
mounting screws shall be provided.
Stat ion shall provide two (2)
separate sets of Form 'C' type c ontact
connections for activation of two (2)
separate signals/devices.

Contractor shall observe all local and
national elect rical and building codes.

SF154A2 Emergency Push Call StationSF154A2 Emergency Push Call Station

The Alpha Communicat ions® SF154A2 push type emergency stat ion is used to initiate
system emergency signals. Signaling an emergency is accomplished by depressing the
locking push button switch located at the center of the fac eplate to t he "IN" position. In
this position, t he butt on will appear Red. Depressing the push butt on again cancels the c all
and the Red color disappears and turns Black. The signal c annot be cancelled except at t he
point of origin. The SF 154A2 can easily act ivate two (2) separate signals, since it c ontains
two (2) separate Form 'C' type dry cont ac t connec tions.

FeaturesFeatures

Simple, reliable operation
Call activates lamp on annunciator panel and c orridor lamp.
Mounted on attractive flame retardant white ABS plastic faceplate with the word
EMERGENCY in black lett ering
Has two (2) separate Form 'C' type dry cont acts

SpecificationsSpecifications

Dimensions:

Height: 4.50" (114mm)
Width: 2.75" (70mm)
Depth: 2.44" (52mm)

Panel: Flame retardant White ABS plastic fac eplate

Connection: Wire pigtail leads (2 sets of 2)

Mounting:

Steel City #52171 box with Steel City #52C14 plaster ring, or Alpha
Communications® Model IH358 box with IH357 ring, or EXACT EQUAL.
Vertical mount.

Marking: Marked EMERGENCY in Black lett ering
