Alpha SF119-2A Specsheet

Product Specification Sheet APS677 - Rev. 07/2013

SF119/2A Emergency Call Switch for AlphaStatus™ systemSF119/2A Emergency Call Switch for AlphaStatus™ system

387 CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone] CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone]

Web: www.canalalarm.comWeb: www.canalalarm.com

Copyright © 1998-2 017 Alpha Communication s® - All Righ ts Reserved.

Due to c ontinuo us product i mprovement, all col ors, sizes, materials, finishes and sp ecifications are subject to change witho ut not ice.

Architects' And Engineers' SpecificationsArchitects' And Engineers' Specifications

The Emergency Call switc h(es) shall be Alpha Communications®
model SF119/2A, or approved equal with pull cord operated switc h,
mounted on a durable ABS plastic (flame retardant) fac eplate
marked "EMERGENCY". Signaling for assistance shall only require a
short pull in any direction on the 6' nylon cord. Canc eling the c all
shall be possible only at the point of origin. Unit shall mount
on single-gang elect ric "gem" box or plaster ring. The

SF119/2A the shall have a RED 'Call-Plac ed' Flag Indicator

which gives positive visual assurance when a c all is
placed, without the need for any additional power or
stat ion wiring. Pull cords without a RED 'call placed' flag
indicator shall not be acceptable.

Typic ally, the Emergency Call switc h(es) may be used with 'stand­alone' low-voltage emergency systems, or with the AlphaEcall™,
CM800, DS100, AlphaStatus™ and/or QwikBUS™ series systems.

Contractor shall observe all local and national electrical and
building codes.

SF119/2A Emergency Pull Cord SwitchSF119/2A Emergency Pull Cord Switch

The Alpha Communicat ions® SF119/2A Emergency Pull Switc h
features a rugged, long-life, positive- ac ting switch mounted on a
durable ABS plastic fac eplate. Signaling an emergency requires just
a short pull on the 6' long nylon cord, in any direction. T he signal
cannot be c anc eled except at t he point of origin. It is primarily
designed to be used with the AlphaStatus™ room status syst em,
but c an be used for other low-voltage applications as well.

The SF119/2A provides t wo (2) separate circuits to operate two
(2) separate signaling devices, suc h as a remote annunciator lamp,
and a c orridor dome lamp, or other similar type applicat ion.

The SF119/2A features a rugged, long-life, positive- acting switc h
mounted on a flame retardant type ABS plastic faceplate marked
"EMERGENCY" in Black lett ering. In addition, the SF119/2A features
our 'Exclusive' RED 'Call-Placed' Flag Indicator which gives positive
visual assurance when a c all is placed, without t he need for
any additional power or station wiring.

Wiring RequirementsWiring Requirements

Refer to system wiring diagram for more c omplete
wiring information. These switc hes are low-voltage Class II
type and should only be used for low- voltage indoor applications.
They are not suitable for wet environments.

SpecificationsSpecifications

Dimensions:

Height: 4.50" (114mm) (less cord)
Width: 2.75" (70mm)
Depth: 1.50" (38mm) (into wall)

Faceplate: White ABS plastic.

Switch:

SF119/2A - 2PDT 2 separate set s of

N/O latching contac ts
Switc h rating: 125V, 2A

Connection: Pigtail wire leads

Mounting: Standard single-gang electrical box

Marking: "EMERGENCY" in Black Letters

Cord Length:

6 foot long (can be shortened in
the field), made of durable Nylon
