Description
11 Megapixel CCD camera - 5 fps
The 11 megapixel GE4000 is a very high-resolution CCD camera with Gigabit Ethernet output
(GigE Vision®). The GE4000 features the high-quality 35 mm format Truesense KAI-11002
CCD image sensor that provides exceptionally high resolution, sensitivity, and dynamic range.
●
5 fps at 4008 x 2672
●
F-mount
●
Models:
❍
GE4000, 4008 x 2672, 5 fps, CCD, mono
❍
GE4000C, 4008 x 2672, 5 fps, CCD, color
●
Modular options:
❍
Canon EF Lens Mount (Factory conversion via RS232 I/O)
❍
IRC Filter on Monochrome cameras (Factory installation)
❍
Taped glass and microlens (Factory built)
❍
Taped glass No microlens (Factory built)
❍
Truesense Class 1 (Factory built with Class 1 sensor grade)
❍
Truesense Class 0 (Factory built with Class 0 sensor grade)
http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-ge/ge4000.html 1
Specifications
Prosilica GE 4000
Interface IEEE 802.3 1000baseT
Resolution 4008 x 2672
Sensor Truesense KAI-11002
Sensor type CCD Progressive
Sensor size Type 35 mm
Cell size 9 µm
Lens mount F
Max frame rate at full resolution 5 fps
A/D 12 bit
On-board FIFO 32 MB
Output
Bit depth 8/12 bit
Mono modes Mono8, Mono12, Mono12Packed
Color modes YUV n/a
Color modes RGB n/a
Raw modes BayerGR8, BayerGR12, BayerGR12Packed
General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 3 outputs (with galvanic isolation)
RS-232 1
Operating conditions/Dimensions
Operating temperature 0°C ... +50°C
Power requirements (DC) 5V - 24V
Power consumption (12 V) 6 W
Mass 402 g
Body Dimensions
(L x W x H in mm)
Regulations CE, FCC Class A, RoHS (2011/65/EU)
110 x 66 x 66 including connectors, w/o tripod and lens
Download Prosilica GE4000 technical drawing (click here)
http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-ge/ge4000.html 2
Smart features
Features include:
●
Auto Exposure
●
Auto Gain
●
Auto White balance
●
Flexible Binning
●
Region of Interest readout (AOI partial scan)
●
DSP subregion (selectable ROI for auto features)
●
StreamBytesPerSecond (easy bandwidth control)
●
Stream hold
●
Asynchronous external trigger and sync I/O
●
Global shutter (digital shutter)
●
Recorder and Multiframe Acquisition Modes
Application Note:
Birger EF-Mount, Modular Option -09
http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-ge/ge4000.html 3
Applications
The GE4000 is ideal for a wide range of applications requiring very high resolution. These
include:
●
LCD panel inspection
●
Semiconductor wafer inspection
●
Solar panel inspection
●
Aerial photography
●
3-D metrology
●
General machine vision
●
Public security
●
Surveillance
●
Traffic imaging (Intelligent Traffic Systems)
●
Embedded systems
●
OEM applications
Application Case Studies:
●
Prosilica Cameras Go Airborne
Security & Traffic: Prosilica GE4000 used in UAV technology.
●
GE4000 Observes Gamma-Ray Phenomena
Science & Research: The Sternberg Astronomical Institute of the Moscow State University in
Russia uses Prosilica GE4000 GigE Vision cameras to detect and measure gamma ray
bursts.
