Description
1.4 Megapixel CCD camera with GigE Vision
The 1.4 Megapixel GC1350 is a high-resolution CCD camera with Gigabit Ethernet interface
(GigE Vision®). The GC1350 incorporates a high-quality Sony ½" CCD sensor providing
excellent monochrome and color image quality. The GC1350 runs 20 frames per second at
1360 x 1024 resolution and even faster with region of interest readout.
●
High resolution - 1.4 megapixels (1360 x 1024)
●
Sony ICX205 ½" Progressive scan CCD
●
Models:
❍
GC1350, 1360 x 1024, 20 fps, CCD, mono
❍
GC1350C, 1360 x 1024, 20 fps, CCD, color
http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-gc/gc1350.html 1
Specifications
Prosilica GC 1350
Interface IEEE 802.3 1000baseT
Resolution 1360 x 1024
Sensor Sony ICX205
Sensor type CCD Progressive
Sensor size Type 1/2
Cell size 4.65 µm
Lens mount C (adjustable)
Max frame rate at full resolution 20 fps
A/D 12 bit
On-board FIFO 16 MB
Output
Bit depth 8/12 bit
Mono modes Mono8, Mono12, Mono12Packed
Color modes YUV YUV411Packed, YUV422Packed, YUV444Packed
Color modes RGB RGB8Packed, BGR8Packed
Raw modes BayerRG8, BayerRG12, BayerGR12Packed
General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 1 output
Opto-coupled I/Os 1 input, 1 output
RS-232 1
Operating conditions/Dimensions
Operating temperature 0°C ... +50°C
Power requirements (DC) 5-25 VDC*
Power consumption (12 V) 3 W
Mass 100 g
Body Dimensions
(L x W x H in mm)
Regulations CE, FCC Class A, RoHS (2011/65/EU)
59 x 46 x 33 including connectors, w/o tripod and lens
* 5–16 VDC for Cameras with SN: 02-XXXXX-0XXXX
Download Prosilica GC1350 technical drawing (click here)
http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-gc/gc1350.html 2
Smart features
The GC1350 features include:
●
Auto Exposure
●
Auto Gain
●
Auto White balance
●
Flexible Binning
●
Region of Interest readout (AOI partial scan)
●
StreamBytesPerSecond (easy bandwidth control)
●
DSP subregion (selectable ROI for auto features)
●
Stream hold
●
Asynchronous external trigger and sync I/O
●
Global shutter (digital shutter)
●
Recorder and Multiframe Acquisition Modes
http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-gc/gc1350.html 3
Applications
The GC1350 is ideal for a wide range of applications including:
●
Industrial inspection
●
Machine vision
●
Ophthalmology
●
Aeronautical and aerospace
●
Public security
●
Surveillance
●
Traffic imaging
●
OEM applications
Application Case Studies:
●
Mobile machine vision system featuring AVT GigE cameras surveys pavement
condition
Proper infrastructure and road maintenance is essential to ensure the safety of road users
and to keep vehicle operating costs down.
