Allen&Heath RPS11 User Manual

RPS11

Rack Mount Power Supply

USER GUIDE

Publication AP2725

Warranty

LIMITED ONE YEAR WARRANTY

This product is warranted to be free from defects in materials or workmanship for a period of one year from the date of purchase by the original owner.

To ensure the high level of performance and reliability for which this equipment has been designed and manufactured please read the User Guide before use.

In the event of a failure notify and return the defective unit to ALLEN & HEATH or its authorised agent as soon as possible for repair under warranty subject to the following conditions:

CONDITIONS OF WARRANTY:

1. The product has been installed and operated in accordance with the instructions in the User Guide.

2. The product has not been subject to misuse either intended or accidental, neglect, or alteration other than as described in the User Guide or Service Manual, or approved by ALLEN & HEATH.

3. Any necessary adjustment, alteration, or repair has been carried out by ALLEN & HEATH or its authorised agent.

4. The defective unit is to be returned carriage prepaid to ALLEN & HEATH or its authorised agent with proof of purchase.

5. Units to be returned should be packed to avoid transit damage.

In certain territories the terms may vary. Check with your Allen & Heath agent for any additional warranty that may apply.

Allen & Heath Agent:

Publication AP2725 Issue 5

Allen & Heath Limited, Kernick Industrial Estate, Penryn, Cornwall. England. TR10 9LU

Tel: 01326 372070

Fax: 01326 377097

Information in this manual is subject to change without notice and does not represent a commitment on the part of the vendor. ALLEN & HEATH shall not be liable for any loss or damage whatsoever arising from the use of information or any error contained in this manual.

No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by means, electronic, electrical, mechanical, optical, chemical, including photocopying and recording, for any purpose without the express written permission of ALLEN & HEATH.

It is recommended that all maintenance and service on the product should be carried out by ALLEN & HEATH or its authorised agents. ALLEN & HEATH cannot accept any liability whatsoever for any loss or damage caused by service, maintenance or repair by unauthorised personnel.

RPS11 Power Supply

INTRODUCING THE RPS11

The RPS11 is a linear power supply which, like other linear supplies, produces DC voltages by rectifying, smoothing and regulating AC voltages from the secondary windings of a mains transformer.

Allen & Heath mixing consoles employ a number of DC voltage supply levels in their operation and these are provided at the output of the power supply unit.

IMPORTANT: Please read this manual carefully before connecting your

RPS11

CONSOLE POWER SUPPLY

ALLEN&HEATH

POWER

DC FUSES

CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE

REPLACE FUSE WITH SAME TYPE AND RATING.

ATTENTION: REMPLACER LE FUSIBLE AVEC UN DES MEMES

CARACTERISTIQUES.

T 10A 250V 20mm

V+

V-

ON OFF

RPS11 power supply to the mains.

This product complies with the European Electromagnetic Compatibility directives 89/336/EEC & 92/31/EEC and the European Low Voltage directive 73/23/EEC & 93/68/EEC.

IMPORTANT: Any changes or modifications to the equipment not approved by Allen & Heath could void the compliance of

the console and therefore the users authority to operate it.

Precautions and Safety instructions

General Precautions

Avoid storing or using the RPS11 in conditions of excessive heat or cold, or in positions where it is likely to be subjected to vibration, dust or moisture. Do not use any liquids to clean the exterior of the unit: a soft, dry cloth or brush is ideal.

SOLVENTS MAY CAUSE DAMAGE TO PAINT OR PLASTIC PARTS

Handling and Transport

The RPS11 is supplied in a specially designed cardboard box. If it is necessary to move the unit any distance after installation, it is recommended that this carton is used to protect it. Be sure to disconnect all cabling before moving. If the RPS11 is to be moved regularly (e.g. touring) it is recommended that it is installed in a foam lined case. At all times avoid applying excessive force to any switches or connectors.
