16ch multitrack recorder + USB / FireWire interface
ALLEN&HEATH
INCLUDES ice-16d
WITH BALANCED d SUB I/O
16ch multitrack recorder + USB / FireWire interface
ICE-16 records 16 tracks of audio directly to a USB key or hard drive. Just connect the 16 analogue inputs
to any line level source (your mixer’s direct outs are ideal), plug in your memory and press record to
capture live shows, band rehearsals, conferences or services for mixing or playback afterwards.
ICE-16 also functions as a 16 x 16 channel interface to your computer in the studio, streaming high quality
digital audio at 24bit, up to 96kHz sample rate over FireWire or high speed USB 2.0. Units can be linked when
streaming over FireWire to expand the channel count even further.
The ICE-16D version offers fully balanced inputs & outputs on standard D Sub connectors, making it ideal
The
for use in professional studios or where long cable runs are needed.
Live or in the studio, ICE-16 makes multitrack recording easy.
FEATURES
16 analogue Inputs, 16 analogue Outputs
Front USB socket for quick capturing to USB mass storage devices
Hybrid FireWire (IEE1394) / USB2 .0 16x16 audio interface
Industry standard wav file format
Up to 6 hours of 16 channel audio on a 32GB USB stick
Signal Present and Peak LED metering on each channel
Mono headphone bus for Input or Output monitoring
Daisy chain multiple units over FireWIre
Familiar Transport buttons and intuitive controls
ALLEN&HEATH
16 trs jack inputs & 16 rca outputs
16 balanced i/o with D Sub connectors
Connect
Interface
Multiple units can be daisy-chained over the FireWire bus, or kept
in sync using the DIN connectors when recording on multiple USB
devices, making iCE-16 the perfect companion for both small and
large analogue consoles such as our acclaimed ZED, MixWizard
and GL mixers. Plug into your desk Direct Outs or use a mix of
Groups and Aux sends to save on channels.
Record
The USB DRIVE is automatically detected and checked by the system.
Starting the recording is as simple as pushing a button. Remove and
plug the key into a computer to access or transfer the WAV files to
any DAW.
APPLICATIONS
Removing the USB stick or powering up the unit without one enables
the USB / FireWire interface. Signals present at the inputs will be
sent to the Mac or PC on channels 1-16. WDM/ASIO drivers and USB2.0
class compliance ensure full compatibility with most DAWs,
including Logic, Sonar, Cubase and Pro Tools.
PLAY
Fancy a ‘virtual soundcheck’ or just need to play cues during a live
gig? Tracks can be played back directly from the USB DRIVE AND full
multichannel audio can be sent from the computer to the ICE-16
analogue Outputs.
sync link to
second ice-16
for extra i/o
(1) Direct streaming to USB device
– multiple units can be linked to
record in sync on multiple USB
keys, gaining extra I/O e.g. for a 32
channel mixer.
ice-16 outputs
to mixer
line inputs
mixer direct ouputs
to ice-16 inputs
daisy chain to
second ice-16
for extra i/o
(2) Recording on a laptop –
multiple units can be daisy-
chained on the FireWire bus,
gaining extra I/O e.g. for a 32
channel mixer.
ice-16 outputs
to mixer
line inputs
mixer direct ouputs
to ice-16 inputs
TECH SPECS ICE-16
Operating Levels
Input (Jack socket)
Output (RCA Phono)
Operating Levels ice-16 d
Input (d sub connectors)
Output (d sub connectors)
USB 2.0 & IEE1394 FireWire streaming
USB 2.0 & IEE1394 FireWire streaming
Sample rates (kHz)
Round trip latency
Metering and Monitoring
Input signal/Output Signal Level indicator threshold
Input signal/Output Peak Level indicator threshold
Headphone Monitor
DIMENSIONS
Size (W x D x H)
Weight (unpacked)
0dBu nominal (+21dBu maximum)
0dBu nominal (+21dBu maximum)
+4dBu nominal (+26dBu maximum)
+4dBu nominal (+26dBu maximum)
44.1, 48, 88.2, 96
<10mS
-22dBu
-22dBu
+15dBu (6dB below clip)
1/4” & 3.5mm TRS Jack
482 x 230 x 44mm (19” x 9” x 1.75”) : 1U
3kg (6.6lb)
Bit depth (Depending on USB Drive quality)
USB Drive Direct Recording
Sample rates (kHz)
Memory devices
File format
Maximum track recording time
Fat/Fat 32 file size limited to 4GB
Fat/Fat 32 file size limited to 4GB
Memory usage rate, 16 tracks
16bit 44.1kHz
16bit 48kHz
24bit 44.1kHz
24bit 48kHz
Maximum supported hard drive size
44.1, 48
16, 24
USB 2.0/3.0 Stick or hard drive
.wav
Mono track 16bit/44.1kHz 12:30h
Mono track 16bit/48kHz 11.34h
Mono track 24bit/44.1kHz 8:20h
Mono track 24bit/44.1kHz 8:20h
Mono track 24bit/48kHz 7:42h
84.67MB/minute
92.16MB/minute
127MB/minute
138.24MB/minute
8TB
Weight (packed)
Technical specifications are subject to change without notice
Allen & Heath reserves the right to alter any information supplied in this document or any other document supplied hereafter
ALLEN&HEATH
4.4kg (9.7lb)
www.allen-heath.com allenheathofficial
allen_heath
Issue: AP8967_2
