Owner’s Instructions
PDP4294
BN68-00504A-00
Thank you for choosing AKAI! Your new AKAI product represents the latest in television technology.
We designed it with easy-to-use on-screen menus and closed captioning capabilities, making it one of
the best products in its class. We are proud to offer you a product that will provide convenient,
dependable service and enjoyment for years to come.
Important Safety Information
Always be careful when using your PDP. To reduce the risk of fire, electrical shock, and other injuries,
keep these safety precautions in mind when installing, using, and
maintaining your machine.
• Read all safety and operating instructions before operating your PDP.
• Keep the safety and operating instructions for future reference.
• Heed all warnings on the PDP and in the operating instructions.
• Follow all operating and use instructions.
• Unplug the PDP from the wall outlet before cleaning. Use a damp cloth; do not use liquid or aerosol
cleaners.
• Never add any attachments and/or equipment without approval of the manufacturer. Such additions
can increase the risk of fire, electric shock, or other personal injury.
• Do not use the PDP where contact with or immersion in water is a possibility, such as near bath tubs,
sinks, washing machines, swimming pools, etc.
• Do not place the PDP on an unstable cart, stand, tripod, bracket,
table, or floor where it can fall. A falling PDP can cause serious injury
to a child or adult, and serious damage to the appliance. Use only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the PDP. Follow the manufacturer's instructions
when mounting the unit, and use a mounting accessory recommended
by the manufacturer. Move the PDP and cart with care. Quick stops,
excessive force, and uneven surfaces can make the unit and cart
unsteady and likely to overturn.
• Provide ventilation for the PDP. The unit is designed with slots in the cabinet for ventilation to protect it
from overheating. Do not block these openings with any object, and do not place the PDP on a bed,
sofa, rug, or other similar surface. Do not place it near a radiator or heat register. If you place the
PDP on a rack or bookcase, ensure that there is adequate ventilation and that you've followed the
manufacturer's instructions for mounting.
• Operate your PDP only from the type of power source indicated on the marking label. If you are not
sure of the type of power supplied to your home, consult your appliance dealer or local power company.
• Use only a grounded or polarized outlet. For your safety, this PDP is equipped with a polarized alternating current line plug having one blade wider than the other. This plug will fit into the power outlet
only one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If
the plug still does not fit, contact your electrician to replace your outlet.
Warning! Important Safety Instructions
32
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact
with any inside part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Note to CATV system installer: This reminder is provided to call CATV system installer's attention to Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building as close to the point of cable entry as practical.
Caution: FCC/CSA regulations state that any unauthorized changes or modifications to this equipment may
void the user's authority to operate it.
Caution: To prevent electric shock, match the wide blade of plug to the wide slot, and fully insert the plug.
Attention: pour eviter les chocs electriques, introduire la lame le plus large de la fiche dans la borne corre-
spondante de la prise et pousser jusqu'au fond.
Important: One Federal Court has held that unauthorized recording of copyrighted TV programs is an
infringement of U.S. copyright laws.
Certain Canadian programs may also be copyrighted and any unauthorized recording in whole or in part
may be in violation of these rights.
TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
Thank You for Choosing AKAI
5
• Protect the power cord. Power supply cords should be routed so that they won’t be walked on or pinched
by objects placed on or against them. Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from the unit.
• Unplug the PDP from the wall outlet and disconnect the antenna or cable system during a lightning storm
or when left unattended and unused for long periods of time. This will prevent damage to the unit due to
lightning and power-line surges.
• Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead
power lines or other electric light or power circuits or where it can fall into such power lines or circuits.
When installing an outside antenna system, be extremely careful to keep from touching the power lines
or circuits. Contact with such lines can be fatal.
• Do not overload the wall outlet or extension cords. Overloading can result in fire or electric shock.
• Do not insert anything through the openings in the unit, where they can touch dangerous voltage points
or damage parts. Never spill liquid of any kind on the PDP.
• Ground outdoor antennas. If an outside antenna or cable system is connected to the PDP, be sure the
antenna or cable system is grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA No.70-1984, provides information about proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
• Do not attempt to service the PDP yourself. Refer all servicing to qualified service personnel. Unplug the
unit from the wall outlet and refer servicing to qualified service personnel under the following conditions:
- when the power-supply cord or plug is damaged
- if liquid has been spilled on the unit or if objects have fallen into the unit
- if the PDP has been exposed to rain or water
- if the PDP does not operate normally by following the operating instructions
- if the PDP has been dropped or the cabinet has been damaged
- when the PDP exhibits a distinct change in performance
• If you make adjustments yourself, adjust only those controls that are covered by the operating instructions. Adjusting other controls may result in damage and will often require extensive work by a qualified
technician to restore the PDP to normal.
• When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may result in additional damage to the unit.
• Upon completion of any service or repairs to this PDP, ask the service technician to perform safety checks
to determine that the PDP is in a safe operating condition.
• The PDP can properly operate in a temperature range of 32~104°F(0~40°C) and 80% humidity.
Do not use in a hot and humid place.
• Before moving the PDP equipped with speakers, separate the speakers from the PDP. If you move the PDP
with the speakers attached, it may result in damage or injury.
4
General Information
Your New Plasma Display Panel....................10
Remote Control Buttons ................................12
Wall Installation Instructions..........................14
Connections
Connecting VHF and UHF Antennas ..............20
Connecting Cable TV ..................................21
Connecting Speakers ..................................23
Connecting a VCR ......................................24
Connecting a Camcorder ............................25
Connecting a DVD Player ............................26
Connecting a DTV Receiver ..........................27
Operation
Turning the PDP On and Off ........................30
Memorizing the Channels ............................32
Setting Up Your Remote Control ....................37
Picture Control
Customizing the Picture ..............................40
Using Automatic Picture Settings ..................41
Selecting the Color Tone ..............................42
Viewing the Picture-in-Picture ........................43
Changing the Screen Size ..........................49
Freezing the Picture ...................................50
Sound Control
Customizing the Sound ................................52
Using Automatic Sound Settings ...................53
Choosing a Multi-Channel Sound (MTS)Soundtrack
......54
Using the Auto Volume ................................55
Using Dolby Virtual......................................56
Using a Subwoofer......................................57
Channel Control
Fine Tuning Channels ..................................60
LNA (Low Noise Amplifier) ..........................61
Connecting a PC and Operation
Connecting to a PC ....................................64
Adjusting the PC Screen ..............................68
Changing the Position of the Image................69
Changing the Size of the Image ..................70
Information ................................................71
Picture Quality Adjustment ..........................72
Time Setting
Setting the Clock ........................................76
Setting the Sleep Timer ................................77
Setting the Timers ........................................78
Setting the Preferred Channel and Volume Level
....80
Function Description
Selecting a Menu Language ........................82
Viewing Closed Captions ............................83
Digital Noise Reduction ..............................84
Setting Auto Power Off ................................85
Using the V-Chip..........................................86
Selecting the Film Mode ..............................91
Appendix
Troubleshooting ..........................................94
Care and Maintenance ................................95
Specifications..............................................96
7
Important Warranty Information
Regarding Television Format Viewing
User Instructions
Wide screen format PDP Displays (16:9,the aspect ratio of the screen width to height) are primarily
designed to view wide screen format full-motion video.The images displayed on them should primarily be
in the wide screen 16:9 ratio format,or expanded to fill the screen if your model offers this feature and constantly moving. Displaying stationary graphics and images on screen, such as the dark side-bars on nonexpanded standard format television video and programming, should be limited to no more than 5% of the
total television viewing per week.
Additionally,viewing other stationary images and text such as stock market reports, video game
displays,station logos,web sites or computer graphics and patterns,should be limited as described above
for all televisions. Displaying stationary images that exceed the above guidelines can
cause uneven aging of PDP Displays that leave subtle,but permanent burned-in
ghost images in the PDP picture.To avoid this,vary the programming and images,
and primarily display full screen moving images,not stationary patterns or dark bars.
On PDP models that offer picture sizing features,use these controls to view different formats as a full screen
picture.
Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a
result of format selection and use,as well as burned-in images, are not covered by your AKAI limited
warranty.
6
Table of Contents
Screen Image retention
Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma
display panel for more than several minutes as it can cause screen image retention. This image retention is
also known as “screen burn”. To avoid such image retention, refer to page 40 of this manual to reduce the
degree of brightness and contrast of this screen when displaying a still image.
Cell Defect
The plasma display panel consists of fine cells. Although the panels are produced with more than 99.9
percent active cells, there may be some cells that do not produce light or remain lit.
Altitude
The PDP will not operate normally at altitudes above 6500 ft.
Warranty
Warranty Period: Two years starting from the purchase of your PDP.
Warranty does not cover any damage caused by image retention.
PLASMA DISPLAY PANEL
General Information
Your New Plasma Display Panel ....................................................10
Remote Control Buttons ................................................................12
Wall Installation Instructions ..........................................................14
Remote Control
Signal Receiver
Aim the remote
control towards
this spot on the PDP.
Power Indicator
Power Off : LED Red
Power On (Timer On) : LED Green
Power On (Timer Off) : LED Off
Front Panel
11
Your New Plasma Display Panel
10
Rear Panel
Checking Accessories
Remote Control/AAA Batteries
Antenna Cable Speaker Cables
Power Cord Owner’s Instructions
ŒService jack
For service only.
´DVI Input jacks
Receives the digital video/audio signals from a
set top box or PC.
ˇPC(RGB) Input jacks(15pin)
Connect to the video/audio output jacks on
your PC.
¨S-Video Input jacks
Connect S-Video/audio signals from external
sources such VCRs or DVD players.
ˆVideo Input jacks
Connect video/audio signals from external
sources such VCRs or DVD players.
ØComponent Video/Audio Input jacks
(Y/Pb/Pr/Audio L/Audio R)
Connect to the audio and component output
jacks of a DVD player or Set-Top Box.
∏External Speaker Out jacks
Connect external speakers.
”Antenna jack
Connect to antenna.
’Sub-woofer speaker output jack
Connect to the Sub-woofer speaker jack.
˝Power Input jack
Connect the supplied power cord.
Speakers
(optional)
SOURCE button
Press to display all of the available video sources
(ie., Video, S-Video, Component1, Component2, PC ).
MENU button
Displays the main on-screen menu.
VOL(+,-) button
Press to increase or decrease the volume. Also used
to select or adjust items on the on-screen menu.
CH(▼,▲) button
Press CH▲ or CH▼ to change Channels.
Also
used to move up or down in the On-screen menu.
POWER button
Press to turn the PDP on and off.
Stand-Base
(2EA)
Ferrite Cores(3EA)
Once you have unpacked your PDP, check to make sure that you have all the parts shown here.
If any piece is missing or broken, call your dealer.
Assembling the Stand-Base
Fit the Stand-Base into the guide hole on the bottom of the monitor and tighten the left and
right sides using four screws for each side.
Two or more peple should carry the PDP.
Never lay the PDP on the floor because of possible damage
to the screen. Always store the PDP upright.
˘Sleep button
Press to select a preset time interval for automatic
shutoff.
¿ CH.Scan button
Press to memorize(scan) the available channels.
¸Caption button
Controls the caption decoder.
˛PIP control buttons
Source : Press to select one of the available signal
sources for the PIP window.
Swap : Exchanges the video signal that is currently
displayed on the main screen with the signal
in the PIP window.
Locate : Press to move the PIP window on the screen.
S.Swap: Press to select the audio (PIP or Main).
Size : Press to make the PIP window Large, Small
or Double.
CH
▲,▼
: Displays the available channels in sequence.
(These buttons change channels in the PIP
window only).
◊Auto Program button
The TV automatically cycles through all of the available
channels and stores them in memory.
± SET button
Used during setup of this remote control, so that it will
work compatibly with other devices (VCR, cable box,
DVD, etc.)
≠Add/Erase button
Press to add or erase channels in the TV’s memory.
–VCR, DVD control buttons
Controls VCR tape or DVD disc functions: Stop, Rewind,
Play/Pause, Fast Forward.
13
Remote Control Buttons
ŒPower button
Turns the PDP on and off.
´Number buttons
ˇ+100 button
Press to select channels over 100. For example, to select
channel 121, press “+100”, then press “2” and “1.”
¨Menu button
Displays the main on-screen menu.
ˆCH (Channel) and VOL (Volume) buttons
Use it to switch channels or adjust volume.
ØMute button
Press to mute the PDP sound.
∏PIP button
Activates picture in picture.
”Aspect button
Press to change the screen size.
’P.Mode button
Adjust the PDP picture by selecting one of the preset
factory settings (or select your personal, customized
picture settings.)
˝S.Mode button
Adjust the PDP sound by selecting one of the preset
factory settings (or select your personal, customized
sound settings.)
ÔMode button
Selects a target device to be controlled by the AKAI
remote control (ie., VCR, Cable, or DVD players).
Pre-CH button
Tunes to the previous channel.
ÒSource button
Press to display all of the available video sources
(ie., Video, S-Video, Component1, Component2, PC, DVI).
ÚJoystick button
Use it to move between options, select an option or
adjust the On-screen menu.
ÆDisplay button
Press to display information on the PDP screen.
ıStill button
Press to pause the current screen.
˜MTS button
Press to choose stereo, mono or Separate Audio
Program (SAP broadcast).
¯Dolby Virtual button
This feature allows the TV’s L/R speakers to provide a
Home Theater-like Dolby effect. The center and surround
sounds are mixed into the L/R speakers.
12
Remote Control
Flip the cover open
in the arrow direction.
Installing the Batteries in Your Remote Control
1
Slide the back cover
to open the battery
compartment of the
remote control.
3
Slide the cover back into
place.
2
Install two AAA size batteries. Make sure to match the
“+” and “-” ends of the batteries with the diagram
inside the compartment.
Remote Control Operation Range.
You can use your remote control within a distance of 23 feet and an angle of 30 degrees
from the left and right sides of the remote control receiver of the PDP.
15
Wall Installation Instructions
14
1
Remove the screws on the rear of the PDP panel.
2
Connect Insulation holders to screws. (see the illustration below)
3
Tighten the screws connected to the Insulation holders on the rear of the PDP panel.
1
Do not install the PDP in any location other than a vertical wall.
2
To protect the performance of the PDP and prevent problems, avoid the following
places.
• Do not install next to smoke and fire detectors.
• Do not install in an area subjected to vibration.
• Do not install in an area subjected to high voltage.
• Do not install near or around any heating apparatus.
3
Use only recommended parts and components.
Screws
(4 EA)
Insulation holders
(4 EA)
Installation Notes
Parts (Wall attachment panel is sold separately. Check with your dealer)
Fixing the PDP panel to the wall attachment panel bracket
Removing four screws
Connecting four screws
Wall attachment panel
1716
4
Put the 4 pegs on the PDP in the grooves of the wall mount bracket and pull down on
the PDP (Œ) to secure it to the wall mount bracket. (´) Tighten the screws as shown
(ˇ) so that the PDP cannot be separated from wall mount bracket.
How to Adjust Mounting Angle
Notice
Notice : Please secure the mounting bracket on the wall surface after setting its angle at 0°
Factory default
PDP panel
Wall attachment
panel bracket
Wall
The wall mount bracket is delivered separately.
Please tighten the captive screw in the direction
of the arrow after assembling the bracket.
1
Secure the PDP to the wall mount
bracket.(Please refer to the following
instructions.)
2
Set the angle by pulling the upper end of
the PDP attached to bracket in the direction
of the arrow.
3
The angle can be adjusted from 0° to 20°
by ±2°.
Changeing the angle
1.Contact an authorized technician when installing the wall attachment panel.
2.After hanging the PDP panel on the wall attachment panel, make sure that
the Insulation holders are completely hung.
3.Be careful so that fingers are not caught.
4.Make sure the wall attachment panel brackets are tightened.
Otherwise, the PDP panel may fall down and you might be hurt.
PLASMA DISPLAY PANEL
Connections
Connecting VHF and UHF Antennas ..............................................20
Connecting Cable TV....................................................................21
Connecting Speakers....................................................................23
Connecting a VCR........................................................................24
Connecting a Camcorder ..............................................................25
Connecting a DVD Player..............................................................26
Connecting a DTV Receiver ..........................................................27
21
Connecting VHF and UHF Antennas
20
Antennas with 75-ohm Round Leads
If your antenna looks like this: it has 75-ohm round leads.
1
Plug the antenna lead into the VHF/UHF terminal on the PDP.
Use the Antenna Cable, an accessory included
in the product package.
Connecting Cable TV
You can connect different cable systems to your PDP, including cable without a cable box,
and cable with a cable box that descrambles some or all channels.
Cable without a Cable Box
1
Plug the incoming cable into the VHF/UHF terminal on the PDP.
Use the Antenna Cable, an accessory included
in the product package.
Cable with a Cable Box that Descrambles All Channels.
1
Find the cable connected to the ANTENNA OUT terminal on your cable box. This terminal
might be labeled "ANT OUT", "VHF OUT", or simply "OUT".
2
Connect the cable to the VHF/UHF terminal on the PDP.
Use the Antenna Cable, an accessory included
in the product package.
22
Cable with a Cable Box that Descrambles Some (But Not All) Channels
To complete this connection you will need a two-way splitter, a RF (A/B) switch, and four coaxial
cables (which you can buy from your AKAI dealer or any electronics store).
1
Find and disconnect the cable that is connected to the ANTENNA IN terminal of
your cable box.
This terminal might be labeled "ANT IN",
"VHF IN", or simply, "IN". Connect this
cable to a two-way splitter.
2
Connect a coaxial cable between an OUTPUT terminal of the splitter and the IN terminal of the cable box.
3
Connect a coaxial cable between the
ANTENNA OUT terminal of the cable box
and the B-IN terminal of the A/B switch.
4
Connect a coaxial cable between the
ANTENNA OUT terminal of the cable box
and the B-IN terminal of the A/B switch.
5
Connect the last coaxial cable between the
OUT terminal of the RF (A/B) switch and
the VHF/UHF terminal on the PDP.
After you've made this connection, set the A/B switch to the "A" position for normal viewing.
Set the A/B switch to the "B" position to view scrambled channels. (When you set the A/B switch
to "B", you will need to tune your Set-Top Box to the cable box's output channel, which is usually
channel 3 or 4.)
23
Connecting Speakers
External speakers are sold seperately. Check with your dealer.
Speaker Audio Cable
Connect the speaker audio cable to the external speaker output jack on the PDP matching the
“+” and “-” ends of the cable with the diagram on the PDP.
How to Connect
Fix the bracket onto the guide pole located on the rear of speaker and fasten the screws.
After removing the three screws on the PDP, clamp the speaker and the PDP together and
fasten the screws.
Connecting PDP and Speakers
1
2
✱ External speakers MUST have a power handling
capability of 10 watts minimum (impedance 8 ohm).
Speaker Audio Cable
Powered Subwoofer
(Option)
Please use the speaker-built in amplified audio.
Guide
pole
Guide
pole
25
Connecting a Camcorder
24
Connecting a VCR to the Video or S-Video/Audio jack
S-Video Cable
Audio Cable
Video Cable
Power Plug
Connect the Video/Audio cables between the AUDIO(L/R)/VIDEO jacks on the PDP and
AUDIO/VIDEO OUT jacks on the VCR. (Note: For better video, you can use an S-Video cable.)
Videotape Playback:
1. Turn on your PDP, and press the SOURCE button on the remote control.
2. Move the joystick up or down to select “Video” or “S-Video”, then press the joystick to enter.
3. Turn on your VCR, insert a videotape and press the play button.
How to Connect
The ferrite cores are used to attenuate undesired signals. When connecting the audio cable (PC,
DVI, S-Video, Video) , attach one of these ferrite cores to the cable near the connector.
When you connect the audio cable (PC, DVI, S-Video, Video) to the
connectors, bind the ferrite core around the cable to secure it.
Ferrite Cores
Connecting a VCR
Audio Cable
Video Cable
Power Plug
Connect a Video/Audio cable between the AUDIO(L/R)/VIDEO jacks on the PDP and the
VIDEO/AUDIO OUTPUT jacks on the camcorder.
Viewing Tapes
1. Turn on your PDP, and press the SOURCE button on the remote control.
2. Move the joystick up or down to select the “Video”, then press the joystick to enter.
3. Turn on your camcorder and set it to Video Mode. (For details, refer to your camcorder
owner's instructions.)
4. Set the IN/OUT switch on your camcorder to OUT.
5. Insert the tape into the camcorder and press the Play button.
How to Connect
Viewing camcorder tapes
PDP VCR
PDP
Camcorder
Ferrite Cores
Ferrite Cores
27
Connecting a DVD Player (480i, 480p)
This PDP displays the optimum picture in 720p mode.
26
Playing DVD
Audio Cable
Video Cable
Power Plug
Connect a Video Cable between the Y, Pb, Pr (COMPONENT1, 2) input jacks on the PDP
and Y/PB/PRoutput jacks on the DVD players.
Connect a Audio Cable between the AUDIO L/R(COMPONENT1, 2) input jacks on the PDP
and the AUDIO OUT jacks on the DVD player.
To Play DVD:
1. Turn on your PDP, and press the SOURCE button on the remote control.
2. Move the joystick up or down to select the “COMPONENT1” or “COMPONENT2”,
then press the joystick to enter.
3. Turn on your DVD player, insert a DVD disc and press the Play button.
• For an explanation of Component video, see your DVD owner’s instructions.
How to Connect
1
2
PDP DVD Player
Watching DTV
Video Cable
Audio Cable
DVI Cable
or
Power
Plug
Connect the cable or antenna to the antenna input jack on the DTV.
Connect a Video cable between the Y, Pb, Pr (COMPONENT 1, 2) or DVI jack on the PDP
and the Y, PB, PR(VIDEO OUTPUT JACKS) on the DTV receiver.
Connect an Audio cable between the COMPONENT 1, 2 (L/R AUDIO) or DVI jacks on the
PDP and the AUDIO OUTPUT jacks on the DTV.
To Watch DTV:
1. Turn on your PDP, and press the SOURCE button on the remote control.
2. Move the joystick up or down to select the “COMPONENT1 ”, “COMPONENT2” or
“DVI”, then press the joystick to enter.
3. Turn on your DTV receiver.
• For an explanation of Component video, see your DTV receiver owner’s instructions.
How to Connect
1
2
3
Connecting a DTV Receiver(480p, 720p, 1080i)
This PDP displays the optimum picture in 720p mode.
Use the DVI-D connection cable. (sold separately)
PDP
DTV Receiver
Ferrite Cores
PLASMA DISPLAY PANEL
Operation
Turning the PDP On and Off..........................................................30
Memorizing the Channels..............................................................32
Setting Up Your Remote Control ....................................................36
Turning the PDP On and Off
30 31
T urning the PDP On and Off
Press the Power button on the remote control.
The PDP will be turned on and you will be ready to use it’s
features.
You can also use the Power button on the front of the
PDP.
Notes:
• If your PDP isn’t turned on when the power button is
pressed: Press the MODE button to check if the TV mode
has been chosen ( ).
Viewing the Menus and Displays
Your PDP has a simple, easy-to-use menu system that appears on the PDP screen. This system makes it convenient and fast to use features on the PDP. Your PDP also lets you display the status of many of your PDP’s
features.
Viewing the Menus
1
With the power on, press the Menu button on the
remote control. The main menu appears on the screen.
The Picture menu is selected.
2
Use the joystick (up, down) button to move items in the
menu. Use the joystick (left, right) button to display,
change, or use the selected items.
Use the joystick ( ) button to enter items in the menu.
On screen menus disappear from the screen
automatically after about thirty seconds, or you can
press the Menu button on your remote control to exit the
menu.
Displaying Status Information
Press the Display button on the remote control. The PDP will
display the Picture mode, Sound mode, MTS, Signal and
Caption.
Mode
Adjust
Color Tone
Custom
Normal
Ant 6
Picture : Custom
Sound : Custom
MTS : Mono
Signal : Mono
Caption : Off
Move Enter Menu
Memorizing the Channels
Your PDP can memorize and store all of the available channels for both “off-air” (antenna)
and cable channels. After the available channels are memorized, use the CH and CH
buttons to scan through the channels. This eliminates the need to change channels by entering
the channel digits. There are three steps for memorizing channels: selecting a broadcast
source, memorizing the channels (automatic) and adding and deleting channels (manual).
32 33
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must specify the type of
signal source that is connected to the PDP (i.e., an antenna or a cable system).
1
Press the Menu button. Move the joystick up or
down to select “Channel”, then press the joystick
to enter.
2
Move the joystick left or right to select “Ant”,
“STD”, “HRC” or “IRC”.
•If you are connected to an antenna, leave "Ant"
displayed. If you connected cable, move the
joystick left or right to the display the type of cable
system: "STD", "HRC", or "IRC".
(If you are not sure which type of cable system you
have, contact your cable company).
3
Press the Menu button to exit.
Note
• STD, HRC and IRC identify various types of cable TV systems. Contact your local cable company
to identify the type of cable system that exists in your particular area.
At this point the signal source has been selected. Proceed to “Storing Channels in Memory”
(next page).
Storing Channels in Memory (Automatic Method)
1
First, select the correct signal source (Ant, STD, HRC,
IRC). See steps on previous page.
Press the Menu button. Move the joystick up or down to
select “Channel”, then press the joystick to enter.
2
Move the joystick up or down to select “Auto Program”,
then press the joystick to enter.
3
The PDP will begin memorizing all of the available
channels.
After all the available channels are stored, the
Auto program menu reappears. Move the joystick right
to exit.
Note
• The PDP automatically cycles through all of the available channels and stores them in memory.
This takes about one to two minutes.
Quick way to access the Automatic Channel Setting : Just
press the “Auto Program”button on the remote control.
!
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Channel
Ant
0
Off
Channel
STD
0
Off
Move Select Menu
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Enter Menu
Channel
Ant
0
Off
Channel
Ant
0
Off
Ant 50
Auto Program
: Stop
34 35
Adding and Erasing Channels (Manual Method)
1
Use the number buttons to directly select the channel that
will be added or erased.
Ex) Channel “4”
2
Press the Add/Erase button:
Repeatedly pressing this button will alternate between
“Added” and “Erased.”
Note
• You can view any channel (including an erased channel) by using the number buttons on the remote
control.
To View Memorized Channel (PIP Mode)
1
Press the Menu button. Move the joystick up or
down to select “Channel”, then press the joystick
to enter.
2
Move the joystick up or down to select “Ch. Scan”,
then press the joystick to enter.
Only the memorized channels are chosen.
Move the joystick right to stop.
Ant 4
Ant 4
Added
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Enter Menu
Ch. Scan
Ant 7
: Stop
Channel
Ant
0
Off
Channel
Ant
0
Off
36 37
Setting Up Your Remote Control
This PDP's remote control can operate almost any VCR, cable box, or DVD. After it has been set up
properly, your remote control can operate in four different modes :TV, VCR, Cable, or DVD.
Pressing the corresponding button on the remote control allows you to switch between these modes,
and control whichever piece of equipment you choose.
Note:The remote control may not be compatible with all DVD Players, VCRs, and Cable boxes.
Setting Up the Remote to Operate Your VCR, Cable box, or DVD player
1
Turn off your VCR. (or Cable box, DVD player.)
2
Press the MODE button and make sure that the VCR
(or Cable box, DVD) LED is illuminated.
3
Press the Set button on your TV's remote control.
4
Using the number buttons on your remote control,
enter three digits of the VCR (or Cable box, DVD)
code listed on page 37 of this manual for your
brand of VCR (or Cable box, DVD player). Make
sure you enter three digits of the code, even if the
first digit is a "0".
(If more than one code is listed, try the first one.)
5
Press the Power button on the remote control.
Your VCR (or Cable box, DVD player) should turn
on if your remote is set up correctly. If your VCR (or
Cable box, DVD player) does not turn on after set
up, repeat steps 2, 3, and 4, but try one of the other
codes listed for your brand of VCR (or Cable box,
DVD player).
If no other codes are listed, try each code, 000
through 089 (or Cable box: 000 through 077,
DVD player: 000 through 008).
Notes
• When your remote control is in “VCR” mode, the VCR control buttons (Stop, REW,
Play/Pause, FF) still operate your VCR.
• When your remote control is in “Cable box” or “DVD” mode, the VCR control buttons
(Stop, REW, Play/Pause, FF) still operate your VCR.
Changing Channels
Using the Channel Buttons
Press the CH or CH buttons to change channels.
When you press the CH or CH buttons, the PDP changes channels in sequence. You will see all the
channels that the PDP has memorized. (The PDP must have memorized at least three channels.)
You will not see channels that were either erased or not memorized.
To View Memorized Channel
Press the CH.Scan button or the Channel button. Only the memorized channels are chosen.
Directly Accessing Channels
Press the number buttons to go directly to a channel. For example, to select channel 27, press “2” then “7”.
The TV will change channels when you press the second number.
When you use the number buttons, you can directly select channels that were either erased or not memorized. To
change to single-digit channels (0~9) faster, press “0” before the single digit. (For channel “4” press “0” then “4”.
Using the Pre-CH button to select the previous channel
Press the Pre-CH button. The TV will switch to the fast channel viewed.
To quickly switch between two channels that are far apart, tune to one channel, then use the number button
to select the second channel. Then, use the Pre-CH button to quickly alternate between them.
Adjusting the Volume
Using the Volume Buttons
Press the VOL + or VOL – buttons to increase or decrease the volume.
Using Mute
Using the Mute Buttons
At any time, you can temporarily cut off the sound using the Mute button.
1
Press the Mute button and the sound cuts off.
The word “Mute” will appear in the lower-left
corner of the screen.
2
To turn mute off, press the Mute button again, or
simply press the VOL + or VOL – button.
Mute
PLASMA DISPLAY PANEL
Picture Control
Customizing the Picture ................................................................40
Using Automatic Picture Settings ....................................................41
Selecting the Color Tone................................................................42
Viewing the Picture-in-Picture..........................................................43
Changing the Screen Size ............................................................49
Freezing the Picture ......................................................................50
Remote Control Codes
VCR Codes
Cable Box Codes
DVD Codes
Customizing the Picture
You can use the on-screen menus to change the Contrast, Brightness, Sharpness, Color,
and Tint settings of your PDP.
41
1
Press the Menu button, then press the joystick to
enter.
2
Move the joystick left or right to select “Custom”,
“Dynamic”, “Standard” or “Movie” picture setting.
• You can select “High”, “Middle”, “Low” or
“Custom” in PC/DVI mode.
3
Press the Menu button to exit.
Using Automatic Picture Settings
Your PDP has automatic picture settings that allow you to adjust the video display easily.
40
1
Press the Menu button, then press the joystick to
enter.
2
Move the joystick up or down to select “Adjust”,
then press the joystick to enter.
You will also see the items “Contrast”, “Brightness”,
“Sharpness”, “Color” and “Tint”.
3
Move the joystick up or down to select the item you
wish to change.
4
Move the joystick left or right to change the value of
the item.
5
Press the Menu button to exit.
Note
• In the PC/DVI mode, you can’t adjust the Sharpness, Color and Tint.
• The Tint cannot be adjusted in Component(480p, 720p, 1080i) mode.
Quick way to access the picture setting:
Just
press the “P.Mode” button on the remote control.
!
Mode
Adjust
Color Tone
Move Select Menu
Mode
Adjust
Color Tone
Move Enter Menu
Contrast
Brightness
Sharpness
Color
Tint R 50 G 50
Move Adjust Menu
Custom
Custom
Custom
Normal
Adjust
80
50
50
50
Mode
Adjust
Color Tone
Move Select Menu
Mode
Adjust
Color Tone
Move Select Menu
Custom
Custom
Dynamic
Custom
82Contrast
4342
Selecting the Color Tone
1
Press the Menu button, then press the joystick to
enter.
2
Move the joystick up or down to select “Color
Tone”, then move the joystick left or right to select
“Normal”, “Warm1”, “Warm2”, “Cool2” or
“Cool1”.
• You can select “Custom”, “Color1”, “Color2” or
“Color3” in PC mode.
• You can select “Color1”, “Color2” or “Color3” in
DVI mode.
3
Press the Menu button to exit.
.
Viewing the Picture-in-Picture
Selecting the PIPScreen
1
Press the Menu button. Move the joystick up or
down to select “PIP”, then press the joystick to
enter.
2
Move the joystick left or right to select “On”.
The PIP image will appear in the corner of the
screen.
3
Press the Menu button to exit.
PIP Settings
Quick way to access the PIP: Just press the
“PIP” button on the remote control.
!
PIP screen
Main screen
TV Video S-Video Component 1 Component 2 PC DVI
TV
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
X
X
X
X
O
O
O
X
X
X
X
O
O
O
X
X
X
X
O
O
O
X
X
X
X
Video
S-Video
Component 1
Component 2
PC
DVI
O:
PIP and Swap Operate
X:
PIP doesn’t Operate
Mode
Adjust
Color Tone
Move Select Menu
Mode
Adjust
Color Tone
Move Select Menu
Custom
Custom
Custom
Normal
Select
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
Off
Select Menu
PIP
On
TV
Large
Ant
Ant 5
4544
Selecting an External Signal
You can use PIP to view a signal from an external source, such as a VCR.
1
Press the Menu button. Move the joystick up or
down to select “PIP”, then press the joystick to
enter.
2
Move the joystick up or down to select “Source”.
3
Move the joystick left or right to cycle through
all of the available signal sources:
“TV”, “Video”, “S-Video”, “Component 1”,
“Component 2”, “PC” and “DVI”.
The signal from these inputs will not appear if you
have not connected any equipment to the PDP’s
respective input.
4
Press the Menu button to exit.
Note
• The PIP function operates in Wide screen.
• Using Multi-Screen in the Normal, Zoom1 or Zoom2 screen will change the size of the main screen
to Wide screen.
Quick way to access the PIP source:
Just press
“Source” button in the cover on the remote control.
!
Swapping the Contents of the PIP Image and Main Image
1
Press the Menu button. Move the joystick up or
down to select “PIP”, then press the joystick to
enter.
2
Move the joystick up or down to select “Swap”,
then press the joystick to enter.
• The image in the PIP window will appear on the
main screen, and vice versa.
3
Press the Menu button to exit.
Selecting the Sound Source
S.Swap
Press the S.Swap button to switch between the Main or Sub
(PIP) audio source.
Quick way to access swapping: Just press the
“Swap” button on the remote control.
!
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
Video
Large
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Enter Menu
PIP
On
TV
Large
Ant
Ant 5
46 47
Changing the Size of the PIP Window
1
Press the Menu button. Move the joystick up or
down to select “PIP”, then press the joystick to
enter.
2
Move the joystick up or down to select “Size”.
3
Move the joystick left or right to select “Small”,
“Double” or “Large”.
4
Press the Menu button to exit.
Quick way to access the PIP size:
Just press the
“Size” button in the cover on the remote control.
!
Changing the Location of the PIP Image
1
Press the Menu button. Move the joystick up or
down to select “PIP”, then press the joystick to
enter.
2
Move the joystick up or down to select “Locate”.
3
Move the joystick left or right to move the PIP screen
where you want.
4
Press the Menu button to exit.
Quick way to access the PIP location: Just press
the “Locate” button on the remote control.
!
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Small
Ant
Ant 5
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
Ant
Ant 5
49
Changing the Screen Size
48
WWide
ide
Sets the picture to 16:9 wide mode.
Panorama
Converts regular 4:3 aspect ratio screen to
wide screen.
Zoom1
The screen size when Wide screen is vertically
enlarged.
Zoom2
The screen size when the Zoom1 screen is
vertically enlarged.
Normal (4:3)
Sets the picture to 4:3 normal mode.
Notes
• In TV, VIDEO, S-VIDEO and Component(480i) modes, all screen modes can be selected.
(Wide ➝ Panorama ➝ Zoom1 ➝ Zoom2 ➝ Normal).
• In PC/DVI mode, only Wide & Normal modes can be selected.
• In Component(480p, 720p. 1080i) modes, Panorama mode can’t be selected.
• In Component(480p, 720p. 1080i) modes, you can move the picture on screen by pressing
the Up▲ or Down▼ button. (All screen modes)
• Changing the screen size to Normal, Zoom1 or Zoom2 during PIP mode will cause the PIP
window to disappear.
When you press the Aspect button on the remote control, the PDP’s screen mode should appear in
sequence. The screen displays in this order: Wide, Panorama, Zoom1, Zoom2, Normal.
Note
• If you watch a still image or the Normal (4:3) mode for a long time (over 2 hours), an image may
be burned onto the screen. View the monitor in Wide or Panorama mode as much as possible.
Changing the PIP Channel
1
Press the Menu button. Move the joystick up or
down to select “PIP”, then press the joystick to
enter.
2
Move the joystick up or down to select “Ant/CATV”.
Move the joystick left or right to select “Ant”, “STD”,
“HRD” or “IRC”.
3
Move the joystick up or down to select “Channel”.
Move the joystick left or right to change the channel
that appears in the PIP window. You can also press
PIP CH▲, ▼ buttons on the remote control.
4
Press the Menu button to exit.
Wide
Panorama
Normal
Zoom1
Up/Down
Zoom2
Up/Down
Quick way to change the PIP channel: Just press the
“CH▲,▼” buttons under the cover of the remote control.
!
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
Select
Source
Swap
Size
Locate
Ant/CATV
Channel
Move Select Menu
PIP
On
TV
Large
Ant
Ant 5
PIP
On
TV
Large
STD
STD 5
PIP
On
TV
Large
STD
STD 9
50
PLASMA DISPLAY PANEL
Sound Control
Customizing the Sound ................................................................52
Using Automatic Sound Settings ....................................................53
Choosing a Multi-Channel Sound (MTS)Soundtrack ..........................54
Using the Auto Volume..................................................................55
Using Dolby Virtual ......................................................................56
Using a Subwoofer ......................................................................57
Freezing the Picture
Still
Press the Still button on the remote control to freeze a
moving picture. Press again to cancel.
53
Customizing the Sound
52
1
Press the Menu button. Move the joystick up or
down to select “Sound”, then press the joystick
to enter.
2
Move the joystick left or right to select “Custom”,
“Standard”, “Music”, “Movie” or “Speech” sound
setting.
3
Press the Menu button to exit.
Using Automatic Sound Settings
1
Press the Menu button. Move the joystick up or
down to select “Sound”, then press the joystick
to enter.
2
Move the joystick up or down to select “Adjust”,
then press the joystick to enter.
You will also see the items “Bass”, “Treble” and
“Balance”.
3
Move the joystick up or down to select the item you
wish to change.
4
Move the joystick left or right to change the value of
the item.
5
Press the Menu button to exit.
Quick way to access the sound setting:
Just
press the “S.Mode” button on the remote control.
!
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Enter Menu
Bass
Treble
Balance
Move Adjust Menu
Sound
Custom
Mono
Off
Off
Sound
Custom
Mono
Off
Off
Adjust
L 50
R 50
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Sound
Music
Off
Off
Off
Off
50
50
82Bass
55
Choosing a Multi-Channel Sound (MTS)
Soundtrack
Depending on the particular program being broadcast, you can listen to stereo, mono,
or a Separate Audio Program. (SAP audio is usually a foreign-language translation.
Sometimes SAP has unrelated information like news or weather.)
54
1
Press the Menu button. Move the joystick up or
down to select “Sound”, then press the joystick
to enter.
2
Move the joystick up or down to select “MTS”.
3
Move the joystick left or right to select “Mono”,
“Stereo” or “SAP”.
4
Press the Menu button to exit.
Quick way to access the MTS menu: Just press
the “MTS” button on the remote control.
!
Using the Auto Volume
Each broadcasting station has its own signal conditions, which can make it necessary to
adjust the volume every time the channel is changed. “Auto volume” lets you automatically
adjust the volume of the desired channel by lowering the sound output when the modulation signal is high or by raising the sound output when the modulation signal is low.
1
Press the Menu button. Move the joystick up or
down to select “Sound”, then press the joystick
to enter.
2
Move the joystick up or down to select “Auto
Volume”.
3
Move the joystick right to select “On”.
4
Press the Menu button to exit.
• Choose
Stereo
Stereo for channels that are broadcasting in stereo.
• Choose
Mono
Mono for channels that are broadcasting in mono, or if you are having difficulty receiving
a stereo signal.
• Choose
SAP
SAP to listen to the Separate Audio Program, which is usually a foreign-language translation.
Note
• The MTS function operates in TV mode only.
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Sound
Standard
Stereo
Off
Off
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Sound
Standard
Mono
On
Off
Using Dolby Virtual
This feature allows the PDP’s optional L/R speakers to provide a Home Theater-like Dolby
effect. The center and surround sounds are mixed into the L/R speakers.
Using a Subwoofer
56 57
1
Press the Menu button. Move the joystick up or
down to select “Sound”, then press the joystick
to enter.
2
Move the joystick up or down to select “Woofer”,
then press the joystick to enter.
3
Move the joystick left or right to select “On”.
4
Move the joystick up or down to select “Volume”,
then move the joystick left or right to adjust the
value of the item.
This sets the volume for the subwoofer.
5
Move the joystick up or down to select “Cutoff
Freq.”, then move the joystick left or right to adjust
the value of the item.
This sets the cutoff frequency for the subwoofer.
For example, if you set the cutoff frequency at
130Hz, the subwoofer will reproduce frequencies
of 130Hz and lower.
6
Press the Menu button to exit.
1
Press the Menu button. Move the joystick up or
down to select “Sound”, then press the joystick
to enter.
2
Move the joystick up or down to select “
Dolby
Virtual
”.
3
Move the joystick left or right to select “On”.
4
Press the Menu button to exit.
Quick way to access the Dolby Virtual: Just press
the “Dolby Virtual” button on the remote control.
!
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Sound
Standard
Mono
Off
On
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Select Menu
Mode
Adjust
MTS
Auto Volume
Dolby Virtual
Woofer
Move Enter Menu
Woofer
Volume
Cutoff Freq.
Move Select Menu
Woofer
Volume
Cutoff Freq.
Move Adjust Menu
Sound
Custom
Mono
Off
Off
Sound
Standard
Mono
Off
Off
Woofer
On
120Hz
Woofer
On
120Hz
50
50
65Volume
Woofer
Volume
Cutoff Freq.
Woofer
On
130Hz
50
Move Adjust Menu
PLASMA DISPLAY PANEL
Channel Control
Fine Tuning Channels....................................................................60
LNA (Low Noise Amplifier)............................................................61
61
Fine Tuning Channels
Use fine tuning to manually adjust a particular channel for optimal reception.
60
1
Press the Menu button. Move the joystick up or
down to select “Channel”, then press the joystick to
enter.
2
Move the joystick up or down to select “Fine Tune”.
3
Move the joystick left or right to adjust the fine
tuning.
4
To store the fine tuning setting in the TV’s memory,
move the joystick up. (A star icon<*>will appear.)
To reset the fine tuning to “0”, move the joystick
down.
5
Press the Menu button to exit.
LNA (Low Noise Amplifier)
If the TV is operating in a weak-signal area, sometimes the LNA function can improve
the reception (a low-noise preamplifier boosts the incoming signal).
1
Press the Menu button. Move the joystick up or
down to select “Channel”, then press the joystick to
enter.
2
Move the joystick up or down to select “LNA”.
3
Move the joystick left or right to select LNA “On.”
• Moving the joystick left or right will alternate
between “On” and “Off.”
4
Press the Menu button to exit.
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Adjust Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Add/Erase Adjust Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Channel
Ant
0
Off
Channel
Ant
0
Off
Channel
Ant
+3
Off
Channel
Ant
+3
Off
Ant/ CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Ant / CATV
Auto Program
Fine Tune
LNA
Ch. Scan
Move Select Menu
Channel
Ant
0
Off
Channel
Ant
0
Off
Channel
Ant
0
On
Add/Erase Adjust Menu
PLASMA DISPLAY PANEL
Connecting a PC and Operation
Connecting to a PC......................................................................64
Adjusting the PC Screen................................................................68
Changing the Position of the Image................................................69
Changing the Size of the Image ....................................................70
Information..................................................................................71
Picture Quality Adjustment ............................................................72
65
Connecting to a PC
Connection to a Macintosh PC may require an adaptor that fits the PC terminal.
64
Connect a PC (15pin) cable between the Video Output jack(or DVI jack) on the PC and the
RGB IN(or DVI IN) Input jack (15p D-SUB) on the PDP.
Connect a Audio cable between the Audio (RGB or DVI) on the PC and the Audio L/R (RGB
or DVI) input jacks on the PDP.
To watch the PC screen:
1. Turn on your PDP, and press the Source button on the remote control.
2. Move the joystick up or down to select “PC”, then press the joystick to enter.
3. Turn on PC and check for PC system requirements. (Refer to pages 66 and 67
for PC system requirements.)
3. Adjust the PC screen. (Refer to pages 68 and 74.)
Connecting a PC to the PDP
Audio CablePC CableDVI Cable
Power Plug
1
2
Pin Configuration
D-Sub Cable
DVI-D Cable (Digital-Only Connector)
• 15Pin Signal Cable (based on protruded pin)
Setting up Your PDP (Plug and Play)
Our adoption of the new VESAPlug and Play solution eliminates complicated and time consuming
setup. It allows you to install your monitor in a Plug and Play compatible system, without the usual
setup hassles and confusion. Your PC system can easily identify and configure itself for use with your
display. This monitor automatically tells the PC system its Extended Display Identification data (EDID)
using Display Data Channel (DDC) protocols.
DVI jack
(The actual configuration on your PC
may be different,
depending on the
model.)
PDP
PC
or
Use the DVI-D
connection cable.
(sold separately)
Ferrite Cores
6766
How to Set up Your PC Software (Windows only)
The Windows display-settings for a typical computer are shown below. However, the actual screens
on your PC will probably be different, depending upon your particular version of Windows and your
particular video card. But even if your actual screens look different, the same, basic set-up information
will apply in almost all cases. (If not, contact your computer manufacturer or AKAI Dealer.)
On the windows screen, select in the following
sequence : Start ➝ Settings ➝ Control Panel.
When the control panel screen appears, click on
“Display” and a display dialog-box will appear.
Select the “Settings” tab in the display dialogbox.
The two key variables that apply to the PDP-PC
interface are “resolution” and “colors”.
The correct settings for these two variables are:
• Size (sometimes called “resolution”):
640 x 480 pixels.
• Color: “24-bit” color (might also be expressed as “16 million colors”)Shown at left is
a typical screen for “Display” dialog box.
If a vertical-frequency option exists on your
display settings dialog box, the correct value is
“60” or “60 Hz.” Otherwise, just click “OK”
and exit the dialog box.
Continued...
Notes:
Both screen position and size will vary, depending on the type of PC monitor and its resolution.
The table below shows all of the display modes that are supported:
• The interlace mode is not supported.
• The PDP operates abnormally if a non-standard video format is selected.
Notes:
• When this PDP is used as a PC display, 32-bit color is supported.
• Depending on the manufacturer, your PC display screen might appear different.
(and depending on your particular version of Windows).
Check your PC instruction book for information about connecting your PC to a PDP.
• If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5kHZ
(horizontal).
• In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power
is turned off (or if the PC is disconnected). If so, press the Source button to enter the VIDEO mode.
Also, make sure that the PC is connected.
• Connect only a PC monitor to the monitor output port while viewing the PC screen. (Otherwise,
random signals might appear).
Video signal Dot X Line
640 X 350
640 X 400
720 X 400
640 X 480
IBM PC / AT
Compatible
800 X 600
1024 X 768
Vertical
Frequency (Hz)
70.086
85.080
85.080
70.087
85.039
59.940
72.809
75.000
85.008
56.250
60.317
72.188
75.000
85.061
60.004
70.069
75.029
84.997
Horizontal
Frequency (KHz)
31.469
37.861
37.861
31.469
37.927
31.469
37.861
37.500
43.269
35.156
37.879
48.077
46.875
53.674
48.363
56.476
60.023
68.677
Vertical
polarity
N
N
P
P
P
N
N
N
N
N/P
P
P
P
P
N
N
P
P
Horizontal
polarity
P
P
N
N
N
N
N
N
N
N/P
P
P
P
P
N
N
P
P
69
Adjusting the PC Screen
68
Adjusting the R.G.B
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button, then press the joystick to
enter.
2
Move the joystick up or down to select “Color
Tone”, then move the joystick left or right to select
“Custom”. When “Custom” is selected, the word
“Color Adjust” will appear on the screen.
3
Move the joystick up or down to select “Color
Adjust”, then press the joystick to enter.
4
Move the joystick up or down to select the item you
want to change, then move the joystick right or left
to change the value of the item, using the on-screen
gauge as your guide.
5
Press the Menu button to exit.
Changing the Position of the Image
After connecting the PDP to your PC, adjust the position of the screen if it is not well-aligned.
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button. Move the joystick up or
down to select “PC”, then press the joystick to enter.
2
Press the joystick to enter, then adjust the screen
position by using the joystick button.
3
Press the Menu button to exit.
Mode
Adjust
Color Tone
Color Adjust
Move Select Menu
Mode
Adjust
Color Tone
Color Adjust
Move Select Menu
Mode
Adjust
Color Tone
Color Adjust
Move Enter Menu
Custom
Custom
Custom
Custom
Custom
Custom
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Move Move Menu
PC
Wide
Position
Red
Green
Blue
Move Adjust Menu
Adjust
50
50
50
82Red
71
Changing the Size of the Image
70
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button. Move the joystick up or
down to select “PC”, then press the joystick to enter.
2
Move the joystick up or down to select “Scaling”.
3
Move the joystick left or right to select “Wide”
or “Normal”.
4
Press the Menu button to exit.
Information
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button. Move the joystick up or
down to select “PC”, then press the joystick to enter.
2
Move the joystick up or down to select “Informa-
tion”, then press the joystick to enter.
The vertical, horizontal frequencies and resolution
appear.
3
Press the Menu button to exit.
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Select Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Select Menu
PC
Wide
PC
Wide
PC
Normal
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Resolution : 1024 * 768
H-Frequency : 48.52 KHz
V-Frequency : 60.36 Hz
PC
Wide
PC
Wide
Information
Menu
73
Coarse Adjustment
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button, move the joystick up or
down to select “PC”, then press the joystick to enter.
2
Move the joystick up or down to select “Adjust”,
then move the joystick left or right to enter.
3
Move the joystick up or down to select “Coarse”.
Remove picture noise (vertical stripes) on the screen
by moving the joystick left or right. (If Coarse is
not set properly, vertical stripes will appear on the
screen.)
4
Move the Menu button to exit.
72
Picture Quality Adjustment
Picture Automatic Adjustment
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button. Move the joystick up or
down to select “PC”, then press the joystick to enter.
2
Move the joystick up or down to select “Auto
Adjust”, then move the joystick left or right to enter.
3
The message “Auto Adjust” appears on the screen
and the picture adjustments are automatically
activated.
4
Press the Menu button to exit.
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
PC
Wide
PC
Wide
Auto Adjust
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Corase
Fine
Move Adjust Menu
PC
Wide
PC
Wide
Adjust
50
7
53Coarse
74
PLASMA DISPLAY PANEL
Time Setting
Setting the Clock.......................................................................76
Setting the Sleep Timer...............................................................77
Setting the Timers......................................................................78
Setting the Preferred Channel and Volume Level............................80
Fine T uning (Fine)
Preset:
• Press the Source button, then move the joystick up or down to select PC. Press the joystick to select PC mode.
1
Press the Menu button. Move the joystick up or
down to select “PC”, then press the joystick to enter.
2
Move the joystick up or down to select “Adjust”,
then move the joystick left or right to enter.
3
Move the joystick up or down to select “Fine”.
Remove picture noise (vertical stripes) on the screen
by moving the joystick left or right. (If Fine is
not set properly, vertical stripes will appear on the
screen.)
4
Move the Menu button to exit.
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Position
Adjust
Scaling
Information
Auto Adjust
Move Enter Menu
Corase
Fine
Move Adjust Menu
PC
Wide
PC
Wide
Adjust
50
7
53Fine
7776
Setting the Clock
You can set your PDP to automatically turn off after a preset interval.
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Time”, then
press the joystick to enter.
3
Move the joystick up or down to select “Sleep”.
4
Move the joystick left or right to select the time inter-
val for the PDP to stay on. The interval ranges from
10 to 180 minutes.
5
Press the Menu button to exit.
Setting the Sleep Timer
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Time”, then
press the joystick to enter.
3
Move the joystick left or right to select hour, then
move the joystick up or down to select the correct
hour.
4
Move the joystick left or right to select minute, then
move the joystick up or down to select the correct
minute.
5
Press the Menu button to exit.
Note
• Time setting will be reset when you pull out the Power cord if the PDP is ON.
(If you want to keep the time setting, turn the PDP off using the Power button on the remote control
or the Front Panel.)
Function
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
English
Off
Off
Off
Function
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
English
Off
Off
Off
Quick way to access the sleep timer: Just press
the “Sleep” button on the remote control.
!
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Time
10 :
- -
- -
:
- -
- -
:
- -
Time
10 : 30 am
- -
:
- -
- -
:
- -
am
am
am
am
am
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Off
Off
Off
10
3
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Off
Off
Off
10
3
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Function
English
Function
English
Time
10 : 30 am
- -
:
- -
- -
:
- -
Time
10 : 30 am
- -
:
- -
- -
:
- -
Off
Off
Off
Off
Off
Off
am
Off
am
Off
Off
10
3
am
Off
am
Off
30
10
3
7978
Setting the Timers
This PDP can be set to turn on or off automatically at specific times that you choose. Before
using the timers, you must set the PDP’s clock, as described previously.
6
Move the joystick left or right to select “Off” or
“On”, then move the joystick up down to select
“Off” or “On”.
7
If you want to set Off Time, move the joystick down
to select the “Off Time”.
Set the “Off Time” just as you set “On Time”.
8
Press the Menu button to exit.
Note
• If you set to On Time or Off Time, the Power Indicator on the Front Panel is changed to Green.
Setting the On/Off Timer
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Time”, then
press the joystick to enter.
3
Move the joystick up or down to select “On Time”.
4
Move the joystick left or right to select hour, then
move the joystick up or down to select the correct
hour.
5
Move the joystick left or right to select minute, then
move the joystick up or down to select the correct
minute.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Move Select Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Time
10 : 30 am
- -
:
- -
- -
:
- -
Time
10 : 30 am
7 :
- -
- -
:
- -
am
am
am
am
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Time
10 : 30 am
7 : 30
- -
:
- -
Time
12 : 00 am
7 : 30
- -
:
- -
am
On
am
Off
Off
10
3
am
On
am
Off
Off
10
3
Off
Off
Off
10
3
Off
Off
Off
10
3
Clock
On Time
Off Time
Sleep
On Time Volume
On time Channel
Adjust Move Menu
Time
10 : 30 am
7 : 30
- -
:
- -
am
am
Off
Off
Off
10
3
Selecting a Menu Language .....................................................82
Viewing Closed Captions.........................................................83
Digital Noise Reduction ...........................................................84
Setting Auto Power Off ...........................................................85
Using the V-Chip.....................................................................86
Selecting the Film Mode...........................................................91
PLASMA DISPLAY PANEL
Function Description
80
Setting the Preferred Channel
and Volume Level
The preferred channel and volume can be set for when the timer automatically turns on the TV.
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Time”, then
press the joystick to enter.
3
Move the joystick up or down to select “On Time
Volume”.
Move the joystick left or right to adjust volume level.
4
Move the joystick up or down to select “On Time
Channel”.
Move the joystick left or right to select the channel.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Clock
On Time
Off Time
Sleep
On Time Volume
On Time Channel
Move Select Menu
Function
English
Function
English
Time
- -
:
- -
- -
:
- -
- -
:
- -
Time
- -
:
- -
- -
:
- -
- -
:
- -
Off
Off
Off
Off
Off
Off
am
am
am
am
am
am
Off
Off
Off
10
3
Off
Off
Off
10
3
Selecting a Menu Language
8382
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Caption”,
then press the joystick to enter.
3
Move the joystick left or right to turn closed captioning on/off.
4
Move the joystick up or down to select “Mode”, then
move the joystick left or right to select “Caption” or
“Text.”
5
Depending on the particular broadcast, it might be
necessary to make changes to “Channels” and
“Field”: Move the joystick up, down, left and right
to make the changes. (Follow the same procedure
as in steps 3~4 above.)
Press the Menu button to exit.
Note
• Different channels and fields display different information: Field 2 carries additional information
that supplements the information in Field 1. (For example, Channel 1 may have subtitles in English,
while Channel 2 has subtitles in Spanish.
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick left or right to select the appropriate language : English, Français or Español.
3
Press the Menu button to exit.
Viewing Closed Captions
Your TV decodes and displays the closed captions that are broadcast with certain
TV shows. These captions are usually subtitles for the hearing impaired or foreignlanguage translations. All VCRs record the closed caption signal from television
programs, so home-recorded video tapes also provide closed captions. Most prerecorded commercial video tapes provide closed captions as well. Check for the
closed caption symbol in your television schedule and on the tape’s packaging: .
Note: The Caption feature does not work with DVD or DTV signals.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Caption
Mode
Channel
Field
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Caption
On
Caption
2
1
Move Select Menu
Caption
Mode
Channel
Field
Move Select Menu
Caption
On
Text
2
1
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Auto Power
Off”.
3
Move the joystick left or right to select “On”.
4
Press the Menu button to exit.
Note
• If the Off timer is set, Auto Power Off will not function.
• The power will be turned off automatically after 15 minutes if the PDP is ON and there is no input
signal. (For instance, if you select a channel without a signal while in TV mode or when there is no
input signal after selecting an output signal)
8584
Digital Noise Reduction
If the broadcast signal received by your TV is weak, you can activate the Digital Noise
Reduction feature to help reduce any static and ghosting that may appear on the screen.
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “NR”.
3
Move the joystick left or right to select “On”.
4
Press the Menu button to exit.
Setting Auto Power Off
The PDP can be set to turn off automatically if no buttons are pressed for 3 hours
after the PDP turns on via the On timer.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Function
English
On
Off
Off
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Function
English
Off
Off
Off
Function
English
Off
On
Off
8786
Using the V-Chip
The V-Chip feature automatically locks out programs that are deemed inappropriate
for children. The user must enter a PIN (personal ID number) before any of the V-Chip
restrictions are set up or changed.
Note : When the V-chip feature is activated, the PIP and auto channel program features
do not function.
Setting Up Your Personal ID Number (PIN)
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “V-Chip”,
then press the joystick to enter.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
Note: The default PIN number of a new TV set is
“0-0-0-0.”
4
The “V-chip” screen will appear. Move the joystick
up or down to select “Change Pin,” then press the
joystick to enter.
5
The Change pin screen will appear. Choose any
4-digits for your PIN and enter them.
As soon as the 4 digits are entered, the “Confirm
New Pin” screen appears. Re-enter the same 4
digits. When the Confirm screen disappears, your
PIN has been memorized.
6
Press the Menu button to exit.
Note
• If you forget the PIN, press the remote-control buttons in the following sequence, which resets the pin
to 0-0-0-0 : Power Off ➔ Mute ➔ 8 ➔ 2 ➔ 4 ➔ Power On.
How to Enable/Disable the V-Chip
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “V-Chip”,
then press the joystick to enter.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
4
The “V-chip” screen will appear.
To enable the V-Chip feature, move the joystick to
the right so that the “V-Chip Lock” field is Yes.
(Move the joystick to the left or right will alternate
between Yes and No.)
5
Press the Menu button to exit.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Enter Menu
Change Pin
Confirm New Pin
Function
English
Off
Off
Off
Function
English
Off
On
Off
V-Chip
Enter Pin :
----
V-Chip
No
V-Chip
Enter New Pin :
----
V-Chip
Confirm New Pin :
-
Enter Pin :
Function
English
Off
Off
Off
Function
English
Off
On
Off
V-Chip
----
V-Chip
Yes
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Select Menu
8988
How to Set up Restrictions Using the “TV guidelines”
First, set up a personal identification number (PIN), and enable the V-Chip. (See previous section.)
Parental restrictions can be set up using either of two methods: The TV guidelines or the MPAA rating.
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “V-Chip”,
then press the joystick to enter.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
4
The “V-chip” screen will appear.
Move the joystick up or down to select “TV Guidelines”, press the joystick to enter.
5
The “TV guidelines” screen will appear. Move the
joystick up or down to select one of the six agebased categories:
TV-Y Young children
TV-Y7 Children 7 and over
TV-G General audience
TV-PG Parental guidance
TV-14 Viewers 14 and over
TV-MA Mature audience
6
At this point, one of the TV-Ratings is selected.
Move the joystick to the right: Depending on your existing setup, a letter “U” or “B” will start
blinking.
(U= Unblocked, B= Blocked)
While the “U” or ”B” is blinking, move the joystick up or down to block or unblock the
category.
Move the joystick to the right to save the TV guidelines. A TV-Rating will be selected,
and no letters will blink.
To select a different TV-Rating, move the joystick up or down and then repeat the process.
Note 1: The TV-Y7, TV-PG, TV-14 and TV-MA have additional options. See the next step to
change any of the following sub-ratings:
FV: Fantasy violence
D: Sexually Seggesive Dialog
L: Adult Language
S: Sexual situation
V: Violence
Note 2: The V-Chip will automatically block certain categories that are “more restrictive”.
For example, if you block “TV-Y” category, then TV-Y7 will automatically be blocked.
Similarly, if you block the TV-G category, then all the categories in the “young adult” group
will be blocked (TV-G, TV-PG, TV-14 and TV-MA). The sub-ratings (D, L, S, V) work together
similarly. (See next section.)
7
How to set the FV, D, L, S and V sub-ratings.
First, select one of these TV-Ratings: TV-Y7, TV-PG, TV-14 or TV-MA (See Step 4, on
previous page).
Next, while the TV-Rating is selected, repeatedly move the joystick to the right.
This will cycle through the available sub-ratings (FV,L, S, D or V).
A blinking letter (“U” or “B”) will be displayed for each sub-rating. While the “U” or “B” is
blinking, move the joystick up or down to change the sub-rating.
Move the joystick to the right to save the TV guidelines. A TV-Rating will be selected and no
letters will select. To select a different TV-Rating, move the joystick up or down and then
repeat the process.
Note: The V-chip will automatically block certain categories that are “More restrictive”.
For example, if you block “L” sub-rating in TV-PG, then the “L” sub-ratings in TV-14 and
TV-MA will automatically be blocked.
8
Press the Menu button to clear all the screens. (Or proceed to the next section, and set up
additional restrictions based on the MPAA codes).
Note
• Note: These categories consist of two separate groups: TV-Y and TV-Y7 (young children
through age 7), and TV-G through TV-MA (everybody else). The TV-Y and TV-Y7 categories
are colored blue.
The restrictions for these two groups work independently: If a household includes very young
children as well as young adults, the TV guidelines must be set up separately for each age
group. (See next step.)
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Enter Menu
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Move Select Menu
Enter Pin :
TV GuideLines
All
FVUV
U
U
U
U
U
U
Function
English
Off
Off
Off
Function
English
Off
On
Off
V-Chip
----
V-Chip
No
S
L
D
B : Blocked
U : Unblocked
U
U
U
U
U
U
U
U
U
U
U
9190
How to Set up Restrictions using the MPAA Ratings: G, PG, PG-13, R, NC-17, X
The MPAA rating system uses the Motion Picture Association of America (MPAA) system, and its main application is
for movies. When the V-Chip lock is on, the TV will automatically block any programs that are coded with objectionable ratings (either MPAA or TV-Ratings).
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “V-Chip”,
then press the joystick to enter.
3
The message "Enter Pin" will appear. Enter your
4-digit PIN number.
4
The “V-chip” screen will appear. Move the joystick down
to select “MPAA Rating,” press the joystick to enter.
5
The “MPAA rating” screen will appear. MPAA category.
Moving the joystick up or down will cycle through the
MPAA categories:
While a particular category is selected, move the joystick to the right to activate it.
A selected letter (“U” or “B”) will be displayed. Move the joystick up or down to select “U” or”B”.
Move the joystick to the right to save the settings.
Note: The V-Chip will automatically block any category that is “more restrictive.” For example,
if you block the “PG-13” category, then “R,” “NC-17,” and “X” will automatically be blocked also.
How to Reset the TV after the V-Chip Blocks a Channel (“Emergency Escape”)
If the TV is tuned to a restricted channel, the V-Chip will block it. The screen will go blank
and the following message will appear: “Excessive rating.”
To resume normal viewing, tune to a different channel using the number buttons.
Under certain conditions (depending on the rating of the local TV programs) the V-Chip might
lock out all the channels. In this case, use the V.Chip function for an “emergency escape”:
1
Press the Menu button.
2
Move the joystick up or down to select “V-Chip”, then press the joystick to enter.
3
Enter your PIN number, and move the joystick to the right to temporarily disable
the V-Chip Lock.
G General audience (no restrictions).
PG Parental guidance suggested.
PG-13 PG-13 (Parents strongly cautioned).
R
R (Restricted. Children under 17 should be accompanied by an adult).
NC-17 No children under age 17.
X X (Adults only).
NR Not rated.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Enter Menu
Function
English
Off
Off
Off
Function
English
Off
On
Off
Enter Pin
V-Chip Lock
TV GuideLines
MPAA Rating
Change Pin
Move Enter Menu
G
PG
PG-13
R
NC-17
X
NR
Move Select Menu
Enter Pin :
MPAA Rating
U
U
U
U
U
U
U
V-Chip
----
V-Chip
No
B : Blocked
U : Unblocked
92
PLASMA DISPLAY PANEL
Appendix
Troubleshooting............................................................................94
Care and Maintenance ................................................................95
Specifications ..............................................................................96
Selecting the Film Mode
1
Press the Menu button. Move the joystick up or
down to select “Function”, then press the joystick
to enter.
2
Move the joystick up or down to select “Film Mode”,
then move the joystick left or right to select “On” or
“Off”.
•On: Automatically senses and processes film
signals from all sources and adjusts the
picture for optimum quality.
•Off: Switches off the Film mode.
3
Press the Menu button to exit.
Note
• Film mode is supported in Video, S-Video, Component 480i.
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Language
Time
Caption
NR
Auto Power Off
V-Chip
Film Mode
Move Select Menu
Function
English
Off
Off
Off
Function
English
Off
Off
On
9594
Troubleshooting
Problem
Poor picture.
Your Remote control does not
operate the PDP.
The PDP won’t turn on.
There is no screen image.
The image is too light or
too dark.
The image is too large or
too small.
Before you call a service technician, please scan this list of problems and possible solutions. It may save you
time and money.
Possible Solution
Check all wire connections.
Press the “Mode” button to put your remote control in the “TV”
mode.
Check if the power plug is connected.
Check to see that both the PDP and the source are plugged in
and turned on.
Adjust the Brightness or Contrast settings.
Adjust the Size settings.
With proper care, your PDP will give you many years of service. Please follow these guidelines to get
the maximum performance from your PDP.
Identifying Problems
• Do not put the PDP near extremely hot, cold, humid or dusty places.
• Do not put the PDP near appliances that create magnetic fields.
• Keep the ventilation openings clear.
• Do not place the PDP on a rough and slanted surface, such as cloth or paper.
Liquids
• Do not place liquids near or on the PDP.
Cabinet
• Never open the cabinet or touch the parts inside.
• Wipe your PDP with a clean, dry cloth. Never use water, cleaning fluids, wax, or chemicals.
• Do not put heavy objects on top of the cabinet.
Temperature
• If your PDP is suddenly moved from a cold to a warm place, unplug the power cord for at least two
hours so that moisture that may have formed inside the unit can dry completely.
Care and Maintenance
9796
MemoSpecifications
PDP4294
1027 (W) X 79 (D) X 630.5 (H) mm ; 40.43 (W) X 3.11 (D) X 24.82(H) inches
54 (W) X 31.5 (D) X 220 (H) mm ; 2.13 (W) X 1.24 (D) X 8.66 (H) inches
31 kg ; 68.34 lbs {37.6 kg ; 82.89 lbs (with stand)}
150g (including batteries) ; 0.33lbs
100 - 240V~, 60Hz
370 Watts
852(H) x 480(V)
107 Cm/42 inches
VHF, UHF (75Ω unbalanced)
VIDEO
S-VIDEO
COMPONENT 1 - 480i / 480p / 720p / 1080i
COMPONENT 2 - 480i / 480p / 720p / 1080i
RGB : D-SUB 15P
DVI
VIDEO / S-VIDEO
COMPONENT 1
COMPONENT 2
PC (RGB)
DVI
10W + 10W (8 Ω)
Subwoofer (500mv RMS at 1KHz)
Model
Dimensions Display
Remote Control
Weight Display
Remote Control
Voltage
Power Consumption
Number of Pixels
Screen Size
ANTENNA input
VIDEO input
AUDIO input
AUDIO output
Exterior design and product specifications are subject to change without prior notice to improve
the performance of this product.
This PDP applies to Class B digital device.
(Note: Class B system is for home use.)
This PDP has been registered for residential use in terms of EMI. So it can be used in all areas as
well as residential areas.
99
Memo
98
Memo
Loading...
