Aiwa XR-FA500 User Manual
Micro Hi-Fi Component System
XR-FA500
4-247-459-21
030108AMI-H-B
WARNING
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
Do not install the appliance in a confined space, such
as a bookcase or built-in cabinet.
This appliance is classified
CLASS 1 LASER PRODUCT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
To prevent fire, do not cover the ventilation of the apparatus
with newspapers, table-cloths, curtains, etc. And don't
place lighted candles on the apparatus.
To prevent fire or shock hazard, do not place objects filled
with liquids, such as vases, on the apparatus.
as a CLASS 1 LASER
product.
This label is located on the
exterior.
Don't throw away the battery with
general house waste, dispose of it
correctly as chemical waste.
PRECAUTIONS
On operating voltage
Before operating the system, check that the operating voltage
of your system is identical with the voltage of your local power
supply.
On safety
•The unit is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet, even if
the unit itself has been turned off.
•Unplug the system from the wall outlet (mains) if it is not to
be used for an extended period of time. To disconnect the
cord (mains lead), pull it out by the plug. Never pull the
cord itself.
•Should any solid object or liquid fall into the component,
unplug the stereo system and have the component checked
by qualified personnel before operating it any further.
•The AC power cord must be changed only at a qualified
service shop.
On placement
•Place the unit in a location with adequate ventilation to
prevent heat build-up the unit.
•Do not place the unit in an inclined position.
•Do not place the unit in locations where it is;
- Extremely hot or cold
- Dusty or dirty
-Very humid
-Vibrating
- Subject to direct sunlight.
2
On heat buildup
•Although the unit heats up during operation, this is not
malfunction.
•Place the unit in a location with adequate ventilation to
prevent heat build-up in the unit.
If you continuously use this unit at a large volume, the cabinet
temperature of the top, side and bottom rises considerable.
To avoid burning yourself, do no touch the cabinet.
On operation
•If the system is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture may
condense on the lens inside the CD player. Should this occur,
the system will not operate properly. Remove the CD and
leave the system turned on for about an hour until the
moisture evaporates.
•When you move the system, take out any discs.
Notes on discs
•Discs recorded on CD-R/RW drives may not be played back
because of scratches, dirt., recording condition or the drive's
characteristics.
•CD-R/RW discs which are not finalized at the end of
recording cannot be played back.
•Do not attach adhesive label, etc. to either side of a CD-R/
RW disc, as doing so may cause malfunction.
•Do not load an unrecorded CD-R/RW disc. The disc may be
damaged.
•Discs with non-standard shapes (e.g., heart, square, star)
cannot be played on this unit. Attempting to do so may
damage the unit. Do not use such discs.
•DVD, SACD, CD-ROM, VCD, and CD with MP3 files cannot
be played on this unit.
Music discs encoded with copyright protection
technologies
This product is designed to playback discs that conform to
the Compact Disc (CD) standard. Recently, various music
discs encoded with copyright protection technologies are
marketed by some record companies. Please be aware that
among those discs, there are some that do not conform to the
CD standard and may not be playable by this product.
If you have any questions or problems concerning your stereo
system, please consult your nearest Aiwa dealer.
TABLE OF CONTENTS
PRECAUTIONS .................................... 2
PREPARATIONS ................................... 4
PARTS AND CONTROLS ......................... 5
ADJUSTMENTS BEFORE OPERATION.......... 7
CD OPERATIONS .................................. 8
TUNER OPERATIONS ........................... 10
SOUND ADJUSTMENTS ........................ 13
TAPE PLAYBACK ................................ 14
TAPE RECORDING .............................. 15
TIMER OPERATIONS ........................... 16
REFERENCE ..................................... 18
3
PREPARATIONS
Connection
Plug in the AC power cord to the AC power socket after all
other connections are made.
1
Connect the speaker cords to the speakers.
Connect the copper cords to the + terminals and the silver
cords to the - terminals.
3
Connect the supplied antennas.
Connect the FM antenna to the FM 75 Ω terminal and the
AM antenna to the AM LOOP terminal.
AM antenna
Remote commander
Detach the battery compartment lid at the rear of the remote
commander and insert two R6 (size AA) batteries with correct
polarity.
R6(AA)
2
Connect the speakers to the main unit.
Connect the right speaker to the SPEAKERS R terminals
and the left to the SPEAKERS L terminals. The copper
cords go to the ) terminals.
4
FM antenna
4
Connect the AC power cord to an AC power
socket.
The clock will appear in the display.
For setting the clock, see page 7.
Speakers
•Do not short-circuit the ) and ( speaker cord leads.
•Do not leave objects generating magnetism or objects
affected by magnetism near the speakers.
Antennas
Keep antennas away from metallic objects, electrical
equipment and cords.
•FM antenna: Extend fully and position for the best
reception. If reception is poor, connect an optional outdoor
antenna to the FM 75 Ω terminal. Note that, when connecting
an optional outdoor antenna, use an adaptor as required.
•AM antenna: Rotate to find best reception.
•Replace the batteries with new ones when the operational
distance between the remote commander and main unit
becomes shorter.
•Remove the batteries if the unit is not going to be used for
an extended period of time.
•The remote commander may not operate if it is used under
intense sunlight or if its line of sight is obstructed.
PARTS AND CONTROLS
Main unit: front
Refer to the pages indicated in parentheses for details.
1
2
3
4
1 POWER 6STANDBY/ON (7)
Switches the unit on and off (standby).
ECO (7)
Sets the ECO mode on or off.
RDS (10-12)
Activates RDS features.
2 PHONES jack
Plug in optional headphones set with a stereo mini plug
(ø3.5 mm). Speaker output is cancelled.
3 SYNCHRO REC (15)
Starts recording and CD play simultaneously.
wREC START/REC PAUSE (15)
Starts and pauses recording.
4 BASS (13)
Adjusts the bass level.
TREBLE (13)
Adjusts the treble level.
5
6
7
8
9
5 ECD (7-9)
Starts and pauses CD play.
TUNER/BAND (7, 10)
Selects tuner function and the tuner band.
dTAPE (REC MUTING) (7, 14, 15)
Starts playback and changes the playback side.
Also used to enter 4-second blank spaces during
recording.
AUX (7)
Selects the function of external equipment connected to
AUX IN jacks.
6 zOPEN/CLOSE (8)
Opens or closes the disc compartment.
7 sSTOP (8, 9, 14, 15)
CD and Tape: stops playback.
f/r-, +t/g (8, 10, 12-14, 16,
17)
CD: skips to a previous or a succeeding track when
pressed, searches a track in fast forward or reverse
playback when held down.
Tape: rewinds or fast forwards the tape.
Tuner: manually tunes up or down within the band.
8 zPUSH EJECT (14, 15)
Opens or closes the cassette holder.
9 VOLUME (13, 16)
Adjusts the volume.
Main unit: rear
Refer to the pages indicated in parentheses for details.
1
2
3
4
5
1 AM LOOP terminal and FM 75 Ω terminal
(4)
Plug in the supplied AM and FM antennas.
2 AUX IN jacks
Accept analogue sound signals from external equipment.
Connect external equipment using an optional connecting
cable with RCA phono plugs (red plug to R jack, white
plug to L jack). Refer also to the operating instructions
for your equipment.
To switch function to external input, press AUX.
To change a source name in the display of the
AUX function.
Hold down AUX and press POWER while the power is
on.
AUX VIDEO TV
3 SUB WOOFER3 jack
Connect optional powered sub woofer with a built-in
amplifier to the jack.
4 SPEAKERS3 terminals (4)
Connect the speaker cords of the supplied speakers.
5 AC power cord (4)
5
Remote commander
Refer to the pages indicated in parentheses for details.
1
2
3
4
5
6
7
Buttons with the same or similar names on the main unit
basically have the same function.
1 POWER (7)
2 1–10/0, >10 (8, 10)
CD: selects a track of the specified number.
Tuner: tunes in the station with the specified preset
number.
The numbered buttons take on these functions when pressed with
SHIFT held down
CLOCK (7)
Selects clock mode.
TIMER (16)
Selects timer mode.
TUNER MODE (13)
Switches between stereo or monaural FM reception.
:
8
9
0
!
@
#
REV MODE (14, 15)
Selects a reverse mode.
3 SHUFFLE/PROGRAM (8, 9)
Selects shuffle or programmed CD playback mode.
REPEAT (8)
Selects repeat CD playback mode.
4 PRESETN,M (10)
f/r,t/g (8, 10, 12-14, 16, 17)
ENTER (7, 10, 16, 17)
Determines the mode.
Stores the received station to preset.
5 ECD (7-9)
TUNER/BAND (7, 10)
dTAPE (7, 12)
AUX (7)
6 DISPLAY (8)
Changes the display in CD playback mode.
DIMMER (7)
Adjusts the display window brightness.
SLEEP (16)
Selects sleep-timer mode.
7 SHIFT
Hold down when pressing a numbered button to change
its function to that printed above the number.
8 MUTING (13)
To turn off the sound temporarily.
9 CLEAR (9, 10, 17)
CD: Clears a CD program
Tuner: Clears a preset station.
0 TREBLE (13)
BASS (13)
! s (8, 9, 14, 15)
@ FUNCTION (15)
Switches the active function among TAPE, TUNER, AUX
(VIDEO or TV) and CD.
# VOLUME +,- (13)
6
ADJUSTMENTS BEFORE OPERATION
POWER
6STANDBY/ON
ECO
Power
Tur ning the unit on
Press POWER 6STANDBY/ON (POWER on the remote ).
Alternatively, press dTAPE, TUNER/BAND, AUX or
ECD. Playback will start automatically if a disc or tape is
loaded.
Tur ning the unit off
Press POWER 6STANDBY/ON again.
The unit goes into standby.
Dimmer
The display window brightness can be selected.
Press DIMMER on the remote repeatedly.
Each press of the button changes the following three levels:
"DIMMER 1", "DIMMER 2" and "DIMMER 0".
"DIMMER 0" is brightest.
ECD,
TUNER/
BAND,
dTA PE,
AUX
f,g
POWER
CLOCK
ECD,
TUNER/
BAND,
dTA PE,
AUX
SHIFT
DIMMER
ENTER
f,g
ECO mode
Reduces power consumption in standby mode with the following
operations.
Press ECO.
Each press of the button changes the mode as follows;
ECO ON: Power economizing mode is activated.
When the unit turns off, everything in the display disappears
and only the red indicator above POWER lights to show that
the power is being supplied.
ECO OFF: Power economizing mode is cancelled.
When the unit turns off, the clock display appears.
Initial mode is ECO OFF.
Standby power consumption
ECO ON: 0.3 W
ECO OFF: 10 W
Setting the clock
1
In stop mode, hold down SHIFT and press CLOCK
on the remote.
Go to step 3 when the hour of the clock display flashes.
2
Within 6 seconds, press ENTER.
The hour flashes in the display.
3
Press f or g to set the hour, then press
ENTER.
4
Press f or g to set the minute.
Each press changes the time in 1-minute steps.
5
Press ENTER.
The time display stops flashing and the clock starts from
00 seconds.
To display the time while the power is on
Hold down SHIFT and press CLOCK on the remote.
The time will be displayed for 6 seconds.
Tip:
''AM 12:00" indicates midnight and "PM12:00" noon.
If "- -:- -" appears when the unit is turned off
There has been a power interruption. Reset the clock.
7
Loading...
