Airstream Interstate 2010 Owner's Manual

INTRODUCTION

The Owners Manual for your new Airstream Motorhome is designed to respond

to the most frequent inquiries regarding the operation, function and care of the

many systems that make modern motor homing a joy.

The Airstream Interstate Motorhome is integrated into a Sprinter Van, designed

and manufactured by Sprinter. Operation of the Sprinter, its engine, power

train, and other related components are discussed in the Sprinter Operator’s

Manual and other literature provided by Sprinter. As a point of reference, those

systems discussed in the Sprinter literature are warranted by Sprinter or their

suppliers.

Airstream realizes our customers possess varying degrees of expertise in the

area of repairing and maintaining the appliances in their motorhome. For this

reason, the service and trouble-shooting information found in this manual is

directed toward those with average mechanical skills. We also realize you

may be more familiar in one area than you are in another. Only you know your

capabilities and limitations.

We want you to use this manual, and hope you will find the information con-

tained in it helpful, however, should you ever feel you may be “getting in over

your head” please see your dealer to have the repairs made.

The operation and care of component parts such as, refrigerator, furnace, water

heater and others are briefly explained in this manual. However, you will also

2010 INTERSTATEINTRODUCTION

find the complete manufacturer’s information supplied in a packet included

with this manual.

Note: All information, illustrations and specifications contained in the literature

are based on the latest product information available at the time of publica-

tion approval. Airstream reserves the right to make changes if and when new

materials and/or production techniques are developed that can improve the

quality of its product, or when material substitutions are necessary due to

availability.

We have provided many important safety messages in this manual. Always

read and obey all safety messages.

Warning indicates a potentially hazardous situation that, if not

avoided, could result in death or serious injury.

CaUTiOn indicates a potentially hazardous situation that, if not

avoided, could result in minor or moderate injury.

NOTE: Important information regarding the maintenance of your recreational

vehicle.

(Optional)

This denotes items that may be an option on all or particular models. Additionally,
some optional items can only be included during the manufacturing phase and
cannot be added.

The inclusion of optional items does not imply or suggest the availability,
application suitability, or inclusion for any specific unit.

NOTICE: Your Sprinter Van Operator’s and Warranty Manuals contain im-

portant cautions, warnings, operational, and warranty information on the

Sprinter and its components. All information in the Sprinter manual should

be reviewed and followed for your safety. The Airstream Interstate Owner’s

Manual may provide addition information and tips on the use of the Van

as a motorhome, however, no information in the Airstream manual should

be interpreted as advice or directions to disregard or void the warnings,

cautions, or other information contained in the Sprinter’s manuals.

Important Safety Precautions

nOTiCE: used without the safety alert symbol indicates a situation that could

result in property damage if not avoided.

You’ll find many safety recommendations on this page and throughout this

manual. The recommendations on the next two pages are the ones we

INTRODUCTION

consider to be the most important. Most are covered in depth in later sections

of this manual.

Mold (See page D-18)

There are mold and mold spores throughout the indoor and outdoor environment.

There is no practical way to eliminate all mold and mold spores in the indoor

environment; the way to control indoor mold growth is to control moisture.

Towing and Weight Distribution (See section B of this manual)

Weight distribution is an important factor when loading your motorhome. A

recreational vehicle with the cargo distributed properly will result in efficient,

trouble-free towing. Be sure to follow the instructions in this manual.

Generator Safety (See page H-10)

Do not operate the generator in an enclosed building or in a partly enclosed

area such as a garage. Nor should the generator be operated while sleeping.

Be sure to follow all instructions and warnings in this manual and the generator

manufacturer’s manual.

Appliances and Equipment (See LP section on G-1 and Appliances on

page I-1)

The appliances (stove, outdoor grills, etc.) and equipment (hot water heater,

furnace generator, etc.) typically operate on propane gas. Propane gas is

flammable and is contained under high pressure. Improper use may result in

a fire and/or explosion. Be sure to follow all instructions and warnings in this

manual (see LP Plumbing section) as well as the specific owners’ manuals of

the appliances and equipment.

Tire Safety (See pages C-3 through C-5 and the Tire Safety Manual

Addendum)

Properly maintained tires improve the steering, stopping, traction, and load-

carrying capability of your vehicle. Under inflated tires and overloaded

vehicles are a major cause of tire failure. Be sure to read the Tire Safety Manual

Addendum included with your owner’s packet.

2010 INTERSTATEINTRODUCTION

Chemical Sensitivity

Chemical Sensitivity

After you first purchase your new recreational vehicle and sometimes after it

has been closed up for an extended period of time you may notice a strong

odor and chemical sensitivity. This is not a defect in your recreational vehicle.

Like your home, there are many different products used in the construction of

recreational vehicles such as carpet, linoleum, plywood, insulation, upholstery,

etc. Formaldehyde is also the by-product of combustion and numerous

household products, such as some paints, coatings and cosmetics. However,

recreational vehicles are much smaller than your home and therefore the

exchange of air inside a recreational vehicle is significantly less than a home.

These products, when new or when exposed to elevated temperatures and/

or humidity, may “off-gas” different chemicals, including formaldehyde. This

off-gassing, in combination with the minimal air exchange, may cause you to

experience irritation of the eyes, nose, and throat and sometimes headache,

nausea, and a variety of asthma-like symptoms. Elderly persons and young

children, as well as anyone with a history of asthma, allergies, or lung problems,

may be more susceptible to the effects of off-gassing.

Most of the attention regarding chemical off-gassing surrounds formaldehyde.

Formaldehyde is a naturally occurring substance. It is also a key industrial

chemical used in the manufacture of the numerous consumer products which

we referred to above and used in the construction of recreational vehicles.

Trace levels of formaldehyde are also released from smoking, cooking, use of

soaps and detergents such as carpet shampoos, cosmetics, and many other

household products. Some people are very sensitive to formaldehyde while

others may not have any reaction to the same levels of formaldehyde. Amounts

released decrease over time.

Your Airstream motorhome was manufactured using low formaldehyde

emitting (LFE) wood products, which is the typical usage in the recreation

vehicle industry. Formaldehyde has an important role in the adhesives used

to bind wood products used in recreation vehicles. The wood products in

your motorhome are designed to emit formaldehyde at or lower than industry

guidelines and should not produce symptoms in most individuals.

While LFE wood products typically do not emit formaldehyde at a level that

would cause symptoms in most individuals, it is possible, though not likely, for

that to occur when the trailer is not properly ventilated. Ventilation is an essential

requirement for trailer use, for many reasons. Any effects of formaldehyde

can be greatly reduced by actions such as opening windows, opening roof

vents, running the air conditioner, or some combination thereof. In addition,

the emission of formaldehyde by these products naturally decreases rapidly

over time.

INTRODUCTION

Airstream strongly suggests that you take measures to properly ventilate your

motorhome on a regular basis.

Ventilation

To reduce or lessen exposure to chemicals from off-gassing it is of utmost

importance that you ventilate your recreational vehicle. Ventilation should occur

frequently after purchase and at times when the temperatures and humidity are

elevated. Remember off-gassing is accelerated by heat and humidity. Open

windows, exhaust vents, and doors. Operate ceiling and/or other fans, roof air

conditioners, and furnaces and use a fan to force stale air out and bring fresh air

in. Decreasing the flow of air by sealing the recreational vehicle increases the

formaldehyde level in the indoor air. Please also follow the recommendations

contained in Chapter 2 regarding tips to avoid condensation problems. Many

of the recommendations contained in Chapter 2 will assist in avoiding exposure

to chemicals that off-gas.

If you have any questions with respect to proper ventilation of your motorhome,

please do not hesitate to contact your dealer or Airstream.

Do Not Smoke

Finally, we recommend that you do not smoke inside your recreational vehicle.

In addition to causing damage to your recreational vehicle, tobacco smoke

releases formaldehyde and other toxic chemicals.

Medical Advice

If you have any questions regarding the health effects of formaldehyde, please

consult your doctor or local health department.

Chemical gassing is not a “Defect” in your recreational vehicle and is not

covered by the Limited Warranty. Please follow the recommendations in this

manual to address this concern.

TABLE OF CONTENTS

A. WARRANTY AND SERVICE

Warranty

Warranty Explanation

Service

Reporting Safety Defects

Maintenance Schedule

B. DRIVING

Loading

Weighing The Motorhome

Seat Belts

Trailer Towing & Driving Tips

Towing The Motorhome

Safety Check List

C. SPRINTER VAN

Component Identification

Tire/Wheels

Changing a Tire

Wheel Simulator

D. CAMPING

Safety

Smoke/CO Alarm

LP Gas Detector

Overnight Stop

Extended Stay

Winter Traveling

E. EXTERIOR

Cleaning Exterior

Roadside Exterior Features

Curbside Exterior Features

Awning

F. INTERIOR FURNISHINGS

AND ACCESSORIES

Seats

Lounge/Bed, Dinette

Vinyl Floor

Cabinets

Wet bath

Galley/Lavatory Sinks

Interior Skin

Fabric

Shades

Countertops

Vents

Interior Bulbs

G. PLUMBING

LP (Liquid Petroleum) Gas

Water System

Water Pump

City Water Hookup

Exterior Shower

Faucets

Drain Valve Locations

Toilet

Storage and Winterizing

Drainage/Waste System

H. ELECTRICAL

120 Volt System

Energy Management System

GFI Breakers

Generator

12-volt Operation

Battery Disconnect

Monitor System

TV Antenna

Entertainment Center

Satellite System

Solar Power

I. APPLIANCES

Air Conditioner

Furnace

Refrigerator

Cooktop

Microwave Oven

Water Heater

Coffee Maker

J. SPECIFICATIONS

Dimensions

Capacities

INDEX

WARRANTy AND SERvICE

AIRSTREAM MOTORHOME LIMITED WARRANTY

WARRANTY COVERAGE

Airstream Inc. (“Airstream”) warrants that it will repair or replace defects in

material or workmanship in any components of a new Airstream motorhome

purchased from an authorized Airstream dealer in the United States or Canada

for 36,000 miles (57,937 Kilometers) or a period of thirty-six (36) months from

the date the motorhome is first delivered to the original retail purchaser. In order

to obtain coverage under this Limited Warranty, you must notify an authorized

Airstream dealership or Airstream of the warrantable defect no later than ten

(10) days following expiration of this Limited Warranty. Airstream’s obligation

to repair or replace defective materials or workmanship is the sole obligation of

Airstream under this Limited Warranty. Airstream reserves the right to use new

or remanufactured parts of similar quality to complete any warranty work.

LIMITATION OF IMPLIED WARRANTIES

IMPLIED WARRANTIES ARISING UNDER APPLICABLE LAW, IF

ANY, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE

HEREBY LIMITED IN DURATION TO THE TERM OF THIS LIMITED WARRANTY.

ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, ARE HEREBY DISCLAIMED

BY AIRSTREAM. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW

LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY

NOT APPLY TO YOU.

WHAT IS NOT COVERED BY THIS LIMITED WARRANTY

This Limited Warranty does not provide coverage for any of the following:

1. Tires, batteries, stereo, television, range/stove, furnace, refrigerator, water

heater, microwave, generator, slide-out mechanisms, and other materials, parts

and components warranted by persons or entities other than Airstream. Please

refer to the warranties of component manufacturers for terms and conditions

of coverage;

2. Any part or component of the motorhome that was not manufactured or

installed by Airstream;

3. Normal deterioration due to wear or exposure, including but not limited to

rust, corrosion, oxidation, and cosmetic blemishes;

4. Normal maintenance and service items, including but not limited to light

bulbs, fuses, lubricants, sealants and seals, slide out adjustments, door adjust-

ments, and awning tension;

5. After-market equipment or accessories installed on the motorhome after

completion of manufacture by Airstream, or any defects or damage caused by

such items;

6. Motorhomes not purchased through an authorized dealer of Airstream mo-

torhomes, and motorhomes purchased directly or indirectly through auction,

salvage, repossession, or other non-customary sale means;

AA

A - 1

WARRANTy AND SERvICE

A - 3

7. Defects or damage caused by, in whole or in part, or in any way related to:

a. Accidents, misuse (including off-road use), or negligence.

b. Failure to comply with the instructions set forth in any owner’s

manual provided with the motorhome.

A

c. Alteration or modification of the motorhome except such altera

tions or modifications approved in writing by Airstream.

d. Acts of God or other environmental conditions, such as lightning,

hail, salt, or other chemicals in the atmosphere.

e. De-icing agents or other chemicals applied to the motorhome.

f. Failure to properly maintain or service the motorhome, includ

ing but not limited to the maintenance of lubricants, sealants, and

seals.

g. Condensation and the results of condensation including water

damage and the growth of mold or mildew. Mold and mildew are

natural growths given certain environmental conditions and are not

covered by the terms of this Limited Warranty.

h. Use of the motorhome other than for temporary recreation pur

poses, including but not limited to use of the motorhome for residen

tial, commercial, disaster relief, or rental purposes.

i. The addition of weight to the motorhome that causes the motor

home’s total weight to exceed applicable motorhome weight rat

ings, or addition of weight causing improper distribution of the

weight of the motorhome.

j. Failure to seek and obtain repairs in a timely manner.

k. Failure to use reasonable efforts to mitigate damage caused by

defects.

l. Failure to properly ventilate the motorhome.

m. Improper electric power supply or improper vehicle hookup to

other facilities.

n. Acts or omissions of any person or entity other than Airstream.

DISCLAIMER OF INCIDENTAL AND CONSEQUENTIAL DAMAGES

Airstream hereby disclaims any and all incidental and consequential damages

arising out of or relating to the motorhome, including expenses such as trans-

portation to and from vehicle dealerships and Airstream repair facilities, loss of

time, loss of pay, loss of use, inconvenience, commercial loss (including lost

profits), towing charges, bus fares, vehicle rental, service call charges, gasoline

expenses, incidental charges such as telephone calls and facsimile transmis-

sions, and expenses for lodging. This disclaimer is independent of any failure of

the essential purpose of any warranties provided with the motorhome, and shall

survive any determination that a warranty failed of its essential purpose. Some

states do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitation or exclusion may not apply to you.

OBTAINING WARRANTY SERVICE

In order to obtain warranty service under this Limited Warranty, the owner must

A - 2

WARRANTy AND SERvICE

do all of the following:

1. Owner and dealer representative must complete, sign, and return

the Customer Performance Checkout within 10 days from delivery

of the motorhome;

2. Notify Airstream or one of its authorized, independent dealers, of

any claimed defect within the warranty period or 10 days thereafter;

3. Provide notification of a defect within 10 days of discovery of that

defect; and

4. Promptly return the motorhome to an authorized Airstream dealer

or Airstream for repairs.

If you believe a defect covered by this Limited Warranty still exists after an at-

tempted repair by an authorized Airstream dealer, you must contact Airstream

at the following address, specifying:

1. The complete serial number of the motorhome;

2. The date of original purchase and the date of original delivery;

3. The name of the selling dealer; and

4. The nature of the problem and the steps or service which have

been performed.

AIRSTREAM, INC. 419 West Pike Street P.O. Box 629 Jackson Center, Ohio

45334-0629 Attention: Owner Relations Department

Airstream may direct you to an authorized Airstream dealer, or may request that

you bring your motorhome to the Airstream factory in Jackson Center, Ohio for

repairs.

AA

Airstream does not control the scheduling of repairs at its authorized Airstream

dealers, and repairs at the Airstream factory may not be immediately available.

Therefore, you may encounter delays in scheduling repairs and/or completion

of repairs. All costs associated with transporting the motorhome for any war-

ranty service shall be the sole responsibility of the owner.

DEALER REPRESENTATIONS EXCLUDED

The entire Limited Warranty provided by Airstream is set forth herein. Airstream

will not be responsible for any additional representations or warranties made by

any person or entity other than Airstream, and Airstream’s obligations are solely

as set forth in the terms and conditions of this Limited Warranty.

WARRANTY TRANSFER

This Limited Warranty is transferable to subsequent owners for the remaining

duration of the warranty period, upon approval from Airstream. Transfer of this

Limited Warranty will only be approved by Airstream upon all of the following:

(1) Airstream’s receipt of a completed transfer application form; (2) the pay-

ment of a $250.00 processing fee to Airstream; and (3) the completion of an

inspection of the condition of the motorhome, at the owner’s expense, by an

A - 3

WARRANTy AND SERvICE

A - 5

authorized Airstream dealer in accordance with Airstream’s required procedure

and Airstream’s receipt of a written report as to the results of such inspection.

Transfer application forms are available from your dealer or Airstream’s Service

Administration Department.

A

CHANGES IN DESIGN

Airstream reserves the right to make changes in design and improvements

upon its products from time-to-time, without imposing upon itself any obliga-

tion to install additional features in your motorhome.

CONSUMER ARBITRATION PROGRAM

Airstream Inc. participates in the Consumer Arbitration Program for Recreation

Vehicles (CAP-RV). This third-party dispute resolution program is available, at

no charge to you, to settle unresolved warranty disputes for recreation vehicles.

This dispute resolution program reviews eligible product and service related

complaints involving warranty covered components.

To find out more about this program, or to request an application/brochure,

please call the Arbitration Administration office toll-free 800.279.5343.

fore claiming rights conferred by 15 USC section 2310 (Uniform Commercial

Code) or Civil Code section 1793.22(b) (Song-Beverly Warranty Act). You are

not required to use the program if you choose to seek redress by pursuing

rights and remedies not created by those laws.

Members of the armed forces who purchased the vehicle in California, or who

were stationed in or a resident of California at the time of purchase (regardless

of state of purchase) or who are stationed in California at the time of application

to this program may utilize the CAP-RV program.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY

ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

AIRSTREAM, INC.

419 West Pike Street

P.O. Box 629

Jackson Center, OH 45334-0629

Tele: 937-596-6111

Fax: [phone]

For recreation vehicles purchased in the State of California: The CAP-RV

program operates as a certified mechanism under the review of the California

Arbitration Certification Program. You must utilize the arbitration program be-

A - 4

WARRANTy AND SERvICE

WARRANTY EXPLANATION

Along with your new Airstream motorhome, you have purchased the Airstream

Limited Warranty. Read your Limited Warranty carefully. It contains the entire

agreement with respect to Airstream’s obligation on the Limited Warranty on

your new vehicle. The terms of the Limited Warranty, and only those terms, will

define Airstream’s responsibility. When you receive your Limited Warranty file

it for safekeeping.

Upon proof of purchase date to any Airstream Dealer Service Center, defects in

materials or workmanship will be repaired or replaced without cost to the owner

for a period of thirty six (36) months from the original purchase date, or 36,000

miles (57,937 kilometers), whichever occurs first. Written warranties of some

manufacturers of components of the motorhome will be honored by Airstream

for the duration on that manufacturer’s warranty.

The Airstream Limited Warranty Excludes:

Normal Wear:

Items such as curtains, upholstery, floor coverings, window and vent seals may

show wear within the three year/36000 mile Limited Warranty period depending

upon the amount of usage, weather, and atmospheric conditions.

Accident

Damage caused by accident is usually visible, and we strongly urge our dealers

and customers to inspect the motorhome upon delivery for any damage caused

by accident while being delivered to the dealer, or while it is on the dealer’s

lot. Damage of this nature becomes the dealer’s or your responsibility upon

acceptance of the motorhome. GLASS BREAKAGE, whether obviously struck

or mysterious, is always accidental and covered by most insurance policies.

Abuse

Lack of customer care and/or improper maintenance, including failure to com-

ply with the instructions and terms of the all owner’s manuals and booklets, or

failure to heed proper vehicle operation shown by the dash instruments is not

covered by warranty.

Exposure

Deterioration by sunlight is possible to such items as tires, curtains or uphol-

stery. Steel or metal surfaces are subject to the elements, causing rust and cor-

rosion that is normal and beyond the control and responsibility of Airstream.

AA

A - 5

WARRANTy AND SERvICE

A - 7

Appearance

Paint and appearance items that show imperfections, damage to interior and

exterior surfaces resulting from abrasion, collision or impact, and broken win-

A

dow glass is not covered by the Airstream Limited Warranty and should be

brought to the attention of your Airstream dealer at the time of delivery and

during pre-delivery inspection.

Overload

Overload Damage due to loading beyond capacity or to cause improper bal-

ance is not covered by the Airstream Limited Warranty. The Airstream motor-

home is engineered to properly handle any normal load. There are limits to the

amount of load that can be safely transported depending upon speed and road

conditions. If these limits have been exceeded, the Airstream Limited Warranty

will not cover resulting damage. For additional information on the load capacity

of your motorhome, consult your Sprinter and Airstream Owner’s Manuals or

gross vehicle weight rating plate.

Chemical Gassing

manual Introduction section to address this concern.

Sprinter Van

Airstream, Inc., does not accept any responsibility in connection with any of its

motorhomes for the Sprinter Van or its components. The Sprinter Van and its

components are covered by Sprinter Warranties as explained by Sprinter litera-

ture provided with each motorhome. Your Sprinter Van and its components are

pre-checked by its manufacturer before delivery to Airstream. All service to the

Sprinter Van and its components must be performed by Sprinter designated

service points according to the manufacturer’s warranty and service policies.

Sprinter Literature is supplied with each Airstream motorhome. The literature

gives important information concerning its warranty coverage, maintenance,

and operation.

Warning: Your Sprinter Van Operator’s and Warranty Manuals

contain important cautions, warnings, operational, and warranty informa-

tion on the Sprinter and its components. All information in the Sprinter

manual should be reviewed and followed for your safety.

Chemical gassing is not a “Defect” in your recreational vehicle and is not

covered by the Limited Warranty. Please follow the recommendations in this

The Airstream Interstate Owner’s Manual may provide addition information and

tips on the use of the Van as a motorhome, however, no information, in whole

A - 6

WARRANTy AND SERvICE

or in part, in any Airstream manuals should be interpreted as advice or direc-

tions to disregard or void the Warnings, Cautions, Notices, or other information

contained in the Sprinter’s manuals.

Other Exclusions

Tires, batteries, and the generator are serviced by their respective manufac-

turers and will be handled by their service centers according to the terms of

their written policy. Any warranty forms from these manufacturers should be

completed promptly, preferably at time of purchase.

Service

Before leaving the factory, each and every vital part of the motorhome is tested

for performance. Each test is signed and certified by an inspector. After the

motorhome arrives on your dealer’s lot all of these vital parts and systems are

again tested. When you take delivery of your new motorhome you will receive

a complete Customer Performance Checkout.

Major service under your Airstream Limited Warranty is available through our

nationwide network of Airstream Dealer Service Centers. An up-to-date list of

Dealer Service Centers has been provided with your new motorhome. This list

is current as of the date of publication. Please contact an authorized Airstream

dealer if you need service.

Occasionally dealerships change, or new dealers are added who may not ap-

pear on this list. For this reason, it is suggested that you contact your selling

dealer from time to time and bring your list up to date or go to www.airstream.

com and use the dealer locator. Airstream customer relations can also supply

you with an up to date list.

ALL SERVICE CENTERS OPERATE ON AN APPOINTMENT BASIS FOR

THE UTMOST EFFICIENCY.

When you require service from the Airstream Factory Service Center or a

Certified Dealer Service Center, please contact the service manager for an

appointment, and kindly inform him if you are unable to keep the appointment

date or wish to change it. Service may be arranged at the Airstream Factory

Service Center by contacting the Service Coordinator at:

Airstream Factory Service Center

P.O. Box 629

419 W. Pike Street

Jackson Center, Ohio 45334-0629

Phone: [phone] Fax: [phone]

AA

A - 7

WARRANTy AND SERvICE

A - 9

REPORTING SAFETY DEFECTS

If you believe that your vehicle has a defect which could cause a crash or could

cause injury or death, you should immediately inform the National Highway

A

Traffic Safety Administration (NHTSA) in addition to notifying Airstream Inc..

If NHTSA receives similar complaints, it may open an investigation, and if it

finds that a safety defect exists in a group of vehicles, it may order a recall and

remedy campaign. However, NTHSA cannot become involved in individual

problems between you, your dealer, or Airstream Inc.

To contact NHTSA, you may either call the Vehicle Safety Hotline toll-free at

1-888-327-4236 (TTY: 1-800-424-9153); go to http://www.safercar.gov; or

write to: Administrator, NHTSA, 1200 New Jersey Avenue, S.E., Washington,

DC 20590.

You can also obtain other information about motor vehicle safety from http://

www.safercar.gov.

A - 8

WARRANTy AND SERvICE

MAINTENANCE SCHEDULE

Warning: FAILURE TO MAINTAIN YOUR COACH CAN CAUSE

PREMATURE AND UNEXPECTED PARTS BREAKAGE AND/OR ERRATIC

OPERATION THAT MAY BE HAZARDOUS. SERIOUS INJURY COULD

RESULT FROM FAILURE TO HEED THIS WARNING.

EVERY 1,000 MILES OR 60 DAYS

Smoke/CO Alarm Test weekly and replace battery as required.

GFI Circuit Breaker Test and record.

EVERY 5,000 MILES OR 90 DAYS

LPG Regulator Check bottom vent for obstructions

Roof Vent Lubricate with light household oil

Living Area Windows Lubricate with light household oil

EVERY 10, 000 MILES OR 6 MONTHS

Smoke/CO Alarm Vacuum exterior only.

EVERY 12,000 MILES OR 1 YEAR

LP Tank Check for damage.

Sealer Check and reseal, windows, lights, and

vents. Reseal with urethane

sealant or equivalent as needed.

APPLIANCES

Appliances have maintenance schedules and advice in their respective

Owners/Operation Manuals. These manuals are included in the owner’s

packet given to you by your dealer. Please become familiar with and follow

all information in these manuals.

AUTOMOTIVE

AA

See the Sprinter Operators Manual and Maintenance Logbook for

Automotive Maintenance schedules and pre-trip inspections.

A - 9

WARRANTy AND SERvICE

MAINTENANCE RECORDS

A

DAT E DEALER SERvICE PERFORMEDDAT E DEALER SERvICE PERFORMED

A - 10

DRIvING

LOADING

One of the most critical aspects of safely operating a motorhome is knowing

the weights involved and where they are placed. The first thing to determine is

how much cargo is being loaded and confirming that it is within the capacities

of the equipment being used. Determining WHERE that load is placed is criti-

cal to the way your rig will handle on the road.

Do not try to guess what your recreational vehicle weighs loaded. Load your

RV including water, propane, etc and take it to a public scales. Weigh each

axle of your vehicle. Refer to your axle weight and tire limits to see if your

within a safe range. Total all axle weights and make sure you are below the

GVWR. If you are not overloaded make sure your load is balanced. Do not

load too much on one side. A balanced load is much easier to tow or drive.

Front to back balance is also important. Step back and look at your recre-

ational vehicle. Make sure that there is not too much weight on the hitch or on

the rear of the RV. Be sure to secure all items. Loose items can cause damage

and be a safety issue if not properly secured.

The Cargo Carrying capacity tag shown below is installed on every

motorhome and can be found on the inside of the screen door on your

vehicle.

MOTOR HOME OCCUPA NT AND CARGO CARRYING CAP A CITY

VIN #################

THE COMBINED WEIGHT OF OCCUP A NTS AND CARGO SHOULD NEVER EXCEED

XXX kg or XXX lbs

Safety belt seating capacity: XXX

CAUTION

A full load of water equals XXX kg or XXX lbs of cargo @ 1 kg/L (8.3 lb/gal) and the tongue

weight of a towed trailer counts as cargo

To arrive at the “THE COMBINED WEIGHT OF OCCUPANTS AND CARGO

SHOULD NEVER EXCEED” number, Airstream weighs the vehicle as finished

and adds the weight of full tanks of liquid propane and chassis fuel. That num-

ber is subtracted from the Gross Vehicle Weight Rating (GVWR) of the motor-

home and listed on the tag, The total weight of any and all cargo, including but

not limited to dealer or customer modifications or additions, fluids (freshwater,

holding, and water heater tanks), food, clothes, tools, the tongue weight of a

towed trailer or vehicle, and passengers should never exceed the number listed

while the motorhome is in transit.

The “Safety belt seating capacity” is the number of passengers that seat belts

are provided for.

B

The “A full load of water equals” number is arrived at by multiplying the fresh

B - 1

DRIvING

water tank and water heater capacities by 1Kg/L or 8.3 lb/gl.

When loading the vehicle it is important to keep the Gross Vehicle Weight

Rating, Gross Axle Weight Ratings, Tire Weight Ratings (listed on the vehicle

Tire Information Placard), and the Cargo and Occupant Capacity in mind and

not to exceed these specifications. Your safety depends on not overloading the

motorhome, motor home axles, and tires. See the specification section for the

weight rating list of these items.

WEIGHING

To determine the actual weight of your vehicle with personal cargo and water

it must be weighed on scales as you plan to travel. The most common scales

are those used by states to weigh trucks used along the highway. In rural areas,

grain elevators and cement outlets are a good source and another would be a

gravel pit. Note: Weighing instructions for this motorhome is explained on the

next page. If you have trouble locating scales, a call to your State Highway

Patrol will usually find them very cooperative in assisting you.

Vehicle and Trailer Weights and Ratings Definitions

Gross Vehicle Weight Rating • (GVWR) is the maximum permissible

weight of the motorhome.

Gross Vehicle Weight • (GVW): comprises weight of vehicle including

tools, spare tire, installed accessories, passengers, cargo, and

trailer tongue weight. It must never exceed the GVWR.

Gross Axle Weight Rating• (GAWR) is a maximum permissible axle

weight.

Gross Trailer Weight • (GTW) is a maximum permissible trailer weight

to be towed.

Trailer Tongue Weight Rating• (TWR) is the maximum permissible

weight of the trailer tongue. This counts as cargo when loading a

motorhome.

NOTE: Check the Sprinter manual for all weights and the tire information

placard location.

Procedure for Weighing A RV (See chart on next page).

Vehicle should be weigh loaded as you normally travel.

1. Fill in first row from Specification Section of this manual.

2. Weigh vehicle as shown in row 2 (Scale Weight) and fill in blanks.

3. Weigh one side of vehicle as shown In Individual Wheel Position Weight.

4. Calculate other side as shown in last row.

Information for line 1 is located in the specification section in this manual.

NOTE: Check the Sprinter manual for all weights and tire information placard

location.

B - 2BB - 3

Front Axle GAWR GVWR Rear Axle GAWR GCWR - GVW

SCALE WEIGHT Optional Tow Weight

DRIvING

B

___________

STEP 1

Front Axle GAW

INDIVIDUAL WHEEL POSITION WEIGHT

___________

STEP 4

Left Front Wheel

Position

Calculated Calculated Calculated

___________

Right Front Wheel

Position

Step 1 minus Step 4

___________

STEP 2

GVW

Rear Axle GAW

___________

STEP 5

Left Side

(Total LF + LR)

___________

Right Front

(Total RF + RR)

Step 2 minus

Step 5

___________

STEP 3

___________

STEP 3a

Tow Weight minus

Weight of Trailer

or Vehicle Towed

___________

STEP 6

Left Rear Wheel

Position

___________

Right Rear

Wheel Position

Step 3 minus Step 6

B - 3

GAWR = Gross Axle Weight Rating

GVWR = Gross Vehicle Weight Rating

GCWR = Gross Combination Weight Rating

DRIvING

WEIGHT DISTRIBUTION

Motorhomes have fresh water and wastewater tanks, a water heater, and stor-

age areas. It gives you great flexibility in loading. With flexibility comes respon-

sibility. If you want to load down all the storage compartments, the amount of

fluids may have to be reduced. It’s a trade off so plan wisely. Distribute your

additional cargo as evenly as possible with the heaviest objects located as low

as possible.

Do you really want to carry a full freshwater tank to a RV park 1,000 miles

away and then hook up to a city water supply? Even if you’re going to the

“boondocks”, you can usually fill your water tank shortly before entering the

area. Just reducing your load by 10 gallons of water lets you carry an additional

30 pounds of cargo.

SAFETY

SEAT BELTS

Federally approved seat belts are provided for the use of the driver, the right

front passenger, the second row captains chairs, and the rear lounge. Most

states require by law that all passengers in a motor vehicle use seat belts while

in transit. It is strongly recommended that all occupants remain seated with their

safety belts firmly attached while the motorhome is in transit. The driver should

adjust his seat so that he is able to reach all controls easily with the belt on, and

be able to use all the travel on the foot brake. Seat belts should be placed as

low as possible around the hips to prevent sliding out from under them in case

of accident. This places the load of the body on the strong hipbone structure

instead of around the soft abdominal area. Remember one occupant per seat

belt when traveling.

The driver and front passenger seat belt buckle operation and is explained in

the Sprinter manual.

The rear lounge and rear captain chairs seat

belt buckles are secured by inserting the male

end into the female buckle until the buckles

are secured. To release the buckle press the

Release Button

B - 4BB - 5

release button on the female end.

Warning: Become familiar with and follow all directions, ad-

vice, and warnings pertaining to seats, seat belt operation, and restraint

systems, provided in the Sprinter Operator’s Manual. Do not allow pas-

sengers to ride anywhere in the motorhome except in seats that are

equipped with approved seat belts.

Warning: Children must be secured in a Federally Approved

Child Restraint Device. Failure to use proper restraints while in transit

can result in severe or fatal injuries. Never place an infant seat that faces

to the rear on the front passenger seat. Never place an unbelted infant

seat on any seat while in transit.

Child restraint devices are designed to be secured with lap or lap/shoulder

belts. All instructions supplied by the restraint manufacturer must be followed.

Statistics have shown children are safer when properly restrained in a rear seat-

ing position than in a front seating position.

DRIvING

CHILDREN HAVE LOVED ONES TOO.

IF YOU WON’T BUCKLE UP FOR YOURSELF, BUCKLE UP FOR THEM.

B

dangEr: Drinking or taking drugs and driving is a very danger-

ous combination. Even a small amount of alcohol or drugs can affect your

reflexes, perception, and judgment. The possibility of a serious or even

fatal accident is sharply increased when you drink or take drugs and drive.

Never drink and/or take drugs and drive or allow anyone to drive after

drinking and/or taking drugs.

Often the children traveling in motorhomes are grandchildren. There are times

when our love for grandchildren makes us hesitate to properly supervise their

actions. Don’t hesitate when it comes to passenger safety. Make sure all pas-

sengers are properly restrained.

B - 5

DRIvING

TRAILER TOWING AND DRIVING TIPS

(Some text is partial excerpts from Sprinter Operators Manual)

Warning: Failure to use proper equipment and driving tech-

nique can result in a loss of vehicle control when towing a trailer. Improper

towing or failure to follow the instructions contained in this section can

result in serious injury. Follow the guidelines below carefully to assure

safe trailer operation. Ask your authorized Sprinter or Airstream dealer if

you require an explanation of information contained in the manuals.

Trailer Hitches

Units have hitches and wiring installed from the Sprinter manufacturer. The

Sprinter 7- way connector is used for lights and charge line on a trailer. For

further information, please see your authorized Sprinter dealer.

The bumpers on your vehicle are not designed for use with clamp type hitches.

Do not attach rental hitches or other bumper type hitches to them.

To reduce the possibility of damage, remove the hitch ball adapter from the

receiver when not in use.

Since this vehicle is designed and intended primarily as a load-carrying vehicle,

towing a trailer will affect handling, durability and economy. Maximum safety

and satisfaction depends upon proper use of correct equipment and avoiding

overloads and other abusive operation.

Warning: The total weight of the motorhome and trailer must

not exceed the GCWR listed in the specification section of this manual.

The maximum towing capacity varies according to the size of the moto-

rhome and its GCWR. Vehicles should be properly equipped for towing

trailers. Information on trailer hauling capabilities and special equipment

required may be obtained from your Sprinter and/or Airstream dealer.

Loading a Trailer

When loading a trailer, you should observe that neither the permissible GTW

(Gross Tongue Weight), nor the trailer GVWR are exceeded.

Maximum permissible values are listed on the safety compliance certification

labels for the vehicle and for the trailer to be towed. For their location, see the

Sprinter Operators Manual. The lowest value listed must be selected when

determining how the vehicle and trailer are loaded.

To assist in attaining good handling of the vehicle/trailer combination it is im-

portant that the tongue weight be maintained at approximately 10%-15% of

the loaded trailer weight, but not to exceed the hitch rating. Tongue loads can

B - 6BB - 7

DRIvING

be adjusted by proper distribution of the load in the trailer, and can be checked

by weighing separately the loaded trailer and then the tongue.

The tongue weight (TW) at the hitch ball must be added to the GVW to prevent

exceeding your Sprinter towed vehicles or rear GAWR.

When towing trailers, motorhome tires should be inflated to the highest pres-

sures shown on the Sprinter Tire Information Placard. See Sprinter Manual for

its location. The Cargo Carrying Capacity (CCC) of this vehicle is reduced by

the amount that equals the trailer tongue load on the trailer hitch.

Checking Weights of Vehicle and Trailer

To assure that the tow vehicle and trailer comply with the maximum permissible

weight limits and to know the actual weights, have the loaded vehicle-trailer

combination (tow vehicle including driver, passengers, and cargo and trailer

fully loaded) weighed on a commercial scale as explained earlier in this sec-

tion.

Also check the vehicles front and rear axle weights and tongue weight. The val-

ues as measured must not exceed the Sprinter weight ratings listed on vehicle

information placards and in the Sprinter manual. These ratings are also listed in

the Specification section of this manual, page J-1.

NOTE: Check the Sprinter manual for all weights and tire information placard

locations.

Attaching a Trailer

B

Please observe maximum permitted trailer dimensions (weight and length).

Most states and all Canadian provinces require safety chains between your tow

vehicle and trailer. The chains should be crisscrossed under the trailer tongue.

It must be attached to the hitch receiver, and not to the vehicles bumper or

axle. Be sure to leave enough slack in the chains to permit turning corners.

Most states and all Canadian provinces required a separate brake system

for towing trailers.

Warning: The towing vehicle’s braking system is rated for op-

eration at GVWR (GROSS VEHICLE WEIGHT RATING), NOT at the GCWR

(GROSS COMBINED WEIGHT RATING). A separate functioning brake

system is required for any towed vehicles or trailers weighing more than

1000 lbs. (450 kg) when fully loaded. NEVER exceed the GVWR (GROSS

VEHICLE WEIGHT RATING), or the GAWR (GROSS AXLE WEIGHT RATING)

specified on a motorhome certification label. Also NEVER, exceed the

B - 7

DRIvING

weight ratings of trailer hitch installed on a motorhome. Failure to heed

any part of this warning could result in loss of control of the motorhome

and towed vehicle or trailer and may cause an accident and serious injury.

For specified towed vehicle braking requirements, consult the Sprinter

Operator’s manual that comes with this vehicle.

Warning: Do not connect a trailer brake system (if trailer is so

equipped) directly to the vehicles hydraulic brake system if your vehicle is

equipped with antilock brakes. If you do, neither the vehicles brakes nor

the trailers brakes will function properly. Property damage, injury or death

to you or others may be the result.

The provided vehicle electrical wiring harness for a trailer towing has a brake

signal wire for hookup to a brake controller. Most states and all Canadian

provinces require a brake away switch on trailers with a separate brake

system. The switch activates the trailer brakes in the possible event that the

trailer might separate from the tow vehicle. Please consider using a trailer

sway control system. For further information, see your authorized Sprinter or

Airstream dealer.

Towing a Trailer

with trailer towing. Make sure that your vehicle -- trailer combination will be

legal; not only for where you reside, but also for where you’ll be driving. A good

source for this information can be the State Attorney General, State Police, or

local authorities.

Before you start driving with a trailer, check the trailer’s hitch, brake away

switch, safety chains, electrical connections, lighting and tires. Also, adjust the

mirrors to permit unobstructed view beyond rear of trailer.

If the trailer has brakes using an electric brake controller, start your vehicle and

trailer moving slowly, and then apply the brakes manually using the brake con-

troller to be sure the brakes are working properly. Read and follow the controller

manufacturers recommendations.

When towing a trailer, check occasionally to be sure that the load is secure, and

that lighting and trailer brakes (if so equipped) are functioning properly. Always

secure items in the trailer to prevent load shifts while driving.

Take into consideration that when towing a trailer, the handling characteristics

are different and less stable from those when operating the vehicle without a

trailer. It is important to avoid sudden maneuvers.

There are many different laws, including speed limit restrictions, having to do

The vehicle and trailer combination is heavier, and therefore is limited in ac-

B - 8BB - 9

DRIvING

celeration ability, and requires longer stopping distances. It is more prone to

reacting to side wind gusts, and requires more sensitive steering input.

In order to gain skill and an understanding of the vehicles behavior, you should

practice turning, stopping and backing up in an area which is free from traffic.

If possible, do not brake abruptly, but rather engage the brake slightly at first to

permit trailer to activate its brake. Then increase the braking force.

We want every owner to be a safe and courteous driver. A few hours of towing

practice in a large empty supermarket lot will make pulling your trailer over the

road much easier. Line out two corners for left and right turns. You may also use

these corners to practice backing and parking.

DURING PRACTICE OBSERVE THAT THE TRACKS MADE BY THE TRAILER

WHEELS ARE DISTINCTLY DIFFERENT FROM THOSE MADE BY THE TOW

VEHICLE.

Studying this will make it easier for you to correct mistakes. Consider truck or

trailer type fender or door grip rear view mirrors for maximum visibility. In most

states the law requires them.

tow. Check traffic, signal that you are about to pull away, and start slowly. Look

often in your mirrors, and observe the action of the trailer, then carefully move

into the proper lane of traffic. Remember that the trailer wheels will not follow

the path of the tow vehicle wheels; therefore, WIDER TURNS ARE NECESSARY

WHEN TURNING TO THE LEFT OR TO THE RIGHT.

ON FREEWAYS OR EXPRESSWAYS try to pick the lane you want and stay in

it. Always maintain plenty of space between you and the car ahead, at least the

length of the tow vehicle plus trailer for every ten miles per hour. Remember

that in order to pass another vehicle you will need longer to accelerate. You

must also allow for the length of the trailer when returning to the right

hand lane.

B

After thoroughly inspecting your hitch, brakes, and tires you should be ready to

B - 9

DRIvING

Tracking

On a two-lane road cars may be lining up behind you because you are traveling

at a lower speed. It is both courteous and sensible to signal and pull over at the

earliest safe opportunity, and let them pass.

The BRAKE CONTROLLER (if so equipped) is activated when you apply the

brakes of the tow vehicle. Your tow vehicle brakes will automatically apply

the trailer brakes first when properly adjusted. This will help keep your tow

vehicle and trailer in a straight line and make you stop as if you were driving

the tow vehicle alone. If swaying or swerving should occur, briefly operating

the controller separate from the vehicle brakes may help correct the situation.

Practice this maneuver on a clear highway. Don’t wait for an emergency then

grope for the controller.

When trailering you might encounter a temporary cooling system overload

during severe conditions such as hot days when pulling on a long uphill grade,

when slowing down after higher speed driving, or driving long idle periods in

traffic jams. If the hot indicator light comes on, or the temperature gauge indi-

cates overheating and you have your air conditioner turned on, turn it off. Pull

over in a safe place and put on your emergency brake. Don’t turn off the engine.

Increase the engine idle speed. Lift the engine hood and check for fluid leaks

at the radiator overflow outlet. Check to see that all drive belts are intact and

the fan is turning. If you have a problem have it fixed at the next opportunity. If

there is no problem the light should go off or temperature should come down

within one minute. Proceed on the highway a little slower. Ten minutes later

resume normal driving.

dangEr: Never open a radiator cap when the tow vehicle is

hot. Add coolant when the vehicle is cool.

When going downhill in dry weather, down shift so that engine compression

will slow the whole rig down. Take dips and depressions in the road slowly and

do not resume normal driving speeds until you are sure that the trailer wheels

are clear of the dip.

Warning: On slippery pavement do not use engine drag to

help slow down as this may cause the rear wheels of the tow vehicle to

B - 10BB - 11

skid. On icy pavement drive slowly and if you feel the tow vehicle skidding

gently apply the trailer brakes only. This will bring the tow vehicle and

trailer back into a single line. Chains do not help trailer wheels.

DRIvING

When driving in mud and sand let the momentum carry the rig through. Apply

power gently and use as little as possible. Stay in the tracks of the vehicle

ahead and keep the tow vehicle in the highest possible gear. If you are stuck it

is best to tow out the entire rig together without unhitching.

Despite the best hitch you will notice that whenever a large bus or truck

overtakes your rig the displaced air first pushes the trailer rear slightly to the

right and then affects the front. It may be necessary to steer very slightly, mo-

mentarily, toward the bus or truck to help compensate for the sway induced

by the passing-vehicle. Do not apply the vehicle brakes, as this can tend to

exaggerate the situation. You may find, however, that briefly applying the trailer

brakes with your manual control will help eliminate sway.

Warning: CHOCK THE TRAILER WHEELS when stopping on

a hill or slope. Leaving your tow vehicle in gear is not enough for standstill

safety. Do not use trailer brakes as parking brakes.

B

B - 11

DRIvING

Backing Up

In BACKING UP the important thing to remember is to DO EVERYTHING

SLOWLY and to correct immediately if you see the trailer turning the wrong

way. Concentrate on the rear of the trailer. With your tow vehicle and trailer in

a straight line, back up slowly and turn the bottom of the steering wheel in the

direction you want the trailer to go. Watch out the window or in the mirror until

the rear of the trailer is pointing in the desired direction. Your tow vehicle will be

following the trailer in an arc. Straighten the tow vehicle and trailer by turning

the steering wheel more sharply, and then when

they are in line, straighten the steering wheel.

ALWAYS TRY TO BACK TO YOUR LEFT BECAUSE

THE VISIBILITY IS MUCH BETTER. When you don’t

make it on the first try it is usually much easier to

pull forward to your original straight position and

start over.

If your spouse or traveling companion normally

directs you when backing they should position

themselves forward of the tow vehicle so the driver

can easily see them. Their directions should always

indicate to the driver the direction the rear of the

trailer should go. A little practice in a parking lot with the person giving direc-

tions can save a lot of frustration when backing into a campsite.

Warning: take into consideration that when towing a trailer,

the handling characteristics are different and less stable from those with

operating the vehicle without a trailer. It is important to avoid sudden ma-

neuvers. Sudden maneuvers may lead to loss of control over the vehicle

-- trailer combination.

B - 12BB - 13

DRIvING

nOTiCE: If the transmission hunts between gears on inclines, manually shift

to a lower gear. A lower gear and reduction of speed reduces the chances of

engine overloading and/or overheating. When going down a long hill, shift into

a lower gear and use the engines braking effect. Avoid riding the brakes, thus

overheating the vehicle and trailer brakes. If the engine coolant rises to an

extremely high temperature (coolant temperature needle approaching the red

zone) when the air conditioner is on, turn off the air conditioner. Engine coolant

heat can be additionally vented by opening the windows, switching the climate

control fan speed to high and setting the temperature control to the maximum

hot position.

Passing

Extreme care must be exercised when passing another vehicle. A vehicle with

a trailer attached will require additional passing distance ahead then when driv-

ing without a trailer. Because your vehicle and trailer is longer then your vehicle

alone, you will also need to go much further ahead of the passed vehicle before

you can return to your lane.

Parking Your Motorhome

B

Warning: to reduce the risk of personal injury, or damage to

the vehicle power train, as a result of vehicle/trailer movement, always:

Keep right foot on the brake pedal.•

Shift gear selector lever to position "N".•

Have a second person place wheel chocks on downhill side of left •

and right trailer wheels.

Slowly release brake pedal cannot vehicle and trailer roll into chocks •

until stopped.

Firmly depress parking brake pedal.•

Move gear selector lever to position "P".•

On inclines, turn wheels towards the road curb.•

B - 13

DRIvING

TOWING YOUR MOTORHOME

nOTiCE: Considerable damage may occur if the motorhome is improp-

erly lifted for towing purposes. Only qualified professional towing service

companies with proper equipment should be used. Observe all cautions

and warnings in the Sprinter Operator’s manual before towing your mo-

torhome.

nOTiCE: Do not tow the vehicle if the key cannot be turned in the ignition

lock.

If the key cannot be turned, the ignition lock remains locked and the vehicle

cannot be steered. With the engine not running there is no power assistance

for the braking and steering systems. In this case, it is important to keep in

mind that a considerably higher degree of effort is necessary to brake and

steer the vehicle. The vehicle must not be towed with the front axle raised and

key in position two in the ignition lock as the drive wheels could then lock due

to the acceleration skid control (ASR). See the Sprinter Operators Manual for

information on the ASR.

pedal in the driver’s foot well. Slide the red release down and pull it off the

post. This will save jump starts, battery charge ups and possibly battery

damage and replacement. The Sprinter manual describes its location,

operation, and cautions in detail.

In addition Airstream recommends the house battery ground should also

be disconnected during chassis electrical work. The battery box is located

under the curbside rear lounge on the rear lounge model and under the

roadside rear bed in the twin model model. A grounding stud is located

inside the house battery box at the top. Battery ground wires are routed to

this threaded stud. Remove the wires from the stud to break the ground

circuit.

NOTE: Sprinter recommends disconnecting the current to all chassis

electric consumers using the Battery isolator Switch if the vehicle sits for

periods longer than 2 months. It is located to the right of the accelerator

B - 14BB - 15

DRIvING

SAFETY CHECK LIST

Your Airstream motorhome should be given a thorough safety check before

a trip. Regular use of the following list will provide safe operation of your

motorhome and will help you spot any malfunctioning equipment and correct

the problem as soon as possible. The list is to help you and may not be all-

inclusive.

Warning: Failure to heed the following items may cause

damage to the vehicle or personal injury.

EXTERIOR CHECK LIST (BEFORE ENTERING VEHICLE)

1. Check condition of tires, keep tires at recommended inflation pressure per

the tire and loading placard on the driver’s door B-pillar.

2. Turn off Remote LPG valve switch.

3. Check that macerator hose, city water hookup, TV cable/satellite, and all

exterior components are unhooked and properly stowed.

4. Check that all external compartments and filler openings are properly

closed, latched, and/or locked.

5. Check that items stored on exterior of vehicle are securely tied down.

6. Would any items stored on exterior of vehicle present a clearance problem?

8. Follow all automotive manufacturers recommendations on checking and

filling fluid levels.

9. Check exterior lights and general condition of vehicle.

INTERIOR CHECK LIST (BEFORE DRIVING OFF)

1. It is important that all doors be completely closed and locked during travel.

2. Turn off living area water pump.

3. Check that refrigerator door is closed and latched if equipped.

4. Check that nothing heavy is stored in overhead or high cabinets, which

could fall out and cause injury. Heavy items should be stored in lower

cabinets.

5. Stow galley flip up shelf and pedestal tables.

6. Check that counter tops, range top, and shelves are clear of even small

items that could become projectiles during an emergency braking or ac-

cident.

7. Retract and latch the wetbath wall.

8. Do not cook while unless motorhome is parked and stable. Hot food or

liquid could scald due to a sudden stop or accident while traveling.

9. Be sure all LPG controls on the appliances are turned off.

10. Check that any internal stowage is securely held in place

11. Check that lights and switches are set in positions safe for travel.

12. Adjust the driver’s seat so that you can easily reach and operate all

controls. Make sure seat is locked in position. Do not adjust driver’s seat

swivel or recline mechanisms while vehicle is moving. The seat could move

B

B - 15

DRIvING

unexpectedly causing loss of control.

13. Check that all passengers have seat belts on properly.

14. The freedom of movement of the brake and accelerator pedals must not

be impaired in any way.

15. Check rear view mirrors adjustment, inside and outside. Adjust window

B

coverings if necessary for maximum visibility.

16. Secure children in a Federally Approved Child Restraint Device.

B - 16

SPRINTER vAN

The Airstream Interstate Motorhome is integrated into a Sprinter Van designed

and manufactured by Sprinter. Operation of the Sprinter, its engine, power train,

and other related components are discussed in the Sprinter Owner’s Manual

and other literature provide by Sprinter. As a point of reference, those systems

discussed in this literature are warranted by Sprinter or their suppliers.

IMPORTANT SPRINTER INFORMATION

Your Sprinter Van Operator’s and Warranty Manuals contain important cau-

tions, warnings, operational, and warranty information on the Sprinter and

its components. All information in the Sprinter manual should be reviewed

and followed for your safety. The Airstream Interstate Owner’s Manual may

provide addition information and tips on the use of the Van as a motorhome,

however, no information in the Airstream manual should be interpreted as

advice or directions to disregard or void the warnings, cautions, or other

information contained in the Sprinter’s manuals. IF YOU BELIEVE THERE

IS A CONFLICT IN INFORMATION, WARNINGS, CAUTIONS, OR SAFETY

RELATED INFORMATION BETWEEN THE SPRINTER AND AIRSTREAM

MANUALS, PLEASE CONTACT THE AIRSTREAM CUSTOMER RELATIONS

DEPARTMENT IMMEDIATELY TO RESOLVE THE CONFLICT.

Fuel

nOTiCE: The Sprinter Owner’s Manual contains important fuel requirement

information on using Ultra-Low Sulfur Diesel, Bio fuels, and very low tempera-

ture operation. Please read, understand, and follow this information.

Component Identification

If repairs are needed, it may be difficult to determine which parts are the

Sprinter’s and which are Airstream’s responsibility. The following partial lists

show the major components of the van and the company responsible for their

servicing.

Sprinter Van Serviced by Sprinter or its suppliers.

In the United States: In Canada:

Chrysler Motors Company LLC Chrysler Canada, Inc.

Customer Center Customer Center

PO Box 21-8004 PO Box 1621

Auburn Hills, MI. 48321-8004 Windsor, Ontario N9A-4H6

Ph.: 800-992-1997 Ph.: 800 465-2001

See Sprinter Warranty Information Manual for complete instructions.

C

C - 1

SPRINTER vAN

Engine Exterior Automotive lights

Engine Battery Power mirrors

Engine Cooling System Fog lamps

Transmission Chassis Suspension

Brakes Drive Axle and Hubs

Steering Assembly, Steering Wheel Rear window defroster

Automotive Fuse Panel Rear backup alarm

Wheels, Tires Parking Brake

Alternator Fuel Pump

Speed Control Automotive electrical system

Instrument Panel Cluster Hitch receiver and tow plug

Doors, cab, side and rear cargo *Drivers/Passenger seats

Cab door windows and windshield Radio/CD Player/Antenna

Dash AC/Heater/Defroster Cargo door assist handle

12V Air compressor and puncture sealant

Radio

Driver’s and Passenger’s Seats and Restraint systems.

Sprinter provides the swivel pedestals and Airstream provides the seat deco-

rative skirting and recovers the front seats to match the surrounding decor’.

Airstream Components serviced by Airstream Authorized Service Centers

or Airstream suppliers.

Cab Area:

Driver’s and passenger’s seat skirting and covers.

Floor Mats

Optional Burlwood Dash Kit

Living Quarters:

Second row cab seats, swivels. Fire extinguisher.

Interior furniture. Smoke/CO detector

Privacy curtains. Window Coverings.

Floor covering. All plumbing systems.

Appliances in the lounge/lavy area.

Non-automotive electrical components including:

Monitor panel and its system Generator and components.

Inverter/Charger House battery (optional 2)

Battery disconnect Power vents

120-volt system Sliding step

12 Volt living area system Living area entertainment center

Roof AC

C - 2CC - 3

SPRINTER vAN

Exterior

TV antenna Exterior patio light

Wheel simulators Radio antenna

Exterior body kit. Awning

Power Step

Exterior windows excluding windshield, drivers and passenger door

Access doors and other living area electrical and plumbing components

If you need further clarification or information, contact the Airstream Customer

Relations Department at 937-596-6111 before contacting a service center for

an appointment.

If you wish to write, the address is:

Airstream Inc.

Attn: Customer Service

419 W. Pike Street

P.O. Box 629

Jackson Center, Ohio 45334

TIRES

Don’t let anyone tell you that under inflation or over inflation of tires is all right.

It’s not. If your tires don’t have enough air (under inflation) you can get tire

flexing, heat build-up, tire overloading, bad handling, bad fuel economy, and

uneven wear. Too high an air pressure (over inflation) can result in abnormal

wear, bad handling, harsh ride, and increase the chance of damage from road

hazards.

Tire inflation pressures should be checked as per the Sprinter’s Owner’s manual

and when significantly changing the load you plan to carry in your motorhome.

Set the correct tire pressure before loading the vehicle. If the vehicle has been

loaded, check the tire pressure and correct them if necessary. Always check

tire inflation pressures when the tires are “cold”.

Standard inflation pressures for tires are listed on a Tire Information Placard.

Check the Sprinter manual for the placard location. Front and rear pressures are

shown for each model and GVWR, and are based on the GVWR and front and

rear axle ratings (GAWRs) printed on your vehicle VIN plate and Certification

label. Tires must be inflated to these pressures when the vehicle is fully loaded

or an axle GAWR is reached.

C

Proper FRONT END ALIGNMENT improves tire tread mileage. Your front-end

C - 3

SPRINTER vAN

suspension parts should be inspected periodically and aligned when needed.

Improper alignment may or may not cause the vehicle to vibrate. However,

improper toe alignment will cause front tires to roll at an angle, which will result

in faster tire wear. Incorrect caster or camber alignment will cause your front

tires to wear unevenly and can cause the vehicle to “pull” to the left or right.

Vehicle Placard and Tire Inflation Pressure Label

The TIRE AND LOADING INFORMATION placard supplies information on the

size and the cold tire inflation pressure for the original equipment tires supplied

with your vehicle. Check the Sprinter manual for all weights and tire information

placard location.

A MOTORHOME TIRE SAFETY ADDENDUM is included with your

Airstream owner’s packet. Please take the time to read, understand, and

follow the information contained in the booklet.

PROPER TIRE INFLATION

The level of air in your tires affects your vehicle’s overall performance. Not

even the highest quality tire will perform well if it’s not inflated properly. The

correct pressure varies from vehicle to vehicle and depends in part upon driver

preference. Each vehicle has a recommended inflation pressure, usually found

on a placard. Check the Sprinter manual for all weights and tire information and

the placard location.

Correct tire inflation is a key component in tire care. The recommended inflation

pressures for your tires are indicated on the certification label or in your owner’s

manual. Since RVs can be loaded with many different configurations, the load

on each tire will vary. For this reason, air pressure should be checked based

on the load on each individual tire. Cold Inflation Pressure should be adjusted

to handle the maximum tire load, and all tires on the axle should carry the

same inflation pressure. COLD TIRE INFLATION PRESSURE is the tire pressure

checked in the morning before you drive more than a few miles or before rising

ambient temperatures or the sun’s radiant heat affects it. Check your tires’ air

pressures at least once a month, before each trip and each morning you drive

during a trip. Tire pressure should be checked cold, as tire pressure ratings

have been designed with typical running heat/pressure build-up in mind. Make

sure the valves and caps are free of dirt and moisture.

Under Inflation

Under inflation brings a higher risk of susceptibility to damage due to road

hazards, reduces tire casing durability, and causes a loss in fuel economy, plus

uneven or irregular tire wear. Severe under inflation brings about an increased

risk of tread separation, handling difficulties, and possibly tire failure, which is

C - 4CC - 5

SPRINTER vAN

caused by overheating.

IMPORTANT: It’s a common practice for RV owners to lower tire pressure in

their search for a smoother ride. This is not only dangerous, it’s relatively inef-

fective, and the difference in ride quality is not significant. When minimum

inflation pressure requirements are not met, tire durability and optimum operat-

ing conditions are compromised. Tire inflation pressure should always meet at

least the minimum guidelines for vehicle weight.

• Itmaybenecessarytoinateyourtiresatatruckstoportruck

service center in order to achieve adequate air pressure for your

coach's needs

• Onlypermanentairsealmetalvalvecapsshouldbeused.

• Besafe-ifatirehasbeenrun20%underinated,itmustbe

dismounted and inspected by a trained professional. It should not

be aired up without a full inspection or without using a safety cage.

Use a calibrated gauge. If your tire is rated for higher inflation pres-

sures, a special gauge will be required designed for larger tires.

• Don'tbleedairfromwarmtirestoreducepressurebuildup

• Don'tinatetirestocoldPSIratingbeyondrimspecications

HOW OVERLOADING AFFECTS YOUR TIRES

Tire pressure is what enables your RV tire to support loads. Overloading

your tires can have serious consequences for passengers and your RV. Too

much weight can cause stress on your RV’s suspension system, brake failure,

shock absorber damage, handling and steering problems, irregular tire wear

and possible tire failure. Excessive loads or under inflation can lead to an

excessive amount of heat and tire failure. If you discover that your tires can-

not handle the load, lighten the weight of the load on your tires.

TIRES and WHEELS (partially excerpted from the Sprinter Van Operator’s

Manual)

Check tires regularly for even tread wear; tread depth (note legal requirements)

and signs of external damage.

Use only wheels and tires of the same size, make and pattern.

Do not install tires that are not approved for the size and type of wheel installed

on the vehicle itself. Only use those wheel sizes that were delivered to you buy

your authorized Sprinter dealer.

C

Use only wheels and tires that have been tested and approved by the vehicle

C - 5

SPRINTER vAN













manufacturer.

Break in the tires at moderate speeds for distance of about 65 miles.

Warning: always replace wheel nuts that are damaged or

rusted. Never apply oil or grease to wheel nuts. Damaged wheel hub

threads should be repaired immediately. Incorrect mounting bolts or im-

properly tightened mounting bolts can cause the wheel to come off. This

could cause an accident. Be sure to use the correct mounting bolts.

Checked tightness of wheel nuts regularly and retighten if necessary.

After changing a wheel, the wheel nuts must be tightened once the vehicle has

been driven for about 30 miles.

If new or repainted wheels are fitted, the wheel nuts must be retighten again

after about 600 to 3000 miles.

Warning: Fitting wheel sizes other than those supplied by

Sprinter to the vehicle will change the Sprinter’s handling characteristics

and may lead to an accident resulting in severe personal injuries, death

and property damage.

Do not use remolded tires.

Tighten all wheel nuts evenly in the sequence indicated to

133 Lbf/ Ft. + or - 14 Lbf. /Ft with a torque wrench..

NOTE: Read the Sprinter manual for wheel torque and wheel tightening

procedures.

Tire Grip

Tire grip is greatly reduced on a wet or icy road. Speed and driving style must

therefore be adapted to suit road conditions. In winter, install M + S radial

tires. Below a tread depth of 1/8 in., tire grip begins to decrease rapidly on

wet roads.

Hydroplaning

Depending on the depth of the water layer on the road, hydroplaning may

occur, even at low speeds and with new tires. Reduce vehicle speed, avoid

grooves in the road, and apply brakes cautiously in the rain.

While we are on hydroplaning lets discuss driving in a flooded area. The major-

ity of flood-related deaths are caused by people attempting to drive through

C - 6CC - 7

SPRINTER vAN

moving water.

Ironically, many drivers rescued from flood waters report that they were in a

hurry to get home-- to safety -- as a reason for tempting the danger of driving

into water. However it looks, and despite what car commercials depict, driv-

ing into flood waters may be the most dangerous things one might ever try

considering the following:

Most cars will float (and be swept away) in 18-24 inches of moving water.

Trucks and SUVs are not much better with only 6-12 more inches of clearance.

Creeks and rivers can rise very rapidly and the road bottom can also wash

away making the water much deeper than it appears.

Once cars are swept downstream they will often roll to one side or perhaps flip

over entirely. The driver has a few precious seconds to escape the vehicle. In

fact, many drivers panic as soon as the vehicle submerges and are found later

with their seat belt intact.

Changing the Tire (partially excerpted from the Sprinter Van Operator’s

Manual)

Warning: The Sprinter Operator’s Manual contains important

cautions, warnings, specifications, and operational information on chang-

ing, maintaining, and replacing of the tires and wheels. Read, understand,

and follow the Sprinter manual sections for changing a tire.

CaUTiOn: Changing a tire on a motorhome chassis is a physi-

cally demanding procedure. It requires specialized tools and knowledge

of safety procedures. Only you can determine your knowledge base and

physical ability. Don’t take any unnecessary risks. You could turn an in-

convenience into a tragedy. Please find a safe area to park your unit, call

a tire service center and supply them with the information in the Sprinter

Manual if you have any doubts about changing a tire.

Flat Tire

If you get a flat tire while driving, gradually decrease your speed. Hold the

steering wheel firmly and slowly move to a safe place on the side of the road.

The pressure of the spare wheel always has to be checked regularly (at least

after every tenth time at the filling station).

The vehicle tool kit and the jack are located in a hatch under the front pas-

senger foot well.

C

C - 7

SPRINTER vAN

Warning: The jack is designed exclusively for jacking up the

vehicle at the jack take-up brackets built into either side of the vehicle.

To help avoid personal injury, use the jack only to lift the vehicle during a

wheel change. Never get beneath the vehicle while it is supported by the

jack.

Precautions when changing a wheel:

• Keephandsandfeetawayfromtheareaunderthelifted

vehicle.

• Alwaysrmlysetparkingbrakeandblockwheelsbeforerais-

ing vehicle with jack.

• Donotdisengageparkingbrakewhilevehicleisraised.

• Alwaysusethejackonalevelsurface.

• Donotjackthevehicleupmorethan1.2inchesbetweenthe

tire and the surface. Otherwise, the vehicle may tip over and

may cause serious injury or death to you or others.

• Besurethatthejackarmisfullyseatedinthejacktake-up

bracket.

• Alwayslowerthevehicleontosufcientcapacityjackstands

before working under the vehicle.

• Donotdamage,grease,oroilwheelnutsorstudthreads.

Procedure:

• Parkthevehicleonarm,level,non-slipperysurface.

• Switchonthehazardwarningasherswitch,applytheparking

brake, and place the transmission selector in “P”.

• Everyonemustleavethevehiclebeforeyoujackitup.

• Everyonemustleavethedangerzone,beforejackingthevehicle.

Danger zones vary with locations. Take a minute and look at what

might happen if the vehicle falls off the jack and rolls. Set up your

danger zone.

• Thevehiclemustbesafeguardedinaccordancewithlegalregula-

tions (such as using a warning triangle).

• Preventvehiclefromrollingawaybyblockingwheelswithwheel

chocks (not supplied with vehicle) or sizable woodblocks or stone.

On a level road place one chock in front of and one behind the

wheel that is diagonally opposite to the wheel being changed.

When changing a wheel on mild uphill or downhill grade, place

chocks on the downhill side blocking both wheels of the other axle.

Do not jack vehicle up on a steep grade.

Warning: Do not change wheels on a steep uphill or downhill

grade. The vehicle may begin to move and fall from the jack, which could

cause property damage, personal injury and/or death.

C - 8CC - 9

SPRINTER vAN

Spare Tire Carrier

Airstream remounts the spare tire and installs the spare tire winch assembly.

The spare tire is located under the rear of the motorhome against the bottom of

the chassis floor structure .

Floor

Tire

Blocks

Yoke w/pins

A winch mounted under the rear floor is used to lower and raise the spare tire.

The winch has a nut sticking up through the floor under the center rear lounge

on the rear lounge model accessed by opening the rear cargo doors. The nut

is located inside the roadside bed on the twin bed model and is accessed by

opening the bed storage door. To remove the spare tire, use the ratchet and a

19MM or 22MM deep well socket located in the tire replacement bag under the

passenger side compartment floor to turn the winch nut counter clock wise.

Place blocks under the tire before it reaches the ground to block the tire up and

remove the weight from the yoke, then slide the yoke through the rim, and slide

the tire from under the motorhome.

Nut

Winch

Cable

Ground

Wheel lug pins

Wheel lug pins

Winch Tire Yoke

To store a spare tire reverse the removal instructions. The winch tire yoke has

two pins that align with the wheel rim lug holes. The yoke pins must be placed

in the lug holes to prevent the wheel assembly from sliding against the cable

during transit and possibly cutting it. Be sure wheel is turned on the correct

side so pins will fully engage the lug holes. The side of the rim that goes against

the hub goes against the floor.

C

nOTiCE: Spare tire carrier winch is designed for hand operation only. Do

not use impact type power tools to drive this device.

Warning: Defective spare tire equipment or an improperly stored spare

tire could damage your equipment and/or cause serious, possible fatal in-

juries to people inside your motorhome, other motorists and pedestrians.

The yoke pins must be inserted into the spare tire lug holes while wheel

is in the store position during travel. The cable and support system must

be free from defects and in good working order. The complete system

should be checked before each trip and every 1000 miles during a trip

for any signs of wear or possible failure. Please contact your dealer or

Airstream Customer Service if you have any questions on the use of this

equipment.

C - 9

SPRINTER vAN

JACK

Read, understand, and follow the Sprinter operator's manual instructions, cau-

tions, and warnings for changing a wheel and jack point locations.

Warning: The jack is intended only for raising the vehicle

briefly, for instance when changing a wheel. The jack must be placed on

a firm, flat surface only. Do not change wheels on either uphill or downhill

grades. Do not crawl under the vehicle while raised with jack. Do not start

the engine while the vehicle is jacked up. Do not jack the vehicle up more

than 1.2 inches between the tire and the surface. Otherwise, the vehicle

may tip over and may cause serious injury or death to you or others. Jack

stands must always be used while working beneath the vehicle. Failure to

follow these precautions could result in property damage, personal injury

and/or death.

The jack is located together with vehicle tool kit under the hatch in the front

passenger foot well.

• Loosenthewheelnutsbeforeraisingthevehicle.

• Closethereleasevalveonthejack.

• Assemblethepumpleverprovidedandinsertitintothesocketon

the jack.

• Secureleverbyturningitclockwiseinthesocket.

• Positionthejackundertheappropriatejackpointandraisethe

vehicle by pumping the lever.

WHEEL SIMULATORS

Front Wheel Simulators

Hook

The wheel simulators are installed by Airstream.

Removing The Front Wheel Simulator: Loosen the 3 Phillips head screws until

the hook mounts disengage from the rim oval hand holes.

Installing Front Wheel Simulator

Step 1: Line up the mounting hooks on the back of the wheel simulator with

the oval hand holes of the wheel. Note: It is recommended not to use the oval

hole by the valve stem for the mounting hooks. Then gently push the wheel

simulator against the wheel until one of the hooks engage into one of the wheel

Screw

C - 10CC - 11

SPRINTER vAN

hand holes. Then continue one at a time engaging each hook into the other

hand holes. Note: You may have to loosen the Phillips head screws a little

before all the hooks will engage.

Step 2. Proper Engagement And Tightening

Make sure all the hooks have engaged into the proper hand holes of the wheel.

Next, begin alternating tightening each Phillips head screw a few turns. Very

Important: Look into the holes of the simulator where the hooks are and see

that the hooks are engaged onto the center portion of the wheel oval hand

holes. Next, carefully feel with your fingers through the holes in the simulator,

to make sure the mounting hooks are fully engaged onto the center of the

oval hand holes. As you continue alternating tightening each hook, keep your

fingers in the oval holes of the simulator where you’re tightening to make sure

the hook stays engaged and in the center of the wheel oval hand holes.

Step 3. Verify Wheel Simulator Is Centered On Wheel

At this point stop alternating tightening the Phillips head screws, and check to

see that the simulator is being tightened evenly all the way around the simulator

and rim. Also check that the hand holes of the simulator align with the wheel

hand holes. Slide your hands around the edge of the simulator and rim, making

sure the simulator is evenly spaced all the way around the rim. If it’s not even,

you may have to loosen the screws and readjust the simulator so that it is

centered around the rim and the hand holes align, then repeat the tightening

procedure in Step 2.

Step 4. Final Tightening Of Wheel Simulator

After final checking that the hooks are engaged into the center of the hand

holes of the wheel and the simulator is evenly spaced and true all the way

around the rim, then continue to alternate tightening the Phillips head screws

until the simulator is securely tightened to the wheel.

Rear Wheel Simulators

The rear simulators have two brackets fastened to the axle cover plate by the

axle nuts. The brackets each have one threaded hole. The simulator is fastened

to the brackets by two Philip head screws.

To remove a rear simulator, loosen and remove the two screws.

To install a rear simulator:

Place wheel simulator onto the wheel making sure to line the holes in the

simulator with the threaded holes of the mounting brackets. Then thread two

C

C - 11

SPRINTER vAN

Phillips head screws through the simulator and into the threaded holes of the

mounting brackets and tighten securely.

nOTiCE: After reinstallation, the WHEEL SIMULATOR mounting system

will seat itself into the wheel. After the first 100 miles check that the

simulators are tight and secure to the wheels. If necessary, retighten the

mounting screws. We recommend that the wheel simulators are checked

and inspected periodically to make sure that they are tight and secure to

the wheels.

Removing a Wheel

Remove Wheel simulator if so equipped.•

Loosen the wheel nuts.•

Jack up the vehicle until the wheel is clear of the ground.•

Unscrew the wheel nuts and remove the wheel (keep the wheel nuts •

clean).

NOTE: If the vehicle moves forwards or backwards while it is being jacked up,

lower it, stabilize the vehicle, and repositioned the jack. When the vehicle is

jacked up, the jack must stand vertically (plumb-line).

INSTALLING A WHEEL

Mounting The New wheel

• Beforettingthesparewheel,cleanrustanddirtoffthecontact

services of the wheel and the wheel hub, and from the wheel nuts.

• Notethespeciedwheelandtiresize,tireloadcapacityandspeed

code.

• Donotchangethetire'sdirectionofrotation.

• Donotdamage,grease,oroilwheelnutsortheirthreads.

Centering wheels with wheel nuts

• Ifdualassembliesareused,beforeplacement,theinnerwheel

should be inspected to ensure that all ball bearing rings are in

proper position.

• Installthewheelandsnugthewheelnuts.

• Slightlytightenwheelnuts.

Lowering the Vehicle

• Slowlyopenedjackreleasevalvetolowervehicleuntiltireis

resting on ground.

• Tightenthewheelnutsinacrosswisepatterntothespeciedto

work with a torque wrench. For tire pressure & Wheel bolt torque

procedures: See Sprinter Van Operator’s Manual.

C - 12CC - 13

SPRINTER vAN













• Removejackandstowitinthevehicletoolkit.

• Checkthetirepressure,fortirepressuresseeSprinteroperator's

manual.

• Retightenthewheelnutstothespeciedtorquewithatorque

wrench after a distance of approximately 30 miles.

Warning: Only certain tires meeting the tire size/load/speed

index ratings contained in the Tire Pressure Tables, to be found from the

Index Section of the Sprinter’s Operators or Owners Manual, are certi-

fied to conform to FMVSS 120 for the Sprinter Vehicle at this time. Please

check your sidewalls of your originally equipped tires for specific makes/

sizes, and speed load ratings when you need to replace your tires. To

prevent accident, injury or possible death, use only the correct tires for

your tire replacement.

Wheel Bolt Tightening

IMPORTANT! Consult the Sprinter Operators manual

for extensive wheel tightening and wheel torque pro-

cedures, cautions, and warnings.

Tighten all wheel nuts evenly in the crosswise se-

quence indicated.

Warning: For safety reasons, the wheel tightening torque

must be checked immediately after changing a tire and again after 30

miles to 133 Lbf/ Ft. + or - 14 Lbf. /Ft. The wheels could otherwise come

loose.

TIRE ROTATION

Front and rear tires perform different jobs and can wear differently depending

on the types of roads driven, your driving habits, etc. To obtain the longest tire

life you should INSPECT AND ROTATE your tires regularly.

C

Many automotive dealers and tire dealers will perform a free tire inspection to

look for uneven or abnormal tire wear.

C - 13

SPRINTER vAN

Tires should be rotated every 6,000 to 8,000 miles. For the longest tire life, any

time irregular wear is seen have the tires checked, alignment checked, and tires

rotated by your truck or tire dealer. Have the cause of uneven wear corrected.

Rotation pattern for single and dual rear wheels.

Front

Rear

NOTICE: Read Sprinter manual for complete instruction on tire rotation,

installation, and maintenance.

Vehicles with aluminum alloy wheels may requires tires to dismounted and

remounted so as to leave rims in original locations.

Front

Rear

SUPPORT

Since motorhomes may sit for long periods it is important to properly support

the tires if blocks are used for leveling.

Extreme caution must be taken to ensure that the tires are fully supported

when using blocks to level motorhomes. The load on the tire should be evenly

distributed on the block and in the case of duals, evenly distributed on blocks

for both tires. If not property done, the steel cables in the sidewall of the tires

may be damaged and could lead to premature fatigue of the sidewall.

CORRECT

Singles

Tire Foot Print

Dual Tire Foot Print

Duals

C - 14CC - 15

Figure 1

The CORRECT methods are shown in Figure 1. A single tire or dual tires

are supporting the full load. Please note that the blocks are wider than the

tread and longer than the tire’s footprint. This provides maximum support to

the tires and assures that the load is evenly distributed throughout the tire’s

footprint area.

INCORRECT

SPRINTER vAN

Warning: Tires that are incorrectly supported may be dam-

aged which could lead to casing failure resulting in serious injury or

property damage. If, on previous occasions, the tires have been incor-

rectly supported, a hidden damage may be present. Please contact your

local tire dealer and request an inspection and a determination of possible

damage.

C

INCORRECT methods are shown in figure 2: One tire, a portion of one tire, or

portions of two tires are supporting the full load.

Figure 2

Auminum Wheels (Option)

Alcoa Dura-Bright® Wheel Finish Care and Maintenance

1. Clean frequently with high-pressure water from a hose. The use of a mild

detergent will speed the cleaning process. Do not clean with abrasives, abra-

sive brushes, steel wool, scouring pads or strong chemicals, such as acids or

alkaline products. Never spray cold water on extremely hot wheels. Always

allow time to cool before cleaning.

2. When tires are removed, the entire wheel must be cleaned and inspected.

With a brush, remove any foreign products from the tire side of the wheel

(portion of the wheel that supports the tire). Do not use an abrasive brush to

remove dirt, corrosion or other foreign products from the Dura-Bright® wheel

surfaces. It is recommended to generously coat the entire air chamber surface

C - 15

SPRINTER vAN

with an approved surface protectant and lubricate each time the tire is removed

(see the recommendations in the Alcoa Technical Data brochure).

3. To maintain the original appearance of your Alcoa Dura-Bright® wheels, the

following procedures are recommended:

a. After installing new wheels and prior to operating your vehicle,

C

use a sponge or cloth to wash exposed wheels surfaces with a mild

detergent and warm water. Do not use abrasives, abrasive brushes,

steel wool, scouring pads or strong chemicals (such as acids or

alkaline products). Standard off-the-shelf car wash and wheel

detergents are sufficient. Warm water and a mild detergent will

speed the cleaning process.

b. Rinse thoroughly with clean water.

c. Wipe dry to avoid water spots.

d. Clean your Alcoa Dura-Bright® wheels, using the above

procedures, on a regular basis to avoid sticking or encrusting

of the disc brake dust.

Typical road soils, grime and brake dust trap moisture, which can cause corro-

sion over a period of time. These must be removed regularly. If not, disc brake

dust can encrust. To assist in the removal of excessive dust, dirt and road grime,

the use of warm, high-pressure water with a mild detergent is recommended.

The surface of Alcoa Dura-Bright® wheels will be damaged, discolored or

removed if abrasives, abrasive brushes, steel wool, scouring pads or strong

chemicals (such as acids or alkaline products) are used to clean the wheel. DO

NOT USE the Alcoa cleaning products (ALclean, ALbrush, ALpolish and

ALfinish) on Dura-Bright® wheels at any time during their service life.

4. Once in service, Dura-Bright® wheels can become nicked or scratched by

road debris and/or mechanical damage. If this occurs, continue to follow the

normal washing and cleaning instructions provided above. The surface of an

Alcoa Dura-Bright® wheel is designed to limit cracking and peeling if nicked or

scratched while in service.

5. Even as durable as Dura-Bright® wheels are, the mounting area can become

scratched, marred or discolored when mounted against another wheel, hub or

drum. The use of a wheel mounting surface guard, such as Alcoa DiscMatesTM,

is recommended.

C - 16

SAFETY

Emergency Exit

There are three avenues of escape from the motorhome in the event of an

emergency, the driver’s door, the passenger door, and the sliding side cargo

door. As always, safety should be one of your top priorities. Make sure you, and

everyone traveling with you, can operate these doors and exit rapidly without

light. A little planning and a quick practice session at each camping site is well

worth the time it may take.

CAMPING

Warnings:

DON’T SMOKE IN BED!

KEEP MATCHES OUT OF REACH OF SMALL CHILDREN!

DON’T CLEAN WITH FLAMMABLE MATERIAL!

KEEP FLAMMABLE MATERIAL AWAY FROM OPEN FLAME!

We have all heard these warnings many times,

but they are still among the leading causes of fires.

D

Warning: At each campsite make sure you have not parked

in such a manner as to block the operation of the doors or the escape

avenues by being too close to trees, fences or other impediments. Scenic

views are one reason for traveling, but don’t park so the beautiful lake or

steep cliff is just outside your doors. Do not block access to the doors

from the inside or outside of the vehicle.

Warning: Read the directions carefully on the fire extin-

guisher. If there is any doubt on the operation, you and your family should

practice, then replace or recharge the extinguisher. You will find your local

fire department will be happy to assist you and answer any questions.

Other safety information on the LPG system of your motorhome is located in

the Plumbing Section of this manual.

D - 1

CAMPING

SMOKE ALARM/CARBON MONOXIDE DETECTOR

Manufacturer: First Alert

Model SCO5RVA

UNITED STATES

BRK Brands, Inc.

3901 Liberty Street Road

Aurora, Illinois 60504

For consumer inquiries call: 800-323-9005

CANADA

Dicon Global, Inc.

20 Steelcase Road. West, Unit #3

Markham, Ontario.

L3R 1B2

Tel: [phone]

Fax [phone]

For consumer inquires call: 800-323-9005

IMPORTANT! Dangers, Warnings, and Cautions alert you to important

operating instructions or to potentially hazardous situations. Pay special

attention to these items.

Parts of this section on the Smoke Alarm/Carbon Monoxide Detector are a

reprint of the manual included with each device and provided to you in the

Airstream owner’s briefcase. Please read, understand, and follow all aspects of

the complete manual before activating and operating the Smoke Alarm/Carbon

Monoxide Detector. If you have not received the manual, use the appropri-

ate contact information above to obtain one or contact Airstream Customer

Relations at 937-596-6111.

Features:

• Separate sensors to detect smoke and CO; the two alarm systems work

independently

•Poweredbytwo“AA”batteries

•Sideaccessdrawerforeasybatteryreplacement

Warning: Have a professional technician check all safety

related systems yearly or whenever any doubts of their ability to function

properly arise.

FIRE SAFETY TIPS

Follow safety rules and prevent hazardous situations: 1) Use smoking materials

properly. Never smoke in bed. 2) Keep matches or lighters away from children;

D - 2DD - 3

CAMPING

3) Store flammable materials in proper containers; 4) Keep electrical appliances

in good condition and don’t overload electrical circuits; 5) Keep stoves and

barbecue grills grease and debris free; 6) Never leave anything cooking on

the stove unattended; 7) Keep portable heaters and open flames, like candles,

away from flammable materials; 8) Don’t let rubbish accumulate.

Keep alarms clean, and test them weekly. Replace alarms immediately if they

are not working properly. Smoke Alarms that do not work cannot alert you to

a fire. Keep at least one working fire extinguisher in your RV, and an additional

one in the kitchen. Have fire escape ladders or other reliable means of escape

from an upper floor in case stairs are blocked.

Warning: Smoke and Carbon Monoxide Alarm is shipped

with batteries deactivated. Ask dealer to activate batteries or activate

batteries immediately upon delivery. Failure to follow warning will remove

your protection.

Battery Activation

To activate battery pull labeled clear plastic tan from device. If tab was previ-

ously removed, test batteries and replace as needed.

BASIC SAFETY INFORMATION

CaUTiOn: This combination Smoke/Carbon Monoxide Alarm

has two separate alarms. The CO Alarm is not designed to detect fire or

any other gas. It will only indicate the presence of carbon monoxide gas

at the sensor. Carbon monoxide gas may be present in other areas. The

Smoke Alarm will only indicate the presence of smoke that reaches the

sensor. The Smoke Alarm is not designed to sense gas, heat or flames.

Warnings:

• This Smoke/CO Alarm cannot operate without working batteries.

Removing the batteries for any reason, or failing to replace the batteries

at the end of their service life, removes your protection.

• NEVER ignore any alarm. See “If Your Smoke/CO Alarm Sounds” for

more information on how to respond to an alarm. Failure to respond can

result in injury or death.

•TheSilenceFeaturesareforyourconvenienceonlyandwillnotcorrecta

problem.See“UsingtheSilenceFeatures”fordetails.Alwayscheckyour

home for a potential problem after any alarm. Failure to do so can result

in injury or death.

•TestthisSmoke/COAlarmonce a week. If the Alarm ever fails to test

D

D - 3

CAMPING

correctly, have it replaced immediately! If the Alarm is not working prop-

erly, it cannot alert you to a problem.

•This product is intended foruse in ordinary indoor locations offamily

living units. It is not designed to measure CO levels in compliance with

Occupational Safety and Health Administration (OSHA) commercial or

industrial standards. Individuals with medical conditions that may make

them more sensitive to carbon monoxide may consider using warning

devices which provide audible and visual signals for carbon monoxide

concentrations under 30 ppm. For additional information on carbon mon-

oxide and your medical condition contact your physician.

Warning: Test Units in your RV after the vehicle has been in

storage, before each trip, and at least once a week while in use. Failure to

test units used in RVs as described may remove your protection.

Horn Pattern Selection For Smoke Alarm

When the alarm detects smoke, the default horn pattern is 3 beeps, pause, 3

beeps. To manually change the horn pattern to 6 beeps, pause, 6 beeps: open

the battery drawer (with batteries installed) , press and hold the test button

down and then close the battery drawer.

To return to the default horn pattern of 3 beeps, pause, 3 beeps; open the

battery drawer and then close the battery drawer.

In the U. S. the horn pattern is 3 beeps, pause, 3 beeps.•

In Canada the horn pattern is 6 beeps, pause, 6 beeps•

Always test the alarm to verify the horn pattern for your area.

NOTE: see the First Alert User’s Manual for information on optional locking

features.

WEEKLY TESTING

Warnings:

•NEVER use an open ameofany kind to test thisunit. Youmight ac-

cidentally damage or set fire to the unit or to your home. The built-in test

switch accurately tests the unit’s operation as required by Underwriters

Laboratories, Inc. (UL). NEVER use vehicle exhaust! It may cause perma-

nent damage and voids your warranty.

•DONOTstandclosetotheAlarmwhenthehornissounding.Exposure

at close range may be harmful to your hearing. When testing, step away

when horn starts sounding.

D - 4DD - 5

CaUTiOn: It is important to test this unit every week to make

sure it is working properly. Using the test button is the recommended way

to test this Smoke/CO Alarm.

Test this Smoke/CO Alarm: Press and hold the Test/Silence button 3-5 sec-

onds until unit starts to alarm.

During testing, you will see and hear the following sequence:

The • Horn will sound 3 beeps, pause, 3 beeps. The Power/Smoke LED

flashes Red and the CO LED will be Off. NOTE: For Canada the horn will

sound 6 beeps, pause, 6 beeps. The Power/Smoke LED flashes Red and

the CO LED will be Off.

Next the Horn will sound 4 beeps, pause, 4 beeps. The• Power/Smoke

LED will be Off and the CO LED flashes Red.

If the unit does not alarm, make sure the batteries are correctly installed and

test again. If the unit still does not alarm, replace it immediately.

CAMPING

Parts Of This Smoke/CO Alarm

2

Test/Silence Button1.

Battery Compartment2.

Power/Smoke Alarm LED3.

CO Alarm LED4.

REGULAR MAINTENANCE

This unit has been designed to be as maintenance-free as possible, but there

are a few simple things you must do to keep it working properly. Use only

the replacement batteries listed below. The unit may not operate properly with

other batteries. Never use rechargeable batteries since they may not provide

a constant charge.

•Testitatleastonceaweek.

•CleantheSmoke/COAlarmatleastonceamonth;gentlyvacuumtheoutside

of the Smoke/CO Alarm using your household vacuum’s soft brush attach-

ment. A can of clean compressed air (sold at computer or office supply stores)

may also be used. Follow manufacturer instructions for use. Test the Smoke/

CO Alarm once a week. Never use water, cleaners or solvents since they may

damage the unit.

•IftheSmoke/COAlarmbecomescontaminatedbyexcessivedirt,dustand/

1

4

3

D

D - 5

CAMPING

or grime, and cannot be cleaned to avoid unwanted alarms, replace the unit

immediately.

• Relocate the unit if it sounds frequent unwanted alarms.See “Where This

Alarm Should Not Be Installed” for details.

Choosing a replacement battery:

Your Smoke/CO Alarm requires two standard AA batteries. It was shipped

with two AA batteries. The following batteries are acceptable as replacements:

Eveready Energizer E91. These batteries are available at many local

retail stores.

IMPORTANT!

Actual battery service life depends on the Smoke/CO Alarm and the environ-

ment in which it is installed. All the batteries specified above are acceptable

replacement batteries for this unit. Regardless of the manufacturer’s suggested

battery life, you MUST replace the battery immediately once the unit starts

“chirping” (the “low battery warning”).

To replace the batteries (without removing Alarm from the ceiling or wall):

1. Open the battery compartment.

2. Press tabs A and B as shown in the diagram and remove each battery.

3. Insert the new batteries, making sure they snap

completely into the battery compartment. Match

the terminals on the ends of the batteries with the

terminals on the unit.

4. Close the battery compartment, and then test the

unit by pressing the Test/Silence button.

B

A

Warning: The battery door will resist closing unless batter-

ies are installed. This warns you that the unit will not operate without

batteries.

IF YOUR SMOKE/CO ALARM SOUNDS

WHAT TO DO FIRST - IDENTIFY THE TYPE OF ALARM

Type of Alarm What You See and Hear

Carbon Monoxide (CO) CO LED: Flashes Red

Horn: 4 beeps, pause, 4 beeps, pause.

Power/Smoke LED: Off.

Smoke Power/Smoke LED: Flashes Red

Horn: (US) 3 beeps, pause, 3 beeps, pause.

Horn: (Canada) 6 beeps, pause, 6 beeps, pause.

CO LED: Off.

D - 6DD - 7

CAMPING

If The CO Alarm Sounds

dangEr: Actuation of your CO Alarm indicates the presence

of carbon monoxide (CO) which can kill you. In other words, when your CO

Alarm sounds, you must not ignore it!

1. Operate the Test/Silence button.

2. Call your emergency services, fire department or 911. Write down the num-

ber of your local emergency service here:

__________________________________________________________________

3. Immediately move to fresh air—outdoors or by an open door or window. Do

a head count to check that all persons are accounted for. Do not reenter the

premises, or move away from the open door or window until the emergency

services responder has arrived, the premises have been aired out, and your CO

Alarm remains in its normal condition.

4. After following steps 1-3, if your CO Alarm reactivates within a 24-hour

period, repeat steps 1-3 and call a qualified appliance technician to investigate

for sources of CO from fuel-burning equipment and appliances, and inspect

for proper operation of this equipment. If problems are identified during this

inspection have the equipment serviced immediately. Note any combustion

equipment not inspected by the technician, and consult the manufacturers’

instructions, or contact the manufacturers directly, for more information about

CO safety and this equipment. Make sure that motor vehicles are not, and have

not, been operating in an attached garage or adjacent to the residence. Write

down the number of a qualified appliance technician here:

____________________________________________________________________

“ALARM-MOVETOFRESHAIR”

If you hear the CO alarm horn and the CO red light is flashing, move

everyone to a source of fresh air. DO NOT remove the batteries!

IF THE SMOKE ALARM SOUNDS

RESPONDING TO AN ALARM

dangEr:

If the unit alarms and you are not testing the unit, it is warning you of •

a potentially dangerous situation that requires your immediate atten-

tion. NEVER ignore any alarm. Ignoring the alarm may result in injury

or death.

Never remove the batteries from a battery operated Smoke/CO •

Alarm to stop an unwanted alarm (caused by cooking smoke, etc.).

Removing batteries disables the alarm so it cannot sense smoke, and

D

D - 7

CAMPING

removes your protection. Instead open a window or fan the smoke

away from the unit. The alarm will reset automatically.

If the unit alarms get everyone out of the motorhome immediately.•

WHAT TO DO IN CASE OF FIRE

Don’t panic; stay calm. Follow your family escape plan.•

Get everyone out of the motorhome as quickly as possible. •

Don’t stop to get dressed or collect anything.

Feel doors with the back of your hand before opening them. If a •

door is cool, open it slowly. Don’t open a hot door. Keep doors

and windows closed, unless you must escape through them.

Cover your nose and mouth with a cloth (preferably damp). Take •

short, shallow breaths.

Meet at your planned meeting place outside your motorhome, •

and do a head count to make sure everybody got out safely.

Call the Fire Department as soon as possible from outside. Give •

your address, then your name.

Never go back inside a burning motorhome for any reason.•

Contact your Fire Department for ideas on making your moto-•

rhome safer.

DEVELOP AND PRACTICE A PLAN OF ESCAPE:

• Makeaoorplanindicatingalldoorsusedasescaperoutes

from the motorhome.

• Haveafamilymeetinganddiscussyourescapeplan,showing

everyone what to do in case of fire.

• Ateachcampgrounddetermineaplaceoutsideyourmotor-

home where you all can meet if a fire occurs.

• FamiliarizeeveryonewiththesoundoftheSmokeAlarmand

train him or her to leave your motorhome when they hear it.

• Practicearedrillatleasteverysixmonthsorwhenever

new guests are with you. Practice allows you to test your

plan before an emergency; you may not be able to reach your

children or may be visiting a fellow camper while they sleep. It

is important they know what to do.

Alarms have various limitations. See “General Limitations of Smoke/CO Alarms”

for details.

D - 8DD - 9

CAMPING

USING THE SILENCE FEATURES

Warning: Never remove the batteries to quiet an unwanted

alarm. Removing the batteries disables the alarm and removes your pro-

tection. Do not use the Silence Feature in emergency situations. It will not

correct a CO problem or extinguish a fire.

The Silence Feature is intended to temporarily silence the horn while you

identify and correct the problem. The Silence Feature can temporarily quiet

an unwanted alarm for several minutes. Press the Test/Silence button on the

alarm cover for at least 3-5 seconds. After the Test/Silence button is released,

the Red LED blinks during the silence mode.

SILENCING THE LOW BATTERY WARNING

This silence feature can temporarily quiet the low battery warning “chirp” for

up to 8 hours. You can silence the low battery warning “chirp”: press the Test/

Silence Button on the alarm cover.

Once the low battery warning “chirp” silence feature is activated, the unit con-

tinues to flash the Green light twice a minute for 8 hours. After 8 hours, the low

battery “chirp” will resume. Replace the batteries as soon as possible; this

unit will not operate without battery power!

To deactivate this feature: Press the Test/Silence button again. The unit will

go into Test Mode and the low battery warning will resume (LED flashes and

unit sounds “chirp” once a minute).

WHAT YOU NEED TO KNOW ABOUT CARBON MONOXIDE (CO). WHAT IS

CO?

CO is an invisible, odorless, tasteless gas produced when fossil fuels do not

burn completely, or are exposed to heat (usually fire). Electrical appliances typi-

cally do not produce CO.

D

These fuels include: Wood, coal, charcoal, oil, natural gas, gasoline, diesel,

kerosene, and liquid propane.

D - 9

CAMPING

Common appliances are often sources of CO. If they are not properly main-

tained, are improperly ventilated, or malfunction, CO levels can rise quickly. CO

is a real danger now that homes are more energy efficient. “Air-tight” homes

with added insulation, sealed windows, and other weatherproofing can “trap”

CO inside.

SYMPTOMS OF CO POISONING

These symptoms are related to CO POISONING and should be discussed with

ALL household members.

Mild Exposure: Slight headache, nausea, vomiting, fatigue (“flu-like” symp-

toms).

Medium Exposure: Throbbing headache, drowsiness, confusion, fast heart

rate.

Extreme Exposure: Convulsions, unconsciousness, heart and lung failure.

Exposure to Carbon Monoxide can cause brain damage, death.

Important!

extremely high in a short period of time, or if CO levels reach a certain minimum

over a long period of time. The CO Alarm generally sounds an alarm before the

onset of symptoms in average, healthy adults. Why is this important? Because

you need to be warned of a potential CO problem while you can still react

in time. In many reported cases of CO exposure, victims may be aware that

they are not feeling well, but become disoriented and can no longer react well

enough to exit the building or get help. Also, young children and pets may be

the first affected. The average healthy adult might not feel any symptoms when

the CO Alarm sounds. However, people with cardiac or respiratory problems,

infants, unborn babies, pregnant mothers, or elderly people can be more

quickly and severely affected by CO. If you experience even mild symptoms of

CO poisoning, consult your doctor immediately!

FINDING THE SOURCE OF CO AFTER AN ALARM

Carbon monoxide is an odorless, invisible gas, which often makes it difficult to

locate the source of CO after an alarm. These are a few of the factors that can

make it difficult to locate sources of CO:

Motorhome well ventilated before the investigator arrives.•

Problem caused by “backdrafting.”•

Transient CO problem caused by special circumstances.•

This CO Alarm measures exposure to CO over time. It alarms if CO levels are

D - 10DD - 11

CAMPING

POTENTIAL SOURCES OF CO IN THE RECREATIONAL VEHICLE

Fuel-burning appliances like: a portable heater, gas kitchen range or cook

top, furnace, hot water heater.

Damaged or insufficient venting: corroded or disconnected water heater vent

pipe, leaking or damage furnace vent, or cracked heat exchanger, blocked or

clogged appliance vents.

Improper use of appliances/device: operating fuel burning appliances or

vehicle in an enclosed area (like a garage or screened porch).

Transient CO Problems: “transient” or on-again-off-again CO problems can

be caused by outdoor conditions and other special circumstances.

The following conditions can result in transient CO situations:

1. Excessive spillage or reverse venting of fuel appliances caused by outdoor

conditions such as:

Wind direction and/or velocity, including high, gusty winds. •

Heavy air in the vent pipes (cold/humid air with extended peri-

ods between cycles).

Negative pressure differential resulting from the use of exhaust •

fans.

Several appliances running at the same time competing for •

limited fresh air.

Vent pipe connections vibrating loose from the furnace, water •

heater or other fuel burning appliances.

Obstructions in or unconventional vent pipe designs which can •

amplify the above situations.

2. Extended operation of non vented fuel burning devices (cooktop).

3. Temperature inversions, which can trap exhaust close to the ground.

4. Motorhome idling in an open or closed attached garage, or near a home.

These conditions are dangerous because they can trap exhaust in your moto-

rhome.

Since these conditions can come and go, they are also hard to recreate during

a CO investigation.

HOW CAN I PROTECT MY FAMILY FROM CO POISONING?

A CO Alarm is an excellent means of protection. It monitors the air and sounds

a loud alarm before Carbon Monoxide levels become threatening for average,

healthy adults.

D

D - 11

CAMPING

A CO Alarm is not a substitute for proper maintenance of home appli-

ances.

To help prevent CO problems and reduce the risk of CO poisoning:

Clean appliance vents yearly. Keep them free of debris, leaves, •

and nests for proper air flow. Also, have a professional check for

rust and corrosion, cracks, or separations. These conditions can

prevent proper air movement and cause back drafting. Never

“cap” or cover a vent in any way that would block air flow.

Test and maintain all fuel-burning equipment annually. Most RV •

service centers offer appliance inspections for a nominal fee.

Make regular visual inspections of all fuel-burning appliances. •

Check appliances for excessive rust and scaling. Also check

the flame on the burner and pilot lights. The flame should be

blue. A yellow flame means fuel is not being burned completely

and CO may be present. Keep the blower door on the furnace

closed. Use vents or fans when they are available on all fuel-

burning appliances. Make sure appliances are vented to the

outside. Do not grill or barbecue indoors, or in garages or on

screen porches.

Check for exhaust back flow from CO sources. Check the draft •

hood on an operating furnace for a back draft. Look for cracks

on furnace heat exchangers.

Check the RV beside you at a campground. CO can come in an •

open window or vent

Keep windows and doors open slightly. If you suspect that CO •

is escaping into your motorhome, open a window or a door.

Opening windows and doors can significantly decrease CO

levels.

•

GENERAL LIMITATIONS OF SMOKE/CO ALARMS

Smoke/CO Alarms may not waken all individuals. Practice the escape plan

before every excursion and with all newcomers to the vehicle, making sure that

everyone is involved. Allow children to master fire escape planning and practice

before holding a fire drill at night when they are sleeping. If children or others do

not readily waken to the sound of the Smoke/CO Alarm, or if there are infants or

family members with mobility limitations, make sure that someone is assigned

to assist them in a fire drill and in the event of an emergency. It is recommended

that you hold a fire drill while family members are sleeping in order to determine

their response to the sound of the Smoke/CO Alarm while sleeping and to

determine whether they may need assistance in the event of an emergency.

Smoke/CO Alarms cannot work without power. Battery operated units can-

not work if the batteries are missing, disconnected, or dead, if the wrong type

of batteries are used, or if the batteries are not installed correctly. AC units

D - 12DD - 13

CAMPING

cannot work if the AC power is cut off for any reason (open fuse or circuit

breaker, failure along a power line or at a power station, electrical fire that burns

the electrical wires, etc.). If you are concerned about the limitations of battery

or AC power, install both types of units.

This Smoke/CO Alarm will not sense smoke or CO that does not reach

the sensors. It will only sense smoke or CO at the sensor. Smoke or CO may

be present in other areas. Doors or other obstructions may affect the rate at

which CO or smoke reaches the sensors. Consider installing another alarm

device (Combination CO and Smoke Alarm, or separate CO Alarms and Smoke

Alarms) if you habitat areas you believe need protection.

Smoke/CO Alarms may not be heard. The alarm horn loudness meets or

exceeds current UL standards of 85 dB at 10 feet (3 meters). However, the

Smoke/CO Alarm may not wake up a sound sleeper or one who has recently

used drugs or has been drinking alcoholic beverages. This is especially true if

the door is closed or only partly open. Even persons who are awake may not

hear the alarm horn if the sound is blocked by distance or closed doors. Noise

from traffic, stereo, radio, television, air conditioner, or other appliances may

also prevent alert persons from hearing the alarm horn. This Smoke/CO Alarm

is not intended for people who are hearing impaired.

The Alarm may not have time to alarm before the fire itself causes dam-

age, injury, or death, since smoke from some fires may not reach the unit

immediately. Examples of this include persons smoking in bed, children

playing with matches, or fires caused by violent explosions resulting from

escaping gas.

This Smoke/CO Alarm is not a substitute for life insurance. Though this

Smoke/CO Alarm warns against increasing CO levels or the presence of

smoke, Airstream Inc. and/or BRK Brands, Inc. does not warrant or imply in

any way that they will protect lives. Motorhome owners and users must still

insure their lives.

This Smoke/CO Alarm has a limited life. Although this Smoke/CO Alarm and

all of its parts have passed many stringent tests and are designed to be as

reliable as possible, any of these parts could fail at any time. Therefore, you

must test this device weekly. The unit should be replaced immediately if it is not

operating properly. Any Smoke/CO Alarm that is beyond its replacement date

should be replaced immediately.

This Smoke/CO Alarm is not foolproof. Like all other electronic devices, this

Smoke/CO Alarm has limitations. It can only detect smoke or CO that reaches

the sensors. It may not give early warning of the source of smoke or CO is in a

remote part of the motorhome, away from the alarm device.

D

D - 13

CAMPING

The First Alert Users Manual provided in your owner’s packet has troubleshoot-

ing and other important information. Please read, understand, and follow all

information contained the First Alert Manual. If you have any questions con-

cerning the alarm that cannot be answered in this manual or the First Alert

manual please contact First Alert Consume Affairs at 1 800.323.9005, M-F 7:30

AM to 5:00 PM (CST) or Airstream Customer relations 937.596.6111.

LP GAS DETECTOR

In the kitchen area of your unit, approximately six inches above the floor, is the

LP gas detector. LP gas is a mixture of gases produced and sold commercially

as a fuel for heating and cooking appliances. LP gas is highly flammable and,

as a result, can be explosive if ignited under certain circumstances. LP gas is

heavier than air and,

If confined in a closed space, will accumulate close to the floor. When the LP

gas concentration in your unit exceeds 2000 PPM the detector will provide a

visual and audible alarm by sounding a buzzer and flashing the red LED two

times per second.

dangEr: Activation of this detector indicates the presence of

LP gas, which can cause an explosion and/or fire. This normally indicates

a leak in the LP gas installation or a LP gas appliance. Extinguish all open

flames, open your windows and door and evacuate the unit immediately.

Do not activate any electrical switch. Turn off the LP at your gas bottle (s).

DO NOT RE-ENTER YOUR UNIT UNTIL A QUALIFIED REPAIR TECHNICIAN

HAS CORRECTED THE PROBLEM.

OPERATION

Your LP gas detector is wired directly to your vehicle battery and incorporates

a 1-amp in-line fuse. When the device is operating normally the green LED will

be lit.

nOTiCE: It is not recommended that the detector be disconnected from

the battery during periods of storage. There is a small heater on the sen-

sorofthedevice,which“burns”awayimpuritiesintheairduringperiods

of normal use. During periods when power is interrupted, impurities can

build up on the sensor. When power is returned to the detector the detec-

toralarmmayactivateuntiltheimpuritiesare“burned”off.Thiscouldtake

anumberofhours,duringwhichtimethealarmwillbeconstantly“on”.

DETECTOR TEST

Press the test button for 5 to 6 seconds until the alarm sounds then release the

test button. The red LED should flash and the alarm sound for approximately

D - 14DD - 15

CAMPING

4 minutes. This test should be performed at least once a week during normal

vehicle operation, and after periods of storage, and before each trip.

LOW VOLTAGE

Below 10 VDC the detector will continue to operate but will blink alternately

green and orange. Below 8 VDC the unit will behave erratically and will eventu-

ally shut off. To ensure proper operation, do not operate the unit below 10

VDC.

COMPONENT FAILURE

The failure of any circuit component will cause the detector to display a con-

tinuous orange LED fault light and a short beep indicating failure. If this occurs,

immediately contact your dealer or Airstream Customer Service for the name

of the nearest detector service center.

Please read the operating instructions for your detector, which have been sup-

plied with the paper work of your unit.

Warning: Have a professional technician check all safety re-

lated systems yearly or whenever any doubts of their ability to function

properly arise.

OVERNIGHT STOP

In time you will develop a knack for spotting wonderful little roadside loca-

tions by turning off the main highway and exploring. There are many modern

recreational vehicle parks, including State, County and Federal parks with good

facilities, where you may obtain electrical, water and sewer hookups and con-

nections. Directories are published which describe in detail these parks and tell

what is available in the way of services and hookups.

All you need to do to enjoy the self-contained luxury is to:

1. Turn on LP gas supply and light appliance pilots if required.

2. Turn on water pump and open faucets until air is expelled from the system.

Before moving on, turn off the LP gas and water pump. Check your campsite,

both for cleanliness and to be sure you haven’t left anything behind. Make sure

everything is properly stowed.

Overnight or Weekend Trips

On overnight or weekend trips, chances are you will not use up the capacity

of the holding tanks, deplete the water supply, or run down the battery which

supplies the living area 12 volt current.

D

D - 15

CAMPING

LONGER TRIP

On a longer trip, when you have stayed where sewer connections and utility

hookups were not available, it will be necessary for you to stop from time to

time to dispose of the waste in the holding tank and replenish the water sup-

ply. Many gas stations (chain and individually owned) have installed sanitary

dumping stations for just this purpose. Booklets are available which list these

facilities.

When you stop for the night, your Airstream motorhome is built to be safely

parked in any spot that is relatively level and where the ground is firm. Your

facilities are with you. You are self- contained. Try to pick as level a parking

spot as possible.

EXTENDED STAY

Making a long trip is not very different from making a weekend excursion. Since

everything you need is right at hand, you are at home wherever you go. When

packing for an extended trip, take everything you need, but only what you

need.

When you plan to stay in the same place for several days, weeks or months,

you will want your motorhome to be as level as possible. Check the attitude

with a small spirit level set on the inside work counter. If a correction is neces-

sary, then you must first level from side to side. This can be done most easily by

driving up a small ramp consisting of 2” x 6” boards tapered at both ends. WE

DO NOT RECOMMEND PLACING TIRES IN A HOLE FOR LEVELING. Check

the tire section of the chassis portion of this manual for information on tire

support.

Hook Up to Water by attaching a ½ “ minimum high-pressure water hose to

the city water service.

Plug the 110 volt, 30 amp Electrical Cable into the City Power Service. Be

sure you have the wire grounded and have the proper polarity. See Electrical

Section for technical details.

To use the Generator you simply start it. All switching is done automatically.

The generator can be started from the switch inside the curbside rear roof

locker. It is easier on your generator and appliances if you’ll allow the generator

to reach its normal operating speed (about a minute) prior to applying heavy

current loads.

A Cable/Satellite TV connection is located in the exterior compartment along

with the switches for the dump valves, macerator pump and macerator pump

high pressure hose reel.

D - 16DD - 17

CAMPING

Turn on the gas supply. Lighting a top range burner to bleed any air from the

system will make it easier to start other appliances including the furnace.

When you stay for extended periods where electric or water hookups are

not available, you must make regular checks on the condition of your 12-volt

battery and the contents of your water tank. Carry drinking water in a clean

bucket to refill your tank. When your waste tanks nears capacity, move your

motorhome to a dumping location.

EFFECTS OF PROLONGED OCCUPANCY

Your motorhome was designed primarily for recreational use and short-term

occupancy. If you expect to occupy the motorhome for an extended period,

be prepared to deal with condensation and the humid conditions that may be

encountered. The relatively small volume and tight compact construction of

modern recreation vehicles mean that the normal living activities of even a few

occupants will lead to rapid moisture saturation of the air contained in the mo-

torhome and the appearance of visible moisture, especially in cold weather.

Just as moisture collects on the outside of a glass of cold water during humid

weather, moisture can condense on the inside surfaces of the motorhome dur-

ing cold weather when relative humidity of the interior air is high. This condition

is increased because the insulated walls of a recreation vehicle are much thin-

ner than house walls. Estimates indicate that two adults can vaporize up to

one and a half gallons of water daily through breathing, cooking, bathing, and

washing. Unless the water vapor is carried outside by ventilation, or condensed

by a dehumidifier, it will condense on the inside of the windows and walls as

moisture, or in cold weather as frost or ice. It may also condense out of sight

within the walls or the ceiling where it will manifest itself as warped or stained

panels. Appearance of these conditions may indicate a serious condensation

problem. When you recognize the signs of excessive moisture and condensa-

tion in the motorhome, action should be taken to minimize their effects.

Note: Your motorhome is not designed, nor intended, for permanent

housing. Use of this product for long term or permanent occupancy may

lead to premature deterioration of structure, interior finishes, fabrics, car-

peting, and drapes. Damage or deterioration due to long-term occupancy

may not be considered normal, and may under the terms of the warranty

constitute misuse, abuse, or neglect, and may therefore reduce the war-

ranty protection.

To avoid condensation problems, try to follow these tips to help allevi-

ate excess moisture:

Allow excess moisture to escape to the outside when bathing, washing dishes,

hair drying, laundering, and using appliances and non-vented gas burners.

D

D - 17

CAMPING

Always use an exhaust fan when cooking.

Keep the bathroom door closed and the vent or window open when bathing

and for a period of time after you have finished.

Do not hang wet clothes in the motorhome to dry.

In hot weather, start the air conditioner early as it removes excess humidity

from the air while lowering the temperature.

Keep the temperature as reasonably cool during cold weather as possible.

The warmer the vehicle, the more cold exterior temperatures and warm interior

temperatures will collide on wall surfaces, thus creating condensation.

Use the ceiling vent to keep air circulating inside the vehicle so condensa-

tion and mildew cannot form in dead air spaces. Allow air to circulate inside

closets and cabinets (leave doors partially open). Please keep in mind that a

closed cabinet full of stored goods prevents circulation and allows the exterior

temperature to cause condensation.

The natural tendency would be to close the vehicle tightly during cold weather.

This will actually compound the problem. Simply put, you need to remove some

of the warm air, and allow some cool outside air to get inside the vehicle, so the

furnace will not recycle the humid interior air.

Minimize use of incandescent lights, which produce heat and contribute to

condensation.

ABOUT MOLDS

What are molds?

Molds are microscopic organisms that naturally occur in virtually every environ-

ment, indoors and out. Outdoors, mold growth is important in the decomposi-

tion of plants. Indoors, mold growth is unfavorable. Left unchecked, molds

break down natural materials, such as wood products and fabrics. Knowing

the potential risks is important for any type of homeowner to protect their

investment.

What factors contribute to mold growth?

For mold growth to occur, temperatures, indoor or outdoors, must be between

40 degrees and 100 degrees Fahrenheit and also have a source of moisture,

such as humidity, standing water, damp materials, etc. Indoors, the most rapid

growth occurs with warm and humid conditions.

D - 18DD - 19

CAMPING

How can mold growth be inhibited?

By controlling relative humidity, the growth of mold and mildew can be inhibited.

In warm climates, use of the air conditioner will reduce the relative humidity.

Vents are located in the bathing and cooking areas and constant use is advised

during food preparation and bathing, even during colder weather. Additionally,

opening a window during these activities will assist in ventilation. In extremely

humid conditions, the use of a dehumidifier can be helpful. If using a dehumidi-

fier, please read and follow all manufacturer instructions and recommendations

to the use and cleaning of the dehumidifier.

Frequent use of your RV or cleaning regularly is an important preventive

measure. Further, any spills should be wiped up quickly and dried as soon

as possible. Avoid leaving damp items lying about. On safe surfaces, use

mold or mildew killing cleaning products. Check sealants regularly, and reseal

when necessary to avoid water leaks. Proper preventive maintenance to the

RV and its accessories, as described both in this manual and in accompanying

literature, will provide the best protection to the RV.

WINTER TRAVELING

Traveling in your motorhome during the cold winter months can be a most

exhilarating experience. There are, of course, certain precautions that must be

taken as you would in your home in low temperatures.

The Interstate motorhome has 12-Volt heat pads installed with the fresh

water and grey water holding tanks. The black water tank is above the floor

allowing heat from the furnace to protect it from freezing. The lighted switch,

when switch is lit the heating pad is on, for the heating pads is located on the

forward shower wall inside the sliding cargo door. To conserve battery power,

RV antifreeze may be used to protect the gray and black tanks. Battery power

will last about 4 hours unless the unit is plugged into a 120-volt shoreline or the

generator is ran to operate the inverter/charger.

Some states do not allow LPG to be turned on while moving. While traveling in

these states you must use your common sense. How cold is it? How long will it

be before you can turn the heat back on? Is the temperature dropping or rising?

Remember, the wind chill factor when driving 50 MPH will cause the interior of

the motorhome to cool much faster than when it is parked.

D

1. You must have a plentiful supply of propane gas as the heat from the

furnace warms the motorhome and keeps the fresh water lines and black

D - 19

CAMPING

water holding tank from freezing.

2. If your stay is longer than overnight, you should endeavor to have 120-volt

electricity available. The house battery, fully charged, will not last more than

about 15 hours in freezing weather, less (4 Hours) with use of the tank heat-

ing pads. Of course, you can run your generator to recharge the battery, or

even use the generator continually. Keep an eye on your LP Gas or engine

fuel according to the type of generator your motorhome is equipped with.

Since the generator starts off the house battery, it is recommended to start

the generator prior to running the battery down.

3. Minimize use of electricity if 120-volt power source is not available.

4. Leave cabinet doors, wet bath doors and wardrobe doors slightly open at

night to allow circulation of air in and around all components.

5. Save 12-volt power by using non-toxic RV approved antifreeze in greywater

holding tank instead of heating pad to prevent freezing. Quantity of anti-

freeze needed will vary with ambient temperature and the amount of liquids

in tank.

6. For extended stays in cold weather, insulate all water lines outside the

motorhome. You should remember that low temperatures in combination

with high winds cause an equivalent chill temperature much below what

your thermometer is reading. For instance, with an outside temperature of

zero degrees, and the wind velocity of 10 miles per hour, the equivalent chill

temperature is minus 20° F.

7. Remember to remove and drain the exterior shower faucet to prevent

freeze damage.

Exterior Sliding Step

The curbside sliding door has a sliding step w/auto retract, step out warning

buzzer, and a lock extended switch located just inside the sliding door on the

forward shower wall. Please read, understand, and instruct passengers of the

following operational and safety information pertaining to the step:

The step extends and retracts as the sliding door is opened and closed with

the engine off and step lock extend switch off. The step will not extend with

the engine running.

The step retracts autromatically and will not extend when the engine is started

and running to prevent damage while in transit.

If the step does not retract fully a warning buzzer will sound. The vehicle should

D - 20DD - 21

CAMPING

not be driven if the step fails to retract completely.

The step 20 amp fuse is located in the Sprinter fuse panel under the driver’s

seat, position F-10.

Lock Extended Switch

To use the lock extend switch, turn the engine off, open the door to extend the

step, and turn the switch on. The step will now remain extended while opening

and closing the door. Turn the switch off to return step to normal operating

mode.

Warning: The lock extended switch must be turned off before

starting the engine. Failure to follow this instruction may cause property

damage or personal injury.

If you forget to turn the lock extended switch off before starting the engine, the

step will retract when the engine is started, however it will not extend when the

engine is turned off and the door is opened. To reset the step: turn the engine

off and the step lock extended switch off with the door closed.

that step is extended before leaving and entering vehicle. Failure to follow

this warning could result in person injury.

nOTiCE: Check step is retracted before moving vehicle. Failure to follow

this caution could result in property damage.

D

Warning: LOOK BEFORE YOU LEAP. The step will not extend

with the opening of the sliding door when the engine is running. Check

D - 21

CAMPING

NOTES

D

D - 22

EXTERIOR

The exterior of your Airstream Interstate Motorhome, except for the optional

body kit, has been painted by Sprinter. The care of the paint is detailed in the

Sprinter manual.

The following additional information is provided by Airstream to help you un-

derstand the finish and its care. Following these instructions will provide a long

lasting, high-gloss finish for your recreational vehicle. These same procedures

can also be applied to your everyday automobile, producing the same long-

lasting results.

nOTiCE: Information on finish care may provide addition information and

tips on the use of the Van as a motorhome, however, no information about

the exterior finish of your motorhome in this manual should be interpreted

as advice or directions to disregard or void the warnings, cautions, or

other information contained in the Sprinter’s manuals.

Waxes and Polishes

Over 90 percent of all automotive finishes are clear coat. The finish on your

RV is a state-of-the-art Acrylic Urethane Basecoat/ClearCoat. This means that

what you will wash and polish is a clear urethane coating designed to protect

the basecoat: the pigmented coating that provides color. As its main func-

tion of protecting the basecoat, clearcoats need to be maintained especially

in harsh environments. Clearcoats do not fade themselves, but appear to fade

or lose gloss as the surface becomes contaminated by the environment. If

this contamination is not removed frequently, results will be a dull or low gloss

finish. Occasional washing alone will not adequately remove some forms of

contamination and will require polishing.

Polishes and waxes primarily served the following purposes:

1. To remove minor surface imperfections caused by water spots and acid

rain.

2. To remove minor scratches by filling them and leveling the surface.

3. To beautify the paint finish appearances with more depth and high-gloss.

4. To protect the paint finish from the elements.

Do not use products that contain harsh abrasives such as rubbing or polishing

compounds. These products should be used by experienced technicians with

the proper training and equipment. Most polishes and waxes are designed to

clean and polish in one application.

A hand applied polish or wax will offer outstanding performance and protect

the Interstate’s finish. When applying polish or wax, do so in a shaded area

making sure the surface is at the specified temperature according to the polish

manufacturers recommendations. Due to the variations of polishes and waxes,

E

E - 1

EXTERIOR

incorporate the following suggestions into the polishing technique:

1. Condition the polishing pad by rubbing a slight amount of polish on it.

2. Use only the amount of polish specified in the label directions.

3. Work a small area at a time.

4. Rinse off and remove dried polish from crevices, trim and moldings.

5. Follow the products manufactuers directions.

How to Care for Your RV Finish

Keeping your RV looking its best at all times involves keeping the paint finish

clean and in good condition. This means periodic washing and polishing, as

well as getting the paint finish repaired as soon as possible when the paint is

damage or affected in anyway. The purpose of the paint finish is two fold:

(1) Provide an aesthetically pleasing appearance.

(2) To protect the vehicle from the environment. Your RV is exposed to many

environmental conditions that have an adverse effect on the paint finish:

1. ROAD SALTS AND SODIUM CHLORIDE

2. ROAD TAR/BUGS

3. BIRD DROPPINGS/TREE SAP

4. INDUSTRIAL FALLOUT/ACID RAIN/POLLUTION

5. ULTRAVIOLET EXPOSURE AND MOISTURE

The most common problems resulting from these conditions are corrosion,

staining, and chemical spotting. These problems can be minimized through

regularly scheduled washing and polishing.

Washing your RV:

Make sure the RVs surface temperature is not too hot, under 90 degrees

Fahrenheit, and not in direct sunlight. A shady area is ideal for washing your

vehicle as direct sunlight causes water and soap to evaporate too fast, result-

ing in water spotting. Use a mild soap or detergent. Most auto care stores

carry a car wash shampoo. Try to avoid combination wash-n-wax products

as these waxes cause buildup and are designed for smaller surfaces. Have

two dedicated sponges or wax mitts: one for the paint finish and one for the

wheels and under carriage. Brushes or wash mitts that have plastic bristles

are acceptable for use on tires and wheel wells, but are not intended for use

on the paint finish.

Avoid using such items on painted surfaces, as they will damage the RV paint

and finish. Wash the wheels and wheel wells first as this removes heavy dirt

and debris and prevents it from splattering on already clean panels. Wet the

entire area down to remove loose dirt and grime, hand wash one area at time

using your dedicated paint finish sponge or wash mitt. Wash from the top and

E - 2EE - 3

EXTERIOR

work your way down, frequently rinsing the rinsing to minimize grit abrasion.

Follow with a final rinse of water.

This process will remove most contamination from the RVs surface. For stub-

born stains such as road tar, use an ammonia based glass cleaner or a small

amount of rubbing alcohol on a damp cloth immediately followed by warm

soapy water and rinse with clean water. This may not dissolve the road tar, but

will loosen tar and bugs stains and remove them from the surface. Do not use

solvent based cleaners on bird droppings or tree sap as these are water-based

stains and will eventually dissolve using an ammonia based glass cleaner, warm

soapy water and a little “elbow grease”. Once again, after removing stubborn

stains immediately rinse with clean water.

Drying the RV is just as important as washing your vehicle as today’s tap water

and well water contain many chemicals that could water stain your RVs finish.

We suggest using a damp natural or synthetic chamois, however, there are

other drying products such as lint free micro-fiber towels that work just as

well.

Follow the simple cautionary measures, and your new finish will give you maxi-

mum gloss and durability.

It is recommended that the caulking and sealant used in external seams and

joints such as window frames, light bezels, beltline and rub-rail molding, etc.,

be checked regularly. If this material has dried out and becomes cracked or

checked, or if a portion has fallen out, it should be replaced with fresh material

to prevent possible rain leaks. Caulking and sealing material is available from

your motorhome dealer and most RV supply stores.

Body Kit

The body kit provided by Airstream is made from state of art high impact plas-

tic. The same material is used in the automotive industry for moldings, bumper

guards, and trim. The kit is made to color specifications and requires no paint

or finish. The cleaning procedures are the same as the painted finish on the

Sprinter body, however there are several automotive plastic care products on

the market for exterior parts that will provide added protection from UV ray

damage, dirt, and stains. Find one you like and use it as often as needed to

help prevent fading.

E

E - 3

EXTERIOR

Roadside Exterior Features

10

1

2

E - 4EE - 5

3

4

9

5

7

11

6

8

EXTERIOR

Roadside Exterior Features

NOTE: This is a basic explanation of the location and function of exterior fea-

tures. More in depth explanations of certain feature’s care and maintenance is

include in this manual in other sections.

1. City Water Hook-up provides access for city water to your fresh water

system. Use ½” minimum hose for water supply.

2. Water Fill is used to fill the fresh water tank. Use only clean fresh potable

water.

3. Furnace exhaust vent should be cleaned regularly. When operating furnace,

be sure exhaust can escape into a well-ventilated area. Air coming from vent

can be hot, when parking the motorhome, be sure to have proper clearance

in venting area.

4. Exterior Shower outlet can be used on the water pump or with the city

water hook up after faucet/valve/hose assembly is inserted.

5. Utility Hatch contains the cable/satellite TV inlet, the switches for the dump

valves, macerator pump and macerator pump high pressure hose reel.

6. Electronic Ignition Water Heater Door and Vent is part of the plumbing sys-

tem. The intake vent, drain plug and exhaust vent are located inside this door.

Regular maintenance by a qualified service technician is required to keep the

water heater operating efficiently.

7. Cable/Satellite TV inlet is located inside the utility hatch and is pre-wired for

cable/satellite TV. A portable satellite dish can be connected and used in the

cable connection.

E

8. 110 Volt Power Cord Inlet, 30-amp service is required, power cord is stored

inside rear cargo doors in a plastic storage compartment.

9. Macerator hose reel compartment stores the electric reel holding the

pump hose and the Black Tank Flush.

10. Body kit.

11. House Battery Vent (Rear Twin Model Only) allows battery gasses from

the battery compartment located under the rear lounge to escape and fresh

air to enter.

E - 5

EXTERIOR

Curbside Exterior Features

1

11

2

3

9

4

8

7

10

6

5

E - 6EE - 7

EXTERIOR

Curbside Exterior Features

NOTE: This is a basic explanation of the location and function of exterior fea-

tures. More in depth explanations of certain feature’s care and maintenance is

include in this manual in other sections.

1. House Battery Vent (Rear Lounge Model Only) allows battery gasses from

the battery compartment located under the rear lounge to escape and fresh

air to enter.

2. Exterior 110 Volt Outlet provides an exterior GFI protected electrical

source.

3. TV Outlet/12 Volt Power Port provides reception for an exterior television.

It is pre-wired and integrated into the Cable TV/Satellite TV system. There is

also a 12 Volt outlet.

4. LP tank remote fill and shutoff.

5. Sliding Step w/Auto Retract has a step out warning buzzer and a lock

extended switch for easy entry into the motorhome.

shower wall.

7. MaxxAir Roof Vent, exhaust only, complete operating instructions are in the

appliance section of this manual. Keep all vents clear to encourage airflow.

8. Roof Air Conditioner

9. Power Boosted Omni-Directional TV Antenna is wired into TV outlets on

exterior of coach and inside unit at entertainment center cabinet.

10. Radio Antenna

11. Patio Awning operating and care instructions are including in this section

of this manual.

E

6. Porch Light is switched just inside the sliding cargo door on the forward

E - 7

EXTERIOR

PATIO AWNING

Awning Motor Pre-wire: Units equipped with the standard manual awning are

prewired for the addition of a motor to convert to power operation. Four wires

are located inside the removable rear panel of the rear roof locker. Those four

wires run through the body to under the passenger cab seat where two other

wires are run from the chassis fuse panel under the driver’s seat. The switch

can be mounted inside the compartment on the side of the passenger seat.

MANUAL OPERATION

NOTICE: The sliding cargo door must be shut to extend the awning, with-

out this happening the arm and the opening cover will contact the door

possible cause damage to the awning or door finish. Once the awning is

extended the sliding door will

open and shut fine without any

interference.

2. Unscrew the leg tension knob.

3. Take the leg near its hinge-joint and pull it in a horizontal direction.

TO EXTEND AWNING

1. Hook awning extension crank

into gear motor loop and extend

awning about 36 inches.

Gear
Assembly
Loop

Insert the end of
the crank handle into
the gear assemly loop
and turn clockwise
to extend

E - 8EE - 9

EXTERIOR

4. After leg clears case, rotate leg down

and extend leg to the ground. Use leg ten-

sion knob to secure leg length to ground.

Repeat with other leg. NOTE: Awning poles

are stored on the floor behind the rear center

sofa and are accessed by opening the rear

cargo doors. When traveling store the poles

securely using the straps provided.

4a. To use the carport position, legs

sitting on the ground, crank the

awning completely out while moving

the support arms each time when

necessary.

Drive ground stakes through the holes in the carport

foot and into the ground for support or tie off on a

rope stake.

CaUTiOn. GROUND STAKES WILL NOT PREVENT THE AWNING

FROM MOVING IN THE WIND!

4b. To use the bottom brackets, swing each arm toward the vehicle, lift the

bracket pin and position foot into bracket and then release the pin. Then turn

crank until awning is all of the way out. Turn the crank back a partial turn to

back wind the awning slightly. This tightens the fabric.

E

After unrolling the awning completely fix the legs at the chosen height.

E - 9

EXTERIOR

To stow the awning reverse the extend procedure.

NOTICE: Never use the awning with damaged fabric. Make sure the

awning can be correctly rolled up. A damaged fabric does not allow a

correct rolling up of the awning.

AWNING USE IN WIND AND RAIN.

We remind you that the awning is a sun protection, so please roll up your aw-

ning in case of rain, wind or snow. Otherwise take the following precautions:

To prevent water build up on the awning, position one upper arm substantially

lower than the other to create enough of a slope for adequate water run off and

use a tension rafter available from Fiamma. (See figure below)

To avoid the awning being taken up by a sudden wind, causing possible dam-

age to the vehicle by the swinging of the legs. It is necessary to secure the

legs to the ground with the provided hooks. As a supplementary security we

strongly advise to make use of a storm cord at the upper side of each support

leg, or to acquire and anchor the legs with the Fiamma Toe-Down Kit Strap.

(See figure below)

NOTE: IF WIND OR EXTENDED PERIODS OF RAIN ARE EXPECTED, ROLL UP

THE AWNING AND SECURE AS FOR TRAVEL!

nOTiCE: THE EFFECTS OF WIND AND RAIN ON ANY AWNING ARE

UNPREDICTABLE. SEVER DAMAGE TO THE VEHICLE AND OR THE

AWNING MAY RESULT AND CANNOT BE COVERED BY WARRANTY!

Rafter

Tie
Down
Straps

E - 10EE - 11

EXTERIOR

POWER AWNING (Option)

The switch for the power awning is located on the passenger seat pedestal

and accessed by opening access dor on the seat pedestal. While the carport

leg deployment procedure can be used with the power option, Airstream rec-

ommends following the procedure using the legs inserted into the brackets

mounted on the side of the unit.

NOTE: Awning will not extend while vehicle engine is running.

CARE AND MAINTENANCE

1. CARE OF FABRIC: Fiamma recommends cleaning with Fiamma Brill.

2. PERIODIC MAINTENANCE Like any other part of the RV, an owner should

periodically inspect the awning. The following items should be checked.

A. All mounting brackets are tight.

B. Check all pivot points for enlargements of holes or broken rivets.

D. Check that awning rail is tight against coach and all screws are tight.

E. Check canopy for loose stitching and possible shrinkage or puckering.

F. Clean and lubricate all tension knobs and pivot points.

Fuse Location: Chassis fuse panel under driver’s seat, position F-10.

E

C. Check end caps for cracking, splitting.

E - 11

F - 2

INTERIOR

The interior of your Airstream motorhome has been designed to take a limited

amount of space and provide you with all the comfort, convenience, durability

and appearance possible. An understanding of the operational procedures and

maintenance techniques of the interior appointments will add to your pleasures,

as well as to the long life of your motorhome.

Driver and Passenger Seats

The driver and passenger seats are provided by Sprinter, sent out to be recov-

ered by Airstream to match the interior decor.

F

The seat adjustment mechanism provided by Sprinter allows the seat to be

moved forward or backward and swivel left or right. A release bar under the

front of the seat is used to move the seat forward and backward. Pressing

down on a handle centered under the front of the seats allows the seat to

swivel. Return seat to full upright position before using swivel adjustment.

Lumbar and other seat adjustments are part of the reupholstered Sprinter seat

and their operation is explained in the Sprinter manual.

dangEr: Adjust the driver’s seat so that you can easily reach

and operate all controls. Make sure seat is locked in position. Do not

adjust driver’s seat swivel or fore and aft mechanism while vehicle is

moving. The seat could move unexpectedly causing loss of control.

Captain’s Chairs, 2nd Row

The captains chairs have 3 adjustments. A lever on the side of the seat reclines

the seat back. A lever on the seat pedestal under the front of the seat allows the

seat to be adjusted forward or back, and a lever on the pedestal under the side

of the seat allows the seat to swivel. Return seat to full upright position before

using swivel adjustment.

nOTiCE: Seat backs on cab and 2nd row seats must be returned to full

upright position and seat moved forward before seat is swiveled. Failure

to do so could result in damage to the seats upholstery, the wall panels,

and the seat decorative skirt.

Rear Lounge/Bed

The dinette seats and rear center lounge transform into a rear bed. The center

power lounge is operated by a switch located under the curbside rear roof

locker. Remove headrests and press switch to lower seat back.

The side dinette seats fold out by lifting up on the seat edge and pulling out.

F - 1

INTERIOR

The backrests will slide down into place as the seats slide out. Raise the coun-

tertop extension before pulling out the roadside sofa to prevent the sofa from

hitting it. To sleep stow the extension.

Clean ultra leather coverings with standard products used for that purpose.

Follow instructions on the cleaning products container.

NOTE: Never remove cushion covers for separate dry cleaning or washing. Any

tumble cleaning method can destroy the backing, shrink or otherwise damage

upholstery fabric.

Warning: Keep your furniture and family safe from fires

caused by careless smoking. Do not smoke when drowsy. Remove

immediately any flowing ash or a lighted cigarette, which falls on furniture.

Smoldering smoking material can cause upholstered furniture fires.

Dinette Table

The dinette table is a pedestal table. The top is stored between the galley and

the captains chair. The table pedestal is stored in back of the rear center sofa

on the rear lounge model accessed by opening the two rear cargo doors and

inside the roadside wardrobe in the twin bed model. The pedestal table can be

placed in floor mounted threaded holders located between the dinette seats

or the 2nd row captain chairs. The pedestal is inserted into the floor cups and

twisted to lock into place.

Warning: Return table top and pedestal to their respective

storage positions before moving vehicle. In a emergency stop or accident

the top and pedestal could cause personal injury and /or death.

Vinyl Floor

The vinyl floor in your unit can be cleaned and waxed with products recom-

mended for vinyl floors.

CaUTiOn: Warn occupants entering the vehicle when the floor

is wet or fresh wax has been applied. Just like a home, the floor can be

slippery and falls are possible.

Cabinets/Overhead Lockers

The furniture is manufactured from of a high-pressure laminate and can be

cleaned with soap and water, or you can use a common solvent on tough

spots. Furniture polish can be used sparingly. Glass doors must be cleaned

with a anti-static cleaner and cloth. Windex or common ammonia products will

F

F - 2

F - 4

INTERIOR

damage the coating on the surface.

Notice: Do not use any abrasive material. Abrasive cleaners, cloths and pads

as there is the possibility they could scratch the surface. A protective pad

should always be placed under hot utensils.

Wet Bath

To clean your fiberglass shower stall unit, use warm water and a liquid deter-

gent. Do not use abrasive cleaners; they may scratch and dull the surface of

F

your fiberglass unit. Stubborn stains can be removed with solvents such as

turpentine, paint thinner or acetone. Restore dulled areas by rubbing with an

automotive-type liquid cleaner, and then put the soft glow back into the sides

of your unit with a light application of liquid wax. DO NOT wax the shower

bottom as it may become slippery leading to a fall.

Bath Wall Extension.

The bath wall next to the toilet is hinged and is designed to extend into the hall-

way to provide more space. A latch at the top of the swinging wall is provided

to release and secure the wall in two positions. The wall should be always be

secured by the latch in whatever position you decide to use.

Warning: During transit Airstream recommends the wall be

retracted and secured, freeing up hall space for emergency

exits.

Galley Sink/Faucet

SMEV

WWW.SMEV.COM

To use: Open lid and rotate faucet to upright position. Open hot or cold faucet

as needed.

Clean Acrylic lid with warm soapy water, no abrasives. For the stainless steel

sink each sink comes with a packet of SMINOX stainless steel polish/cleaner

which is included with your owner’s case. This would be the preferred cleaner

for sink appliances per SMEV, however any stainless steel (non-abrasive)

cleaner is fine.

Notice: Do not use any abrasive cleaners or cloths on surfaces.

F - 3

INTERIOR

Lavatory Sink/Shower Faucet

The lavatory shower/sink faucet is equipped with a retractable, adjustable

showerhead. It has ceramic valves with chromed brass construction. The

faucet spout can be pulled out for use as a shower or left in place for the sink.

The spray can be adjusted by turning the spout end. The chrome finish can be

cleaned with warm, mild, soapy water and a clean soft cloth.

NOTICE: Do not use abrasive cleaners, pads, or cloths to clean the

chrome finish. This will damage the finish and is not covered by your war-

ranty.

Metal Interior Skin

The metal interior skin on the ceiling is coated with a baked on acrylic coat-

ing. Use soft rags or wash mitts always moving lengthwise with the grain of

the aluminum. NEVER rub hard on the coating. Oil, grease, dust and dirt may

be removed by washing with a 5% solution in water of commonly used com-

mercial and industrial detergents. Cleaning should be followed by a thorough

clean water rinse. Drying the metal with a chamois or a soft cloth may prevent

spots and streaks. WHEN WASHING OR WAXING THE METAL, ALWAYS WIPE

“WITH” THE GRAIN OF THE METAL.

After cleaning and drying, a good grade of nonabrasive automotive paste or

liquid wax once a year will increase the life of the finish and help remove minor

scratches and abrasions. It will also protect the metal from minor scratches and

make subsequent cleaning easier.

If a substance is found on the coating that cannot be removed by normal wash-

ing procedures, Airstream recommends using DX 330 Acryli-Clean made by

PPG Industries. Follow all directions and warnings on the product container.

Acryli-Clean should be used by trained personnel only, using the proper equip-

ment under controlled conditions. Use the Acryli-Clean as sparingly as possible

to remove oil or grease. Rinse with cool water immediately after use.

nOTiCE: ABRASIVE POLISHES OR CLEANING SOLVENTS SUCH

AS AUTOMATIC DISHWASHER OR ACID ETCH CLEANERS ARE TOO

STRONG AND SHOULD NEVER BE USED. RINSE ALL GRIT FROM

SURFACE PRIOR TO WASHING. Use soft rags always moving lengthwise

with the unit. NEVER rub hard on the coating. Even the softest rag will

damage the coating if excessive pressure is applied.

F

F - 4

F - 6

INTERIOR

Upholstery

Cleaning Instructions for Ultraleather™

Spot clean with mild soap and water.

Air dry or dry quickly with warm setting of a hair dryer.

For stubborn stains, use mild solvent (ie. Fantastic or Formula 409).

Disinfect with a 5:1 bleach solution.

Dry cleanable by conventional methods using commercial dry cleaning

solvents.

This material cannot be machine-washed.

F

Stain Removal:

Use mild detergent for coffee, tea, red wine, liquor, soft drinks, milk, ketchup,

steak sauce, soy sauce, mayonnaise, butter, salad oil, chocolate, cosmetic

foundation, lipstick, face cream, suntan oil/lotion, shoe polish and urine.

Use a mild cleaning fluid (Woolite) on stains like machine oil and on more

stubborn stains when mild detergent is not enough.

Shades

Day/Night shades are lowered and raised by the bars running across the

shade. To raise and lower the complete assembly, grasp in the center of the

bottom bar or place hands evenly on the bar. Lift or lower the bar to open or

close the shade. A second bar has two knobs to lower and raise the day part

of the shade. Rough roads and long trips may cause the pleated shades to

move slightly during travel. Tensions on the strings at the sides of the shades

adjust the ease of operation and their ability to stay up during travel. Do not

over-tighten as this may cause the string to break, requiring service.

A feather duster or the soft-bristled brush often found as part of vacuum cleaner

attachments, are recommended for cleaning the pleated shades. The longevity

of the pleated shades will be increased if the shades are closed, glass shows,

when your vehicle is stored.

Counter Tops/Backsplash

The standard counter top is manufactured from of a high-pressure laminate.

Laminates will burn, scratch, and stain, so you’ll have to be considerate of your

countertops to keep them looking good.

F - 5

Regular applications of appliance wax or light furniture wax will help lami-•

INTERIOR

nate surfaces resist stains and scratching.

Never use abrasive cleansers or steel wool on laminate countertops. •

For general cleaning, a two-sided scrubbing pad with fiber on one side •

and a sponge on the other works particularly well. Moistened slightly with

water, the fiber side is just abrasive enough to loosen greasy smears and

other soil.

The optional counter top is a Lite Gran solid surface material. It has a

fiberglass core with a tough Acrylic coating.

You have to go out of your way to harm an acrylic countertop. A very hot pan

will leave a permanent burn mark on the surface, but scouring powder or steel

wool will remove stains and scratches. For routine cleaning, use a mild abrasive

cleanser applied directly to the wet surface. Rinse well and buff with a soft

cloth. Remember the top is coated with acrylic and not solid acrylic.

For Lite Gran Repair Procedures please contact:

Better Way Products, Inc.

70891 CR 23

New Paris, IN 46553

Phone/Fax: [phone]

Email: [e-mail]

Bath Exhaust

The round bath exhaust is operated by

pushing up on the handle to raise the fan lid.

A push button switch will activate the fan.

High Volume Exhaust fan

MAXXAIR VENT FAN

Model 00-06201-005

MAXXAIR CORP.

Corporate Headquarters 5513 West Sligh Ave

Tampa, FL 33634

The MaxxFan is a unique, one-of-a kind ventilation system that keeps your

RV interior safe from any weather- rain or shine. It circulates hot, musty air

out - at any time - in any weather. It includes a built in rain shield that moves

into position, automatically, every time the MaxxFan vent is opened. Best of

all, this rain shield tucks away when the MaxxFan is closed, providing a low

profile, euro-style appearance.

The MaxxFan opens and closes like most standard roof vents using a manual

knob located at the ceiling. The controls for the fan are placed at the ceiling

around the fan intake screen. In addition, the MaxxFan features an easy to

Button (on/off)

Handle

To
Open

F

F - 6

F - 8

INTERIOR

remove screen. Simply rotate four retaining knobs and remove the screen for

cleaning, no tools required.The MaxxFan’s large exhaust vent employs a rigid

louver system that, along with the internal heavy-duty screen, keeps rain,

debris and critters from entering the vent area when opened.

Note: The MaxxFan is designed to be fully opened or fully closed when the

vehicle is moving.

CAUTIONS AND CARE OF THE MAXXFAN

F

This product has been manufactured using prime UV stabilized Polymers

for maximum toughness and durability. However, the use of non-compatible

chemicals will cause cracking and product failure.

Please clean all parts with mild soap and water only.

Do not use Petroleum Containing Additives or Solvent Based Products on any

of the MaxxFan’s components or its corrosion resistant hardware.

Listed below are some known chemical products to be aware of:

Amines, Aromatic Hydrocarbons, (Loctite Formulas), or references re: chemi-

cals that are not to be used on Plastics.

GENERALLY COMPATIBLE (But should be used in low concentration where

possible)

Acids, Alcohol, Alkalis, Aliphatic Hydrocarbons, Mild Soap solution (avoid

strong Alkaline material), Silicone Oil or Greases (avoid those containing

Aromatic Hydrocarbons or other additives). Review the contents of your

cleaning materials carefully.

If your MaxxFan fails to operate properly under normal conditions, please call

MaxxAir using the toll free number listed below or your dealer. If calling MaxxAir,

please have the motorhome retail sales date and the MaxxFan Serial Number

readily available when you call. The Serial number for your MaxxFan is located

on the fan control plate under the round insect screen frame. Reference your

operating guide. Rotate the four retaining knobs 180 degrees and remove the

screen to view. Do not operate the MaxxFan with the screen removed

Maxxfan Toll Free Customer Service

[phone], 8:00 am - 5:00 p.m. EST, Monday - Friday

NON COMPATIBLE CHEMICALS - DO NOT USE THESE:

Keytones, Esters, Acetone or other like solvents, Halogenated Hydrocarbons,

F - 7

INTERIOR

Light Bulbs

To change the bulb in the round ceiling light, first remove the lens assembly.

The lens assembly is spring loaded and pops out of the fixture at its chrome

ring. A small screwdriver may be used, be careful not to scratch the chrome

and be sure the bulb is cool before attempting replacement. The bulb inserts

into the ballast by two wire prongs. Grasp the bulb with a piece of cloth and

pull it gently straight out from its ballast. Insert the new bulb, and replace the

lens. The lens assembly has two grooves that must be aligned to the light

fixture before snapping the lens back into place. The round ceiling light bulb is

halogen # 12V-10W.

The reading light bulbs are spring loaded and are removed by pushing in

slightly and turning counter clockwise.

dangEr: Always replace the light bulb on an interior or

exterior light fixture with the correct bulb for that light. Always

be sure light is tuned off and bulb is cool before removing a bulb. Take

proper precautions on a broken bulb to prevent lacerations. Failure to

heed these warnings could cause fire, property damage, personal injury,

or death.

Privacy Curtain

Privacy curtains are provided for the front

windshield and cab windows. The curtains

have pockets sewn into them that slide

over the sunvisors and straps on each end

that slide over the seat belt mechanism.

Light brushing with an upholstery brush or gentle use of a vacuum cleaner will

suffice in most situations. For heavy soiled conditions Dry-Clean only. Washing

the curtain may void the warranty.

Privacy Curtain

F

F - 8

INTERIOR

NOTES

F

F - 9

PLUMBING

LPG SYSTEM

Your motorhome is equipped with a permanently mounted tank for LPG (Liquid

Petroleum Gas) with a remote fill and remote gas supply shut off switch. LPG

burns with a clean blue flame, Propane is used where subfreezing temperatures

are common, since it freezes at -40° F. How long a full tank of gas will last is

dependent on usage. In cold weather, when you are using the furnace, or when

you use large amounts of hot water, or cook extensively, you will naturally use

more than you will in warm weather, or when you may do limited cooking. On

the average, with normal cooking and other appliance use, you can probably

count on two to four weeks of usage from the tank.

If you have allowed the tank to run out, air may have gotten into the lines. In this

event the air must be allowed to bleed from the lines before lighting appliances.

Follow the appliance manufacturers instructions and light the appliance closest

to the LP supply tank. Then move to the next closest, etc.

LP TANK REMOTE FILL

The LP tank is filled by accessing the remote fill hook up located in the com-

partment under the passenger side rear fender behind the rear wheels. Be sure

the fill is free of dirt. It may help to remind your LP supplier to only use a clean

fill hose to fill your tank. Turn off the remote switch when the LP system is not

in use as it draws 12 volt current from th batteries.

Warning: Only certified LP suppliers should fill the LP Tank.

Turn remote gas supply switch off before filling or refilling LP tank.

Warning: Always shut off the LP gas when refueling the mo-

torhome.

Remote Gas Supply Switch

A remote switch for shutting off the

gas to all appliances is located in

the same compartment. The switch

activates an electric solenoid that

opens and closes, shutting the gas

off at the tank. The switch rotates ¼

turn. This switch should be turned off

during the filling of the LP tank. NOTE: The electric gas shut-off solenoid closes

automatically when 12-volt power is disconnected. It will reopen when power

is restored.

Bleeder Valve

LP Remote Fill Point

Exterior LP Port

LP Remote Switch

Warning: All LP gas appliances must be turned off during

refueling of motorhome fuel tank and permanently mounted LPG tank.

G

G - 1

PLUMBING

Gas lines should be checked periodically for leaks with ammonia free soapy

water.

dangEr: Do not use open flame to search for problems. If

gas can be smelled, appliance pilots fail to stay on, or any other abnor-

mal situation occurs, use the remote supply switch to shut off the tank

valve immediately and call on a qualified LPG service center or Airstream

Service Center.

CaUTiOn: Moisture in the LPG tank will cause a malfunction of

the regulator in controlling proper pressure. This may result in the flame

lifting off the burner, or the flame may go out frequently. Many refueling

stations will add approximately ¼ to ½ gallon of alcohol to lower the mois-

ture temperature. Moisture will then pass through the regulator without

the formation of ice crystals.

LPG Regulator

The LPG regulators used on Airstream motorhomes are designed for low-

pressure service, with a normal outlet pressure setting of 11.5 inches water

column. Only personnel trained in the proper procedures, codes, standards,

etc., should service regulators. Have the regulator inspected each time the

tank is refilled. Replace any regulator that has had water in the spring case, or

shows evidence of external corrosion, or corrosion inside the spring case.

BASIC RULES FOR SAFETY

dangEr:

DO NOT store LP containers within vehicle. LP containers are equipped

with safety devices that vent gas should the pressure become excessive.

DO NOT use cooking appliances for comfort heating. Cooking appliances

need fresh air for safe operation. Before operation open overhead vent or

turn on exhaust fan and open window.

A warning label has been located in the cooking area to remind you to

provide an adequate supply of fresh air for combustion. Unlike homes, the

amount of oxygen supply is limited due to the size of the recreational ve-

hicle, and proper ventilation when using the cooking appliances will avoid

dangers of asphyxiation. It is especially important that cooking appliances

not be used for comfort heating as the danger of asphyxiation is greater

when the appliance is used for long periods of time.

Portable fuel burning equipment, including wood and charcoal grills and

stoves, shall not be used inside the recreational vehicle. The use of this

equipment inside the recreational vehicle may cause fires or asphyxia-

G - 2GG - 3

PLUMBING

tion.

A Warning Label has been located near the LP gas container. This

label reads: DO NOT FILL CONTAINER (S) TO MORE THAN 80% PERCENT

OF CAPACITY. Overfilling the LP gas container can result in uncontrolled

gas flow that can cause fire or explosion. A properly filled container will

contain approximately 80 percent of its volume as liquid LP gas.

Do not bring or store LP gas containers, gasoline or other flammable

liquids inside the vehicle because a fire or explosion may result.

dangEr: If you smell gas:

1. Extinguish any open flames, pilot lights and all smoking materials.

2. Do not touch electrical switches.

3. Shut off the gas supply using the remote shut off switch.

4. Open doors and other ventilating openings.

5. Leave the area until odor clears.

6. Have the gas system checked and leakage source corrected before

using again.

with a protective cover. Make sure that regulator vent faces downward

and that cover is kept in place to minimize vent blockage that could result

in excessive gas pressure causing fire or explosion.

The regulator at the L.P. tank is under a gray plastic cover. The protective cover

certainly helps to keep the vent on the regulator from being clogged by wasps

or ice, but should still be checked regularly to make sure the vent remains

clear.

dangEr: Do not attempt to seal regulator cover.

G

Warning: Check vent each time tank is filled to make sure it

is clear of obstructions.

LP gas regulators must always be installed with the diaphragm vent facing

downward. Regulators that are not in compartments have been equipped

G - 3

PLUMBING

LPG CONNECTIONS

A quick connect low pressure LPG connection is located under the passenger

side rear quarter panel behind the dual wheels. It is a utility connection to use

for an outside grille or other LPG appliance.

The connections are relative easy to use. Check that the remote LPG shut off

switch is turned completely off. Slide the collar on the female end back and

plug the male hose into the connection. Release the collar and check that the

hose is properly connected by giving a firm pull on the hose. Turn the LPG

remote shut off switch on and recheck all connections to the appliances and

quick connection to be sure no leaks are present.

Follow all instructions, cautions, and warnings presented in this manual when

connecting and disconnecting appliances.

WATER SYSTEM - SELF-CONTAINED

The fresh water system consists of a city water hook up, fresh water tank grav-

ity fill, fresh water tank and drain valve, water-pump, pump filter, hot and cold

water lines, water heater, fresh water line low point drain valves, and faucets.

Full explanations on the locations and use of these feature are explained in this

section.

Before using a water system, check that the water heater by-pass valve is

turned to the use position. The by-pass valve is located on the back of the

water heater under the lounge on the roadside, accessed by opening the rear

cargo doors and reaching under the lounge. See Winterizing and Storage for

further information on the By-Pass. Check that the exterior water heater drain

plug is installed. Close all low point drain valves and the fresh water tank drain

valve.

To operate the system with the water pump:

Fill the water tank by opening the exterior gravity feed water fill door. A garden

hose can now be inserted or use a clean bucket and funnel to fill the tank. It’s

a good idea to let the water run through a hose for a short time to flush it out.

RVers sometimes fill their tanks with “home” water to avoid strange water that

may be distasteful to them on short outings. Remember the more water you

G - 4GG - 5

PLUMBING

carry in the fresh water tank, the less cargo carrying capacity you have for

other items.

The amount of water in the tank may be checked on the Monitor Panel, or you

may fill the tank until water overflows out of the fill.

Fill the water heater by opening the hot side of either the galley, wet-bath, or

exterior shower faucet and turning on the water pump switch located under the

galley roof locker or by connecting to an exterior city water source. Close the

cold side of all faucets. For some time the open faucet will only sputter. This

is because the water heater is being filled and air is being pushed out through

the lines. Once the water heater is full, a steady stream of water will come from

the faucet.

Now open a cold faucet. It will sputter for a short time, but will soon expel a

steady stream. All other faucets can now be opened until all air is expelled.

Once the system is filled with water and the faucets are closed, the water pump

will shut off. When a faucet is opened the pump will come back on automati-

cally. If the faucet is just barely open it is normal for the pump to cycle on and

off rapidly.

It is normal for a pump to occasionally cycle when all faucets are off to keep

the water pressure at the set point. However, if it cycles frequently (more than

a few times an hour) the plumbing system, pump, and pump strainer should be

checked to be sure it is not loosing pressure through a slow water leak or back

through the pump.

nOTiCE: To prevent equipment damage the water heater should only be

started after the water system is primed and ready for use.

nOTiCE: Turn the water pump off when the motorhome is left unat-

tended.

Water Pump And Strainer

Manufacturer:

USA Canada

Flojet Fluid Products Canada

20 Icon 55 Royal Road

Foothill Ranch, CA 92610 Guelph, Ontario, N1H 1T1

Phone: [phone] 519-821-1900

The water pump and strainer are located under the galley, accessed by

removing the galley drawer. The strainer should be visually checked for ac-

cumulation of sand or debris that could affect water flow.

G

G - 5

PLUMBING

To clean the strainer screen: With the clear plastic at the top press on the sides

of the strainer releasing the tabs holding the clear plastic top in place, hold

the sides in and pull straight up on the clear plastic top to remove the screen

assembly. Rinse all debris from the screen. Replace the screen assembly by

aligning the screen in the seating groves and pressing gently down until tabs

catch and hold the clear plastic top in place.

Quick
Disconnect
Fitting

The inlet and outlet hoses and the strainer assembly are held in place by

self sealing blue quick connect fittings. To disconnect a hose or the strainer

grasp the blue tab on the female fitting by the grooved finger edges and

pull straight out on the tab. This will release the male fitting connected to

the hoses and strainer. Be sure that both the female and male fitting on the

disconnect are free of all debris and are not damaged before replacing.

Check the pump system for leaks anytime the disconnect fittings on the

hoses and/or strainer are removed.

Blue
Finger
Ta b

nOTiCE: Failure to check the quick disconnect fitting for water leaks

when reinstalling inlet and outlet hoses or the water pump strainer may

cause the pump system to leak causing damage to personal property.

To operate the system using a city water source:

CITY WATER HOOKUP

City Water

The city water inlet is a standard garden hose thread.

Hookup

Use a high-pressure RV/Marine FDA approved

drinking waterhose of at least ½ “ diameter made

from material that is tasteless, odorless, and non-

Water

Inlet

City

toxic. We suggest you carry two lengths of hoses so

you have the ability to reach hookups further away

than normal, plus you have a spare should one fail

or become damaged unexpectedly.

After hooking up the hose and turning on the city water valve provided in the

park, slowly open a faucet. There will be spurts and sputtering until all the air is

expelled from the motorhome system. Be sure to turn the water heater bypass

to the normal flow position as described earlier in this section so it will fill. If the

water heater is empty it will take some time before all the air is expelled and

you get a steady flow of water at the faucet. Once a steady flow is achieved

G - 6GG - 7

PLUMBING

at one faucet, the others should be opened long enough to expel the air in the

lines going to them.

Your plumbing system has a built in pressure regulator to protect your lines

and faucets from extremely high pressures on some city water systems. An

after-market external regulator is not recommended, as it could lower the water

pressure at the inlet and thus to your faucets and shower.

Sanitizing

Potable water systems require periodic maintenance to deliver a consistent

flow of fresh water. Depending on use and the environment the system is sub-

ject to, sanitizing is recommended prior to storing and before using the water

system after a period of storage. Systems with new components, or ones that

have been subjected to contamination, should also be disinfected as follows:

1. Use one of the following methods to determine the amount of common

household bleach needed to sanitize the tank.

A) Multiply “gallons of tank capacity” by 0. 13; the result is the

ounces of bleach needed to sanitize the tank.

B) Multiply “Liters of tank capacity” by 1.0; the result is the milliliters

of bleach needed to sanitize the tank.

2. Mix into solution the proper amount of bleach within a container of water.

3. Pour the correct amount of solution (water/bleach) into the freshwater tank

and fill with potable water.

4. Open all faucets (Hot & Cold) allowing the water to run until the distinct

odor of chlorine is detected.

5. The standard solution must have four (4) hours of contact time to disinfect

completely. Doubling the solution concentration will allow for contact time

of one (1) hour.

6. When the contact time is completed, drain the tank. Refill with potable

water and flush the plumbing of all sanitizing solution.

NOTE: The sanitizing procedure outlined above is in conformance with the ap-

proved procedures of RVIA ANSI A 119.2 and the U.S. Public Health Service.

EXTERIOR SHOWER

Off Position

An exterior shower is provided for your convenience. The shower valve/hose

assembly is stored inside the rear doors. To use: lift the hinged exterior cover,

align the handle to the off position, and insert the shower handle assembly

G

G - 7

PLUMBING

into the wall mounted shower inlet. The assembly can only be inserted and

removed with handle aligned to the off position. Press the spout button and

rotate the handle counter clockwise to the desired temperature. To remove

handle assembly, return the handle to the off position, press the spout button

to relieve any residual pressure and pull the handle out of the wall insert. Snap

cover completely shut so rubber o-ring seal will seal and road dust and grime

from the insert assembly. Be sure to remove and drain the hose and open the

valves before opening the low point drain lines for winterization.

HEATED FRESH WATER TANK

The Interstate motorhome has 12-Volt heat pads installed with the fresh wa-

ter and grey water holding tanks to help prevent freezing. The tank pads are

controlled by a lighted switch located on the forward shower wall just inside

the sliding door. The switch is lit when the pads are on. Battery power will last

about 4 hours unless the unit has a 120-volt source (generator or shoreline) to

operate the inverter/charger. To conserve battery power in a remote location RV

antifreeze may be used to protect the tanks in freezing conditions.

DRAIN VALVE LOCATIONS

Drain and shut off

valve positions

open

close

Waterline

The fresh water system has four fresh water line low point drain valves. There

is two under the galley accessed by removing the drawer and two under the

curbside lounge or bed accessed by removing the cup holders. The cup hold-

ers lift up and out of the armrest.

The fresh water tank drain valve is located on the front of the tank pan under

the motorhome.

SHUT OFF VALVES

There is one shut off valve in the motorhome. It is for the toilet and is on the

water feed line beside the toilet base.

G - 8GG - 9

PLUMBING

TOILET

Manufacturer: Canada:

Thetford Corporation Thetford Sanitation Ltd.

7101 Jackson Road 2710 Slough Street

Ann Arbor, MI 48103 Mississauga, Ontario

313-769-6000 Canada, L4T 1G3

The RV toilet in your Airstream is a design that has been used for many years. In

normal use, when you are hooked up to city water, both pedals are depressed

together. This dumps the sewage and flushes fresh water down the side of

the bowl. Water will continue to run into the bowl for a short time after the

pedals are released. Follow manufacturers instruction on operating, cleaning,

and sanitizing toilet.

nOTiCE: When you dump the bowl of the toilet make sure all paper and

solids have cleared the slide mechanism before you allow it to close.

Trouble Shooting

1. Leaks:

a) Back of toilet: check water supply line connection at water valve.

Secure or tighten as necessary. If leak persists from water valve,

replace.

b) Vacuum breaker leaks while flushing: replace Vacuum Breaker or

water module, depending on model.

c) Between closet flange and toilet: check flange nuts for tightness.

If leak continues, remove toilet and check flange height. Use

Thetford spacers to adjust, if necessary, to 7/1 6” above floor.

Replace flange seal.

2) Toilet won’t hold water:

a) Check for and remove any debris from blade/ball seal track.

b) Check blade/ball seal compression with mechanism.

If blade/ball seal is worn, replace.

3) Harder than normal pedal or hand lever operation: Apply light film of Thetford

Toilet Seal Lubricant & Conditioner or silicone spray to blade/ball. (Note: To

avoid damage do not use spray lubricants other than silicone.)

4) Poor flush: Pedals or hand levers must be held fully open during flush. A

good flush should be obtained within 2 to 3 seconds. If problem persists, re-

move the water supply line and check flow rate. The flow rate should be at least

ten quarts (9.5 liters) per minute.

G

G - 9

PLUMBING

MAINTENANCE

If the bowl-sealing blade does not operate freely after extended use, it may be

restored to its original, smooth operating condition by applying a light film of

silicone spray to the blade. To clean the toilet use Thetford Aqua Bowl or any

other high grade, non-abrasive cleaner. Do not use highly concentrated or high

acid content household cleaners. They may damage the rubber seals.

REMOVAL

1. Shut off water valve behind toilet or main water supply and flush toilet.

2. Disconnect water supply line from toilet. You will probably find a small

mirror very useful.

3. Remove mounting nuts.

4. Cover riser or tank inlet with cardboard to prevent debris from falling into

tank.

Toilet Winterizing

Draining Method: Turn off RV’s water supply. Drain toilet bowl. Disconnect

supply line at water valve. Completely drain the toilet’s water supply line.

nOTiCE: To avoid damage, when using air pressure to blow water from

the lines, be sure toilet valve is in the open position.

nOTiCE: If water is frozen in the toilet, do not attempt to flush unti the

ice thaws.

Antifreeze Method: Use RV (potable) antifreeze only.

nOTiCE: Never use automotive type antifreeze.

For Thetford service centers: USA 1-800-521-3032

Canada: 1-888-215-5410

NOTE: Always replace flange seal when toilet has been removed.

G - 10GG - 11
