AirLive IP-1000R User Manual

I

P

-

R

Wired Broadband Router

1000

User’s Manual

1

Copyright

The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in
an information retrieval system, translated into any language, or transmitted in any form or by any
means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior
written permission.

Trademarks

All products, company, brand names are trademarks or registered trademarks of their respective
companies. They are used for identification purpose only. Specifications are subject to be changed
without prior notice.

FCC Interference Statement

The IP-1000R has been tested and found to comply with the limits for a Class B digital device pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against radio
interference in a commercial environment. This equipment can generate, use and radiate radio
frequency energy and, if not installed and used in accordance with the instructions in this manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause interference, in which case the user, at his own expense, will be required to take
whatever measures are necessary to correct the interference.

CE Declaration of Conformity

This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022/A1
Class B.

The specification is subject to change without notice.

2

Table of Contents

Chapter 1 Introduction ........................................................................................................4

Functions and Features.................................................................................................4

Packing List.....................................................................................................................6

Chapter 2 Hardware Installation........................................................................................7

2.1 Panel Layout.............................................................................................................7

2.2 Procedure for Hardware Installation..................................................................... 9

Chapter 3 Network Settings and Software Installation........................................................10

3.1 Make Correct Network Settings of Your Computer...........................................10

Chapter 4 Configuring IP-1000R Broadband Router........................................................... 11

4.1 Start-up and Log in ................................................................................................12

4.2 Status.......................................................................................................................13

4.3 Wizard...................................................................................................................... 14

4.4 Basic Setting...........................................................................................................15

4.5 Port Forwarding...................................................................................................... 26

4.6 Firewall Settings.....................................................................................................30

4.7 Advanced Settings................................................................................................. 43

4.8 Maintenance........................................................................................................... 53

Appendix A TCP/IP Configuration for Windows 95/98...................................................... 58

Appendix B FAQ and Troubleshooting ...............................................................................63

Reset to factory Default............................................................................................... 63

3

C

h

a

p

t

e

r

1

I

n

t

r

o

d

u

c

t

i

o

n

C

h

a

p

t

e

r

1

I

n

t

r

o

d

u

C

h

a

p

t

e

r

1

I

n

t

r

Congratulations on your purchase of this outstanding IP-1000R. This product is specifically designed
for Small Office and Home Of fice n eeds. It provide s a compl ete SO HO solutio n for Internet su rfing, an d
is easy to configure and operate even for non-technical users. Instructions for i nstalling and configuring
this product can be found in this manual. Before you install and use this product, please read this
manual carefully for fully exploiting the functions of this product.

Functions and Features

Router Basic functions

z Auto-sensing Ethernet Switch

Equipped with a 4-port auto-sensing Ethernet switch.

z WAN type supported

The router supports some WAN types, Static, Dynamic, PPPoE , PPTP ,L2TP, Dynamic IP
with Road Runner .

z Firewall

o

d

u

c

c

t

i

o

n

t

i

o

n

All unwanted packets from outside intruders are blocked to protect your Intranet.

z DHCP server supported

All of the networked computers can retrieve TCP/IP settings automatically from this product.

z Web-based configuring

Configurable through any networked computer’s web browser using Netscape or Internet
Explorer.

z Virtual Server supported

Enable you to expose WWW, FTP and other services on your LAN to be accessible to Internet
users.

z User-Definable Application Sensing Tunnel

User can define the attributes to support the special applications requiring multiple
connections, like Internet gaming, video conferencing, Internet telephony and so on, then this
product can sense the application type and open multi-port tunnel for it.

z DMZ Host supported

Lets a networked computer be fully exposed to the Internet; this function is used when special
application sensing tunnel feature is insufficient to allow an application to function correctly.

z Statistics of WAN Supported

Enables you to monitor inbound and outbound packets

4

Wireless functions

z High speed for wireless LAN connection

Up to 54Mbps data rate by incorporating Orthogonal Frequency Division Multiplexing
(OFDM).

z Roaming

Provides seamless roaming within the IEEE 802.11b (11M) and IEEE 802.11g (54M) WLAN
infrastructure.

z IEEE 802.11b compatible (11M)

Allowing inter-operation among multiple vendors.

z IEEE 802.11g compatible (54M)

Allowing inter-operation among multiple vendors.

z Auto fallback

54M, 48M, 36M, 24M, 18M, 12M, 6M data rate with auto fallback in 802.11g mode.

11M, 5.5M, 2M, 1M data rate with auto fallback in 802.11b mode.

Security functions

z Packet filter supported

Packet Filter allows you to control access to a network by analyzing the incoming and

outgoing packets and letting them p ass or halting them based on the IP address of the source
and destination.

z Domain Filter Supported

Let you prevent users under this device from accessing specific URLs.

z URL Blocking Supported

URL Blocking can block hundreds of websites connection by simply a keyword.

z VPN Pass-through

The router also supports VPN pass-through.

z 802.1X supported

When the 802.1X function is enabled, the Wireless user must authenticate to this router first
to use the Network service.

z Support WPA-PSK and WPA

When the WPA function is enabled, the Wireless user must authenticate to this router first to
use the Network service

z SPI Mode Supported

When SPI Mode is enabled, the router will check every incoming packet to detect if this
packet is valid.

z DoS Attac k Detec tion Supported

5

When this feature is enabled, the router will detect and log the DoS attack comes from the
Internet.

Advanced functions

z System time Supported

Allow you to synchronize system time with network time server.

z E-mail Alert Supported

The router can send its info by mail.

z Dynamic dns Supported

At present,the router has 3 ddns.dyndns,TZO.com and dhs.org.

z SNMP Supported

The router supports basic SNMP function.

z Routing Table Supported

Now, the router supports static routing.

z Schedule Rule supported

Customers can control some functions, like virtual server and packet filters when to access or
when to block.

Other functions

z UPNP (Universal Plug and Play)Supported

The router also supports this function. The applications: X-box, Msn Me ssenger.

Packing List

z Wireless broadband router unit
z Installation CD-ROM

z Power adapter
z CAT-5 UTP Fast Ethernet cabl e

6

C

h

a

p

t

e

r

2

H

a

r

d

w

a

r

I

e

n

s

t

a

l

l

a

t

i

n

o

C

h

a

p

t

e

r

2

H

a

r

d

w

a

r

e

I

n

s

t

a

l

l

C

h

a

p

t

e

r

2

H

a

r

d

w

a

r

e

I

n

2.1 Panel Layout

2.1.1. Front Panel

Figure 2-1 Front Panel

LED:

LED Function Color Status Description

POWER

Power
indication

Green On Power is being applied to this product.

a

s

t

a

l

l

a

t

i

o

n

t

i

o

n

Status

WAN

W.LAN

Link/Act.

1~4

10/100 Data Rate Green On

System

status

WAN port

activity

Wireless

activity

Link status Green

Green Blinking

Green

Green Blinking Sending or receiving data via wireless

On The WAN port is linked.

Blinking The WAN port is sending or receiving data.

On

Blinking

Status is flashed once per second to indicate system
is alive.

An active station is connected to the corresponding
LAN port.

The corresponding LAN port is sending or receiving
data.

Data is transmitting in 100Mbps on the
corresponding LAN port.

7

2.1.2. Rear Panel

Figure 2-2 Rear Panel

Ports:

Port Description
PWR
WAN
Port 1 - 4

RESET

Power inlet
The port where you will connect your cable (or DSL) modem or Ethernet router.
The ports where you will connect networked computers and other devices.

To reset system settings to factory defaults

8

2.2 Procedure for Hardware Installation

2. Decide where to place your IP-1000R Wireless Broadband Router

You can place your IP-1000R Wireless Broadband Router on a desk or other flat surface, or you
can mount it on a wall. For optimal performance, place your IP-1000R Wireless Broadband Router
in the center of your office (or your home) in a location that is away from any potential source of
interference, such as a metal wall or microwave oven. This location must be close to power and
network connection.

2. Setup LAN connection
a. Wired LAN connection: connects an Ethernet cable from your computer’s Ethernet port to one of

the LAN ports of this product.

b. Wireless LAN connection: locate this product at a proper position to gain the best transmit

performance

Figure 2-3 Setup of LAN and WAN conne ction s for this product.

3. Setup WAN connection
Prepare an Ethernet cable for connecting this product to your cable/xDSL modem or Ethernet

backbone. Figure 2-3 illustrates the WAN connection.

4. Power on

Connecting the power cord to power inlet and turning the power switch on, this product will
automatically enter the self-test phase. When it is in the self-test phase, the indicators M1 will be
lighted ON for about 10 seconds, and then M1 will be flashed 3 times to indicate that the self-test
operation has finished. Finally, the M1 will be continuously flashed once per second to indicate that
this product is in normal operation.

9

C

h

a

p

t

e

r

3

N

e

t

w

o

r

k

S

e

t

t

i

n

g

s

a

n

C

h

a

p

t

e

r

3

N

e

t

w

o

r

k

S

e

t

t

i

n

C

h

a

p

t

e

r

3

N

e

t

w

o

r

k

S

To use this product correctly, you have to properly configure the network settings of your computers and
install the attached setup program into your MS Windows platform (Windows 95/98/NT/2000).

3.1 Make Correct Network Settings of Your Computer

The default IP address of this product is 192.168.1.254, and the default subnet mask is 255.255.255.0.
These addresses can be changed on your need, but the default values are used in this manual. If the
TCP/IP environment of your computer has not yet been configured, you can refer to Appendix A to
configure it. For example,

1. configure IP as 192.168.1.1, subnet mask as 255.255.255.0 and g ateway as 192. 168.1.25 4, or
more easier,

2. configure your computers to load TCP/IP setting automatically, that is, via DHCP server of this
product.

g

e

t

t

i

n

g

d

s

a

n

s

a

n

d

d

f

t

w

a

r

e

I

n

s

t

a

l

l

a

t

i

o

n

S

o

o

f

t

w

a

r

e

I

n

s

t

a

l

l

S

f

t

w

a

r

e

I

S

o

n

a

s

t

a

l

l

a

t

i

o

n

t

i

o

n

After installing the TCP/IP communication protocol, you can use the ping command to check if your
computer has successfully connected to this product. The following example shows the pin g procedure
for Windows 95 platforms. First, execute the ping command

ping 192.168.1.254

If the following messages appear:

Pinging 192.168.1.254 with 32 bytes of data:
Reply from 192.168.1.254: bytes=32 time=2ms TTL=64

a communication link between your computer and this product has been successfully established.
Otherwise, if you get the following messages,

Pinging 192.168.1.254 with 32 bytes of data:
Request timed out.

There must be something wrong in your installation procedure. You have to check the following items in
sequence:

1. Is the Ethernet cable correctly connected between thi s pro duct and your computer?
Tip: The LAN LED of this product and the link LED of network card on your computer must be

lighted.

2. Is the TCP/IP environment of your computers properly configured?
Tip: If the IP address of this product is 192.168.1.254, the IP address of your computer must be

192.168.1.X and default gateway must be 192.168.1.254.

10

C

h

a

p

t

e

r

4

C

o

n

f

i

g

u

r

i

n

g

I

P

-

1

0

0

C

h

a

p

t

e

r

4

C

o

n

f

i

g

u

r

i

n

g

I

C

h

a

p

t

e

r

4

C

o

n

f

i

g

u

r

This product provides Web based configuration scheme, that is, configuring by your W eb browser, such
as Netscape Communicator or Internet Explorer. Th is approach can be adopted in any MS Windows,
Macintosh or UNIX based platforms.

P

i

n

g

I

P

0

-

1

0

0

0

-

1

0

0

0

R

R

R

o

a

d

b

a

n

d

R

o

u

t

e

r

B

r

r

o

a

d

b

a

n

d

R

B

o

a

d

b

B

r

a

n

d

o

R

o

u

u

t

e

r

t

e

r

11

4.1 Start-up and Log in

Activate your browser, and disable the proxy or add the IP address of this product into the
exceptions. Then, type this product’s IP addre ss in the Location (for Net scape ) or Address (for IE) field

and press ENTER. For example: http://192.168.1.254.
After the connection is established, you will see the web user interface of this product. There are two

appearances of web user interface: for general users and for system administrator.
A window would pop-up asking for Login and Password. Please enter “admin” for login, and “airlive”

or “ovislink” for password

12

4.2 Status

This option provides the function for observing this product’s working status:

A. WAN Port Status.

If the WAN port is assigned a dynamic IP, there may appear a “Renew” or “Release” button
on the Sidenote column. You can click this button to renew or release IP manually.

B. Statistics of WAN: enables you to monitor inbound and outbound packets

13

4.3 Wizard

Setup Wizard will guide you through a basic configuration procedure step by step. Press”Next ”

Setup Wizard - Select WAN Type: For detail settings, please refer to 4.4.1 primary setup.

14

4.4 Basic Setting

4.4.1 Primary Setup – WAN Type, Virtual Computers

Press “Change”

15

This option is primary to enable this product to work properly. The setting items and the web
appearance depend on the WAN type. Choose correct WAN type before you start.

1. LAN IP Address: the local IP address of this device. The computers on your network must use the

LAN IP address of your product as their Default Gateway. You can change it if necessary .

2. WAN Type: WAN connection type of your ISP. You can click Change button to choose a correct

one from the following four options:

A. Static IP Address: ISP assigns you a static IP address.
B. Dynamic IP Address: Obtain an IP address from ISP automatically.
C. Dynamic IP Address with Road Runner Session Management.(e.g. Telstra BigPond)
D. PPP over Ethernet: Some ISPs require the use of PPPoE to connect to their services.
E. PPTP: Some ISPs require the use of PPTP to connect to their services.
F. L2TP: Some ISPs require the use of L2TP to connect to their services

16

4.4.1.1 Static IP Address

WAN IP Address, Subnet Mask, Gateway, Primary and Secondary DNS: enter the proper setting
provided by your ISP.

4.4.1.2 Dynamic IP Address

1. Host Name: optional. Required by some ISPs, for example, @Home.

2. Renew IP Forever: this feature enables this product to renew your IP address automatically when
the lease time is expiring-- even when the system is idle.

4.4.1.3 Dynamic IP Address with Road Runner Session Management.(e.g. Telstra BigPond)

1. LAN IP Address is the IP address of this product. It must be the default gateway of your
computers.

2. WAN Type is Dynamic IP Address. If the WAN type is not correct, change it!

3. Host Name: optional. Required by some ISPs, e.g. @Home.

4. Renew IP Forever: this feature enable this product renew IP address automatically when the
lease time is being expired even the system is in idle state.

4.4.1.4 PPP over Ethernet

1. PPPoE Account and Password: the account and password your ISP assigned to you. For

security,

this field appears blank. If you don't want to change the password, leave it empty.

2. PPPoE Service Name: optional. Input the service name if your ISP requires it. Otherwise, leave

it blank.

3. Maximum Idle T ime: the amount of time of inactivity before disconnecting your PPPoE session.

Set it to zero or enable Aut o-reconn ect to disable this feature.

4. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The most common

MTU value is 1492.

5. Connection Control: There are 3 modes to select:

Connect-on-demand: The device will link up with ISP when the clients send outgoing packets.

Auto-Reconnect(Always-on): The device will link up with ISP until the connection is establi shed.

Manually: The device will not make the link until someone clicks the connect-button in the

Status-page.

17

4.4.1.5 PPTP

1. My IP Address and My Subnet Mask: the private IP address and subnet mask your ISP assigned

to you.

2. Server IP Address: the IP address of the PPTP server .

3. PPTP Account and Password: the account and password your ISP assigned to you. If you don't

want to change the password, keep it empty.

3. Connection ID: optional. Input the connection ID if your ISP requires it.

4. Maximum Idle Time: the time of no activity to disconnect your PPTP session. Set it to zero or

enable Auto-reconnect to disable this feature. If Auto-reconnect is enabled, this product will
connect to ISP automatically, after system is restarted or connection is dropped.

5. Connection Control: There are 3 modes to select:

Connect-on-demand: The device will link up with ISP when the clients send outgoing packets.

Auto-Reconnect(Always-on):The device will link upw with ISP until the connection is established.

Manually: The device will not make the link until someone clicks the connect-button in the

Status-page.

18

4.4.1.6 L2TP

First, please check your ISP assigned and Select Static IP Address or Dynamic IP Address.

For example: Use Static

1. My IP Address and My Subnet Mask: the private IP address and subnet mask your ISP assigned

to you.

2. Server IP Address: the IP address of the PPTP server .

3. PPTP Account and Password: the account and password your ISP assigned to you. If you don’t

want to change the password, keep it empty.

3. Connection ID: optional. Input the connection ID if your ISP requires it.

4. Maximum Idle Time: the time of no activity to disconnect your PPTP session. Set it to zero or

enable Auto-reconnect to disable this feature. If Auto-reconnect is enabled, this product will
connect to ISP automatically, after system is restarted or connection is dropped.

6. Connection Control: There are 3 modes to select:

Connect-on-demand: The device will link up with ISP when the clients send outgoing packets.

Auto-Reconnect(Always-on):The device will link up with ISP until the connection is established.

Manually: The device will not make the link until someone clicks the connect-button in the

Status-page.

19

4.4.1.7 Virtual Computers

Virtual Computer enables you to use the original NAT feature, and allows you to setup the one-to-one
mapping of multiple global IP address and local IP address.

• Global IP: Enter the global IP address assigned by your ISP.

• Local IP: Enter the local IP address of your LAN PC corresponding to the global IP address.

• Enable: Check this item to enable the Virtual Computer feature.

20

4.4.2 DHCP Server

Press “More”
The settings of a TCP/IP environment include host IP, Subnet Mask, Gateway, and DNS co nfigurations.

It is not easy to manually configure all the computers and devices in your network. Fortunately, DHCP
Server provides a rather simple approach to handle all these settings. This product supports the
function of DHCP server. If you enable this product’s DHCP server and configure your computers as
“automatic IP allocation” mode, then when your computer is powered on, it will automatically load the
proper TCP/IP settings from this product. The settings of DHCP server include the following items:

1. DHCP Server: Choose “Disable” or “Enable.”

2. IP pool starting Address/ IP pool starting Address: Whenever there is a request, the DHCP

server will automatically allocate an unused IP address from the IP address pool to the
requesting computer . You must specify the starting and ending address of the IP address pool.

3. Domain Name: Optional, this information will be passed to the client.

4. Primary DNS/Secondary DNS: This feature allows you to assign DNS Servers

5. Primary WINS/Secondary WINS: This feature allows you to assign WINS Servers

6. Gateway: The Gateway Address would be the IP address of an alternate Gateway.

This function enables you to assign another gateway to your PC, when DHCP
server offers an IP to your PC.

21

4.4.3 Wireless Setting, and 802.1X setting

Wireless settings allow you to set the wireless configuration items.

1. Network ID (SSID): Network ID is used for identifying the Wireless LAN (WLAN). Client stations

can roam freely over this product and other Access Points that have the same Network ID. (The
factory setting is “default”)

2. Channel: The radio channel number. The permissible channels depend on the Regulato ry Domain.

The factory setting is as follow: channel 6 for North America; channel 7 for European (ETSI);
channel 7 for Japan.

3. WEP Security: Select the data privacy algorithm you want. Enabling the security can protect your

data while it is transferred from one station to another. The standardized IEEE 802.11 WEP (128 or
64-bit) is used here.

4. WEP Key 1, 2, 3 & 4: When you enable the 128 or 64 bit WEP key security, please select one WEP

key to be used and input 26 or 10 hexadecimal (0, 1, 2…8, 9, A, B…F) digits.

5. Pass-phrase Generator: Since hexadecimal characters are not easily

remembered, this device offers a conversion utility to convert a simple
word or phrase into hex.

6. 802.1X Setting

22

802.1X

Check Box was used to switch the function of the 802.1X. When the 802.1X function is enabled, the
Wireless user must authenticate to this router first to use the Network service.
RADIUS Server

IP address or the 802.1X server’s domain-name.
RADIUS Shared Key

Key value shared by the RADIUS server and this router. Thi s key value is consi stent with the key value
in the RADIUS server.

23

WPA-PSK

1. Select Preshare Key Mode

If you select HEX,you have to fill in 64 hexadecimal (0, 1, 2…8, 9, A, B…F) digits
If ASCII,the length of preshare key is from 8 to 63.

2. Fill in the key, Ex 12345678

24

WPA

Check Box was used to switch the function of the WPA. When the WPA function is enabled, the
Wireless user must authenticate to this router first to use the Network service. RADIUS Server

IP address or the 802.1X server’s domain-name.
RADIUS Shared Key

Key value shared by the RADIUS server and this router. Thi s key value is consi stent with the key value
in the RADIUS server.

25

4.5 Port Forwarding

4.5.1 Virtual Server

This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind
this product are invisible to the outside world. If you wish, you can make some of them accessible by
enabling the Virtual Server Mapping.
A virtual server is defined as a Service Port, and all requests to this port will be redirected to the
computer specified by the Server IP. Virtual Server can work with Scheduling Rules, and give user
more flexibility on Access control. For Detail, please refer to Scheduling Rule.

For example, if you have an FTP server (port 21) at 192.168.1.1, a Web server (port 80) at 19 2.168.1.2,
and a VPN server at 192.168.1.6, then you need to specify the following virtual server mapping table:

26

Service Port Server IP Enable

21 192.168.1.1 V
80 192.168.1.2 V

1723 192.168.1.6 V

27

4.5.2 Special AP

Some applications require multiple connections, like Internet games, Video conferencing, Internet
telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router.
The Special Applications feature allows some of these applications to work with this product. If the
mechanism of Special Applications fails to make an application work, try setting your computer as the
DMZ host instead.

1. Trigger: the outbound port number issued by the application..

2. Incoming Ports: when the trigger packet is detected, the inbound packets sent to the specified

port numbers are allowed to pass through the firewall.

This product provides some predefined settings Select your application and click Copy to to add the
predefined setting to your list.

Note! At any given time, only one PC can use each Special Application tunnel.

4.5.3 Miscellaneous Items

28

IP Address of DMZ Host

DMZ (DeMilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be
exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet
telephony and other special applications.

NOTE: This feature should be used only when needed.

Non-standard FTP port

You have to configure this item if you want to access an FTP server whose port number is not 21. This
setting will be lost after rebooting.

29

4.6 Firewall Settings

30

4.6.1 Packet Filter

Packet Filter enables you to control what packet s are allowed to p ass the route r. Outbound filter applies
on all outbound packets. However, Inbound filter applies on packets that destined to Virtual Servers or
DMZ host only. You can select one of the two filtering policies:

1. Allow all to pass except those match the specified rules

2. Deny all to pass except those match the specified rules

You can specify 8 rules for each direction: inbound or outbound. For each rule, you can define the
following:

• Source IP address

• Source port address

• Destination IP address

• Destination port address

• Protocol: TCP or UDP or both.

• Use Rule#

For source or destination IP address, you can define a single IP address (4.3.2.1) or a range of IP
addresses (4.3.2.1-4.3.2.254). An empty implies all IP addresses.

31

For source or destination port, you can define a single port (80) or a range of ports (1000-1999). Add
prefix "T" or "U" to specify TCP or UDP protocol. For example, T80, U53, U2000-2999. No prefix
indicates both TCP and UDP are defined. An empty implies all port addresses. Packet Filter can work
with Scheduling Rules, and give user more flexibility on Access control. For Detail, please refer to
Scheduling Rule.

Each rule can be enabled or disabled individually.

Inbound Filter:

To enable Inbound Packet Filter click the check box next to Enable in the Inbound Packet Filter
field.

Suppose you have SMTP Server (25), POP Server (110), Web Server (80), FTP Server (21), and News
Server (119) defined in Virtual Server or DMZ Host.
Example 1:

(1.2.3.100-1.2.3.149) They are allow to send mail (port 25), receive mail (port 110), and browse the
Internet (port 80)

(1.2.3.10-1.2.3.20) They can do everything (block nothing) Others are all blocked.

32

Example 2:

(1.2.3.100-1.2.3.1 19 ) They can do every thing except read net news (po rt 119) and transfer files via FTP
(port 21)
Others are all allowed.

After Inbound Packet Filter setting is configured, click the save button.

Outbound Filter:

To enable Outbound Packet Filter click the check box next t o Enable in the Outbound Packet Filter
field.

33

Example 1:

(192.168.1.100-192.168.1.149) They are allowed to send mail (port 25), receive mail (port 110), and
browse Internet (port 80); port 53 (DNS) is necessary to resolve the domain name.

(192.168.1.10-192.168.1.20) They can do everything (block nothing)
Others are all blocked.

34

Example 2:

(192.168.1.100-192.168.1.119) They can do everything except read net news (port 119) and transfer
files via FTP (port 21)

Others are allowed

After Outbound Packet Filter setting is configured, click the save button.

35

4.6.2 Domain Filter

Domain Filter

Let you prevent users under this device from accessing specific URLs.

Domain Filter Enable

Check if you want to enable Domain Filter.

Log DNS Query

Check if you want to log the action when someone accesses the specific URLs.

Privilege IP Addresses Range

Setting a group of hosts and privilege these hosts to access network without restriction.

Domain Suffix

A suffix of URL to be restricted. For example, ".com", "xxx.com".

Action

When someone is accessing the URL met the domain-suffix, what kind of action you want.
Check drop to block the access. Check log to log these access.

Enable

Check to enable each rule.

36

Example:

In this example:

1. URL include “www.msn.com” will be blocked, and the action will be record in log-file.

2. URL include “www.sina.com” will not be blocked, but the action will be record in log-file.

3. URL include “www.google.com” will be blocked, but the action will not be record in log-file.

4. IP address X.X.X.1~ X.X.X.20 can access network without restriction.

37

4.6.3 URL Blocking

URL Blocking will block LAN computers to connect to pre-defined Websites.

The major difference between “Domain filter” and “URL Blocking” is Domain filter require user to input
suffix (like .com or .org, etc), while URL Blocking require user to input a keyword only. In other words,
Domain filter can block specific website, while URL Blocking can bl ock hundreds of websites by simply
a keyword.

URL Blocking Enable

Checked if you want to enable URL Blocking.

URL

If any part of the Website's URL matches the pre-defined word, the connection will be blocked.
For example, you can use pre-defined word "sex" to block all websites if their URLs contain pre-defined
word "sex".

Enable

Checked it to enable each rule.

38

In this example:

1. URL include “msn” will be blocked, and the action will be record in log-file.

2. URL include “sina” will be blocked, but the action will be record in log-file

3. URL include “cnnsi” will not be blocked, but the action will be record in log-file.

4. URL include “espn” will be blocked, but the action will be record in log-file

39

4.6.4 MAC Address Control

MAC Address Control allows you to assign different access right for different users and to assign a
specific IP address to a certain MAC address.

MAC Address Control Check “Enable” to enable the “MAC Address Control”. All of the

settings in this page will take effect only when “Enable” is checked.

Connection control Check "Connection control" to enable the controlling of which wired and

wireless clients can connect to this device. If a client is denied to connect to
this device, it means the client can't access to the Internet either. Choose
"allow" or "deny" to allow or deny the clients, whose MAC addresses are not
in the "Control table" (please see below), to connect to this device.

Association control Check "Association control" to enable the controlling of which wireless

client can associate to the wireless LAN. If a client is denied to associate
to the wireless LAN, it means the client can't send or receive any data via
this device. Choose "allow" or "deny" to allow or deny the clients, whose
MAC addresses are not in the "Control table", to associate to the wireless
LAN.

40

Control table

"Control table" is the table at the bottom of the "MAC Address Control" page.
Each row of this table indicates the MAC address and the expected IP
address mapping of a client. There are four columns in this table:

MAC Address

IP Address

C

A

In this page, we provide the following Combobox and button to help you to input the MAC address.

You can select a specific client in the “DHCP clients” Combobox, and then click on the “Copy to” button

MAC address indicates a specific client.
Expected IP address of the corresponding

client. Keep it empty if you don't care its IP
address.

When "Connection control" is checked,
check "C" will allow the corresponding
client to connect to this device.

When "Association control" is checked,
check "A" will allow the corresponding
client to associate to the wireless LAN.

to copy the MAC address of the client you select to the ID selected in the “ID” Combobox.

Previous page and Next Page To make this setup page simple and clear, we have divided the

“Control table” into several pages. You can use these buttons to
navigate to different pages.

41

4.6.5 Miscellaneous Items

Remote Administrator Host/Port

In general, only Intranet user can browse the built-in web pages to perform administration task. This
feature enables you to perform administration task from remote host. If this feature is enabled, only the
specified IP address can perform remote admini stration. If the specified IP address is 0.0.0.0, any host
can connect to this product to perform administration task. You can use subnet mask bits "/nn" notation
to specified a group of trusted IP addresses. For example, "10.1.2.0/24".

NOTE: When Remote Administration is enabled, the web server port will be shifted to 88. You can
change web server port to other port, too.

Administrator Time-out

The time of no activity to logout automatically. Set it to zero to disable this feature.

Discard PING from WAN side

When this feature is enabled, any host on the WAN cannot ping this product.

SPI Mode

When this feature is enabled, the router will record the packet information pass through the router like
IP address, port address, ACK, SEQ number and so on. And the router will check every inco ming
packet to detect if this packet is valid.

DoS Attack Detection

When this feature is enabled, the router will detect and log the DoS attack comes from the Internet.
Currently, the router can detect the following DoS attack: SYN Attack, WinNuke, Port Scan, Ping of
Death, Land Attack etc.

42

4.7 Advanced Settings

4.7.1 System Time

43

Get Date and Time by NTP Protocol

Selected if you want to Get Date and Ti me by NTP Protocol.

Time Server

Select a NTP time server to consult UTC time

Time Zone

Select a time zone where this device locates.

Set Date and Time manually

Selected if you want to Set Date and Time manually.

Set Date and Time manually

Selected if you want to Set Date and Time manually.

Function of Buttons
Sync Now: Synchronize system time with network time server

Daylight Saving:Set up where the location is.

4.7.2 System Log

This page support two methods to export system logs to specific destination by means of syslog(UDP)
and SMTP(TCP). The items you have to setup including:

44

IP Address for Syslog

Host IP of destination where syslogs will be sent to.
Check Enable to enable this function.

E-mail Alert Enable

Check if you want to enable Email alert (send syslog via email).

SMTP Server IP and Port

Input the SMTP server IP and port, which are connected with ':'. If you do not specify port number, the
default value is 25.
For example, "mail.your_url.com" or "192.168.1.100:26".

Send E-mail alert to

The recipients who will receive these logs. You can assign more than 1 recipient, using ';' or ',' to
separate these email addresses.

4.7.3 Dynamic DNS

To host your server on a changing IP address, you have to use dyna mic domain name service (DDNS ).

So that anyone wishing to reach your host only needs to know the name of it. Dynamic DNS will map
the name of your host to your current IP address, which changes each time you connect your Internet
service provider.

Before you enable Dynamic DNS, you need to register an account on one of these Dynamic DNS
servers that we list in provider field.

To enable Dynamic DNS click the check box next to Enable in the DDNS field.

45

Next you can enter the appropriate information about your Dynamic DNS Server.

You have to define:

Provider

Host Name

Username/E-mail

Password/Key

You will get this information when you register an account on a Dynamic DNS server.

Example:

After Dynamic DNS setting is configured, click the save button.

46

4.7.4 SNMP Setting

In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the
capability to remotely manage a computer network by polling and setting terminal values and
monitoring network events.

Enable SNMP

You must check either Local or Remote or both to enable SNMP function. If Local is che c ked, this
device will response request from LAN. If Remote is checked, this device will response request from
WAN.

Get Community

Setting the community of GetRequest your device will response.

Set Community

Setting the community of SetRequest your device will accept.

47

4.7.5 Routing Table

Routing Tables allow you to determine which physical interface address to use for outgoing IP data

grams. If you have more than one routers and subnets, you will need to enable routing table to allow
packets to find proper routing path and allow different subnets to communicate with each other.

Routing Table settings are settings used to setup the functions of static.

Static Routing: For static routing, you can specify up to 8 routing rules. You can enter the destination
IP address, subnet mask, gateway, hop for each routing rule, and then enable or disable the rule by
checking or unchecking the Enable checkbox.

48

Example:

Configuration on NAT Router

Destination SubnetMask Gateway Hop Enabled

192.168.1.0 255.255.255.0 192.168.123.216 1 ˇ

192.168.0.0 255.255.255.0 192.168.123.103 1 ˇ

So if, for example, the client3 wanted to send an IP data gram to 192.168.0.2, it would use the above
table to determine that it had to go via 192.168.1.103 (a gateway),
And if it sends Packets to 192.168.1.11 will go via 192.168.1.216
Each rule can be enabled or disabled individually.
After routing table setting is configured, click the save button.

49

4.7.6 Schedule Rule

You can set the schedule time to decide which service will be turned on or off. Select the “enable” item.
Press “Add New Rule”

You can write a rule name and set which day and what time to sche dule from “Start T ime” to “End Time”.
The following example configure “ftp time” as everyday 14:10 to 16:20

50

After configure Rule 1Æ

Schedule Enable

Selected if you want to Enable the Scheduler.
Edit
To edit the schedule rule.
Delete
To delete the schedule rule, and the rule# of the rules behind the deleted one will decrease one
automatically.
Schedule Rule can be apply to Virtual server and Packet Filter, for example:

51

Exanple1: Virtual Server – Apply Rule#1 (ftp time: everyday 14:10 to 16:20)

Exanple2: Packet Filter – Apply Rule# 1 (ftp time: everyday 14:10 to 16:20).

52

4.8 Maintenance

53

4.8.1 Change Password

You can change Password here. We strongly recommend you to change the system password for
security reason.

4.8.2 System Log

You can View system log by clicking the View Log button

54

4.8.2 Firmware Upgrade

You can upgrade firmware by clicking Firmware Upgrade button.

55

4.8.3 Backup Setting

You can backup your settings by clicking the Backup Setting button and save it as a bin file. Once you
want to restore these settings, please click Firmware Upgrade button and use the bin file you saved.

4.8.4 Reset to default

You can also reset this product to factory default by clicking the Reset to default button.

4.8.5 Reboot

You can also reboot this product by clicking the Reboot button.

56

4.8.6 Miscellaneous Items

MAC Address for Wake-on-LAN

Wake-on-LAN is a technology that enables you to power up a networked device remotely . In order to
enjoy this feature, the target device must be Wake-on-LAN enabled and you have to know the MAC
address of this device, say 00-11-22-33-44-55. Clicking "Wake up" button will make the router to send
the wake-up frame to the target device immediately.

57

A

p

p

e

n

d

i

x

A

T

C

P

/

I

P

C

o

n

f

i

g

u

r

a

A

p

p

e

n

d

i

x

A

T

C

P

/

I

P

C

o

n

f

A

p

p

e

n

d

i

x

A

T

C

P

/

I

P

C

This section introduces you how to install TCP/IP protocol into your personal computer. And suppose
you have been successfully installed one network card on your personal computer. If not, please refer
to your network card manual. Moreover, the Section B.2 tells you how to set TCP/IP values for working
with this NAT Router correctly .

A.1 Install TCP/IP Protocol into Your PC

1. Click Start button and choose Settings, then click Control Panel.

2. Double click Network icon and select Configuration tab in the Network window.

3. Click Add button to add network component into your PC.

4. Double click Protocol to add TCP/IP protocol.

o

n

i

f

i

g

g

u

u

t

r

a

t

r

a

t

o

r

W

i

n

d

o

w

s

9

5

/

9

8

i

o

n

f

f

o

r

W

i

n

d

o

w

s

i

o

n

o

r

W

i

n

i

o

n

f

d

o

w

9

s

9

5

/

9

8

5

/

9

8

5. Select Microsoft item in the manufactures list. And choose TCP/IP in the Network Protocols. Click

OK button to return to Network window.

58

6. The TCP/IP protocol shall be listed in the Network window. Click OK to complete the install

procedure and restart your PC to enable the TCP/IP protocol.

A.2 Set TCP/IP Protocol for Working with NAT Router

1. Click Start button and choose Settings, then click Control Panel.

2. Double click Network icon. Select the TCP/IP line that has been associated to your network card in

the Configuration tab of the Network window.

3. Click Properties button to set the TCP/IP protocol for this NAT Router.

4. Now, you have two setting methods:

59

a. Select Obtain an IP address au tomatically in the IP Address tab.

b. Don’t input any value in the Gateway tab.

60

c. Choose Disable DNS in the DNS Configuration tab.

B. Configure IP manually

a. Select Specify an IP address in the IP Address tab. The default IP address of this

product is 192.168.1.254. So please use 192.168.1.xxx (xxx is between 1 and 253) for
IP Address field and 255.255.255.0 for Subnet Mask field.

61

b. In the Gateway tab, add the IP address of this product (default IP is 192.168.1.254) in

the New gateway field and click Add button.

c. In the DNS Configuration tab, add the DNS values which are provided by the ISP into

DNS Server Search Order field and click Add button.

62
