AirLive FE-200DM User Manual

FE-200DM

2-MegaPixel Ceiling Mount Fish Eye PoE IPCAM

User’s Manual

AirLive FE-200DM Manual

Owner's Record

The model and serial numbers are located at the bottom of device. Record these numbers in the spaces provided below. Refer to these numbers whenever you call upon your dealer regarding this product.

Model No. ____________________ Serial No. ____________________

To prevent fire or shock hazard, do not expose the unit to rain or moisture. For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

AirLive FE-200DM Manual

For customers in the U.S.A.

This equipment has been tested and found to comply with the limits for a digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

– Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

The shielded interface cable recommended in this manual must be used with this equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

Declaration of Conformity

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may

cause undesired operation.

IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device.

AirLive FE-200DM Manual

NOTICE TO USERS

© 2006~11 All rights reserved. This manual or the software described herein, in whole or in part, may not be reproduced, translated or reduced to any machine readable form without prior written approval.

This product contains some codes from GPL. In compliance with GPL agreement, AirLive

will publish the GPL codes on our website. Please go to www.airlive.com and go to the

"Support->GPL" menu to download source code.

WE PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE OR SUCH OTHER INFORMATION. IN NO EVENT SHALL WE BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.

We reserve the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.

AirLive FE-200DM Manual

iii

Table of Contents

1. Introduction.................................................................................................................1

1.1 Overview..............................................................................................................1

1.2 Package Contents ...............................................................................................2

1.3 Physical Overview and Connections....................................................................3

1.4 Mounting the Camera ..........................................................................................5

1.5 Install the Camera in LAN....................................................................................6

2. Preparation..................................................................................................................7

2.1 Search and Set up by IPWizard II........................................................................7

2.1.1 Search .......................................................................................................7

2.2 UPnP of Windows® XP, Vista or 7.......................................................................8

2.3 Install the Device behind a NAT Router ...............................................................9

2.4 Access the Device from the Internet Explorer for the First Time........................10

2.5 Logging in as an User........................................................................................11

2.6 Logging in as an Administrator ..........................................................................11

3. Operating the Network Camera ...............................................................................12

4. Administrating the Device ........................................................................................16

4.1 Video: Configure Profile.....................................................................................16

4.1.1 General....................................................................................................16

4.1.2 Advanced.................................................................................................17

4.2 Camera: Adjust Camera Parameters .................................................................19

4.2.1 General....................................................................................................19

4.2.2 Advanced.................................................................................................21

4.3 Event .................................................................................................................27

4.3.1 Event Server............................................................................................27

4.3.2 Motion Detection......................................................................................28

4.3.3 I/O Ports ..................................................................................................30

4.3.4 Event Configuration .................................................................................31

i AirLive FE-200DM Manual

Table of Contents

4.4 Schedule............................................................................................................31

4.4.1 General....................................................................................................31

4.4.2 Storage....................................................................................................32

4.5 Network .............................................................................................................32

4.5.1 General....................................................................................................32

4.5.2 Advanced.................................................................................................34

4.5.3 SMTP (Setup E-Mail Configuration) ........................................................35

4.5.4 DDNS (Dynamic DNS).............................................................................35

4.6 System...............................................................................................................36

4.6.1 Information...............................................................................................36

4.6.2 User.........................................................................................................37

4.6.3 Day & Time..............................................................................................37

4.6.4 Server Maintenance ................................................................................38

4.6.5 Log Service..............................................................................................40

4.7 Customize..........................................................................................................40

5. Appendix....................................................................................................................42

Appendix A: Restore Factory Default.......................................................................42

Appendix B: Alarm I/O Connector ............................................................................43

Appendix C: Troubleshooting & Frequently Asked Questions..................................44

Appendix D: PING IP Address .................................................................................50

Appendix E: Bandwidth Estimation..........................................................................51

Appendix F: Specifications.......................................................................................51

Appendix G: Configure Port Forwarding Manually...................................................53

Appendix H: DDNS Application................................................................................56

Appendix I: Power Line Frequency..........................................................................62

Appendix J: 3GPP ...................................................................................................63

Appendix K: Enable UPnP of Windows XP..............................................................64

AirLive FE-200DM Manual

1. Introduction

1.1 Overview

AirLive FE-200DM is a Fish-Eye Panorama Network Dome Camera featured with 2Mega Pixel resolution and superior H.264-AVC performance and rich functions. AirLive FE-200DM includes a fish-eye lens for 360° panoramic wide angle view without blind spot. It is very suitable to view a wide area with only one single camera such as hallway, store, and office without the need to install multiple cameras.

The hardware base panorama video processing ability provides user flexible video layout including broad view, double broad view, 3 PTZ view, QUAD view, and table view. The e-PTZ function, pan, tilt and Zoom In/Out without moving parts, can replace traditional PTZ camera and thus save lost of traditional mechanical Pan/Tilt maintain cost.

The PoE function is designed for flexible installation. Further functions include two-way audio, DI/DO alarm application and micro SD card slot for local storage application.

AirLive FE-200DM Manual

Features

z Panoramic 360 Degrees Full View z H.264 & MJPEG Video Compression z 2 Megapixels Resolution at 1600 x 1200 pixels z Two-way Audio Support z Mechanical ICR z Built-In Speaker & Microphone z Micro SD Card Slot for Local Storage z Power-Over-Ethernet 802.3af z Advanced e-PTZ z Support Ceiling Mount, Wall Mount and Table View Application

1. Introduction

Minimum System Requirements

z Microsoft Internet Explorer 7.0 or later z Microsoft Media Player 11.0 or later (to playback recorded file) z VGA Monitor resolution 1280 x 1024 or higher z Pentium-4 3.6 GHz or higher z Memory Size: 1GB or more z Windows XP, Vista, 7

1.2 Package Contents

A user can find the following items in the package:

1. FE-200DM

2. Power Adapter dedicates 12V DC electric power output to Network Camera.

3. Installation CD provides installation software, application program, tutorial videos,

important information and instructions for operating the Network Camera.

4. Quick Start Guide provides important information and instructions for installing this

device.

Note: Using a power supply with a different voltage than the one included with the Network Camera will cause damage and void the warranty for this product.

AirLive FE-200DM Manual

1.3 Physical Overview and Connections

1. Introduction

1. Light Sensor:

The Light sensor is for detecting IP Camera environmental illumination. If IP Camera is in the dark/night environment, IR Cut Filter is switched off to let infrared light pass through for clear night view.

2. MIC:

The IP Camera has built-in an internal microphone, which is hidden in the pinhole located on the front panel.

3. Lens Focus Adjustment:

Rotate the lens to adjust the focal length to the best image. If necessary, clean the lens with a soft cotton cloth.

4. Speaker:

The IP Camera has built-in an internal speaker, which is hidden in the pinhole located on the front panel.

5. Reset Button

This button is hidden in the pinhole. For more information, please refer to Appendix A for Restore Factory Default instruction.

AirLive FE-200DM Manual

1. Introduction

6. Power Jack:

The input power is DC 12V, 2A.

Note: ONLY use package power adapter supplied with the internet. Otherwise, the

product may be damaged.

7. RJ-45 LAN Socket:

Connect to PC or Hub / Switch via a 10Base-T Ethernet or 100Base-TX Fast Ethernet Cable. This Ethernet port built with audio-negotiation protocol which can detect or negotiate the transmission speed of the network automatically. Please use CAT-5 cable to connect the Network Camera to a 100Mbps Fast Ethernet network switch or hub.

Note: ONLY use one power source, either from DC or from 802.3af Power over Ethernet.

8. Micro SD Card Slot:

The IP Camera has built-in a Micro SD card slot which can accepts Micro SD memory card for image / video event recording.

9. Audio In:

Connect a microphone to the IP Camera. Be noted to use actively microphone (normally with power supplier on microphone) for this application.

10. Audio Out:

Connect a loud speaker to the IP Camera. This is for voice alerting and two-way audio. Be noted to use actively speaker (normally with power supplier on speaker) for this application.

AirLive FE-200DM Manual

11. GPIO:

The 7 pin terminal block includes 4 input ports and 1 output ports.

1.4 Mounting the Camera

Fix the camera with as below.

1. Take out the camera and accessories from the package:

1. Introduction

The installation sticker, stand and FE-200DM

2. First, paste the sticker to a suitable position. Fasten the screws with stand into the mounting hole. Pass the network cable through the "conduit hole".

AirLive FE-200DM Manual

1. Introduction

3. Connect the network cable into the camera, and then mount the camera onto the stand.

4. Rotate the camera by clockwise to mount it firmly.

1.5 Install the Camera in LAN

1. Plug an Ethernet cable into the Camera

Connect an Ethernet cable to the LAN socket and attach it into the network.

2. Connect the external power supply to Camera

Connect the attached power adapter to the DC power jack of the camera.

Note: Use the power adapter, 12VDC, included in the package and connect it to wall

outlet for AC power.

Once you have installed the camera well and powered it on, the power LED (orange) will turn on later. The power LED turned on, it means the system is booting up successfully. Furthermore, if you have a proper network connection, and access to the camera, the LAN LED (green) will flash.

AirLive FE-200DM Manual

2. Preparation

2.1 Search and Set up by IPWizard II

When you installed the Camera on a LAN environment, you have two easy ways to search your Cameras by IPWizard II or UPnP™ discovery. Here is the way to execute IPWizard II to discover Camera’s IP address and set up related parameter in a Camera.

2.1.1 Search

When launch the IPWizard II, a searching window will pop up. IPWizard II is starting to search Network Cameras on the LAN. The existed devices will be listed as below.

AirLive FE-200DM Manual

2. Preparation

2.2 UPnP of Windows® XP, Vista or 7

UPnP™ is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. This device is an UPnP enabled device. If the operating system, Windows XP, Vista or 7, of your PC is UPnP enabled, the Network Camera will be very easy to be found.

Please refer to Appendix J to enable UPnP settings only if your operating system of PC is running Windows XP.

Note: Windows 2000 does not support UPnP feature.

To discover your device, go to your Desktop and click My Network Places.

AirLive FE-200DM Manual

2. Preparation

Click the targeted Device. Then Internet Explorer will connect to this Network Camera

automatically.

2.3 Install the Device behind a NAT Router

Once installed, the device is accessible on your LAN. To access the device from the Internet, you must configure your broadband router to allow incoming data traffic to the device. If the device is installed on the LAN with a router, then it may get a dynamic IP address from the DHCP server. However, if the device wants to be accessed from the WAN, its IP address needs to be setup as fixed IP, also the port forwarding or Virtual Server function of router needs to be setup. However, if your NAT router supports UPnP feature, it can be very easy to achieve NAT traversal automatically. To do this, enable the NAT-traversal feature, which will attempt to automatically configure the router to allow access to the camera.

Installing the device with an UPnP router on your network is an easy 3-step procedure:

(1) Enable UPnP option of your NAT router　 (2) Enable UPnP NAT traversal option of the Network Ca　 mera (default) (3) Access your Network Camera by DIPS　

AirLive FE-200DM Manual

2. Preparation

(1) Enable UPnP option of your NAT router

To use UPnP IGD function (NAT traversal), you need to make sure the UPnP function is enabled in your router. Most new home routers should support this function. Some of routers are default enable and others are not. Please check user’s manual of your NAT router for detail.

(2) Enable UPnP NAT traversal option of the Network Camera

Refer to Setting Î Network Î UPnP page for detail NAT traversal setting.

Note that this option is default enabled.

(3) Access your Network Camera by DIPS

Refer to Setting Î System Î System page for detail DIPS information.

2.4 Access the Device from the Internet Explorer for the First

Time

1. Start the web browser on the computer and type the IP address of the Camera you want to monitor as below:

The Login Window of the Camera is prompted:

AirLive FE-200DM Manual

2. Preparation

2. Type in your login name and password under “USERNAME” and “PASSWORD” textbox.

For the first time use (default value), input the

User Name: admin Password: airlive

After typing in “admin” on the “USERNAME” and “airlive” on the “PASSWORD”, click

“OK” button to start the main menu.

3. According your browser’s security setting, the IE Web Page may prompt the “Security Warning” window. If so, select “Yes” to install and run the ActiveX control into your PC. Otherwise, the system will load the ActiveX silently.

4. After the ActiveX control is installed and ran, the first image will be displayed.

2.5 Logging in as an User

If you log in the Camera as an ordinary User, “Configuration” function will be not accessible.

2.6 Logging in as an Administrator

If you log in the Camera as the Administrator, you can perform all the settings provided by the device.

AirLive FE-200DM Manual

3. Operating the Network Camera

3. Operating the

Start-up screen will be as follow no matter an ordinary users or an administrator.

Network Camera

Configuration

Click for configuring the camera settings.

Language

The device could provide multiple languages to meet customer’s requirement.

Display Mode

Click on different video modes to display different views.

Actual Size

Display the actual resolution size of the video when checked.

Video Profile

The device supports multi-profile function for H.264, MEPG4 and JPEG simultaneously. A user can chose the proper and/or preferred profile which is listed here.

AirLive FE-200DM Manual

3. Operating the Network Camera

Protocol

User can select proper streaming protocol according to networking environment.

Manual Trigger

Trigger manually a preset event in the configuration page.

PTZ

The PTZ function will display in Broad view, Quad view, Quad with source view, Double view and Triple view of Ceiling Mount. Click on the PTZ icon, the web will popup the control panel to control e-PTZ function of FE-200DM.

z Broad view PTZ control panel:

1. Step: Set the speed of Pan Function. (1~10)

2. Pan Arrow: Click to control Pan Function.

3. Move the control panel.

4. Close the control panel.

AirLive FE-200DM Manual

z Quad view & Quad with source view PTZ control panel:

3. Operating the Network Camera

1. Ch：Select the channel. (1~4) & (2~4)

2. Step：Set the speed of Pan/Tilt Function. (1~10)

3. Pan/Tilt Arrow：Click to control the Pan/Tilt Function.

4. Zoom：Digital zoom in/out. (1~10)

5. Move the control panel.

6. Close the control panel.

7. List of preset points. (1~16)

2-Way Audio

The device supports 2-way audio function. A user can choose to enable or disable this function by toggling the icon below.

: Disable speaker function.

: Enable speaker function.

: Disable audio uploading function.

: Enable audio uploading function.

AirLive FE-200DM Manual

3. Operating the Network Camera

Volume

Click Speaker button to activate this function. Scroll the control bars to adjust the audio attribute.

Full Screen

Enlarge video to full screen display. Press “ESC” key to disable this function.

Snapshot

Click Snapshot to activate this function. Press Snapshot button to take a picture. The image file is saved as JPEG format into your local PC. If you like to retrieve the saved image, select the file to display the saved image by using any one of graph editing tools.

Snapshot Location

Select Snapshot Location to select the save path and file name prefix, select OK to continue.

Record

Click Record to activate this function. Press Record button to start recording. The video file is saved as ASF format into your local PC. While you want to stop it, press Stop to stop recording.

Recording Location

Select Recording Location to select the save path and file name prefix, select OK to continue.

Push to talk

Click on the "push to talk" button continually, you can talk to the person via speaker of the IP Camera.

AirLive FE-200DM Manual

4. Administrating the Device

4. Administrating

the Device

System Setting

This function is only available for a user logs into Camera as administrator.

Click on each menu name to display its setting page.

Item Action

Video Configure bit rate and frame rate of video profiles.

Camera Adjust camera parameters.

Event Setup Event server, Motion Detection, I/O Ports and Event

configuration.

Schedule Configure the schedule while event triggered

Network Configure Network settings such as DHCP, DDNS, RTSP,

PPPoE and UPnP

System Configure system information, date & time, maintenance,

and view system log file.

Customize Provides the user features to customize the outlook of the

web user interface

4.1 Video: Configure Profile

4.1.1 General

z OSD Setting:

Enable OSD to display camera name and date/time on the image.

AirLive FE-200DM Manual

4.1.2 Advanced

4. Administrating the Device

z Stream Setting

Note: Configuration of stream 2 is the same as stream 1, but Stream 2 can only be set to 320x240 or 640x480.

z RTSP Path

The RTSP Path is the stream ID used for RTSP client streaming connection, such as VLC player. The default values are v00, v01 and v02 for the three streams respectively. The string can be any combination of number or capital/small letters. It cannot be empty however.

z Resolution

The resolution here describes an image size counted by width and height, e.g. 640x480, referring to pixel resolution. The 1st stream can be set from more options of resolution; 1600x1200 (2 megapixels), 1280x720(HD), 800x600(SVGA), 640x480(VGA), 320x240(QVGA), while Stream2 has the options of VGA and QVGA.

z Video Mode

This option allows the selection of two bit rate modes, the Constant Bit Rate (CBR) or Variable Bit Rate (VBR). CBR refers to the setting of a fixed Target Bit Rate (configuration in the rage of 64Kbps to 6Mbps) that would apply in the case of limited bandwidth or/and storage requirement. While CBR concerns a fixed data rate transmitting, the video quality is of high priority for VBR mode selected. VBR therefore is configured with the Quality Level (Standard, Good, Best). In general, CBR predicts the provided condition; if image activity requires higher bit rates than configured, the frame rate and quality would be affected as not likely to increase bandwidth (bit rate). In spite of the required recording storage estimation, VBR is by way of compensation that adjustable bit rate fits the actual image activity.

AirLive FE-200DM Manual

+ 51 hidden pages
