8924E CDMA Mobile Station Test Set

User’s Guide

Firmware Version A.03.02 and above

POWER

DO NOT APPLY RF WHEN OFF

RF IN/OUT

MAX PWR

CDMA CALL CONTROL

CDMA SCRNS

CELL CALL CTRL

SPECTRUM

GEN

CTRL

ANALOG SCRNS

ENCODER

ANL

SPEC ANL

GEN

END

CALL

RANGE

TEST

MSRPT

TEST

DECODER

RX TEST ACP

TX TEST

SCOPE DUPLEX

CALL ANS

USER DATA

k1’

k2’

k3’

ASSIGN

RELEASE

DUPLEX OUT

MAX PWR

200 mW

ANTENNA IN

6 W

FUNCTIONS

MSG

PRINTER

HELP

DATA FUNCTIONS

REF SET

METER

INCR

: 10

SET

LO LIMIT HI LIMIT

CURSOR

CONTROL

CANCELSHIFT

I/O CONFIG CONFIG

PREV TESTS

AVG

INCR X10

PUSH TO SELECT

INSTRUMEN T STATE

ADRS

SAVE

LOCAL

RECALL

789

456 123

YES

Ω

ppm

ON/OFF

dBµV

AUDIO OUTSQUELCHVOLUMEMIC/ACC

MAX

12 v Pk

HOLD

MEAS

PRESET

RESET

MEMORY

CARD

ENTER

GHz dBm

MHz

kHz

ms Hz

AUDIO IN

LOHI

MAX

42 v Pk

Agilent Part Number: 08924-90057

Printed in U. S. A.

March 2000

Rev. D

Notice Information contained in this document is subject to change without notice.

This material may be reproduced by or for the U.S. Government pursuant to the Copyright License under the clause at DFARS 52.227-7013 (APR 1988).

Agilent Technoloiges, Inc. Learning Products Department 24001 E. Mission Liberty Lake, WA 99019-9599 U.S.A.

S:\agilent\8924e\Usrguide\Book\CHAPTERS\titlepg.fb

Manufacturer’s Declaration

This statement is provi ded to co mply with the req uiremen ts of t he German Sou nd Emission Directive, from 18 January 1991.

This product has a sound pressure emission (at the operator position) < 70 dB(A).

• Sound Pressure Lp < 70 dB(A).

• At Operator Position.

• Normal Operation.

• According to ISO 7779:1988/EN 27779:1991 (Type Test).

Herstellerbescheinigung

Diese Information steht im Zusammenhang mit den Anforderungen der

Maschinenlärminformationsverordnung vom 18 Januar 1991.

• Schalldruckpegel Lp < 70 dB(A).

• Am Arbeitsplatz.

• Normaler Betrieb.

• Nach ISO 7779:1988/EN 27779:1991 (Typprüfung).

Safety Considerations

GENERAL This product and relate d documentation must be reviewed fo r familiariz ation with

safety markings and instructions before operation. This product has been designed and tested in accordance with IEC Publication

1010, "Safety Requirements for Electronic Measuring Apparatus," and has been supplied in a safe condition. This ins tr uct io n documentation contai ns information and warnings which must be followed by the user to ensure safe operation and to maintain the product in a safe condition.

SAFETY EARTH GROUND A uninterruptible safety earth ground must be provided from the main power

source to the product input wiring terminals, power cord, or supplied power cord set.

CHASSIS GROUND TERMINAL T o pre vent a pot ential s hock hazard , always connect th e rear -panel chassi s ground

terminal to earth ground when operating this instrument from a dc power source. SAFETY SYMBOLS Indicates instrument damage can occur if indicated operating limits are exceeded.

Indicates hazardous vol tag es. Indicates earth (ground) terminal

WARNING

A WARNING note denotes a hazard. It calls attention to a procedure, practice, or the like, which, if not correctly performed or adhered to, could result in personal injury. Do not proceed beyond a WARNING sign until the indicated conditions are fully understood and met.

CAUTION

A CAUTION note denotes a hazard. It calls attention to an operation procedure, practice, or the like, which, if not correctly performed or adhered to, could result in damage to or destruction of part or all of the product. Do not proceed beyond an CAUTION note until the indicated conditions are fully u nderstood and met.

S:\agilent\8924e\Usrguide\Book\CHAPTERS\titlepg.fb

Safety Considerations for this Instrument

WARNING This product is a Safety Class I instrument (provided with a protective

earthing ground incorporated in the power cord). The mains plug shall only be inserted in a socket outlet provided with a protective earth contact. Any interruption of the protective conductor inside or outside of the product is likely to make the product dangerous. Intentional interruption is prohibited..

Whenever it is likely that the protection has been impaired, the instrument must be made inoperative and be secured against any unintended operation.

If this instrument is to be energized via an autotransformer (for voltage reduction), make sure the common terminal is connected to the earth terminal of the power source.

If this product is not used as specified, the protection provided by the equipment could be impaired. This product must be used in a normal condition (in which all means for protection are intact) only.

No operator serviceable parts in this product. Refer servicing to qualified personnel. To prevent electrical shock, do not remove covers.

Servicing instructions are for use by qualified personnel only. To avoid electrical shock, do not perform any servicing unless you are qualified to do so.

The opening of covers or removal of parts is likely to expose dangerous voltages. Disconnect the product from all voltage sources while it is being opened.

Adjustments described in the manual are performed with power supplied to the instrument while protective covers are removed. Energy available at many points may, if contacted, result in personal injury.

The power cord is connected to internal capacitors that my remain live for 5 seconds after disconnecting the plug from its power supply.

For Continued protection against fire hazard, replace the line fuse(s) only with 250 V fuse(s) or the same current rating and type (for example, normal blow or time delay). Do not use repaired fuses or short circuited fuseholders.

CAUTION: Always use the three-prong ac power cord supplied with this product. Failure to ensure

adequate earth grounding by not using this cord may cause product damage.

This product is designed for use in Installatio n Cat egory II and P ollutio n Degree 2 per IEC 1010 and IEC 664 respectively.

This product has autoranging line voltage input, be sure the supply voltage is within the specified range.

Ventilation Requirements: When installing the product in a cabinet, the convection into and out of the product must not be restricted. The ambient temperature (outside the cabinet) must be less than the maximum operating

temperature of the product by 4° C for every 100 watts dissipated in the cabinet. If the total power dissipated in the cabinet is greater than 800 watts, then forced convection must be used.

Product Markings CE - the CE mark is a registered trademark of the European Community. A CE

mark accompanied by a year indicated the year the design was proven. CSA - the CSA mark is a registered trademark of the Canadian Standards

Association.

S:\agilent\8924e\Usrguide\Book\CHAPTERS\titlepg.fb

Agilent Technoloiges 8924E CDMA

Mobile Station Test Set

Hewett-Packard Warranty Statement for Commercial Products

Duration of Warranty: 1 year

1. Agilent Technoloiges warrants Agilent Technologies hardware, accessories and

supplies against defects in materials and workmanship for the period specified above. If Agilent Technologies receives notice of such defects during the warranty period, Agilent Technologies will, at its option, either repair or replace products which prove to be defective. Replacement products may be either new or like-new.

2. Agilent Technologies warrants that Agilent Technologies software will not fail to exe-

cute its programming instructions, for the period specified above, due to defects in material and workmanship when properly installed and used. If Agilent Technologies eceives notice of such defects during the warranty period, Agilent Technologies will replace software media which does not execute its programming instructions due to such defects.

3. Agilent Technologies does not warrant that the operation of Agilent Technologies

products will be uninterrupted or error free. If Agilent Technologies is unable, within a reasonable time, to repair or replace any product to a condition as warranted, customer will be entitled to a refund of the purchase price upon prompt return of the product.

4. Agilent Technologies products may contain remanuf actured parts equ ivalent to new in

performance or may have been subject to incidental use.

5. The warranty period begins on the date of delivery or on the date of installation if

installed by Agilent Technologies. If customer schedules or delays Agilent Technologies installation more than 30 days after delivery, warranty begins on the 31st day from delivery.

6. Warranty does not apply to defects resulting from (a) improper or inadequate

maintenance or calibration, (b) software, interfacing, parts or supplies not supplied by Agilent Technologies, (c) unauthorized modification or misuse, (d) operation outside of the published environmental specifications for the product, or (e) improper site preparation or maintenance.

7. TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE WARRANTIES

ARE EXCLUSIVE AND NO OTHER WARRANTYOR CONDITION, WHETHER WRITTEN OR ORAL IS EXPRESSED OR IMPLIED AND AGILENT TECHNOLOGIES SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES OR CONDITIONS OR MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.

8. Agilent Technologies will be liable for damage to tangible property per incident up to

the greater of $300,000 or the actual amou nt pai d for the prod uct that i s the subject of the claim, and for damages for bodily injury or death, to the extent that all such damages are determined by a court of competent jurisdiction to have been directly caused by a defective Agilent Technologies product.

9. TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS

WARRANTY STATEMENT ARE CUSTOMER’S SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WI LL AGIL ENT TECHNOLOGIES OR ITS SUPPLIERS BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE.

FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND: THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE RESTRICT OR MODIFY AND ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.

S:\agilent\8924e\Usrguide\Book\CHAPTERS\titlepg.fb

Agilent 8924E Support Contacts

Repair assistance is available for the Agilent 8924E CDMA Mobile Test Set from the factory by phone and e-mail. Internal Agilent Technoloiges users can contact the factory

through cc:Mail© (Lotus Corporation). Parts information is also available from Agilent Technoligies.

When calling or writing for repair assistance, please have the following information ready:

• Instrument model number (Agilent 8924E)

• Instrument Serial Number (tag located on the rear panel).

• Installed options - if any (tag located on the rear panel).

• Instrument firmware revision (displayed at the top of the screen when the Test Set is powered up, and is also displayed on the CONFIGURE screen).

Support Telephone

1 800 827 3848 (Spokane Division Service Assistance, U.S. only) 1 509 921 3848 (Spokane Division Service Assistance, International) 1 800 227 8164 (Agilent Direct Parts Ordering, U.S. only) 1 916 783 0804 (Agilent Service Parts Identification, U.S. & Intl.)

Electronic mail (Internet): Spokane_Service@spk.Agilent .com cc:Mail: SERVICE, SPOKANE /Agilent -Spokane,desk1

Numbers:

Table 1 Regional Sales and Service Offices

United States of America: Agilent Technologies Test and Measurement Call Center P.O. Box 4026

Englewood, CO 80155-4026

(tel) 1 800 452 4844

Japan:

Agilent Technologies Japan Ltd. Measurement Assist ance Center 9-1 Takakura-Cho, Hachioji-Shi, Tokyo 192-8510, Japan

(tel) (81) 456-56-7832 (fax) (81) 426-56-7840

Asia Pacific:

Agilent Technologies 24/F, Cityplaza One, 111 Kings Road, Taikoo Shing, Hong Kong

Canada: Agilent Technologies Canada Inc. 5150 Spectrum Way Mississauga, Ontario L4W 5G1

(tel) 1 877 894 4414

Latin America:

Agilent Technologies Latin America Region Headquarters 5200 Blue Lagoon Drive, Suite #950 Miami, Florida 33126 U.S. A.

(tel) (305) 267 4245 (fax) (305) 267 4286

Europe: Agilent Technologies European Marketing Organization P.O. Box 999 1180 AZ Amstelveen The Netherlands

(tel) (3120) 547 9999 Australia/New Zealand:

Agilent Technologies Australia Pty Ltd. 347 Burwood Highway Forest Hill, Victoria 3131

(tel) 1 800 629 485 (Australia) (fax) (61 3) 9272 0749 (tel) 0 800 738 378 (New Zealand) (fax) (64 4) 802 6881

(tel) (852) 3197 7777 (fax) (852) 2506 9233

S:\agilent\8924e\Usrguide\Book\CHAPTERS\titlepg.fb

In this Book Throughout this manual the term "Test Set" is used to denote the Agilent

Technologies 8924E. Test Set screens shown in this manual may not match those displayed on the Test

Set in every d etail.

Chapter 1, Getting Started

This chapter provides basic remote and front-panel operating procedures, a quick check for verifying operation, GP-IB programming procedures, and simple programming examples.

Chapter 2, Configuring Your Test Set

This chapter provides information about setting screen intensity, setting RF voltage

interpretation, setting time and date, and setting the beeper’s volum e.

Chapter 3, Operating Overview

This chapter explains how to specify units of measure, how to use the analog meter, how to use measurement averaging, how to set a measurement reference, how to set measurement limits, how to enter and change values, how to save and recall instrument setups, how to use the USER keys, and how to set a frequency offset. It also desc ribes some important interactions that occur between screen settings.

Chapter 4, Keys

This chapter provides front-panel key descriptions.

Chapter 5, Connectors

This chapter describes the front and rear panel connectors.

Chapter 6, Screens

This chapter provides a picture of each screen available on the Test Set with an overview of the functions provided.

Chapter 6, Fields

This chapter provides a description of the functions performed by each field.

Chapter 7, Memory Cards, Mass Storage

This chapter describes memory cards and mass storage devices used with the Test Set.

Error Messages

This section discusses error and operating messages.

S:\agilent\8924e\Usrguide\Book\CHAPTERS\titlepg.fb

Contents

1 Getting Started

Before Connecting a Radio 26

Accessing the Test Set’s Screens 27

Changing A Field’s Setting 30

Obtaining Measurement Results 34

Control Annunciators 35

Verifying that the Test Set is Operating Pro perly 36

Contents

2 Configuring Your Test Set

Recommended Calibration Procedures 40

Instrument Displa y Setup 42

Contents

Operating Overview

To Change the Measurement Display 44

To Enter and C hange Values 50

Saving and Recalling Instrument Setups 53

Using USER Keys 57

Setting an RF Generator/Analyzer Frequency Offset 60

Setting an RF Generator/Analyzer Level Offset 61

Printing A Screen 62

Triggering Analog Measurements In Local Mode (Front Panel Operation) 63

Triggering CDMA Measurements In Local Mode (Front Panel Operation) 64

Contents

4 Description of Keys

Keys That Begin with the Letter A 67

Keys That Begin with the Letter C 68

Keys That Begin with the Letter E 69

Keys That Begin with the Letter H 70

Keys That Begin with the Letter I 71

Keys That Begin with the Letter K 72

Keys That Begin with the Letter L 73

Keys That Begin with the Letter M 74

Keys That Begin with the Letter O 75

Keys That Begin with the Letter P 76

Keys That Begin with the Letter R 77

Keys That Begin with the Letter S 78

Keys That Begin with the Letter Y 79

Keys That Begin with a Number 80

Symbol Keys 81

Miscellaneous Hardware 82

DATA FUNCTIONS Keys 83

USER Keys 84

Contents

5 Description of Connectors

Connectors That Begin with the Letter A 87

Connectors That Begin with the Letter C 90

Connectors That Begin with the Letter D 94

Connectors That Begin with the Letter H 95

Connectors That Begin with the Letter M 96

Connectors That Begin with the Letter P 99

Connectors That Begin with the Letter R 101

Connectors That Begin with the Letter S 103

Connectors That Begin with a Number 106

Contents

6 Description of Screens

Analog Meas Screen 108

Authentica tion (Call Con trol) 110

Call Configure (Call Control) 111

Call Control Screen 112

Call Data (Call Control) 113

CDMA Authentication Screen 116

CDMA Call Control Screen 117

CDMA Cell Site Configuration Screen 118

CDMA Cellular Mobile Receiver Test Screen 119

CDMA Cellular Mobile Transmitter Test Screen 121

CDMA Generator Control Screen 122

CDMA Mobile Reporting Screen 124

CDMA Reverse Channel Spectrum Screen 125

CDMA Short Message Service Screen 126

CDMA Transmitter Power Range Test Screen 127

Configure Screen 128

I/O Configure Screen 129

Oscilloscope Screens 130

Print Configure Screen 131

Contents

Spectrum Analyzer Screens (Opt 012 only) 132

Contents

7 Description of Fields

Fields That Begin with the Letter A 136

Fields That Begin with the Letter B 156

Fields That Begin with the Letter C 159

Fields That Begin with the Letter D 176

Fields That Begin with the Letter E 192

Fields That Begin with the Letter F 201

Fields That Begin with the Letter G 206

Fields That Begin with the Letter H 207

Fields That Begin with the Letter I 209

Fields That Begin with the Letter L 214

Fields That Begin with the Letter M 215

Fields That Begin with the Letter N 232

Fields That Begin with the Letter O 239

Fields That Begin with the Letter P 243

Fields That Begin with the Letter R 254

Fields That Begin with the Letter S 271

Fields That Begin with the Letter T 282

Fields That Begin with the Letter U 293

Fields That Begin with the Letter V 295

Contents

Fields That Begin with the Letter W 297

Fields That Begin with a Number 298

Contents

8 Memory Cards/Mass Storage

Using Memory Cards 300

Backing Up Procedure and Library Files 306

Copying Files Using IBASIC Commands 307

Default File System 3 09

Mass Storage Device Overview 311

Mass Storage Access 320

DOS and LIF File System Considerations 321

Using the ROM Disk 326

Using RAM Disk 327

Using External Disk Drives 329

Contents

A Error Messages

Contents

Index 361

Getting Started

This chapter will help familiarize you with fundamental Test Set operation, including:

• Accessing screens and fields

• Making a simple measurement

• Preparation for remote operation via GP-IB

Chapter 1, Getting Started

Before Connecting a Radio

NOTE: The RF IN/OUT port should be used for all transmitter tests when th e radio is connected

directly to the Test Set. (All MSUT (Mobile Station Under Test) transmitter power measurements are made through this port). Off-the-air measurements can be made using the highly-sensitive ANT IN port.

CAUTION: Overpower Damage — Refer to the Test Set’s front panel for maximum input power level.

Exceeding this level can cause permanent instrument damage.

Other Damage — Blocking the fans’s rotation or operating the Test Set in an environment that causes excessive heat may cause damage.

Important: If excessive temperatures are sensed on the power supply regulator assembly, the Test Set’s power supply will shut off. After temperature has lowered to within normal operating range, use the POWER switch to cycle power on. Remove RF power from the RF IN/OUT connector whenever the Test Set is off.

Accessing the Test Set’s Screens

CDMA and Analog Modes

The Test Set has two operating modes, analog and CDMA. In CDMA mode, the T est Set conf igure s itself as a cal ibrat ed CDMA base st ation . In Ana log mode, t he Test Set has AMPS, NAMPS and TACS analog cellular phone test capability.

CDMA is the default power-up mode. To enter analog mode from CDMA mode:

• press one of the ANLG SCRNS keys, or

• select a screen from the Analog To Screen menu, or

• programmatically select an analog screen using the display (DISP) GP-IB subsystem, or

• execute a CDMA to Analog handoff.

Chapter 1, Getting Started

Accessing the Test Set’s Screens

To enter CDMA mode from analog mode:

• press one of the CDMA SCRNS keys, or

• select a screen from the CDMA To Screen menu, or

• programmatically select a CDMA screen using the display (DISP) GP-IB subsystem.

Chapter 1, Getting Started

Accessing the Test Set’s Screens

Functions Screens

Screens that control various instrument functions such as configuration, access to the Tests subsystem, and the PREV (previous screen) key are found under the

front-panel “Functions ” brac ket .

CDMA Digital Transceiver Measurements

Analog Transceiver Tests

POWER

DO NOT APPLY RF WHEN OFF

RF IN/OUT

MAX PWR

6 W

MAX PWR

200 mW

ANTENNA INDUPLEX OUT

Figure 1 Accessing Test Set Screens

Instrument Functions

CDMA CALL CONTRO L

CDMA SCRNS

CELL CALL CTRL

SPECTRUM

GEN

CTRL

ANALOG SCRNS

ENCODER

ANL

SPEC ANL

GEN

END

CALL

RANGE

TEST

MSRPT

TEST

DECODER

TEST ACP

TEST

SCOPE DUPLEX

CALL ANS

USER DATA

k1’

k2’

k2 k3’

ASSIGN

RELEASE

FUNCTIONS

MSG

PRINTER

HELP

DATA FUNCTIONS

REF SET

METER

INCR

: 10

SET

LO LIMIT HI LIMIT

CURSOR

CONTROL

CANCELSHIFT

I/O CONFIG CONFIG

PREV TESTS

AVG

INCR X10

PUSH TO SELECT

INSTRUMENT STATE

ADRS

LOCAL

789

456 123 0

YES

ppm

ON/OFF

AUDIO OUTSQUELCHVOLUMEMIC/ACC

MAX

12 v Pk

SAVE

RECALL

HOLD

MEAS

PRESET

RESET

MEMORY

CARD

ENTER

GHz

dBm

MHz

kHz

Ω

µV

dBµV

AUDIO IN

LOHI

MAX

42 v Pk

Cursor Control

Chapter 1, Getting Started

Accessing the Test Set’s Screens

INSTRUMENT STATE

ADRS

SAVE

LOCAL

RECALL

789

456 123

ON/OFF

YES

Ω

ppm

dBµV

AUDIO OUTSQUELCHVOLUMEMIC/ACC

MAX

12 v Pk

HOLD

MEAS

PRESET

RESET

MEMORY

CARD

ENTER

GHz dBm

MHz

kHz

ms Hz µV

AUDIO IN

LOHI

MAX

42 v Pk

MAX PWR

200 mW

ANTENNA IN

CDMA CALL CONT ROL

CDMA SCRNS

CELL CALL CTRL

SPECTRUM

GEN

CTRL

CDMA SCRNS

ENCODER

ANL

SPEC ANL

GEN

END CALL

RANGE

TEST

MSRPT

TEST

DECODER

RX TEST ACP

TX TEST

SCOPE DUPLEX

CALL ANS

USER DATA

k1’

k2’

k2 k3’

ASSIGN

RELEASE

FUNCTIONS

MSG

PRINTER

HELP

DATA FUNCTIONS

REF SET

METER

INCR

: 10

SET

LO LIMIT HI LIMIT

CURSOR

CONTROL

CANCELSHIFT

I/O CONFIG CONFIG

PREV TESTS

AVG

INCR X10

PUSH TO SELECT

1. Position

To position the cursor, rotate the Cursor Control knob, which moves the cursor from field to field or from menu item to menu item. Normally the cursor appears as a small highlighted rectangular box.

2. Select

To select an item, push the Curso r Control knob. After selection, t he background of the item selected becomes highlighted or the item selected appears in an associated field.

Chapter 1, Getting Started

Changing A Field’s Setting

There are several types of CRT display fields in the Test Set. This section describes some of the different types of fields, and how they are used.

Units-of-Measure Field

Figure 2 Units-of-Measure Field

Units-of-measure f iel ds al low selection of val id units for given mea sur emen t. See

figure 2 to see an example of a units-of-measure field.

To change a unit-of-measure

1. Position the cursor at the unit field on th e display.

2. Press a key labeled with a different unit-of-measure (such as W).

3. If the new units are valid, the measurement valu e will be displayed in the new unit-of-

measure.

Underlined Immediate-Action Field

Chapter 1, Getting Started

Changing A Field’s Setting

Figure 3 Underlined Immediate-Action Field

Underlined immediate action fields provide a choice of two settings. See in

figure 3 to see an example of an underlined immediate-action field.

To change an underlined entry

1. Position the cursor at the field.

2. Push the CURSOR CONTROL knob or the ENTER key to underline the desired

choice.

Chapter 1, Getting Started

Changing A Field’s Setting

One-of-Many Field

Figure 4 One-of-Many Field

One-of-many fields displ ay a list of cho ices when select ed. See in figure 4 to see an example of a one-of many field.

To make a one-of-many choice

1. Position the cursor at the field.

2. Push the C

3. Move the cursor through the choices by turning the knob.

4. Push the C

URSOR CONTROL knob or the ENTER key to display the choices.

URSOR CONTROL knob or the ENTER key to make the choice.

Numeric-Entry Field

Chapter 1, Getting Started

Changing A Field’s Setting

Figure 5 Numeric-Entry Field

Numeric-entry fields contain numeric values. See in figure 5 to see an example of a numeric-entry field.

To change a value

1. Position the cursor at the field.

2. Key in the desired number using the DATA keys.

3. Press ENTER to select the choice.

1. Position the cursor at the field.

2. Push the C

3. Turn the knob to increment or decrement the value.

4. Push the C

URSOR CONTROL knob to high li g ht the desi red choice.

URSOR CONTROL knob or the ENTER key to select the choice.

Chapter 1, Getting Started

Obtaining Measurement Results

Setting Up a Call

To obtain CDMA measurements, the Test Set must have the MSUT (Mobile Station Under Test) on a call (the Connected annun ciator on the CDMA CALL CONTROL screen is lit when the MSUT is on a call).

The procedure for setting up a call is provided in “Setting Up a Call”, found in the

Agilent 8924E Introduction to Operation

performing CDMA tests.

Triggering and Displaying Measurements

. In this guide, there are also procedures for

When operate d over the front panel (local control), Test Set measuremen t results are obtained by selecting a screen that displays the desired measurement, arming the measurement if necessary, and observing the displayed value.

When operated remotely, measurement results are obtained via GP-IB by triggering a measurement if necessary and querying the desired measurement field.

NOTE: In CDMA mode, transmitter (TX) measureme nts and r eceiv er (RX) mea surements c an

run concurrently. For example, an Average Power or Channel Power measurement can be queried while the RX TEST screen is selected and an FER measurement is running.

For a detailed description of triggering measurements, see

Displaying Measurements" on page 34

"Triggering and

Control Annunciators

The letters and symbols at the top right corner of the display indicate these conditions:

R indicates the T est Set is in remote mode. The Test Set can be put into the remote mode by an external controller or by an IBASIC program running on the built-in IBASIC controller.

• L indicates the Test Set has been addressed to listen.

• T indicates the Test Set has been addressed to talk.

• S indicates the Test Set has sent the require service message by setting the service re-

quest (SRQ) bus line true. (Se e "Status Reporting" on page 117).

• C indicates the Test Set is currently the active controller on the bus.

Chapter 1, Getting Started

Control Annunciators

• * indicates an IBASIC program is running.

• ? indicates an IBASIC program is waiting for a user response.

• - indicates an IBASIC program is paused.

Chapter 1, Getting Started

Verifying that the Test Set is Operating Properly

If your T est Set powers- up and displays the CDMA CALL CONTROL screen, but you suspect an instrument problem, the CDMA Mode Quick Check will verify

operation of the instrument’s basic functions.

"CDMA Mode Quick Check" on page 36 req uires the Test Set with Option 102

The (spectrum analyzer). If your Test Set does not have this option, you will only be able to perform the

CDMA Mode Quick Check

NOTE: This procedure assumes that the Test Set is configured for cellular mobile station testing, not

PCS. If necessary, access the CONFIGURE screen and turn PCS Intrfc Control Off then be necessary to cycle power.

"Analog Mode Quick Check" on page 37.

. It will

1. Remove any cabling from the front-panel connectors.

2. Turn instrument power on (if it is not already on).

3. Press the PRESET key.

4. Press and release the SHIFT key then the TESTS key to access the CONFIGURE

screen.

5. Position the cursor in the RF Display field, and press the knob to select Freq. The

RF Offset and (Gen)-(Anl)fields will appear below RF Display.

6. Change the (Gen)-(Anl) value to 0 MHz.

7. Position the cursor in the Output Port field and Select Dupl

8. Press GEN CTRL, +/-, 5, 0 ENTER to adjust Sector A Power to -50 dBm/BW.

9. Press and release the SHIFT key then the GEN CTRL key to access the CDMA

REVERSE CHANNEL SPECTRUM analyzer screen.

10. Position the cursor in the Ref Level field, and press +/-, 1, 0, ENTER to enter a

reference level of -10 dBm.

11. The display should show a CDMA signal, approximately 1.23 MHz wide.

If no failure is indicated by this test, but you still suspect a problem, refer to the performance tests information in the Agilent 8924E Assembly Level Repair Manual.

Analog Mode Quick Check

1. Turn instrument power on (if it is not already on).

2. Press the PRESET key.

3. Press and release the SHIFT key, then the TESTS key to access the CONFIGURE

screen.

4. Position the cursor in the RF Display field, and press the knob to select Freq.

5. The RF Offset and (Gen)-(Anl) fields will appear below the RF Display.

6. Change the(Gen)-(Anl) value to 0 MHz.

7. Under the To Screen menu, select the Analog drop-down screen list.

8. Select DUPLEX to display the DUPLEX TEST screen.

9. Position the cursor in the Amplitude field and enter -20.

10. Position the cursor in the AF Anl In field, and press the knob. Select FM Demod from

the Choices menu.

Chapter 1, Getting Started

Verifying that the Test Set is Operating Properly

11. Position the cursor below the AFGen1 To field Off subfield, and use the ON/OFF key

to turn AF Generator 1 On (make sure it remains set to FM).

12. Check the FM Deviation measurement. It should be about 2.1 kHz (assuming the De- tector field is set to RMS).

13. Check the SINAD measurement. It should be about 34 dB.

14. Press the SCOPE key to access the OSCILLOSCOPE screen.

15. Two complete sinewave cycles should be displayed.

16. Peak deviation should be about 3 kHz peak (1.5 units above/below the center line).

17. If a Spectrum Analyzer (Option 102) is installed in your test set, press the SPEC ANL

key to access the SPECTRUM ANALYZER.

18. A frequency modulated carrier at the current RF Generator setting should be displayed.

If no failure is indicated by this test, but you still suspect a problem, refer to the Performance Tests information in the Agilent 8924E Assembly Level Repair Manual.

Chapter 1, Getting Started

Verifying that the Test Set is Operating Properly

Configuring Your Test Set

This chapter will help you prepare the Test Set for making measurements. This includes:

• Calibration Guidelines

• Setting screen intensity

• Setting time and date

• Setting beeper volume

Chapter 2, Configuring Your Test Set

Recommended Calibration Procedures

Step-by-step calibration procedures are located in the Agilent 8924E Introduction to Operation, “Calibrate the Test Set”.

Use the table below to determine which calibration procedures need to be performed.

Chapter 2, Configuring Your Test Set

Recommended Calibration Procedures

Table 2 Recommended Calibration Procedures

After 30 minute warm-up period

After firmware is upgraded

When the "Uncal" light is flashing

Before making an Average Power measurement

If the RF connections to the PCS interface are adjusted

If the ambient temperature changes more 5 degrees C after 30 minute warm-up period

CDMA Channel

Levels

Channel Power

Measurements

RF Generator

Levels

A v erage Power

Measurement

Zeroing

After calibrating CDMA Channel levels (also known

as “PCB CAL”.

Chapter 2, Configuring Your Test Set

Instrument Display Setup

The following procedures are related to features available on the CONFIGURE screen. The Test Set will retain these settings during power cycles or instrument PRESET.

To Set Screen Intensity

1. Access the CONFIGURE screen.

2. Select the Intensity field.

3. Rotate the knob to change the setting (1=dim, 8=bright).

To Set the Date and Time

1. Access the CONFIGURE screen.

2. Select the Date field and use the DATA keys to enter the date in the format shown

below the field.

3. Select the Time field and use the DATA keys to enter the time in the format shown

below the field.

The Test Set has a built-in clock that keeps track of the date and time. It is powered by an internal battery to keep it operating when the instrument is off.

To Change the Beeper’s Volume

1. Access the CONFIGURE screen.

2. Select the Beeper field to display the volume choices.

3. Select the desired choice.

The beeper alerts you to important operating and measurement conditions. It beeps any time a message is displayed at the top of the screen. These messages warn you of conditions su ch as excee ding the RF in put lev el or trying to set a fi eld to an unacceptab le value. Therefore, it is r ecommended t hat you d o not disable the beeper .

Operating Overview

The information in this chapter describes how to use many of the operating features of the Test Set, including:

• "To Change the Measurement Display" on page 44

• "To Enter and Change Values" on page 50

• "Saving and Recalling Instru ment Setups" on page 53

• "Using USER Keys" on page 57

• "Setting an RF Generator/Analyzer Frequency Offset" on page 60

• "Setting an RF Generator/Analyzer Level Offset" on page 61

• "Printing A Screen" on page 62

Chapter 3, Operating Overview

To Change the Measurement Display

To Use the On/Off Function

The on/off function is used for the following operations.

• Measurements that are displayed as numbers , or as meters using the METER function , can be turned on and off.

• The data functions REFerence, METer, HLIMit and LLIMit can be turned on and off.

• Any instrument functio n that generates a s ignal can be tu rned on and o ff. This in cludes the CDMA Sector A Power, Sector B Power, and AWGN.

• Trace displays, such as the CDMA Reverse Channel Spectrum Analyzer, cannot be turned off.

The front-panel ON/OFF key is used to turn measurements, instrument functions and data functions on or off.

Front-Panel Example

The following front-panel operation turns Avg Power off.

1. Move the cursor in front of the unit-of-measure for the Avg Power measurement.

2. Press the ON/OFF key. The Avg Power measurement field displays the word OFF

in place of units

To Use the METER Format

The METER function displays measurements graphically. The METER format is available for most measurements. To determine if the METER format is provided

for a measurement, position the cursor in front of the measurement’s units field and press the knob. If t he message “Press ON/OFF, LIMIT s, REF, AVG, METER, or units” is displayed, the METER format is provided.

As a measurement is displayed on the meter, the value is also displayed in small digits below the meter. You can specify the high and low end points and number of intervals, or you can use the default meter settings.

1. Position the cursor in front of the measurement’s unit-of-measure.

2. Press and release the SHIFT key, then the INCR SET key to select the METER func-

tion. The default number of average samples is displayed below the measurement.

3. Select On/Off

4. Repeat steps 1 and 2 then select LoEnd, Hi End, or Intervals to enter each meter

end point and the meter intervals.

5. Repeat steps 1, 2, and 3 to cancel the meter function.

Chapter 3, Operating Overview

To Change the Measurement Display

from the Meters: field on the CRT display

Front-Panel Example

The following front panel operation turns on the Avg Power measurement meter.

1. Move the cursor in front of the unit-of-measure for the Avg Power measurement).

2. Press and release the SHIFT key, then the INCR SET key to select the METER func-

tion, then press the ENTER key. The meter will appear below the measurement units field with default low/high ends and number o f in tervals. To tur n off the measurement meter, repeat this process.

Chapter 3, Operating Overview

To Change the Measurement Display

To Set a Measurement Reference

The REF SET function establishes a measurement reference point. This allows you to make a direct comparison between two measurement results, or between a measurement standard and the actual measurement results.

Referenced measurements are displayed as either a ratio (dB) or difference between the measured value and the reference.

1. Position the cursor in front of the unit-of-measure for the measurement you want to set the reference for.

2. Press and release the SHIFT key, then the INCR ÷10 key to select the REF SET func- tion.

3. Enter the reference value.

4. Ref appears below the measurement value to indicate that a reference has been set. The

measurement field may display a different u nit-of-measure, and limit ch oices for units.

Front-Panel Example

The following front-panel operation sets a 10 dBm reference for Avg Power measurements.

1. Move the cursor in front of the unit-of-measure for the Avg Power measurement).

2. Press and release the SHIFT key, then the INCR ÷10 key.

3. Enter 10 dBm using the DATA keys.

The abbreviation Ref will appear below the Avg Power measurement field and Avg Power measurements will be expressed in dB. Absolute power (mW, W) will

not be selectable.

To Use Measurement Averaging

The AVG (average) function allows you to reduce the effects of a rapidly changing measurement by displaying the average value of a number of measurements.

1. Position the cursor in front of the measurement’s unit-of-measure.

2. Press and release the SHIFT key, then the INCR × 10 key to select the AVG function.

The default number of average samples is displayed below the measurement.

• Enter the desired number of measurement samples to be used for calculating the average, or

• Press the ON/OFF key to use the currently-displayed number of samples.

3. To turn averaging off, position the cursor in front of the unit-of-measure and press re-

lease the SHIFT key, then the INCR × 10 key, then the ON/OFF key to turn averaging off.

Chapter 3, Operating Overview

To Change the Measurement Display

Front-Panel Example

The following front-panel operation averages Avg Power measurements over 10 samples.

1. Move the cursor in front of the unit-of-measure for the Avg Power measurement.

2. Press and release the SHIFT key, then the INCR × 10 key to select the AVG function.

3. Enter 10 using the DATA keys and press the ENTER key. The abbreviation Avg will

appear below the Avg Power measurement field.

Chapter 3, Operating Overview

To Change the Measurement Display

To Set Measurement Limits

The LO LIMIT and HI LIMIT functions are used to define a measurement

“window” to alert you to meas urements that are outside these limits. When limits are assigned,

A measurement that goes above or be low t he defined limits causes thr ee thi ngs to happen:

1. A message appears at the top of the screen indicating a limit was exceeded.

2. The Lo or Hi indicator by the measurement flashes.

3. The Beeper beeps if it is has not been turned off in the CONFIGURATION screen.

Limits are helpful when you can’t watch the Test Set display while you are making an adjustment on the equip ment you are test ing or r epairing. They are a lso a convenient way of alerting you to long-term measurement drift without having to observe the screen.

Lo and/or Hi appear by the measurement.

1. Position the cursor in front of the unit-of-measure for the measurement you are setting

limits for.

2. Press and release the SHIFT key, then the down-arrow key to select the LO LIMIT

function.

3. Enter the measurement’s low limit value and unit-of-measure.

4. Press and release the SHIFT key, then the up-arrow key to select the LO LIMIT func-

tion.

5. Enter the measurement’s high limit value and unit-of-measure.

To reset a limit that has been exceeded:

1. Position the cursor in front of the unit-of-measure for the measurement you assigned

the limit to.

2. Press and release the SHIFT key, then the down-arrow (LO LIMIT) or up-arrow (HI

LIMIT key, or press the MEAS RESET key.

To remove a limit you have set:

1. Position the cursor in front of the unit-of-measure for the measurement you assigned

the limit to.

2. Press and release the SHIFT key, then the down-arrow (LO LIMIT) or up-arrow (HI

LIMIT key, then press the ON/OFF key.

1. The fundamental unit for the LIMITs does not have to be the same as the measurement’s units. For instance, when measuring AC Level in Volts, you can set HI and LO LIMITs in units of dBm if desired.

Chapter 3, Operating Overview

To Change the Measurement Display

Front-Panel Example

This example sets limits for the Avg Power measurement. These limits will indicate if the power level is between

1. Position the cursor in front of the unit-of-measure for the Avg Power measurement

(the default is dBm).

2. Press and release the SHIFT key, then the down-arrow key to select the LO LIMIT

function.

3. Enter −5 using the DATA keys and press the ENTER key.

4. Press and release the SHIFT key, then the up-arrow key to select the HI LIMIT func-

tion.

5. Enter 5 using the DATA keys and press the ENTER key.

−5 dBm and +5 dBm.

The Hi limit and Lo limit annunciators will appear below the Avg Power measurement field.

To Specify Units-of-Measure for CRT Display

Most measurements, data functio ns, and instrument functions all ow you to specify which unit-of-measurement should appear on the CRT display.

1. Position the cursor in front of the present unit-of-measurement.

2. Press the key labeled with the desired unit.

Front-Panel Example

The following front-panel operation causes the Test Set to display Avg Power in units of Watts instead of dBm.

1. Press the PRESET key.

2. Press the CALL CTRL key to access the CDMA CALL CONTROL screen.

3. Move the cursor in front of the unit-of-measure for the Avg Power measurement

(dBm).

4. Press the RATIO W key. The measurement value is changed immediately to display in

Watts.

Chapter 3, Operating Overview

To Enter and Change Values

To Enter and Change Val ues

To Enter Decimal Values

Values can be entered and changed using various methods, depending on your testing needs.

1. Position the cursor in front of the numeric entry field to be changed.

2. Either:

• Enter the number and unit-of-measure directly using the keypad, or

• Press the CURSOR CONTROL knob or the ENTER key to highlight the field, and use the knob, or

• Use the down-arrow and up-arrow keys to increment or decrement the present value.

Front-Panel Example

The following front panel operation changes Sector A Power to -73 dBm/BW.

1. Move the cursor in front of the Sector A Power field.

Enter −73 dBm using the DATA keys.

To Enter Hexadecimal Values

Hexadecimal (Hex) values are used for entering some signaling parameters, such as MIN (Mobile Identification Number). No unit-of-measure is associated with these values.

Hexadecimal values are either entered from the keypad (using the A-F shifted functions), or by using the

Front-Panel Example

The following front-panel operation enters the Hexadecimal number #H0D2565F15 into the MIN field.

1. Move the cursor to the field below MS ID.

2. If the field currently says Phone Num press the ENTER key, use the CURSOR CON-

TROL knob to select MIN, and press th e ENTER key again. (If MIN is already s elected, proceed to step 3.)

3. Use the CURSOR CONTROL knob to select the numeric entry field below MIN.

4. Enter 0, then press and release the SHIFT key, then the 3 key (to select D), enter 2 565,

press and release the SHIFT key, then the 5 key (to select F), enter 15, and then press the ENTER key. This is the hexadecimal code derived from the phone number 321-456-7890.

Chapter 3, Operating Overview

To Enter and Change Values

Choices menu.

To Enter Values With Exponents

Front-Panel Example

The following front-panel operation changes Confidence (limit) to 95.

1. Press the CALL CTRL key.

2. Move the cursor in front of the Confidence field.

3. Enter 9 EEX 1.

The EEX key can be used to enter values in exponential notation. Exponential notation is only allowed on floating-point entry fields.

Chapter 3, Operating Overview

To Enter and Change Values

To Increment/Decrement Values

Incrementing and decrementing values on the Test Set can be performed from the front panel with the CURSOR CONTROL knob or the up/down arrow keys., or the INCR

÷10 and INCR ×10 keys.

The INCR

÷10, INCR ×10, and INCR SET keys are used to assign a specific

increment value. To change an increment/decrement setting:

1. Move the cursor to the numeric entry field to be changed.

2. To change the current increment/decrement setting by a factor of 10, use the INCR ÷10

or INCR ×10 keys.

3. To set a specific increment/decrement value, press INCR SET, and enter the desired

value.

Front-Panel Example

The following front panel operation sets the increment value on the Sector A

Power

field to 3 dB.

1. Press the CDMA SCRNS, CALL CTRL key.

2. Move the cursor in front of the Sector A Power field.

3. Press INCR SET, 3, ENTER.

4. Turn the knob or press the up/down arrow keys.

Saving and Recalling Instrument Setups

The save and recall functions allow you to store different instrument setups and retrieve them later, eliminating the task of re-configuring the Test Set.

The number of available sa ve regi sters depends on how many chan ges were made to the BASE instrument setup for each save. (See

page 56

registers that can be used (typically over 200). SAVE/RECALL register settings can be saved to several types of mass storage.

This allows you to “back up” the settings in case you need to clear them from memory (see when a firmware upgrade is performed.

.) The smaller the number of changes, the greater the number of SAVE

"Memory Considerati ons" on page 56) for running lar ge programs, or

Chapter 3, Operating Overview

Saving and Recalling Instrument Setups

"To Specify a BASE Setting" on

To Save an Instrument Setup

1. Press and release the SHIFT key, then the PREV key to access the I/O CONFIGURE

screen. Select the storage media using the Save/Recall field. (The default storage media is internal memory.)

2. Make any changes to the instrument that you want to save in a register.

3. Press and release the SHIFT key, then the RECALL key to select the SAVE function.

4. Use the DATA keys or the Save: menu at the bottom right of the screen to enter the

save register name.

Front-Panel Example

This example saves the current instrument settings.

1. Press and release the SHIFT key, then the RECALL key to select the SAVE function.

A prompt appears at the top of the screen asking you to enter a name.

2. Using the DATA keys, enter 123, then press the ENTER key to assign a name.

Chapter 3, Operating Overview

Saving and Recalling Instrument Setups

To Recall an Instrument Setup

1. Press and release the SHIFT key, then the PREV key to access the I/O CONFIGURE

screen and select the media to recall settings from using the Save/Recall field. (The default is internal memory.)

2. Press the RECALL key.

3. Use the knob to select the desired setup to be recalled from the Recall menu at the

bottom right of the screen.

Front-Panel Example

This example recalls the current instrume nt settings. Press RECALL, 1, 2, 3, ENTER. The saved instrument settings are recalled.

To Clear All SAVE Registers

1. Press the RECALL key.

2. Use the knob to position the cursor in front of the entry in the Recall menu at the

bottom right of the screen.

3. Press the knob or the ENTER key. A prompt appears at the top of the screen to verify

that you want to clear all registers.

4. Press the ON/OFF key to select YES.

To Remove (Clear) an Individual SAVE Register

1. Specify where the register is stored using the Save/Recall field on the I/O

CONFIGURE screen.

2. Press the RECALL key.

3. Use the knob to position the cursor in front of the register to be removed from the Re-

call menu at the bottom right of the screen. The register name and percentage of SAVE memory occupied by that register are indicated at the very top of the screen.

4. Press the ON/OFF key. A prompt appears, asking if you want to del ete the save register.

5. Press the ON/OFF key to select YES. (Press the RATIO W key to select NO.)

To Choose a Register Name

You can use any number, letter, or combination of numbers and letters as a name for storing instrumen t settin gs. For inst ance; if yo u want to save a set up for tes ting

a “Vulcan7” radio, you can save the setting as “VULCAN7”. Two register names are reserved for special purposes: POWERON and BASE.

To Specify a POWERON Setting

You can specify the instrument setting at power-on by following the procedure described in name POWERON. If a SAVE Register named POWERON is detected by the Test Set during its power -on rou tine, the Test Set will configure itself us ing the se ttings stored in the POWERON register.

Chapter 3, Operating Overview

Saving and Recalling Instrument Setups

"To Save an Instrument Setup" on page 53, and choosing the register

NOTE: If the Test Set does not successfully complete its power-on routine because of the

POWERON settings (e.g., the Test Set displays a message that requires you to cycle power to recover) you must:

1. Turn off the Test Set.

2. Hold down the PRESET and the Hz/uV keys simultaneously.

3. Turn on power while holding the PRESET and the H z/uV keys down unt il the CALL

CONTROL screen appears.

This procedure will clear all SAVE registers, including POWERON.

Chapter 3, Operating Overview

Saving and Recalling Instrument Setups

To Specify a BASE Setting

The BASE register contains any field settings the user has SAVEd that are different fro m the instrume nt PRESET state. I t establish es a refere nce point fo r all future SAVEs. (The PRESET state is stored in the BASE register until you SAVE another instrument setup.)

When you SAVE an instrument setup, the new setup is compared to the BASE settings, and any differences are stored under the register name you supply. Because only differences are stored, a much larger number of instrument setups can be saved than if the contents of every field was saved.

When you RECALL an instrument setting, every field is reset to the BASE settings. Th e SAVED set tings are then u sed to re-establish the desired instrument setup.

You can define your own BASE setting. If your d esi red settings are very different from the PRESET values, you may want to change the BASE register. This will decrease the amount o f memory used to SAVE e ach setup , and all ow you to SAVE many more setups.

CAUTION: Since each SAVE/RECALL register only contains the differences between the setup being

saved and the presen t BAS E regist er sett ings, ch anging the BASE res ults in all ot her sav ed setups being ERASED from memory (including the POWERON setting if one has been saved).

Unless you consistently change the same fields to the same value each time you use the instrument, you should probably not create your own BASE settings.

Memory Considerations

When the Save/Recall field of the I/O CONFIGURE screen is set to

Internal, instrument setups are saved to the same non-volatile RAM used to

create RAM Disk(s) and run IBASIC programs. By saving a large number of instrument setups, you reduce the amount of RAM available to run programs. If

you get a “memory overflow” message while trying to load a program, you must clear one or more SAVE/RECALL registers to free RAM space).

Using USER Keys

User keys instantly access instrument settings without using the knob. You can use USER keys to move quickly between fields on the same scree n, and to ac ces s field settings that are not normally available on the screen you are using.

Local USER keys are used to move between settings on the screen that is displayed. When the USER key is pressed, the cursor instantly moves to, and selects, the assigned field; eliminating the need to turn and push the knob. Five local USER keys are available for each screen: K1, K2, K3, K4, and K5.

Global USER keys are used to acce ss se ttin gs that ar e not ava ilabl e on th e curre nt

screen. Three global USER keys are available: K1’, K2’, and K3’. (These are shifted functions of the local USER keys.)

Chapter 3, Operating Overview

Using USER Keys

When defining USER keys, the ASSIGN fu nction is used to c reate key d efiniti ons; the RELEASE function removes the definitions. Re-assigning a USER key to a different field setting automatically Releases it from the setting it was previously associated with.

Chapter 3, Operating Overview

Using USER Keys

To Assign Local USER Keys

1. Move the cursor to the field you want to assign a local USER key to.

2. Press and release the SHIFT key, then the K4 key to select the ASSIGN function. Press

a local USER key (K1-K5). The USER key number appears in front of the field you assigned it to.

Example of Assigning a Local USER Key

Use this example to assign local USER key K1 to the Filter 1 field in the RX TEST screen.

1. Access the RX TEST screen and position the cursor in front of the Filter 1 field.

2. Press and release the SHIFT key, then the K4 key to select the ASSIGN function.

3. Press K1. A small 1 appears next to the field indicating that USER key K1 has been

assigned to it.

4. Move the cursor to any other field on the screen an d press K1. The cursor immed iately

returns to the Filter 1 field. The field is also highlighted to change the entry using the CURSOR CONTROL knob or arrow keys.

To Release Local USER Keys

1. Display the screen containing the USER key assignment to be removed.

2. Press and release the SHIFT key, then the K5 key to select the RELEASE function.

3. Press the USER key (K1-K5) that you want to release.

To Assign Global USER Keys

1. Move the cursor to the field you want to assign a global USER key to.

2. Press and release the SHIFT key, then the k4 key to select the ASSIGN function.

3. Press a global USER key (K1’ -K3’). Unlike a local USER key, the USER key number

does not appear in front of the field you assigned a global USER key to. A prompt appears at the top of the screen confirming the key assignment.

Example of Assigning a Global USER Key

Use this example to assign global USER key K1’ to the AF Anl In field, and then access this field in the OSCILLOSCOPE screen.

1. Access the AF ANALYZER screen and position the cursor in front of the AF Anl In

field.

2. Press and release the SHIFT key, then the K4 key to select the ASSIGN function.

Chapter 3, Operating Overview

Using USER Keys

3. Press and release the SHIFT key, then the K1’ key. Notice the pr ompt Global User

key 1 assigned. at the top of the screen.

4. Access the OSCILLOSCOPE screen.

5. Press SHIFT, K1’.

AF Anl Input

present input is set to FM Demod). To change the input, use the arrow keys, or press the ENTER key to access the

A field that is ac cessed usi ng a glob al USER key i s only dis played at the top of the screen while it is being accessed. Moving the cursor to any other field in the screen causes the USER key field to disappear until it is accessed again.

To Release Global USER Keys

1. Move the cursor to the field with the global USER key assigned to it.

2. Press SHIFT, K5, SHIFT, and the USER key to be released (K1’-K3’).

, FM Demod is displayed at the top of the screen (assuming the

Choices menu.

Chapter 3, Operating Overview

Setting an RF Generator/Analyzer Frequency Offset

Setting an RF Generator/Analyzer Freque ncy Offset

You can set a fixed frequency offset between the RF Generator and the RF Analyzer. At power-up and instrument preset this feature is ON with a transmit/receive frequency offset of 45 MHz.

NOTE: A 45 MHz offs et is requir ed for making a call or making measurem ents in CDMA m ode.

To Turn Off RF Frequency Offset

1. Access the CONFIGURE screen.

2. Position the cursor below the RF Display field and select Freq.

3. Set the RF Offset to Off

To Change the RF Frequency Offset

1. Access the CONFIGURE screen.

2. Position the cursor below the RF Display field and select Freq.

3. Set the RF Offset to On

4. Enter an offset frequency ((Gen)-(Anl)).

Setting an RF Generator/Analyzer Level Offset

You can correct for path loss by setting up an RF Level Offset on the front-panel RF connector(s) used in your application. At power-up and instrument preset this feature is OFF with 0.0 dB loss in all connector fields.

An RF Level Offset is required to ensure proper power levels to the analyzer when testing CDMA mobile stations.

Refer to “Calibrate the Test Set” in the Agilent 8924E Introduction to Operation.

Chapter 3, Operating Overview

Printing A Screen

To Print A Screen’s Contents

1. Connect a printer to the appropriate rear-panel connector.

2. Press and release the SHIFT key, then the PRINT key to access the PRINT

CONFIGURE screen and set the Printer Port field to the appropriate type of printer connection.

• If GP-IB is selected, enter the GP-IB Printer Address of the printer.

3. Select the type of printer you are using in the Model field. If your printer is not list ed,

configure your printer to emulate one that is listed .

4. Enter a Print Title using the knob (optional). The title will appear at the top of

your printout.

5. Display the screen you want to print and press the PRINT key.

To interrupt prin ting, select the Abort Print field on the PRINT CONFIGURE screen.

Chapter 3, Operating Overview

Triggering Analog Measurements In Local Mode (Front Panel Operation)

Triggering Ana log Measurements In Local Mode (Front Panel Operation )

• Repetitive re-triggering is the only tr igger mo de available fro m the front panel for analog measurements. Single trigger mode can be simulated using the Test Set’s measurement HOLD feature. Selecting the HOLD key causes all currently displayed measurement results to be held on the screen and stops the cur rent measurement cy cle. To resume making measurements press the HOLD key again.

Manual Operation:

1. Press then release the SHIFT key, then press the MEAS RESET key to HOLD measurement results.

2. Select HOLD again to return to Repetitive mode.

CDMA CALL CONTROL

CDMA SCRNS

CELL CALL CTRL

SPECTRUM

GEN CTRL

ANALOG SCRNS

ENCODER

ANL

SPEC ANL

GEN

END

CALL

RANGE

TEST

MSRPT

TEST

DECODER

TEST

ACP

TEST

SCOPE

DUPLEX

CALL ANS

USER DATA

k1’

k2’

k2 k3’

ASSIGN

RELEASE

FUNCTIONS

MSG

PRINTER

HELP

DATA FUNCTIONS

REF SET

METER

INCR

: 10

SET

LO LIMIT HI LIMIT

CURSOR

CONTROL

CANCELSHIFT

I/O CONFIG CONFIG

PREV TESTS

AVG

INCR X10

PUSH TO

SELECT

Meas Reset begins a measurement cycle, interrupting any measurement in progress.

INSTRUMEN T STATE

ADRS

SAVE

LOCAL

RECALL

789

456 123

ON/OFF

YES

Ω

ppm

dBµV

AUDIO OUTSQUELCHVOLUMEMIC/ACC

MAX

12 v Pk

HOLD

MEAS

PRESET

RESET

MEMORY

CARD

ENTER

GHz dBm

MHz

kHz

ms Hz µV

AUDIO IN

LOHI

MAX

42 v Pk

Chapter 3, Operating Overview

Triggering CDMA Measurements In Local Mode (Front Panel Operation)

For FER and Rho Suite of Measurements

• Continuous - Once a measurement has completed, the Test Set is internally re-triggered and another measurement cycle begins.

• Single - Requires selection of the Arm field to be begin a measurement cycle.

Manual Operation:

1. Position the cursor at the Single/Cont field.

2. Press the knob to underline the desired mode.

3. If you selected Single, select the Arm field to trigger a measurement.

Tes t St a tu s

Meas Cntl

Single/Cont Arm Disarm

CDMA CELLULAR MOBILE RECEIVER TEST

Connected Svc Opt 2 Tes t i n g Passed Failed Max Frames

Max Frames

On/Off

Confidence

FER Specs

Display Interim Results

Yes /No

95.00

3.00

Traffic Data Mode

Svc Opt 1

Data Rate

Full

Eb/Nt

FER

Errors Counted Frames Counted

----

Sector A Power

-75.0

dBm/BW

Traffic

15.6

AWGN

-75.0

dbm/BW

To Screen

CDMA

CALL CNTL

Analog

RX TEST

Cnfig

PRNT CNFG

When Single is selected, the Arm and Disarm fields are displayed. When Continuous is selected the Arm and Disarm fields will not appear.

Description of Keys

The keys are listed in alphabetical order.

Chapter 4, Description of Keys

POWER

DO NOT APPLY RF WHEN OFF

RF IN/OUT

MAX PWR

6 W

DUPLEX OUT

MAX PWR

200 mW

ANTENNA IN

Figure 6 Agilent 8924 E Front Panel

CDMA CALL CONTRO L

CDMA SCRNS

CELL CALL CTRL

SPECTRUM

GEN CTRL

ANALOG SCRNS

CALL CTRL

CALL CNFG

AUTHEN

SPEC ANL

RANGE

MS RPT

ANLG MEAS

CALL DATA

SCOPE

END CALL

TEST

CALL ANS

USER DATA

k1’

k2’

k2 k3’

ASSIGN

RELEASE

FUNCTIONS

MSG

PRINTER

HELP

DAT A F UNCTIONS

REF SET

METER

INCR

: 10

SET

LO LIMIT HI LIMIT

CURSOR

CONTROL

CANCELSHIFT

I/O CONFIG CON FIG

PREV TESTS

AVG

INCR

X10

PUSH TO

SELECT

INSTRUMENT STATE

ADRS

LOCAL

789

456 123 0

YES

ppm

ON/OFF

AUDIO OUTSQUELCHVOLUMEMIC/ ACC

MAX

12 v Pk

SAVE

RECALL

HOLD

MEAS

PRESET

RESET

MEMORY

CARD

ENTER

GHz dBm

MHz

kHz

Ω

µV

dBµV

AUDIO IN

LOHI

MAX

42 v Pk

Keys That Begin with the Letter A

ADRS

Press and release the SHIFT key, then the LOCAL key to display the GP-IB address of the Test Set. There is no equivalent GP-IB command for the ADRS key.

See Also

"I/O Configure Screen" on page 129

ANS

Chapter 4, Description of Keys

Keys That Begin with the Letter A

AVG

ASSIGN

This key functions only when Answer Mode is set to Manual. Pressing thi s key answers C DMA-mode mobi le-station-originated calls by

removing the ring back tone from the mobile station’s audio path and allowing user conversation or other traffic to be exchanged.

The Test Set will automatically answer calls if

Answer Mode is set to Auto.

Press and release the SHIFT key, then the INCR x10 key to access the average function. This enables or disables measurement averaging.

See Also

"To Use Measurement Averaging" on page 47

This key is used to assign the User Keys, K1 through K5, and K1’ through K3’. Press and release the SHIFT key, then the K4 key to select the ASSIGN function.

See Also

"Using USER Keys" on page 57

Chapter 4, Description of Keys

Keys That Begin with the Letter C

CALL

When this key is pressed, the Test Set attempts a CDMA-mode page to a mobile station. The Call Status annunciators on the CDMA CALL CONTROL screen indicate call flow.

Refer to “Set Up a Call” chapter in th e Agilent 8924E Introduction to Operation.

CANCEL

CANCEL is used to cancel an entry in progress, or to stop a running IBASIC program. For example, if you press RECALL to recall an instrument setup, and then decide not to recall a setting, pressing CANCEL exits the recall procedure.

Keys That Begin with the Letter E

END CALL

When this key is pressed, the Test Set disconnects any CDMA-mode call that is currently connected.

ENTER

ENTER is used to select a field or screen, and to enter numbers when the unit-ofmeasure is not specified. This function is identical to pressing the cursor-control knob.

Chapter 4, Description of Keys

Keys That Begin with the Letter E

EEX

Press and release the SHIFT key, then the +/- key to access the exponen t funct ion. This function is used for entering numbers using scientific notation.

See Also

"To Enter Values With Exponents" on page 51

Chapter 4, Description of Keys

Keys That Begin with the Letter H

HOLD

Press and release the SHIFT key, then the MEAS RESET key. This stops all measurements. Selecting HOLD ag ain resumes measurements.

The HOLD key is used to hold/resume all active measurements. There is no equivalent GP-IB command for the HOLD key. However, the functionality of the HOLD key can be implemented remotely by using Single Triggering of measurements.

See Also

“Measurement Triggering Process” in the Operating Overview chapter of the

Agilent 8924E User’s Guide.

Keys That Begin with the Letter I

INCR ÷ 10, INCR SET, INCR x10

These keys are used to change the incr ement/decrement value when changing field value s.

The increment divide-by-10 function reduces the increment setting by a factor of 10 (new increment setting = current setting

The increment setting function sets the increment value for real-number numeric entry field s.

The increment multipl y-by-10 funct ion i ncreas es the incr ement se ttin g by a fac tor of 10 (new increment setting = current setting

Chapter 4, Description of Keys

Keys That Begin with the Letter I

÷ 10).

× 10).

Chapter 4, Description of Keys

Keys That Begin with the Letter K

K1 - K5, & K1’- K3’

These keys are used to disp lay fie lds fr om anoth er scr een, or acces s fiel ds wit hout using the CURSOR CONTROL knob or changing screens.

See Also

"Using USER Keys" on page 57

Keys That Begin with the Letter L

LOCAL

LOCAL returns the instrument to manual control after GP-IB control is used, except when the Test Set is in local-lockout mode. The Test Set returns to Local operation (full front-panel control) when either the Go To Local (GTL) bus command is received, the f ront-panel L OCAL key is pressed o r the REN line goes false. When the Test Set returns to local mode the output signals and internal

settings remain unchanged, except that triggering is reset to “repetitive” and settling is res et to “ full” . The LOCAL key will not fun ction if the Test Set is in the local lockout mode.

Chapter 4, Description of Keys

Keys That Begin with the Letter L

LO LIMIT, HI LIMIT

Press and release the SHIFT key, then the down-arrow key to access the low limit function.Press and release the SHIFT key, then the up-arrow key to access the high limit function. These functions are used to set measurement endpoints. Exceeding the end points causes screen prompts to blink until they are reset.

Chapter 4, Description of Keys

Keys That Begin with the Letter M

MEAS RESET

MEAS RESET clears the measurement history for all of the instrument’s measurement algorith ms (su ch as th e averag ing and p eak hold function s) to r estart all measurements that are in progress.

METER

The METER function displays measurements graphically. The METER format is available for most measure ment s. To determine if the METER format is provi ded for a measurement, position the cursor in front of the measurement’s units field and press the knob. If t he message “Press ON/OFF, LIMIT s, REF, AVG, METER, or units” is displayed, the METER format is provided.

Keys That Begin with the Letter O

ON/OFF

ON/OFF is used to enable and disable measurements, and to turn numeric fields (such as

See Also

"To Use the On/Off Function" on page 44

Amplitude) on and off.

Chapter 4, Description of Keys

Keys That Begin with the Letter O

Chapter 4, Description of Keys

Keys That Begin with the Letter P

PRESET

PRESET restores most of the instrument’s settings to their factory default states, although most CONFIGURE screen changes are not affected. Instrument selfdiagnostics are not run when PRESET is pressed.

PREV accesses the previous screen.

PRINT

POWER

Pressing PRINT outputs the entire contents of the displayed screen, the time and date, and any print title defined in the PRINT CONFIGURE screen. To print measurement results through GP-IB, the program must query the measurement and print the result in a format determined by the programmer.

See Also

"Print Configure Screen" on page 131 "Printing A Screen" on page 62

POWER turns the instrument’s power on and off.

Keys That Begin with the Letter R

RECALL

RECALL is used to recall instrument setups saved in SAVE/RECALL registers.

Programming RECALL

The GP-IB commands :REGister:RECall are used to select this function programmatically. The SAVE/RECALL mass storage device is selected using the

SAVE/RECALL field on the I/O CONFIGURE screen.

See Also

"Saving and Recalling Instrument Setups" on page 53

Chapter 4, Description of Keys

Keys That Begin with the Letter R

REF SET

RELEASE

Press and release the SHIFT key, then the INCR÷10 key to access the reference set function. This fu nctio n is us ed to ente r or r emove a mea surement refe re nce for relative AF and RF measurements.

This key is used to delete the assignment of the User Keys, K1 through K5, and

K1’ through K3’. Press and release the SHIFT key, then the K5 key to select the RELEASE function.

See Also

"Using USER Keys" on page 57

Chapter 4, Description of Keys

Keys That Begin with the Letter S

SAVE

Press and release the SHIFT key, then the RECALL key to access the save function. This stores instrument setups.

SHIFT

SHIFT is used to sele cted the blue- label ed func tions listed abo ve some keys ( such as PRINTER, CONFIG, RELEASE, EEX, and so forth).

Keys That Begin with the Letter Y

YES, NO

YES and NO are used to confirm selected operations before they are executed. Press and release the SHIFT key, then the ON/OFF key to access the YES function. Press and release the SHIFT key, then the RATIO W key to access the NO function.

Chapter 4, Description of Keys

Keys That Begin with the Letter Y

Chapter 4, Description of Keys

Keys That Begin with a Number

0 to 9, decimal point (.), +/-, and A to F

These keys are for entering and changing values. A through F are shifted functions. Press and rele ase the SHIFT key, then the appropriate key (0 throu gh 5) to select the letter A through F.

See Also

"To Enter and Change Values" on page 50

Symbol Keys

BACKSPACE

The backspace key is used to move the cu rsor to t he left when enter ing numbers in a field, such as to the left, erasing the previous character.

Down-Arrow, Up-Arrow

These keys increment (up-arrow) or decrement (down-arrow) field values. The increment value is determined by the INCR SET (:INCRement) data function.These keys are also used to select alternate field entries without displaying the the cursor in string entry fields (such as the CONFIGURE screen).

Chapter 4, Description of Keys

Symbol Keys

RF Gen Freq. Each press of this key moves the cursor one place

Choices menu used by some fields. They are also used to move

Print Title field on the PRINT

Programming Increment Up/Down (Arrow Keys)

See Also

"To Increment/Decrement Values" on page 52

Units-of-Measure Keys

The units keys are for ent ering and changing th e unit-of -measure (s uch as GHz, V, dBm, %, mW, and so forth) for measurements or field entrie s. Mil li wat ts (mW ) i s a shifted functio n. Press and r eleas e the SHIFT key, then the ENTER key to s elect mW.

See Also

"To Specify Units-of-Measure for CRT Display" on page 49

Chapter 4, Description of Keys

Miscellaneous Hardware

Knobs

CURSOR CONTROL

CURSOR CONTROL has thre e functions:

• Moving the cursor .

• Selecting fields, screens, and settings from a list of choices .

• Changing numeric field values.

VOLUME

VOLUME controls the speaker volume for monitoring the AF Analyzer's selected input. The volume is also affected by the Speaker Vol and Speaker ALC fields in the analog AF ANALYZER screen.

SQUELCH

SQUELCH adjusts the squelch level when demodulating AM, FM, or SSB signals. The squelch level is affected by the Squelch field in the analog RF ANALYZER screen.

DATA FUNCTIONS Keys

The DATA FUNCTIONS keys can b e divi ded into two grou ps; those which af f ect measurements (REF SET, METER, AVG, HI LIMIT and LO LIMIT), and those which affect numeric entry fields (INCR down-arrow). For measurements, the data functions enable the programmer to change the way measurements are calculated and displayed, and provide measurement limit detection. For numeric entry fields, the data functions enable

the programmer to set, scale, and change the field’s increment value.

Chapter 4, Description of Keys

DATA FUNCTIONS Keys

÷10, INCR SET, INCR×10 , up-arrow,

Chapter 4, Description of Keys

USER Keys

User keys instantly access instrument settings without using the knob. You can use user keys to move quickly between fields on the same screen, and to access field settings that are not normally available on the screen you are using.

Local user keys are u sed t o move between setting s on the screen that i s d is played. When the user key is pressed, the cursor instantly moves to, and selects, the assigned field; eliminating the need to turn and push the knob. Five local user keys are available for each screen: k1, k2, k3, k4, and k5.

Five factory-assi gned local user keys are av ail ab le in eac h screen; however, using these keys removes any other local user keys you may have already set up.

Global user keys are used to access settings that are not available on the current screen. Three global user keys are available: k1’, k2’, and k3’. (These are shifted functions of the local user keys.)

When defining user keys, the ASSIGN function is used to create key definitions; the RELEASE function removes the definitions. Re-assigning a user key to a different field setting automatically releases it from the setting it was previously associated with.

Description of Connectors

The connectors are listed in alphabetical order.

Chapter 5, Description of Connectors

POWER

DO NOT APPLY RF WHEN OFF

RF IN/OUT

MAX PWR

6 W

DUPLEX OUT

MAX PWR

200 mW

ANTENNA IN

Figure 7 Agilent 8924E Front Panel

CDMA CALL CONTRO L

CDMA SCRNS

CELL CALL CTRL

SPECTRUM

GEN CTRL

ANALOG SCRNS

CALL CTRL

CALL CNFG

AUTHEN

RANGE

MS RPT

ANLG MEAS

CALL DATA

SCOPESPEC ANL

END CALL

TEST

CALL ANS

USER DATA

k1’

k2’

k3’

ASSIGN

RELEASE

FUNCTIONS

MSG

PRINTER

HELP

DAT A F UNCTIONS

REF SET

METER

INCR

: 10

SET

LO LIMIT HI LIMIT

CURSOR

CONTROL

CANCELSHIFT

I/O CONFIG CON FIG

PREV TESTS

AVG

INCR

X10

PUSH TO

SELECT

INSTRUMENT STATE

ADRS

LOCAL

789

456 123 0

YES

NO ppm

ON/OFF

AUDIO OUTSQUELCHVOLUMEMIC/ ACC

MAX

12 v Pk

SAVE

RECALL

HOLD

MEAS

PRESET

RESET

MEMORY

CARD

ENTER

GHz dBm

MHz

kHz

Ω

µV

dBµV

AUDIO IN

LOHI

MAX

42 v Pk

Connectors That Begin with the Letter A

ANTENNA IN

The antenna input is used to analyze low-power RF signals (≤ 200 mW), and is typically used for off-the-air measurements. This port can be selected in the analog TX TEST, DUPLEX TEST, RF ANALYZER, or SPECTRUM ANALYZER screens.

Operating Considerations

•BNC

• Input impedance = 50Ω

• TX Power cannot be measured using this port; use the RF IN/OUT port. However, low power levels can be measured using this port with the spectrum analyzer.

• Additional sensitivity for this port is available using the Sensitivity field in the analog RF ANALYZER and SPECTRUM ANALYZER screens.

Chapter 5, Description of Connectors

Connectors That Begin with the Letter A

CAUTION: Connecting a signal of >200 mW to the ANT IN port can cause instrument damage (although

internal protection circuits can typically withstand a short-duration signal of 1 or 2 Watts).

If the over-power circuit is triggered (signified by a warning message at the top of the screen), remove the signal from the ANT IN port, and press the MEAS RESET key, or turn the Test Set off and on to reset it.

Chapter 5, Description of Connectors

Connectors That Begin with the Letter A

AUDIO IN LO, HI

The audio inputs are used to input audio signals to the AF Analyzer.

• AUDIO IN HI is the main audio signal input connection.

• AUDIO IN LO is used for the audio signal reference. Three choices are available using the AF ANALYZER screen's Audio In Lo field:

• Gnd - connects the center pin through approximately 100Ω to chassis ground

• Float - provides a floating input.

• 600 To Hi - provides a 600 internal load to match an audio source with an output.

The measured level is the po tenti al bet ween the HI and LO cente r pins. The shell s of both connectors are at chassis ground.

Operating Considerations

•BNC

• Input impedance switchable between

•1 MΩ in parallel with 95 pF,

•600Ω floating.

• This port is selected as the AF Analyzer's input using the AF Anl In field in the analog TX TEST screen, DUPLEX TEST screen, AF ANALYZER screen, and various ENCODER screens. This port is always the AF Analyzer's input when the analog RX TEST screen is displayed.

• Signals input to the AF Analyzer are routed through different filters, amplifiers, and detectors that affect the displayed measurement.

CAUTION: The maximum level between the HI an d LO center pi ns is 4 2 V peak (approx imatel y 30 Vrms).

Exceeding this value can cause permanent instrument damage.

See Also

AF Anl In Audio In Lo

field description, on page 143

field description, on page 151

AUDIO OUT

The audio output is used to output signals from AF Generators 1 and 2, including the Encoder functions

Operating Considerations

•BNC

• Output impedance <1Ω

• Maximum output current = 20 mA peak

• Maximum reverse voltage = 12 V peak

• The output level is set by the AF Generators, and it is not affected by the front-panel VOLUME control.

• AC/DC coupling is s elect ed us i ng th e Audio Out f ield. This field is available in the DUPLEX TEST screen, RF GENERATOR screen, and various ENCODER screens.

AUD MONITOR OUTPUT

Chapter 5, Description of Connectors

Connectors That Begin with the Letter A

The audio monitor output provides an external output from various tap points in the AF Analyzer.

Operating Considerations

•BNC

• Output impedance is < 1 kΩ

•The Scope To field in the analog AF ANALYZER screen determines the source of this signal.

• The level is not affected by the front-panel VOLUME knob.

Chapter 5, Description of Connectors

Connectors That Begin with the Letter C

CELL SITE/TRIGGERS

This is a 37-pin connec tor. It provides CDMA triggers and digital cell diagno stics. Four pins are not used.

A cable adapter is provided for protocol logging. Refer to “Protocol Logging”

chapter in the Agilent 8924C Application Guide, for a description of using this feature. The adapter consists of a ribbon cable with 1 sub-miniature type-D, female, 15-pin connector and 2 male, 9-pin connectors.

Operating Considerations

• Pin 1 - GND

• Pin 2 - GND

• Pin 3 - 1.25 ms Frame Clock The 1.25 ms Frame Clock provides a clock output that is aligned with power control

group timeslots. See also - "CDMA CLOCK MUX OUTPUT" on page 93.

• Pin 4 - 26.667 ms Frame Clock The 26.667 ms Frame Clock provides a clock that is aligned with the short (Pilot PN)

spreading sequence and the Sync Channel frame structure. See also - "CDMA CLOCK MUX OUTPUT" on page 93.

• Pin 5 - EVEN_SEC_OUT The Even Second Clock provides a clock that is aligned with the timing reference for

CDMA frame clocks. The even second reference is input on the rear-panel connector, EVEN SEC IN.

• Pin 6 - SAT0

• Pin 7 - SAT2

• Pin 8 - PROTO_TRIG2

• Pin 9 - A_RI_2 Part of cell site #2 diagnostic port.

Pin 10 - A_CTS_2 Part of cell site #2 diagnostic port.

•Pin 11 - A_RTS_2 Part of cell site #2 diagnostic port.

•Pin 12 - A_DSR_2 Part of cell site #2 diagnostic port.

• Pin 13 - Ground

•Pin 14 - A_DTR_1 Part of cell site #1 diagnostic port.

• Pin 15 - A_TXD_1 Part of cell site #1 diagnostic port.

• Pin 16 - A_RXD_1

Chapter 5, Description of Connectors

Connectors That Begin with the Letter C

Part of cell site #1 diagnostic port.

• Pin 17 - A_SD_1 Part of cell site #1 diagnostic port.

• Pins 18, 19 - Not connected

• Pins 20, 21 - Ground

• Pin 22 - 20 ms Frame Clock The 20 ms Frame Clock provides a clock output that is aligned with Traffic and

Access Channel frames. See also - "CDMA CLOCK MUX OUTPUT" on page 93.

• Pin 23 - 80 ms Frame Clock The 80 ms Frame Clock provides a clock that is aligned with the Paging Channel Slots

(referring to mobile station slotted mode operation) and the Sync Channel Superframe. See also - "CDMA CLOCK MUX OUTPUT" on page 93.

Chapter 5, Description of Connectors

Connectors That Begin with the Letter C

• Pin 24 - DSP_TRIG_OUT A true condition on this connector indicates the DSP Analyzer was triggered. The DSP

analyzer can be triggered by a signal on the EXT DSP TRIGGER rear -panel B NC connector, or by the user arming a measurement.

CDMA CLOCK MUX OUTPUT

The CDMA frame clocks provide the CDMA timing re ferences for generating a nd demodulating CDMA signals. The CDMA clock MUX output provides the following CDMA frame clocks on a multiplexed output.

1.25 ms

20.00 ms

26.67 ms

80.00 ms

2.00 s

Each of these CDMA frame clocks is available by selecting from the list of choices displayed on the CONFIGURE screen.

The CELLSITE/TRIGGERS connector, a rear-panel miniature D-type 15-pin connector provides all of the above frame clock outputs simultaneously. The timing of these frame cl ocks may be offset slight ly fr om the ti ming of the CDMA

CLOCK MUX OUTPUT’s frame clocks due to propagation delays.

Chapter 5, Description of Connectors

Connectors That Begin with the Letter C

Operating Considerations

•BNC

• Select which frame clock will be output on the CDMA CLOCK MUX OUTPUT

• Nominal output level is >+5 dBm

• Output impedance is 50Ω

• All frame clocks are locked to the Test Set’s internal 10 MHz reference. Frequency

See Also

Frame Clock

COMPOSITE VIDEO

The composite video o utput p rovide s a si gnal f or usi ng an ext ernal video monitor. The signal provides a duplicate of the Test Set’s screen.

Operating Considerations

•BNC

• A multi-sync monitor must be used to match the video sync rate of 19.2 kHz. Example

connector by pressing and releasing the SHIFT key, then the TESTS key to select the CONFIGURE screen, then selecting the Frame Clock field to display the list of choices.

stability is the same as the signal applied to the REF INP UT connector.

field description, on page 203

monitors include - Electrohome EC M 1410-DMS 14 -inch co lor monit or and the EVM 1242-P4VID 12-inch monochrome monitor.

Chapter 5, Description of Connectors

Connectors That Begin with the Letter D

DC CURRENT MEAS

The current sense input is used in seri es with a dc sup ply and l oad to provide a 0 to 10 amp dc current meter.

Operating Considerations

• Dual-Banana Jack

• The dc-current meter is designed to measure positive current (the connector's polarity is marked on the rear panel). Negative current of ≤10 amps will not damage the instrument, but will cause inaccurate positive current measurements (due to magnetic memory within the current-sensing element).

• To re-calibrate the current meter after negative current has been applied

1. Connect a 10-amp positive current.

2. Dis connect the current

3. Acces s the analog AF ANALYZER screen.

4. Select the DC Current Zero field to zero the meter.

DUPLEX OUT

The duplex output is an output for the RF Generator and Tracking Generator. When testing CDMA mobile stations, it is important to enter an RF Level Offset

for the selected inp ut a nd out put por ts. Refer to “Calibrating the Test Set” chapter

in the Agilent 8924C Application Guide.

Operating Considerations

•BNC

• Output impedance = 50Ω

• The RF Generator's output is selected in the Output Port field. This field is available on the CONFIGURE, RX TEST, DUPLEX TEST, RF GENERATOR, and SPECTRUM ANALYZER screens.

CAUTION: Connecting an RF source of >200 mW to this connector can permanently damage the

instrument.

Connectors That Begin with the Letter H

GP-IB

The main GP-IB port allows communication between the Test Set and other instruments or computers using the Hewlett-Packard Interface Bus (GP-IB).

Operating Considerations

• 36-pin GPIB

See Also

Chapter 5, Description of Connectors

Connectors That Begin with the Letter H

GP-IB Adrs

field description, on page 208

Chapter 5, Description of Connectors

Connectors That Begin with the Letter M

MIC/ACC

The microphone/accessory connector is used for several functions:

Key Out 1 Key In

N.C.

• Mic In is used to modulate the RF Generator when the Key In line is grounded. This signal is summed with the external modulation input signal. The Mod In To field of the RF GENERATOR screen sets the type of modulation (AM or FM) and sensitivity (%AM/Vpk or kHz/Vpk) for this connection.

• Key In provides control of the RF Generator's output state (on or off) and automatic switching between the TX TEST and RX TEST screens (if the CONFIGURE screen’s RX/TX Cntl functions are set to Auto line is grounded.

• Key Out 1 and Key Out 2 pr ovide a swi tch pat h to control exte rnal equipmen t (s uch as keying a transmitter). Key Out 1 and Key Out 2 are connected when the Ext TX key field is set to On

GND

Key Out 2

MIC In

N.C.

Ground Tab

and PTT). Screen switching occurs when this

Chapter 5, Description of Connectors

Connectors That Begin with the Letter M

To Use the Microphone

1. Connect the microphone to the MIC/ACC connector.

2. Access the analog RF GENERATOR screen.

3. Enter the carrier frequency in the RF Gen Freq field.

4. Enter the RF Generator Amplitude.

5. Select the Output Port (RF OUT or DUPL).

6. Connect the selected output port to your receiver or antenna.

7. Using the Mod In To field a. Select the type of modulation: FM (/Vpk) b. Enter the modulation sensitivity to a 1 V peak signal (usually 1 kHz for microphone

use).

Operating Considerations

•8-pin DIN

• Input impedance = 100 kΩ

• Maximum input level = 10 V peak

• Full scale input = 10 mV

• Bandwidth is limited to 3 kHz.

• The MIC IN signal is filtered and amplified to provide a stable deviation-limited signal to the RF Generator.

•750µs microphone pre-emphasis is selected in the analog RF GENERATOR screen.

See Also

"Configure Screen" on page 128

Chapter 5, Description of Connectors

Connectors That Begin with the Letter M

MODULATION INPUT

The modulation input provides an external modulation connection to the RF Generator.

Operating Considerations

•BNC

• Input thre shold = 2.5 V

• Max input level = 20 V peak

• Input impedance

• 100 kΩ (input < 5.6 V peak)

•5 kΩ (input > 5.6 V peak)

•The Mod In To field of the analog RF GENERATOR screen sets the type of modulation (AM or FM) and sensitivity (%AM/Vpk or kHz/Vpk) for this connection.

• This signal is summed with the microphone’s input signal from the MIC/ACC connector.

•The FM Coupling field in the RF GENERATOR, DUPLEX TEST, and various ENCODER screens selects AC or DC coupling of this signal for FM operation.

Connectors That Begin with the Letter P

PARALLEL PORT

This port is used with printers requiring a p arallel interf ace when printing screen images or test results. Set the CONFIGURE screen or TESTS (Printer Setup) screen) to this port. Use address 15 when sending data to this port from IBASIC programs.

Pin numbers are embossed on the connector.

1. nStrobe

2. Data 1 (Least Significant Bit)

3. Data 2

4. Data 3

5. Data 4

6. Data 5

7. Data 6

8. Data 7

9. Data 8 (Most Significant Bit)

10. nAck

11. Busy

12. PError

13. Select

14. nAutoFd

15. nFault

16. nInit

17. nSelectIn

18. Signal Ground (nStrobe)

19. Signal Ground (Data 1 and Data 2)

20. Signal Ground (Data 3 and Data 4)

21. Signal Ground (Data 5 and Data 6)

22. Signal Ground (Data 7 and Data 8)

23. Signal Ground (Busy and nFault)

24. Signal Ground (PError, Select, and nAck)

25. Signal Ground (nAutoFd, nSelectIn, and nInit)

Chapter 5, Description of Connectors

Connectors That Begin with the Letter P

Printer Port: field (on the PRINT

Parallel to print to

Operating Considerations

• 25-pin Centr onics

Chapter 5, Description of Connectors

Connectors That Begin with the Letter P

POWER DET

The POWER DET input routes a dc-coupled signal from the average power detector on the HP 83236 PCS Interf ace to the DSP Analyzer in th e Test Set. This signal, which is multiplexed with other power measurements, cannot be selected by the user.

Operating Considerations

•SMA

• If a frequency translator is connected to the Test Set, the POWER DET input must be connected to the POWER DET output from the frequency translator to make average power measurements.

See Also

PROTOCOL DIAG

TX Power

field description, on page 291

The protocol logging, cell site 1, RS-232 port is not implemented at this time.

Operating Considerations
