The Agilent Technologies 8924E CDMA mobile station
test set provides the key set of measurements to verify
the performance of dual-mode CDMA mobile phones
operating from 500 to 1000 MHz. With the Agilent
Technologies 83236B PCS Interface, the 8924E additionally offers CDMA mobile testing from 1700 to 2000 MHz.
Acting as a calibrated, high performance CDMA base station, the 8924E verifies not only the parametric characteristics of CDMA phones, but also the functional
aspects of phone performance.
The 8924E’s full AMPS, NAMPS, EAMPS, TACS, NTACS,
ETACS and JTACS test capability saves you space, cost,
and training expenses by allowing you to make both analog and CDMA digital measurements with the same
instrument.
For complete, call processing verification, the 8924E
supports both mobile and base station initiated call connect and disconnect. Once a phone call is established,
verifying the overall functionality of a CDMA mobile is
simple using the 8924E’s voice echo mode. For testing a
variety of protocol formats, the 8924E offers six user
selectable protocol stacks: IS-95, IS-95A, TSB-74, J-STD008, ARIB T53, and KOREAN PCS. The 8924E also supports a number of service options, including 9600 BPS
and 14,400 BPS traffic channel configurations.
Agilent 8924E
CDMA Mobile Station
Service Test Set—30 MHz to
1000 MHz, 1700 MHz to 2000 MHz
Technical Specifications
2
High Accuracy CDMA Source for CDMA Receiver
Test
The 8924E provides active cell site emulation by supporting the following CDMA channels: pilot, sync, paging, traffic, and orthogonal channel noise source (OCNS).
An additive white Gaussian noise (AWGN) source is also
included to provide the interference generated by adjacent cells in a working CDMA network. The 8924E measures receiver frame-error-rate (FER) at all four date
rates used in the CDMA system: full, half, quarter, and
one-eighth. Confidence limit technology is used to
reduce receiver test time to an absolute minimum.
CDMA Transmitter Measurements
The 8924E provides an average power measurement
based on new DSP technology. A DSP based channel
power measurement enables the 8924E to achieve accurate low level CDMA power measurements. Access probe
power measurements are also available. The 8924E
measures transmitted waveform quality by using the
IS-98A/J-STD-018 recommended correlated power
method, also known as the rho (ρ) measurement. In
addition, the rho measurement reports the frequency
error, modulation phase and amplitude error, and the
carrier feedthrough.
Handoff Verification
To speed testing, the 8924E supports hard hand-offs
between RF channels. CDMA to analog hand-offs from
both cellular and PCS bands are also supported.
Authentication and Short Message Service Support
The 8924E provides the necessary features for testing a
CDMA mobile station’s ability to perform call processing
functions with authentication for Korea and the United
States. Also, the 8924E supports mobile terminated SMS.
Automated Software
The Agilent Technologies E8290A PoST (point of service
test) software makes the 8924E an automated CDMA test
solution. The E8290A quickly provides accurate phone
performance and quality data at the point of sale. This
PC-based solution is very easy to use, reduces churn,
reduces no trouble found (NTF), and improves customer
care.
The Agilent Technologies 83217A CDMA dual-mode
mobile station test software can also be used to automate CDMA and analog mobile phone measurements.
The 83217A solution does not require a PC. Rather, automatic tests can be completely set up using the front
panel of the 8924E. Options are available to meet your
test needs for CDMA, AMPS, NAMPS, JTACS, NTACS,
U.S. PCS, and Korean PCS phones.
Specifications describe the instrument’s warranted performance
and apply after a 30 minute warm-up. These specifications are
valid over the 8924E’s entire operating environmental range
unless otherwise noted.
Supplemental Characteristics (shown in italics) are intended to
provide additional information, useful in applying the instrument
by giving typical expected, but non-warranted performance.
3
8924E Analog Mode Specifications
Call Processing Functionality
Standards: AMPS, NAMPS, TACS, JTACS, and NTACS
Registration Support: Zone Registration
Call Control: BS call originate and disconnect, MS call originate,
and disconnect
Authentication: Registration, paging, origination, SSD update, and
unique challenge
Orders: Power levels 0 through 7, maintenance, and alert
Handoff Support: Handoff to new frequency, between narrow
channel and wide channel
Signal Generator
RF Frequency
Range:
Standard: 30 MHz to 1000 MHz
With the 83236B:
800 MHz to 960 MHz
1710 MHz to 1785 MHz
1805 MHz to 1910 MHz
1930 MHz to 1990 MHz
Usable from 1700 to 1999.999999 MHz
Accuracy and Stability: Same as reference oscillator ±0.015 Hz
Switching Speed: <150 ms to be within 100 Hz of carrier frequency
Resolution: 1 Hz
Output
RF IN/OUT Connector
Level Range:
Standard: –127 dBm to –10.5 dBm into 50 Ω
With the 83236B: –130 dBm to –20 dBm into 50 Ω
Level Accuracy:
Standard: ±1.2 dB (Level ≥–127 dBm)
Typically ±1.0 dB for all levels
With the 83236B:
±1.8 dB, at 25 °C ±10 °C
±2.0 dB, at 0 °C to 55 °C
±1.0 dB typically
Reverse Power:
Standard: 3 W
With the 83236B: 10 W
SWR: Standard: <1.5:1
With the 83236B: <1.2:1
DUPLEX OUT/RF OUT Only Connector
Level Range:
Standard: –127 dBm to +3.5 dBm into 50 Ω
With the 83236B: –130 dBm to –10 dBm into 50 Ω
Level Accuracy:
Standard: ±1.0 dB
With the 83236B:
±1.8 dB, at 25 °C ±10 °C
±2.0 dB, at 0 °C to 55 °C
±1.0 dB typically
Reverse Power: 200 mW maximum
SWR: Standard: <2.0:1 (level <–7.5 dBm)
With the 83236B: <1.6:1
Resolution: 0.1 dB (settable in 0.01 dB increments)
Spectral Purity
All specifications are for ≤–2.5 dBm output level at DUPLEX OUT
or ≤–15 dBm output level at RF IN/OUT
Harmonics: <–30 dBc
Non-Harmonic Spurious: <–60 dBc (at >5 kHz offset from carrier)
Residual FM (CCITT, rms):
Standard:
<7 Hz for 500 MHz <f
c
<1000 MHz
<4 Hz for 250 MHz ≤f
c
≤500 MHz
<7 Hz for 30 MHz ≤f
c
<250 MHz
With the 83236B:
<7 Hz for 810 MHz <f
c
<960 MHz
<10 Hz for 1710 MHz <f
c
<1990 MHz
SSB Phase Noise:
Standard: <–116 dBc/Hz (for >20 kHz offsets at a
1000 MHz carrier frequency)
With the 83236B: <–100 dBc/Hz at >20 kHz offsets
FM
FM Deviation (rates >25 Hz):
Standard:
100 kHz; 30 to <249 MHz
50 kHz; 249 to <501 MHz
100 kHz; 501 to 1000 MHz
With the 83236B:
100 kHz; 800 MHz to 960 MHz, 1710 MHz to 1785 MHz;
1805 MHz to 1910 MHz, 1930 MHz to 1990 MHz
FM Rate (1 kHz reference):
Internal: DC to 25 kHz (1 dB BW)
External: AC Coupled: 20 Hz to 75 kHz (typical –3 dB BW)
FM Accuracy (1 kHz rate):
<10 kHz deviation: ±3.5% of setting ±50 Hz
>10 kHz deviation: ±3.5% of setting ±500 Hz
4
FM Distortion (THD+Noise, 0.3 to 3 kHz BW):
<0.5 % at >4 kHz deviation and 1 kHz rate
External Modulation Input Impedance: 600 Ω nominal
Resolution:
50 Hz for <10 kHz deviation
500 Hz for ≥10 kHz deviation
Audio Source
Frequency
Range: 300 Hz to 10 kHz
Accuracy: 0.025 % of setting
Resolution: 0.1 Hz
Output Level
Range: 0.1 mV to 4 Vrms
Maximum Output Current: 20 mA peak
Output Impedance: <2.5 Ω (at 1 kHz)
Accuracy: ±2% of setting plus resolution
Residual Distortion (THD + Noise, level ≥200 mVrms):
<0.125%; 300 Hz to 10 kHz in an 80 kHz BW
Resolution:
Level ≤0.01 V: ±50 µV
Level ≤0.1 V: ±0.5 mV
Level ≤1 V: ±5 mV
Level <10 V: ±50 mV
RF Analyzer
RF Frequency Measurement
Measurement Range:
Standard: 30 MHz to 1000 MHz
With the 83236B:
800 MHz to 960 MHz
1710 MHz to 1785 MHz
1805 MHz to 1910 MHz
1930 MHz to 1990 MHz
Usable from 1700 to 1999.999999 MHz
Level Range:
Standard:
RF IN/OUT: –10 dBm to +35 dBm (0.1 mW to 3 W)
ANT In: –36 dBm to +20 dBm
With the 83236B:
RF IN/OUT: –10 dBm to +40 dBm (0.1 mW to 10 W)
Accuracy: ±1 Hz plus timebase accuracy
Minimum Resolution: 1 Hz
RF Power Measurement
Note: To achieve the specified accuracy when measuring power
at the RF IN/OUT port, the internal signal generator level must be
40 dB below the measured power or less than –20 dBm at the
DUPLEX OUT port.
Frequency Range:
Standard: 30 MHz to 1000 MHz
With the 83236B:
800 MHz to 960 MHz
1710 MHz to 1785 MHz
1805 MHz to 1910 MHz
1930 MHz to 1990 MHz
Input Connector: RF IN/OUT connector only
Measurement Range:
Standard: –10 dBm to +35 dBm (0.1 mW to 3 W)
With the 83236B: –13 dBm to +40 dBm (50 µW to 10 W)
Accuracy (after power meter zero):
Standard:
±5% of reading ±0.01 µW from 15 °C to 35 °C
±10% of reading ±0.01 µW from 0 °C to 55 °C
With the 83236B:
±5% of reading ±2.5 µW at 23 °C ±10 °C
±10% of reading ±2.5 µW
SWR:
Standard: <1.5:1
With the 83236B: <1.2:1
Resolution:
Standard:
Power <10W: 1 mW
Power <100 mW: 0.1 mW
Power <10 mW: 0.01 mW
With the 83236B: 0.01 dB or 10 µW
FM Measurement
Frequency Range:
Standard: 30 MHz to 1000 MHz
With the 83236B:
800 MHz to 960 MHz
1710 MHz to 1785 MHz
1805 MHz to 1910 MHz
1930 MHz to 1990 MHz
Deviation Range: 20 Hz to 75 kHz
Sensitivity: 2 µV (15 kHz IF BW, High Sensitivity Mode,
0.3 to 3 kHz BW)
1
Typically <1 µV (12 dB SINAD, fc >30 MHz)
1. Possible degradation in the 1700 to 1999 MHz bandwidth
5
Accuracy (20 Hz to 25 kHz rates, deviation <25 kHz):
±4 % of reading plus residual FM and noise contribution
Bandwidth (3 dB): 2 Hz to 70 kHz
THD+Noise: <1% for >5 kHz Deviation and 1 kHz rate in a 0.3 to
3 kHz BW
1
Input Level Range for Specified Accuracy:
Standard:
–28 to +35 dBm at RF IN/OUT (1.6 µW to 3 W)
–50 to +14 dBm at Ant In
With the 83236B: –36 dBm to +40 dBm
Residual FM and Noise (0.3 to 3 kHz, rms):
Standard: <7 Hz
With the 83236B: <10 Hz
Resolution:
Deviation <10 kHz: 1 Hz
Deviation ≥10 kHz: 10 Hz
Spectrum Analyzer (Option 102 required)
Frequency Range: (Center frequency coupled to RF Analyzer setting)
Standard: 30 MHz to 1000 MHz
With the 83236B:
800 MHz to 960 MHz
1710 MHz to 1785 MHz
1805 MHz to 1910 MHz
1930 MHz to 1990 MHz
Frequency Span/Resolution Bandwidth (coupled):
Standard: Span
Bandwidth
<50 kHz 300 Hz
<200 kHz 1 kHz
<1.5 MHz 3 kHz
<18 MHz 30 kHz
>18 MHz 300 kHz
With the 83236B:
Span
Bandwidth
<50 kHz 300 Hz
<200 kHz 1 kHz
<1.5 MHz 3 kHz
Display: Log with 10 dB/division, 2 dB/division, or 1 dB/division
Display Range: 80 dB
Reference Level Range: +50 to –50 dBm
Residual Responses: <–70 dBm (no input signal, 0 dB
attenuation)
Image Rejection: >50 dB
Non-harmonic Spurious Responses: >70 dB (for input
signals ≤–30 dBm)
Level Accuracy: ±2.5 dB
Log Scale Linearity: ±2 dB (for input levels <–30 dBm and/or
60 dB range)
Displayed Average Noise Level: <–114 dBm (≤50 kHz spans)
Other Features: Peak hold, marker with frequency and level read-
out, marker to peak, marker to next peak, trace comparison A-B
Tracking Generator
(Not available when used with the 83236B)
Frequency Range: 30 MHz to 1000 MHz
Frequency Offset: Frequency span endpoints ± frequency offset
cannot be <30 MHz or >1000 MHz
Output Level Range: Same as signal generator
Sweep Modes: Normal and Inverted
Audio Analyzer
Frequency Measurement
Measurement Range: 20 Hz to 400 kHz
Accuracy: ±0.02% plus resolution plus reference oscillator accuracy
External Input: 20 mV to 30 Vrms
Resolution:
f <10 kHz: 0.01 Hz
f <100 kHz: 0.1 Hz
f ≥100 kHz: 1 Hz
AC Voltage Measurement
Measurement Range: 0 to 30 Vrms
Accuracy (20 Hz to 15 kHz, >1 mV): ±3% of reading
Residual THD+Noise (15 kHz BW):
With a load (<=600 Ω) connected to Audio In Hi: 150 µV
Without load: 480 µV
3 dB Bandwidth: Typically 2 Hz to 100 kHz
Nominal Input Impedance: Switchable between 1 M Ω in parallel
with 95 pF or 600 Ω floating
Resolution:
4 digits for inputs ≥100 mV
3 digits for inputs <100 mV
1. Possible degradation in the 1700 to 1999 MHz bandwidth.
Loading...
