Agilent 86120B
Multi-Wavelength Meter
Technical Specifications
The Agilent 86120B Multi-Wavelength Meter is a Michelson interferometer-based instrument that measures wavelength
and optical power of laser light in the 700 to 1650 nm wavelength range. Simultaneous measurements of multiple laser
lines are performed allowing measurements of WDM (wavelength division multiplexed) signals and multiple lines of FabryPerot lasers. Each laser line is assumed to have a linewidth of less than 10 GHz.
This technical specifications sheet describes the measurement accuracy and operating condition of the Agilent 86120B
Multi-Wavelength Meter. The specifications apply to all functions over the temperature range 0 to 55°C and relative
humidity <95% (unless otherwise noted). All specifications apply after the instrument’s temperature has been stabilized
after 15 minutes continuous operation, and when the instrument is in NORMAL UPDATE mode unless noted.
Wavelength
Range
700 to 1650 nm (182 to 428 THz)
Absolute accuracy, laser lines separated by >30 GHz
±3 ppm (±0.005 nm at 1550 nm, ±0.004 nm at 1310 nm)
Differential accuracy
1
±2 ppm
Minimum resolvable separation
l,2
(equal power lines input)
20 GHz (0.16 nm at 1550 nm, 0.11 nm at 1300 nm)
Display resolution
0.001 nm, normal update mode
0.01 nm, fast update mode
Power
Calibration accuracy
±0.5 dB (at ±30 nm from 780, 1310, and 1550 nm)
Flatness, 30 nm from any wavelength
1200 to 1600 nm
l
±0.2 dB
700 to 1650 nm
l
±0.5 dB
Linearity
3
±0.3 dB
Polarization dependence,
1200 to 1600 nm ±0.5 dB
700 to 1650 nm
l
±1.0 dB
Display resolution 0.01 dB
1
Characteristic
2
For lines separated by less than 30 GHz, wavelength accuracy is reduced.
3
1200 to 1600 nm, lines above –30 dBm
2
Definition of Terms
Characteristics and Specifications
The distinction between specifications and characteristics is described as follows:
• Specifications describe warranted performance.
• Characteristics provide useful, but nonwarranted information about the functions and performance of the instrument.
Wavelength
• Range refers to the allowable wavelength range of the optical input signal.
• Absolute accuracy indicates the maximum wavelength error over the allowed environmental conditions.
• Differential accuracy indicates the maximum wavelength error in measuring the wavelength difference between two
signals that are simultaneously present.
• Minimum resolvable separation indicates the minimum wavelength separation of two laser lines input required to
measure each wavelength simultaneously. Two laser lines closer in wavelength than the minimum resolvable separation
are not resolved and one average wavelength is displayed.
• Display resolution indicates the minimum incremental change in displayed wavelength.
Power
• Calibration accuracy indicates the maximum power calibration error at the specified wavelengths over the allowed
environmental conditions.
• Flatness refers to the maximum amplitude error in a measurement between two lines that are separated in wavelength
by no more than the specified amount.
• Linearity indicates the maximum power error in measuring the change in power of one laser line.
• Polarization dependence indicates the maximum displayed power variation as the polarization of the input signal is
varied.
• Display resolution indicates the minimum incremental change in displayed power.
Sensitivity
• Sensitivity is defined as the minimum power level of a single laser line input to measure wavelength and power
accurately. A laser line with less than the minimum power may be measured but with reduced wavelength and power
accuracy. For multiple laser lines input, sensitivity may be limited by total input power.
Selectivity
• Selectivity indicates the ability to measure the wavelength and power of a weak laser line in the proximity of a specified
stronger laser line and separated by the specified amount.
Input Power
• Maximum displayed level indicates the maximum total input power (total of all laser lines present) to accurately
measure wavelength and power.
• Maximum safe input power indicates the maximum total input power (total of all laser lines present) to avoid
permanent optical damage to the instrument.
Maximum Number of Lines Input
• Maximum number of lines input is the maximum number of displayed lines. If more than 100 lines are input, only the
100 longest wavelength lines are displayed.
Input Return Loss
• Input return loss indicates the optical power reflected back to the user’s fiber cable relative to the input power. It is
limited by the return loss of the front panel connector, and assumes the user’s connector is good.
Measurement Cycle Time
• Measurement cycle time refers to the cycle time when measuring wavelength and power of laser lines. Specific
advanced applications may require longer cycle times.
3
Sensitivity
4
700 to 800 nm, single line input –20 dBm
800 to 1200 mn, single line input –25 dBm
1200 to 1600 nm, single line input
5
–40 dBm
1600 to 1650 nm, single line input
5
–30 dBm
700 to 1650 nm, multiple lines input
l
30 dB below total input power, but not less than single
line input sensitivity
Selectivity
2 lines input separated by >100 GHz
l
25 dB
2 lines input separated by >30 GHz
l
10 dB
Input Power
Maximum displayed level (sum of all lines input)
+10 dBm
Maximum safe input level (sum of all lines input)
+18 dBm
Maximum Number of Laser Lines Input
100
Input Return Loss
With flat contacting connectors 35 dB
With angled contacting connectors (option 022) 50 dB
Measurement Cycle Time
Normal update mode
l
1.0 sec (1 measurement/sec)
Fast update mode
l
0.33 sec (3 measurements/sec)
Wavelength Units
nm (vacuum or standard air), cm–1, THz
Power Units
dBm, mW, µW
Measurement Modes
List by Wavelength Table, List by Power Table, Single Wavelength and Power, Average Wavelength and Total Power
Delta Modes
Delta Wavelength, Delta Power, Delta Wavelength and Power
Built in Automatic
Measurement Applications
Signal-to-Noise Ratio
l
>35 dB (0.1 nm noise bandwidth), lines above –25 dBm
Signal-to-Noise Ratio
l
of Modulated Lasers
(with Averaging)
>35 dB (0.1 nm noise bandwidth), lines above –25 dBm,
with 100 averages
Drift
Maximum, minimum, total drift (max-min) of wavelengths and powers over time
Coherence length
l
Fabry-Perot lasers, 1 to 200 mm coherence length,
accuracy to within ±5%, 0.75 sec cycle time
Additional Features
Power Offset, Power Bars (On or Off), user adjustable
Peak Excursion and Peak Threshold, user adjustable
Start and Stop wavelength limits, Graphical display,
Save and Recall instrument states.
Inputs/Outputs
Optical input 9/125 µm fiber
Rear panel connectors
GPIB, parallel printer por-t, AC Line
Dimensions and Weight
Dimensions
140 mm high x 340 mm wide x 465 mm deep
(5.5 in x 13.4 in x 18.3 in)
Weight
9 kg (19 lb)
Environmental
Operational Storage
Temperature O°C to +55°C –40°C to +70°C
(warranted)
Humidity <95% R. H. at +40°C, Noncondensing
(type tested) 5 day soak 90% R. H. at +65°C
for 24 hrs.
Shock 300 g, half sine,
(type tested) 2 msec pulse
Vibration Random, 5 g rms
(type tested) 5 to 500 Hz, 10 min./axis
Sine, 0.75 g (0 to peak)
5 to 500 Hz, 1 octave/min.
EMC Conducted and radiated interference is in
compliance with CISPR Pub 11, IEC 801-2,
IEC 801-3, IEC 801-4 and IEC 555-2
Note: “type tested” means tested, but not warranted, for continuous operation.
Power Requirements
Voltage and frequency
88 to 269 VAC, 45 Hz to 440 Hz
Maximum power
70 watts max (125 VA max)
1
Characteristic
2
For lines separated by less than 30 GHz, wavelength accuracy is reduced.
3
1200 to 1600 nm, lines above –30 dBm
4
Contact HP for availability of special instruments with higher sensitivity.
5
Spurious free under Preset conditions
Ordering Information
Agilent 86120B Multi-Wavelength Meter
Standard instrument includes a front-panel FC/PC optical
fiber connector interface and a User’s Manual.
Connector options replacing the standard FC/PC
connector interface:
Option O11 HMS-10
Option 013 DIN
Option 014 ST
Option 017 SC
Option 022 Replace flat physical contact interface
with angled physical contact interface
Additional connector interfaces can be ordered
separately:
81000AI Diamond HMS-10 connector interface
8100OFI FC/PC/SPC/APC connector interface
81000GI D4 connector interface
81000KI SC connector interface
81000SI DIN 47256/4108.6 connector interface
8100OVI ST connector interface
8100OWI Biconic connector interface
Fixed external 10 dB attenuators:
Option 412 FC/PC
Option 417 FC/APC (requires option 022)
Other options:
Option 512 Upgrade of existing Agilent 86120A to
Agilent 86120B specifications
Option UK5 Nylon carrying case with shoulder strap
Option UK6 Commercial calibration certificate with
test data
For more information about Agilent Technologies
test and measurement products, applications,
services, and for a current sales office listing,
visit our web site,
www.agilent.com/comms/lightwave
You can also contact one of the
following centers and ask for a test and
measurement sales representative.
United States:
Agilent Technologies
Test and Measurement Call Center
P.O. Box 4026
Englewood, CO 80155-4026
(tel) 1 800 452 4844
Canada:
Agilent Technologies Canada Inc.
5150 Spectrum Way
Mississauga, Ontario
L4W 5G1
(tel) 1 877 894 4414
Europe:
Agilent Technologies
Test & Measurement
European Marketing Organization
P.O. Box 999
1180 AZ Amstelveen
The Netherlands
(tel) (31 20) 547 2000
Japan:
Agilent Technologies Japan Ltd.
Call Center
9-1, Takakura-Cho, Hachioji-Shi,
Tokyo 192-8510, Japan
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Latin America:
Agilent Technologies
Latin American Region Headquarters
5200 Blue Lagoon Drive, Suite #950
Miami, Florida 33126, U.S.A.
(tel) (305) 267 4245
(fax) (305) 267 4286
Australia/New Zealand:
Agilent Technologies Australia Pty Ltd
347 Burwood Highway
Forest Hill, Victoria 3131, Australia
(tel) 1-800 629 485 (Australia)
(fax) (61 3) 9272 0749
(tel) 0 800 738 378 (New Zealand)
(fax) (64 4) 802 6881
Asia Pacific:
Agilent Technologies
24/F, Cityplaza One, 1111 King’s Road,
Taikoo Shing, Hong Kong
(tel) (852) 3197 7777
(fax) (852) 2506 9284
Technical data subject to change
Copyright © 1996
Agilent Technologies
Printed in U.S.A. 3/00
5965-3667E
INVISIBLE LASER RADIATION-AVOID
