Agilent 86100B
Wide-Bandwidth
Oscilloscope
Technical Specifications
• Modular platform for testing waveforms up to 40 Gb/s
• Compatible with Agilent 86100A-series, 83480A-series and 54750-series modules
• 200 fs inherent jitter
• Windows
®
98 User Interface
Three instruments in one
A digital communications analyzer,
a full featured wide-bandwidth oscilloscope,
and a time-domain reflectometer.
Table of Contents
2
Overview
Features 3
40 Gb/s 7
Specifications
Mainframe & Triggering
(includes Precision Time Base Module) 8
Computer System & Storage 10
Modules
Overview 11
Module Selection Table 12
Specifications
Multimode/Single-Mode 13
Single-Mode 15
Dual Optical 16
Dual Electrical 17
TDR 18
Clock Recovery 18
Ordering Information 19
3
Windows is a U.S. registered trademark of Microsoft Corporation.
Features
Three Instruments in One
For basic oscilloscope operation there is easy front
panel access with that familiar analog-look and feel. A
Windows®-based system lets you easily navigate through
the user-interface. The 86100B Infiniium DCA can be
viewed as three high-performance instruments in one. It’s
a general-purpose wide-bandwidth sampling oscilloscope.
It’s a digital communications analyzer. It’s a time domain
reflectometer. Just select the instrument mode and start
making measurements.
Configurable to Meet Your Needs
The 86100B supports a wide range of plug-ins for testing
both optical and electrical signals. Select plug-ins to get
the specific bandwidth, filtering, and sensitivity you need.
Digital Communications Analysis
Accurate eye-diagram analysis is essential for characterizing the quality of transmitters used from 100 Mb/s to
40 Gb/s. The 86100B was designed specifically for the
complex task of analyzing digital communications waveforms. Compliance mask and parametric testing no longer
require a complicated sequence of setups and configurations. If you can press a button, you can perform a
complete compliance test. The important measurements
you need are right at your fingertips, including:
• industry standard mask testing with built-in
margin analysis,
• extinction ratio measurements with accuracy and
repeatability, and
• eye measurements: crossing %, eye height and width, ‘1’
and ‘0’ levels, jitter, rise or fall times and more.
The key to accurate measurements of lightwave communications waveforms is the optical receiver. The 86100B
has a broad range of precision receivers integrated
within the instrument.
• Built-in photodiodes, with flat frequency responses,
yield the highest waveform fidelity. This provides high
accuracy for extinction ratio measurements.
• Standards-based transmitter compliance measurements
require filtered responses. The 86100B has a broad
range of filter combinations. Filters can be automatically and repeatably switched in or out of the measurement channel remotely over GPIB or with a front panel
button. The frequency response of the entire measurement path is calibrated, and will maintain its performance over long-term usage.
• The integrated optical receiver provides a calibrated
optical channel. With the accurate optical receiver built
into the module, optical signals are accurately measured
and displayed in optical power units.
Switches or couplers are not required for an average
power measurement. Signal routing is simplified and
signal strength is maintained.
Eye Diagram Mask Testing
The 86100B provides efficient, high-throughput waveform
compliance testing with a suite of standards based eyediagram masks. The test process has been streamlined
into a minimum number of keystrokes for testing at
industry standard data rates.
Standard Masks
Rate (Mb/s)
1X Gigabit Ethernet 1250
2X Gigabit Ethernet 2500
10 Gigabit Ethernet 9953.28
10 Gigabit Ethernet 10312.5
FC 1063 1062.5
FC 2125 2125
10X Fibre Channel 10518.75
STM0/OC1 51.84
STM1/OC3 155.52
STM4/OC12 622.08
STM16/OC48 2488.3
Infiniband 2500
XAUI 3125
STM64/OC192 9953.28
STM64/OC192 FEC 10664.2
STM64/OC192 FEC 10709
STM64/OC192 Super FEC 12500
STM256/OC768 39813
STS1 EYE 51.84
STS3 EYE 155.52
able measurement conditions, such as mask margins for
guardband testing, number of waveforms tested, and
stop/limit actions.
Measurement Speed
Measurement speed has been increased with both fast
hardware and a user-friendly instrument. In the lab, don’t
waste time trying to figure out how to make a measurement. With the simple-to-use 86100B, you don’t have to
relearn how to make a measurement each time you use it.
Agilent 86105A Optical Receiver Section
The integrated optical channel can be used as a fully
calibrated SONET/SDH/Gigabit Ethernet or Fibre Channel
reference receiver or as a wide-bandwidth receiver.
Overview of Infiniium DCA
Other eye-diagram
masks are easily
created through scaling
those listed at left. In
addition, mask editing
allows for new masks
either by editing
existing masks, or
creating new masks
from scratch. A new
mask can also be
created or modified on
an external PC using a
text editor such as
Notepad, then can be
transferred to the
instrument’s hard
drive using LAN or the
A: drive.
Perform these mask
conformance tests with
convenient user-defin-
Optical
Receiver
Average
Power
Monitor
▲
SDH/Sonet
Filter
▲
Sampling/
Amplification
4
In manufacturing, it is a battle to continually reduce the
cost per test. Solution: Fast PC-based processors, resulting
in high measurement throughput and reduced test time.
Measure
Standard Measurements/Features
The following measurements are available from the tool
bar, as well as the pull down menus. Measurements available are dependent on the DCA operating mode.
Oscilloscope Mode
Time
Rise Time, Fall Time, Jitter RMS, Jitter p-p, Period,
Frequency, + Pulse Width, - Pulse Width, Duty Cycle,
Delta Time, [T
max
, T
min
, T
edge
—remote commands only]
Amplitude
Overshoot, Average Power, V amptd, V p-p, V rms,
Vtop, V base, V max, V min, V avg
Eye/Mask Mode
NRZ Eye Measurements
Extinction Ratio, Jitter RMS, Jitter p-p, Average Power,
Crossing Percentage, Rise Time, Fall Time, One Level,
Zero Level, Eye Height, Eye Width, Signal to Noise
(Q-Factor), Duty Cycle Distortion, Bit Rate, Eye
Amplitude
RZ Eye Measurements
Extinction Ratio, Jitter RMS, Jitter p-p, Average Power,
Rise Time, Fall Time, One Level, Zero Level, Eye
Height, Eye Amplitude, Opening Factor, Eye Width,
Pulse Width, Signal to Noise (Q-Factor), Duty Cycle,
Bit Rate, Contrast Ratio
Mask Test
Open Mask, Start Mask Test, Exit Mask Test, Filter,
Mask Test Margins, Mask Test Scaling, Create NRZ Mask
TDR/TDT Mode (requires TDR module)
Quick TDR, TDR/TDT Setup, Normalize, Response,
Rise Time, Fall Time, ∆ Time
Standard Functions
Standard functions are available through pull down
menus and soft keys, and some functions are also accessible through the front panel knobs.
Markers
Two vertical and two horizontal (user selectable)
TDR Markers
Horizontal — seconds or meter
Vertical — volts, ohms or Percent Reflection
Propagation — Dielectric Constant or Velocity
Limit Tests
Acquisition Limits
Limit Test Run Until Conditions — Off, # of Waveforms,
# of Samples
Report Action on Completion — Save waveform to
memory or disk, Save screen image to disk
Measurement Limit Test
Specify Number of Failures to Stop Limit Test
When to Fail Selected Measurement — Inside Limits,
Outside Limits, Always Fail, Never Fail
Report Action on Failure - Save waveform to memory
or disk, Save screen image to disk, Save summary to
disk
Mask Limit Test
Specify Number of Failed Mask Test Samples
Report Action on Failure — Save waveform to memory
or disk, Save screen image to disk, Save summary to
disk
Configure Measurements
Thresholds
10%, 50%, 90% or 20%, 50%, 80% or Custom
Eye Boundaries
1 and 2
Format Units for
Duty Cycle Distortion — Time or Percentage
Extinction Ratio — Ratio, Decibel or Percentage
Eye Height — Amplitude or Decibel (dB)
Eye Width — Time or Ratio
Average Power — Watts or Decibels (dB)
TDR — Ohm (Ω) or Volts
Meters or Seconds
Top Base Definition
Standard or Custom
∆ Time Definition
First Edge Number, Edge Direction, Threshold
Second Edge Number, Edge Direction, Threshold
Quick Measure Configuration
4 User Selectable Measurements for Each Mode
Default Settings
(Eye/Mask Mode)
Extinction Ratio, Jitter RMS, Average Power, Crossing
Percentage
Default Settings
(Oscilloscope Mode)
Rise Time, Fall Time, Period,
V amptd
5
Built-in Information System
The 86100B has a contextsensitive on-line manual providing immediate answers to your
questions about using the instrument. Links on the measurement screen take you directly
to the information you need
including algorithms for all of
the measurements. The on-line
manual includes technical specifications of the mainframe and plug-in
modules. It also provides useful
information such as the mainframe
serial number, module serial numbers,
firmware revision and date, and hard
disk free space. There is no need for
a large paper manual consuming
your shelf space.
File Sharing and Storage
Use the internal 10 GB hard drive or
3.5 inch, 1.44 MB floppy disk drive to
store instrument setups, waveforms,
or screen images. Images can be
stored in formats easily imported
into various programs for documen-
tation and further analysis. LAN
interface is also available for network
file management and printing. The
mainframe also has an integrated
CD-ROM drive for firmware upgrades.
Powerful Display Modes
Use gray scale and color graded trace
displays to gain insight into device
behavior. Waveform densities are
mapped to color or easy-to-interpret
gray shades. These are infinite
persistence modes where shading
differentiates the number of times
data in any individual screen pixel
has been acquired.
Internal Triggering
Through Clock Recovery
Very high-speed oscilloscopes are
not capable of triggering directly on
the signal under test. Typically an
external timing reference is used to
synchronize the oscilloscope to the
test signal. In cases where a trigger
signal is not available, clock recovery
modules are available to derive a
timing reference directly from the
waveform to be measured. The
Agilent 8349XA series of clock
recovery modules cover the three
most popular transmission media
Histograms
Configure
Histogram Scale (1 to 8 divisions)
Histogram Axis (vertical or
horizontal)
Histogram Window (Adjustable
Window via Marker Knobs)
Math Measurements
4 User Definable Functions
Operator — Magnify, Invert,
Subtract, Versus, Min, Max
Source — Channel, Function,
Memory, Constant, Response
(TDR)
Calibrate
All Calibrations
Module (Amplitude)
Horizontal (Time Base)
Extinction Ratio
Probe
Optical Channel
Front Panel Calibration Output Level
User Selectable –2V to 2V
Horizontal Skew Adjustment
Per Channel, User Selectable
Utilities
Set Time and Date
Remote Interface
Set GPIB Interface
Touch Screen
Configuration/Calibration
Calibration
Upgrade Software
Upgrade Mainframe
Upgrade Module
Agilent 8349XA
e
A
e
C
o
e
(
y
)
t
t
a
t
C
l
t
/
a
y
*Depends on clock recovery module
*
Clock Recovery Trigger Modul
Data Ou
Clock Ou
Dat
Inpu
hanne
Inpu
Agilent 861XX or 8348X
Plug-In Modul
Clock
Dat
Recover
Mainfram
routed
lock t
internall
used today—electrical lines, multimode, and single-mode
fiber. A built-in coupler reduces external hardware
requirements. All five modules have excellent jitter
performance to ensure accurate measurements. Each
clock recovery module is designed to synchronize to a
variety of common transmission rates.
Clock Recovery Loop Bandwidth
The Agilent clock recovery modules have two loop
bandwidth settings. Loop bandwidth is very important
in determining the accuracy of your waveform when
measuring jitter, as well as testing for compliance.
•Narrow loop bandwidth provides a clean system clock
for accurate jitter measurements
• Wide loop bandwidth in some applications is specified
in the standards for compliance testing. It allows the
recovered clock to track the data and is useful for
extracting a signal that may have propagated through a
complex network and have large amounts of jitter. While
this obviously negates any ability to quantify the jitter,
it does allow other parameters of an eye to be measured.
Note: When using recovered clocks for triggering, jitter
measurement accuracy is suspect unless the scheme has
a very narrow loop bandwidth.
Improved Autoscaling
Autoscaling has been significantly improved to provide
quick horizontal and vertical scaling of both pulse and
eye-diagram (RZ and NRZ) waveforms.
Time Domain Reflectometer (TDR)
TDR measurements are focused on high-speed applications where it is necessary to optimize electrical system
components, such as microstrip lines, PC board traces,
SMA edge launchers and coaxial cables where imperfections cause signal distortion and reflections. Signal
integrity is a critical requirement in high-speed digital
signal transmission.
Gated Triggering
Trigger gating port allows easy external control of data
acquisition for circulating loop or burst-data experiments. Use TTL-compatible signals to control when the
instrument does and does not acquire data.
Easier Calibrations
Calibrating your instrument has been simplified by
placing all the performance level indicators and calibration procedures in a single high-level location. This
provides greater confidence in the measurements made
and saves time in maintaining equipment.
Stimulus Response Testing
Using the Agilent N4906A Serial BERT
Error performance analysis represents an essential part
of digital transmission test. The Agilent 86100B and
N4906A SmartBERT have similar user interfaces and
together create a powerful test solution.
Transitioning from the Agilent 83480A and
86100A to the 86100B
The 86100B has been designed to be a virtual drop-in
replacement for the Agilent 86100A and Agilent 83480A
digital communications analyzers and Agilent 54750A
wide-bandwidth oscilloscope. All modules used in the
Agilent 83480A and 54750A can also be used in the
86100B. The remote programming command set for the
86100B has been designed for direct compatibility with
software written to control the 86100A, 83480A and
54750A.
6
When developing 40 Gb/s devices,
even a small amount of inherent
scope jitter can become significant
since 40 Gb/s waveforms only have a
bit period of 25 ps. Scope jitter of
1ps RMS can result in 6 to 9 ps of
peak-to-peak jitter, causing eye
closure even if your signal is jitterfree. The Agilent 86100A and B have
been improved specifically for 40
Gb/s waveform analysis.
7
Accurate views of your
40 Gb/s waveforms
1
Unique methods and algorithm used in the precision
timebase module will be discussed upon receipt of U.S.
patent protection.
The same 40 GHz sinewave
captured using current DCA (top)
and now with 86107A precision
timebase module (bottom).
The new 86107A precision timebase
reference module represents one of
the most significant improvements in
wide-bandwidth sampling oscilloscopes in over a decade.
1
Jitter
performance has been reduced by
almost an order of magnitude to 200
fs RMS. Oscilloscope jitter is virtually eliminated! The reduced jitter of
the 86107A precision timebase
module allows you to measure the
true jitter of your signal. The 86107A
requires a 10, 20 or 40 GHz electrical
reference clock that is synchronous
with the signal under test. Timebase
resolution has also been improved
from 10 ps/division to 2 fs/division,
a 5 times improvement.
Meeting your growing need
for more bandwidth
Today’s communication signals have
significant frequency content well
beyond an oscilloscope’s 3-dB bandwidth. A high-bandwidth scope does
not alone guarantee an accurate
representation of your waveform.
Careful design of the scope’s
frequency response (both amplitude
and phase) minimizes distortion
such as overshoot and ringing.
The Agilent 86116A, 86116B and
86109B are plug-in modules that
include an integrated optical
receiver designed to provide the
optimum in bandwidth, sensitivity,
and waveform fidelity. The 86116B
extends the bandwidth of the
86100B Infiniium DCA to 80 GHz
electrical, 65 GHz optical in the
1550nm wavelength band. The
86116A covers the 1300nm and
1550nm wavelength bands with 63
GHz of electrical bandwidth and 53
GHz of optical bandwidth. The
86109B is an economical solution
with 50 GHz electrical and 40 GHz
optical bandwidth. You can build the
premier solution for 40 Gb/s waveform analysis around the 86100
mainframe that you already own.
Performing return-to-zero
(RZ) waveform measurements
An extensive set of automatic RZ
measurements are built-in for the
complete characterization of returnto-zero (RZ) signals at the push of
a button.
Specifications
Mainframe Specifications
HORIZONTAL SYSTEM (Time Base)
Scale Factor (Full scale is ten divisions.)
Minimum 2 ps/div (with 86107A: 500 fs/div)
Maximum 1 s/div
Delay
1
Minimum ≥24 ns (Standard), 28 ns (Option 001)
Maximum 1000 screen diameters or 10 s, whichever is smaller
Time Interval Accuracy ≤8 ps + 0.1% of reading (dual marker measurement performed at a temperature within
±5°C of horizontal calibration temperature)
8 ps + 0.1% + 0.5 ps/°C to (5 < absolute temperature value <15°C)
Time Interval Resolution ≤ (screen diameter)/(record length) or 62.5 fs, whichever is larger
Display Units Bits or time (TDR mode–meters)
VERTICAL SYSTEM (Channels)
Number of Channels 4 (simultaneous acquisition)
Vertical Resolution 12 bit A/D converter (up to 15 bits with averaging)
Full Resolution Channel Scales Adjusts in a 1-2-5-10 sequence for coarse adjustment or fine adjustment resolution
from the front panel knob
Adjustments Scale, offset, activate filter, sampler bandwidth, attenuation factor, transducer conversion factors
Typical Acquisition Rate 40 kHz per Channel
Record Length Manual setting between 450 and 4050 samples (increments of 1, 1350 default sample setting)
or using up arrow/down arrow keys, increments of 450 samples: 450, 900, 1350 (default) etc.
up to 4050 samples
8
Specifications describe warranted performance over the temperature range of +10°C to + 40°C (unless otherwise noted). The specifications are
applicable for the temperature after the instrument is turned on for one (1) hour, and while self-calibration is valid. Many performance parameters are
enhanced through frequent, simple user calibrations. Characteristics provide useful, non-warranted information about the functions and
performance of the instrument. Characteristics are printed in italic typeface.
Factory Calibration Cycle -For optimum performance, the instrument should have a complete verification of specifications once every twelve (12) months.
General Specifications
This instrument meets Agilent Technologies’ environmental specifications (section 750) for class B-1 products with exception as described for
temperature and condensation. Contact your local field engineer for complete details.
Temperature
Operating 10°C to +40°C (50°F to + 104°F)
Non-operating –40°C to +70°C (–40°F to +158°F)
Humidity
Operating Up to 90% humidity (non-condensing) at +40°C (+104°F)
Non-operating Up to 95% relative humidity at +65°C (+149°F)
Altitude
Operating Up to 4,600 meters (15,000 ft)
Non-operating Up to 15,300 meters (50,000 ft)
Vibration
Operating Random vibration 5–500 Hz, 10 minutes per axis, 2.41 g (rms)
Non-operating Random vibration 5–500 Hz, 10 minutes per axis, 0.3 g (rms); Resonant search, 5–500 Hz
swept sine, 1 octave/min sweep rate, 0.75 g, 5 minute resonant dwell at 4 resonances/raxis
Power Requirements
Voltage 90–132 or 198–264 Vac, 48–66 Hz
Power (including modules) 604 VA; 391 W
Weight
Mainframe without modules 15.5 kg (34 lb)
Each Module 1.2 kg (2.6 lb)
Mainframe Dimensions (excluding handle)
Without front connectors and rear feet 215.1 mm H x 425.5 mm W x 566 mm D (8.47 in x 16.75 in x 22.2 in)
With front connectors and rear feet 215.1 mm H x 425.5 mm W x 629 mm D (8.47 in x 16.75 in x 24.8 in)
1
Time offset relative to the front panel trigger output on the instrument mainframe.
9
Mainframe Specifications (continued)
Standard (Direct Trigger) Option 001 (Divided Trigger)
Trigger Modes
Internal Trigger
1
Freerun
External Direct Trigger
2
Limited Bandwidth
3
DC to 100 MHz
Full Bandwidth DC to 2.75 GHz
External Divided Trigger 2 to 12 GHz (1 to 15 GHz)
Jitter
Characteristic <1.0 ps RMS + 5*10E-5 of delay setting
4
1.2 ps RMS for time delays less than 100 ns
Maximum 1.5 ps RMS + 5*10E-5 of delay setting
4
1.7 ps RMS for time delays less than 100 ns
Trigger Sensitivity 200 m Vpp (sinusoidal input or 200 m Vpp sinusoidal input from 2 to 12 GHz
200 ps minimum pulse width)
Trigger Configuration
Trigger Level Adjustment –1 V to + 1 V AC coupled
Edge Select Positive or negative
Hysteresis
5
Normal or high sensitivity
Trigger Gating
Gating Input Levels Disable: 0 to 0.6 V
(TTL compatible) Enable: 3.5 to 5 V
Pulse width >500 ns, period >1 µs
Gating Delay Disable: 627 ns + trigger period +
Max time displayed
Enable: 100 ns
Trigger Impedance
Nominal Impedance 50Ω
Reflection 10% for 100 ps rise time
Connector Type 3.5 mm (male)
Maximum Trigger Signal ±2 V + 2 Vac peak (+16 dBm)
Precision Time Base 86107A
86107A option 010 86107A option 020 86107A option 040
Trigger Bandwidth 2.4 – 4.0 GHz 9.0 – 12.6 GHz 9.0 – 12.6 GHz
9.0 – 12.6 GHz 18.0 – 25.0 GHz 18.0 – 25.0 GHz
39.0 – 43.0 GHz
Typical Jitter (RMS) 2.4 – 4.0 GHz trigger: <280 fs <200 fs 9 – 12.6 GHz, 18 – 25 GHz
trigger bands: <250 fs
9 – 12.6 GHz trigger: <200 fs 38 – 45 GHz trigger: <200 fs
Time Base Linearity Error < 100 fs
Input Signal Type Synchronous clock, no constraint on waveform shape.
Input Signal Level 0.5 – 1.0 Vpp
1
0.2 – 1.5 Vpp (Typical functional performance)
DC Offset Range ±200 mV
Required Trigger Signal-to-Noise Ratio ≥ 200 : 1
Trigger Gating Disable: 0 to 0.6 V
Gating Input Levels (TTL compatible) Enable: 3.5 to 5 V
Pulse width >500 ns, period >1 µs
Trigger Impedance 50 Ω
Connector Type 3.5 mm (male) 3.5 mm (male)
2.4 mm (male)
1
To achieve characteristic performance:
Requires 86100A or B with 86100A software revision 3.0 or above.
For the 86107A with option 020, the Agilent 11742A (DC Block) is recommended if the DC offset magnitude is greater than 200 mV.
1
The freerun trigger mode internally generates an asynchronous trigger that allows viewing the sampled signal amplitude without an external trigger signal but provides no timing information. Freerun is useful in
troubleshooting external trigger problems.
2
The sampled input signal timing is recreated by using an externally supplied trigger signal that is synchronous with the sampled signal input.
3
The DC to 100 MHz mode is used to minimize the effect of high frequency signals or noise on a low frequency trigger signal.
4
Measured at 2.5 GHz with the triggering level adjusted for optimum trigger.
5
High Sensitivity Hysteresis Mode improves the high frequency trigger sensitivity but is not recommended when using noisy, low frequency signals that may result in false triggers without normal hysteresis enabled.
Computer System and Storage
CPU 866 MHz Microprocessor
Disk Drives 10 GByte internal hard drive and 3.5" MS-DOS
®
compatible 1.44 MB floppy disk drive. Store and
recall setups, waveforms, and screen images to both the hard drive and the floppy drive.
Storage capacity is limited only by disk space. CD-ROM drive.
File Types/Management (Internal
1
) Setup files .SET
Waveform files .WFM
Color grade gray scale files .CGS
Mask files .MSK
TDR/TDT normalization files .TDR
Upgrade header files .HDR
Waveforms Internal, verbose,Y values (Verbose and Y values are .TXT)
Images bmp, eps , gif, pcx, ps, jpeg, tif
Operating System Microsoft Windows 98
Waveform Store 1 color grade-grayscale memory
4 nonvolatile waveform memories
Waveform memory setup (for each channel) (vertical scale, offset, horizontal scale, position)
Printer Configure Printer
Options
Waveform only
Include instrument setup info
Monochrome
Invert waveform background color
Add printer
DISPLAY
Display Area 170.9 mm x 128.2 mm (8.4 inch diagonal color active matrix LCD module incorporating amorphous
silicon TFTs)
Active Display Area 171mm x 128 mm (21,888 square mm) 6.73 in x 5.04 in (33.92 square inches)
Waveform Viewing Area 103 mm x 159 mm (4.06 in x 6.25 in)
Entire Display Resolution 640 pixels horizontally x 480 pixels vertically
Graticule Display Resolution 451 pixels horizontally x 256 pixels vertically
Waveform Colors Select from 100 hues, 0–100% saturation and 0–100% luminosity
Persistence Modes Gray scale, color grade, variable, infinite
Waveform Overlap When two waveforms overlap, a third color distinguishes the overlap area
Connect-the-dots On/Off selectable
Persistence Minimum, Variable (100 ms to 40 s), Infinite
Graticule On/Off
Grid Intensity 0 to 100%
Backlight Saver 2 to 8 hrs, enable option
Dialog Boxes Opaque or transparent
FRONT AND REAR PANEL
INPUTS AND OUTPUTS
Cal BNC (female) and test clip, banana plug
Trigger APC 3.5 mm, 50Ω, ±2 V maximum
GPIB Fully programmable, complies with IEEE 488.2
RS-232 Serial Printer, 9 pin D-sub (male)
Centronics Parallel Printer port, 25 pin D-sub (female)
+15 V Bias 100 ma, 15 V, SMB
Mouse PS/2
Gated Trigger Input TTL compatible
Keyboard IBM 5 pin (female) (for optional keyboard)
LAN A keyboard must be used to setup LAN connection
Video Output VGA, full color, 15 pin D-sub (female)
10
1. These files are internal files and can only be used in the 86100A/B mainframes.
MS-DOS is a U.S. registered trademark of Microsoft Corporation.
11
Optical/Electrical Modules
750-860 nm
The 86101A, 86102A and 86102U modules support waveform compliance testing of short wavelength signals with
up to 15 GHz of optical bandwidth. Each module also has
an electrical channel with 20 GHz of bandwidth.
1000–1600 nm
<20 GHz Optical and Electrical Channels:
The 86103A, 86103B, 86105A and 86105B modules are
optimized for testing long wavelength signals with up to
20 GHz of optical bandwidth. Each module also has an
electrical channel with 20 GHz of bandwidth.
20 – 40 GHz Optical and Electrical Channels:
The 86106B and 86109A are optimized for testing
10 Gb/s signals. The 86106B has 28 GHz of optical bandwidth with multiple 10Gb/s compliance filters. The
86109A has 30 GHz of optical bandwidth. Each of these
module also has an electrical channel with 40 GHz of
bandwidth.
40 GHz and Greater Optical and Electrical Channels:
The 86109B and 86116A are optimized for testing 40 Gb/s
signals. The 86109B has an optical channel with 40 GHz
of bandwidth and an electrical channel with 50 GHz of
bandwidth. The 86116A has more than 50 GHz of optical
bandwidth and 60 GHz of electrical bandwidth. The
86116B is the widest bandwidth optical module with
more than 65 GHz optical (1550nm band only) and 80 GHz
electrical bandwidth.
Dual Optical Channel Modules
86111A and 86111U are short wavelength optical
modules that have up to 15 GHz of bandwidth optimized
for testing signals from 155 Mb/s to 3125 Mb/s.
86113A is a long wavelength module with 2.85 GHz of
optical bandwidth optimized for testing of signals up to
2.488 Gb/s.
86115B is a long wavelength module that has 28 GHz of
optical bandwidth. This module is designed for testing
10 Gb/s signals.
Dual Electrical Modules
86112A has two low-noise electrical channels with
20 GHz of bandwidth.
86117A has two electrical channels with up to 50 GHz of
bandwidth ideal for testing signals up 10 Gb/s.
86117B has two electrical channels with up to 65 GHz of
bandwidth ideal for testing signals up to 40 Gb/s.
86118A has two electrical channels, each housed in a
compact remote sampling head, attached to the module
with separate light weight cables. With over 70 GHz of
bandwidth, this module is intended for 40 Gb/s and
above measurements.
Clock Recovery Modules
This range of clock recovery modules is designed to
provide a trigger signal for the Infiniium DCA when no
clock is present. In each case, the input signal can be fed
to the module input; the module taps off a portion of the
signal, and supplies the remainder to an output connector
on the front panel, so that the signal can be patched
across to the input of an adjacent sampling module. Each
also has recovered clock outputs on the front panel to
supply other test equipment if desired.
The 83491A is an electrical module. It works for rates up
to 2.5 Gb/s.
The 83492A works for optical signals and has multimode
inputs, one working over the 750 – 860 nm range, the
other 1000 – 1600 nm.
The 83493A and 83494A work with single-mode input,
1000 – 1600 nm. The 83493A works for various rates up
to 2.5 Gb/s. The 83494A works for various rates up
to 10 Gb/s.
The 83495A works for optical and electrical signals and
has either multimode (750 – 860 nm) or single mode
(1000 – 1600 nm) inputs. It operates over a continuous
range of rates from 9.95 Gb/s – 11.3 Gb/s.
Time Domain Reflectometry (TDR)
The Infiniium DCA may also be used as a powerful, high
accuracy TDR, using the 54754A differential TDR module.
Module Overview
12
86100B Family Plug-In Module Matrix
86101A 201 1 1 750-860 2.85 20 62.5 -17 ■■
202 1 1 750-860 2.85 20 62.5 -17 ■■
86102A 201 1 1 750-860 10 20 62.5 -13.5 ■■
202 1 1 750-860 10 20 62.5 -13.5 ■■
203 1 1 750-860 10 20 62.5 -13.5 ■■
86102U 201 1 1 750-860 15 20 62.5 -7.5 ■■
202 1 1 750-860 15 20 62.5 -7.5 ■■
203 1 1 750-860 15 20 62.5 -7.5 ■■
86103A 201 1 1 1000-1600 2.85 20 62.5 -20 ■■
202 1 1 1000-1600 2.85 20 62.5 -20 ■■
86103B 201 1 1 1000-1600 10 20 62.5 -15 ■■
202 1 1 1000-1600 10 20 62.5 -15 ■■
203 1 1 1000-1600 10 20 62.5 -15 ■■
86105B 101 1 1 1000-1600 15 20 9 -12 ■■■■■
102 1 1 1000-1600 15 20 9 -12 ■■ ■■ ■■■■■
103 1 1 1000-1600 15 20 9 -12 ■■■■ ■■■■■
86106B 1 1 1000-1600 28 40 9 -7 ■
410 1 1 1000-1600 28 40 9 -7 ■■ ■■
86109A 1 1 1000-1600 30 40 9 N/A
86109B 1 1 1000-1600 40 50 9 N/A
86116A 1 1 1000-1600 53 63 9 N/A
86116B 1 1 1480-1620 65 80 9 N/A
86111A 201 2 0 750-860 2.85 N/A 62.5 -17 ■■
202 2 0 750-860 2.85 N/A 62.5 -17 ■■
86111U 201 2 0 750-860 15 N/A 62.5 -7.5 ■■
202 2 0 750-860 15 N/A 62.5 -7.5 ■■
86113A 201 2 0 1000-1600 2.85 N/A 62.5 -20 ■■
202 2 0 1000-1600 2.85 N/A 62.5 -20 ■■
301 2 0 1000-1600 2.5 N/A 62.5 -20 ■■ ■
86115B 101 2 0 1000-1600 28 N/A 9 -7 ■
410 2 0 1000-1600 28 N/A 9 -7 ■■■■■
54754A 0 2 N/A 18
86112A 0 2 N/A 20
86118A 0 2 N/A 70
86117A 0 2 N/A 50
86117B 0 2 N/A 65
Module
Option
No. of optical channels
No. of electrical channels
Wavelength range (nm)
Unfiltered optical bandwidth (GHz)
Electrical bandwidth (GHz)
Fiber input (µm)
Mask test sensitivity (dBm)
155 Mb/s
622 Mb/s
1063 Mb/s
1250 Mb/s
2125 Mb/s
2488/2500 Mb/s
2.666 Gb/s
2.72 Gb/s
3.125 Gb/s
3.1875 Gb/s
3.32 Gb/s
9.953 Gb/s
10.3125 Gb/s
10.51875 Gb/s
10.664 Gb/s
10.709 Gb/s
Filtered data rates
The 86100B has a large family of plug-in modules designed for a broad
range of data rates for optical and electrical waveforms. The 86100B can
hold up to 2 modules for a total of 4 measurement channels.
Optical/
Electrical
Dual
Optical
Dual
Electrical
13
Multimode and Single-Mode 86101A 86102A 86102U
OPTICAL CHANNEL SPECIFICATIONS
Optical Channel Unfiltered Bandwidth 2.85 GHz (3 GHz typical) 10 GHz 15 GHz
Wavelength Range 750–860 nm
Calibrated Wavelengths 850 nm
Optical Sensitivity
1
–17 dBm –13.5 dBm –7.5 dBm
Transition Time (10% to 90% calculated from TR = 0.48/BW optical)
Unfiltered 160 ps 48 ps 32 ps
RMS Noise
Characteristic 1.5 µW 3.4 µW 14 µW
Maximum 2.5 µW 5.5 µW 20 µW
Scale Factor (per division)
Minimum 5 µW 20 µW
Maximum 100 µW 500 µW
CW Accuracy (single marker, referenced to ±6 µW ±0.4% of full scale ±25 µW ±2% of (reading-channel
average power monitor, <50 µW/division) ±3% of (reading-channel offset) offset), 15 GHz
CW Offset Range (referenced two divisions
from screen bottom) +0.2 mW to –0.6 mW +1 mW to –3 mW
Average Power Monitor
(specified operating range) –30 dBm to –2.2 dBm –30 dBm to –2.2 dBm –27 dBm to +3 dBm
Factory Calibrated Accuracy ±5% ±100 nW ±connector uncertainty, 20°C to 30°C
User Calibrated Accuracy ±2% ±100 nW ±power meter uncertainty, <5°C change
Maximum Input Power
Maximum non-destruct average 0.4 mW (–4 dBm) 0.8 mW (–1 dBm) 2 mW (+3 dBm)
Maximum non-destruct peak 10 mW (+10 dBm)
Fiber Input 62.5/125 µm, user selectable connector
Input Return Loss
(HMS-10 connector fully filled fiber) 20 dB
ELECTRICAL CHANNEL SPECIFICATIONS
Electrical Channel Bandwidth 12.4 and 20 GHz
Transition Time 28.2 ps (12.4 GHz)
(10% to 90%, calculated from TR = 0.35/BW) 17.5 ps (20 GHz)
RMS Noise 0.25 mV (12.4 GHz)
Characteristic 0.5 mV (20 GHz)
Maximum 0.5 mv (12.4 GHz)
1 mV (20 GHZ)
Scale Factor
Minimum 1 mV/division
Maximum 100 mV/division
DC Accuracy (single marker) ±0.4% of full scale ±2 mV ±1.5% of (reading-channel offset), 12.4 GHz
±0.4% of full scale ±2 mV ±3% of (reading-channel offset), 20 GHz
DC Offset Range (referenced to center of screen) ±500 mV
Input Dynamic Range (relative to channel offset) ±400 mV
Maximum Input Signal ±2 V (+16 dBm)
Nominal Impedance 50 ohm
Reflections (for 30ps rise time) 5%
Electrical Input 3.5 mm (male)
Module Specifications: Single-Mode
& Multimode Optical/Electrical
1
Smallest average optical power required for mask test. Values represent typical sensitivity
of NRZ eye diagrams. Assumes mask test with complicance filter switched in.
14
Multimode and Single-Mode
Optical/Electrical Modules 86103A 86103B 86105B
OPTICAL CHANNEL SPECIFICATIONS
Optical Channel Unfiltered Bandwidth 2.85 GHz 10 GHz 15 GHz
Wavelength Range 1000–1600 nm
Calibrated Wavelengths 1310 nm/1550 nm
Optical Sensitivity
1
–20 dBm –15 dBm –12 dBm
Transition Time (10% to 90%
calculated from TR = 0.48/BW optical) 160 ps 48 ps 32 ps
RMS Noise
Characteristic 0.75 µW Opt 201 2 µW 5 µ, (10 GHz)
1.0 µW Opt 202 12 µW, (15 GHz)
Maximum 1.5 µW Opt 201 3.7 µW 8 µW, (10 GHz)
2.5 µW Opt 202 15 µW (15 GHz)
Scale Factor (per division)
Minimum 5 µW 20 µW
Maximum 100 µW 500 µW
CW Accuracy (single marker, ±6 µW ±0.4% of full scale
±25 µW ±2% of (reading-channel offset),10 GHz
referenced to average power monitor) ±3% of (reading-channel offset)
±25 µW ±4% of
(reading-channel offset),
15 GHz
CW Offset Range (referenced two divisions
from screen bottom) +0.2 mW to –0.6 mW +1 mW to –3 mW
Average Power Monitor
(specified operating range) –30 dBm to 0 dBm –30 dBm to +3 dBm
Factory Calibrated Accuracy
Single mode
±5% ±100 nW ±connector uncertainty
(20°C to 30°C)
Multi mode
±10% ±100 nW ±connector uncertainty
(20°C to 30°C)
N/A
User Calibrated Accuracy ±2% ±100 nW ±power meter uncertainty, <5°C change
Maximum Input Power
Maximum non-destruct average 0.4 mW (–4 dBm) 0.8 mW (–1 dBm) 2 mW (+3 dBm)
Maximum non-destruct peak 10 mW (+10 dBm)
Fiber Input 62.5/125 µm, user selectable connector 9/125 µm user selectable connector
Input Return Loss
(HMS-10 connector fully filled fiber) 20 dB 33 dB
ELECTRICAL CHANNEL SPECIFICATIONS
Electrical Channel Bandwidth 12.4 and 20 GHz
Transition Time 28.2 ps (12.4 GHz)
(10% to 90%, calculated from TR = 0.35/BW) 17.5 ps (20 GHz)
RMS Noise
Characteristic 0.25 mV (12.4 GHz)
0.5 mV (20 GHz)
Maximum 0.5 mv (12.4 GHz)
1 mV (20 GHz)
Scale Factor
Minimum 1 mV/division
Maximum 100 mV/division
DC Accuracy (single marker) ±0.4% of full scale ±2 mV ±1.5% of (reading-channel offset), 12.4 GHz
±0.4% of full scale ±2 mV ±3% of (reading-channel offset), 20 GHz
DC Offset Range (referenced to
center of screen) ±500 mV
Input Dynamic Range
(relative to channel offset) ±400 mV
Maximum Input Signal ±2 V (+16 dBm)
Nominal Impedance 50 ohm
Reflections (for 30ps rise time) 5%
Electrical Input 3.5 mm (male)
Module Specifications: Single-Mode
& Multimode Optical/Electrical
(continued)
1
Smallest average optical power required for mask test. Values represent typical sensitivity
of NRZ eye diagrams. Assumes mask test with complicance filter switched in.
15
High Bandwidth, Single-Mode
Optical/Electrical Modules 86106B 86109A 86109B 86116A
1
86116B
1
OPTICAL CHANNEL SPECIFICATIONS
Optical Channel Unfiltered Bandwidth 28 GHz 30 GHz 40 GHz
2
53 GHz 65 GHz (best pulse fidelity)
Wavelength Range 1000–1600 nm 55 GHz (best sensitivity)
Calibrated Wavelengths 1310/1550 nm 1480-1620 nm
Optical Sensitivity
4
–7 dBm N/A
Transition Time (10% to 90%,
calculated from TR = 0.48/BW optical) 18 ps 16 ps 12 ps (FWHM)
3
9.0 ps (FWHM)
3
7.4 ps (FWHM)
RMS Noise
Characteristic 13 µW (Filtered) 12 µW 25 µW (30 GHz) 60 µW (50 GHz) 140 µW (65 GHz)
23 µW (Unfiltered) 65 µW (40 GHz) 190 µW (53 GHz) 50 µW (55 GHz)
Maximum 15 µW (Filtered) 30 µW 30 µW (30 GHz) 90 µW (50 GHz) 250 µW (65 GHz)
30 µW (Unfiltered) 75 µW (40 GHz) 260 c(53 GHz) 85 µW (55 GHz)
Scale Factor
Minimum 20 µW/division 200 µW/division
Maximum 500 µW/division 1.0 mW/division 2.5 mW/division 5 mW/division
CW Accuracy (single marker, ±50 µW ±4% of
referenced to average power monitor) (reading-channel offset) ±150 µW ±4% of (reading-channel offset)
CW Offset Range (referenced two
divisions from screen bottom) +1 mW to –3 mW +6 mW to –2 mW +5 mW to –15mW +8 to –12 mW
Average Power Monitor
(specified operating range) –27 dBm to +3 dBm –23 dBm to + 9 dBm
Factory Calibrated Accuracy ±5% ±100 nW ±connector uncertainty, 20°C to 30°C
User Calibrated Accuracy ±2% ±100 nW ±power meter uncertainty, <5°C change
Maximum Input Power
Maximum non-destruct average 2 mW (+3 dBm) 10 mW (+10 dBm)
Maximum non-destruct peak 10 mW (+10 dBm) 50 mW (+17 dBm)
Fiber Input 9/125 µm, user selectable connector
Input Return Loss
(HMS-10 connector fully filled fiber) 30 dB 20 dB
1
86116A requires the 86100A/B software revision A.3.0 or above.
2
Specified with 8 point moving average in frequency response.
3
FWHM (Full Width Half Max) as measured from optical pulse with 700 fs FWHM, 5 MHz repetition rate and 10 mW peak power.
4
Smallest average optical power required for mask test. Valves represent typical sensitivity of NRZ eye diagrams. Assumes mask test with compliance filter switched in.
ELECTRICAL CHANNEL SPECIFICATIONS
Electrical Channel Bandwidth 18 and 40 GHz 26 and 50 GHz 43 and 63 GHz 80, 55 and 30 GHz
Transition Time (10% to 90%, 19.5 ps (18 GHz) <13.2 ps (26 GHz) 8.1 ps (43 GHz) 6.4 ps (55 GHz)
calculated from TR = 0.35/BW) 9 ps (40 GHz) 7 ps (50 GHz) 5.6 ps (63 GHz) 4.4 ps (80 GHz)
RMS Noise
Characteristic 0.25 mV (18 GHz) 0.25 mV (26 GHz) 0.6 mV (43 GHz) 0.6 mV (55 GHz)
0.5 mV (40 GHz) 0.60 mV (50 GHz) 1.7 mV (63 GHz) 1.1 mV (80 GHz)
Maximum 0.5m V (18 GHz) 0.50 mV (26 GHz) 0.9 mV (43 GHz) 1.1 mV (55 GHz)
1.0 mV (40 GHz) 1.0 mV (50 GHz) 2.5 mV (63 GHz) 2.2 mV (80 GHz)
Scale Factor
Minimum 1 mV/division 2 mV/division
Maximum 100 mV/division 100 mV/division
DC Accuracy (single marker) ±0.4% of full scale ±0.4% of full scale ±0.8% of full scale ±0.4% of full scale
±2 mV ±1.5% of (reading- ±2 mV ±1.5% of (reading- ±2 mV ±1.5% of (reading- ±3 mV ±2% of (reading-
channel offset), 18 GHz channel offset), 26 GHz channel offset), 43 GHz channel offset), ±2% of
±0.4% of full scale ±0.4% of full scale ±2.5% of full scale offset (all bandwidths)
±2 mV ±3% of (reading- ±2 mV ±2% of (reading- ±2 mV ±2% of (reading-
channel offset), 40 GHz channel offset), 50 GHz channel offset), 63 GHz
DC Offset Range (referenced
to center of screen) ±500 mV
Input Dynamic Range
(relative to channel offset) ±400 mV
Maximum Input Signal ±2 V (+16 dBm)
Nominal Impedance 50 ohm
Reflections (for 20 ps rise time) 5% 10% (DC–70 GHz)
20% (70–100 GHz)
Electrical Input 2.4 mm (male) 1.85 mm (male)
Module Specifications: Single-Mode Optical/Electrical
16
Dual Mode Optical Modules
1
86111A 86111U 86113A 86115B
OPTICAL CHANNEL SPECIFICATIONS
Optical Channel Unfiltered Bandwidth 2.85 GHz 15 GHz 2.85 GHz 28 GHz
Wavelength Range 750-860 nm 1000–1600 nm
Calibrated Wavelengths 850 nm 1310/1550 nm
Optical Sensitivity
1
–17 dBm –7.5 dBm –20 dBm –7 dBm
Transition Time (10% to 90%,calculated from TR = 0.48/BW optical)
Unfiltered 160 ps 32ps 160 ps 18 ps
RMS Noise
Characteristic 1.5 µW 14µW 1.0 µW 13 µW (Filtered)
23 µW (Unfiltered)
Maximum 2.5 µW 20 µW 2.5 µW 15 µW (Filtered)
30 µW (Unfiltered)
Scale Factor
Minimum 5 µW 20 µW 5 µW 20 µW
Maximum 100 µW 500 µW 100 µW 500 µW
CW Accuracy (single marker, referenced ±6 µW ±0.4% of 25 µW ±2% of ±6 µW ±0.4% of ±50 µW ±4% of
to average power monitor) full scale ±3% of (reading-channel offset), full scale ±3% of (reading-channel
(reading-channel offset) 15 GHz (reading-channel offset) offset)
CW Offset Range (referenced two
divisions from screen bottom) +0.2 mW to –0.6 mW +1 mW to –3 mW +0.2 mW to –0.6 mW +1 mW to –3 mW
Average Power Monitor
(specified operating range) –30 dBm to –2.2 dBm –27 dBm to +3 dBm –30 dBm to 0 dBm –27 dBm to +3 dBm
Factory Calibrated Accuracy
Single mode ±5% ±100 nW ±connector uncertainty, (20°C to 30°C)
Multi mode
±10% ±100 nW ±connector uncertainty,
(20°C to 30°C) N/A
User Calibrated Accuracy ±2% ±100 nW ±power meter uncertainty, <5°C change
Maximum Input Power
Maximum non-destruct average 0.4 mW (–4 dBm) 2 mW (+3 dBm) 0.4 mW (–4 dBm) 2 mW (+3 dBm)
Maximum non-destruct peak 10 mW (+10 dBm)
Fiber Input 62.5/125 µm, 9/125 µm, user
user selectable connector selectable connector
Input Return Loss
(HMS-10 connector fully filled fiber) 20dB 30 dB
1
Requires the 86100A/B software revision 3.0 or above.
Module Specifications: Dual Optical
17
Dual Electrical Channel Modules 86112A 54754A
Electrical Channel Bandwidth 12.4 and 20 GHz 12.4 and 18 GHz
Transition Time (10% to 90%, 28.2 ps (12.4 GHz); 28.2 ps (12.4 GHz);
calculated from TR = 0.35/BW) 17.5 ps (20 GHz) 19.4 ps (18 GHz)
RMS Noise
Characteristic 0.25 mV (12.4 GHz); 0.25 mV (12.4 GHz);
0.5 mV (20 GHz) 0.5 mV (18 GHz)
Maximum 0.5 mv (12.4 GHz); 0.5 mv (12.4 GHz);
1 mV (20 GHz) 1 mV (18 GHz)
Scale Factor
Minimum 1 mV/division
Maximum 100 mV/division
DC Accuracy (single marker) ±0.4% of full scale ±0.4% of full scale or marker reading
±2mV ±1.5% of (reading-channel offset), 12.4 GHz (whichever is greater)
±0.4% of full scale ±2 mV ±1.2% of (reading-channel offset)
±2 mV ±3% of (reading-channel offset), 20 GHz
CW Offset Range (referenced from
center of screen) ±500 mV ±500 mV
Input Dynamic Range (relative to
channel offset) ±400 mV ±400 mV
Maximum Input Signal ±2 V (+16 dBm) ±2 V (+16 dBm)
Nominal Impedance 50 ohm 50 ohm
Reflections (for 30 ps rise time) 5% 5%
Electrical Input 3.5 mm (male) 3.5 mm (male)
Module Specifications: Dual Electrical
Dual Electrical Channel Modules 86117A 86117B 86118A
Electrical Channel Bandwidth 30 and 50 GHz 30, 50 amd 65 GHz 50 and 70 GHz
Transition Time (10% to 90%, 11.7 ps (30 GHz) 11.7 ps (30 GHz)
calculated from TR = 0.35/BW) 7 ps (50 GHz) 7 ps (50 GHz)
5.4 ps (65 GHz)
RMS Noise
Characteristic 0.4 mV (30 GHz) 0.4 mV (30 GHz) 0.7 mV (50 GHz)
0.6 mV (50 GHz) 0.5 mV (50 GHz) 1.3 mV (70 GHz)
1.3 mV (65 GHz)
Maximum 0.7 mv (30 GHz); 0.7 mv (30 GHz) 1.8 mV (50 GHz)
1.0 mV (50 GHz 0.9 mV (50 GHz) 2.5 mV (70 GHz)
2.2 mV (65 GHz)
Scale Factor
Minimum 1 mV/division
Maximum 100 mV/division
DC Accuracy (single marker) ±0.4% of full scale ±0.4% of full scale ±0.4% of full scale
±2 mV ±1.2% of (reading- ±2 mV ±1.2% of (reading- ±1.5 mV ±1% of (reading-
channel offset) (30 GHz) channel offset) (30 GHz) channel offset) (50 GHz)
±0.4% of full scale ±0.4% of full scale ±0.4% of full scale
±2 mV ±2% of (reading- ±2 mV ±2% of (reading- ±1.5 mV ±3% of (reading-
channel offset) (50 GHz) channel offset) (50 GHz) channel offset) (70 GHz)
±0.4% of full scale
±2 mV ±2% of (reading-
channel offset) (65 GHz)
CW Offset Range (referenced from
center of screen) ±500 mV
Input Dynamic Range (relative to
channel offset) ±400 mV
Maximum Input Signal ±2 V (+16 dBm)
Nominal Impedance 50 ohm
Reflections (for 30 ps rise time) 5%
Electrical Input 2.4 mm (male) 1.85 mm (male) 1.85 mm (male)
Clock Recovery Single Mode,
Multimode and Electrical Modules 83491A 83492A 83493A 83494A
Channel Type Electrical Multimode Optical Single Mode Optical Single Mode Optical
Clock Recovery Phase Locked Loop Bandwidth
Internal Path Triggering 50 to 70 kHz 90 kHz
External Output 4 MHz ±10%
Data Rates (Mb/s) 155, 622, 1063, 1250, 155, 622, 1063, 1250, 155, 622, 1250, 155, 622, 2488, 9953
2125, 2488, 2500 2125, 2488, 2500 2488, 2500
Tracking/Acquisition Range ±0.1% 155, 622, 2488, ±0.1%;
9953 ±0.03%
Internal Splitter Ratio 50/50 50/50 10/90 10/90
Output Jitter <0.0125 UI RMS 155, 622, 2488 0.02 UI RMS
9953 0.03 UI RMS
Input Power for Clock Recovery –10 dBm to +3 dBm 750 to 860 nm, –20 dBm to +3 dBm –12 dBm to +3 dBm
–10 to +3 dBm (155, 622, 2488 Mb/s)
1000 to 1600 nm, –8 dBm to +3 dBm
–13 to +3 dBm (9953 Mb/s)
Input/Output Connectors APC 3.5 mm, 50 ohm FC/PC, 62.5/125 µm FC/PC, 9 /125 µm
multimode, user
selectable connector
Auxiliary Recovered Clock and
Regenerated Data Outputs Type N with SMA adapters
Input Return Loss DC–1250 MHz, 20 dB 20 dB 28 dB 28 dB
1250–2500 MHz, 15 dB
Input Insertion Loss DC–1250 MHz, 7 dB 5 dB Maximum 1.5 dB Maximum
1250–2500 MHz, 15 dB
Clock Recovery Single Mode,
Multimode and Electrical Modules 83495A-100 83495A-101
Channel Type Single Mode Optical & Electrical Multimode Optical & Electrical
Clock Recovery Phase Locked Loop Bandwidth
Internal Path Triggering ≤100 KHz or ≤4 MHz (3.5 MHz typical
1
) user selectable
2
External Output ≤100 KHz or ≤4 MHz (3.5 MHz typical1) user selectable
2
Data Rates (Gb/s) 9.953 to 11.32
Tracking/Acquisition Range Continuous within data rate range
Internal Splitter Ratio 20/80 30/70
Clock Output Jitter 0.01 UI (0.007 UI typical) RMS
3
Input Level for Clock Recovery
4
–11 dBm to +1 dBm optical –8 dBm to +1 dBm optical
5
0.10 to 2.0 Vp-p electrical 0.10 to 2.0 Vp-p electrical
Input/Output Connectors FC/PC, 9/125 um & Type N FC/PC, 62.5/125 um & Type N
Auxiliary Recovered Clock and
Regenerated Data Outputs Type N with SMA adapters (no data output)
Input Return Loss 32 dB maximum optical 28 dB maximum optical
DC–2.5 GHz, 20 dB electrical DC–2.5 GHz, 20 dB electrical
2.5 GHz–11.32 GHz, 15 dB electrical 2.5 GHz–11.32 GHz, 15 dB electrical
Input Insertion Loss 2.5 dB maximum optical 3.0 dB maximum optical
18
Clock Recovery
TDR System Oscilloscope/TDR Performance Normalized Characteristics
Rise Time 40 ps nominal Adjustable from larger of 10 ps or 0.08 x time/div
Maximum: 5 x time/div
TDR Step Flatness ≤ ±1% after 1 ns from edge ≤0.1%
≤ ±5%, –3% 1 ns from edge
Low Level 0.00 V ±2 mV 0.00 V ±2 mV
High Level ±200 mV ± 2 mV ±200 mV ± 2 mV
TDR System
1
Achieved with input power ≥–8 dBm for option 100; ≥–5 dBm for option 101.
2
Loop BW transfer function is guaranteed to be less than a low pass
response with the specified corner frequency rolling off –20 dB/dec.
3
Measured with a PRBS 223-1 pattern. For total scope jitter, RSS
clock output jitter with mainframe jitter.
4
For optical input power, source extinction ratio ≥8.2 dB when measured per
TIA/EIA OFSTP-4A. For extinction ratio equal to 8.2 dB, OMA is defined as
(P
1–P0
) and is equal to average input power (dBm) + 1.68 dB.
5
Input is a fully filled multimode signal.
PRELIMINARY
19
Ordering Information
86100B lnfiniium DCA mainframe, wide bandwidth
digital oscilloscope
86100B-001 12 GHz trigger bandwidth
86100B-AX4 Rack mount flange kit
86100B-AXE Rack mount flange kit with handles
86100B-UK6 Commercial cal certificate with test data
Optical/Electrical Modules
86101A 2.85 GHz optical channel; multimode, amplified
(750-860 nm) 20 GHz electrical channel
86101A-201 155, 622 Mb/s
86101A-202 1.063, 1.25 Gb/s
86102A 10 GHz optical channel; multimode, amplified (750-860 nm)
20 GHz electrical channel
86102A-201 2.125, 3.187 Gb/s
86102A-202 2.488, 3.125 Gb/s
86102A-203 2.72, 3.32 Gb/s
86102U 15 GHz optical channel; multimode, unamplified
(750-860 nm)
20 GHz electrical channel
86102U-201 1.25, 2.488 Gb/s
86102U-202 2.488, 3.125 Gb/s
86102U-203 3.125, 10.3125 Gb/s
86103A 2.85 GHz optical channel; multimode, amplified
(1000-1600 nm)
20 GHz electrical channel
86103A-201 155, 622 Mb/s
86103A-202 1.063, 1.25 Gb/s
86103B 10 GHz optical channel; multimode, amplified
(1000-1600 nm)
20 GHz electrical channel
86103B-201 622 Mb/s, 2.488 Gb/s
86103B-202 1.063, 1.25 Gb/s
86103B-203 2.125, 2.488 Gb/s
86105B 15 GHz optical channel; single-mode, unamplified
(1000-1600 nm)
20 GHz electrical channel
86105B-101 9.953, 10.3125, 10.51875, 10.664, 10.709 Gb/s
86105B-102 155, 622 Mb/s
2.488, 2.666, 9.953, 10.3125, 10.51875, 10.664,
10.709 Gb/s
86105B-103 1.063, 1.250, 2.125, 2.488, 2.666, 9.953, 10.3125,
10.51875, 10.664, 10.709 Gb/s
86106B 28 GHz optical channel; single-mode, unamplified
(1000-1600 nm)
40 GHz electrical channel
86106B-410 9.953, 10.3125, 10.664, 10.709 Gb/s
86109A 30 GHz optical channel; single-mode, unamplified
(1000-1600 nm)
40 GHz electrical channel
86109B 40 GHz optical channel; single-mode, unamplified
(1000-1600 nm)
50 GHz electrical channel
86116A 53 GHz optical channel; single-mode, unamplified
(1000-1600 nm)
63 GHz electrical channel
86116B 65 GHz optical channel; single-mode, unamplified
(1480-1620 nm)
80 GHz electrical channel
Dual Optical Channel Modules
86111A Dual 2.85 GHz optical channels; multimode, amplified
(750-860 nm)
86111A-201 155, 622 Mb/s
86111A-202 1.063, 1.25 Gb/s
86111U Dual 15 GHz optical channels; multimode, unamplified
(750-860 nm)
86111U-201 1.25, 2.488 Gb/s
86111U-202 2.488, 3.125 Gb/s
86111U-203 3.125, 10.3125 Gb/s
86113A Dual 2.85 GHz optical channels; multimode, amplified
(1000-1600 nm)
86113A-201 155, 622 Mb/s
86113A-202 1.063, 1.25 Gb/s
86113A-301 155 Mb/s, 622 Mb/s, 2.488 Gb/s
86115B Dual 28 GHz optical channels; single-mode, unamplified
(1000-1600 nm)
86115B-101 9.953 Gb/s
86115B-410 9.953 Gb/s, 10.3125, 10.664, 10.709 Gb/s
Dual Electrical Channel Modules
86112A Dual 20 GHz electrical channels
86117A Dual 50 GHz electrical channels
86117B Dual 65 GHz electrical channels
86118A Dual 70 GHz electrical remote sampling channels
TDR/TDT Modules
Included with each of these TDR modules is a TDR demo board, programmers
guide, 2 50Ω terminations, APC-3.5 (m), and one short, APC-3.5 (m).
54754A Differential TDR module with dual 18 GHz TDR/electrical
channels
Trigger Module
86107A Precision timebase reference module
86107A-010 2.5 and 10 GHz clock input capability
86107A-020 10 and 20 GHz clock input capability
86107A-040 10, 20 and 40 GHz clock input capability
20
Clock Recovery Modules
The following modules provide a recovered clock from the data signal for
triggering at standard telecommunications and enterprise data rates:
83491A Electrical signals. Data rates
155, 622, 1063, 1250, 2125, 2488, 2500 Mb/s
83492A Multimode optical. Data rates
155, 622, 1063, 1250, 2125, 2488, 2500 Mb/s
83493A Single-mode signals. Data rates
155, 622, 1250, 2488, 2500 Mb/s
83494A Single-mode signals. Data rates
155, 622, 2488 Mb/s and 9.953 Gb/s
83494A-103 Single-mode signals. Data rates
155, 622, 2488 Mb/s and 10.3125 Gb/s
83494A-106 Single-mode signals. Data rates
155, 622, 2488, 2666 Mb/s and 10.664 Gb/s
83494A-107 Single-mode signals. Date rates
155, 622, 2488, 2666 Mb/s and 10.709 Gb/s
83495A 10 Gb/s Clock recovery module
83495A-100 Single-mode signals (1000–1600 nm) and electrical
83495A-101 Multimode signals (750–860 nm) and electrical
83495A-200 Continuous data rates from 9.953 Gb/s to 11.32 Gb/s
Warranty Options (for all products)
R1280A Customer return repair service
R1282A Customer return calibration service
Connector Options
(for All Optical Modules)
81000 AI Diamond HMS-10 connector
81000 FI FC/PC connector adapter
81000 SI DIN connector adapter
81000 VI ST connector adapter
81000 KI SC Connector Adapter
Accessories
10086A ECL terminator
11667B Power splitter, DC to 26.5 GHz, APC 3.5 mm
11667C Power splitter, DC to 50 GHz, 2.4mm
11742A 45 MHz to 26.5 GHz DC blocking capacitor
11742A-K01 50 GHz DC blocking capacitor
11898A 1.5 meter remote extender module
54008B 24 ns delay line
54121-68701 RF accessories kit
83430A 2.5 Gb/s lightwave transmitter
83440B/C/D Optical-to-electrical converters (6/20/32 GHz)
83446A 2.5 Gb/s lightwave receiver
8490D-020 2.4 mm 20dB attenuator
86101-60005 Filler panel
C3751-60201 Mouse (included with 86100B)
E2610-68700 Keyboard (included with 86100B)
N1020A 6 GHz TDR probe kit
N1025A 1 GHz active differential probe
Probes
1130 Series InfiniiMax probing systems
1134A 7 GHz InfiniiMax probe amp – order one or both E266xA
connectivity kits per amp
1132A 5 GHz InfiniiMax probe amp – order one or both E266XA
connectivity kits per amp
1131A 3.5 GHz InfiniiMax probe amp – order one or both E266xA
connectivity kits per amp
Connectivity kits model
E2669A InfiniiMax connectivity kit for differential measurements
E2668A InfiniiMax connectivity kit for single-ended measurements
Additional Components
E2675A InfiniiMax differential browser probe head and accessories,.
Includes 20 replaceable tips and ergonomic handle. Order
E2658A for replacement accessories.
E2676A InfiniiMax single-ended browser probe head and accessories.
Includes 2 ground collar assemblies, 10 replaceable tips, a
ground lead socket and ergonomic browser handle. Order
E2663A for replacement accessories.
E2677A InfiniiMax differential solder-in probe head and accessories.
Includes 20 full bandwidth and 10 medium bandwidth
damping resistors. Order E2670A for replacement accessories.
E2678A InfiniiMax single-ended/differential socketed probe head and
accessories. Includes 48 full bandwidth damping resistors,
6 damped wire accessories, 4 square pin sockets and socket
heatshrink. Order E2671A for replacement accessories.
E2679A InfiniiMax single-ended solder-in probe head and accessories.
Includes 16 full bandwidth and 8 medium bandwidth
damping resistors and 24 zero ohm ground resistors. Order
E2672A for replacement accessories.
Adapters
N1022A Adapts 113x/115x active probes to 86100 Infiniium DCA
Other Compatible Probes
54006A 6 GHz passive probe
54701A 2.5 GHz active probe
Adapters for Electrical Channels
11900B 2.4mm (f-f) adapter
11901B 2.4mm (f) to 3.5mm (f) adapter
11901C 2.4mm (m) to 3.5mm (f) adapter
54124-24101 2.4mm termination
5061-5311 3.5mm (f-f) adapter
1250-1158 SMA (f-f) adapter
1810-0118 3.5mm termination
Firmware and software
Firmware and software upgrades are available through the Web or your
local sales office. www.agilent.com/comms/dcaupgrade
21
Agilent Technologies’
Test and Measurement Support, Services, and Assistance
Agilent Technologies aims to maximize the value you receive, while minimizing your risk and
problems. We strive to ensure that you get the test and measurement capabilities you paid for and
obtain the support you need. Our extensive support resources and services can help you choose
the right Agilent products for your applications and apply them successfully. Every instrument
and system we sell has a global warranty. Support is available for at least five years beyond the
production life of the product. Two concepts underlie Agilent’s overall support policy: “Our
Promise” and “Your Advantage.”
Our Promise
Our Promise means your Agilent test and measurement equipment will meet its advertised
performance and functionality. When you are choosing new equipment, we will help you with
product information, including realistic performance specifications and practical recommendations
from experienced test engineers. When you use Agilent equipment, we can verify that it works
properly, help with product operation, and provide basic measurement assistance for the use of
specified capabilities, at no extra cost upon request. Many self-help tools are available.
Your Advantage
Your Advantage means that Agilent offers a wide range of additional expert test and measurement
services, which you can purchase according to your unique technical and business needs. Solve
problems efficiently and gain a competitive edge by contracting with us for calibration, extra-cost
upgrades, out-of-warranty repairs, and on-site education and training, as well as design, system
integration, project management, and other professional engineering services. Experienced Agilent
engineers and technicians worldwide can help you maximize your productivity, optimize the return
on investment of your Agilent instruments and systems, and obtain dependable measurement
accuracy for the life of those products.
By internet, phone, or fax, get assistance with all your test & measurement needs.
Online assistance:
www.agilent.com/comms/lightwave
Phone or Fax
United States:
(tel) 1 800 452 4844
Canada:
(tel) 1 877 894 4414
(fax) (905) 282 6495
China:
(tel) 800-810-0189
(fax) 1-0800-650-0121
Europe:
(tel) (31 20) 547 2323
(fax) (31 20) 547 2390
Japan:
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Korea:
(tel) (82-2) 2004-5004
(fax)(82-2) 2004-5115
Latin America:
(tel) (305) 269 7500
(fax) (305) 269 7599
Taiwan:
(tel) 080-004-7866
(fax) (886-2) 2545-6723
Other Asia Pacific Countries:
(tel) (65) 375-8100
(fax) (65) 836-0252
Email: tm_asia@agilent.com
Product specifications and descriptions in this document subject to change without notice.
© 2000, 2001, 2002, 2003 Agilent Technologies
Printed in USA August 27, 2003
5988-5311EN
Loading...
