HP 4339B High Resistance Meter
User's Guide
HP Part No. 04339-90041
Printed in JAPAN July 1999
Third Edition
Notice
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced, or translated to another
language without the prior written consent of the Hewlett-Packard Company.
Hewlett-Packard Japan, LTD.
Kobe Instrument Division
1-3-2, Murotani, Nishi-Ku, Kobe-shi,
Hyogo, 651-2241 Japan
c
Copyright 1996,1999 Hewlett-Packard Japan, Ltd.
HP 4339B
Manual Printing History
March 1996
::::::: :::::: ::::::: ::::::: :::::: ::::::: ::::::: :::::: ::::::: ::::::: ::::::
December 1996
July 1999
::::::: ::::::: :::::: ::::::: ::::::: :::::: ::::::: ::::::: :::::: ::::::: :::::::
::::: ::::::: :::::: ::::::: ::::::: :::::: ::::::: ::::::: :::::: ::::::: :
First Edition
Second Edition
Third Edition
iii
HP 4339B
Safety Summary
The following general safety precautions must be observed during all phases of operation,
service, and repair of this instrument. Failure to comply with these precautions or with specic
WARNINGS
elsewhere in this manual may impair the protection provided by the equipment.
In addition it violates safety standards of design, manufacture, and intended use of the
instrument.
The Hewlett-Packard Company assumes no liability for the customer's failure to comply with
these requirements.
Note
HP 4339B is designed for use in INSTALLATION CATEGORY II according to IEC
61010-1 and POLLUTION DEGREE 1 according to IEC 61010-1 and IEC 60664-1.
HP 4339B is an INDOOR USE product.
Note
LEDs in HP 4339B are Class 1 in accordance with IEC60825-1.
CLASS 1 LED PRODUCT
Ground The Instrument
To avoid electric shock hazard, the instrument chassis and cabinet must be connected to a
safety earth ground by the supplied power cable with earth blade
.
DO NOT Operate In An Explosive Atmosphere
Do not operate the instrument in the presence of ammable gasses or fumes
. Operation of any
electrical instrument in such an environment constitutes a denite safety hazard.
Keep Away From Live Circuits
Operating personnel must not remove instrument covers. Component replacement and internal
adjustments must be made by qualied maintenance personnel. Do not replace components
with the power cable connected. Under certain conditions, dangerous voltages may exist even
with the power cable removed. To avoid injuries, always disconnect power and discharge
circuits before touching them.
DO NOT Service Or Adjust Alone
Do not attempt internal service or adjustment unless another person, capable of rendering rst
aid and resuscitation, is present.
DO NOT Substitute Parts Or Modify Instrument
Because of the danger of introducing additional hazards, do not install substitute parts
or perform unauthorized modications to the instrument. Return the instrument to a
Hewlett-Packard Sales and Service Oce for service and repair to ensure that safety features
are maintained.
iv
HP 4339B
Dangerous Procedure Warnings
Warnings
, such as the example below, precede potentially dangerous procedures throughout
this manual. Instructions contained in the warnings must be followed.
Warning
Dangerous voltages, capable of causing death, are present in this
instrument. Use extreme caution when handling, testing, and adjusting
this instrument.
v
HP 4339B
Certication
Hewlett-Packard Company certies that this product met its published specications at the
time of shipment from the factory. Hewlett-Packard further certies that its calibration
measurements are traceable to the United States National Institute of Standards and
Technology, to the extent allowed by the Institution's calibration facility, or to the calibration
facilities of other International Standards Organization members.
Warranty
This Hewlett-Packard instrument product is warranted against defects in material and
workmanship for a period of one year from the date of shipment, except that in the case of
certain components listed in
General Information
of this manual, the warranty shall be for the
specied period. During the warranty period, Hewlett-Packard Company will, at its option,
either repair or replace products that prove to be defective.
For warranty service or repair, this product must be returned to a service facility designated by
HP. Buyer shall prepay shipping charges to HP and HP shall pay shipping charges to return the
product to Buyer. However, Buyer shall pay all shipping charges, duties, and taxes for products
returned to HP from another country.
HP warrants that its software and rmware designated by HP for use with an instrument will
execute its programming instruction when property installed on that instrument. HP does not
warrant that the operation of the instrument, or software
, or rmware will be uninterrupted or
error free.
Limitation Of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate
maintenance by Buyer, Buyer-supplied software or interfacing, unauthorized modication or
misuse, operation outside the environmental specications for the product, or improper site
preparation or maintenance.
No other warranty is expressed or implied. HP specically disclaims the implied warranties
of merchantability and tness for a particular purpose.
vi
HP 4339B
Exclusive Remedies
The remedies provided herein are buyer's sole and exclusive remedies. HP shall not be liable
for any direct, indirect, special, incidental, or consequential damages, whether based on
contract, tort, or any other legal theory.
Assistance
Product maintenance agreements and other customer assistance agreements are available for
Hewlett-Packard products.
For any assistance, contact your nearest Hewlett-Packard Sales and Service Oce.Addresses
are provided at the back of this manual.
vii
HP 4339B
Safety Symbols
General denitions of safety symbols used on equipment or in manuals are listed below.
Instruction manual symbol: the product is marked with this symbol when it is
necessary for the user to refer to the instruction manual.
Alternating current.
Direct current.
On (Supply).
O (Supply).
This
Warning
condition or the like, which, if not correctly performed or adhered to, could
result in injury or death to personnel.
This
Caution
condition or the like, which, if not correctly performed or adhered to, could
result in damage to or destruction of part or all of the product.
sign denotes a hazard. It calls attention to a procedure, practice,
sign denotes a hazard. It calls attention to a procedure, practice,
Note
practice, condition or the like, which is essential to highlight.
Axed to product containing static sensitive devices use anti-static handling
procedures to prevent electrostatic discharge damage to component.
Caution, risk of electric shock : Terminals which may be supplied from the
interior of the equipment at a voltage exceeding 1 kV
voltage exceeding 1 kV are marked with this symbol.
denotes important information. It calls attention to a procedure
, or allow connection to a
,
viii
HP 4339B
HP 4339B High Resistance Meter at a Glance.
Warning
Do
not
touch the UNKNOWN terminals or the electrodes of the accessory,
when the High Voltage indicator is ON.
ix
In User's Guide
Chapter 1, Preparation for Use
For initial turn on of the HP 4339B
Chapter 2, Operating the HP 4339B
Basic measurement operation
Getting acquainted with the HP 4339B|for beginners
Handy reference for common measurement tasks|for all users
Chapter 3, Measurement Examples
Measurement Examples for typical HP 4339B applications
Measuring Insulation Resistance of a Capacitor
Measuring Volume Resistivity of a Insulation Material
In the User's Guide, information on the following subjects is not discussed:
Initial Inspection
HP-IB remote control
Using with Handler
Maintenance
Specications
Error Messages
HP 4339B
For detailed information on these subjects, see the
HP 4339B Operation Manual
.
x
Contents
1. Preparation for Use
In This Chapter ............................... 1-1
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
To Set Power LINE Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
To Set Power LINE Frequency ........................ 1-2
2. Operating the HP 4339B
In This Chapter ............................... 2-1
To Reset HP 4339B to its Default Settings ...... ...... ...... . 2-2
To Connect Test Fixture . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
HP 16008B Resistivity Cell . . . . . . . . . . . . . . . . . . . . . . . . .
HP 16117B Low Noise Test Lead ......................
HP 16339A Component Test Fixture . . . . . . . . . . . . . . . . . . . . .
ToPerform Calibration|Canceling internal measurement errors ........ 2-4
To Set Test Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Set Current Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ToPerform OPEN Correction
|Canceling the stray admittance in parallel with the DUT
...... ...
If \Out Of Limit" is displayed . . . . . . . . . . . . . . . . . . . . . . . .
2-2
2-3
2-3
2-4
2-4
2-5
2-5
To Connect DUT ............................
To Select Measurement Parameter ...... ...... ..... .....
Setting the Parameters for Resistivity Measurement .... ...... ...
Setting Thickness of the DUT . . . . . . . . . . . . . . . . . . . . . . .
2-6
2-6
2-7
2-7
Setting the Electrode Size ...... ...... ...... ...... 2-7
To Select Measurement Range ........................ 2-8
Auto Range mode|Automatically selecting the optimum measurement range . 2-8
Hold Range mode|Holding the measurement range of your choice ...... 2-8
To Select Measurement Time Mode ...................... 2-8
To Set Averaging Rate|Stabilizing the measurement result . . . . . . . . . . .
To Select Trigger Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Set Trigger Delay Time ..........................
To Use Deviation Measurement Function ...................
Setting the Deviation Reference Values ...................
Selecting the Deviation Mode . . . . . . . . . . . . . . . . . . . . . . . .
To Use Comparator Function .........................
Setting the Limit Values .. ...... ...... ...... ..... .
2-9
2-9
2-9
2-10
2-10
2-10
2-11
2-11
Sorting .................................. 2-11
To Select Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
To Select Beeper Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-13
To Use Contact Check Function |Monitoring the connection of test electrodes and
DUT...................................
To Print Measurement Data . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-13
2-14
2-14
Contents-1
Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Disabling Printing ............................. 2-14
To Use Measurement Sequence Function
|Controlling charge-measurement in a sequence . . . . . . . . . . . . . . 2-15
Selecting the Measurement Sequence Mode ................. 2-15
Setting the Measurement Sequence . . . . . . . . . . . . . . . . . . . . . 2-15
Starting Measurement Sequence . . . . . . . . . . . . . . . . . . . . 2-16
Aborting Measurement Sequence . . . . . . . . . . . . . . . . . . . . . . 2-16
To Apply Test Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
To Trigger a Measurement .......................... 2-16
To Turn OFF Voltage Output . . . . . . . . . . . . . . . . . . . . . . . 2-16
Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Accessories Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Test Fixtures and Test Leads ....................... 2-17
HP 16064B LED Display/Trigger Box ................... 2-19
Other Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If You Have a Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Measurement Examples
2-20
2-20
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Measuring Insulation Resistance of Capacitor ........ ..... ....
Measurement Setup ............................
Measurement Procedure ..........................
For More Information .... ...... ...... ..... ......
Measuring Resistivity of Insulation Material ..................
Measurement Setup ............................
Measurement Procedure ..........................
For More Information ..........................
3-1
3-2
3-2
3-2
3-5
3-6
3-6
3-6
3-9
Contents-2
Figures
2-1. Printer Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Tables
1-1. Power Voltage Selector Setting ...... ...... ...... ..... 1-1
Contents-3
1
Preparation for Use
In This Chapter
Before turning the HP 4339B ON, you must rst set the HP 4339B to match the available power
LINE voltage.
If the HP 4339B's power LINE voltage and frequency are properly set and ready to use, you
can skip this chapter.
Power Requirements
The HP 4339B's power source requirements are as follows:
6
LINE Voltage
LINE Frequency
Power Consumption
To Set Power LINE Voltage
: 100 / 120 / 220 / 240 V ac (
: 47to66Hz
:45VA maximum
10%)
1. Conrm that the power cable is disconnected.
2. Slide the LINE Voltage selector on the rear panel to match the power LINE voltage which
will be used (see Table 1-1).
Table 1-1. Power Voltage Selector Setting
Voltage Selector Line Voltage Required Fuse
100V/120Vac(610%) UL/CSA type, Time delay 0.5A 250V
(HP part number 2110-0202)
220V/240Vac(610%) UL/CSA type, Time delay 0.25A 250V
(HP part number 2110-0201)
Preparation for Use 1-1
HP 4339B
To Set Power LINE Frequency
1. Connect the power cable to the power cord receptacle on the rear panel.
2. Push the LINE switch in. The HP 4339B will emit a beep and perform the self test. (If any
message is displayed, see \Error Messages" back of
HP 4339B Operation Manual
.) The
HP 4339B will be ready for operation after a message like the following is displayed.
3. Press . The following menu is displayed.
4. Press until
5. Press until
more
blinks, and press .
Line
blinks, and press .
A blinking item means that it is currently selected.
6. If the setting does not match the power LINE frequency, press
between
7. Select
Note
50Hz
Exit
and
60Hz
, then press .
and press
to exit this menu.
The power line frequency setting is stored and is not changed after reset or
power-o. Once you set it, you do not need to set the line frequency again as
long as the same power line frequency is being used.
to toggle the setting
1-2 Preparation for Use
Operating the HP 4339B
In This Chapter
Basic measurement operations of the HP 4339B and references are explained.
2
Operating the HP 4339B 2-1
To Reset HP 4339B to its Default Settings
HP 4339B
1. Press
2. Press until
For more information about the default settings, see \Default Settings" later in this chapter.
To Connect Test Fixture
Connect the test xture to the UNKNOWN terminals as follows:
Warning
HP 16008B Resistivity Cell
The HP 16008B is used to measure the volume or surface resistance/resistivity of insulation
materials.
to select the reset menu.
Yes
blinks, and press .
Do
not
touch the UNKNOWN terminals or the electrodes of the accessory,
when the High Voltage indicator is ON, the HP 4339B outputs dangerous
voltage of up to 1000 Vdc. Before handling the HP 4339B or the
accessory, turn OFF the test voltage pressing and conrm that the
High Voltage indicator is OFF.
Three size electrodes are available.For detail see \Accessories Available" later in this chapter.
2-2 Operating the HP 4339B
HP 4339B
HP 16117B Low Noise Test Lead
The HP 16117B is used to measure the resistance of insulation materials.
HP 16339A Component Test Fixture
The HP 16339A is used to measure insulation resistance of electronic components.
Three type modules are available.For detail see \Accessories Available" later in this chapter.
* Measuring a high capacitance DUT keeping good S/N ratio, change the short bar to an
appropriate resistor.For detail, see page 3-6 of
and Service Manual
.
HP 16339A Component Test Fixture Operation
Operating the HP 4339B 2-3
HP 4339B
ToPerform Calibration|Canceling internal measurement errors
1. Press
2. Select
calibration. After the calibration is completed with the message
HP 4339B will return to the measurement display.
To Set Test Voltage
1. Press . The voltage setting menu will be displayed.
2. Enter the value using the numeric ENTRY keys (for example
ExecCal
), then press .
.
using or and press . The HP 4339B will perform the
Calibration Complete
, to set 100 V, press
, the
To Set Current Limit
1. Press
2. Enter the current limit value using the numeric keys
to exit.
Available current limits are:
0.5 mA (default)
1.0 mA
2.0 mA (at test voltage 0 to 500 V only)
.
5.0 mA (at test voltage 0 to 250 V only)
10 mA (at test voltage 0 to 100 V only)
, then press
to enter the value and
2-4 Operating the HP 4339B
HP 4339B
ToPerform OPEN Correction
|Canceling the stray admittance in parallel with the DUT
1. Separate each electrode of the test xture.For details
about xture operation, refer to
\Test Fixtures and Test Leads" later in this chapter.
2. Press
xture, and the
Warning
. A source voltage is applied to the test
V Output
indicator will turn ON.
Pressing may cause the HP 4339B to output dangerous voltage,upto
1000 Vdc. Do
not
touch the UNKNOWN terminals or the electrodes of the
accessory when the V Output indicator is ON.
3. Press
4. Select
OpenMeas
. The OPEN correction menu will be displayed.
using or and press . The HP 4339B will perform the OPEN
correction.
After a while, the HP 4339B will display the message
the measurement mode.
5. Press
to turn the voltage OFF. The
V Output
Correction Complete
indicator will turns OFF.
, and return to
If \Out Of Limit" is displayed
The OPEN admittance is so high that it would be unsuitable for OPEN correction data.
Check that the test electrodes are properly opened.
Perform the OPEN correction again.
Operating the HP 4339B 2-5
To Connect DUT
Set the DUT to the test xture.For details, see \Test Fixtures and Test Leads".
Do
not
Warning
when the High Voltage indicator is ON, the HP 4339B outputs dangerous
voltage of up to 1000 Vdc. Before handling the HP 4339B or the
accessory, turn OFF the test voltage pressing and conrm that the
High Voltage indicator is OFF.
To Select Measurement Parameter
1. Press . The measurement parameter selection menu will be displayed.
touch the UNKNOWN terminals or the electrodes of the accessory,
HP 4339B
2. Select the desired parameter using or and press .(R:Resistance,I:Current,
Rv
:Volume resistivityv,Rs:Surface resistivitys)
Note
If the HP 16008B resistivity cell is connected to the HP 4339B, to change
volume and surface resistivity, switch the volume/surface selector on the
resistivity cell.
2-6 Operating the HP 4339B
HP 4339B
Setting the Parameters for Resistivity Measurement
If you measure the volume or surface resistivity, set the parameters as follows:
Press
Setting Thickness of the DUT
1. Select
2. Enter the thickness value using the numeric ENTRY keys, and press .
Setting the Electrode Size
1. Select
Thickness
ResCell
.
using or and press .
using or and press .
2. Select the electrode size that you want to use (
press .
3. Press
4. Select
Exit
and press to exit the menu.
26mm,50mm
,or
76mm
) using
Operating the HP 4339B 2-7
or , and
To Select Measurement Range
Auto Range mode
|Automatically selecting the optimum measurement range
HP 4339B
Press . The
Hold Range
annunciator(9) turns OFF.
Hold Range mode|Holding the measurement range of your choice
To select the measurement range,
1. Press . The measurement range setup menu is displayed.
2. Press or until the desired range is displayed. Or, input the current value to
be measured using the numeric ENTRY keys, and the HP 4339B will select the optimum
measurement range setting.
3. Press
Hold Range
annunciator(9) turns ON.
. The
Available measurement ranges:
100 pA (Not available at measurement time Short)
1nA
10 nA
100 nA
1A
10A
100A(Available at measurement time Short only)
To Select Measurement Time Mode
Press
Short,Med
until the
(Medium) or
Meas Time
Long
.
annunciator(9) points to the desired measurement time mode :
2-8 Operating the HP 4339B
HP 4339B
To Set Averaging Rate|Stabilizing the measurement result
1. Press .
2. Enter the averaging rate using the numeric ENTRY keys.(For example, to enter 4, press
.) You can enter integer values from 1 to 256. Also, you can increase or decrease the
value using or .
3. Press
To Select Trigger Mode
Press until the
Int
(Internal) Free running measurement
Man
(Manual) Triggers a measurement when
Ext
(External) Triggers a measurement by external trigger signal input (through the external
To trigger a measurement in each mode, see \To Trigger a Measurement" later in this chapter.
To Set Trigger Delay Time
1. Press
to set the value and to exit.
Trigger
trigger connector or handler interface).
.
annunciator(9) points to the desired trigger mode.
is pressed.
2. Enter the desired trigger delay time using the numeric ENTRY keys.(For example, to set
0.5 s, press
3. Press
to set the value and to exit.
.) You can set the trigger delay time from 0 s to 9.999 s.
Operating the HP 4339B 2-9
To Use Deviation Measurement Function
Setting the Deviation Reference Values
HP 4339B
1. Press
2. Select
3. Enter the numeric value using the numeric ENTRY keys.
4. Press to enter the value.
Selecting the Deviation Mode
5. Select
1RefEnt
ModeSet
.
using or and press .
using or and press .
6. Select the desired mode using or and press .
1ABS
mode: Measured value0Reference
1
% mode: (Measured value0Reference)/Reference2100 %
2-10 Operating the HP 4339B
HP 4339B
To Use Comparator Function
Setting the Limit Values
1. Press
2. Enter the lower limit value using the numeric ENTRY keys, then press to enter the
value.You can set the value from09.90021037to 9.90021037.
3. Press .
4. Enter the upper limit value using the numeric ENTRY keys
value and to exit. You can set the value from09.900210
, then press
37
to 9.900210
37
.
to enter the
Sorting
To start sorting,
Press
Comprtr On
annunciator(9) turns ON.
. The
To turn sorting OFF,
Press
again. The
Comprtr On
annunciator turns OFF.
The sorting results are HIGH, IN, and LOW.
Where,
HIGH greater than higher limit
IN between higher limit and lower limit
LOW less than lower limit
The HP 4339B shows the comparison results using the display
, beeper, printer, and
HP 16064B LED Display/Trigger Box.(To use the HP 16064B, see \Accessories Available" later
in this chapter.)
For result output to the display, see \To Select Display Mode" in the next page.
For result output to the beeper, see \To Select Beeper Mode" in the next page.
For result output to the printer, see \To Print Measurement Data" later in this chapter.
Operating the HP 4339B 2-11
To Select Display Mode
HP 4339B
Press
.
Select the desired mode using or and press .
(
Data
:Measurement Display,
If you select
Formt
, the following menu will be displayed. You can select the display digits and
Comprtr
:Comparison Display,
display format of the Measurement Display mode.
To select the display digits, select
4or5
.
Digit
and press . Then select the display digits from3,
To selet the display format for the measurement data, select
select
Exponent
mode or
Prefix
mode.
Each display mode shows the result as follows:
The Measurement Display mode shows the measurement data:
Off
:Display OFF)
R-Unit
and press
. Then
Exponent
Prefix
mode
mode
The Comparison Display mode shows the comparison results:
The Display OFF mode (
DISP OFF
) does not show any measurement result.
2-12 Operating the HP 4339B
HP 4339B
To Select Beeper Mode
To change the beeper mode for the comparator result reporting:
1. Press
2. Select
Beep
.
using or and press to select.
3. Select the beep mode using or , and press to exit to the previous display.
OFF
FAIL
No beep
Emits a beep when the comparator result is HIGH, LOW
, or the contact
check FAILed.
PASS
4. Select
Exit
Emits a beep when the comparator result is IN.
using
or , and press to exit.
To Use Contact Check Function |Monitoring the connection of
test electrodes and DUT
To enable or disable the contact check function:
1. Press
2. Select
ON/OFF
3. SelectOnor
4. Select
5. The
Exit
Cont Chk
When contact check failed, the HP 4339B displays
contact check function is changable. Refer to
.
using or and press to select.
Off
using or , and press to exit to the previous display.
using
or , and press to exit.
annunciator(9) turns ON if the contact check function is on.
N.C.
(No-Contact). The limit value for the
Operation Manual
.
The OPEN correction function must be performed correctly for a valid contact check.
Operating the HP 4339B 2-13
To Print Measurement Data
Setting the Printer
1. Use an HP-IB compatible printer, set to the listen-always mode.
2. Connect the printer to the HP 4339B's HP-IB port on the rear panel.
3. Turn the printer ON.
Printing
Set the HP 4339B to talk only mode (Set the HP 4339B's HP-IB address to 31).
1. Press .
HP 4339B
2. Press . The
measurement data.
Disabling Printing
Change the HP-IB address to an address other than 31 (for example
setting).
Press
Talk Only
annunciator(9) turns ON, and the printer begins printing the
Figure 2-1. Printer Output
.
, 17, which is the default
2-14 Operating the HP 4339B
HP 4339B
To Use Measurement Sequence Function
|Controlling charge-measurement in a sequence
Selecting the Measurement Sequence Mode
Press
.
Select the desired mode using or and press .
Single
Continuous
Off
Single mode
Continuous mode
Measurement sequence OFF (normal measurement mode)
Setting the Measurement Sequence
1. Press
. The sequence mode menu will be displayed.
2. Set Charge time.
a. Select
Chrg
using
or and press .
b. Enter the charge time using the numeric ENTRY keys
3. Set Interval time and Number of repetitions (
a. Select
Intvl
using or and press .
Cont
b. Enter the interval time using the numeric ENTRY keys
, and press
mode only).
, and press
.
.
c. Enter the number of measurement points (equivalent to Memory size), and press .
4. Select
Exit
and press to exit.
Operating the HP 4339B 2-15
Starting Measurement Sequence
HP 4339B
Press
Warning
. The
Seq Running
annunciator(9) turns ON.
Pressing may cause the HP 4339B to output dangerous voltage,upto
1000 Vdc. Do
not
touch the UNKNOWN terminals or the electrodes of the
accessory, when the V output indicator is ON.
Aborting Measurement Sequence
Press . The
Seq Running
annunciator(9) turns OFF.
To Apply Test Voltage
Press . The
Warning
V Output
indicator turns ON.
Pressing may output dangerous voltage, up to 1000 Vdc. Do
touch the UNKNOWN terminals or the electrodes of the accessory when
the V Output indicator is ON.
not
To Trigger a Measurement
In internal trigger mode|The HP 4339B makes continuous free-running measurements
In manual trigger mode|Press
when you want to trigger a measurement.
.
In external trigger mode| Connect the external trigger source to the EXT TRIGGER terminal
on the HP 4339B's rear panel, and apply a TTL level trigger signal to trigger a measurement.
(For details, see the
HP 4339B Operation Manual
.)
Note that the HP 4339B must be set to the external trigger mode to be triggered from an
external handler or from the HP 16064B LED Display/Trigger Box.
To Turn OFF Voltage Output
Press
Warning
and conrm the
If the High Voltage Indicator turns ON after turning OFF the test voltage,
V Output
indicator and the
High Voltage
indicator is turn OFF.
the DUT is still charged. This happens especially for capacitive DUTs.Do
NOT
handle the DUT while the High Voltage Indicator is turned ON. When
the charge on the DUT discharges to a safe level(less than 42 V) the High
Voltage indicator will turn OFF.
2-16 Operating the HP 4339B
HP 4339B
Reference
Default Settings
Test voltage output : OFF
Test voltage :0V
Current limit : 0.5 mA
Measurement parameter : R
Resistivity cell D1 : 50 mm
D2 :70mm
t :2mm
B :0
Deviation measurement : OFF
Measurement range :Auto
Measurement time : MEDium
Averaging rate :1
Trigger mode : Internal
Trigger delay time :0ms
Comparator : OFF
Contact check : OFF
Display mode : Measurement mode
Beep mode :
Oset-error canceling : OFF
OPEN correction data is cleared
FAIL
mode
Accessories Available
Test Fixtures and Test Leads
Following test xtures and test leads are available for the HP 4339B for various forms of DUTs.
Operating the HP 4339B 2-17
HP 16008B
HP 16339A
HP 4339B
HP 16117B
2-18 Operating the HP 4339B
HP 4339B
HP 16118A
HP 16064B LED Display/Trigger Box
The HP 16064B LED Display/Trigger Box triggers a measurement when its trigger key is
pressed, and displays the comparison results using LEDs. It allows you to manually operate the
comparator function of the HP 4339B.
Operating the HP 4339B 2-19
Other Topics
HP 4339B
For details on these functions, see the
Initial Inspection | Chapter 1 of the
Auto-Oset Canceling | Chapter 2 and Chapter 3 of the
Key Lock Function | Chapter 2 and Chapter 3 of the
HP-IB | Chapter 4 and Chapter 5 of the
Handler Interface | Chapter 3 and Appendix B of the
Save / Recall | Chapter 2 and Chapter 3 of the
Backup Function | Chapter 3 of the
Specication | Chapter 8 of the
Maintenance | Chapter 9 of the
Error Messages | \Error Messages" in back of the
HP 4339B Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
Operation Manual
.
If You Have a Problem
If any of the problems listed below occur, follow the instructions given for the problem.
If you nd yourself lost when operating the HP 4339B
You can get back on track by:
To return to the measurement mode
To return to the default settings
Press
several times. When
select it and press
Press . Select
.
Yes
Exit
is in the menu,
and press .
If the reset is not accepted, conrm that the
Lock
annunciator(9) is turned ON. See next.
Key
If the HP 4339B does not accept key input:
Check whether or not the
Press
. The
Key Lock
Key Lock
annunciator(9) is ON. If so:
annunciator(9) turns OFF and the front-panel keys are
unlocked.
Check that the HP 16064B LED display/trigger box is connected to the HP 4339B and it
is set to lock out the keys.Ifso, unlock the keys from the HP 16064B.
If
is not accepted:
Check whether the interlock connector is rmly connected.
If you are using the HP 16008B or the HP 16339A,
Check whether the top cover of the test xture is closed.
If
------
or \OVLD" is displayed:
The measurement result is out of the measurable range. Check the DUT and make sure the
measurement range is properly set.
2-20 Operating the HP 4339B
Measurement Examples
In This Chapter
The HP 4339B's features are discussed, which you can investigate by trying the typical
measurement examples described in this chapter.
Do
not
Warning
when the High Voltage indicator is ON, the HP 4339B outputs dangerous
voltage of up to 1000 Vdc. Before handling the HP 4339B or the
accessory, turn OFF the test voltage pressing and conrm that the
High Voltage indicator is OFF.
touch the UNKNOWN terminals or the electrodes of the accessory,
3
Measurement Examples 3-1
HP 4339B
Measuring Insulation Resistance of Capacitor
This example shows the procedure to measure insulation resistance of capacitor after charged 1
minute. Using the test sequence measurement function reduces the measurement complexity.
DUT
Chip ceramic capacitor
Measurement Setup
Measurement Parameter : R
Measurement Range : Auto range mode
Test Voltage : 100 V
Use the measurement sequence single mode (measure after charged for 1 minute.)
Measurement Procedure
1. Reset the HP 4339B.
a. Press
b. Select
2. Connect the test xture to the UNKNOWN terminals as follows:
Yes
.
using or and press .
Requirements
Test Fixture : HP 16339A, SMD module
*For detail, see \HP 16339A Component Test Fixture" in Chapter 2.
3. Perform calibration.
Press .
3-2 Measurement Examples
HP 4339B
Select
completed with the message \
4. Set the test voltage.
a. Press .
b. Press to set the test voltage to 100 V.
5. Perform the OPEN correction.
a. Separate the test electrodes and x them (nothing must be connected to the electrodes).
ExecCal
using or and press . After a while, the calibration will be
Calibration Complete
".
b. Close the cover.
c. Press
d. SelectIusing or and press to select the current measurement mode.
displayed.
e. Press . The
f. Press
The
V Output
g. Wait until theIvalue has stabilized within 0.5 pA.
.
Meas Time
to turn ON the test voltage.
indicator will turn ON.
annunciator(9) will indicate
Long
.
Measurement Examples 3-3
HP 4339B
h. Press
i. Select
OpenMeas
.
using or and press .
After a while, the OPEN correction will be completed with the message \
Complete
". (If
Out Of Limit
is displayed, see \ ToPerform OPEN Correction
|Canceling the stray admittance in parallel with the DUT " in Chapter 2.)
j. Press to turn OFF the test voltage. The
V Output
indicator will turn OFF.
6. Connect the DUT and close the cover.
Correction
7. Press .
8. SelectRusing or and press to select the resistance measurement mode.
R
(Resistance).
9. Set the measurement sequence charging time to 1 minute.
a. Press
b. Select
Chrg
.
using or and press .
c. Press .
d. Select
Exit
and press
3-4 Measurement Examples
to exit.
HP 4339B
e. Press .
f. Select
Single
using or and press .
10. Press . After charging 1 minute, the measuremen result will be displayed. The
following gure shows the typical measurement result display.
For More Information
To print out the measurement result | See \To Print Measurement Data" in Chapter 2
To select measurement level | See \To Set Test Voltage" in Chapter 2
Measurement Examples 3-5
HP 4339B
Measuring Resistivity of Insulation Material
This example shows the procedure to measure resistivity of an insulation material after charged
1 minute. The HP 16008B Resistivity Cell is a right tool to measure resistivity of solid insulation
materials.
DUT
Insulation Material
(5 mm2120 mm2120 mm)
Measurement Setup
Measurement parameter : Rv(v)
Measurement Range : Auto range mode
Test Voltage : 500 V
Use the measurement sequence single mode (measure after charged for 1 minute.)
Measurement Procedure
1. Reset the HP 4339B.
a. Press
b. Select
2. Connect the test xture to the UNKNOWN terminals as follows:
Yes
.
using or and press .
Requirements
Test Fixture : HP 16008B,50 mm electrode
3-6 Measurement Examples
HP 4339B
3. Perform calibration.
a. Press .
b. Select
After a while, the calibration is completed with the message \
4. Set the test voltage.
a. Press .
b. Press to set the test voltage to 500 V.
5. Perform the OPEN correction.
a. Turn the load knob counterclockwise(ccw) until the upper electrode does not move
ExecCal
using or and press .
Calibration Complete
".
.
b. Close the cover.
c. Press
.
Measurement Examples 3-7
HP 4339B
d. SelectIusing or and press to select the current measurement mode.
e. Press . The
Meas Time
annunciator(9) will
indicates
f. Press . The
Long
.
V Output
indicator will turn ON.
g. Wait until theIvalue has stabilized within 0.5 pA.
h. Press
i. Select
OpenMeas
.
using or and press .
After a while, the OPEN correction is completed with the message \
Complete
". (If
Out Of Limit
is displayed, see \
ToPerform OPEN Correction
|Canceling the stray admittance in parallel with the DUT " in Chapter 2.)
j. Press
. The
V Output
indicator will turn OFF.
6. Set the DUT.
a. Place the DUT on the Main electrode.
Correction
b. Turn the load knob and stick the electrode on the DUT.(Let the load scale indicate more
than 0 kg and less than 10 kg.)
c. Close the cover.
7. Set the measurement parameter to Rv(v : volume resistivity).
a. Turn the Volume/Surface selector of the HP 16008B to \Volume".
b. Press
.
c. SelectRvusing or and press .
3-8 Measurement Examples
HP 4339B
8. Set the measurement sequence charging time to 1 minute.
a. Press .
b. Select
c. Press .
d. Select
e. Press .
f. Select
9. Press . After charging 1 minute, the measurement result will be displayed. The
following gure shows the typical measurement result display.
Chrg
and press .
Exit
and press
Single
using or and press .
to exit.
For More Information
To print out the measurement result | See \To Print Measurement Data" in Chapter 2
To select other measurement parameters | See \To Select Measurement Parameter" in
Chapter 2
To select measurement level | See \To Set Test Voltage" in Chapter 2
Measurement Examples 3-9
Loading...
