HP 4155B/4156B Trade-In Program for
HP 4145A/B and HP 4155A/4156A Owners

Promotional Information

Introduction

Program Outline

With the introduction of the
HP 4155B Semiconductor Parameter
Analyzer and the HP 4156B
Precision Semiconductor Parameter
Analyzer, HP is offering a trade-in
program to existing HP 4145A/B and
HP 4155A/4156A owners. The key
points of the program are:

ì The percentage discount

increases with the number of
units returned for trade-in credit.

ì Percentage discounts do not

accumulate; they must be done on
a single transaction basis.

ì The percentage discounts are

based on the number of units
returned; this number must match
the number of new units
purchased exactly.

ì Discounts from this program may

be added to other applicable HP
discounts.

ì Units returned for credit must be

shipped within 60 days of receipt
of new instruments to the regional
return site, or the credit is forfeit.

ì The packing slip must reference

your name, and the HP order
number from your original order of
the HP 4155B and/or HP 4156B.
All returns must be on one packing
slip, and the packing slip must
include a complete listing of
product and serial numbers of the
units being returned.

ì The trade-in program runs until

February 29, 2000 for the
HP 4145A/B, HP 4155A, and
HP 4156A.

2

New Features

The HP 4155B/4156B
Semiconductor Parameter
Analyzers

Specification Changes

Instrument Control

HP 4155B and 4156B function control:
Internal or external computer controls
the HP 4155B and HP 4156B functions
via HP-IB interface.
New Command set:
HP FLEX command set
New Program Memory:
Using the HP 4155B/4156B HP FLEX
command set, the user can store
program code in the HP 4155B or the
HP 4156B. Maximum number of
subprograms is 256 (8 bit).

NFS LAN capability increases flexibility and efficiency

LAN Capability

The HP 4155B/4156B supports the
NFS protocol and has a 10BASE-T
compatible LAN port. You can
define up to 4 different network
directories per instrument, which all
of your networked parameter
analyzers can share. You can also
use any networked printer to make
hard copies of your test results. This
gives you the capability to share data
and setup files on a site-wide or even
worldwide basis (Note: The
instrument itself does not support

network gateways). In addition,
you can easily pull data into data
analysis tools (such as spreadsheets)
on your desktop PC.

Better Printer Support for
Cleaner Presentations

The HP 4155B/4156B now
supports the popular TIF file
format, enabling you to place plots
and other graphical information
directly into your reports. In
addition, the new parameter
analyzers also support a special

high-resolution format (HR). The
HR format eliminates some of the
common printing/plotting issues

(such as “stair-step” wave forms)
which detract from the appearance of
final reports. Finally, the new
analyzers have parallel printer
interfaces (Centronics), replacing the
older serial printer interface.

Easy to Use VXIplug&play Drivers
for Visual Programming
Languages

HP supplies VXIplug&play
drivers for the HP 4155B,
HP 4156B, and HP E5250A (Low
Leakage Switch Mainframe). More
powerful and easier to use than the
old panel drivers, the plug&play
drivers unleash the full power of
visual programming languages such
as HP VEE. HP VEE easily allows
you to create test sequences, make
conditional branching decisions, and
develop operator interfaces, and does
this in much shorter time periods
than more traditional programmatic
languages.

VXIplug&play Drivers

µ

5965-8810E

3

Feature Comparison

Resolution: 1fA & 2

Color Display

External Keyboard

Knob Sweep

Auto Analysis Capability

Auto Analysis Function + IBASIC

MS-DOS Format Supported

Expandable to >4 SMUs

SCPI Support

HP FLEX Support

Program Memory

Parallel Printer Interface

TIFF File Format Support

LAN Capability

VXIplug&play Drivers

* On the HP 4156B unit only.

V

HP 4155B/4156BHP 4155A/4156AHP 4145A/B

Yes*Yes*No

YesYesNo
YesYesNo
YesYesNo
YesYesNo
YesYesNo
YesYesNo
YesYesNo
YesYesNo
YesNoNo
YesNoNo
YesNoNo
YesNoNo
YesNoNo
YesNoNo

Trade-In Discounts

Return Procedure

for Trade-In*

US and Canada

You must ship the trade-in units to
the following address within 60 days
of receipt of the HP 4155B/4156B
units:
Hewlett Packard Company
HUMC
5301 Stevens Creek Boulevard
Santa Clara, CA 95051-7295
ATTN: “HP 4155B/4156B Semicon-

ductor Para Analy Trade-In”
Contact: Jeannette Meline

International

You must ship the trade-in units to
the local HP Sales Office within 60
days of receipt of the HP 4155B/
4156B units.

* The quantity of trade-in units must be the same as the number of new units purchased.
** These discounts apply to the mainframe only; options are not eligible for trade-in credit.

Packing Slips

The promotional discount will be
denied if the units are returned
without a correct packing slip.
“Correct Packing Slip” means that

Related HP Literature

Systematic Solutions to the Parametric Puzzle

product brochure

HP 4156B Precision Semiconductor Parameter Analyzer

technical data sheet

for Trade-In*

% Discount**Quantity of HP 4145A/Bs

10%1
12%2 - 4
14%5 - 9
16%10 - 99

% Discount**Quantity of HP 4155/56As

25%1
27%2 - 4
29%5 - 9
31%10 - 99

the packing slip is addressed to “HP
4155B/4156B Semiconductor
Parameter Analyzer Trade-In
Program,” and that the packing slip
must reference your name, and the
HP order number from your original

order of the HP 4155B and/or
HP 4156B. All returns must be on
one packing slip, and the packing slip

5965-9619EHP 4155B Semiconductor Parameter Analyzer

must include a complete listing of
product and serial numbers of the
units being returned.

Program End

Date

February 29, 2000

Program End

Date

February 29, 2000
