Aeroflex 2390A Data Sheet

The 2390A series of spectrum analyzers
from IFR combine exceptional performance
with excellent value for money. There are
three instruments in the range:-

2392A 9 kHz to 2.9 GHz

2390A 9 kHz to 22 GHz

2393A 9 kHz to 26.5 GHz

Frequency Accuracy

All three instruments are fully
synthesized to give accurate frequency
measurements. Even on wide spans the
2390A series gives precise frequency
measurements and an integral frequency
counter enables the measurement of
individual signals to 1 Hz resolution.

Fundamental mixing to 12 GHz enables
the microwave versions to reach their
maximum frequency in only two harmonic

sweeps. This gives excellent sensitivity and
accuracy right up to 26.5 GHz.

Narrow Resolution

The 2390A series all have resolution
bandwidths down to 3 Hz. Narrow
resolution bandwidths provide the ability to
resolve closely spaced signals or
sidebands.

FM spectrum

The 3 Hz filter is also used for close in
signal analysis, for example it can be used
to identify 50 or 60 Hz power line
sidebands on oscillators. The average
displayed noise level when using a 3 Hz
filter is less than -135 dBm at 2.9 GHz and
below -125 dBm at 26.5 GHz. This makes
2390A series suitable for locating and
identifying low level spurious and harmonic
signals.

Wideband Filters for Spread Spectrum
and Pulsed Signals

When analyzing signals with wide
spectrum bandwidths such as digitally
modulated carriers or pulsed radar, the
resolution bandwidth of the spectrum
analyzer can limit the measurement. The
2390A series have 10 MHz and 30 MHz

bandwidth filters. These give the best
available characterization of wideband
signals and have an impulse bandwidth
>5 MHz. In zero span mode a minimum
sweep time of 200 ns/div makes displaying
radar pulses precise and straightforward.

200 ns sweep clearly shows ringing on

demodulated radar pulse

AM and FM Receiver Modes

The 2390A series features built-in
receivers for both AM and FM signals.
Modulation detection can be set to
narrowband or wideband mode.

For an FM transmission a modulation
scale of 1 kHz to 5 MHz per division allows
direct measurement of the modulation
component of carrier signals up to
±20 MHz deviation. Frequency
synthesizer settling time can be measured
using the DC coupled output from the FM
detector.

A high quality audio output through
either a built-in speaker or headphone
connector allows audible detection of noise
or distortion. It can also be used to identify
the source of interfering transmissions.

2390A Series

Spectrum Analyzers

A range of RF and
Microwave Spectrum
Analyzers that offer value
and performance to both
field and bench users.

Spectrum Analyzers

Fully synthesized Spectrum
Analyzers to 26.5 GHz

3 Hz to 30 MHz resolution
bandwidth filters

Excellent intermodulation
performance

+30 to -135 dBm measurement
range

Measurements to 300 GHz with
external mixers

Optional built-in tracking generator
Receiver mode with AM and FM

demodulators
Optional quasi-peak detector and

EMC filters

2390A Series

1

http://www.ifrinternational.com

Harmonic and Spurious Measurements

When monitoring the frequency
spectrum or installing and maintaining
radio systems it is important to check the
spurious and harmonic signals.
The 2390A series has fundamental mixing
to 12 GHz and sweeps to 26.5 GHz in only
two harmonic steps. This means that good
sensitivity is maintained across the whole
frequency band revealing interfering signals
that may otherwise have been lost in noise.

Internally generated intermodulation
distorting products are minimized by the
high performance input mixer. This gives
more than 80 dBc intermodulation free
dynamic range. As a result the user can be
confident that all displayed signals are true
signals even when measuring at busy
transmitter sites.

Third order intermodulation measurement of

a 1 GHz amplifier

Network Measurements

An optional built-in tracking generator is
available covering from 100 kHz to

2.9 GHz. It is ideal for frequency response
measurements on filters, amplifiers and
couplers. A normalization function sets a
0 dB reference level which can be used for
absolute measurements of insertion loss or
gain.

If used with a bridge the return loss of
devices such as antennas or loads can also
be measured.

The output level of the tracking
generator is adjustable from -70 dBm to
0 dBm. It can be used as a low level input
for amplifiers, or in CW mode as a
synthesized local oscillator.

Filters can be characterized using the

optional tracking generator

Field Measurements

For measurements at remote sites in
the field the 2390A series is portable and
rugged. Mobile and cellular radio base
stations demand 24 hour reliability. The

2392A is ideal for field measurements of
spurious, harmonics and intermodulation
products. Integral frequency counter and
receiver modes mean that interfering
signals can be identified quickly and easily.

For microwave radio links the 2390A or
2393A offer frequency coverage to 22 GHz
and 26.5 GHz respectively. A wide 30 MHz
resolution bandwidth filter, and limit mask,
facilitate testing of modulated point-to­point or trunk radio links.

Monitoring signals at a cellular radio base

station

EMC Measurements

2390A series can be used for pre­compliance testing of electronic products
to meet stringent EMC specifications.
Before sending a product to an expensive
test house a pre-compliance test will
indicate if the product is likely to pass.

Option 08 provides quasi-peak
detection and five extra resolution
bandwidth filters. These comply with
the CISPR recommendations for
measurements of RF emissions.

In-built FFT and Oscilloscope

When analyzing communications
systems it is often necessary to test the
audio and IF frequencies, as well as the RF
signal. With its built-in 20 kHz FFT analyzer
and 5 MHz oscilloscope, audio analysis
and fault finding is possible. The FFT
analyzer enables harmonic distortion
measurements on audio signals and the
scope provides a general fault finding and
diagnostic tool.

Clear Operation

The 2390A series has a large 7 TFT
colour display for clear viewing of signals
and instrument settings. All key elements
such as sweep speed, resolution
bandwidth, input attenuation and IF gain
are automatically set, depending on the
users span and reference level. Two
markers can be used to measure signals as
well as provide standard operations such
as peak find, marker to centre and delta
marker. This speeds up and simplifies
measurements.

99 traces and 99 instrument settings
can be stored into the non-volatile memory
of the 2390A series. In this way tests can
be stored in the instrument and results
saved to memory for printout at a later
time. The 2390A series spectrum analyzer
is also equipped with both RS-232 and
IEEE-488 interfaces.

Applications Software

Accessory AC 1047 provides an
additional 10 measurement applications to
the 2390A series. The applications are:-

- Adjacent Channel Power

- Occupied Bandwidth

- Voltage Standing Wave Ratio

- Cable Fault

- Pulse Identification

- Noise Marker

- Carrier/Noise 1Hz Normalized

- Carrier/Noise 1.23 MHz

- Normalized

- Amps Cellular Channel Mode
Increment

All applications are supplied on a single

3.5 disk. They are downloaded into non
volatile memory in the 2390A series
spectrum analyzer.

EasySpan Software

The EasySpan software is a Windows
based program for PCs. It facilitates
viewing 2390A series traces on the PC
display without the need for spreadsheets.
Traces and set-ups may be recorded to disk
for future reference. An interactive window
allows macros to be written allowing
automatic trace acquisition. The
instrument may be connected to a modem
allowing traces to be viewed and recorded
from a remote location, for remote site
monitoring.

Active Probe

The AC2388 Active Probe covers from
50 kHz to 1.25 GHz. It enables accurate
measurements of devices from HF to UHF
without loading the circuit. A built-in
continuously variable attenuator minimizes
probe distortion during measurement.

Specification

FREQUENCY RANGE

2392A 9 kHz to 2.9 GHz
2390A 9 kHz to 22 GHz
2393A 9 kHz to 26.5 GHz
Internal Mixing (version dependent)
Band 0 0 Hz to 2.9 GHz
Band 1 2.6 GHz to 12.0 GHz
Band 2 11.5 GHz to 26.5 GHz

EXTERNAL MIXING (ALL INSTRUMENTS)

3 GHz to 300 GHz

FREQUENCY READOUT ACCURACY

±(3% of Span Width + Frequency Standard
Accuracy + 50 % of RBW)

FREQUENCY SPAN RANGE

2392A 10 Hz/div to 290 MHz/div
2390A 10 Hz/div to 2.2 GHz/div
2393A 10 Hz/div to 2.65 GHz/div
All versions have continuously variable span and zero
span (0 Hz)

ACCURACY

±5% of indicated span

FREQUENCY COUNTER
Resolution

1 Hz, 10 Hz, 100 Hz, 1 kHz

Accuracy

±(Frequency Standard Accuracy + Counter
Resolution)

Sensitivity

(at 120 MHz with 0 dB attenuation)
<-85 dBm with 3 kHz RBW

Frequency

2390A Series

2390A Series

2

http://www.ifrinternational.com

<-65 dBm with 5 MHz RBW

FREQUENCY STANDARD
Temperature Stability (0°°C - 50°°C)

±0.2 ppm
±0.02 ppm (Option 09)

Ageing

First year
±2 ppm/year
±1 ppm/year (Option 09)
Thereafter
±1 ppm/year
±0.5 ppm/year (Option 09)

RESIDUAL FM

(peak to peak in 20 ms, spans <1 MHz/div,
100 Hz video filter)
<10 Hz, below 6 GHz
<20 Hz, 6 GHz to 12 GHz
<40 Hz, 12 GHz to 26.5 GHz

NOISE SIDEBANDS

(Span <100 kHz/div)

10 kHz offset 30 kHz offset

0.1 to 1.0 GHz -97 dBc/Hz -101 dBc/Hz

1.0 to 2.8 GHz -92 dBc/Hz -95 dBc/Hz

2.8 to 6.0 GHz -93 dBc/Hz -100 dBc/Hz

6.0 to 12.0 GHz -88 dBc/Hz -95 dBc/Hz

12.0 to 26.5 GHz -81 dBc/Hz -88 dBc/Hz

SYSTEM RELATED SIDEBANDS

(at 300 Hz RBW)
<-65 dBc below 12 GHz
<-60 dBc 12 GHz to 26.5 GHz

TIME
Span >200 Hz/div

1 ms to 10 s/div in 1-2-5 sequence

Zero Span

200 ns/div to 10s/div in 1-2-5 sequence
(Resolution reduced <2 µs/div)

ACCURACY

±1% >1 µs/div

TRIGGER SOURCE

Internal (Video), External (front panel), External (rear
panel) or line (AC input)

TRIGGER MODE

Free Run, Auto Normal or Single

TRIGGER COUPLING

AC, DC, High-Pass Filter, Low-Pass Filter, TV line,
TV field

TRIGGER BANDWIDTH

>5 MHz @ -3 dB (at EXTERNAL INPUT connector)

TRIGGER LEVEL RANGE
Video

Adjustable over 8 divisions, positive or negative
polarity

Front Panel BNC

User settable threhold: -2.5 V, -1.0 V, -0.5 V, 0 V,
+0.5 V, +1.0 V, +2.5 V; nominal

Rear Panel BNC

+2.5 V nominal

TRIGGER SENSITIVITY
Internal

1 division

Front Panel BNC

200 mV peak

Rear Panel BNC

+2 V (TTL)

TRIGGER DELAY (using Zero Span)

0 to ±300 divisions in time/div to a maximum of
±200 second

MAXIMUM INPUT LEVEL

0 V DC,
+20 dBm,
+30 dBm CW >0 dB input attenuation
+50 dBm peak; 10 µs, <1% duty cycle,
>0 dB input attenuation

DISPLAYED AVERAGE NOISE LEVEL

(in 10 Hz Video Resolution Bandwidth)

3 Hz RBW 300 Hz RBW
9 kHz to 100 kHz <-115 dBm <-95 dBm
100 kHz to 2.9 GHz <-135 dBm <-115 dBm

2.9 to 12.0 GHz <-130 dBm <-110 dBm

12.0 to 26.5 GHz <-125 dBm <-105 dBm

GAIN COMPRESSION

<1.0 dB with -5 dBm (0 dB attenuation)

AMPLITUDE UNITS

Logarithmic display
dBm, dBµW, dBmV, dBmV
Linear display
mW, µW, mV, µV

DISPLAY LINEARITY
Log

5 or 10 dB/div
±0.15 dB/dB, ≤1.5 dB over 8 divisions
1 or 2 dB/div
±0.5 dB over 8 divisions

Linear
<10 MHz RBW

±2% of Reference Level over 8 divisions
10 MHz and 30 MHz RBW
±10% of Reference Level over 8 divisions
(<10 dB IF Gain)

FREQUENCY RESPONSE
(with 10 dB attenuation, relative to REF OUT)

±1.5 dB, 9 kHz to 2.9 GHz
±2.0 dB, 2.9 GHz to 12 GHz
±3.0 dB, 12 GHz to 18 GHz
±4.0 dB, 18 GHz to 26.5 GHz

RESOLUTION BANDWIDTH
Range

3 Hz, 10 Hz, 30 Hz, 100 Hz (Digital Resolution);
300 Hz, 3 kHz, 30 kHz, 300 kHz and 5 MHz (at
3 dB);
10 MHz and 30 MHz (at 3 dB) (Linear display and
FM modes)

Option 08

Additional 1 kHz and 1 MHz (at 3 dB);
200 Hz, 9 kHz and 120 kHz (at 6 dB)

Accuracy

±20%, 300 Hz to 30 kHz;
±30%, 300 kHz to 30 MHz;
±10%, 200 Hz, 9 kHz and 120 kHz

Selectivity

60 dB/3 dB ratio
<5:1, 3 kHz, 30 kHz, 300 kHz, 1 MHz, 5 MHz;
<12:1, 1 kHz;
60 dB/6 dB ratio <5:1, 9 kHz and 120 kHz;
50 dB/3 dB ratio <10:1, 300 Hz;
50 dB/6 dB ratio <10:1, 200 Hz

Switching Error

(referenced to 30 kHz RBW)
±0.5 dB, 1 kHz to 5 MHz;
±1.0 dB, <1 kHz;
±2.0 dB, 10 MHz, 30 MHz;

VIDEO BANDWIDTH
Range

10 Hz to 1 MHz in decade steps plus NONE
(no Video Filter activated)

INPUT ATTENUATOR
Range

0 to 60 dB in 10 dB steps

Accuracy

Greater of ±0.5 dB or ±2%, 9 kHz to 2.9 GHz
Greater of ±1.0 dB or ±4%, 2.9 GHz to 18 GHz
Greater of ±1.5 dB or ±7%, 18 GHz to 26.5 GHz

REFERENCE LEVEL
Range

<10 MHz RBW

-95 to +30 dBm in 0.1 dB steps
10 MHz, 30 MHz, RBW

-50 to +30 dBm in 0.2 steps

Accuracy

With 10 dB attenuation and RBW <10 MHz
±0.25 dB, -20 to -40 dBm
±0.5 dB, -40 to -85 dBm
RBW 10 MHz, 30 MHz
±2.0 dB

Offset

0 to ±99.9 dB in 0.1 dB steps

SPURIOUS RESPONSES
Harmonic Distortion

<-70 dBc, 9 kHz to 2.9 GHz
(-30 dBm input and 10 dB attenuation)
<-100 dBc, 2.9 GHz and 26.5 GHz
(-10 dBm input and 10 dB attenuation)

Third Order Intermodulation Distortion

<-80 dBc (-30 dBm input and 10 dB attenuation)
<-75 dBc ( 9 - 12 GHz only)

Residual Response

(input terminated with 50 Ω)
<-90 dBm, 9 to 100 kHz;
<-100 dBm, 100 kHz to 26.5 GHz

Other Input Related Spurious

(-30 dBm input and -10 dB attenuation)
<-70 dBc below 18 GHz
<-60 dBc 18 GHz to 26.5 GHz

DISPLAY BANDWIDTH
Linear mode

>5 MHz (-3 dB), 30 MHz RBW;
>2.5 MHz (-3 dB), 5 MHz RBW;
at <5 µs/div Sweep Time

Log mode

>1 MHz (-3 dB), 5 MHz RBW;
at <20 µs/div Sweep Time

FREQUENCY RANGE

2392A 9 kHz to 2.9 GHz
2390A 9 kHz to 22 GHz
2393A 9 kHz to 26.5 GHz

SENSITIVITY

5µV at 100 MHz (30 kHz RBW, 3 kHz Video
Bandwidth, 5 kHz FM deviation at 1 kHz rate,
10 dB SINAD with 10 dB IF Gain)

SELECTIVITY

Available analyzer RBW between 200 Hz and
300 MHz

DEMODULATION
AM Scales

10%, 20 %, 50 %/div

FM Scales

(in 1-2-5 sequence)
1 kHz to 100 kHz, <10 MHz RBW;
200 kHz to 5 MHz, 10 MHz, 30 MHz RBW

TRACE STORAGE CAPACITY

99 traces (including user defined traces and test
limits)

RECALL TO DISPLAY AT ONE TIME

4 traces

SET-UP STORAGE CAPACITY

99 set-ups

MACRO PROGRAM CAPACITY

64 kbytes

INPUT
Type

BNC (f)

Impedance

1 MΩ and 27 pF nominal

Coupling

AC, DC, GND

Voltage Range

5 mV/div to 5 V/div (±3% of Full Scale) in
1-2-5 sequence

Frequency Range

DC to >5 MHz (-3 dB) at <5 µs/div Sweep Time

INPUT

(as per oscilloscope)

AMPLITUDE
Attenuation

0 to 60 dB in 20 dB steps

Reference Level Range

2.23 mV to 22.3 V Full Scale
(-40 to +40 dBm/50 Ω reference voltage)

FFT Analyzer

Oscilloscope

Memory

Receiver

Amplitude

Sweep

2390A Series

Spectrum Analyzers

2390A Series

3

http://www.ifrinternational.com

Response

+0/-3 dB (0 Hz to 20 kHz)

DYNAMIC RANGE

80 dB

Average Noise Level

<1 µV

Spurious

<7 µV

FREQUENCY
Range

0 to 20 kHz

Span

10 to 200 Hz/div continuously variable

Bandwidth

3, 10, 30 or 100 Hz

TRIGGER FUNCTION

Selectable external trigger (time-gate) capabilities

PULSE WIDTH

>100 ns

EXTERNAL MIXER IF INPUT
Type

SMA (f)

Frequency

410.7 MHz at -30 dBm ±3 dB for top of screen
display

Compression

1 dB at >-5 dBm

EXTERNAL MIXER LO OUTPUT
Type

SMA, 50 Ω nominal (must be terminated when not
in use)

Frequency

3 to 12 GHz

Amplitude

>

+8 dBm

ANALYZER INPUT

2392, Precision Type N (f)
2390A, Precision Type N (f)
2393, Field replaceable Planar Crown with

3.5 mm (f) and Type N (f) both supplied

INPUT VSWR

(>0 dB input attenuation)
<1.3:1 <2.9 GHz - (2390A, 2393A)
<1.45:1 <2.9 GHz - (2392A)
<1.5:1 2.9 GHz to 8 GHz
<2.0:1 8 GHz to 18 GHz
<2.5:1 18 GHz to 26.5 GHz

EXTERNAL REAR TRIGGER INPUT

10 kΩ nominal

EXT REF INPUT
Type

BNC (f), 1 kΩ nominal 10 MHz at 1 to 10 Vpk-pk

PHONES OUTPUT

1/8 (3.2 mm) phone jack

REF OUT (CALIBRATOR)
Type

BNC (f), 50 Ω nominal

Frequency

100 MHz

Accuracy

Same as Frequency Standard

Amplitude

-30 dBm

Accuracy

±0.5 dB

10.7 MHz IF OUTPUT

Type BNC (f), 50 Ω nominal

410.7 MHz IF OUTPUT

Type BNC (f), 50 Ω nominal

EXT DISPLAY OUTPUT

15 pin VGA format for external color display

VIDEO OUTPUT

100 mV/div ±10% into 1 MΩ

FUNCTION CONNECTOR

External Rear Trigger, pin 8 10 kΩ nominal
Upper Limit Relay Drive, pin 13 50 V, 200 mA max
Lower Limit Relay Drive, pin 5 50 V, 200 mA max
Sweep, pin 14 0 to +5 V ramp ±0.5 V

Sweep Hold, pin 6 TTL Level

Auxiliary Video, pin 7 100 mV/div ±10% into 1 MΩ

IEEE-488 GPIB
Conforms to

IEEE-Standard 488-1987

Implemented Subsets

SH1, AH1, T1, TE0, L2, LE0, SR1, RL2, PP0, DC1,
DT1 and C0

Compatibility

IEEE-488.2 Command Set.
High Speed waveform transfer supported.

RS-232
Type

Half-duplex RS-232 (operates as slave to controller
[DTE])

Baud Rate

110, 150, 300, 600, 1200, 2400, 4800, 9600,
19200 or 38400

Handshake Modes

XON/XOFF (Software), CTS/RTS (Hardware)

Parity Check

Odd, Even or None

DIMENSIONS (ALL VERSIONS)

40.64 cm (16″) wide (including handle);

19.05 cm (7.5″) high; 55.88 cm (22″) deep

WEIGHT (WITHOUT OPTIONS)

2392 15.5 kg (34.1 lbs)
2390A 16.6 kg (36.6 lbs)
2393 16.7 kg (36.8 lbs)

POWER REQUIREMENTS
AC Line

90 to 132 Vac, 50 to 60 Hz / 400 Hz, <170 W
198 to 264 Vac, 50 to 60 Hz / 400 Hz, <170 W

ENVIRONMENT
Operating Temperature

0 to 50°C

Storage Temperature

-40 to 71°C

Temperature Change

1°C/minute for specified accuracy

Altitude

Operational 3,048 m (10,000 ft)
Nonoperational 12,192 m (40,000 ft)

ELECTRO-MAGNETIC COMPATIBILITY

Conforms with the protection requirements of EEC
Council Directive 89/336/EEC.
Complies with the limits specified in the following
standards:
EN55011-1991 (Emissions) CISPR11
EN50082-1:1992 (Immunity) IEC801-2 1991

IEC801-3: 1984
IEC801-4: 1988

EN60555-2: 1987 IEC555-2

SAFETY

Complies with IEC 1010-1.BSEN 61010-1 for class
1 portable equipment and is for use in a pollution
degree 2 environment. The instrument is designed
to operate from an installation category 2 supply.
NOTE: The 2390A series requires 15 minutes of
warm-up time to meet specifications. Specifications
only apply with TIME CALIBRATION set to ENABLE in
the Analyzer Configuration Screen Option Menu or
immediately after manually activating a TIME
CALIBRATION.

TRACKING GENERATOR (Option 02)
Frequency Range

100 kHz to 2.9 GHz

Flatness (at -10 dBm)

±2.0 dB, 100 kHz to 1 MHz;
±1.5 dB, 1 MHz to 2.9 GHz

Output Level

0 to -70 dBm in 1 dB steps

Attenuator Accuracy

±1 dB or 0.05 dB/dB

Nonharmonic Spurious

<-30 dBc

Harmonics

<-20 dBc

Leakage (Dynamic range)

-120 dBm

QUASI-PEAK DETECTOR (Option 08)

Selected Freq Charge Discharge Display
Bandwidth Range Time* Time* Time*

200 Hz 10 to 150 kHz 45 500 160
9 kHz 0.15 to 30 MHz 1 160 160

120 kHz 0.03 to 1 GHz 1 550 100

* Time is given in ms ±20%

HIGH STABILITY TIMEBASE (Option 09)
Temperature Stability

±0.02 ppm/°C

Ageing

First year ±1 ppm/year
Thereafter±0.5 ppm/year

When ordering please quote the full ordering number
information.

Ordering
Numbers Versions

2392A-110 9 kHz to 2.9 GHz Spectrum Analyzer, 110

VAC

2392A-110-C 9 kHz to 2.9 GHz Spectrum Analyzer 110

VAC with certificate of calibration

2392A-220 9 kHz to 2.9 GHz Spectrum Analyzer, 220

VAC operation

2392A-220-C 9 kHz to 2.9 GHz Spectrum Analyzer, 220

VAC with certificate of calibration

2392AT-110 9 kHz to 2.9 GHz Spectrum Analyzer,

Tracking generator, 110 VAC

2392AT-110-C 9 kHz to 2.9 GHz Spectrum Analyzer,

Tracking generator, 110 VAC, certificate of
calibration

2392AT-220 9 kHz to 2.9 GHz Spectrum Analyzer,

Tracking Generator, 220 VAC

2392AT-220-C 9 kHz to 2.9 GHz Spectrum Analyzer,

Tracking Generator, 220 VAC, Certificate of
Calibration

2392AP-110 2392A Premium (Tracking generator;

200 Hz, 1, 9 and 120 kHz Filters; Quasi­peak Detector) 110 VAC

2392AP-110-C 2392A Premium (Tracking generator;

200 Hz, 1, 9 and 120 kHz Filters; Quasi-

peak Detector) with certificate of calibration
2392AP-220 2392A Premium, 220 VAC operation
2392AP-220-C 2392A Premium, 220 VAC with certificate

of calibration
2390A-110 9 kHz to 22 GHz Spectrum Analyzer, 110

VAC operation
2390A-110-C 9 kHz to 22 GHz Spectrum Analyzer, 110

VAC with certificate of operation
2390A-220 9 kHz to 22 GHz Spectrum Analyzer, 220

VAC operation
2390A-220-C 9 kHz to 22 GHz Spectrum Analyzer, 220

VAC with certificate of calibration
2390AT-110 9 kHz to 22 GHz Spectrum Analyzer,

Tracking generator, 110 VAC
2390AT-110-C 9 kHz to 22 GHz Spectrum Analyzer,

Tracking generator, 110 VAC, with

certificate of calibration
2390AT-220 9 kHz to 22 GHz Spectrum Analyzer,

Tracking generator, 220 VAC
2390AT-220-C 9 kHz to 22 GHz Spectrum Analyzer,

Tracking generator, 220 VAC, with

certificate of calibration
2390AP-110 2390A Premium (Tracking generator;

200 Hz, 1, 9, 120 kHz Filters; Quasi-peak

Detector, 0.02 ppm high stability time

base), 110 VAC operation
2390AP-110-C 2390A Premium (Tracking generator;

200 Hz, 1, 9, 120 kHz Filters; Quasi-peak

Detector, 0.02 ppm high stability time

base), 110VAC with certificate of calibration
2390AP-220 2390A Premium, 220VAC operation
2390AP-220-C 2390A Premium, 220VAC with certificate of

calibration
2393A-110 9 kHz to 26.5 GHz Spectrum Analyzer, 110

VAC operation
2393A-110-C 9 kHz to 26.5 GHz Spectrum Analyzer, 110

VAC with certificate of calibration
2393A-220 9 kHz to 26.5 GHz Spectrum Analyzer, 220

Versions and Accessories

Options

General Characteristics

Input/Output

External Mixer

2390A Series

2390A Series

4

http://www.ifrinternational.com

VAC operation

2393A-220-C 9 kHz to 26.5 GHz Spectrum Analyzer, 220

VAC operation with certificate of calibration

2393AT-110 9 kHz to 26.5 GHz Spectrum Analyzer,

Tracking generator, 110 VAC

2393AT-110-C 9 kHz to 26.5 GHz Spectrum Analyzer,

Tracking generator, 110 VAC, with
certificate of calibration

2393AT-220 9 kHz to 26.5 GHz Spectrum Analyzer,

Tracking generator, 220 VAC

2393AT-220-C 9 kHz to 26.5 GHz Spectrum Analyzer,

Tracking generator, 220 VAC, with
certificate of calibration

2393AP-110 2393A Premium (Tracking generator;

200 Hz, 1, 9, 120 kHz filters; Quasi-peak
Detector, 0.02 ppm high stability time

base) 110 VAC
2393AP-110-C 2393AP-110, Cert. Cal
2393AP-220 2393A Premium (Tracking generator;

200 Hz, 1, 9, 120 kHz filters; Quasi-peak

Detector, 0.02 ppm high stability time

base), 220 VAC
2393AP-220-C 2393AP-220. Cert. Cal

Accessories

AC0100M Near Field Probe Set
AC0410 Maintenance Manual
AC1009M EasySpan (Waveform Transfer Software)
AC 1047 Applications library
AC1600M TMAC Programming Manual
AC2388 1 GHz Active Probe supplied with accessory

power supply
AC4101T Return Loss Bridge (5 MHz to 1 GHz)
AC4103T Return Loss Bridge (5 MHz to 2 GHz)
AC4250 75 Ω Adapter BNC/N
AC4700 Rack Mount Adapter
AC5007 Soft Padded Carrying Case
AC5009 Type SMA PLANAR CROWN Adapter (2393A

only)
AC5010 Type N PLANAR CROWN Adapter (2393A

only)
AC7800 75 Ω Adapter F/N
AC8700 UHF Antenna
5900/327 MI Plot Measurement Presentation

Software.

2390A Series

Spectrum Analyzers

2390A Series

5

http://www.ifrinternational.com

2390A Series

Part no. 46891063

Revision A

2390A Series

6

http://www.ifrinternational.com

IFR Americas, Inc., 10200 West York Street, Wichita, Kansas
67215-8999, USA. E-mail: [e-mail]
Tel: [phone] Toll Free USA: 1 800 835 2352 Fax: [phone]

As we are always seeking to improve our products, the information in this document gives only a general indication of the product capacity, performance and suitability, none of which shall form part of any

contract. We reserve the right to make design changes without notice. All trademarks are acknowledged. Parent Company IFR Systems, Inc. © IFR Ltd. 1998.

Tel: [phone] Freephone UK: 0800 282 388 Fax: [phone]

IFR Ltd, Longacres House, Norton Green Road, Stevenage, Herts

SG1 2BA, United Kingdom. E-mail: [e-mail]
