ENGLISH User Manual
■
POCKET MULTIMETER
5115
Copyright © Chauvin Arnoux®, Inc. d.b.a. AEMC®
Instruments. All rights reserved.
No part of this documentation may be reproduced in
any form or by any means (including electronic storage
and retrieval or translation into any other language)
without prior agreement and written consent from
Chauvin Arnoux
®
, Inc., as governed by United States
and International copyright laws.
Chauvin Arnoux
®
, Inc. d.b.a. AEMC® Instruments
15 Faraday Drive, Dover, NH 03820 USA
Tel: (800) 945-2362 or (603) 749-6434
Fax: (603) 742-2346
This documentation is provided “as is,” without
warranty of any kind, expressed, implied, or otherwise.
Chauvin Arnoux
®
, Inc. has made every reasonable
effort to ensure that this documentation is accurate; but
does not warrant the accuracy or completeness of the
text, graphics, or other information contained in this
documentation. Chauvin Arnoux
®
, Inc. shall not be
liable for any damages, special, indirect, incidental, or
inconsequential; including (but not limited to) physical,
emotional, or monetary damages due to lost revenues
or lost profits that may result from the use of this
documentation, whether or not the user of the
documentation has been advised of the possibility of
such damages.
Chauvin Arnoux
trademarks of Chauvin Arnoux
®
, Inc., AEMC®, are registered
®
, Inc.
2 Pocket Multimeter 5115
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments
certifies that this instrument has been calibrated using
standards and instruments traceable to international
standards.
We guarantee that at the time of shipping your
instrument has met its published specifica tions.
An N.I.S.T. traceable certificate may be requested at
the time of purchase, or obtained by returning the
instrument to our repair and calibration facility, for a
nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please use
our calibration services. Refer to our repair and
calibration section at www.aemc.com
Serial #:
Catalog #: 2154.10
Model #: 5115
Please fill in the appropriate date as indicated:
Date Received:
Date Calibration Due:
Chauvin Arnoux®, Inc.
d.b.a AEMC® Instruments
www.aemc.com
Pocket Multimeter 5115 3
.
Thank you for purchasing the AEMC Pocket
AC - Alternating
Comply with EU
directives
Multimeter Model 5115. For best results and
safety, read and follow all operating instructions
and precautions for use.
current
AC or DC
Shock Hazard
Battery
Diode
Process
according to
WEEE
2002/96/EC.
Sorting for the
recycling of
electric and
electronic waste
in the EU.
DC - Direct
current
Double insulated
Important note
Earth Ground
Danger hazard
Definition of Measurement Categories
CAT I V: Test and measurement circuits
connected to the source of the
building’s low-voltage network.
Examples: Equipment upstream of the
main fuse or building installation cut-off
switch.
4 Pocket Multimeter 5115
CAT III: Test and measurement circuits
connected to parts of the building’s low
voltage network.
Examples: Distribution switchboards,
circuit breakers, cables, busbars,
junction boxes, outlets, motors
permanently connected to the fixed
installation.
CAT II: Test and measurement circuits directly
connected to points of use (power
outlets and other similar points) on the
low voltage network.
Examples: Circuits in network for
household appliances, portable tools,
and similar instruments.
PRECAUTIONS FOR USE
Failure to comply with these safety instructions
can create a risk of electric shock, fire, and
explosion; resulting in destruction of the
instrument, injury to the user, and damage to
the facility. If the instrument is used other than
as specified in this manual, the protection
provided by the instrument may be impaired.
Before using the instrument, make sure it
functions properly by measuring a known
voltage, and check continuity by short
circuiting both test leads.
Pocket Multimeter 5115 5
Do not use the instrument in an explosive
atmosphere or in the presence of flammable
gas or smoke.
Do not use the instrument on electrical
networks with a rated voltage or category
higher than those listed for the instrument.
Be aware of the maximum rated voltages and
currents between terminals and in relation to
ground/earth.
Do not use the instrument if it appears
damaged, incomplete, or improperly closed.
Before each use, check the condition of the
housing and probes. Any instrument on which
the insulation is deteriorated (even partially)
must be set aside for repair or disposal.
Observe all environmental conditions of use.
Do not modify the instrument or replace
components using equivalent parts. Repairs
and adjustments must be performed by
qualified, approved personnel.
Replace the batteries immediately when the
symbol appears on the LCD display.
Disconnect all connections before opening
the instrument casing.
Use personal protection equipment when
conditions require it.
6 Pocket Multimeter 5115
CONTENTS
1. INTRODUCTION ...................................................... 8
1.1. Receiving Your Shipment.................................... 8
1.2. Description .......................................................... 8
1.3. Front Panel .......................................................... 9
1.4. Functions ............................................................. 9
2. SETUP .................................................................... 10
2.1. Battery Installation ............................................. 11
2.2. Instrument Check .............................................. 12
2.3. Sleep Mode ....................................................... 12
3. OPERATION .......................................................... 13
3.1. Backlight/Flashlight ........................................... 13
3.2. Data Hold ........................................................... 13
3.3. MAX Mode ......................................................... 14
3.4. AC/DC Voltage Measurement ........................... 14
3.5. Continuity Check ............................................... 15
3.6. Resistance Measurement ................................. 16
3.7. Diode Check ...................................................... 16
3.8. Non-Contact Voltage Detection (NCV) ............. 17
4. MAINTENANCE ..................................................... 18
4.1. Cleaning ............................................................ 18
4.2. Battery Replacement ......................................... 18
LIMITED WARRANTY ............................................... 22
Pocket Multimeter 5115 7
1. INTRODUCTION
1.1. Receiving Your Shipment
Upon receiving your shipment, ensure the
contents are consistent with the packing
list. Notify your distributor of any missing
items. If the equipment appears to be
damaged, file a claim immediately with the
carrier and notify your distributor at once,
giving a detailed description of any
damage. Save the damaged packing
container to substantiate your claim.
Ordering Information
Multimeter Model 5115………..Cat. #2154.10
Includes meter, soft carrying pouch, two lithium
CR2032 batteries (installed), and user manual.
1.2. Description
The Model 5115 measures AC or DC
voltage, resistance, and continuity (with
buzzer). It can also perform a diode test.
8 Pocket Multimeter 5115
