AEG-Electrolux ER8892C, ER8318C User Manual

refrigerator / réfrigérateur / kühlgeräte / frigorifero / koelkast / køleskap

INSTRUCTION BOOKLET

NOTICE D’UTILISATION

GEBRAUCHSANWEISUNG

ISTRUZIONI D’USO

GEBRUIKSAANWIJZING

BRUGSANVISNING

818 17 72--01/6

ER8318C, ER8892C

Safety instructions

Your new fridge may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using the appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or warnings contact the Customer Care Department.

For the User

· The cabinet is intended for keeping foodstuff in a

normal household as explained in this i nstruction booklet.

· Do not keep explosive gases or liquids in the

refrigerator or freezer compartment. They may explode and cause injury and material damage.

· Do not let sharp objects come into contact with

the refrigerating system on the back of and inside the cabinet. If the refrigerating system is punctured, the cabinet will be damaged and foodstuff inside may spoil.

· Do not keep carbonised drinks or bottles in the

freezer compartment. The glass bottles may break.

· The cabinet is heavy. The edges and projecting

parts of the cabinet may be sharp. Be careful when moving the cabinet and always use gloves.

Child Safety

· Pay attention so that small children do not gain

access to the operating controls or the inside of the cabinet.

Scrapping old cabinets

When discarding the cabinet, hand it over to a recycling station. For more information, call your local city office or your dealer.

instruction

Contents

Safety instructions 2.................

Scrapping ol d cabi nets 2.......................

Contents 2..........................

Description of the Appliance 3........

Control Panel 3..............................

Before use 4.........................

Using the fridge 4....................

To start the fridge and set the correct temperature 4.

Temperature inside the fridge 4.................

Measuring the temperature 4...................

Switching off 5..............................

Cabinet interior 5............................

Hints and Tips 6.....................

Saving energy 6.............................

Food Storage 6..............................

Protect the environment 6......................

Maintenance and Cleaning 6..........

Removing the ventilation grille 6................

Cleaning 6..................................

Defrosting the fridge 7........................

To Change the Light Bulb 7....................

When the appliance is not in use 7...............

Something Not Working 8............

Guarantee Conditions 9.......................

Service and Spare Parts 9......................

Technical specification 9.............

Installation 9........................

Unpacking 9................................

Remove the transport supports 9................

Cleaning 10..................................

Installing the cabinet 10........................

Electrical connection 10........................

Door Reversal 11.............................

Electrolux 818 17 72-01/6

Description of the

ppliance

1. glass shelf

2. bottle shelf

3. bottle shelf

4. egg holder

5. vegetable drawer

6. ventilation grille

7. butter compartment

8. door shelf +box

9. sliding shelf

Model ER8318C

10. door shelf

11. dividing plate between fridge and chiller

Model ER8892C

1. glass shelf

2. bottle shelf

3. bottle shelf

4. egg holder

5. vegetable drawer

6. ventilation grille

7. butter compartment

8. door shelf +box

9. sliding shelf

10. door shelf

11. dividing plate between fridge and chiller

Control Panel

A. Green indicator lamp

Lights when the fridge is operating.

B. Thermostat control

Usetoswitchonandsetthedesiredtemperaturein the fridge.

Electrolux 818 17 72-01/6

Before use

Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray.

Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 4 hours. Otherwise the compressor may sustain damage. This time will allow the oil sufficient time to return to the compressor.

Using the fridge

To start the fridge and set the correct temperature

Turn the thermostat control to the desired position. MIN The lowest position of the thermostat control results in the highest temperature inside the cabinet. MAX The highest position of the thermostat control results in the lowest temperature inside the cabinet. H : Switched off. Allow the cabinet to run for a period of 24 hours whenever the t emperature setting is changed. This will allow the temperature to stabilise inside the cabinet.

Temperature inside the fridge

A suitable temperature inside the fridge is approx. +5°C. If the thermostat control is set to a too cold temperature, food with a high water content may start to freeze if it has been placed in the coldest places in the fridge. The picture shows the coldest and warmest places inside the fridge. (+ warm, - cold) Meat, fish and milk should be put in the coldest part of the cabinet. The temperature will be affecteed by:

· How often the door is opened

· How much food is stored

· Position of the appliance (See chapter

Installation)

+ +

Measuring the temperature

If the temperature is measured using a standard, single thermometer, this should be put in a glass of water centrally placed inside the cabinet. This will reflect the temperature inside the food products. Do not place the thermometer hanging or lying directly on the shelf.

Electrolux 818 17 72-01/6
