Electric ovens
INSTRUCTION BOOKLET
Please read this instruction booklet before using the appliance
35674-1302
Mod. EOB 966
GB
Important Safety Information
You MUST read these warnings carefully before installing or using the oven. If you need assistance,
contact our Customer Care Department on 08705 950950
Installation
This oven must be installed by qualified personnel to the
relevant British Standards.
This oven is heavy. Take care when moving it.
Remove all packaging, both inside and outside the oven,
before using the oven.
Do not attempt to modify the oven in any way.
Child Safety
This oven is designed to be operated by adults. Do not
allow children to play near or with the oven.
The oven gets hot when it is in use. Children should be
kept away until it has cooled.
During Use
This oven is intended for domestic cooking only. It is not
designed for commercial or industrial purposes.
Never line any part of the oven with aluminium foil.
Do not allow heatproof cooking material, e.g. roasting
bags, to come into contact with oven elements.
Never place plastic or any other material which may melt
in or on the oven.
Do not place sealed cans or aerosols inside the oven.
They may explode if they are heated.
Do not hang towels, dishcloths or clothes from the oven
or its handle.
Do not use this oven if it is in contact with water and never
operate it with wet hands.
Take great care when heating fats and oils as they will
ignite if they become too hot.
Always use oven gloves to remove and replace food in the
oven.
Ensure that all control knobs are in the OFF position
when not in use.
Do not leave cookware containing foodstuffs, e.g. fat or
oil in or on the oven in case it is inadvertently switched
ON.
When using other electrical appliances, ensure the
cable does not come into contact with the hot surfaces
of the oven.
Maintenance and Cleaning
Always allow the oven to cool down and switch off the
electrical supply before carrying out any cleaning or
maintenance work.
Service
This oven should only be repaired or serviced by an
authorised Service Engineer and only genuine approved
spare parts should be used.
Environmental Information
After installation, please dispose of the packaging with
due regard to safety and the environment.
When disposing of an old appliance, make it unusable,
by cutting off the cable. Remove any door catches, to
prevent small children being trapped inside.
Keep this instruction book for future reference
and ensure it is passed on to any new owner.
Guide to Use the instructions
The following symbols will be found in the text to guide
you throughout the Instructions:
Safety Instructions
Step by step instructions for an operation
F
Hints and Tips
Environmental information
This appliance complies with the following E.E.C.
Directives:
* 73/23 - 90/683 (Low Voltage Directive);
* 93/68 (General Directives);
* 89/336 (Electromagnetical Compatibility
Directive) .
and subsequent modifications
Only clean this oven in accordance with the instructions.
The oven should be kept clean at all times. A build-up of
fats or other foodstuffs could result in a fire, especially in
the grill pan.
2
Contents
For the User
Important Safety Information 2
Description of the Appliance 3
Controls 4
24 hour Clock and Timer 5
Hints and Tips 7
Before the First Use 7
Using the Oven 7
Using the Fan Oven 8
Defrosting 11
Grilling 12
Cleaning the Oven 14
Cleaning the hinged grill 15
Service and Spare Parts 16
Something not working 16
For the Installer
Guarantee Conditions 17
Technical Data 18
Electrical Connection 18
Building In 19
Oven Door Protection Device
All our appliances comply with the European safety
standards. Nevertheless, in order to ensure the
highest safety level, and avoid small children to be
exposed to the heat when the appliance is operated,
it is possible to fit a special protection device to the
oven door. This device can be purchased in our
Service Force Centres, specifying the relevant code
(35791) and the Product No. shown on the rating
plate.
Description of the Appliance
Control Panel
Electronic
timer
Mains on Light
Thermostat
Control Light
Oven Function
Control Knob
Thermostat
Control Knob
Grill Element
Oven door
Rating Plate
3
Controls
Oven Function Control Knob
Oven Light - The oven light will be on without any
cooking function.
Inner grill element only - can be used for grilling
small quantities.
Double Grill - The full grill element will be on.
Thermal Grilling - This function offers an alterna-
tive method of cooking food items, normally
associated with conventional grilling. The grill
element and the oven fan operate together,
circulating hot air around the food.
Fan Oven cooking - This allows you to roast or
roast and bake simoultaneously using any shelf,
without flavour transference.
Defrost Setting - This setting is intended to assist
in thawing of frozen food.
Thermostat Control Knob
Turn the thermostat control knob clockwise to select
temperatures between 50°C and 250°C (MAX).
The Safety Thermostat
This oven is provided with a safety thermostat. In case of
malfunctioning of the main thermostat, and consequent
over-heating, the safety device will stop the power supply
to the appliance. If this happens, call your local Service
Force Centre. Under no circumstances should you
attempt to repair the appliance yourself.
Cooling fan
The cooling fan operates during cooking. Air is expelled
through vents between the oven door and the control
panel, as shown in the diagram.
The cooling fan may run on after the oven is switched off
to keep the controls cool. This is quite normal.
Accessories
Grill trivet
Grill/
Roasting pan
50
MAX
100
200
150
Anti-tip shelf (x 2)
Removable
handles
4
24 hour Clock and Timer
Minute minder
Cooking duration
End of cooking time
Manual function
Cookpot
symbol
A
A
U
U
T
T
O
O
Auto
symbol
Cookpot symbol - This will be displayed when a
program is in operation.
A
Auto symbol - This will be displayed when the
U
T
oven has been programmed for automatic
O
operation.
- + Time setting knob
The electronic timer can indicate the time of day, operate as a minute minder and automatically operate the oven.
Before the oven can be operated, the time of day must
be set on the electronic timer.
Please note that this is a 24 hour clock. For example,
2pm is shown as 14:00.
In case of loss of power, all the settings (time of day, set
program or program in operation), will be cancelled. When
the power is restored, the numbers on the display will
flash, and the timer has to be reset.
TO SET THE TIME OF DAY
F
Programming
controls
- +
Time
setting
Press buttons and , and at the same time turn
the time setting knob until the correct time of day is
displayed.
TO SET THE MINUTE MINDER
F
Press button and at the same time turn the setting
time knob until the duration time is displayed (maximum
23 hours, 59 minutes).
Our diagram shows the timer set for 35 minutes. After a
few seconds the time of day will show in the display.
To check the number of minutes remaining, press the
button. At the end of the timed period an alarm will
sound. To switch off the alarm press button .
- +
- +
5
MANUAL FUNCTION
F
Press button to set the oven for manual function.
TO SET THE TIMER TO SWITCH OFF ONLY
F
This is useful if you want to begin cooking immediately
but have the oven switch off automatically.
1. Set the oven function control knob and the thermostat
control knob on the required settings.
2. Place food in the oven.
3. Press button and, at the same time, turn the
time setting knob until the required cooking duration
is displayed.
Our diagram shows the timer set for 1 hour 10 minutes.
At the end of the cooking time the oven will switch off, an
alarm will sound. Turn the oven function and thermostat
control knob to zero. To switch off the alarm press button
.
- +
A
A
U
U
T
T
O
O
- +
TO SET THE TIMER TO SWITCH THE OVEN ON
F
AND OFF
1. Ensure the clock is showing the right time of day.
2. Carry out steps 1, 2 and 3 as explained in "To set the
timer to switch off only".
3. Press button and at the same time turn the time
setting knob until the end cooking time is displayed.
Our diagram shows the end cooking time set for 7:35
pm.
At the end of the cooking time turn the oven function and
thermostat control knob to zero.
TO CANCEL A PROGRAMME
F
1. Press button and, at the same time, turn the
time setting knob until the cooking duration is set on
"zero".
2. If the end cooking time has been set too, press button
and at the same time turn the time setting knob
until the end cooking time is set on "zero".
A
A
U
U
T
T
O
O
- +
6
Before the First Use
Remove all packaging, both inside and outside
the oven, before using the appliance.
Before first use, the oven should be heated without food.
During this time, an unpleasant odour may be emitted.
This is quite normal.
1. Set the programmer to manual function.
F
2. Switch the oven function control knob to fan
cooking .
3. Set the thermostat control knob to MAX.
4. Open a window for ventilation.
5. Allow the oven to run empty for approximately
45 minutes.
This procedure should be repeated with the grill
function for approximately 5-10 minutes.
Using the Oven
Always cook with the oven door closed.
Stand clear when opening the drop down oven door.
Do not allow it to fall open - support the door using
the door handle, until it is fully open.
The oven has four shelf levels, and is supplied with
two shelves. The shelf positions are counted from
the bottom of the oven as shown in the diagram.
It is important that these shelves are correctly
positioned as shown in the diagram.
Do not place cookware directly on the oven base.
Hints and Tips
Condensation and steam
When food is heated it produces steam in the same way
as a boiling kettle. The oven vents allow some of this
steam to escape. However, always stand back from
the oven when opening the oven door to allow any
build up of steam or heat to release.
If the steam comes into contact with a cool surface on
the outside of the oven, e.g. a trim, it will condense and
produce water droplets. This is quite normal and is not a
fault with the oven.
To prevent discoloration, regularly wipe away
condensation and also soilage from surfaces.
4
3
2
1
FO 0336
Do not use baking trays larger than 30 cm x 35 cm
(12 in x 14 in) as they will restrict the circulation of
heat and may affect performance.
The effects of dishes
on cooking results
Dishes and tins vary in their thickness, conductivity,
colour, etc. which affects the way they transmit heat to
the food inside them.
Cookware
Use any oven proof cookware which will withstand
temperatures of 250°C.
Baking trays, oven dishes, etc. should not be placed
directly against the grid covering the fan at the back
of the oven, or placed on the oven base.
A Aluminium, earthenware, oven glassware and bright
shiny utensils reduce cooking and base browning.
B Enamelled cast iron, anodized aluminium, aluminium
with non-stick interior and coloured exterior and dark,
heavy utensils increase cooking and base browning.
7
Using the Fan Oven
The air inside the oven is heated by the element around
the fan situated behind the back panel. The fan circulates
hot air to maintain an even temperature inside the oven.
The advantages of cooking with this function are:
l Faster Preheating
As the fan oven quickly reaches temperature, it is not
usually necessary to preheat the oven although you may
find that you need to allow an extra 5-7 minutes on
cooking times. For recipes which require higher
temperatures, best results are achieved if the oven is
preheated first, e.g. bread, pastries, scones, souffles,
etc.
l Lower Temperatures
Fan oven cooking generally requires lower temperatures
than conventional cooking.
Follow the temperatures recommended in the cooking
chart or remember to reduce temperatures by about 2025°C for your own recipes which use conventional cooking.
l Even Heating for Baking
The fan oven has uniform heating on all shelf positions.
This means that batches of the same food can be cooked
in the oven at the same time. However, the top shelf may
brown slightly quicker that the lower one.
This is quite usual. There is no mixing of flavours between
dishes.
How to Use the Fan Oven
F
1. Turn the oven function control knob to .
2. Turn the thermostat control to the required temperature.
THINGS TO NOTE
The oven light will come on when the oven function
control knob is set.
The oven fan will operate continually during cooking.
The thermostat control light will remain on until the
correct temperature is reached. It will then cycle on
and off to show the temperature is being maintained.
FO 2079
8
Cooking Chart
This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your
individual requirements. Only experience will enable you to determine the correct setting for your personal requirements.
Food Shelf Cooking
Position Temp (°C)
Biscuits 180-190
Bread 210-220
Casseroles 130-140
Cakes: Small and queen 160-170
Sponges 160-170
Madeira 140-150
Rich Fruit 130-140
Christmas 130-140
Meringues 90-100
Fish 170-190
Fruit Pies and Crumbles 190-200
Milk Puddings 130-140
Pastry: Choux
Shortcrust
Flaky
Puff
Plate Tarts 180
Quiches/Flans 170-180
Scones 210-220
Roasting: Meat & Poultry 160-180
}
Shelf
positions
are not
critical but
ensure that
oven
shelves are
evenly
spaced
when more
than one is
used.
190-200
When roasting, ensure the meat is cooked thoroughly, use a meat thermometer if preferred to check the centre
temperature has reached the required temperature (see table below).
MEAT TEMPERATURES
Beef Rare - 60°C
Medium - 70°C
Well Done - 80°C
Pork Well Done - 80°C
Lamb Medium - 70°C
Well Done - 80°C
9
Hints and Tips
Shelf positions are not critical, but make sure the shelves
are evenly spread.
When cooking more than one dish in the fan oven, place
dishes centrally on the shelves rather than several dishes
on one shelf.
When the oven is full, you may need to allow slightly
longer cooking time.
A shelf may be placed on the floor of the oven. Place
dishes on a shelf in this position rather than on the oven
base, to allow air circulation around the food.
When the oven is full of the same food, e.g. equal trays
of small cakes or equal size victoria sandwich cakes,
then they will be cooked in the same time and removed
from the oven together. When different sizes of trays or
types of food, e.g. biscuits and cakes are cooked, they
will not necessarily be ready together.
The fan oven can be used to heat foods through without
thawing first, e.g. fruit tarts, mince pies, sausage rolls,
and other small pastry items. Use a temperature of 190200°C and allow 20-40 minutes (depending on the quantity
of food in the oven).
The use of too high temperatures can cause uneven
browning. Check with the recommendations for oven
temperatures given in the cooking charts, but be prepared
to adjust the temperature by 10°C if necessary. Remember
to reduce temperatures by about 20-25°C for your own
conventional recipes.
When roasting do use the trivet in the meat tin. Fat and
meat juices will drain into the meat tin below and can be
used to make gravy. The trivet also prevents splashes of
fat from soiling the oven interior.
The meat tin should not be placed on a heated hotplate
as this may cause the enamel to crack.
10
Defrosting
The oven fan operates without heat and circulates the
air, at room temperature, inside the oven. This increases
the speed of defrosting. However, please note that the
temperature of the kitchen will influence the speed of
defrosting.
This function is particularly suitable for delicate food which
could be damaged by heat, e.g. cream filled gateaux,
iced cakes, pastries, bread and other yeast products.
How to Use Defrosting
F
1. Turn the oven function control knob to .
2. Ensure the thermostat control knob is in the OFF
position.
Food
Defrosting time
(Mins)
Standing time
Hints and Tips
Cover food with a lid, aluminium foil or plastic film to
prevent drying out during defrosting.
ALWAYS COOK THOROUGHLY IMMEDIATELY
AFTER THAWING.
Frozen food should be placed in a single layer when
ever possible and turned over half way through the
defrosting process.
Only joints of meat and poultry up to 2 kg. (4 lb.) are
suitable for defrosting in this way.
Refer to the following table for approximate defrosting
times.
(Mins)
Notes
Chicken 1000 g. 100-140 20-30 Place the chicken on an inverted
saucer on a large plate. Defrost open
and turn at half time or defrost
covered with foil. Remove giblets
as soon as possible.
Meat 1000 g. 100-140 20-30 Defrost open and turn at
half time or cover with foil
Meat 500 g. 90-120 20-30 As above
Trout 150 g. 23-35 10-15 Defrost open
Strawberries 300 g. 30-40 10-20 Defrost open
Butter 250 g. 30-40 10-15 Defrost open
Cream 2 x 200 g. 80-100 10-15 Defrost open (cream is
easy to whip even if parts
of it are still slightly frozen)
Cake 1400 g. 60 60 Defrost open
The times quoted in the chart should be used as a guide only, as the speed of defrosting will depend on the kitchen
temperature. For example, the colder the ambient temperature, the longer the defrosting time.
11
Grilling
Grilling must be carried out with the oven door
closed. The grill pan handles must be removed
from the pan.
How to Use the Grill
F
1. Turn the oven control function knob on .
2. Turn the thermostat control knob on the required temperature.
3. Adjust the grid and grill pan runner position to allow
for different thicknesses of food. Position the food
close to the element for faster cooking and further
away for more gentle cooking.
Preheat the grill on a full setting for a few minutes before
sealing steaks or toasting. Adjust the heat setting and
the shelf as necessary, during cooking.
During cooking, the cooling fan and the thermostat
control light will operate in the same way as described
for the fan oven function.
Hints and Tips
- Most foods should be placed on the grid in the grill
pan to allow maximum circulation of air to lift the food
out of the fats and juices. Food such as fish, liver and
kidneys may be placed directly on the grill pan, if
preferred.
- Food should be thoroughly dried before grilling to
minimise splashing. Brush lean meats and fish lightly
with a little oil or melted butter to keep them moist
during cooking.
- Accompaniments such as tomatoes and mushrooms
may be placed underneath the grid when grilling
meats.
- When toasting bread, we suggest that the top runner
position is used.
- The food should be turned over during cooking, as
required.
The grill element is controlled by the thermostat.
During cooking, the grill cycles on and off to
prevent overheating.
How to Use the Inner Grill
F
Element
The inner grill provides quick direct heat to the central
area of the grill pan. By using the inner grill element for
cooking small quantities, it can help to save energy.
1. Turn the oven control function knob on .
2. Turn the thermostat control knob on the required temperature.
3. Adjust the grid and grill pan runner position to allow
for different thicknesses of food and follow the
instructions for grilling.
How to Use the Thermal
F
Grill
Thermal grilling offers an alternative method of cooking
food items normally associated with conventional grilling.
The grill element and the oven fan operate alternately,
circulating hot air around the food. The need to check
and turn the food is reduced. Thermal grilling helps to
minimize cooking smells in the kitchen.
With the exception of toast and rare steaks, you can
thermally grill all the foods you would normally cook
under a conventional grill. Cooking is more gentle,
therefore food generally takes a little longer to cook with
thermal grilling compared with conventional grilling. One
of the advantages is that larger loads can be cooked at
the same time.
1. Turn the oven control function knob on .
2. Turn the thermostat control knob on the required temperature. Select a maximum temperature of 200°C
and do not exceed 1 hour of operation.
3. Adjust the grid and grill pan runner position to allow
for different thicknesses of food and follow the
instructions for grilling.
12
Hints and Tips
Prepare foods in the same way as for conventional grilling.
Brush lean meats and fish lightly with little oil or butter to
keep them moist during cooking.
A general guide to cooking times is given below but these
times may vary slightly depending on the thickness and
quantity of food being cooked.
Cooking Chart - Grilling
FOOD Grill and Inner Grill Element Thermal Grill
Temp
(°C)
Bacon Rashers 210 2-3 200 8-12
Beefburgers 200 6-10 190 10-15
Chicken Joints 170 10-15 160 35-45
Chops - Lamb 180 7-10 170 20-25
- Pork 180 10-15 170 25-35
Fish - Whole Trout/Herring 170 8-12 170 10-20
- Fillets Plaice/Cod 170 4-6 170 10-20
Kebabs 180 10-15 170 20-30
Kidneys - Lamb/Pig 170 4-6 180 10-15
Liver - Lamb/Pig 170 5-10 180 20-30
Sausages 180 10-15 190 10-15
Toast 250 1-2 --
Heating through and
Browning, e.g. au-gratin, - - 170 20-30
lasagne, shepherd's pie.
Browning dishes only 230 3-5 --
Time
(Mins per side)
Temp
(°C)
depending on size depending on size
Time
(Mins)
13
Cleaning the Oven
Before cleaning always allow the cooling fan to
cool the cooker down before switching off at the
electricity supply.
The oven should be kept clean at all times. A buildup of fats or other foodstuffs could result in a fire,
especially in the grill pan.
Cleaning materials
Before using any cleaning materials on your oven, check
that they are suitable and that their use is recommended
by the manufacturer.
Cleaners that contain bleach should NOT be used as
they may dull the surface finishes. Harsh abrasives
should also be avoided.
External cleaning
Regularly wipe over the control panel, oven door and door
seal using a soft cloth well wrung out in warm water to
which a little liquid detergent has been added.
To prevent damaging or weakening the door glass
panels avoid the use of the following:
Household detergent and bleaches
Impegnated pads unsuitable for non-stick
saucepans
Brillo/Ajax pads or steel wool pads
Chemical oven pads or aerosols
Rust removers
Bath/Sink stain removers
Oven Cavity
The enamelled oven cavity is best cleaned whilst the oven
is still warm.
Wipe the oven over with a soft cloth soaked in warm soapy
water after each use. From time to time it will be
necessary to do a more thorough cleaning, using a
proprietary oven cleaner.
If the soilage has become set, after the oven has cooled
down, the following process will help to soften the splatters
to help make cleaning easier.
1. Place the grill/ meat pan on the oven shelf
F
positioned in the lowest runner.
2. Add a few drops of washing-up liquid to the pan
and fill to about 12 mm. with boiling water from the
kettle.
3. Close the oven door, turn the oven function
knob on fan oven and set the thermostat knob
on 50°C.
4. After 15 minutes, turn off the thermostat and
allow the fan oven to continue without heat for a
further 5 minutes, when the temperature of the
water will have cooled down.
5. Carefully remove the pan of water from the oven
and use normal oven cleaners to clean away soil
residues.
6. Leave a small amount of soapy water to soak
into any burned on spillage on the floor of the oven
for a longer time if necessary.
Oven Shelves
Clean the outer and inner door glass using warm soapy
water. Should the inner door glass become heavily soiled
it is recommended that a cleaning product such as Hob
Brite is used.
DO NOT clean the oven door while the glass panels
are warm. If this precaution is not observed the
glass panel may shatter.
If the door glass panel becomes chipped or has
deep scratches, the glass will be weakened and
must be replaced to prevent the possibility of the
panel shattering. Contact your local Service Force
Centre who will be pleased to advise further.
To clean the oven shelves, soak in warm soapy water
and remove stubborn marks with a well wetted soap
impregnated pad. Rinse well and dry with a soft cloth.The
shelf supports can be removed for easy cleaning (see
diagram). Please, ensure the retaining nuts are secure
when refitting the shelf support.
FO 0145
14
Replacing the Oven Light
Disconnect the appliance
If the oven bulb needs replacing, it must comply with the
following specifications:
- Electric power: 15W,
- Electric rate: 230-240 V (50 Hz),
- Resistant to temperatures of 300°C,
- Connection type: E14.
These bulbs are available from your local Service Force
Centre.
To replace the faulty bulb:
1. Ensure the oven is disconnected from the electrical
supply.
2. Turn the glass cover anticlockwise.
3. Remove the faulty bulb and replace with the new one.
4. Refit the glass cover.
5. Reconnect to the electrical supply.
Cleaning the hinged grill
FO 0287
This model has been fitted with a hinged grill element to
enable you to clean the roof of the oven easily.
Before proceeding ensure the oven is cool and
is isolated from the electricity supply.
1) Undo the screws which holds the grill in place
F
(see diagram). When doing this operation for the
first time, we recommend using a screwdriver.
2) Then gently pull the grill downward to allow
access to the oven roof (see diagram).
3) Clean the oven roof with a suitable cleaner and
wipe dry before replacing the hinged grill element.
4) Gently push up the grill element into place and
firmly screw into place the holding nuts.
Ensure the grill holding nuts are firmly in place to
avoid the grill falling down when in use.
15
Something not working
If the appliance is not working correctly, please carry out the following checks, before contacting your local Service
Force Centre.
IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation,
a charge will be made even if the appliance is under guarantee.
SYMPTOM
n The oven does not come on
n The oven temperature light does not come on
n The oven light does not come on
n It takes too much time to finish the dishes, or they are
cooked too fast.
SOLUTION
u Check the oven is in manual operation and that both a
cooking function and temperature have been selected.
u Check the appliance is wired in properly, and the socket
switch or the switch from the mains supply to the oven
are ON.
u Select a temperature with the thermostat control knob
u Select a function with the oven function control knob.
u Select a function with the oven function control knob
u Check the light bulb, and replace it if necessary (see
"Cleaning the Oven")
u The temperature may need adjusting
u Refer to the contents of this booklet, especially to the
chapter Using the Oven.
n Steam and condensation settle on the food and the
oven cavity.
n The programmer does not work
n The oven fan is noisy
u Leave dishes inside the oven no longer than 15-20
minutes after the cooking is completed.
u Check the instructions for the programmer.
u Check that shelves and bakeware are not vibrating in
contact with the oven back panel.
Service and Spare Parts
In the event of your appliance requiring service, or if you
wish to purchase spare parts, please contact your local
Service Force Centre by telephoning:
0870 5 929929
Your telephone call will be automatically routed to the
Service Force Centre covering your post code area.
For the address of your local Service Force Centre and
further information about Service Force, please visit the
website at www.serviceforce.co.uk
Before calling out an engineer, please ensure you have
read the details under the heading Something Not
Working.
When you contact the Service Force Centre you will need
to give the following details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found
on the rating plate)
5. The purchase date
Please note that a valid purchase receipt or
guarantee documentation is required for inguarantee service calls.
16
Customer Care Department
For general enquiries concerning your Electrolux
appliance and for further information on Electrolux
products, contact our Customer Care Department by letter
or telephone as follows:
Customer Care Department
Electrolux
55-77 High Street
Slough
Berkshire SL1 1DZ
Tel : 08705 950950 (*)
* calls to this number may be recorded for training purposes.
Guarantee Conditions
Electrolux Standard Guarantee
conditions
We, Electrolux, undertake that if, within 12 months of the date
of the purchase, this Electrolux appliance or any part thereof
is proved to be defective by any reason only of faulty
workmanship or materials, we will, at our option, repair or
replace the same FREE OF ANY CHARGE for labour,
materials or carriage on condition that:
* The appliance has been correctly installed and used only
on the gas and electricity supply stated on the rating
plate.
* The appliance has been used for normal domestic
purposes only, and in accordance with the
manufacturer's instructions.
* The appliance has not been serviced, maintained,
repaired, taken apart or tampered with by any person not
authorised by us.
* All service work under this guarantee must be
undertaken by a Electrolux Service Force Centre.
* Any appliance or defective part replaced shall become
the Company's property.
* This guarantee is in addition to your statutory and other
legal rights.
Home visits are made between 8.30am and 5.30pm
Monday to Friday. Visits may be available outside these
hours, in which case a premium will be charged.
Exclusions
This guarantee does not cover:
* Damage or calls resulting from transportation, improper
use or neglect, the replacement of any light bulbs or
removable parts of glass or plastic.
* Costs incurred for calls to put right an appliance which
is improperly installed or calls to appliance outside the
United Kingdom.
* Appliances found to be in use within a commercial or
similar environment, plus those which are the subject to
rental agreements.
* Products of Electrolux manufacture which are not
marketed by Electrolux.
European Guarantee
If you should move to another country within Europe then
your guarantee moves with you to your new home subject
to the following qualifications:
* The guarantee starts from the date you first purchased
your product.
* The guarantee is for the same period and to the same
extent for labour and parts as exist in the new contry of
use for this brand or range of products.
* This guarantee relates to you and cannot be transferred
to another user.
* Your new home is within the European Community (EC)
or European Free Trade Area.
* The product is installed and used in accordance with our
instructions and is only used domestically, i.e. a normal
household
The electrical supply complies with the specification
given in the rating label.
* The product is installed taking into account regulations
in your new country.
Before you move, please contact your nearest Customer
Care centre, listed below, to give them details of your new
home. They will then ensure that the local Service
Organisation is aware of your move and able to look after
you and your appliances.
France Senlis +33 (0) 3 44 62 20 13
Germany Nürnberg +49 (0) 800 234 7378
Italy Pordenone +39 (0) 800117511
Sweden Stockholm +46 (0) 20 78 77 50
UK Slough + 44 (0) 1753 219898
17
Technical Data
Dimensions of recess
Height 580 mm.
Width 560-570 mm.
Depth 550 mm.
Dimensions of the oven cavity
Height 325 mm.
Width 420 mm.
Depth 390 mm.
Oven capacity 53 litres
Heating elements rating
Circular heating element 2.08 kW
Inner Grill element 1.83 kW
Double Grill element 2.66 kW
Oven Light 15 W
Cooling Fan 25 W
Convection Fan 30 W
Total Rating 2.70 kW
Electrical Connection
The oven is designed to be connected to 230-240V (50Hz)
electricity supply.
The oven has an easily accessible terminal block which
is marked as follows:
Letter L - Live terminal
Letter N - Neutral terminal
or E - Earth terminal
It is necessary that you install a double pole switch
between the oven and the electricity supply (mains), with
a minimum gap of 3mm between the switch contacts and
of a type suitable for the required load in compliance with
the current rules.
The switch must not break the yellow and green earth
cable at any point.
THIS OVEN MUST BE EARTHED
The cable used to connect the oven to the electrical
supply must comply to the specifications given below.
For Uk use only
Connection Min. size Cable / flex Fuse
via Cable/flex type
13 A socket 2.5 mm
outlet butyl min.
13 A insulated
spur box
Cooker 2.5 mm
Control twin and 20 A
Circuit earth
2
3 core 13 A
2
PVC/PVC
For Europe use only
Min. size Cable/flex Cable / flex type Fuse
1.5 mm
2
H07 RN-F, H05 RN-F, 13 A
H05 RR-F, H05 VV-F,
H05 V2V2-F (T90),
H05 BB-F
Important
After installation and connecting, the cable must be
placed so that it cannot at any point reach a temperature
of more than 60°C above the ambient temperature.
Before the oven is connected, check that the main fuse
and the domestic installation can support the load; and
that the power supply is properly earthed.
The manufacturer disclaims any responsibility should
these safety measures not be carried out.
18
Building In
Please ensure that when the oven is installed it is
easily accessible for the engineer in the event of a
breakdown.
Building In
The surround or cabinet into which the oven will be built
must comply with these specifications:
l the dimensions must be as shown in the relevant
diagrams;
l the materials must withstand a temperature increase
of at least 60°C above the ambient temperature;
l proper arrangements must be made for a continuous
supply of air to the oven to prevent the oven overheating.
Dimensions of the oven and recess required are given in
the relevant diagrams.
FO 0374
FO 0292
Securing The Oven To The
Cabinet
1. Fit the oven into the cabinet recess,
2. Open the oven door
3. Secure the oven to the kitchen cabinet with four wood
screws, which fit the holes provided in the oven fra-
me.
FO 0290
FO 0039
19
CUSTOMER CARE
Electrolux
Grafiche MDM - Forlì
55-77 High Street
Slough
Berkshire, SL1 1DZ
Tel:
08705 950950
© Electrolux Household Appliances Limited 2002
The Electrolux Group. The worlds No.1 choice.
The Electrolux Group is the worlds largest producer of powered appliances for kitchen, cleaning and outdoor use. More than
55 million Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers)
are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
02/02
Loading...
