AEG-Electrolux EKM90460X User Manual

Page 1
- GB -
Instructions booklet
mod. EKM 90460 X
EKM 10460 X
Page 2
GB
GENERAL INFORMATION
SAFEGUARDING THE ENVIRONMENT
Packaging disposal
Sort packaging into different materials (cardboard, polystyrene etc.) and dispose of them in accordance with local waste disposal laws.
This appliance complies with the following
European Directives:
- 2006/95/EEC regarding "Low Voltage".
- 89/336/EEC regarding "Electromagnetic Disturbances".
- 90/396/EEC regarding Gas appliances
- 89/109/EEC regarding "Materials in contact with food"
- Moreover the above mentioned Directives comply with Directive 93/68/EEC.
- This appliance must be installed in
accordance with the regulations in force and must only be used in well ventilated rooms. Consult the instructions booklet before installing and using the appliance.
- This household appliance has been designed for cooking and it must therefore be used for this purpose only.
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly,you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment,recovery
and recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
DEAR CUSTOMER,
 Carefully read these instructions before using the appliance and keep them for future consultation.  Keep potentially hazardous packaging (plastic bags, polystyrene etc.) out of the reach of children.
WARRANTY
Your new appliance is covered by a warranty. The warranty certificate is herewith enclosed. If it is missing, ask the retailer for it, indicating date of purchase, model, and data plate number which are printed on the data plate identifying the appliance (fig. 9 ). Keep the part intended for the user, and show it upon request to the After-sales Service, along with proof of purchase. If you fail to do so, the after-sales service will be obliged to charge you in full for any repair work carried out. Original spare parts should be purchased only from our After-sales Service and Spare Parts Authorised Centres.
AFTER-SALES SERVICE
Before leaving the factory, this appliance has been tested and set up by skilled personal, in order to ensure optimum performance. Any repair or intervention subsequently required must be carried out with the utmost care and attention. For this reason, we recommend you always contact the Sales Centre or your nearest After­sales Service. Always specify the nature of the problem and the appliance model.
*
2
Page 3
GB
RECOMENDATIONS AND PRECAUTIONS
ATTENTION:
The use of a gas cooking appliance results in the production of heat and moisture in the room in which it is installed. Ensure that the kitchen is well ventilated: keep natural ventilation holes open or install a mechanical ventilation device (mechanical extractor hood). Prolonged intensive use of the appliance may call for additional ventilation, for example opening of a window, or more effective ventilation, for example increasing the level of mechanical ventilation where present. Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible.
- Before using the appliance, remember to remove the protective plastic film present on some parts of the appliance (facia-panel, parts in stainless steel, etc.)
- Do not use the appliance for the purpose of heating.
- When the appliance is not in use, we recommend
electricity and shut the gas tap.
IN THE EVENT OF FIRE:
 In the event of fire,
main valve of the gas supply, unplug the appliance from the mains. Never, under any circumstances, pour water on burning
oil.
 Do not store flammable products or aerosol
containers near the burners, and do not vaporize them near lighted burners.
you unplug it from the mains
immediately shut the
FOR YOUR SAFETY AND THAT OF YOUR CHILDREN.
 Do not store items that are attractive to
children above or near the appliance.
 Keep children well away from the appliance:
bear in mind that some parts of the appliance and the pans become dangerously hot during use, and that they take a while to cool down.
 In order to avoid any unintentional accidents,
pan handles should be turned inwards to the rear of the cooker, not outwards into the room or over adjacent burners.
When cooking, do not use clothes with large
flared sleeves; in case of accidental contact with a lit burner.
The appliance must not be used by people (including children) with limited physical, sensory or mental abilities, or without experience or expertise, unless they have received instructions for using it from those responsible for their safety. Young children should be supervised to ensure they not play with the appliance.
WARNING - OVEN: When the oven or the grill are in use, accessible parts can become very hot; it is necessary to keep children well away from the appliance.
- Never cook food on the base of the oven.
- Keep fingers away from the area of the hinges when closing the door as it is possible to trap them.
- Do not let children sit down on or play with the oven door. Do not use the drop down door as a stool to reach cabinets above.
WARMING DRAWER DO not place inflammable materials or plastic
utensils in the warming drawer (situated below the ovens).
3
Page 4
1
2
3
4
5
6
7
8
9
10
11
12
1 Electronic clock 2 Oven indicator light ( main oven ) 3 Oven indicator light ( function ) 4 Oven indicator light ( second oven) 5 Control knob function ( main oven ) 6 Thermostat knob ( main oven ) 7 Control knob function ( second oven )
GB
Control panel
8 Control knob ( rapid burner left ) 9 Control knob ( semi rapid burner left ) 10 Control knob ( Triple crown burner ) 11 Control knob ( semi rapid burner right ) 12 Control knob ( auxiliary burner )
1
2
3
5
4
6
7
8
9
10
11
12
4
Page 5
GB
COOK-TOP USE
USING THE GAS BURNERS
The following symbols are found on the control panel next to each knob:
- Circle gas off
- Large flame maximum setting
- Small flame minimum setting
The minimum position is at the end of the anti­clockwise rotation of the knob. Knob positions must be set between max. and min.; never set the knobs between max. and off.
MANUAL IGNITION (during mains power failure)
To ignite the burner, press the knob of the selected burner and turn it anticlockwise to the
maximum position then light with a match.
AUTOMATIC ELECTRIC IGNITION
To ignite the burner, press the knob of the selected burner and turn it anticlockwise to
maximum position. Keeping the knob
the pressed in, the automatic ignition of the burner will operate. In case of power failure, the burner can also be lit using a match.
ENERGY SAVING TIPS
 The diameter of the pan bottom should be the same as that of the burner. The burner flame must never exceed the pans diameter.  Use flat-bottomed pans only.  Whenever possible, keep a lid on the pan while cooking. This allows you cook using less heat.  Cook vegetables, potatoes, etc. with as little water as possible to reduce cooking times.
BURNERS PANS
Ø min. Ø max RAPID 180 mm 220 mm SEMIRAPID 120 mm 200 mm AUXILIARY 80 mm 160 mm TRIPLE CROWN 220 mm 260 mm
5
Page 6
GB
USING THE ELECTRIC OVEN
Before the first use of the oven
The first time the oven is used, it may give off smells, these are caused by residues left by the production processes and is quite normal.
Ensure there is adequate ventilation
in the room before performing this action.
(It is necessary to heat up the oven at the maximum temperature for about 30-40 minutes in order to burn off these residues).
It is perfectly normal for the oven to smoke when first used; wait for the smoke to stop before placing food into the oven.
Conventional cooking table
Dish Temp. °C. Minutes Fish 180-240 acc. to size Meat
Roast Roast veal 200-220 30 per kg. Chicken 200-240 50 about Duck and goose 220 acc. to weight Leg of mutton 250 30 per kg. Roast pork 250 60 per kg. Soufflés 200 60 per kg.
Sweets (pastries)
Tea-cake 160 50-60 Sponge finger 160 30-50 Shortcrust pastry 200 15 Puff pastry 250 15 Fruit flan 200-220 30 Meringues 100 60 Quiches, etc. 220 30 Quick sponge 120-140 60 Buns 160-180 45
beef 250 30 per kg.
The oven is fitted with: a grill shelf for cooking food in oven dishes or for placing directly on the grill shelf itself, a drip-tray for cooking sweets, biscuits, pizzas, etc., or for collecting juices and fats from food cooked directly on the grill shelf. Note: The following tables provide a guide for cooking some of the most popular dishes. The cooking times recommended in these tables are approximate. After a few attemps, we are sure that you will be able to adjust the times to get the results you want.
ATTENTION: Always use the oven with the oven door closed.
6
Page 7
GB
Fan oven cooking table
Dish Temp. °C. Minutes Weight kg.
t courses
Firs
Lasagne 200-220 20-25 0,5 Oven
-baked pasta 200-220 25-30 0,5 Creole rice 200-230 20-25 0,5 Pizza 210-230 30-45 0,5
Meat
Roast veal 160-180 65-90 1-1,2 Roast pork 160-170 70-100 1-1,2 Roast beef 170-190 40-60 1-1,2 Roast beef joint 170-180 65-90 1-1,2 Roast fillet beef (rare) 180-190 40-45 1-1,5 Roast lamb 140-160 100-130 1,5 Roast chicken 180 70-90 1-1,2 Roast duck 170-180 100-160 1,5-2 Roast goose 160-180 120-160 3-3,5 Roast turkey 160-170 160-240 5 approx. Roast rabbit 160-170 80-100 2 approx. Roast hare 170-180 30-50 2 approx. Fish 160-180 acc. to weight
Sweets (pastries)
Fruit flan 180-200 40-50 Plain sandwich cake 160-180 35-45 Sponge sandwich cake 200-220 40-45 Sponge cake 200-230 25-35 Currant cake 230-250 30-40 Buns 170-180 40-60 Strûdel 160 25-35 Cream slices 180-200 20-30 Apple fritters 180-200 18-25 Sponge finger pudding 170-180 30-40 Sponge finder biscuits 150-180 50-60 Toasted sandwiches 230-250 7 Bread 200-220 40
7
Page 8
GB
WARNING
Accessible parts will become hot when in use. To avoid burns and scalds children should be kept away. Do not touch the heated elements inside the oven.
CONVECTION OVEN The oven is fitted with:
 a lower heating element;  an upper heating element.
It is possible to select the desired temperature into the oven by turning clockwise the thermostat knob and depending on the models, one or more functions:
Oven off
Oven light
60 - max Upper + lower heating element on
Upper heating element on
Lower heating element on
Grill element on + turnspit
Note: The appliance must be used with the oven door closed.
MULTIFUNCTIONAL OVEN The oven is fitted with:
 a lower heating element;  an upper heating element;  a circular heating element surrounding the fan. N.B.: Always set the temperature on the thermostat knob before selecting any of the functions.
Oven thermostat knob
To obtain an oven temperature between 50°C and MAX°C, turn the knob clockwise.
0
MAX
50
75
100
125
225
200
175
150
90
60
130
0
170
200
MAX
Oven selector knob
It is possible to select one of the following functions turning the
selector knob clockwise.
0
Note:
All the functions mentioned above, switch the oven light on. A warning light on the control panel will stay lit until the selected temperature is reached; after it will light up intermittently.
8
Page 9
Use of the oven The appliance must be used with the oven door closed.
Note: ovens with separate thermostat and function selectors. When the functions are used, place the thermostat knob between 180 ÷ 200°C as maximum temperature.
GB
Medium grill
It is ideal for grilling and gratinating small quantities of traditional food. The thermostat knob must be placed on the maximum position.
ATTENTION:
The temperature shown on the control panel corresponds to the temperature in the oven centre only when the functions selected are or .
Oven lamp
When you turn the control knob to this position, the light will be on for all the following operations.
Defrosting with fan
The air at ambient temperature is distributed inside the oven for defrosting food faster.
Natural convection
Both the lower and upper heating elements operate together. This is the traditional cooking, very good for roasting joints, ideal for biscuits, baked apples and crisping food. You obtain very good results when cooking on a shelf adjusting the temperature between 50 and MAX°C.
Full grill
It is ideal for grilling and gratinating traditional food. Set the thermostat control knob to the 200°C position.
Thermal grilling
The air which is heated by the grill element is circulated by the fan which distributes the heat on the food. The fan assisted grill function can replace the need to use the rotisserie. You can obtain very good results also with large quantities of poultry, sausage, red meat. Set the thermostat control knob to the 200°C position.
Air forced lower heating element
The air which is heated by the lower heating element is circulated by the fan which distributes the heat on the food . This function can be used between 50° and MAX°C.
Fan oven
Both the fan and the circular heating element operate together. The hot air is adjustable between 50 and MAX°C and is evenly distributed inside the oven. This is ideal for cooking several types of food (meat, fish etc) at the same time without affecting taste and smell. It is ideal for delicate pastries.
9
Page 10
GB
USE OF THE GRILL
Install the grid on the third shelf from the oven bottom, at about 12 cm from the surface.
The shelf position can be changed as required depending on personal taste and the type of food.
Heat the oven 5 minutes before introducing the food.
USE OF THE TURNSPIT
To use the turnspit follow the instructions below.
- Thread the chicken or cubes of meat for roasting on the spit L. Ensur
e that it is secured properly between the two forks F and balanc unnecessary strain on the tra
e it correctly to avoid
nsmission R
(fig 4).
-
Rest the spit on the support G, after having fitted the opposite end into socket P of the transmission R (fig 4)
- Place the drip-tray with some water under the turnspit, on the lowest level.
- To remove the spit, operate in the opposite direction using knob A and protecting gloves (see fig. 4).
To operate the turnspit, turn the knob to position .
Fig. 4
R
P
2
F
L
A
1
1
G
10
Page 11
INSTRUCTIONS FOR USE OF CLOCK
LED PROGRAMMER (Fig. 5)
GB
Features
24 hour clock with automatic programme and minute minder.
Functions
Cooking time, cooking end time, manual position, clock, minute minder, times to be set up to 23 hours 59 minutes.
Display
4-figures, 7-segments display for cooking times and time of day. Cooking time and manual function = saucepan symbol Automatic function = AUTO Minute minder = bell symbol The symbols light up when the corresponding functions are selected.
Minute minder
A U T O
Cooking time
Cooking end
Manual
Subtract time
Add time
Fig. 5
Setting
To set, press and release the desired function, and within 5 seconds set the time with + and - buttons.
+ and - buttons.
The + and - buttons increase or decrease the time at a speed depending on how long the button is pressed.
Setting the time
Press any two buttons (cooking time, end time, minute minder at the same time, and + or - button to set the desired time. This deletes any previously set programme and the AUTO symbol flashes.
Manual use
By pressing the manual button the AUTO symbol switches off and the saucepan symbol lights up. Manual operation can only be enabled after the automatic programme is over or it has been cancelled.
Automatic use
Press the cooking time or end time button to switch automatically from the manual to the automatic function.
Semi-automatic use with cooking time setting
Press the cooking time button and set the desired time with + or -. The AUTO and cooking time symbols light up continuously. The relay switches on immediately. When the cooking end time corresponds to the time of day, the relay and cooking time symbol switch off, the sound signal rings and the AUTO symbol flashes.
Semi-automatic use with end time setting
Press the end time button. The time of day appears on the display. Set the cooking end time with + button. The AUTO and cooking time symbols light up continuously. The relay contacts switch on. When the cooking end time corresponds to the time of day, the relay and the cooking time symbol switch off. When the cooking time is up, the AUTO symbol flashes, the sound signal rings and both the relay and the cooking time button switch off.
Automatic use with cooking time and end time setting
Press the cooking time button and select the length of the cooking time with + or - button. The AUTO and cooking time symbols light up continuously. The relay switches on. By pressing the cooking end time button the next cooking end time appears on the display. Set the cooking end time with + button.
11
Page 12
The relay and the cooking time symbol switch off. The symbol lights up again when the time of day corresponds to the cooking start time. When the cooking time is up, the AUTO symbol flashes, the sound signal rings, the cooking time symbol and the relay switch off.
Minute minder
Press the minute minder button and set the cooking time with + or - button. The bell symbol lights up when the minute minder is operating. When the set time is up, the audible signal rings and the bell symbol switches off.
Audible signal The audible signal starts at the end of a programme or of the minute minder function and it lasts for 15 minutes. To stop it, push any one of the function buttons.
GB
Start programme and check
The programme starts 4 seconds after it has been set. The programme can be checked at any time by pressing the corresponding button.
Setting error
A setting error is made if the time of day on the clock falls within the cooking start and end times. To correct the setting error, change the cooking time or cooking end time. The relays switch off when a setting error is made.
Cancelling a setting
To cancel a setting, press the cooking time button and then press the - button until 00 00 appears on the display. A set programme will automatically cancel on completion.
12
Page 13
GB
CARE AND MAINTENANCE
Before cleaning the appliance
mains gas tap and unplug the appliance or disconnect power at the main circuit breaker of the electrical system.
Do not clean appliance surfaces when still hot. Do not use steam cleaners to clean the oven.
ENAMELLED SURFACES
Clean with a damp sponge using soap and water. Grease can be easily removed using hot water or a specific cleansing agent for enamelled surfaces. Do not use abrasive cleansers. Do not leave any acid or alkaline substances (lemon juice, vinegar, salt, etc.) on the enamel. Clean the parts in stainless steel with specific cleansers for stainless steel surfaces. These detergents must be applied using a soft cloth.
, turn off the
CAUTION: Do not use rough or abrasive materials or sharp metal scrapers to clean the glass doors of the oven since they may scratch the surface and cause the glass to break.
GRIDS AND BURNERS
To clean the cooktop burners, remove by pulling upwards and soak them for approximately 10 minutes in hot water with a little detergent. After cleaning and washing them, dry them carefully.
Make sure that burner holes are not clogged.
Clean the burners once a week or more frequently if necessary. MAKE SURE YOU HAVE ASSEMBLED THE BURNERS CORRECTLY.
OVEN
Clean enamelled parts with a damp sponge using soap and water. Grease can be easily removed using hot water or a specific cleansing agent for enamelled surfaces. Do not use abrasive cleansers.
Install shelves by locating them in the horizontal guide rails on the oven walls.
13
Page 14
mod.
EKM 90460 X
mod.
EKM 90460 X
INSTRUCTIONS FOR THE USER
OVERALL DIMENSIONS
GB
min. 50 mm
min. 50 mm
h* = 115 / 165
mod.
EKM 10460 X
895
1000
815
600
600
960
755
h*
900
WARNINGS
Do not use the oven door handle to move the appliance, for example to remove it from the packaging. The appliance is in class 1 or class 2 subclass 1.
Fig.
min.100 mm
"0" mm "0" mm
7B
min. 650 mm
min. 400 mm
The cookers are fitted with 4 legs for easy adjustment of height to suit adjacent furniture (Fig. 8 / 8A).
Mod. EKM 90460 X (fig. 8).
To assemble legs, lift the cooker up and screw the four legs into the suitable threadings located at the corners on the underside of the appliance (fig 8).
OK NO
IMPORTANT:
Any adjacent furniture must be able to withstand high temperatures (min. 90°C). If the appliance is to be installed near units, leave the minimum gaps specified in figure 7B .
The cooker must not be placed on a pedestal
Fig.
8
Mod. EKM 10460 X (fig. 8A).
REG. MAX 15mm
Fig. 8A
14
Page 15
TO FIX THE COOKER TO THE REAR WALL
WARNING - For safety reasons and to prevent
tipping of the appliance, these stabilizing means must be installed. The cooker is equipped with 2 chains fixed on each side at the rear of the cooker near the top (see Fig. A). The chains are fitted with spring clips which must be clipped to the screw eyes provided with the cooker. Install the screw eyes as follows :
1. Drill four 6mm holes (position 1 - 2 - 3 - 4) in the wall as in Fig. A.
2. Insert part R into the holes then screw in the screw eyes part G see Fig. B. Note: If the part provided is not suitable for the wall material please use an appropriate device to ensure secure holding of the screw eyes to the wall.
3. Bring the cooker near the wall and clip the chains on the screw eyes as in Fig. C.
IMPORTANT: If the cooker is moved for any reason (e.g. maintenance) resulting in the cooker being unclipped from the wall, the cooker must be re-clipped to the wall at the completion of the task.
GB
55 mm
Position
2
Position
3
Fig. A
Fig. B
G R Hole
wall
Position
4
Fig. C
55 mm
Position
1
chain
G
76 mm
550 mm
wall
GAS CONNECTION
The gas and electricity connections and any adjustments must be made by specia lised staff.
This appliance shall be installed in accordance whit the regulations in force and only in a well­ventilated space. Read the instructions before installing or using this appliance.
IMPORTANT
We recommend to check wether the appliance has been foreseen for the kind of gas distributed. Conversion for use other gases must only be undertaken by a qualified person. For information for use on other gases contact your local Service Centre. The cooker must be installed by a qualified person, conforming to local regulations. Failure to install the appliance correctly could invalidate any
manufacturers warranty and lead to prosecution under the above quoted regulations.
Provision for Ventilation
The room containing the cooker should have an air supply in accordance with local regulations. Remember that the quantity of air necessary for combustion must never be less than 2m3/h for each kW of power (see total power in kW on the appliance data plate see fig. 9 ).
*
Fig. 9
15
Page 16
GB
Gas Safety (Installation & Use) Regulations
It is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Installation & Use Regulations. It is in your interest and that of safety to ensure compliance with the law.
For UK:
This appliance must be installed by a qualified electrician / competent person gas safe register. Safety may be impaired if installation is not carried out in accordance with these instructions. The appliance must be installed in accordance with All relevant British Standards (latest editions).
Gas Connection
Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the rating plate which can be found on the back cover. This appliance is not designed to be connected to a combustion products evacuation device. Particular attention should be given to the relevant requirements regarding ventilation.
Connection to the cooker should be made with connection in accordance with local regulations.
In order to guarantee that the cooker works safely and has a moderate energy consumption and long service life, you must ensure that the supply pressure corresponds to the values given in
table D.
If this is not the case, a special pressure regulator must be fitted to the gas supply pipe in accordance with the relevant standards. The cooker must be connected to the gas supply pipe such that the cooker is not subjected to any kind of stress.
A special valve for routinely turning the gas supply on/off must be installed between the gas inlet tube to the room and the hob, in order to cut off the gas supply after cooking in the event of accidents during cooking. This valve must be easily accessible at all times, and should be closed during long periods of no use.
The gas tube must be routed in such a way that it is not fed through hot areas and does not come into contact with any hot parts of the appliance, e.g. the underside of the hob. Tube installation must be carried out in such a way as to ensure that it runs freely and that it cannot come into contact with or be bent by any movable parts in the kitchen, e.g. drawers.
1/2
The cookers can be set for supply both on the right or lefthand side (fig 12). In this case it is sufficient to reverse the position of the cad nipple reducer. At the end make sure than there is no leakage of gas.
Warning: do not use flames to check any gas leakages.
INLET STOP
Fig. 12
16
Page 17
GB
GAS ADJUSTMENT
Always isolate the cooker from the electricity supply, shut off the gas supply temporarily and proceed as follows.
- change the injectors,
- adjust the minimum flow of the burners.
REPLACEMENT OF COOKTOP INJECTORS
To change the cooktop injectors, proceed as follows: remove the grids, remove burners and flame-spreaders (see fig. 13), change the injector (see fig. 14 and replace it with another one suitable for the new type of gas (see table D). Re-assemble everything in reverse order, ensuring you position the flame-spreader correctly.
Fig. 13
C
MINIMUM FLOW ADJUSTMENT FOR COOKTOP TAPS
To adjust the minimum, proceed as follows: switch the burner on, and turn the knob towards the minimum flow position . Remove the knob from the tap, introduce a small screwdriver in to the tap rod (fig. 15). Attention: in taps with security valve, the minimum adjustment screw Z is placed outside the tap rod (fig. 16).
Z
Fig. 15
Fig. 16
Loosen the adjustment screw in order to increase the flow or tighten it to decrease the flow. The proper adjustment is obtained when the flame is approximately 3 or 4 mm in length. For butane/propane gas, the adjustment screw must be fully screwed down. Make sure that the flame does not go out when passing quickly from the max. flow to the minimum flow . Assemble the knob again.
Fig. 14
C
C =
Injector
TAB. D
Kind of gas
128 NATURAL 20 101 G 20 77 141
BUTANE 28-30 87 G 30 66 PROPANE 37 50 G 31 96
triple crown
GENERAL INJECTORS TABLE
mbar
Nozzle
N° max.
Burners
Rapid Semi rapid Auxiliary
Triple crown
Rapid Semi rapid
Auxiliary
Triple crown
3,00
1,00
3,00
1,00
17
Power
1,75
3,80
1,75
3,80
Cat. II 2H3+
KW
Page 18
GB
ELECTRICAL CONNECTION
This appliance must be installed by a qualified person in accordance with the latest IEE Regulations and in compliance with the manufacturers instructions.
Check that the voltage is the same as that stated on the rating plate. The rating plate is located on the back cover.
WARNING! THIS APPLIANCE MUST BE EARTHED
If a fixed appliance is not equipped with supply cable and plug,
the power supply must be fitted with a disconnect switch in which the distance between contacts permits total disconnection in accordance with overvoltage category III, as required by installation regulations. We recommend that the cooker circuit is rated to 20 amps. Cable type HO5 RRF 3 X 2.5 mm
2
Connecting the mains cable (fig. 16A).
Open the mains terminal block cover as shown, unscrew screw A the cable clamp, and loosen the screws in the mains terminal block L N E which secure the three wires of the mains cable. Fit the cable and refit screw A, the cable clamp. Allow sufficient cable length for the cooker to be pulled out for cleaning, but do not let it hang lower than 50mm (2) from the floor. The cable can be looped if necessary, but make sure that it is not kinked or trapped when the cooker is in position.
IMPORTANT
The wires in the mains cable are coloured as follows:
GREEN AND YELLOW .....EARTH
BLUE .................................NEUTRAL
BROWN.............................LIVE
REPLACING
OF THE CABLE
If the cable becomes damaged or worn, replace it,
observing the following instructions:
- open the box of the supply board (see fig. 16A);
- unscrew screw A
that secures the cable;
- replace the cable with one of the same length and which corresponds to the features described off, and
-
connect the green-yellow earth wire to the
terminal  , leaving mm longer
-
connect the blue neutral wire to the terminal
marked N
-
connect the live wire to the terminal marked
L
.
in the table; switch the appliance
shut the gas tap;
it approximately 10
than the live wire;
;
Fig. 16A
18
Page 19
APPLIANCE MAINTENANCE
WARNINGS
Isolate the cooker from the electricity supply before attempting to replace the oven lamp. The oven lamp is of a special type designed to withstand high temperatures. To replace it, proceed as follows: remove the protective glass (A) and replace the burnt-out bulb with one of the same type (fig. 18). Re-fit the protective glass.
E 14 25 W - 230 V~ T300°C
A
Fig. 18
GB
19
Page 20
GB
For your safety
The product should only be used for its prescribed purpose, namely for domestic cooking of foodstuffs. Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified personnel.
ALWAYS Always make sure you understand the controls
before using the cooker. Always check that all controls on the cooker are turned off after use. Always stand back when opening an oven door to allow heat to disperse. Always use dry, good quality oven gloves when removing items from the oven. Always take care when removing items from the oven, as they may be dangerously hot. Always keep the oven doors closed when the cooker is not in use. Always place pans centrally over the burners and position them so that the handles cannot accidentally be caught or knocked or become heated by other burners. Always keep the cooker clean, as a build up of grease or fat from cooking can cause a fire. Always allow the cooker to cool before cleaning. Always follow the basic principles of food handling and hygiene to prevent proliferation of bacteria. Always keep ventilation grilles free from obstructions. Always turn off the electricity before cleaning or replacing an oven lamp.
NEVER Never allow children near the cooker when in
use as all surfaces will become hot during and after cooking. Never allow anyone to sit or stand on any part of the cooker. Never heat up unopened food containers as pressure can build up causing the container to burst. Never store chemicals, food stuffs, pressurised containers in or on the cooker, or in cabinets immediately above or next to the cooker. Never fill a deep fat frying pan more than1/3 full of fat or oil and never use a lid with this type of pan.
NEVER LEAVE PANS UNATTENDED WHILE COOKING. Never place flammable or plastic items on or
near the hob burners. Never use proprietary spillage collectors on the hob burners. Never use the cooker for the purpose of heating. Never dry clothes or place other items over or near to the hob burners or oven doors. Never wear garments with long wide sleeves whilst cooking. Never place flammable materials in the oven or the compartment below the oven. Never allow fat or oil to build up in the oven trays, grill pan or oven base. Never place cooking utensils or plates on the oven base. Never grill food containing fat without using the grill rack.
Never cover the grill rack with aluminium foil. Never place hot enamel parts in water, leave
them to cool first. Never allow vinegar, coffee, milk, saltwater, lemon or tomato juice to remain in contact with enamel parts (inside the oven and oven trays). Never use abrasive cleaners or powders since these could scratch the surface of the stainless steel and the enamel.
0051
Tip. Montagnani - Italy - cod. 537866 - B - 0309
Loading...
