USER MANUAL
KPK742220M
EN User Manual
Oven
www.aeg.com
2

CONTENTS

1. SAFETY INFORMATION.............................................................................................3
2. CONDITIONS OF USE................................................................................................4
3. SAFETY INSTRUCTIONS.............................................................................................4
4. PRODUCT DESCRIPTION...........................................................................................7
5. CONTROL PANEL....................................................................................................... 8
6. BEFORE FIRST USE................................................................................................... 10
7. DAILY USE..................................................................................................................10
8. CLOCK FUNCTIONS.................................................................................................14
9. AUTOMATIC PROGRAMMES.................................................................................. 15
10. USING THE ACCESSORIES....................................................................................16
11. ADDITIONAL FUNCTIONS.................................................................................... 19
12. HINTS AND TIPS..................................................................................................... 20
13. CARE AND CLEANING.......................................................................................... 35
14. TROUBLESHOOTING.............................................................................................37
15. INSTALLATION........................................................................................................39
16. ENERGY EFFICIENCY.............................................................................................42
17. WARRANTY .............................................................................................................43
Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
CUSTOMER CARE AND SERVICE
Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.
Warning / Caution-Safety information General information and tips Environmental information
Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
Do not let children play with the appliance.
Keep all packaging away from children and dispose of
it appropriately.
Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are hot.
If the appliance has a child safety device, this should
be activated.
Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
ENGLISH
3

General Safety

1.2
Only a qualified person must install this appliance and
replace the cable.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
www.aeg.com4
Always use oven gloves to remove or put in
accessories or ovenware.
Before carrying out any maintenance, disconnect the
appliance from the power supply.
Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
Do not use a steam cleaner to clean the appliance.
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
Use only the food sensor (core temperature sensor)
recommended for this appliance.
2.

CONDITIONS OF USE

This appliance is intended to be used in household and similar applications such as:
• Farm houses

3. SAFETY INSTRUCTIONS

3.1 Installation

WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instruction supplied with the appliance.
• By clients in serviced apartments, holiday apartments and other residential type environments.
• Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Keep the minimum distance from the other appliances and units.
• Make sure that the appliance is installed below and adjacent safe structures.
ENGLISH
5
• The sides of the appliance must stay adjacent to appliances or to units with the same height.
• The appliance is equipped with an electric cooling system. It must be operated with the electric power supply.

3.2 Electrical connection

WARNING!
Risk of fire and electrical shock.
• All electrical connections should be made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre.
• Do not let mains cables touch or come near the appliance door, especially when the door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it cannot be removed without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation
device must have a contact opening width of minimum 3 mm.
• This appliance complies with the E.E.C. Directives.

3.3 Use

WARNING!
Risk of injury, burns and electrical shock or explosion.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance door while the appliance is in operation. Hot air can release.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface or as a storage surface.
• Open the appliance door carefully. The use of ingredients with alcohol can cause a mixture of alcohol and air.
• Do not let sparks or open flames to come in contact with the appliance when you open the door.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the enamel:
– do not put ovenware or other
objects in the appliance directly on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you finish the cooking.
6
www.aeg.com
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or stainless steel has no effect on the performance of the appliance.
• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.
• This appliance is for cooking purposes only. It must not be used for other purposes, for example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a furniture panel (e.g. a door) make sure the door is never closed when the appliance is in operation. Heat and moisture can build up behind a closed furniture panel and cause subsequent damage to the appliance, the housing unit or the floor. Do not close the furniture panel until the appliance has cooled down completely after use.

3.4 Care and cleaning

WARNING!
Risk of injury, fire, or damage to the appliance.
• Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.
• Make sure the appliance is cold. There is the risk that the glass panels can break.
• Replace immediately the door glass panels when they are damaged. Contact the Authorised Service Centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use any abrasive products, abrasive cleaning pads, solvents or metal objects.
• If you use an oven spray, follow the safety instruction on it's packaging.
• Do not clean the catalytic enamel (if applicable) with any kind of detergent.

3.5 Pyrolytic cleaning

WARNING!
Risk of Injury / Fires / Chemical Emissions (Fumes) in Pyrolytic Mode.
• Before carrying out a Pyrolitic self­cleaning function or the First Use please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided with the product) particularly any non-stick pots, pans, trays, utensils etc.
• Read carefully all the instructions for Pyrolytic cleaning.
• Keep children away from the appliance while the Pyrolytic cleaning is in operation. The appliance becomes very hot and hot air is released from the front cooling vents.
• Pyrolytic cleaning is a high temperature operation that can release fumes from cooking residues and construction materials, as such consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
– provide good ventilation during
and after the first use at maximum temperature operation.
• Unlike all humans, some birds and reptiles can be extremely sensitive to potential fumes emitted during the cleaning process of all Pyrolytic Ovens.
– Remove any pets (especially birds)
from the vicinity of the appliance location during and after the Pyrolytic cleaning and first use maximum temperature operation to a well ventilated area.
• Small pets can also be highly sensitive to the localized temperature changes in the vicinity of all Pyrolytic Ovens when the Pyrolytic self cleaning program is in operation.
1 2
4
3
5 6
7
8
1
2
3
4
ENGLISH 7
• Non-stick surfaces on pots, pans, trays, utensils etc., can be damaged by the high temperature Pyrolytic cleaning operation of all Pyrolytic Ovens and can be also a source for low level harmful fumes.
• Fumes released from all Pyrolytic Ovens / Cooking Residues as described are not harmful to humans, including infants or persons with medical conditions.

3.6 Internal light

• The type of light bulb or halogen lamp used for this appliance is only for household appliances. Do not use it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect the appliance from the power supply.

4. PRODUCT DESCRIPTION

4.1 General overview

• Only use lamps with the same specifications.

3.7 Disposal

WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains electrical cable close to the appliance and dispose of it.
• Remove the door catch to prevent children or pets from becoming trapped in the appliance.

3.8 Service

• To repair the appliance contact an Authorised Service Centre.
• Use original spare parts only.
Control panel
1
Electronic programmer
2
Socket for the core temperature
3
sensor Heating element
4
Lamp
5
Fan
6
Shelf support, removable
7
Shelf positions
8

4.2 Accessories

Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
21 3 4 5 8 9 10 1176
www.aeg.com8
Grill- / Roasting pan
To bake and roast or as a pan to collect fat.
Trivet

5. CONTROL PANEL

5.1 Electronic programmer

For roasting and grilling.
Use the trivet only with the Grill- / Roasting pan.
Food Sensor
To measure the temperature inside the food.
Use the sensor fields to operate the appliance.
Sensor field
1
2
3
Function Comment
- Display Shows the current settings of the appliance.
ON / OFF To turn on and off the appliance.
Heating Functions or Assisted Cook­ing
Press the sensor field to choose the menu: Assis­ted Cooking or Heating Functions. To turn on or turn off the light, press the field for 3 seconds. You can turn on the light also when the appliance is turned off.
A
DE
B C
ENGLISH 9
10
11
Sensor field
4
5
6
7
8
9
Function Comment
Favourites To save and access your favourite programmes.
Temperature se­lection
Down key To move down in the menu.
Up key To move up in the menu.
OK To confirm the selection or setting.
Back key To go back one level in the menu. To show the
Time and addi­tional functions
Minute Minder To set the function: Minute Minder.
To set the temperature or show the current tem­perature in the appliance. Press the field for 3 sec­onds to turn on or turn off the function: Fast heat up.
main menu, press the field for 3 seconds.
To set different functions. When a heating func­tion operates, press the sensor field to set the tim­er or the functions: Function Lock, Favourites, Heat + Hold, Set + Go. You can also change the settings of the core temperature sensor.

5.2 Display

A. Heating function B. Time of day C. Heat-up indicator D. Temperature E. Duration time or end time of a
function
Other indicators of the display:
Symbol Function
Minute Minder The function operates.
Time of day The display shows the current time.
Duration The display shows the necessary time
for cooking.
www.aeg.com10
Symbol Function
End Time The display shows when the cooking
Temperature The display shows the temperature.
Time Indication The display shows how long the heat-
Calculation The appliance calculates the time for
Heat-up Indicator The display shows the temperature in
Fast Heat Up Indicator The function is active. It decreases the
Weight Automatic The display shows that the automatic
Heat + Hold The function is active.

6. BEFORE FIRST USE

time is complete.
ing function operates. Press and
at the same time to reset the time.
cooking.
the appliance.
heat up time.
weight system is active or that weight can be changed.
WARNING!
Refer to Safety chapters.

6.1 Initial Cleaning

Remove all accessories and removable shelf supports from the appliance.
Refer to "Care and cleaning" chapter.
Clean the appliance and the accessories before first use. Put the accessories and the removable shelf supports back to their initial position.

7. DAILY USE

WARNING!
Refer to Safety chapters.

7.1 Navigating the menus

1. Activate the appliance.

6.2 First Connection

When you connect the appliance to the mains or after the power cut, you have to set the language, the display contrast, the display brightness and the time of the day.
1. Press
2. Press to confirm.
2. Press or to select the menu
option.
3. Press to move to the submenu or
accept the setting.
or to set the value.
At each point you can go back to the main menu with
.

7.2 The menus in overview

Main menu
Sym­bol
Submenu for: Basic Settings
Sym­bol
Menu item Application
Heating Functions Contains a list of heating functions.
Assisted Cooking Contains a list of automatic programmes.
Favourites Contains a list of favourite cooking programmes
Pyrolysis Pyrolytic cleaning.
Basic Settings Used to set the appliance configuration.
Specials Contains a list of additional heating functions.
Submenu Description
Set Time of Day Sets the current time on the clock.
ENGLISH 11
created by the user.
Time Indication When ON, the display shows the current time
when you deactivate the appliance.
Fast heat up When ON, the function decreases the heat-up
time.
Set + Go To set a function and activate it later with a press
of any symbol on the control panel.
Heat + Hold Keeps the prepared food warm for 30 minutes af-
ter a cooking cycle finished.
Time Extension Activates and deactivates the time extension
function.
Display Contrast Adjusts the display contrast by degrees.
Display Brightness Adjusts the display brightness by degrees.
Set Language Sets the language for the display.
Buzzer Volume Adjusts the volume of press-tones and signals by
degrees.
www.aeg.com12
Sym­bol
Submenu Description
Key Tones Activates and deactivates the tone of the touch
fields. It is not possible to deactivate the tone of the ON / OFF touch field.
Alarm/Error Tones Activates and deactivates the alarm tones.
DEMO mode Activation / deactivation code: 2468
Cleaning Reminder Reminds you when to clean the appliance.
Service Shows the software version and configuration.
Factory Settings Resets all settings to factory settings.

7.3 Heating Functions

Heating function Application
True Fan Cooking To bake on up to two shelf positions at the same
time and to dry food. Set the temperature 20 - 40 °C lower than for the function: Conventional Cooking.
Pizza Setting To bake food on one shelf position for a more in-
tensive browning and a crispy bottom. Set the temperature 20 - 40 °C lower than for the func­tion: Conventional Cooking.
Conventional Cooking (Top / Bottom Heat)
To bake and roast food on one shelf position.
Frozen Foods To make convenience food like e.g. french fries,
potato wedges or spring rolls crispy.
Grilling To grill flat food and to toast bread.
Turbo Grilling To bake cakes with crispy bottom and to preserve
food.
Bottom Heat To bake cakes with crispy bottom and to preserve
food.
Heating function Application
Moist Fan Baking To bake breads, cakes and cookies. To save ener-
gy during cooking. This function must be used in accordance with the Moist Fan Baking table in or­der to achieve the desired cooking result. To get more information about the recommended set­tings, refer to the Hints and Tips chapter, Moist Fan Baking table. This function was used to define the energy efficiency class acc. to EN 60350-1.
The lamp may automatically deactivate at a temperature below 60 °C during some oven functions.

7.4 Specials

Heating function Application
Keep Warm To keep food warm.
Plate Warming To preheat plates for serving.
ENGLISH 13
Preserving To make vegetable preserves such as pickles.
Drying To dry sliced fruit (e.g. apples, plums, peaches)
Dough Proving For controlled rising of yeast dough before bak-
Slow Cooking To prepare tender, succulent roasts.
Bread Baking To bake bread.
Defrost This function can be used for defrosting frozen

7.5 Activating a heating function

1. Activate the appliance.
2. Select the menu: Heating Functions.
and vegetables (e.g. tomatoes, zucchini, mush­rooms).
ing.
foods, such as vegetables and fruits. The defrost­ing time depends on the amount and size of the frozen food.
3. Press to confirm.
4. Select a heating function.
5. Press to confirm.
6. Set the temperature.
14
www.aeg.com
7. Press to confirm.

7.6 Heat-up indicator

When you activate a heating function, the bar on the display comes on. The bar shows that the temperature increases. When temperature is reached the buzzer sounds 3 times and the bar flashes and then disappears.

7.7 Fast Heat Up Indicator

This function decreases the heat-up time.

8. CLOCK FUNCTIONS

8.1 Clock functions table

Clock function Application
Minute Minder To set a countdown (max. 2 h 30 min). This
Duration To set the length of an operation (max. 23 h
End Time To set the switch-off time for a heating func-
Do not put food in the oven when the Fast heat up function operates.
To activate the function, hold for 3 seconds. The heat-up indicator alternates.

7.8 Residual heat

When you turn off the oven, the display shows the residual heat. You can use the heat to keep the food warm.
function has no effect on the operation of the appliance. You can also activate it when the appliance is deactivated.
Use to activate the function. Press or
to set the minutes and to start.
59 min).
tion (max. 23 h 59 min).
If you set the time for a clock function, the time starts to count down after 5 seconds.
If you use the clock functions: Duration, End Time, the appliance deactivates the heating elements after 90 % of the set time. The appliance uses the residual heat to continue the cooking process until the time ends (3 - 20 minutes).

8.2 Setting the clock functions

Before you use the functions: Duration, End Time, you must set a heating function and temperature first. The appliance deactivates automatically. You can use the functions: Duration and End Time at the same time if you want to automatically activate and deactivate the appliance on a given time later. The functions: Duration and End Time do not work when you use the core temperature sensor.
1. Set a heating function.
ENGLISH
15
2. Press again and again until the
display shows the necessary clock function and the related symbol.
3. Press or to set the necessary
time.
4. Press When the time ends, an acoustic signal sounds. The appliance deactivates. The display shows a message.
5. Press any symbol to stop the signal.
to confirm.

8.3 Heat + Hold

Conditions for the function:
• The set temperature is more than 80 °C.
• The function: Duration is set.
The function: Heat + Hold keeps prepared food warm at 80 °C for 30 minutes. It activates after the baking or roasting procedure ends.
You can activate or deactivate the function in the menu: Basic Settings.
1. Activate the appliance.
2. Select the heating function.
3. Set the temperature above 80 °C.
9.

AUTOMATIC PROGRAMMES

4. Press again and again until the
display shows: Heat + Hold.
5. Press to confirm. When the function ends, an acoustic signal sounds. The function stays on if you change the heating functions.

8.4 Time Extension

The function: Time Extension makes the heating function continue after the end of Duration.
Applicable to all heating functions with Duration or Weight Automatic. Not applicable to heating functions with the core temperature sensor.
1.
When the cooking time ends, an acoustic signal sounds. Press any symbol.
The display shows the message.
2. Press
3. Set the length of the function.
4. Press
to activate or to cancel.
.
WARNING!
Refer to Safety chapters.

9.1 Recipes online

You can find the recipes for the automatic programmes specified for this appliance on our website. To find the proper Recipe Book check the PNC number on the rating plate on the front frame of the appliance cavity.
9.2 Assisted Cooking with
Recipe Automatic
This appliance has a set of recipes you can use. The recipes are fixed and you cannot change them.
1. Activate the appliance.
2. Select the menu: Assisted Cooking.
Press
3. Select the category and dish. Press
4. Select a recipe. Press
to confirm.
to confirm.
to confirm.
When you use the function: Manual, the appliance uses the automatic settings. You can change them as with other functions.

9.3 Assisted Cooking with Weight Automatic

This function automatically calculates the roasting time. To use it, it is necessary to input the food weight.
1. Activate the appliance.
2. Select the menu: Assisted Cooking.
Press to confirm.
Loading...
+ 32 hidden pages
